aspenhome I430-412 User manual

COMPONENTSLIST: I430-412
No.
1Description Sketch Quantity
Headboard(HB) 1PC
COMPONENTSLIST: I430-402
No.
1
2
Description Sketch Quantity
Bed rails
Slats 4PCS
2PCS
COMPONENTSLIST: I430-403
No.
1
2
Description Sketch Quantity
Footboard(FB) 4PCS
1PC
Page1/6
ITEMNO: I430-412 QueenPanelHB
I430-402 QueenRails w/Decking
I430-403 Queen Low Profile FB
Thankyouforpurchasingthisqualityproduct.Besuretocheckallpacking material carefullyfor
small partsthatmaycomelooseinsidethe cartonduringshipment.
UNIT SHOULDBE INSTALLEDBY2ORMORE PERSONS.
All Bedsneedtobeset upinthe exact final
locationsothatafterfull assemblyit will not
needtobemoved. Moving thebedwill cause
thesupportlegstomoveoutofperpendicular
(90degree),weakenthesupportsystem, and
may allowthebedtocollapse.
aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
BEFORE USING THISPRODUCT PLEASEREAD, UNDERSTAND, AND FOLLOWTHESEINSTRUCTIONS.
Save these instructionsforfuture reference.
FORINDOORUSEONLY
TOOLSREQUIRED (NOTPROVIDED)
PHILLIPSSCREWDRIVER
I430-403
I430-402
I430-412
A
HARDWARELIST:I430-402
No. Description Sketch Quantity
8PCS
HexWrench 13mm
8PCS
1PC
8PCS
HangerBolt 5/16" x3"
HexNut5/16"
Wood Screw #4x1-1/4"
HalfMoon Washer 5/16"
B
C
D
E
F
07-19-2023
Decking 7PCS
3
Wood Screw #4 x3/4" 14 PCS
8PCS
SupportLeg(Long)
SupportLeg(Short)
34PCS

aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
Page2/6
Side Rail
STEP1: Theside railsmaybeused on eitherside.
Arrangethesiderailssotheslatbearers arein
UPPERPOSITIONpriortoattachmentasOPTION 1
andtheslatbearersareinLOWERPOSITIONprior
toattachmentasOPTION 2.
Slatbearerin
upperposition
Slatbearerin
lowerposition
OPTION1: Thesiderailsmaybeusedoneitherside.Arrangetheside railssothe slat
bearersareinUPPERPOSITIONpriortoattachment inSTEP 2.
STEP2: Screwthebolts(A)intoHB&FB.Makesuretheslatbearerisinthe UPPER position.
Alignthe boltswiththe holesintheendofsiderailsandattach theside railstoHB&FBusing
halfmoonWasher(B)andhexnuts(C).Thenuseahexwrenchtotighten all the nuts.
Headboard
Slatbearer
Side Rail
A
Makesuretheslatbeareris
inthe UPPER position.
BCD
05-30-2023
ITEMNO: I430-412 QueenPanelHB
I430-402 QueenRails w/Decking
I430-403 Queen Low Profile FB
STEP3: Attachthesupportlegs(long)totheslats
asshownright.
ThisEndUp
Slat
SupportLeg(Long)

aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
05-30-2023
ITEMNO: I430-412 QueenPanelHB
I430-402 QueenRails w/Decking
I430-403 Queen Low Profile FB
Page3/6
STEP4: Arrangeslatsontheslatbearersandthenlaythedeckingon top ofthe slats. Make sure
thetopandbottomslatsaresituatedunderneaththepre-drilled holesasshowninSTEP 5.
Removethedeckingandattachslatstotheslatbearerswithwood screws(E).
STEP5: Putthedeckingovertheslats,securedeckingtotheslatswithwood screws(F)
throughthepre-drilledholesinthe deckingasshownbelow.
E
Pre-drilledhole
Makesurethatthereisaslat
underthepre-drilled hole.
FDecking
Slat

aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
05-30-2023
ITEMNO: I430-412 QueenPanelHB
I430-402 QueenRails w/Decking
I430-403 Queen Low Profile FB
Page4/6
FUNCTIONALITYINSTRUCTION
STEP2: Screwthebolts(A)intoHB&FB.Makesuretheslatbearerisinthe LOWER position.
Alignthe boltswiththe holesintheendofsiderailsandattach theside railstoHB&FBusing
halfmoonWasher(B)andhexnuts(C).Thenuseahexwrenchtotighten all the nuts.
OPTION2: Thesiderailsmaybeusedoneitherside.Arrangetheside railssothe slat
bearersareinLOWERPOSITIONpriortoattachment inSTEP 2.
I430-402
I430-412
I430-403
PoweredUSBPorts(1
Type A+1Type C) for
Charging on bothsides
Side Rail
Headboard A
Slatbearer
Side Rail
BCD
Makesuretheslatbeareris
inthe LOWER position.

aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
05-30-2023
ITEMNO: I430-412 QueenPanelHB
I430-402 QueenRails w/Decking
I430-403 Queen Low Profile FB
Page5/6
STEP4: Arrangeslatsontheslatbearersand then lay the
deckingontopofthe slats.Make surethe topandbottomslats
aresituatedunderneaththepre-drilledholesasshowninSTEP
5. Removethedeckingandattach slatstotheslatbearerswith
wood screws(E).
E
STEP5: Putthedeckingovertheslats,securedeckingtotheslatswithwood screws(F)
throughthepre-drilledholesinthe deckingasshownbelow.
Decking
Pre-drilledhole
F
STEP3: Attachthesupportlegs(short)tothe slats
asshownright.
ThisEndUp
Slat
SupportLeg(Short)

aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
05-30-2023
ITEMNO: I430-412 QueenPanelHB
I430-402 QueenRails w/Decking
I430-403 Queen Low Profile FB
Page6/6
FUNCTIONALITYINSTRUCTION
I430-402
I430-412
I430-403
PoweredUSBPorts(1
Type A+1Type C) for
Charging on bothsides

COMPONENTSLIST: I430-415
No.
1Description Sketch Quantity
Headboard(HB) 1PC
COMPONENTSLIST: I430-406
No.
1
2
Description Sketch Quantity
Bed rails
Slats 5PCS
2PCS
COMPONENTSLIST: I430-407
No.
1
2
Description Sketch Quantity
Footboard(FB) 5PCS
1PC
COMPONENTSLIST: I430-410
No.
1
2
Description Sketch Quantity
Bed rails
Slats 5PCS
2PCS
Page1/6
ITEMNO: I430-415 King PanelHB
I430-406 King Rails w/Decking
I430-410 CalKing Rails w/Decking
I430-407 King Low Profile FB
Thankyouforpurchasingthisqualityproduct.Besuretocheckallpacking material carefullyfor
small partsthatmaycomelooseinsidethe cartonduringshipment.
UNIT SHOULDBE INSTALLEDBY2ORMORE PERSONS.
All Bedsneedtobeset upinthe exact final
locationsothatafterfull assemblyit will not
needtobemoved. Moving thebedwill cause
thesupportlegstomoveoutofperpendicular
(90degree),weakenthesupportsystem, and
may allowthebedtocollapse.
aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
BEFORE USING THISPRODUCT PLEASEREAD, UNDERSTAND, AND FOLLOWTHESEINSTRUCTIONS.
Save these instructionsforfuture reference.
FORINDOORUSEONLY
TOOLSREQUIRED (NOTPROVIDED)
PHILLIPSSCREWDRIVER
I430-407
I430-406
I430-415
I430-410
A
HARDWARELIST:I430-406/410
No. Description Sketch Quantity
8PCS
HexWrench 13mm
8PCS
1PC
10 PCS
8PCS
HangerBolt 5/16" x3"
HexNut5/16"
Wood Screw #4x1-1/4"
HalfMoon Washer 5/16"
B
C
D
E
F
07-19-2023
Decking 9PCS
3
Decking 8PCS
3
WoodCap(onlyfor-410) 8PCS
G
H
Wood Screw #4 x3/4"(onlyfor-406) 18 PCS
16 PCS
Wood Screw #4 x3/4"(onlyfor-410)
SupportLeg(Long)
SupportLeg(Short)
35PCS

aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
Page2/6
STEP3: Attachthesupportlegs(long)totheslats
asshownright.
Side Rail
ITEMNO: I430-415 King PanelHB
I430-406 King Rails w/Decking
I430-410 CalKing Rails w/Decking
I430-407 King Low Profile FB
STEP1: Theside railsmaybeused on eitherside.
Arrangethesiderailssotheslatbearers arein
UPPERPOSITIONpriortoattachmentasOPTION 1
andtheslatbearersareinLOWERPOSITIONprior
toattachmentasOPTION 2.
Slatbearerin
upperposition
Slatbearerin
lowerposition
OPTION1: Thesiderailsmaybeusedoneitherside.Arrangetheside railssothe slat
bearersareinUPPERPOSITIONpriortoattachment inSTEP 2.
STEP2: Screwthebolts(A)intoHB&FB.Makesuretheslatbearerisinthe UPPER position.
Alignthe boltswiththe holesintheendofsiderailsandattach theside railstoHB&FBusing
halfmoonWasher(B)andhexnuts(C).Thenuseahexwrenchtotighten all the nuts.
The outsideholesmatchto6/6standardkingrails,
the insideholesmatchto6/0Calkingbed rails.
Headboard
Slatbearer
Side Rail
A
Makesuretheslatbeareris
inthe UPPER position.
BCD
05-30-2023
ThisEndUp
Slat
SupportLeg(Long)

aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
Page3/6
ITEMNO: I430-415 King PanelHB
I430-406 King Rails w/Decking
I430-410 CalKing Rails w/Decking
I430-407 King Low Profile FB
STEP4: Arrangeslatsontheslatbearersandthenlaythedeckingon top ofthe slats. Make sure
thetopandbottomslatsaresituatedunderneaththepre-drilled holesasshowninSTEP 5.
Removethedeckingandattachslatstotheslatbearerswithwood screws(E).
E
STEP5: Putthedeckingovertheslats,securedeckingtotheslatswithwood screws(F &H)
throughthepre-drilledholesinthe deckingasshownbelow.
Decking
Pre-drilledhole
Makesurethatthereisaslat
underthepre-drilled hole.
I430-407
I430-406
I430-415
I430-410
I430-415
I430-407
H
F&H
F
STEP6: ForCal Kingbed,insertwood capsintotheholeson
headboardandfootboard.ForregularKingbed, skipthisstep. WoodCap(G)
05-30-2023

aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
Page4/6
FUNCTIONALITYINSTRUCTION
I430-407
I430-406
I430-415
I430-410
Standardkingbed
Calkingbed
ITEMNO: I430-415 King PanelHB
I430-406 King Rails w/Decking
I430-410 CalKing Rails w/Decking
I430-407 King Low Profile FB
I430-415
I430-407
PoweredUSBPorts(1
Type A+1Type C) for
Charging on bothsides
STEP2: Screwthebolts(A)intoHB&FB.Makesuretheslatbearerisinthe LOWER position.
Alignthe boltswiththe holesintheendofsiderailsandattach theside railstoHB&FBusing
halfmoonWasher(B)andhexnuts(C).Thenuseahexwrenchtotighten all the nuts.
OPTION2: Thesiderailsmaybeusedoneitherside.Arrangetheside railssothe slat
bearersareinLOWERPOSITIONpriortoattachment inSTEP 2.
The outsideholesmatchto6/6standardkingrails,
the insideholesmatchto6/0Calkingbed rails.
Headboard
Slatbearer
Side Rail
ABCD
Makesuretheslatbeareris
inthe LOWER position.
Side Rail
05-30-2023

STEP3: Attachthesupportlegs(short)tothe slats
asshownright.
ThisEndUp
Slat
STEP4: Arrangeslatsontheslatbearersand then lay the
deckingontopofthe slats.Make surethe topandbottomslats
aresituatedunderneaththepre-drilledholesasshowninSTEP
5. Removethedeckingandattach slatstotheslatbearerswith
wood screws(E).
aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
Page5/6
ITEMNO: I430-415 King PanelHB
I430-406 King Rails w/Decking
I430-410 CalKing Rails w/Decking
I430-407 King Low Profile FB
E
STEP5: Putthedeckingovertheslats,securedeckingtotheslatswithwood screws(F &H)
throughthepre-drilledholesinthe deckingasshownbelow.
Decking
Pre-drilledhole
Makesurethatthereisaslat
underthepre-drilled hole.
F&H
H
F
I430-410
I430-415
I430-407
I430-407
I430-406
I430-415
05-30-2023
SupportLeg(Short)

aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
Page6/6
FUNCTIONALITYINSTRUCTION
I430-407
I430-406
I430-415
I430-410
Standardkingbed
Calkingbed
ITEMNO: I430-415 King PanelHB
I430-406 King Rails w/Decking
I430-410 CalKing Rails w/Decking
I430-407 King Low Profile FB
I430-415
PoweredUSBPorts(1
Type A+1Type C) for
Charging on bothsides
STEP6: ForCal Kingbed,insertwood capsintotheholeson
headboardandfootboard.ForregularKingbed, skipthisstep. WoodCap(G)
05-30-2023
I430-407

COMPONENTSLIST: I430-512
No.
1Description Sketch Quantity
Headboard(HB) 1PC
COMPONENTSLIST: I430-517
No.
1
2
Description Sketch Quantity
Bed rails
Slats 4PCS
2PCS
COMPONENTSLIST: I430-503
No.
1
2
Description Sketch Quantity
Footboard(FB) 1PC
Page1/6
ITEMNO: I430-512 TwinPanelHB
I430-517 TwinRails w/Decking
I430-503 TwinLow Profile FB
Thankyouforpurchasingthisqualityproduct.Besuretocheckallpacking material carefullyfor
small partsthatmaycomelooseinsidethe cartonduringshipment.
UNIT SHOULDBE INSTALLEDBY2ORMORE PERSONS.
All Bedsneedtobeset upinthe exact final
locationsothatafterfull assemblyit will not
needtobemoved. Moving thebedwill cause
thesupportlegstomoveoutofperpendicular
(90degree),weakenthesupportsystem, and
may allowthebedtocollapse.
aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
BEFORE USING THISPRODUCT PLEASEREAD, UNDERSTAND, AND FOLLOWTHESEINSTRUCTIONS.
Save these instructionsforfuture reference.
FORINDOORUSEONLY
TOOLSREQUIRED (NOTPROVIDED)
PHILLIPSSCREWDRIVER
I430-503
I430-517
I430-512
A
HARDWARELIST:I430-517
No. Description Sketch Quantity
8PCS
HexWrench 13mm
8PCS
1PC
8PCS
HangerBolt 5/16" x3"
HexNut5/16"
Wood Screw #4x1-1/4"
HalfMoon Washer 5/16"
B
C
D
E
F
07-19-2023
Decking 5PCS
3
Wood Screw #4 x3/4" 10 PCS
8PCS
4PCS
SupportLeg(Long)
SupportLeg(Short)
34PCS

aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
Page2/6
Side Rail
STEP1: Theside railsmaybeused on eitherside.
Arrangethesiderailssotheslatbearers arein
UPPERPOSITIONpriortoattachmentasOPTION 1
andtheslatbearersareinLOWERPOSITIONprior
toattachmentasOPTION 2.
Slatbearerin
upperposition
Slatbearerin
lowerposition
OPTION1: Thesiderailsmaybeusedoneitherside.Arrangetheside railssothe slat
bearersareinUPPERPOSITIONpriortoattachment inSTEP 2.
STEP2: Screwthebolts(A)intoHB&FB.Makesuretheslatbearerisinthe UPPER position.
Alignthe boltswiththe holesintheendofsiderailsandattach theside railstoHB&FBusing
halfmoonWasher(B)andhexnuts(C).Thenuseahexwrenchtotighten all the nuts.
Headboard
Slatbearer
Side Rail
A
Makesuretheslatbeareris
inthe UPPER position.
BCD
05-30-2023
ITEMNO: I430-512 TwinPanelHB
I430-517 TwinRails w/Decking
I430-503 TwinLow Profile FB
STEP3: Attachthesupportlegs(long)totheslats
asshownright.
ThisEndUp
Slat
SupportLeg(Long)

aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
05-30-2023
Page3/6
STEP4: Arrangeslatsontheslatbearersandthenlaythedeckingon top ofthe slats. Make sure
thetopandbottomslatsaresituatedunderneaththepre-drilled holesasshowninSTEP 5.
Removethedeckingandattachslatstotheslatbearerswithwood screws(E).
STEP5: Putthedeckingovertheslats,securedeckingtotheslatswithwood screws(F)
throughthepre-drilledholesinthe deckingasshownbelow.
E
Pre-drilledhole
Makesurethatthereisaslat
underthepre-drilled hole.
FDecking
Slat
ITEMNO: I430-512 TwinPanelHB
I430-517 TwinRails w/Decking
I430-503 TwinLow Profile FB

FUNCTIONALITYINSTRUCTION
STEP2: Screwthebolts(A)intoHB&FB.Makesuretheslatbearerisinthe LOWER position.
Alignthe boltswiththe holesintheendofsiderailsandattach theside railstoHB&FBusing
halfmoonWasher(B)andhexnuts(C).Thenuseahexwrenchtotighten all the nuts.
OPTION2: Thesiderailsmaybeusedoneitherside.Arrangetheside railssothe slat
bearersareinLOWERPOSITIONpriortoattachment inSTEP 2.
I430-517
I430-512
I430-503
PoweredUSBPorts(1
Type A+1Type C) for
Charging on bothsides
Side Rail
Headboard A
Slatbearer
Side Rail
BCD
Makesuretheslatbeareris
inthe LOWER position.
aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
05-30-2023
Page4/6
ITEMNO: I430-512 TwinPanelHB
I430-517 TwinRails w/Decking
I430-503 TwinLow Profile FB

aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
05-30-2023
Page5/6
STEP4: Arrangeslatsontheslatbearersand then lay the
deckingontopofthe slats.Make surethe topandbottomslats
aresituatedunderneaththepre-drilledholesasshowninSTEP
5. Removethedeckingandattach slatstotheslatbearerswith
wood screws(E).
STEP5: Putthedeckingovertheslats,securedeckingtotheslatswithwood screws(F)
throughthepre-drilledholesinthe deckingasshownbelow.
Decking
Pre-drilledhole
F
E
ITEMNO: I430-512 TwinPanelHB
I430-517 TwinRails w/Decking
I430-503 TwinLow Profile FB
STEP3: Attachthesupportlegs(short)tothe slats
asshownright.
ThisEndUp
Slat
SupportLeg(Short)

aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
05-30-2023
Page6/6
FUNCTIONALITYINSTRUCTION
I430-517
I430-512
I430-503
PoweredUSBPorts(1
Type A+1Type C) for
Charging on bothsides
ITEMNO: I430-512 TwinPanelHB
I430-517 TwinRails w/Decking
I430-503 TwinLow Profile FB

COMPONENTSLIST: I430-515
No.
1Description Sketch Quantity
Headboard(HB) 1PC
COMPONENTSLIST: I430-514
No.
1
2
Description Sketch Quantity
Bed rails
Slats 4PCS
2PCS
COMPONENTSLIST: I430-507
No.
1
2
Description Sketch Quantity
Footboard(FB) 1PC
Page1/6
ITEMNO: I430-515 Full PanelHB
I430-514 Full Rails w/Decking
I430-507 Full Low Profile FB
Thankyouforpurchasingthisqualityproduct.Besuretocheckallpacking material carefullyfor
small partsthatmaycomelooseinsidethe cartonduringshipment.
UNIT SHOULDBE INSTALLEDBY2ORMORE PERSONS.
All Bedsneedtobeset upinthe exact final
locationsothatafterfull assemblyit will not
needtobemoved. Moving thebedwill cause
thesupportlegstomoveoutofperpendicular
(90degree),weakenthesupportsystem, and
may allowthebedtocollapse.
aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
BEFORE USING THISPRODUCT PLEASEREAD, UNDERSTAND, AND FOLLOWTHESEINSTRUCTIONS.
Save these instructionsforfuture reference.
FORINDOORUSEONLY
TOOLSREQUIRED (NOTPROVIDED)
PHILLIPSSCREWDRIVER
I430-507
I430-514
I430-515
A
HARDWARELIST:I430-514
No. Description Sketch Quantity
8PCS
HexWrench 13mm
8PCS
1PC
8PCS
HangerBolt 5/16" x3"
HexNut5/16"
Wood Screw #4x1-1/4"
HalfMoon Washer 5/16"
B
C
D
E
F
07-19-2023
Decking 7PCS
3
Wood Screw #4 x3/4" 14 PCS
8PCS
4PCS
SupportLeg(Long)
SupportLeg(Short)
34PCS

aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
Page2/6
Side Rail
STEP1: Theside railsmaybeused on eitherside.
Arrangethesiderailssotheslatbearers arein
UPPERPOSITIONpriortoattachmentasOPTION 1
andtheslatbearersareinLOWERPOSITIONprior
toattachmentasOPTION 2.
Slatbearerin
upperposition
Slatbearerin
lowerposition
OPTION1: Thesiderailsmaybeusedoneitherside.Arrangetheside railssothe slat
bearersareinUPPERPOSITIONpriortoattachment inSTEP 2.
STEP2: Screwthebolts(A)intoHB&FB.Makesuretheslatbearerisinthe UPPER position.
Alignthe boltswiththe holesintheendofsiderailsandattach theside railstoHB&FBusing
halfmoonWasher(B)andhexnuts(C).Thenuseahexwrenchtotighten all the nuts.
Headboard
Slatbearer
Side Rail
A
Makesuretheslatbeareris
inthe UPPER position.
BCD
05-30-2023
ITEMNO: I430-515 Full PanelHB
I430-514 Full Rails w/Decking
I430-507 Full Low Profile FB
STEP3: Attachthesupportlegs(long)totheslats
asshownright.
ThisEndUp
Slat
SupportLeg(Long)
