aspenhome Combo File IHP-378-FSL User manual

12-26-2016
Page1/2
ITEMNO:IHP-378-FSLComboFile
Thankyou for purchasing thisqualityproduct.Besuretocheckallpacking material carefullyfor
small partsthatmaycomelooseinsidethecartonduringshipment.
BEFOREUSINGTHISPRODUCTPLEASEREAD,UNDERSTAND,ANDFOLLOWTHESEINSTRUCTIONS.
Savetheseinstructionsforfuturereference. FORINDOORUSEONLY
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
COMPONENTS LIST:
No. Description Sketch Quantity
1Case 1PC
2MetalBase 2PCS
TOOLSREQUIRED(NOTPROVIDED)
PHILLIPS SCREWDRIVER
STEP1:Putthecasebacksidedownon asoftsurface.Matchthehole
patternonmetalbasestothethreadedinsertsonthebottomandattachto
thebottomof thecasebyusing8bolts(A),lockwashers(B)and flat
washers(C). Turnthecasetotheuprightposition.
Removethewoodscrews
onthebackpanelsof
drawerboxtoremovethe
rodloopsandfilerodsif
necessary.
FUNCTIONALITY INSTRUCTION
Leveleronmetalbases
Adjusttheleveler
whennecessary
Heavy Duty Ball Bearing Slide
Lockingfiledrawershold
letter or legal size files
Case
Bottom
MetalBase
A
B
C
D
HARDWARELIST:
No. Description Sketch Quantity
ABolt 5/16"*1" 8PCS
BLockWasher5/16" 8PCS
CFlatWasher5/16"*3/4" 8PCS
DAllenWrench 1PC

Hook
Drawer rail
Pushthistabin
To removethedrawer,pleaseremovethesetscrewson two sides
ofthedrawers.Push thetabintoward thedrawerand liftup the
drawertomoveout.
To installthedrawer,pleaseextend theslidesall theway out.Set
thedrawerbox intocabinetrailand slideback so thedrawer rail
goesunderthehook in cabinetrail.Thensnap thetab into drawer
railandreplacesetscrews.
Setscrew
Cabinetrail
Instructionfor theFileDrawerwithHeavyDutyBall Bearing Slides
12-26-2016
Page2/2
ITEMNO:IHP-378-FSLComboFile
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
ah
