aspenhome ICB-492-BCH-KD-1 User manual

Page1/3
Thankyou for purchasing thisqualityproduct.Besuretocheckallpacking material carefullyfor
small partsthatmaycomelooseinsidethecartonduringshipment.
UNITSHOULDBEINSTALLEDBY2ORMOREPERSONS.
BEFOREUSINGTHISPRODUCTPLEASEREAD,UNDERSTAND,ANDFOLLOWTHESEINSTRUCTIONS.
Savetheseinstructionsforfuturereference.
All Bedsneedtobeset upintheexact final
locationsothatafterfullassemblyit will not
needtobemoved. Moving thebedwill cause
thesupport legstomoveoutof perpendicular
(90 degree),weakenthesupportsystem, and
mayallowthebedtocollapse.
FORINDOORUSEONLY
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
ICB-403
ICB-402L
ICB-492
TOOLSREQUIRED(NOTPROVIDED)
PHILLIPS SCREWDRIVER
COMPONENTS LIST:ICB-403
No. Description Sketch Quantity
1Footboard 1PC
2BunFoot 2PCS
3Supportlegswithleveler 4PCS
HARDWARELIST:ICB-492
No. Description Sketch Quantity
ABolt 5/16"*1-3/4" 8PCS
BLockWasher 5/16" 8PCS
CFlatWasher 5/16" 8PCS
DAllenWrench5mm 1PC
HARDWARELIST:ICB-402L
No. Description Sketch Quantity
EWoodScrew 8PCS
FAllenWrench4mm 1PC
COMPONENTS LIST:ICB-402L
No. Description Sketch Quantity
1Bedrails 2PCS
2Slats 4PCS
COMPONENTS LIST:ICB-492
No. Description Sketch Quantity
1Headboard 1PC
2LeftLeg 1PC
3RightLeg 1PC
4WoodStretcher 1PC
10-26-2017
ITEMNO:ICB-492-BCH/BLK/EGG/GRY-KD-1QueenFramedPanel HB
ICB-402L-BCH/BLK/EGG/GRY-1 QueenSideRails
ICB-403-BCH/BLK/EGG/GRY-1QueenLow Profile FB

10-26-2017
Page2/3
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
STEP3:Layfootboard backdownon apadded,cleansurface.Attachbun feet tofootboard. Turn
footboardrightsideup.
Bun Foot
b
a
WoodScrew
Slatbearer
SideRail
STEP4:Theslat bearershavebeenattachedinpositionb. Theslat bearerscanbemovedinto
positionadependingonthemattress/platformconfiguration.Removetheboltsand screws from
theslatbearersandsiderailsasshownbelow.Thenre-attachtheslatbearerstothesiderailsin
desiredpositionwithbolts,lockwashers,flatwashers, and screws. Caution:Donot overtighten
boltsasthismayloosenthethreadedinsertsinthesiderails.
Footboard
ITEMNO:ICB-492-BCH/BLK/EGG/GRY-KD-1QueenFramedPanel HB
ICB-402L-BCH/BLK/EGG/GRY-1 QueenSideRails
ICB-403-BCH/BLK/EGG/GRY-1QueenLow Profile FB
A
B
C
D
A
B
C
D
LeftLeg
RightLeg
Headboard
STEP1:Laytheheadboardfacedownon a
softsurface.Attachtheleftlegand right leg
toheadboardby using 6bolts(A), lock
washers(B)andflatwashers(C).
STEP2:Attachthewoodstretcher
tothelegsbyusing2bolts(A), lock
washers(B)andflatwashers(C).
LeftLeg
RightLeg
Headboard
WoodStretcher

10-26-2017
Page3/3
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
STEP5:Hookthesiderailstotheheadboardandfootboard.
Headboard Slatbearer
SideRail
SideRail
SideRail
STEP6:Attachthesupportlegswithlevelertotheslats.
Adjustthelevelersonbottom ofsupportlegswhennecessary. SupportLeg
Leveler
ThisEndUp
Slat
STEP7:Arrangetheslatsontheslatbearersequally
andattachtotheslatbearerswithwoodscrews (E).
WoodScrews(E)
FUNCTIONALITY INSTRUCTION
Headboard
Footboard
ITEMNO:ICB-492-BCH/BLK/EGG/GRY-KD-1QueenFramedPanel HB
ICB-402L-BCH/BLK/EGG/GRY-1 QueenSideRails
ICB-403-BCH/BLK/EGG/GRY-1QueenLow Profile FB
ICB-403
ICB-402L
ICB-492
1PoweredUSBPortfor
Charging on bothsides

10-26-2017
Page1/5
Thankyou for purchasing thisqualityproduct.Besuretocheckallpacking material carefullyfor
small partsthatmaycomelooseinsidethecartonduringshipment.
UNITSHOULDBEINSTALLEDBY2ORMOREPERSONS.
BEFOREUSINGTHISPRODUCTPLEASEREAD,UNDERSTAND,ANDFOLLOWTHESEINSTRUCTIONS.
Savetheseinstructionsforfuturereference.
All Bedsneedtobeset upintheexact final
locationsothatafterfullassemblyit will not
needtobemoved. Moving thebedwill cause
thesupport legstomoveoutof perpendicular
(90 degree),weakenthesupportsystem, and
mayallowthebedtocollapse.
FORINDOORUSEONLY
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
ICB-403D
ICB-402L
ICB-492
TOOLSREQUIRED(NOTPROVIDED)
PHILLIPS SCREWDRIVER
HARDWARELIST:ICB-492
No. Description Sketch Quantity
ABolt 5/16"*1-3/4" 8PCS
BLockWasher 5/16" 8PCS
CFlatWasher 5/16" 8PCS
DAllenWrench5mm 1PC
HARDWARELIST:ICB-403D
No. Description Sketch Quantity
GBolt 1/4"*1-3/4" 6PCS
HBolt1/4"*1-1/4" 4PCS
ILockWasher 1/4"10PCS
JFlatwasher 1/4"10PCS
KWoodScrew#8*1" 8PCS
LWoodScrew#8*1-1/2" 5PCS
MAllenWrench4mm 1PC
HARDWARELIST:ICB-402L
No. Description Sketch Quantity
EWoodScrew 8PCS
FAllenWrench4mm 1PC
COMPONENTS LIST:ICB-492
No. Description Sketch Quantity
1Headboard 1PC
2LeftLeg 1PC
3RightLeg 1PC
4WoodStretcher 1PC
COMPONENTS LIST:ICB-402L
No. Description Sketch Quantity
1Bedrails 2PCS
2Slats 4PCS
COMPONENTS LIST:ICB-403D
No. Description Sketch Quantity
1Footboard 1PC
2SupportLeg(forcenterrail) 1PC
3SupportLeg(forpedestal) 2PCS
4Decking 4PCS
5Center Rail 1PC
6BunFoot 2PCS
7SupportPanel 2PCS
ICB-403D-BCH/BLK/EGG/GRY-1 QueenLPFBw/Drawers
ITEMNO:ICB-492-BCH/BLK/EGG/GRY-KD-1QueenFramedPanel HB
ICB-402L-BCH/BLK/EGG/GRY-1 QueenSideRails

11-30-2017
Page2/5
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
STEP3:Layfootboard upsidedownonapadded,cleansurface.Attachsupportlegs(for pedestal)
andbunfeettofootboardusing4bolts(H),lockwashers(I)andflatwashers(J). Turnfootboard
right sideup.
Leveler
Bun Foot
H
I
J
M
ICB-403D-BCH/BLK/EGG/GRY-1 QueenLPFBw/Drawers
ITEMNO:ICB-492-BCH/BLK/EGG/GRY-KD-1QueenFramedPanel HB
ICB-402L-BCH/BLK/EGG/GRY-1 QueenSideRails
A
B
C
D
LeftLeg
RightLeg
Headboard
STEP1:Laytheheadboard facedownonasoftsurface.Attachtheleft legand right legto
headboardbyusing6bolts(A),lockwashers(B)andflat washers(C).
STEP2:Attachthewoodstretchertothelegsbyusing2bolts(A),lockwashers(B)and flat
washers(C).
LeftLeg
RightLeg Headboard
WoodStretcher
A
B
C
D

10-26-2017
Page3/5
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
STEP5:Hookthesiderailstotheheadboardandfootboard,Attachsupportlegand centerrail to
headboardandfootboard byusing5wood screws(L).
Headboard
Slatbearer
SideRail
STEP4:Attachsupportlegandsupportpanelstocenterrailbyusing6bolts(G), lockwashers(I)
andflatwashers(J).
SupportPanel
SupportLeg(forcenterrail)
Center Rail
L
L
GIJ
M
ICB-403D-BCH/BLK/EGG/GRY-1 QueenLPFBw/Drawers
ITEMNO:ICB-492-BCH/BLK/EGG/GRY-KD-1QueenFramedPanel HB
ICB-402L-BCH/BLK/EGG/GRY-1 QueenSideRails
SideRail
Footboard

10-26-2017
Page4/5
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
STEP7:Putthedeckingovertheslats,securedeckingtotheslatswithwood screws (K)through
thepre-drilledholesinthedecking asshownbelow.
Makesurethatthereisaslat
underthepre-drilledhole.
Decking
Slat
Decking
Decking
Theslat shouldsupport
bothpiecesofdecking.
KDecking
Pre-drilledhole
STEP6:Arrangeslatsontheslat
bearersandthenlaydecking on
topoftheslats.Makesuretheslats
arepositionedalongtheseamsof
thedeckingasshowninthedetail
inSTEP7underthepre-drilled
hole. Removethedecking and
attachslatstotheslatbearerswith
woodscrews(E).
ICB-403D-BCH/BLK/EGG/GRY-1 QueenLPFBw/Drawers
ITEMNO:ICB-492-BCH/BLK/EGG/GRY-KD-1QueenFramedPanel HB
ICB-402L-BCH/BLK/EGG/GRY-1 QueenSideRails
WoodScrews(E)
Decking
Decking
Decking

FUNCTIONALITY INSTRUCTION
10-26-2017
Page5/5
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
ICB-403D-BCH/BLK/EGG/GRY-1 QueenLPFBw/Drawers
ITEMNO:ICB-492-BCH/BLK/EGG/GRY-KD-1QueenFramedPanel HB
ICB-402L-BCH/BLK/EGG/GRY-1 QueenSideRails
1PoweredUSBPortfor
Charging on bothsides
ICB-403D
ICB-402L
ICB-492

Page1/4
Thankyou for purchasing thisqualityproduct.Besuretocheckallpacking material carefullyfor
small partsthatmaycomelooseinsidethecartonduringshipment.
UNITSHOULDBEINSTALLEDBY2ORMOREPERSONS.
BEFOREUSINGTHISPRODUCTPLEASEREAD,UNDERSTAND,ANDFOLLOWTHESEINSTRUCTIONS.
Savetheseinstructionsforfuturereference.
All Bedsneedtobeset upintheexact final
locationsothatafterfullassemblyit will not
needtobemoved. Moving thebedwill cause
thesupport legstomoveoutof perpendicular
(90 degree),weakenthesupportsystem, and
mayallowthebedtocollapse.
FORINDOORUSEONLY
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
ICB-407
ICB-410L
ICB-406L
ICB-495
TOOLSREQUIRED(NOTPROVIDED)
PHILLIPS SCREWDRIVER
COMPONENTS LIST:ICB-407
No. Description Sketch Quantity
1Footboard 1PC
2BunFoot 2PCS
3Supportlegswithleveler 5PCS
HARDWARELIST:ICB-495
No. Description Sketch Quantity
ABolt 5/16"*1-3/4" 8PCS
BLockWasher 5/16" 8PCS
CFlatWasher 5/16" 8PCS
DAllenWrench5mm 1PC
HARDWARELIST:ICB-406L/410L
No. Description Sketch Quantity
EWoodScrew 10PCS
FAllenWrench4mm 1PC
COMPONENTS LIST:ICB-406L/410L
No. Description Sketch Quantity
1Bedrails 2PCS
2Slats 5PCS
3MagneticPlate(Only for-410L) 4PCS
COMPONENTS LIST:ICB-495
No. Description Sketch Quantity
1Headboard 1PC
2LeftLeg 1PC
3RightLeg 1PC
4WoodStretcher 1PC
10-26-2017
ITEMNO:ICB-495-BCH/BLK/EGG/GRY-KD-1KingFramedPanel HB
ICB-406L-BCH/BLK/EGG/GRY-1 King SideRails
ICB-410L-BCH/BLK/EGG/GRY-1 CalKing SideRails
ICB-407-BCH/BLK/EGG/GRY-1KingLowProfile FB

A
B
C
E
10-26-2017
Page2/4
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
STEP3:Layfootboard backdownon apadded,cleansurface.Attachbun feet tofootboard. Turn
footboardrightsideup.
Bun Foot
b
a
WoodScrew
Slatbearer
SideRail
A
B
C
D
STEP4:Theslat bearershavebeenattachedinpositionb. Theslat bearerscanbemovedinto
positionadependingonthemattress/platformconfiguration.Removetheboltsand screws from
theslatbearersandsiderailsasshownbelow.Thenre-attachtheslatbearerstothesiderailsin
desiredpositionwithbolts,lockwashers,flatwashers, and screws. Caution:Donot overtighten
boltsasthismayloosenthethreadedinsertsinthesiderails.
ITEMNO:ICB-495-BCH/BLK/EGG/GRY-KD-1KingFramedPanel HB
ICB-406L-BCH/BLK/EGG/GRY-1 King SideRails
ICB-410L-BCH/BLK/EGG/GRY-1 CalKing SideRails
ICB-407-BCH/BLK/EGG/GRY-1KingLowProfile FB
Footboard
LeftLeg
RightLeg
Headboard
STEP1:Laytheheadboardfacedownon a
softsurface.Attachtheleftlegand right leg
toheadboardby using 6bolts(A), lock
washers(B)andflatwashers(C).
STEP2:Attachthewoodstretcher
tothelegsbyusing2bolts(A), lock
washers(B)andflatwashers(C).
LeftLeg
RightLeg
Headboard
WoodStretcher

10-26-2017
Page3/4
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
STEP5:Hookthesiderailstotheheadboardandfootboard.
Headboard Slatbearer
Theoutsideholesmatchto6/6bedrails,
theinsideholesmatchto6/0bedrails.
SideRail
SideRail
SideRail
STEP7:Attachthesupportlegswithlevelertothe
slats.Adjustthelevelersonbottomofsupport legs
whennecessary. SupportLeg
Leveler
ThisEndUp
Slat
STEP6:For CalKingbed, usemagnetic plate tocoverthe
exposedhookson headboard andfootboard. For regular
Kingbed,skipthisstep. MagneticPlate
ITEMNO:ICB-495-BCH/BLK/EGG/GRY-KD-1KingFramedPanel HB
ICB-406L-BCH/BLK/EGG/GRY-1 King SideRails
ICB-410L-BCH/BLK/EGG/GRY-1 CalKing SideRails
ICB-407-BCH/BLK/EGG/GRY-1KingLowProfile FB
Headboard
Footboard

10-26-2017
Page4/4
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
STEP8:Arrangetheslatsontheslat
bearersequallyandattachtotheslat
bearerswithwoodscrews(E).
WoodScrews(E)
FUNCTIONALITY INSTRUCTION
1PoweredUSBPortfor
Charging on bothsides
ITEMNO:ICB-495-BCH/BLK/EGG/GRY-KD-1KingFramedPanel HB
ICB-406L-BCH/BLK/EGG/GRY-1 King SideRails
ICB-410L-BCH/BLK/EGG/GRY-1 CalKing SideRails
ICB-407-BCH/BLK/EGG/GRY-1KingLowProfile FB
ICB-407
ICB-410L
ICB-406L
ICB-495
ICB-407
ICB-495
1PoweredUSBPortfor
Charging on bothsides

10-26-2017
Page1/5
Thankyou for purchasing thisqualityproduct.Besuretocheckallpacking material carefullyfor
small partsthatmaycomelooseinsidethecartonduringshipment.
UNITSHOULDBEINSTALLEDBY2ORMOREPERSONS.
BEFOREUSINGTHISPRODUCTPLEASEREAD,UNDERSTAND,ANDFOLLOWTHESEINSTRUCTIONS.
Savetheseinstructionsforfuturereference.
All Bedsneedtobeset upintheexact final
locationsothatafterfullassemblyit will not
needtobemoved. Moving thebedwill cause
thesupport legstomoveoutof perpendicular
(90 degree),weakenthesupportsystem, and
mayallowthebedtocollapse.
FORINDOORUSEONLY
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
ICB-407D
ICB-410L
ICB-406L
TOOLSREQUIRED(NOTPROVIDED)
PHILLIPS SCREWDRIVER
UTILITYKNIFE(FORCALKING)
HARDWARELIST:ICB-407D
No. Description Sketch Quantity
GBolt 1/4"*1-3/4" 9PCS
HBolt1/4"*1-1/4" 4PCS
ILockWasher 1/4" 13PCS
JFlatwasher 1/4" 13PCS
KWoodScrew#8*1" 6PCS
LWoodScrew#8*1-1/2" 5PCS
MAllenWrench4mm 1PC
ICB-495
HARDWARELIST:ICB-406L/410L
No. Description Sketch Quantity
EWoodScrew 10PCS
FAllenWrench4mm 1PC
HARDWARELIST:ICB-495
No. Description Sketch Quantity
ABolt 5/16"*1-3/4" 8PCS
BLockWasher 5/16" 8PCS
CFlatWasher 5/16" 8PCS
DAllenWrench5mm 1PC
COMPONENTS LIST:ICB-495
No. Description Sketch Quantity
1Headboard 1PC
2LeftLeg 1PC
3RightLeg 1PC
4WoodStretcher 1PC
COMPONENTS LIST:ICB-406L/410L
No. Description Sketch Quantity
1Bedrails 2PCS
2Slats 5PCS
3MagneticPlate(Only for-410L) 4PCS
COMPONENTS LIST:ICB-407D
No. Description Sketch Quantity
1Footboard 1PC
2SupportLeg(forcenterrail) 1PC
3SupportLeg(forpedestal) 2PCS
4Decking 3PCS
5Center Rail 1PC
6Filler 1PC
7BunFoot 2PCS
8SupportPanel 2PCS
9Rail connector 1PC
ICB-407D-BCH/BLK/EGG/GRY-1 King/CalKingLPFBw/Drawers
ITEMNO:ICB-495-BCH/BLK/EGG/GRY-KD-1KingFramedPanel HB
ICB-406L-BCH/BLK/EGG/GRY-1 King SideRails
ICB-410L-BCH/BLK/EGG/GRY-1 CalKing SideRails

10-26-2017
Page2/5
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
STEP3:Layfootboard upsidedownonapadded,cleansurface.Attachsupportlegs(for pedestal)
andbunfeettofootboardusing4bolts(H),lockwashers(I)andflatwashers(J). Turnfootboard
right sideup.
Leveler
Bun Foot
M
I
J
ICB-407D-BCH/BLK/EGG/GRY-1 King/CalKingLPFBw/Drawers
ITEMNO:ICB-495-BCH/BLK/EGG/GRY-KD-1KingFramedPanel HB
ICB-406L-BCH/BLK/EGG/GRY-1 King SideRails
ICB-410L-BCH/BLK/EGG/GRY-1 CalKing SideRails
A
B
C
D
A
B
C
D
LeftLeg
RightLeg
Headboard
STEP1:Laytheheadboard facedownonasoftsurface.Attachtheleft legand right legto
headboardbyusing6bolts(A),lockwashers(B)andflat washers(C).
STEP2:Attachthewoodstretchertothelegsbyusing2bolts(A),lockwashers(B)and flat
washers(C).
LeftLeg
RightLeg
Headboard
WoodStretcher
H

10-26-2017
Page3/5
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
STEP5:Hookthesiderailstotheheadboardandfootboard,Attachsupportlegand centerrail to
headboardandfootboard byusing5wood screws(L).
Headboard
Slatbearer
Theoutsideholesmatchto6/6bedrails,
theinsideholesmatchto6/0bedrails.
SideRail
SideRail
SideRail
STEP4:Attachsupportlegandsupportpanelstocenterrailbyusing6bolts(G), lockwashers(I)
andflatwashers(J).
SupportPanel
SupportLeg(forcenterrail)
Center Rail
IJRail connector
Center Rail
ToCal Kingbed,attachrail
connector tothesupportrail first.
L
L
M
ICB-407D-BCH/BLK/EGG/GRY-1 King/CalKingLPFBw/Drawers
ITEMNO:ICB-495-BCH/BLK/EGG/GRY-KD-1KingFramedPanel HB
ICB-406L-BCH/BLK/EGG/GRY-1 King SideRails
ICB-410L-BCH/BLK/EGG/GRY-1 CalKing SideRails
Headboard
G
G
I
J

10-26-2017
Page4/5
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
STEP6:Arrangeslatson the
slatbearersandthenlaythe
deckingontopoftheslats.
Makesurethetopand
bottomslatsaresituated
underneaththepre-drilled
holesasshownbelow in
STEP8.Removethe
deckingandattachslatsto
theslatbearerswithwood
screws (E).
WoodScrews(E)
Filler Notch
STEP8:Putthedeckingovertheslats,securedeckingtotheslatswithwood screws (K)through
thepre-drilledholesinthedecking asshownbelow.
Filler
Makesurethatthereisaslat
underthepre-drilledhole.
K
Decking
Pre-drilledhole
STEP9:For CalKingbed, usemagnetic plateto
covertheexposedhooksonheadboardand
footboard. For regularKingbed,skipthisstep. MagneticPlate
STEP7:ForCalKingbed,useautilityknifetocut off thesmall
pieceat thenotchon theDecking Fillerpieceincludedwiththe
StorageFootboard.ForregularKingbed, skipthisstep.
Cal King bed
King bed
ICB-407D-BCH/BLK/EGG/GRY-1 King/CalKingLPFBw/Drawers
ITEMNO:ICB-495-BCH/BLK/EGG/GRY-KD-1KingFramedPanel HB
ICB-406L-BCH/BLK/EGG/GRY-1 King SideRails
ICB-410L-BCH/BLK/EGG/GRY-1 CalKing SideRails
Decking Decking Decking
Filler
Decking Decking Decking

FUNCTIONALITY INSTRUCTION
10-26-2017
Page5/5
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
ICB-407D
ICB-406L
1PoweredUSBPortfor
Charging on bothsides
ICB-407D-BCH/BLK/EGG/GRY-1 King/CalKingLPFBw/Drawers
ITEMNO:ICB-495-BCH/BLK/EGG/GRY-KD-1KingFramedPanel HB
ICB-406L-BCH/BLK/EGG/GRY-1 King SideRails
ICB-410L-BCH/BLK/EGG/GRY-1 CalKing SideRails
ICB-495
ICB-407D
ICB-410L
1PoweredUSBPortfor
Charging on bothsides
ICB-495
