aspenhome I248-307-1 User manual

Page1/5
ITEMNO:I248-307-1/307-SLT-1SinglePed Desk
I248-308-1/308-SLT-148"ReturnDesk
Thankyouforpurchasingthisqualityproduct.Besuretocheckallpacking material carefullyfor
small partsthatmaycomelooseinsidethe cartonduringshipment.
aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
BEFORE USING THISPRODUCT PLEASEREAD, UNDERSTAND, AND FOLLOWTHESEINSTRUCTIONS.
Save these instructionsforfuture reference.
FORINDOORUSEONLY
HARDWARELIST:I248-307-1/307-SLT-1
1PC
No.
B
C
D
E
Description Sketch Quantity
Bolt 1/4"x1-3/8"
Lock Washer1/4"
FlatWasher1/4" x3/4"
Allen Wrench 4mm
8PCS
10 PCS
A
COMPONENTSLIST:I248-307-1/307-SLT-1
No.
1Description Sketch Quantity DeskTop
2Pedestal
31PC
1PC
41PC
1PCBackStretcher
End Panel
I248-307-1
I248-308-1
Bolt 1/4" x3/4" 2PCS
10 PCS
HARDWARELIST:I248-308-1/308-SLT-1
1PC
No.
G
H
I
J
Description Sketch Quantity
Bolt 1/4"x1-3/8"
Lock Washer1/4"
FlatWasher1/4" x3/4"
Allen Wrench 4mm
3PCS
F
COMPONENTSLIST:I248-308-1/308-SLT-1
No.
1Description Sketch Quantity ReturnDeskTop
2Pedestal 1PC
1PC
Bolt 1/4" x3/4" 6PCS
9PCS
9PCS
1PC
KMetalPlate
I248-307-1
TOOLSREQUIRED (NOTPROVIDED)
PHILLIPSSCREWDRIVER
ForOption 1 ForOption 2
06-28-2022

D
C
A
E
DeskTop
STEP3:Fullyextend the top rightdrawerand attach the end paneltothe table top by using 4bolts(A), lock
washers(C) and flatwashers(D). Donotcompletelytighten bolts.
DCAE
aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
Page2/5
STEP1:Remove the drawersfrom the pedestal: Fullyextend the drawer, then press the plastic tab downon the right
and up on the leftatthe same time asshownbelow. While holding the tabs pressed down/up, pull the drawerout.
PlasticTab
STEP2:Putthe desktop face downon a softsurface, attach the pedestalon the table top by using 4bolts(A), lock
washers(C) and flatwashers(D)asshownbelow. Then use anallen wrench totighten all the bolts.
Foroption1
ITEMNO:I248-307-1/307-SLT-1SinglePed Desk
I248-308-1/308-SLT-148"ReturnDesk
EndPanel
Top RightDrawer
Pedestal
03-22-2022

aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
STEP4:Attach the back stretchertothe pedestaland
end panelby using 2bolts(B), lock washers(C) and
flatwashers(D). Completelytighten all bolts. Push
back the top rightdrawer. Turnthe assembleddesk
tothe uprightposition.
STEP5:Replace all ofthe drawersinpedestal: Fullyextend
the slidesfrom the case. Then align the slides on the drawerto
the slideson the case asshown. Pushthe drawerback in. You
mayhave toslide the drawerinand outseveraltimes inorder
toproperlyalign the ball bearings.
FUNCTIONALITYINSTRUCTION
Adjusttheleveler
whennecessary
Leveleronlegs
Locking filedrawer hold
letter orlegalsize files
Flipdownkeyboardtray
B
C
DE
Press here torelease
Hook latch
Metalplate
Page3/5
Keysforfile lock.
Donottrash.
Remove the wood screws on
the back panelsofdrawerbox
toremove the rod loops and
file rodsifnecessary.
ForOption 1
ITEMNO:I248-307-1/307-SLT-1SinglePed Desk
I248-308-1/308-SLT-148"ReturnDesk
BackStretcher
EndPanel
03-22-2022

aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
STEP3:Remove the top rightdraweratthe single pedestaldeskby the same wayas the STEP1ofpage 2.
I
H
G
J
STEP4:Attach the assembledreturndesktothe peddeskby using 3bolts(G), lock washers(H)and
flatwashers(I). Completelytighten all bolts.
Page4/5
STEP1:Putthe returndesktop face downon a softsurface.
STEP2-1:Attach the pedestalon the table top by using 3bolts(F), lock washers(H)and flatwashers(I)
asshownbelow. Then use an allen wrench totighten all the bolts.
STEP2-2:Attach the metalplate on the returntable top by using 3bolts(G), lock washers(H)and flat
washers(I) asshownbelow. Donotcompletelytighten bolts.
Foroption2
I
H
F
J
I
H
G
J
ITEMNO:I248-307-1/307-SLT-1SinglePed Desk
I248-308-1/308-SLT-148"ReturnDesk
ReturnDeskTop
MetalPlate
Pedestal
03-22-2022

aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
FUNCTIONALITYINSTRUCTION
Adjusttheleveler
whennecessary
Leveleronlegs
Page5/5
LiftTop
ForOption 2
ITEMNO:I248-307-1/307-SLT-1SinglePed Desk
I248-308-1/308-SLT-148"ReturnDesk
03-22-2022

STEP1:Putthe hutch on the desktop.
Take off one screw from eachmetal
plate on the back ofhutch and swing it
inanideallocation as shownbelow.
Then re-secure the metalplate with
screwstodesk.
Page1/1
Thankyouforpurchasingthisqualityproduct.Besuretocheckallpacking material carefullyfor
small partsthatmaycomelooseinsidethe cartonduringshipment.
TOOLSREQUIRED (NOTPROVIDED)
PHILLIPSSCREWDRIVER
aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
ah
BEFORE USING THISPRODUCT PLEASEREAD, UNDERSTAND, AND FOLLOWTHESEINSTRUCTIONS.
Save these instructionsforfuture reference.
FORINDOORUSEONLY
FUNCTIONALITYINSTRUCTION
06-27-2022
ITEMNO:I248-307H-1/307H-SLT-1SinglePed DeskHutch
Adjusttheleveler
whennecessary
Leveleronlegs
I248-307H-1
I248-307-1 TabletHolders
TabletHolders
I248-307H-1
I248-307H-1
I248-307-1
I248-308-1
I248-307-1
