Chapter 1 Introduction
1.1 Package Contents
• NUC BOX 8265U/8365UE
• NUC-8265U/NUC-8365UE (pre-installed motherboard)
• 1 x SATA 1 to 1 Power Cable
• 4 x HDD Screws (M3x4)
• 1 x WiFi Module Screw
• 1 x Screw for M.2 slot
• 1 x 96W Power Adapter
• User Manual
Because the hardware specications might be updated, the content of this documentation
will be subject to change without notice.
If any items are missing or appear damaged, contact your authorized dealer.

NUC BOX 8265U/8365UE
PB 2
English
1.2 Product Specications
NUC BOX
8265U/8365UE Barebone
CPU
Intel® 8th Gen (Whiskey lake-U) Core™ MCP Processors
NUC BOX 8265U (I5-8265U QC, 1.6HGz, 15W)
NUC BOX 8365UE (I5-8365UE QC, 1.6GHz, 15 W)
OS N/A
Chipset SoC
Memory Supports Dual Channel DDR4 2400 MHz, 2 x SO-DIMM slots,
Max. 32GB
HDD
N/A
Optional
Supports 1 x 2.5" SATA HDD*/SSD
LAN Gigabit LAN
WiFi Optional
Audio Realtek ALC233
Front I/O 1 x USB 3.1(Type A), 2 x USB 2.0 (Type A), 1 x Audio-out with
MIC-In
Rear I/O 2 x USB 3.0 (Type A), 1 x HDMI, 2 x DP, 2 x LAN, DC-IN,
1 x Kensington lock
Power Unit 96W Adapter
eMMC
M.2
slot
2.5”HDD

3 4
English
* For NUC BOX 8265U/8365UE, it is not recommended to install 2.5” HDD. If you install the 2.5” HDD, please keep
the NUC BOX 8265U/8365UE in a vertical position to ensure better cooling performance.
Dimension 110.mm (W)x 118.5mm (D) x 67.3mm (H)
VESA Bracket included , supports 75 x 75 and 100 x 100 mm
Volume
(Liters) 0.6L
Operating
Temperature 0°C~40°C

NUC BOX 8265U/8365UE
3 4
English
1.3 Block Diagram

5 6
English

NUC BOX 8265U/8365UE
5 6
English
Chapter 2 Product Overview
is chapter provides diagrams showing the location of important components of
the NUC BOX 8265U/8365UE.
2.1 Front View
No. Description
1 USB 3.0 (Type A)
2Audio(Mic-in, Line-out)
3 2 x USB 2.0 (Type A)
4 Power Button
1 2
3
4

7 8
English
2.2 Rear View
No. Description
1DC-IN
2HDMI
3 2 x USB 3.0 (Type A)
4 2 x DisplayPort
5 2 x RJ-45
* ere are two LEDs on the LAN port. Please refer to the table below for the LAN port LED indications.
Activity / Link LED Speed LED
Status Description Status Description
O No Link O 10Mbps connection
Blinking Data Activity Orange 100Mbps connection
On Link Green 1Gbps connection
ACT/LINK LED
SPEED LED
LAN Port
1 2 3
4 5

NUC BOX 8265U/8365UE
7 8
English
2.3 Inside View
No. Description
1 Mini PCIe Slot
2 M.2 Slot
3 SATA 3.0 Connectors
4SO-DIMM Slot
5 Hard disk drive tray (compatible with 2.5" SATA HDD/SSD)
SO-DIMM memory, hard drive and mSATA SSD are not included with this system.
4
2
1
3
5

NUC BOX 8265U/8365UE
PB 9
English
Chapter 3 Hardware Installation
is chapter helps you install or remove important components.
3.1 How to Remove the Bottom Case
1. Remove the four screws on the bottom case.
2. en li up and remove the bottom panel..

10 11
English
3.2 How to Install the WiFi Module
1. Locate the WiFi Module slot on the motherboard.
2. Carefully insert the WiFi Module into the slot.
3. Tighten the screw to secure the WiFi Module to the motherboard.

NUC BOX 8265U/8365UE
10 11
English
3.3 How to Install the M.2 SSD
1. Locate the M.2 slot on the motherboard.
2. Carefully insert the M.2 SSD into the slot.
3. Tighten the screw to secure the M.2 SSD to the motherboard.

12 13
English
3.4 How to Install the 2.5-inch Hard Drive
1. Remove the four screws on the bottom case. en li up and remove the bottom panel.
2. Attach the HDD to the hard drive mounting bracket and secure it using the four
screws.

NUC BOX 8265U/8365UE
12 13
English
3. Attach the HDD assembly to the bottom panel and secure it using the four screws.
Connect the SATA Data and Power Cable to the HDD.
4. en reinstall the bottom panel.

14 15
English
3.5 How to Install the Memory Modules
(DDR4 Low Voltage (1.2V))
1. Carefully insert the SO-DIMM memory modules into the slot at a 30-degree angle.
2. Push down until the modules snap into place.
1. e NUC BOX 8265U/8365UE requires DDR4 SO-DIMM (1.2V).
2. For dual channel conguration, you always need to install identical (the same brand,
speed, size and chip-type) DDR4 SO-DIMM pairs.
e SO-DIMM only ts in one correct orientation. It will cause permanent damage to the
motherboard and the DIMM if you force the DIMM into the slot at incorrect orientation.

NUC BOX 8265U/8365UE
14 15
English
3.6 How to Install the M.2 Heatsink
1. Gently insert the M.2 module, along the guiding tabs, into the heatsink bracket.
2. Remove the membranes from both sides of the thermal pad. en paste the thermal
pad onto the M.2 module.
3. Align the heatsink to the edge of the bracket and press down the heatsink into the
bracket until it clips into place.
