ASROCK EP2C606-4L/D16 User manual

1
EP2C606-4L/D16
EP2C602-4L/D16
EP2C602/D16
EP2C606-4L
EP2C602-4L
EP2C602
User Manual
Version 1.0
Published Jan 2013
Copyright©2013 ASRock INC. All rights reserved.

2
Copyright Notice:
No part of this manual may be reproduced, transcribed, transmitted, or translated in
any language, in any form or by any means, except duplication of documentation by
the purchaser for backup purpose, without written consent of ASRock Inc.
Products and corporate names appearing in this manual may or may not be regis-
tered trademarks or copyrights of their respective companies, and are used only for
identication or explanation and to the owners’ benet, without intent to infringe.
Disclaimer:
Specications and information contained in this manual are furnished for informa-
tional use only and subject to change without notice, and should not be constructed
as a commitment by ASRock. ASRock assumes no responsibility for any errors or
omissions that may appear in this manual.
With respect to the contents of this manual, ASRock does not provide warranty of
any kind, either expressed or implied, including but not limited to the implied warran-
ties or conditions of merchantability or tness for a particular purpose.
In no event shall ASRock, its directors, ofcers, employees, or agents be liable for
any indirect, special, incidental, or consequential damages (including damages for
loss of prots, loss of business, loss of data, interruption of business and the like),
even if ASRock has been advised of the possibility of such damages arising from
any defect or error in the manual or product.
This device complies with Part 15 of the FCC Rules. Operation is subject to the fol-
lowing two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
CALIFORNIA, USA ONLY
The Lithium battery adopted on this motherboard contains Perchlorate, a toxic
substance controlled in Perchlorate Best Management Practices (BMP) regulations
passed by the California Legislature. When you discard the Lithium battery in Cali-
fornia, USA, please follow the related regulations in advance.
“Perchlorate Material-special handling may apply, see
www.dtsc.ca.gov/hazardouswaste/perchlorate”
ASRock Website: http://www.asrock.com

3
Contents
1 Introduction ....................................................... 5
1.1 Package Contents............................................... 5
1.2 Specications ...................................................... 6
1.3 Motherboard Layout ............................................ 12
1.4 I/O Panel ............................................................. 33
1.5 Block Diagram..................................................... 39
2 Installation ......................................................... 45
2.1 Pre-installation Precautions ................................ 45
2.2 Screw Holes ........................................................ 45
2.3 CPU Installation .................................................. 46
2.4 Installation of Heatsink and CPU fan .................. 48
2.5 Installation of Memory Modules (DIMM) ............. 49
2.6 Expansion Slots (PCI and PCI Express Slots) .... 51
2.7 Jumpers Setup .................................................... 53
2.8 Onboard Headers and Connectors ..................... 54
2.9 Driver Installation Guide...................................... 64
2.10 Hot Plug for Hard Disk Drives ............................ 65

4
3 UEFI SETUP UTILITY......................................... 66
3.1 Introduction ......................................................... 66
3.1.1 UEFI Menu Bar........................................... 66
3.1.2 Navigation Keys ......................................... 67
3.2 Main Screen ........................................................ 68
3.3 Advanced Screen ................................................ 69
3.3.1 ACPI Conguration..................................... 70
3.3.2 WHEA Conguration .................................. 72
3.3.3 CPU Conguration ..................................... 73
3.3.4 North Bridge Conguration......................... 75
3.3.5 South Bridge Conguration ........................ 79
3.3.6 USB Conguration...................................... 80
3.3.7 Intel ME Subsystem ................................... 81
3.3.8 Clock Generator Conguration................... 82
3.3.8 Storage Conguration ................................ 83
3.3.10 Super IO Conguration............................. 85
3.3.11 Serial Port Console Redirection ............... 86
3.3.12 Voltage Control......................................... 87
3.4 Hardware Health Event Monitoring Screen......... 88
3.5 Server Management............................................ 90
3.6 Boot Screen ........................................................ 91
3.7 Security Screen................................................... 93
3.8 Exit Screen.......................................................... 94
3.9 Event Logs .......................................................... 95
4 Software Support .............................................. 96
4.1 Install Operating System ..................................... 96
4.2 Support CD Information ...................................... 96
4.2.1 Running Support CD .................................. 96
4.2.2 Drivers Menu .............................................. 96
4.2.3 Utilities Menu.............................................. 96
4.2.4 Contact Information .................................... 96
5 Troubleshooting ................................................ 97
5.1 Troubleshooting Procedures ............................... 97
5.2 Technical Support Procedures ............................ 97
5.3 Returning Merchandise for Service..................... 97

5
Chapter 1: Introduction
Thank you for purchasing ASRock EP2C606-4L/D16 / EP2C602-4L/D16
/ EP2C602/D16 / EP2C606-4L / EP2C602-4L / EP2C602 motherboard, a
reliable motherboard produced under ASRock’s consistently stringent qual-
ity control. It delivers excellent performance with robust design conforming
to ASRock’s commitment to quality and endurance.
In this manual, chapter 1 and 2 contains the introduction of the mother-
board and step-by-step hardware installation guide. Chapter 3 and 4 con-
tains the conguration guide of BIOS setup and information of the Support
CD.
Because the motherboard specications and the BIOS software
might be updated, the content of this manual will be subject to
change without notice. In case any modications of this manual
occur, the updated version will be available on ASRock’s web-
site without further notice. You may nd the latest VGA cards
and CPU support list on ASRock’s website as well. ASRock
website http://www.asrock.com
If you require technical support related to this motherboard,
please visit our website for specic information about the model
you are using.
www.asrock.com/support/index.asp
1.1 Package Contents
ASRock EP2C606-4L/D16 / EP2C602-4L/D16 / EP2C602/D16 / EP2C606-
4L / EP2C602-4L / EP2C602 Motherboard (SSI EEB Form Factor: 12.0-in
x 13-in, 30.5 cm x 26.7 cm)
Quick Installation Guide
Support CD
5 x Serial ATA (SATA) Data Cables (Optional)
1 x I/O Panel Shield

6
1.2 Specications
EP2C606-4L/D16 / EP2C602-4L/D16 / EP2C602/D16:
Physical
Status
Form Factor EEB
Dimension 12'' x 13'' (30.5 cm x 33 cm)
Processor
System
CPU
- Supports Intel®Xeon processor E5-
1600*/2600/4600 & v2 series
* E5-1400 & E5-1600 support single socket.
Socket Dual Socket R (LGA2011)
Power Phase 6 +1 Power Phase Design
Chipset
EP2C606-4L/D16
Intel®C606
EP2C602-4L/D16 / EP2C602/D16
Intel®C602
BIOS BIOS type 64Mb AMI UEFI Legal BIOS with GUI
support
System
Memory
Max.
Capacity 256GB DDR3 RDIMM
Socket 16 x 240-pin DDR3 DIMM slots
Type Quad Channel DDR3 1600/1333/1066 LR /
Registered /ECC/ UDIMM
Voltage - 1.5V, 1.35V
Expansion
Slot
PCIe 3.0 x 16 4 slots (2 x16, 1 x16/x8, 1 x8/x0)
PCIe 3.0 x 4 1 slots
PCI 1 slots
Storage
SATA/SAS
controller
EP2C606-4L/D16
2 x SATA3 6.0 Gb/s , 4 x SATA2 3.0 Gb/s ,
8xSATA2/SAS 3Gb/s
EP2C602-4L/D16 / EP2C602/D16
2 x SATA3 6.0 Gb/s , 8 x SATA2 3.0 Gb/s
Additional
SATA
controller
Marvell 9230 : 4 x SATA3 6.0 Gb/s
BMC Controller ASPEED AST2300

7
Graphics
Controller ASPEED AST2300
VRAM DDR3 16MB
Output Supports D-Sub with max. resolution up to
1920x1200 @ 60Hz
Ethernet
Interface Gigabit LAN 10/100/1000 Mb/s
IPMI
dedicated
GLAN
Realtek RTL8211E
LAN
Controller
EP2C606-4L/D16 / EP2C602-4L/D16
4 x Intel
®
82574L
EP2C602/D16
2 x Intel
®
82574L
Rear Panel
I/O
Lan port
(RJ45)
EP2C606-4L/D16 / EP2C602-4L/D16
4 + 1 (for IPMI)
EP2C602/D16
2 + 1 (for IPMI)
PS/2 KB/
mouse 2
VGA port D-sub x 1
USB port 2 x USB 2.0
Serial port 1 (COM1)
Internal
connector
COM port
header 1 (COM2)
Auxiliary
panel header
1 (include chassis intrusion , location button
& LED, front LAN LED)
TPM header 1
IPMB header 1
Buzzer 1
Fan header
"8 x 4-pin" or "6 x 4-pin and 2 x 3-pin"
*CPU fan header have 3-pin and 4-pin, only
one of them can be used at a time.
ATX power 1 (24-pin) + 2(8-pin)
USB header 2 (each support 2 USB 2.0)
Type A USB
2.0 port 1

8
Internal
connector
80 debug
port LED 1
Front panel 1
Speaker
(4pin) 1
Support OS OS Microsoft®Windows®Server 2008 / 2008
R2 / Linux compliant
* For detailed product information, please visit our website: http://www.asrock.com

9
EP2C606-4L / EP2C602-4L / EP2C602:
Physical
Status
Form Factor EEB
Dimension 12'' x 13'' (30.5 cm x 33 cm)
Processor
System
CPU
- Supports Intel®Xeon processor E5-
1600*/2600/4600 & v2 series
* E5-1400 & E5-1600 support single socket.
Socket Dual Socket R (LGA2011)
Power Phase 6 +1 Power Phase Design
Chipset
EP2C606-4L
Intel®C606
EP2C602-4L / EP2C602
Intel®C602
BIOS BIOS type 64Mb AMI UEFI Legal BIOS with GUI
support
System
Memory
Max.
Capacity 128GB DDR3 RDIMM
Socket 8 x 240-pin DDR3 DIMM slots
Type Quad Channel DDR3 1600/1333/1066 LR /
Registered /ECC/ UDIMM
Voltage - 1.5V, 1.35V
Expansion
Slot
PCIe 3.0 x 16 5 slots (3 x16, 1 x16/x8, 1 x8/x0)
PCIe 3.0 x 4 1 slots
PCI 1 slots
Storage
SATA/SAS
controller
EP2C606-4L
2 x SATA3 6.0 Gb/s , 4 x SATA2 3.0 Gb/s ,
8x SATA2/SAS 3Gb/s
EP2C602-4L / EP2C602
2 x SATA3 6.0 Gb/s , 8 x SATA2 3.0 Gb/s
Additional
SATA
controller
Marvell 9230 : 4 x SATA3 6.0 Gb/s
BMC Controller ASPEED AST2300

10
Graphics
Controller ASPEED AST2300
VRAM DDR3 16MB
Output Supports D-Sub with max. resolution up to
1920x1200 @ 60Hz
Ethernet
Interface Gigabit LAN 10/100/1000 Mb/s
IPMI
dedicated
GLAN
Realtek RTL8211E
LAN
Controller
EP2C606-4L / EP2C602-4L
4 x Intel
®
82574L
EP2C602
2 x Intel
®
82574L
Rear Panel
I/O
Lan port
(RJ45)
EP2C606-4L / EP2C602-4L
4 + 1 (for IPMI)
EP2C602
2 + 1 (for IPMI)
PS/2 KB/
mouse 2
VGA port D-sub x 1
USB port 2 x USB 2.0
Serial port 1 (COM1)
Internal
connector
COM port
header 1 (COM2)
Auxiliary
panel header
1 (include chassis intrusion , location button
& LED, front LAN LED)
TPM header 1
IPMB header 1
Buzzer 1
Fan header
"8 x 4-pin" or "6 x 4-pin and 2 x 3-pin"
*CPU fan header have 3-pin and 4-pin, only
one of them can be used at a time.
ATX power 1 (24-pin) + 2(8-pin)
USB header 2 (each support 2 USB 2.0)
Type A USB
2.0 port 1

11
Internal
connector
80 debug
port LED 1
Front panel 1
Speaker
(4pin) 1
Support OS OS Microsoft®Windows®Server 2008 / 2008
R2 / Linux compliant
* For detailed product information, please visit our website: http://www.asrock.com

12
1.4 Motherboard Layout
EP2C606-4L/D16
30.5cm (12 in)
26.7cm (13 in)
Intel
C606
ATXPWR1
DDR3_B2 (64 bit, 240-pin module)
DDR3_B1 (64 bit, 240-pin module)
DDR3_A2 (64 bit, 240-pin module)
DDR3_A1 (64 bit, 240-pin module)
DDR3_H2 (64 bit, 240-pin module)
DDR3_H1 (64 bit, 240-pin module)
DDR3_G2 (64 bit, 240-pin module)
DDR3_G1 (64 bit, 240-pin module)
DDR3_E1 (64 bit, 240-pin module)
DDR3_E2 (64 bit, 240-pin module)
DDR3_F1 (64 bit, 240-pin module)
DDR3_F2 (64 bit, 240-pin module)
DDR3_C1 (64 bit, 240-pin module)
DDR3_C2 (64 bit, 240-pin module)
DDR3_D1 (64 bit, 240-pin module)
DDR3_D2 (64 bit, 240-pin module)
EP2C606-4L/D16
ATX12V2
ATX12V1
PS2
Keyboard
PS2
Mouse
VGA
Top:
LAN2
USB 2.0
T: USB0
B: USB1
IPMI
LAN
LAN4 LAN3
COM1
PCI1
PCIE6
CMOS
Battery
RoHS
Dr.
Debug
PCIE5
1
USB_6
CLRCMOS2
1
TR1FRONT_LED_LAN34
HDLED RESET
PLED PWRBTN
PANEL1
USB_4_5
1
COM2
1
1
TPM1
NMI_BTN1
1
AUX_PANEL1
1
ME_RECOVERY1
1
IPMB_1
1
57
SATA_SGPIO1
1
BMC
ROM
UP_ROM1
1
BUZZER1
64Mb
BIOS
BMC_SMB1
1
USB_2_3
1
Super
I/O
1
SCU_SGPIO1
1
1
SCU_SGPIO2 SATA_SGPIO2
SCU_PORT_7 SCU_PORT_6 SCU_PORT_5 SCU_PORT_4
SCU_PORT_3 SCU_PORT_2 SCU_PORT_1 SCU_PORT_0
SATAIII_M0
SATAIII_0
SATAIII_M1
SATAIII_1
SATAIII_M 2
SATAII_ 2
SATAIII_M 3
SATAII_ 3
SATAII_ 4
SATAII_ 5
PSU_CLK_SEL1
PSU_DATA_SEL2
PSU_ALT_SEL3
111
CPU_FAN1_1
CPU_FAN2_1
CPU_FAN1_2
CPU_FAN2_2
REAR_FAN1
REAR_FAN2
PCIE4
PCIE3
PCIE2
LAN1
451 23 6
7
9
8
1
PSU_SMB1
12
14
FRNT_FAN4
FRNT_FAN3
FRNT_FAN2
FRNT_FAN1
10
11
13
16
15
17
18
19
20
21
22
23
25
24
27
29
30
26
32
35 34 33
36 39404142
43 44
4748495052535458 5556 45 37
38
46
51
60
62
63
64
67
68
69
70
71
72
73
74
66
65
59
61
31
1
SPEAKER1
28

13
12 x 240-pin DDR3 DIMM Slots
(DDR3_G2, DDR3_H2, White)
22 x 240-pin DDR3 DIMM Slots
(DDR3_G1, DDR3_H1, Blue)
32 x 240-pin DDR3 DIMM Slots
(DDR3_A2, DDR3_B2, White)
4ATX Power Connector (ATXPWR1)
5ATX 12V Power Connector (ATX12V1)
62 x 240-pin DDR3 DIMM Slots
(DDR3_A1, DDR3_B1, Blue)
7CPU Fan Connector (CPU_FAN1_2)
8CPU Fan Connector (CPU_FAN1_1)
92011-Pin CPU Socket (CPU_BSP1)
10 Front Fan Connector (FRNT_FAN1)
11 Front Fan Connector (FRNT_FAN2)
12 Front Fan Connector (FRNT_FAN3)
13 Front Fan Connector (FRNT_FAN4)
14 PSU SMBus (PSU_SMB1)
15 2 x 240-pin DDR3 DIMM Slots
(DDR3_F2, DDR3_E2, White)
16 2 x 240-pin DDR3 DIMM Slots
(DDR3_D1, DDR3_C1, Blue)
17 PSU Jumpers
(PSU_CLK_SEL1, PSU_DATA_SEL2, PSU_ALT_SEL3)
18 SATA3 Connector (SATAIII_M0, White)
19 SATA3 Connector (SATAIII_M1, White)
20 SATA3 Connector (SATAIII_M2, White)
21 SATA3 Connector (SATAIII_M3, White)
22 SATA3 Connector (SATA III _0, White)
23 SATA3 Connector (SATA III _1, White)
24 Speaker Header (SPEAKER1)
25 SATA2 Connector (SATAII_2, Blue)
26 SCU SGPIO Connector (SCU_SGPIO2)
27 SATA2 Connector (SATAII_3, Blue)
28 SATA2 Connector (SATAII_4, Blue)

14
29 SATA SGPIO Connector (SATA_SGPIO2)
30 SATA2 Connector (SATAII_5, Blue)
31 SATA SGPIO Connector (SATA_SGPIO1)
32 SCU Connector (SCU_PORT_7, Black)
33 SCU Connector (SCU_PORT_6, Black)
34 SCU Connector (SCU_PORT_5, Black)
35 SCU Connector (SCU_PORT_4, Black)
36 SCU SGPIO Connector (SCU_SGPIO1)
37 UP ROM Header (UP_ROM1)
38 ME Recovery Jumper (ME_RECOVERY1)
39 SCU Connector (SCU_PORT_3, Black)
40 SCU Connector (SCU_PORT_2, Black)
41 SCU Connector (SCU_PORT_1, Black)
42 SCU Connector (SCU_PORT_0, Black)
43 System Panel Header (PANEL1)
44 SPI Flash Memory (64Mb)
45 Dr. Debug
46 USB 2.0 Ports (USB_4_5)
47 USB 2.0 Ports (USB_2_3)
48 USB 2.0 Ports (USB_6)
49 Buzzer (BUZZER1)
50 Auxiliary panel header (AUX_PANEL1)
51 Front Lan LED Connector (FRONT_LED_LAN34)
52 Thermal Sensor header (TR1)
53 TPM Header (TPM1)
54 BMC SMB Header (BMC_SMB1)
55 Non Maskable Interrupt Button (NMI_BTN1)
56 Intelligent Platform Management Bus header (IPMB_1)
57 COM Port Header (COM2)
58 BMC ROM
59 PCI Slot (PCI1, White)
60 PCI Express 3.0 x16 Slot (PCIE2, Blue) from CPU_BSP1
61 Intel C606 Chipset
62 PCI Express 3.0 x16 Slot (PCIE3, Blue) from CPU_BSP1
63 PCI Express 3.0 x16 Slot (PCIE4, Blue) from CPU_BSP1

15
64 PCI Express 3.0 x16 Slot (PCIE5, Blue) from CPU_AP1
65 Clear CMOS Pad (CLRCMOS2)
66 PCI Express 2.0 x 4 Slot (PCIE6, White) from CPU_BSP1
67 2 x 240-pin DDR3 DIMM Slots
(DDR3_D2, DDR3_C2, White)
68 2 x 240-pin DDR3 DIMM Slots
(DDR3_F1, DDR3_E1, Blue)
69 Rear Fan Connector (REAR_FAN2)
70 Rear Fan Connector (REAR_FAN1)
71 CPU Fan Connector (CPU_FAN2_2)
72 CPU Fan Connector (CPU_FAN2_1)
73 2011-Pin CPU Socket (CPU_AP1)
74 ATX 12V Power Connector (ATX12V2)

16
EP2C602-4L/D16
30.5cm (12 in)
26.7cm (13 in)
Intel
C602
ATXPWR1
DDR3_B2 (64 bit, 240-pin module)
DDR3_B1 (64 bit, 240-pin module)
DDR3_A2 (64 bit, 240-pin module)
DDR3_A1 (64 bit, 240-pin module)
DDR3_H2 (64 bit, 240-pin module)
DDR3_H1 (64 bit, 240-pin module)
DDR3_G2 (64 bit, 240-pin module)
DDR3_G1 (64 bit, 240-pin module)
DDR3_E1 (64 bit, 240-pin module)
DDR3_E2 (64 bit, 240-pin module)
DDR3_F1 (64 bit, 240-pin module)
DDR3_F2 (64 bit, 240-pin module)
DDR3_C1 (64 bit, 240-pin module)
DDR3_C2 (64 bit, 240-pin module)
DDR3_D1 (64 bit, 240-pin module)
DDR3_D2 (64 bit, 240-pin module)
EP2C602-4L/D16
ATX12V2
PS2
Keyboard
PS2
Mouse
VGA
Top:
LAN2
USB 2.0
T: USB0
B: USB1
IPMI
LAN
LAN4 LAN3
COM1
PCI1
PCIE6
CMOS
Battery
RoHS
Dr.
Debug
PCIE5
1
USB_6
CLRCMOS2
1
TR1FRONT_LED_LAN34
HDLED RESET
PLED PWRBTN
PANEL1
USB_4_5
1
COM2
1
1
TPM1
NMI_BTN1
1
AUX_PANEL1
1
ME_RECOVERY1
1
IPMB_1
1
52
SATA_SGPIO1
1
BMC
ROM
UP_ROM1
1
BUZZER1
64Mb
BIOS
BMC_SMB1
1
USB_2_3
1
Super
I/O
1
SCU_SGPIO1
1
SATA_SGPIO2
SCU_PORT_3 SCU_PORT_2 SCU_PORT_1 SCU_PORT_0
SATAIII_M0
SATAIII_0
SATAIII_M1
SATAIII_1
SATAIII_M
2
SATAII_
2
SATAIII_M 3
SATAII_
3
SATAII_ 4
SATAII_ 5
PSU_CLK_SEL1
PSU_DATA_SEL2
PSU_ALT_SEL3
111
CPU_FAN1_1
CPU_FAN2_1
CPU_FAN1_2
CPU_FAN2_2
REAR_FAN1
REAR_FAN2
PCIE4
PCIE3
PCIE2
LAN1
451 23 6
7
9
8
1
PSU_SMB1
12
14
FRNT_FAN4
FRNT_FAN3
FRNT_FAN2
FRNT_FAN1
10
11
13
16
15
17
18
19
20
21
22
23
25
24
26
29
30
34353637
38 39
4243444547484953 5051 40 32
33
41
46
55
57
58
59
62
63
64
65
66
67
68
69
61
60
54
56
1
SPEAKER1
ATX12V1
27
31
28

17
12 x 240-pin DDR3 DIMM Slots
(DDR3_G2, DDR3_H2, White)
22 x 240-pin DDR3 DIMM Slots
(DDR3_G1, DDR3_H1, Blue)
32 x 240-pin DDR3 DIMM Slots
(DDR3_A2, DDR3_B2, White)
4ATX Power Connector (ATXPWR1)
5ATX 12V Power Connector (ATX12V1)
62 x 240-pin DDR3 DIMM Slots
(DDR3_A1, DDR3_B1, Blue)
7CPU Fan Connector (CPU_FAN1_2)
8CPU Fan Connector (CPU_FAN1_1)
92011-Pin CPU Socket (CPU_BSP1)
10 Front Fan Connector (FRNT_FAN1)
11 Front Fan Connector (FRNT_FAN2)
12 Front Fan Connector (FRNT_FAN3)
13 Front Fan Connector (FRNT_FAN4)
14 PSU SMBus (PSU_SMB1)
15 2 x 240-pin DDR3 DIMM Slots
(DDR3_F2, DDR3_E2, White)
16 2 x 240-pin DDR3 DIMM Slots
(DDR3_D1, DDR3_C1, Blue)
17 PSU Jumpers
(PSU_CLK_SEL1, PSU_DATA_SEL2, PSU_ALT_SEL3)
18 SATA3 Connector (SATAIII_M0, White)
19 SATA3 Connector (SATAIII_M1, White)
20 SATA3 Connector (SATAIII_M2, White)
21 SATA3 Connector (SATAIII_M3, White)
22 SATA3 Connector (SATA III _0, White)
23 SATA3 Connector (SATA III _1, White)
24 Speaker Header (SPEAKER1)
25 SATA2 Connector (SATAII_2, Blue)
26 SATA2 Connector (SATAII_3, Blue)
27 SATA2 Connector (SATAII_4, Blue)
28 SATA2 Connector (SATAII_5, Blue)

18
29 SATA SGPIO Connector (SATA_SGPIO2)
30 SATA SGPIO Connector (SATA_SGPIO1)
31 SCU SGPIO Connector (SCU_SGPIO1)
32 UP ROM Header (UP_ROM1)
33 ME Recovery Jumper (ME_RECOVERY1)
34 SCU Connector (SCU_PORT_3, Blue)
35 SCU Connector (SCU_PORT_2, Blue)
36 SCU Connector (SCU_PORT_1, Blue)
37 SCU Connector (SCU_PORT_0, Blue)
38 System Panel Header (PANEL1)
39 SPI Flash Memory (64Mb)
40 Dr. Debug
41 USB 2.0 Ports (USB_4_5)
42 USB 2.0 Ports (USB_2_3)
43 USB 2.0 Ports (USB_6)
44 Buzzer (BUZZER1)
45 Auxiliary panel header (AUX_PANEL1)
46 Front Lan LED Connector (FRONT_LED_LAN34)
47 Thermal Sensor header (TR1)
48 TPM Header (TPM1)
49 BMC SMB Header (BMC_SMB1)
50 Non Maskable Interrupt Button (NMI_BTN1)
51 Intelligent Platform Management Bus header (IPMB_1)
52 COM Port Header (COM2)
53 BMC ROM
54 PCI Slot (PCI1, White)
55 PCI Express 3.0 x16 Slot (PCIE2, Blue) from CPU_BSP1
56 Intel C602 Chipset
57 PCI Express 3.0 x16 Slot (PCIE3, Blue) from CPU_BSP1
58 PCI Express 3.0 x16 Slot (PCIE4, Blue) from CPU_BSP1
59 PCI Express 3.0 x16 Slot (PCIE5, Blue) from CPU_AP1
60 Clear CMOS Pad (CLRCMOS2)
61 PCI Express 3.0 x 4 Slot (PCIE6, White) from CPU_BSP1
62 2 x 240-pin DDR3 DIMM Slots
(DDR3_D2, DDR3_C2, White)

19
63 2 x 240-pin DDR3 DIMM Slots
(DDR3_F1, DDR3_E1, Blue)
64 Rear Fan Connector (REAR_FAN2)
65 Rear Fan Connector (REAR_FAN1)
66 CPU Fan Connector (CPU_FAN2_2)
67 CPU Fan Connector (CPU_FAN2_1)
68 2011-Pin CPU Socket (CPU_AP1)
69 ATX 12V Power Connector (ATX12V2)

20
EP2C602/D16
30.5cm (12 in)
26.7cm (13 in)
Intel
C602
ATXPWR1
DDR3_B2 (64 bit, 240-pin module)
DDR3_B1 (64 bit, 240-pin module)
DDR3_A2 (64 bit, 240-pin module)
DDR3_A1 (64 bit, 240-pin module)
DDR3_H2 (64 bit, 240-pin module)
DDR3_H1 (64 bit, 240-pin module)
DDR3_G2 (64 bit, 240-pin module)
DDR3_G1 (64 bit, 240-pin module)
DDR3_E1 (64 bit, 240-pin module)
DDR3_E2 (64 bit, 240-pin module)
DDR3_F1 (64 bit, 240-pin module)
DDR3_F2 (64 bit, 240-pin module)
DDR3_C1 (64 bit, 240-pin module)
DDR3_C2 (64 bit, 240-pin module)
DDR3_D1 (64 bit, 240-pin module)
DDR3_D2 (64 bit, 240-pin module)
EP2C602/D16
ATX12V2
PS2
Keyboard
PS2
Mouse
VGA
Top:
LAN2
USB 2.0
T: USB0
B: USB1
IPMI
LAN
COM1
PCI1
PCIE6
CMOS
Battery
RoHS
Dr.
Debug
PCIE5
USB_6
CLRCMOS2
1
TR1
HDLED RESET
PLED PWRBTN
PANEL1
USB_4_5
1
COM2
1
1
TPM1
NMI_BTN1
1
AUX_PANEL1
1
ME_RECOVERY1
1
IPMB_1
1
51
SATA_SGPIO1
1
BMC
ROM
UP_ROM1
1
BUZZER1
64Mb
BIOS
BMC_SMB1
1
USB_2_3
1
Super
I/O
1
SCU_SGPIO1
1
SATA_SGPIO2
SCU_PORT_3 SCU_PORT_2 SCU_PORT_1 SCU_PORT_0
SATAIII_M0
SATAIII_0
SATAIII_M1
SATAIII_1
SATAIII_M
2
SATAII_
2
SATAIII_M 3
SATAII_
3
SATAII_ 4
SATAII_ 5
PSU_CLK_SEL1
PSU_DATA_SEL2
PSU_ALT_SEL3
111
CPU_FAN1_1
CPU_FAN2_1
CPU_FAN1_2
CPU_FAN2_2
REAR_FAN1
REAR_FAN2
PCIE4
PCIE3
PCIE2
LAN1
451 23 6
7
9
8
1
PSU_SMB1
12
14
FRNT_FAN4
FRNT_FAN3
FRNT_FAN2
FRNT_FAN1
10
11
13
16
15
17
18
19
20
21
22
23
25
24
26
29
30
34353637
38 39
4243444546474852 4950 40 32
33
41
54
56
57
58
61
62
63
64
65
66
67
68
60
59
53
55
1
SPEAKER1
ATX12V1
27
31
28
