ASTi Telestra User manual

ASTi
Telestra
Remote Control Interface
User Guide
Document: DOC-01-TELS-RC-1
Advanced Simulation Technology inc. 441-A Carlisle Drive, Herndon, Virginia, 20170 USA
Revision A (July 2000)

Table of Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Setting Up the Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
List of Commands and Responses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Using the Host Emulator, hostemu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Debugging the Remote Control Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Using the Telestra System without a Monitor, Keyboard and Mouse . . . . . . . . . . . . . . . . . . . . . . . . . 7

ASTi Telestra Remote Control Interface User Guide (Version 1, Revision A)
Copyright © 1999-2000 Advanced Simulation Technology inc. 1
Introduction
In order to facilitate easier integration into the simulator environment it is possible to perform sys-
tem commands from a remote computer system, connected to the Telestra unit via a TCP/IP
Ethernet connection. This greatly simplifies the inclusion of Telestra into the wider HLA based
system control architecture, particularly due to interaction of RTI master exec software and the
satellite applications that rely on this.Also this removes the neccessity of running the system with
a keyboard and monitor permanently connected to the unit.
The Telestra system can be managed by remote control through a TCP/IP interface. Through this
interface, a host computer can:
• Tell the Telestra federate to join or resign a federation
• Specify the federate name, federation name to join, and fed file
• Direct the Telestra system to shutdown or reboot
The host can also get information from the Telestra system:
• Joined/resigned status
• Current federate name, federation name, and fed file name
• RTI network activity information
• Lists of objects the federate is currently aware of
The host can only get this information if it is controlling the Telestra system. The commands and
responses through this interface are all text based, human readable messages. A host emulator pro-
gram is supplied with the Telestra system that can act as a console attached to the Telestra feder-
ate, either on the local box or a remote one. The connection is designed to be robust - if the
connection is unexpectedly closed or broken, the socket will automatically re-open and begin lis-
tening for a new connection.
Also described in this document is a tool called hostemu (short for Host Emulator), which pro-
vides a method of experimenting with the Telestra remote control interface. There is also a
method for printing the traffic on the remote control interface to the screen, which can be used in
debugging the interface.
Setting Up the Connection
The remote control interface is set up in the configuration file for the Telestra federate (more
information on the configuration file can be found in the doument Telestra Quick Start Guide. For
example, inserting Control_Port = 45001 into the .cfg file will cause the Telestra federate
to set the remote control interface to listen for TCP/IP connections on UDP port 45001. When
telestra is run from the console (i.e. not automatically at startup), it takes remote control inter-
face commands directly from the console it was run from if no remote control interface port was
specified. If the Telestra federate is run automatically at startup (see the doument Telestra Quick
Start Guide for instructions on how to do this), and no port is specified, it will default to 45001.

ASTi Telestra Remote Control Interface User Guide (Version 1, Revision A)
Copyright © 1999-2000 Advanced Simulation Technology inc. 2
List of Commands and Responses
The Telestra federate expects all command lines to be terminated with a <cr> character ( \n to
you C programmers). If two command lines come at once, they will be executed in order. A com-
mand will not be executed until the final <cr> is received.
Commands are not case sensitive. Some data for the commands may be (for example, the fed file
name must be in the correct case). Where possible, data will not be case sensistive.
Telestra system replies that are of variable length (for example, when retrieving statistics or object
lists) will end with the line “ ENDLIST<cr> ”. This is indication to the host computer that no
more data is being sent.
If the interface receives a command it does not recognize, it will return “ UNKNOWN COMMAND ”
followed by the unrecognized command. If it receives a line of whitespace (followed by a <cr> ),
it will respond with a <cr> .
HELP or ?
Either command returns a list of all the supported remote control interface commands.
JOIN <Federation Name>
This command directs the Telestra federate to join the federation with the name specified. If
no name is given, it will join the last federation name that was set. If the federate is already
joined to a federation, it will resign and attempt to join again. It will do this even if the federa-
tion name is unchanged. If no federation name has been set (either through the remote control
port or from the configuration file), then the JOIN command will fail and respond “ JOIN
<NONAMEGIVEN> FAIL ”. The response to the JOIN command is either “ JOIN Federa-
tionName OK ”, “ JOIN FederationName FAIL ”, or “ JOIN FederationName
FAIL BAD_FED_FILE ”. The last response occurs if the federate could not get handles for
all of the class names and attribute names it requested from the RTI. The normal cause of this
is that the .fed file does not have the ASTi SOM information incorporated into it.
RESIGN
This command tells the federate to resign. The response will be “ RESIGN OK ” or “ RESIGN
FAIL ”. If the federate is not joined to a federation, no action is taken and the federate will
respond “ RESIGN OK ”.
SHUTDOWN
This command will instruct the Telestra system to do an orderly system shutdown. If the fed-
erate is currently joined to a federation, it will resign before shutting down. The Telestra
response to this command is “ GOODBYE ”, following by the connection being broken. The
shutdown will not complete until some time after the “ GOODBYE ” response is received. It is a
good practice to wait at least 60 seconds between receiving the “ GOODBYE ” and powering off
the Telestra system. Otherwise, the file system may be corrupted.

ASTi Telestra Remote Control Interface User Guide (Version 1, Revision A)
Copyright © 1999-2000 Advanced Simulation Technology inc. 3
RESTART
Acts exactly like SHUTDOWN , except it does an orderly reboot of the system
NAME
NAME FEDFILE <NewFedFileName>
NAME FEDERATION <NewFederationName>
NAME FEDERATION_NUMBER <NewFederationNumber>
NAME FEDERATE <NewFederateName>
This command controls the setting of four federate options. <NewFedFileName> is the
name of the .fed file the federation uses. <NewFederationName> is the name of the feder-
ation the Telestra federate will join. <NewFederationNumber> is the number of the feder-
ation as it is known to the DACS. (If you are only running a single federation, this should be
set to 1.) <NewFederateName> is the name of the Telestra federate. The NAME command
alone will simply return the values of these variables. The other forms will set the correspond-
ing value, and return the values for all the variables.
The changes do not take effect until the federate joins the federation. If the values of the name
variables are changed while the Telestra federate is joined, the changes will not take effect
until another JOIN command is issued.
STATUS
Returns either “ JOINED <FederationName> ” or “ RESIGNED ”. The federation name
returned is the one currently joined, even if the NAME command has been issued to change the
FEDERATION variable.
OBJECT
OBJECT TRANSMITTER
OBJECT RECEIVER
OBJECT ENTITY
OBJECT LOCAL
When called with no arguements, the OBJECT command returns a list of objects that the
Telestra federate is aware of. The Telestra federate subscribes to Receiver, Transmitter, and
entity objects. The name, RTI handle, and type of the object is returned. In addition, an object
is designated as “local” if it is owned by the Telestra federate in question (for transmitters and
receivers), or if there is a local transmitter or receiver attached to it (in the case of entities).

ASTi Telestra Remote Control Interface User Guide (Version 1, Revision A)
Copyright © 1999-2000 Advanced Simulation Technology inc. 4
A sample output looks like this:
Receiver Viper3.UHF1.rx handle: 65538 0x10002
Receiver Viper3.UHF2.rx handle: 65542 0x10006
Receiver Viper3.VHF1.rx handle: 65540 0x10004
Receiver Viper3.VHF2.rx handle: 65546 0x10010
Receiver local GeoCntr-6.Radio021.rx handle: 196630 0x30016
Receiver local GeoCntr-6.Radio022.rx handle: 196628 0x30014
Transmitter Viper3.UHF1.tx handle: 65537 0x10001
Transmitter Viper3.UHF2.tx handle: 65541 0x10005
Transmitter Viper3.VHF1.tx handle: 65539 0x10003
Transmitter Viper3.VHF2.tx handle: 65545 0x10009
Transmitter local GeoCntr-6.Radio021.tx handle: 196609 0x30001
Transmitter local GeoCntr-6.Radio022.tx handle: 196613 0x30005
ENDLIST
When issued with an argument, the OBJECT command will only return a subset of the objects
- either transmitters, receivers, entities, or local objects.
Note theASTi naming convention: EntityName.RadioName.tx , where EntityName is
the entity the radio is attached to. RadioName is the name given to the radio object in the
model, and .tx and .rx designate transmitters and receivers. This naming convention is used
to make the output to debugging tools more “human readable”. Other radios that do not fol-
low this naming convention will still be interoperable with the ASTi system.
The host entity name for a radio is also published as an attribute of the transmitters and receiv-
ers. See the ASTi SOM for more details.
ACTIVITY
This command returns activity counters from the Telestra system. A sample output would be:
lifeCounter = 68
Attributes Updates rx:10 tx:441 rx ignored:0
Interactions rx:7437 tx:4198
Number of Transmitters local:11 rti:5
Number Entities total:0 attached:0
The “ lifeCounter ” increments once a second while the entity is joined to a federation. It is
a general indicator of federate health. “ Attribute Updates ” reports the cumulative num-
ber of attribute updates sent and received by the federate. “ rx ignored ” is the number
received and ignored - this happens when the federate receives an update to an entity object
that none of it’s radios are attached to. Note, attributes are object parameters such as power
status, frequency, etc, and an attribute update occurs when one of these changes in some way.
“ Interactions ” is the number of interactions sent and received. Currently, this only
includes audio packet interactions. “ Number of Transmitters ” returns the number of
transmitters owned by the Telestra federate (local), and the number discovered from the RTI.
“ Number Entities ” returns the total number of discovered entities, and the number of
entities that the Telestra federate has radios attached to.
The Telestra federate does not generate any type of entity objects.

ASTi Telestra Remote Control Interface User Guide (Version 1, Revision A)
Copyright © 1999-2000 Advanced Simulation Technology inc. 5
Using the Host Emulator, hostemu
The Telestra system is shipped with a host emulation program. It is located in the /home/
hlauser/bin directory, and can be run by typing
hostemu
at the command prompt. The purpose of the host emulation is to experiment with the host inter-
face and to verify that it is acting correctly. This applies to both the local Telestra unit, and to other
remote Telestra units (if available).
If hostemu is run with no arguments, it will search the local box for sockets that may be remote
control interface sockets for Telestra systems. It will then attempt to attach to the first such socket
it finds. If it is unable to find and connect to a socket, the hostemu program will print a usage mes-
sage.
When attached, hostemu acts as a console. Text typed in is sent to the Telestra remote control
interface, and the replies are printed out on the console.
Use Alt+F1-F6 to move between the 6 available consoles on the Telestra system.
hostemu can be directed to connect to a specific socket on the local machine or to a remote
Telestra unit over a network connection. To connect to port 45003 on the local machine, for exam-
ple, you would enter
hostemu 45003
To connect to port 45003 on a remote network machine with an ip address of 192.42.172.151, you
would type
hostemu 45003 192.42.172.151
or, alternatively,
hostemu 45003 HLAlab1.asti-usa.com
Either of the latter two commands would allow the local Telestra to act as a remote host for a sec-
ond Telestra unit.

ASTi Telestra Remote Control Interface User Guide (Version 1, Revision A)
Copyright © 1999-2000 Advanced Simulation Technology inc. 6
Debugging the Remote Control Interface
The Telestra software can print the commands sent and received through the remote control inter-
face. To do this, add the line
DEBUG_HOST = ON
to the configuration file. Commands to and from the Telestra federate will be printed to the con-
sole:
From Host: ‘status\n’
To telestra : ‘status’
To Host: ‘RESIGNED\n’
“ From Host ” is the data that was received from the host computer. Note that the <cr> is explic-
itly indicated.A command will not be evaluated until a <cr> is received. “ To telestra ” is the
command as it is passed to the Telestra system. These might be different if the host sends two
commands at once. For example. if the host sends the string “ status\nobject\n\n ”, the
debug output would be:
From Host: ‘status\nobject\n\n’
To telestra : ‘status’
To Host: ‘RESIGNED\n’
From Host: ‘’
To telestra : ‘object’
To Host: ‘ENDLIST\n’
From Host: ‘’
To telestra : ‘’
To Host: ‘\n’
The input software parses the input and passes the commands to the Telestra one at a time.
When debugging is complete, you should comment out the DEBUG_HOST command from the
configuration file.
The host emulation program, hostemu, can be used to see how the Telestra software responds to
various commands.

ASTi Telestra Remote Control Interface User Guide (Version 1, Revision A)
Copyright © 1999-2000 Advanced Simulation Technology inc. 7
Using theTelestra System without a Monitor, Keyboard
and Mouse
The Telestra software is configured to start automatically at system boot if it finds a file called
“ startup.cfg” in the /home/hlauser directory. If it finds such a file, it will start the
Telestra federate using /home/hlauser/startup.cfg as its configuration file. When the
Telestra federate is started in this way, it will NOT be attached to the console, so no keyboard
input or screen output will be available from the federate. Because of this, it’s important to set up
the remote control interface before enabling this autostart mode. If you do have a “star-
tup.cfg” file but have not yet set up the host interface, rename or delete the startup.cfg file
and reboot the system to halt the background process that is running. Note however that if a key-
board, mouse and monitor are connected then the “hostemu” software can be used to provide
local control. Use theAlt+F1-F6 to switch to another console and launch the hostemu application.
Because the Telestra system is running Linux, it is of course possible to connect to the system
with either ftp or telnet. This allows another method of using it without a keyboard, monitor, or
mouse.
Warning: If you do inadvertantly start-up the Telestra unit, without a keyboard, mouse and moni-
tor connected with the “startup.cfg” file present Telestra will ONLY be accessible from a
remote computer. It is not possible to connect the peripherals once Telestra has started. If you do
not have a remote computer capable of connecting to the Telestra unit, your only option is to
switch-off the Telestra system. If this is done, do be aware that it is possible to cause file errors
and possible disk corruption, due to not being able to shutdown the unit in a controlled fashion. If
this occurs the only option may be to rebuild the disk.ASTi therefore recommend that during all
testing of the remote interface operation and particulary when combined with use of the “star-
tup.cfg” file, that a keyboard, mouse and monitor combination be connected to Telestra.
