aspenhome I256-6052 User manual

aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
Page1/3
ITEMNO:I256-6052ExtendableCounterHeight Table
Thankyouforpurchasingthisqualityproduct.Besuretocheckallpacking material carefullyfor
small partsthatmaycomelooseinsidethe cartonduringshipment.
BEFORE USING THISPRODUCT PLEASEREAD, UNDERSTAND, AND FOLLOWTHESEINSTRUCTIONS.
Save these instructionsforfuture reference. FORINDOORUSEONLY
TOOLSREQUIRED (NOTPROVIDED)
PHILLIPSSCREWDRIVER
HARDWARELIST:
No. Description Sketch Quantity
A
B
C
D1PC
COMPONENTSLIST:
No. Description Sketch Quantity
1Table Top 1PC
24PCS
Leg
Bolt 5/16"x2-1/2"
Lock Washer5/16"
FlatWasher5/16" x7/8"
8PCS
8PCS
8PCS
Option 1
Option 2
FUNCTIONALITYINSTRUCTION
Adjustthe leveler
when necessary
Leveleron Legs
Butterflyleaf
Leg
HexWrench 12mm
03-29-2022

Page2/3
aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
STEP1:Laythetabletopfacedownonasoft
surface.Attachthelegs totabletopbyusing 8
bolts(A),lockwashers(B)andflatwashers(C). Use
the hex wrench(D)provided to tighten all the bolts.
Turntheassembledtabletotheuprightposition.
STEP2:Unbucklethetablelocksunderthetabletoptothe
OFFpositionasshownbelowandpullthetabletopcompletely
apartfromeachend.
ForOPTION1:
ForOPTION2:
Leg
Leg
TableLock
OFF
POSITION
ON
POSITION
ITEMNO:I256-6052ExtendableCounterHeight Table
D
A
B
C
04-15-2022

Page3/3
aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
STEP3:Unfoldthebutterflyleafasshowntothe
right,beingcarefulnottodamagethehingesand
woodsurfacesoftheleaf.
Caution: Be carefultonotpinchyour handsor
fingerswhenopeningorclosingtheleaforaprons.
Flipopentheaprons priortofullyextendingthe
leaftopreventdamagetotheaprons’surfaces.
STEP4:Whenthebutterflyleafiscompletelyunfoldedandflush withthetabletop,push together
thetablefromeachendtoclosethegaps.BucklethetablelockstotheON position.
Caution:
Lifttableleafhere
Caution:
Lift tableleafhere
Butterflyleaf
Notes:Whenreassembletooption1,pleasereplacesteps4&3and thenstep2above.
Leaf
Apron
ITEMNO:I256-6052ExtendableCounterHeight Table
TableLock
OFF
POSITION
ON
POSITION
04-15-2022

Page1/2
ITEMNO:I256-6643SCounterHeightSideChairw/ Uph Seat (2/Ctn)
Thankyouforpurchasingthisqualityproduct.Besuretocheckallpacking material carefullyfor
small partsthatmaycomelooseinsidethe cartonduringshipment.
TOOLSREQUIRED (NOTPROVIDED)
PHILLIPSSCREWDRIVER
aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
BEFORE USING THISPRODUCT PLEASEREAD, UNDERSTAND, AND FOLLOWTHESEINSTRUCTIONS.
Save these instructionsforfuture reference. FORINDOORUSEONLY
FUNCTIONALITYINSTRUCTION
HARDWARELIST:
No.
B
C
D
Description Sketch Quantity
Lock Washer 5/16"
FlatWasher 5/16" x3/4"
A
COMPONENTSLIST:
No.
1Description Sketch Quantity
2ChairSeat
3
1PC
1PC
E
ChairBack
F
1PC
4PCS
4
G6PCS
Wood Screw #4 x2"
1PC
5LeftSideStretcher 1PC
1PC
6
7
1PC
1PC
FrontStretcher
RightFrontLeg
LeftFrontLeg
RightSideStretcher
HexNut5/16" 4PCS
HexWrench12mm 1PC
9PCS
9PCS
Hex Bolt 5/16" x2-3/4"
Hex Bolt 5/16" x1-3/4"
04-15-2022

Page2/2
aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
ITEMNO:I256-6643SCounterHeightSideChairw/ Uph Seat (2/Ctn)
STEP2: Attachtheassembledchairfrontto
chairseatbyusing4flatwashers(E), lock
washers(D),andhexnuts(C)witha hex
wrench(F),DonottightenboltsuntilSTEP 4.
ChairSeat
ChairBack
D
E
B
STEP4:Attachtheleftsidestretcherand right
sidestretchertothefrontlegs andchairbackwith
woodscrews(G).Completelytightenall wood
screwsandbolts.Turntheassembledchair tothe
uprightposition.
G
G
ChairFront
ChairSeat
CDE
STEP1:Assembletherightfrontlegandthe left
frontlegwithfrontstretcherbyscrews(G).Making
surethedrillholesoneachfrontlegandthe
chamfersonalllegs arealignedasshownright.
GFrontStretcher
RightFrontLeg
LeftFrontLeg
STEP3: Attachthechairseattochairbackby
using4bolts(A),1bolt(B),5lockwashers(D),
5flatwashers(E)withahexwrench(F)Donot
completelytightenbolts.
RightSideStretcher
LeftSideStretcher
F
F
D
E
AF
04-15-2022

aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
Page1/1
ITEMNO:I256-6645SCounterHeightMetal Side Chair(2/Ctn)
Thankyouforpurchasingthisqualityproduct.Besuretocheckallpacking material carefullyfor
small partsthatmaycomelooseinsidethe cartonduringshipment.
BEFORE USING THISPRODUCT PLEASEREAD, UNDERSTAND, AND FOLLOWTHESEINSTRUCTIONS.
Save these instructionsforfuture reference. FORINDOORUSEONLY
TOOLSREQUIRED (NOTPROVIDED)
PHILLIPSSCREWDRIVER
FUNCTIONALITYINSTRUCTION
06-06-2022
Upholstered Back
Upholstered Seat
Adjustthe leveler
when necessary
Leveleron Legs
