Astak EZ READER User manual

V1.1

Contents
Safety Notice...................................................... 1
Your ASTAK EZ Reader.................................... 4
Start using your EZ Reader................................ 6
Installing Battery........................................ 6
Charging the battery................................... 6
Installing SD card....................................... 9
Switch On/Off .......................................... 10
Keyboard Lock......................................... 12
Downloading books is easy! .................... 13
Moving books and music from your
computer to the EZ Reader.................. 14
Search....................................................... 15
Searching by page ............................... 15
Search by sorting ................................. 17
Search by order.................................... 18
Recent File Reading ............................ 19
Switch between Bookshelves................... 20
Reading EZ Reader .................................. 21
Page Turning........................................ 21
Page turning by sequence......... 21

First/Last Page ......................... 22
Page Jump ................................ 22
Zoom In/Out ........................................ 24
Bookmark ............................................ 25
Index .................................................... 28
Information of Book............................ 30
Adjust the contrast and brightness of
pictures ................................................ 31
MP3 .......................................................... 32
System Setting.......................................... 34
Key Sound ........................................... 35
Language Setting................................. 36
Replacing Font..................................... 37
System Information ............................. 38
USB Connection ...................................... 39
Troubleshooting ....................................... 41
Specifications ................................................... 42
After-sales Service Guide ................................ 43

Safety Notice
For safe and efficient use of this product,
please strictly abide by the rules, otherwise
you will void your warranty and/or damage
the device.
Do not put the product under the direct sunlight,
or expose it to an extra high or low temperature
environment. Failure to do this may cause
distortion of the product and damage of the
electronic components and battery.
Do not put or use it in a humid environment. Do
not expose your new EZ Reader to water or any
liquid or excessive dampness as this will cause
the malfunction of operation of the internal
circuits.
Do not violently shake the product or drop it as
this will cause the damage of the product and its
electronic components.
Do not heavily press the display panel or put

objects on the display. We are not responsible
for improper carrying or storage during travels.
Do not put the product in a dusty, dirty place.
Use common sense! This is a fine instrument
and should be treated as such.
Do not use chemical solvents to clean the
surface of the product. Please use a soft cloth to
wipe up the dust from the surface of the screen
or the cover. You can use a little distilled water
on a clean cloth to remove the dirt on the screen
or the cover.
Do not disassemble the product. There are no
user serviceable parts. You will void your
warranty and damage the device!
Please pay attention to store the product or its
accessories in a safe place, where children or
pets cannot reach it!
2

Do not put the product near a magnetic field or
improper current.
Please use the authorized accessories, do not
use unmatched components.
Battery:
* Do not use the rechargeable battery if there
is visible surface damage.
* If the battery leaks liquid, please clean the
product and call toll free customer support
number for replacement of new battery within
warranty period. Battery acid can be harmful to
you also, so use considerable caution!
* Please properly recycle of the old batteries.
Do not just throw into the garbage!! This is the
law!! This product saves energy!! Please
assume stewardship for the earth!
This product is CE approved.
3

Your ASTAK EZ Reader
Front View
Indicato
r
Screen
N
umber key ○ 1
~○
5 /Bookmark
Go to index/○
7
Zoom/○
8
Exit
OK /Menu
Bookmark/○ 6
Previous Page/○
9
N
ext Page/○ 0
N
ext Pa
g
e
Previous Pa
g
e
4

Back View
Reset
Rechargeable
Batter
y
Volume Up (+)
/ Down(-)
Side View
SD Car
d
Slot
Power On/Off
To
p
View
USB PortHeadset Jack
Bottom View
5

Read the cautions below very carefully and
fully! This is a fine instrument and you do not
yet know HOW to keep it working beautifully!
LEARN what to do!
Start using your EZ Reader
Installing Battery
Open the battery cover on the back of the
device.
Install the battery!
according to the
instructions on the
battery slot.
Place battery as illustrated!
Charging the battery
6

* The Power supply of this product is used for
rechargeable battery.
* The battery should be charged at least twelve
hours when first utilized. It's better to recharge
it after its power is completely drained to
encourage the battery to charge fully each time!
Please do the above-mentioned process at least
during the first three times of use.
* It can be charged by USB cable○
1 . Use one
port of the USB cable to connect to the PC, the
other port connects to the device. It takes
approximately three hours to charge the battery
fully. The orange light will flash while the
battery is charging and green light will shine
steady when the battery is fully charged.
* It can be also charged by power adapter. ②
Connect the device with the power adapter, and
plug the power adapter in the socket (please see
the voltage scope on the adapter). It takes
approximately three hours to charge the battery.
The orange light will flash while the battery is
charging and green light will shine steady when
7

the battery is fully charged.
* Do not remove the battery while charging.
* The battery capacity icon is on the bottom
right corner. When the icon shows one grid
volume or system informs low battery volume:
please recharge the battery.
Full Low(please recharge)
* The device can be used while charging, but
the charging time will be increased.
* When the battery is charged at beginning
period, if the indicator is still red, this means the
power is not enough for startup, please
disconnect USB cable and then reconnect it.
* Do not use unauthorized battery and/or
charger. This is critical! Many chargers look
alike but operate on different voltage or
amperage!
* Do not remove the battery while charging is in
progress.
* Make positive you insert the battery with the
8

correct polarity into the polarized contacts. You
can damage the battery and/or device otherwise
and void your warranty or start a fire.
After you insert SD card,
bookshelf interface will
be automatically
displayed. To remove the
SD card, push in the SD
card until you hear a
click
,
then release it.
Insert the SD
card with the
label facing up
and forward
Installing SD card
Insert the SD card carefully and properly! Do
not attempt to force it in! Reverse the card in
the slot if it does not go in easily. It should
insert easily and lock itself into place if done
right!
9

Switch On/Off
Switch on：
Press and hold on/off button to power on.
(Silver button on top of device).
Press
Power On/Off
off
Bookshelf Home Page
10

Switch off：
Press and hold the on/off button for about three
seconds to turn the power off.
Press and Hold
Power On/Off
An
y
Interface
Power off
11

Keyboard Lock
Press on/off button shortly, lock/unlock
keyboard.
An
y
interface Lock ke
y
boar
d
Power
On/Off
12

Downloading books is easy!
The Astak-approved website is:
www.mobiebook.com
Use the web browser on your desktop or
notebook computer to go to this site! There
you will find all the latest and greatest books in
the Mobipocket format that your EZ Reader
requires.
Whether you like The Classics or Comedy or
Drama or Action/Adventure… you can
download easily from this website into any
dedicated file on your computer such as “My
Books” (as a suggestion).
Note: Check to make certain that your computer
has a relatively newer operating system that
will work for such downloading. Most will
without any trouble! Check with the website
for Apple Compatibility.
13

Moving books and music from your
computer to the EZ Reader
With your computer “on”, connect your EZ
Reader via USB cable to your computer. Turn
on the EZ Reader and press “OK” button. This
should bring up a “What do you want Windows
to do” dialogue box. Choose “Open Folder to
View Files”. This should bring up all of the
folders that you have on your SD card or in your
device embedded memory.
After this window is opened, everything is just
“Copy” and “Paste”. Minimize the Opened EZ
Reader screen on the computer, open “My
Books” or “My Music” or “My Pictures”…
click on what you want in the EZ Reader…
right click and choose “Copy”… and then drop
it into the EZ Reader file screen you just
minimized by hitting “Paste”.
14

Make sure your music you load is MP3
formatted and your pictures are JPEG only of
less than 1GB.
That is about all there is to it! The download
from the EZ Reader Screen on your computer to
your EZ Reader is effectively “automatic”.
For “encrypted, DRM, and other formatted
books…look for information on:
www.moiebook.com
Search
Searching by page
Under the bookshelf interface, each page
displays up to eight titles. Press page turning
button to go to previous or next page; or press
and hold down the page turning button to turn
ten pages at one time. User can use the number
keys (①~⑧) to select the title for reading.
15

Quick press to
move to previous
or next bookshelf
Press and hold to
turn 10 pages at
one time
Main Bookshelf
Text
Press Exit ( )
Press ①~⑧
16

Search by sorting
User can save the books of the same type in the
same folder. The device can support multi-level
folders. Press the number keys (①~⑧) to enter
into the sub-folder.
Press ①
~
⑧
Mainfolder Sub-folde
r
Press Exit ( )
17
