ASTA GPS TRACKERS EV-07S Manual

THE EV-07S PERSONAL GPS
TRACKER FROM ASTA GPS
TRACKERS
STEP BY STEP SET UP GUIDE
BY ASTA GPS TRACKERS

EV-07S PACKAGE CONTENTS
•EV-07S PERSONAL TRACKING
DEVICE.
•FREE UK PAY AS YOU GO SIM.
•USB POWER CABLE.
•3 PIN UK 13A USB CHARGING
PLUG.
•LANYARD.
•USB DOCKING CHARGER.
•USER MANUAL.

EV-07S KEY FEATURES
•REAL TIME TRACKING VIA FREE
ON-LINE WEB BASED TRACKING
PLATFORM AND FREE SMART
PHONE APPS.
•FALL DETECTION WITH INSTANT
EMERGENCY MESSAGE AND CALL
FUNCTION.
•2 WAY CALLING.
•3 PRE-SET EMERGENCY CONTACTS
NUMBERS.
•INSTANT SOS ALERT SMS MESSAGE
WITH GOOGLE MAPS LINK.
•GEO-FENCE PRE-SET BOUNDRIES
WITH INSTANT ALERT.
•WATERPROOF TO IPX6
•THE EV-07S HAS BUILT-IN U-BLOX
GPS AND GSM/GPRS
TECHNOLOGY.

SETTING UP YOUR EV-07S GPS TRACKER FOR
THE FIRST TIME
•FOR THE FIRST TIME CHARGING WE
RECOMMEND CHARGING FOR 2 TO 3 HOURS
IN THE SUPPLIED USB CHARGING DOCK.
•PLUG THE USB LEAD IN TO THE BACK OF THE
USB CHARGING DOCK AND CONNECT THE
OTHER END TO A USB PORT ON YOUR PC OR
LAPTOP.
•OR CONNECT USB CABLE TO THE SUPPLIED
USB 13AMP 3 PIN PLUG AND CONNECT TO A
POWER OUTLET.
•PLACE THE EV-07S PERSONAL GPS TRACKER IN
TO THE USB CHANGING DOCK AND THE RED
LED LIGHTS UP IN THE FRONT OF THE
DOCKING STATION.

SWITCHING THE EV-07S GPS TRACKER
ON AND OFF
•TO TURN THE EV-07S ON:
•PRESS THE SIDE POWER BUTTON FOR 1
SECOND, ALL THE LED’S WILL FLASH RAPIDLY.
•THE EV-07S WILL TURN ON AUTOMATICALLY
BY PLACING IT IN THE USB CHARGING DOCK
OR CONNECTING THE USB CABLE DIRECTLY.
•TO GET AN INITIAL LOCATION, USE OUT
DOORS OR NEAR A WINDOW, SO THE EV-07S
MAY FIX ON TO A SATELITE.
•TO TURN OFF THE EV-07S:
•PRESS AND HOLD THE SIDE POWER BUTTON
AND THE SOS BUTTON TOGETHER FOR 1
SECOND UNTILL THE LED’S TURN OFF.

WHAT DO THE LIGHTS MEAN? BLUE
LED
•BLUE LED ON -THE DEVICE IS
CHARGING.
•BLUE LED BLINKING
QUICKLY –BATTERY POWER IS
BELOW 15%.
•BLUE LED IS OFF OR
BLINKING SLOWLY –THE
DEVICE HAS BEEN FULLY
CHARGED OR NOT CHARGING.

WHAT DO THE LIGHTS MEAN? GSM
GREEN LED
•GREEN LED LIGHT SHOWS A SINGLE
FLASH RAPIDLY EVERY 3 SECONDS –
THE EV-07S IS CONNECTED TO THE GSM
NETWORK.
•GREEN LED SHOWS A DOUBLE FLASH
RAPIDLY EVERY 3 SECONDS –THE
DEVICE IS REGISTERED TO THE GPRS
NETWORK.
•GREEN LED SHOWS A SLOW FLASH
EVERY 3 SECONDS –THE EV-07S IS
CONNECTING TO THE GSM NETWORK.
•GREEN LED IS ON AND IS NOT
FLASHING –NO SIM CARD IS DETECTED.

WHAT DO THE LIGHTS MEAN? GPS
BLUE LED
•BLUE LED SHOWS A SINGLE
FLASH EVERY 3 SECONDS –THE
EV-07S HAS A GPS POSITIONING
FIX.
•BLUE LED SHOWS A SLOW FLASH
EVERY 3 SECONDS (EVERY 1
SECOND ON AND 3 SECONDS
OFF) –THE EV-07S HAS NO GPS
FIX.
•BLUE LED OFF (WHEN NOT
CHARGING) –THE GPS CHIP IS
SLEEPING.

SETTING YOUR EV-07S DEVICE USER
NAME FOR SMS CONTENT
•TO MAKE IDENTIFYING YOUR EV-07S PERSONAL GPS TRACKING DEVICE
EASIER, WE WOULD RECOMMEND ASSIGNING A USER NAME.
•TO SET DEVICE USER NAME TEXT name1, FOLLOWED BY THE NAME YOU
WOULD LIKE TO SET.
•FOR EXAMPLE - YOU HAVE GIVEN THE EV-07S TO YOUR MUM AS SHE LIVES
ON HER OWN. SEND A TEXT MESSAGE TO THE EV-07S DEVICE WITH
name1,mum AND HIT SEND.
•THE EV-07S WILL THEN REPLY WITH A TEXT MESSAGE STATING “add name
ok!”
•TO DELETE THE ASSIGNED NAME TEXT name0 TO THE EV-07S.

EV-07S CONFIGURATION AND
OPERATION BY SMS
•1. TO SET THE AUTHORIZED NUMBERS –NOTE: IT IS NOT NESSESSARY TO SET ALL
THREE AURTHORIZED NUMBERS, HOWEVER A MINIMUM OF ONE MUST ALWAYS BE SET.
•OPEN THE TEXT MESSAGING ON YOUR PHONE AND SELECT THE EV-07S GPS TRACKER
FROM YOUR LIST OF CONTACTS (AMY SOS) AND SELECT CREATE TEXT MESSAGE.
•TO SET THE PRIMARY CONTACT TYPE A1, FOLLOWED BY THE PRIMARY CONTACT
NUMBER. A1,0161222888 WITH NO SPACES AND SELECT SEND MESSAGE. YOU WILL THEN
RECEIVE A TEXT REPLY STATING SET MOBILE NUMBER 1 OK!
•TO DELETE THE PRIMARY NUMBER, YOU CAN SEND A TEXT MESSAGE TO YOUR EV-07S
BY TEXTING A0.
•A1, PLUS PHONE NUMBER TO ADD AND A0 TO DELETE.
