Asko W600 User manual

Model W600
(WM-33)
Page
Date
2000-02 1
INDEX
W600 WASHER
(WM-33)
ll PROGRAMS 2
ll DETERGENT DRAWER 4
ll SPARE PARTS LISTS
♦♦ Casing and related parts 6
♦♦ Lower section 8
♦♦ Cylinder and related parts 10
♦♦Control panel 12
♦♦ Upper section 14
ll SERVICE INFORMATION
♦♦ Front door seal 16
♦♦ Wiring information 17
♦♦ Timer unit program 18
♦♦ Water levels 19
♦♦ Fault indications 20
♦♦Fault tracing 22
♦♦Motor brushes 24
♦♦Spring legs 25

Model W600
(WM-33)
Date
2000-02 Page
2
PROGRAMS
THE CONTROL PANEL
Program Recommended Temp.
Number Program Types of Laundry Range (° F)
1White cotton w/prewash For heavily soiled cotton 140–205
2White cotton w/short prewash For normally soiled cotton 140–205
3Normal For lightly soiled cottons & colorfast fabrics 105–140
4Rinse
5Long spin
6Permanent Press/Synthetics For acrylic, polyester 105–140
7Super quick wash For lightly soiled fabrics 85–105
8Short spin
9Wool/Hand wash For silk, nylon, washable wool 85–105
10 Drain
CAUTION! Some fabrics may not be able to withstand extremely hot temperatures.
Please refer to the Recommended Wash Temperatures chart in the Use and
Care Guide.
PROGRAMS
Your ASKO washer has several programs and options specifically designed to give you the cleanest
laundrypossible.Thetablesbelowdefineeachprogramandoption.TheCand SontheProgramControl
are fault codes, which are explained on the next page.
Power Button
The Power button turns the power to the machine on and off. When the power is on, the power
indicator light glows red. The power must be on before you can open the door, set the programs
or start the machine.
Door Open Button
The power mustbe on and you mustpress this button to openthe door. There will be a few seconds
delay before the door opens. Please note that the Program Control knob must be at the end of a
program (at a red mark) to open the glass door. (See also, “Interrupting or Changing a Program”
on the next page.)
For instructions on how to open the door manually in case of power failure, refer tothe Use and Care Guide.
800
65
85
105
120
140
160
170
0
205
10
123
4
5
7
9
8
6
CS
E2
Door Open Button
Press to open the glass door. Please note
that the Program Control knob must be at
the end of a program (at a red mark) to open
the glass door.
Super Rinse Button
Press to program
seven rinses.
Economy Button
Press to extend the wash time
by 22 minutes. (Suggested for
use only with the low wash
temperatures.)
Power Button
Press to turn on power
to the machine.
Program Control
Turn clockwise to
select a program.
Power Indicator Light
Glows when the
power is turned on.
Temperature Control
Turn clockwise to set the
wash temperature.
800 RPM Spin Button
Press to reduce spin
speed from 1000 rpm to
800 rpm.
No Spin Button
Press to omit the
spin cycles.

Model W600
(WM-33)
Page
Date
2000-02 3
PROGRAMS
DefinitionOption
Super Rinse – Provides two additional rinses. Recommended for persons with sensitive
skin or allergies.
Economy – Extends the main wash time by 22 minutes. When used with low wash
temperatures (85°–100° F), this program conserves energy but gives the same high level of
cleaning. Note: You can only use this option with programs 1, 2, and 3.
E2
Reduces the spin speed from 1000 rpm to 800 rpm.
800
No Spin – Omits the spin cycles in all programs. Programs 1–4 will drain the water after the
last rinse. Programs 6, 7, and 9 will stop with water still in the machine. Set the Program
Control knob to 10 to drain the water.
OPTIONS
INTERRUPTING OR CHANGING A PROGRAM
Ifyouneedtostoporinterrupta program after you start the machine, turn the Program Control knob to 10
(Drain). Any water in the machine will be pumped out. Press the Door Open button to open the door. (It
won’t open until the water is out.) To restart the washer, close the door, add detergent (if needed), and
turn the controls to the desired settings.

Model W600
(WM-33)
Date
2000-02 Page
4
DETERGENT DRAWER
THE DETERGENT DRAWER
The detergent drawer on ASKO washers automatically dispenses the detergent and fabric softener at
theappropriatetimes.The drawer is located to the left of the control panel. Simply pull the drawer out and
pour the measured amounts of detergent and softener into the proper compartments (as illustrated) and
close the drawer.
DETERGENT AND FABRIC SOFTENER AMOUNTS
BecauseASKOwashersuseless water than conventional top-loading washers, you need less detergent
andfabricsoftener.Werecommend that you use a low-sudsing powder detergent only, preferably a high-
efficiency(HE)detergent designed specifically for front-loading washers. (Liquid detergents tend to suds
more, which make them more difficult to rinse out.)
Detergent – The amount of detergent needed varies, depending on the detergent you use. For high-
efficiency detergent specifically for front-loading washers, you should use the amounts recommended
by the manufacturer. For regular laundry detergent, 1 to 3 tablespoonsof detergent is all you need for
a normal wash load. More heavily soiled items, however, may need slightly more detergent. Also, the
amount of detergent needed can vary due to differences in water hardness. (Refer to the Use and Care
Guide for more details.) If you choose to use a liquid detergent, start out with a very small amount, such
as one or two tablespoons.
Fabric Softener – We recommend that you use only 2 tablespoons of fabric softener.If more softening
is desired, try using slightly more with the next load.
Prewash detergent
Main wash
detergent
Fabric
softener
We recommend that you don’t use bleach in an ASKO washer. The tumbling
wash action, temperature control options and extended wash times are sufficient
to remove most stains.
NOTE:
The detergent drawer is equipped with an
optional child safety catch. (See the Use and
CareGuide.)

Model W600
(WM-33)
Page
Date
2000-02 5
This page intentionally blank.

Model W600 (WM-33)
Date
2000-02 Page 6CASING AND RELATED PARTS

Model W600 (WM-33)
Page
Description
Fig.PartNo. Notes
Date
2000-02
Qty
7CASING AND RELATED PARTS
1 1 8061817-0 TopCover,white
38900338 Screw RTK STt 4.2x9.5 FZB T20
28901413 Lock washer AZ 4.3 galv.
3 1 8064062 Strip, top cover WMD20
6 1 8801174-0 Side plate compl. WM20
7 2 8061763 Guide,front plate/topcover
8 3 8061916 Cableholder WMD20
928061713 Holder hose, side plate
10 28061623 Plastic bracket, front plate/2
11 18064017 Soundinsulation,outlethose
12 18063925-0 Front plate compl., white WM20
28900327 Screw RTS ST 4.2x13 FZB T20
14 28063371 Guide,frontplate
23 18061657-0 Dooroutletpump WM20
27 18061737 Rear panel WM20
88900338 Screw RTK ST 4.2x9.5 FZB T20
31 18061693 Transport Beam
18901413 Lock washer AZ 4.3 galv.
48900338 Screw RTK ST 4.2x9.5 FZB T20
33 38061735-UL Transport sleeve WM20
34 38901940 Screw M6S M8x70 FZB w/guide
35 38061767 Locking washer, transport beam WM20
36 28061799 Holder hose, rear panel
37 18056950 Connectionpipe W-1500-15-3/4"-3/

Model W600 (WM-33)
Date
2000-02 Page 8LOWER SECTION

Model W600 (WM-33)
Page
Description
Fig.PartNo. Notes
Date
2000-02
Qty
9LOWER SECTION
1 1 8801171 Spring leg kit WM20
2 4 8055796 Rubber buffer, spring leg
3 4 8055797 Rubber buffer, spring leg
4 4 8061668 Rubber Damper, spring leg
433256445 Washer, spring leg 37x37x2
48901193 Lockingnut 8BHBgalv.
68901343 Washer SRKB 11x28x2 FZB
6 1 8061772 Motor 60 Hz WM33/44
7 2 8058261 Spac. tube motor suspension 12x191
828063591 Screw 8.8 M8x205 FZB
18901337 Washer BRB 8.4x16 HB 200 galv.
28901155 Nut M6M8BH8,galv.
10 18086801 Cable set E60-MO WM44/33 (P)
15 18061681 Bellows hose outlet pump WM20
16 18063262 Hoseclip 80.0-708
17 18056471 Hoseclip
18 18052083 Hoseclip RFZ 39.6-706R
19 18061924 Pressure chamber WM20
20 17382670 Rubber hose 5x8x550
21 18801167 Drain pump sync. han. compl. WM20
22 28061649 Rubber buffer, drain pump WM20
23 18061796 Rubberring,drainpump WM20
24 18061725 Drain hose 180mm, WM20
18052731 Hoseclip OETIKER14.8-706R
26 18061998 Outlet hose WM20
18056491 Hoseclip 30.1-708
28 133700183 TerminalESPA
18901097 Screw MRT-11 rx12 FZB T20
18901413 Lock washer AZ 4.3 galv.
30 18061738 Thermistor holder WM20
31 18061663 Thermistor (E30)
28061976 Cable holder, small
18054485 Cable strip T50RSF/PH
34 18061674 Recirculationstub
35 18061673 Grommet, recirc. stub
36 18061945 Hose, recirculation curved 345 mm
38 38054196 Hoseclip FZB 22.8-25.6
40 18061706 Heating element 2000W, 230V
133700450 Cable strip T 30 R

Model W600 (WM-33)
Date
2000-02 Page10CYLINDER AND RELATED PARTS

Model W600 (WM-33)
Page
Description
Fig.PartNo. Notes
Date
2000-02
Qty
11CYLINDER AND RELATED PARTS
1 1 8061650-0 Frontdoorcompl.,white WM20
18061651-0 Frame, front door, outer, white WM20
18061652-0 Frame, front door, inner, white WM20
18061685 Frontglass D306x42mm, WM20
18061798 Lock hook WM20
18061653 Seal, front door
48061624 Securing plate, front glass
18061686-0 Hinge,frontdoor, white WM20
18061687 Shaft for himge WM20
28901969 Screw MRT-TT 5x12 FZB T25
11 18061671-0 Cover plate, outer, white
13 18061980 Gap sealing, lower WM20
14 28061616 Gapsealing,side WM20
15 18061670 Cover plate, inner
16 28061678 Damper weight
38901135 Screw M6SF-TT8x25,DRILOC,FZB
18 18061679 Doorlock WM20
19 18061780 Emergencyopening,compl. WM20
20 18061680-UL Contact guard, door lock WM20
21 18061677 Frontpanel,tub WM20
22 18061889 Sealing strip, front panel (tub)
23 18061669 Tensionring WM20
18901335 Washer BRB 6.4x12 HB 200 Galv.
18901154 Nut M6BH8,Galv.
18901116 Screw MC6S 6x85, 8.8 FZB
25 18061600 Cylinder,compl. WM20
26 38061604 Drumpaddle WM20
27 18061682 Drivebelt 5EPJ 1209
28 18058497 O-Ring 26.2x3 NBR70, DW95
29 18061638 V-ring cassette, compl.
30 28056314 Ballbearing 6206 2RS MTSRL
31 18801165 Container compl. WM20
32 18056810 Scale washer 37x30.5x0.5
33 18056376 Pulley,compl. D292
18057209 Washer 42x10x4
18901052 Screw BUFO8.8,10s25, galv.

Model W600 (WM-33)
Date
2000-02 Page12
CONTROL PANEL

Model W600 (WM-33)
Page
Description
Fig.PartNo. Notes
Date
2000-02
Qty
13CONTROL PANEL
1 1 8063838-0-UL Panel w/handle
48901591 Bindingclip SCO 5740
3 1 8063354-49 Plate,prog.info, English
18063374-49 Plate,prog.info,Spanish
18063366-49 Plate,prog. info,French
4 1 8061630 Detergent compartment WM20
5 1 8061633 Divider detergent compartment
6 1 8061634 Siphon WM20
8 1 8061621-34 Safety catch handle, red
9 1 8061622 Spring, safety catch handle
10 18064010 Spacing sleeve, safety catch
11 68061711-0 Pushbutton WMD20
12 28061892-0 Knob, temp/timer w/clips WMD20
15 18061822 Decor Lens
16 18060478 Indicator lamp (UL-recognized)
17 18061709-0 Safety catch, temperature White, WM20
18 18063974 Tension spring, safety catch Temperature

Model W600 (WM-33)
Date
2000-02 Page14UPPER SECTION

Model W600 (WM-33)
Page
Description
Fig.PartNo. Notes
Date
2000-02
Qty
15UPPER SECTION
1 1 8061690 Beam front WM20
18900338 Screw RTK ST 4.2x9.5 FZBT20
3 1 8061661 Detergent compartment
28901970 Screw PTK 40x14 A2 WN1452 T20
18902072 Screw PT KB40X10, WN1442, galv.
6 1 8061628 Bellows hose, inlet WM20
7 1 8063607 Hoseclip 57.5-708
8 3 8061702 Rubber hose 10x15x300
38056656 Cable strip
10 18061736 Ventilationhosw WM20
18052730 Hoseclip OETIKER21.0-706R
15 18061757 Inlet valve, 3-way WM20
28901097 Screw MRT-TT 4x12 FZB T20
17 18061875 Pushbutton switch 2-pole clos.
18 18063719 Pushbutton switch 1 clos. MOM. UL3
19 48063717 Pushbutton switch 1 clos., UL3
22 18061665 RotarySwitch,BCD
25 18061756 Timer WM33/44 60HZ
26 18061692 Bracket for Elec. comp. WM20
28900338 Screw RTK ST 4.2X9.5 FZB T20
18900327 Screw RTS ST 4.2X13 FZB T20
30 18061664 Pressure sensor Type 1166
31 18061747 Level switch WM20
32 18003641 Rubber hose 5x8x45
33 17382985 Rubber hose 5x8x100
34 18051843 Y-pipe 05
35 18061997 Guard, level switch hose WM20
28061975 Cableholder,big
37 18061694 Crossbeam
48900327 Screw RTS ST 4.2x13 FZB T20
39 18061660 Terminal block, 5-pole
18901097 Screw MRT-TT 4x12 FZB T20
41 18060956 Cord set UL 250V/20A
42 18058558 Radio interference sup. filter
18901419 Lock washer AZ8.4,galv.
18901168 Nut ML6M8FZB
44 28054613 Fuseholder HTB38
45 28055725 Fuse holder insert STI
46 28058140 Fuse 15AT 6.3x32
47 28061923 Balancingspring WM20
18063858 Use and Care Guide WM20

SERVICE
I N F O R M A T I O N
Product: Frontloaded
Date: 00-06-14
Reference:Bo Fredriksson
Group: 21
Num er: 158
ÄO: 7782 Page: 1(1)
Front door seal
WM 33/44/55
Placement of O-ring
Figur 1
Service intervention for leaking front door.
First verify that the door seal is not damaged or covered by lose particles.
In order to increase the sealing strip pressure against the sealing surface of the container, a special O-
ring (part no. 806 178) has been designed.
As of Week 19, 2000, the front door O-ring is factory installed on all WMC 55 Professional models.
The front door O-ring can be fitted on earlier WMC 55 models as well as on WMC 33- -55-66 to
remedy a leaking front door seal.
Fitting the front door O-ring, part no. 80641 8
Fit the O-ring by placing it on the outside, covering the sealing strip (see picture) between the plastic
part of the door and the sealing strip. See the figure.

SERVICE
I N F O R M A T I O N
Product: WM 33/44/55/66
Date: 00-03-15
Reference: Per Svensson
Group: 21
umber: 149
ÄO: 7301 Page: 1(1)
DL1
DL2
DL3
grey
1
2
3
1
2
3
Wiring information
Door lock WM 33, 44, 55, 66
A modification to door hinge article no. 8 61679 has led to the following changes:
1. Door hinge is now labelled (wiring information 1, 2, 3).
2. Leads DL1 and DL3 have swapped markings.
3. Wiring diagram has changed. Diagrams 061751 rev. 00 and 061753 rev 00 have been replaced
by rev. 01.
These changes have been made to machines manufactured after week 22, 1999.
New marking WM 33/44.
Individual leads
Lead marked DL 1 colour grey/red
Lead marked DL 2 colour grey
Lead marked DL 3 orange
New marking WM 55/66.
Connector block
Lead marked DL 1 colour grey
Lead marked DL 2 colour grey
Lead marked DL 3 colour grey
DL 1 grey/red
DL 2 grey
DL 3 orange
Previous marking
WM 33/44
DL 3 grey/red
DL 2 grey
DL 1 orange
Previous marking
WM 55/66
DL 3 grey
DL 2 grey
DL 1 grey
NOTE!
Incorrect connection will cause a short-circuit.
The relative positions are unchanged. It is only the markings on the leads that have changed

SERVICE
I N F O R M A T I O N
Product:WM 33 / 44
Date:00-06-14
Reference: N-Å Carlsson
Group: 1
Number: 159
ÄO: 7743 Page: 1(1)
Change in timer unit pro-
gramme WM 33/44 60 Hz
ASKO WM 33/44 8061756
230V 60 Hz
3320 BB01 10/2000
The timer unit software has been inproved to withstand frequency variations from the power
source.
This change has been implemented on units manufactured after week 13, 2000. The part number of the
timer unit does not change.
Timer units manufactured from week 10, 2000 or later are fitted with the new machine programme.
Check the label on the side of the timer unit
If the programme unit stops at C = (Check)
Check the following before replacing the programme unit.
Possib e error causes:
Thermistor fault
The thermistor output is closed or fully open.
Heating element fault
The set temperature was not reached within:
2 minutes using the Cotton programme or 80 minutes for other programmes.
Water level fault
Overfilling. The mechanical and electronic level guard will indicate a water level fault if the level has not
been reached within minutes or if the level has not been reached within 3 minutes when draining.
Level guard fault
The machine does not heat; it takes too long time (approx. 3 hours).
If the machine does not exhibit any of the above faults, but instead carries out all the programme steps
and then stops at C, then the programme unit should be replaced.

SERVICE
I N F O R M A T I O N
Product: WM 33/44/55/66
Date:00-03-15
Reference: Christer Carlsson
Grou : 21
Number: 150
ÄO: Page: 1(1)
Measurement must be carried out without laundry in machine.
Rinse level for other programmes approx. 9.5 litres
Level with bottom edge of glass
Water levels
WM 33 44 55 66
Wool wash level approx. 16.5 litres
(Wash and rinse levels are the same)
Approx. 4 cm
Main wash level approx. 7.5 litres
Level with bend in front rim of drum

SERVICE
I N F O R M A T I O N
Product: WM 33 / 44
Date: 00-03-15
Reference: N-Å Carlsson
Group: 1
Number: 151
ÄO: Page: 1( )
Description of fault indications
Description of probabable cause when timer stops in position C (Check) or S (Safety)
In position C, the kind of fault can be checked by yourself, see service manual, but
faults in position S are often of more serious kind and requires service action.
C CHECK STEP
Thermistor fault
Indicated when the out gate for the thermistor is closed or fully open
Heating element fault
Indicated when temperature setting not has been reached within:
25 minutes for wool wash cycle,
80 minutes for other cycles.
Timer fault
Indicated when the code transmission in the control unit is incorrect.
Water inlet fault
Indicated when over filling is sensed by the mechanical or electronical
level switch/sensor:
If the set level not is reached within 5 minutes
or if drain level not is passed within minutes.
S SAFETY STEP
Motor fault
Indicated if the tacho generator gates or the triac are short
cut or open, or if the safety relay KL1 is open
Pressure sensor fault
Indicated when water inlet to wash level or rinse level is not reached within 5 minutes,
though the mechanical level switch is operating at setted level.
WM 33/44 (Timer)
