aspenhome Trellis I287-360T User manual

Page1/2
Thankyouforpurchasingthisqualityproduct.Besuretocheckallpacking material carefullyfor
small partsthatmaycomelooseinsidethe cartonduringshipment.
BEFORE USING THISPRODUCT PLEASEREAD, UNDERSTAND, AND FOLLOWTHESEINSTRUCTIONS.
Save these instructionsforfuture reference. FORINDOORUSEONLY
aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
TOOLSREQUIRED (NOTPROVIDED)
PHILLIPSSCREWDRIVER
LiftMechanism
Assemblyinstructions forthe Lift
Mechanism areinthe Lift
Mechanism package. Follow the
below instructionswhen attaching
desktop tothe LiftMechanism.
HARDWARELIST:
1PC
No.
B
C
D
E
Description Sketch Quantity
Bolt 5/16" x3/4"
Lock Washer5/16"
FlatWasher5/16"
Allen Wrench
8PCS
PlasticWireClip
Wood Screw M4 x5/8"
F6PCS
10 PCS
COMPONENTSLIST:
1Set
No.
1Description Sketch Quantity
DeskTop
8PCS
8PCS
ITEMNO:I287-360T60"Adj.LiftDeskTop(forIUAB-301-1)
FUNCTIONALITYINSTRUCTION
LeveleronBase
Adjusttheleveler
whennecessary
Press here torelease
Hook latch
Metalplate
Flipdownkeyboardtray
2ACoutlet/2USB
powerpack
PowerUnit inthe Storage Box
on liftmechanism (IUAB-301-1)
Liftmechanism
(IUAB-301-1)
A
04-10-2020

DeskBack
Screw
F
E
Wire
LiftMechanism
ControlUnit
C
B
A
D
F
DeskBack
LiftMechanism
ControlUnit
ACoutlet PowerUnit
STEP1:Putthe desktop face downon a softsurface.
STEP2:Place LiftMechanism IUAB-301-1on desktop and adjusttoalign withthreaded inserts. Follow Step 3 from
the IUAB-301-1assemblyinstructionsforadjusting widthofLiftMechanism.
STEP3:Secure LiftMechanism IUAB-301-1todesktop by using 8bolts(A), 4wood screws (F), 8lock washers(B)
and 8 flatwashers(C). Then use an allen wrench totighten all the bolts.
Page2/2
aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
STEP4:Tighten boltsthatwere loosened inStep 3 fromthe IUAB-301-1assemblyinstructions.
STEP5:Attach LiftMechanism ControlUnit (“7”on the componentlistforliftdeskmechanism)tothe desired
position withscrews(“A”on the hardwarebag forliftdeskmechanism).
STEP6:Clipthe wire intothe plastic wire clip, Attach the plastic wire clips(E) tothe rightposition with
screws(F).
STEP7:Turnthe assembled desktothe uprightposition.
STEP8:Connectthe appropriate wire clipsleading from the motortothe LiftMechanism ControlUnit.
STEP9:Follow Step 6 from the IUAB-301-1assemblyinstructions.
STEP10:Plug inthe PowerUnittoanACoutlet.
STEP11:If disassemblyisrequired, lowerthe LiftMechanism tothe lowestpoint.
Threadedinsert
Note:RefertoLiftMechanism assemblyinstructions forControlUnit operation.
04-10-2020
ITEMNO:I287-360T60"Adj.LiftDeskTop(forIUAB-301-1)
