Astivita ASTEC60CERTOP User manual

1
Instruction manual
Model No.:ASTEC60CERTOP

2
CONTENTS
GeneralInformation Page3
WarningandSafetyInstructions Page4
InstructionsforUse Pages5-7
InstructionsforInstallation Pages8-9

3
GENERAL INFORMATION
Please read this booklet thoroughly before you use this appliance. It is important that you understand
all the control functions before commencing to cook with your appliance.
Please remember the advice and warnings shown on page 5 which is headed ‘IMPORTANT – Warning
and Safety Instructions’.
This appliance is designed for domestic household use when built into kitchen worktop.
NOTE: The housing, adjacent furniture and all materials used in the installation must be able to
withstand a minimum temperature rise of 85°C above ambient during periods of operation. This
information is for guidance only and the actual withstand temperature will depend on the performance
rating for the surface finish of the worktop.
Certain types of kitchen furniture surface finishes are particularly prone to heat damage or discoloration
at temperatures lower than the above guidelines.
Installing the appliance in contravention of the guidance given will be at the liability of the owner.
Before using this appliance ensure that any protective packaging or coatings have been removed. To
aid the protection of the environment, please sort the packing materials into different types and dispose
of them in accordance with the local waste disposal laws.
Any further information on waste disposal can be obtained from your local Environment Agency office.
When first used, an odour may be emitted by any residual protective finish or moisture, which will
cease after a short period of time.

4
IMPORTANT NOTE – WARNING and SAFETY INSTRUCTIONS
This appliance complies with all current European safety legislation, however do wish to emphasise
that compliance does not remove the fact that surfaces will become hot during use and retain heat after
operation.
Therefore strongly advise that babies and young children are prevented from being near or touching the
appliance at any time.
If it is necessary for younger family members to be in the kitchen, please ensure that they are kept
under close supervision at all times.
We also advise that great care is taken during use and cleaning operations.
Do make sure that the pan handles are always correctly positioned to avoid accidental contact.
Do not leave heated oil or fat unattended as there is a risk of fire.
Do use pans that are flat bottomed and the correct size for the heating area to be used (never smaller).
Do not allow electrical fittings or cables to be in contact with hot areas of the appliance.
Do not use the appliance for space heating or to dry clothes.
Do not install the appliance next to curtains or soft furnishings.
This appliance can be used by children aged from 8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and understand the hazards involved
Children shall not play with the appliance
Cleaning and user maintenance shall not be made by children without supervision
WARNING: The appliance and its accessible parts become hot during use.
Care should be taken to avoid touching heating elements.
Children less than 8 years of age shall be kept away unless continuously supervised.
WARNING: Unattended cooking on a hob with fat or oil can be dangerous and may result in fire.
NEVER try to extinguish a fire with water, but switch off the appliance and then cover flame e.g. with
a lid or a fire blanket.
WARNING: Danger of fire: do not store items on the cooking surfaces
WARNING: If the surface is cracked, switch off the appliance to avoid the possibility of electric shock.
A steam cleaner is not to be used.
The appliance is not intended to be operated by means of an external timer or separate remote-control
system.
Means for disconnection must be incorporated in the fixed wiring in accordance with the wiring rules.
NOTE: This appliance must be correctly installed by a suitably qualified person, strictly in
accordance with the manufacturer’s instructions.
Heat, steam and moisture will be created during use, take care to avoid injury and ensure that
the room is adequately ventilated. If prolonged use occurs, additional ventilation may be
required – please consult your Qualified Installer if you are in any doubt about the amount
required.

5
INSTRUCTION FOR USE
Control Panel: 4 Powers
Control Panel: 2 Powers
1. Power Switch
2. Burner Switch
3. Burner Display
4. Minus
5. Plus
6. Double Burner Zone
7. Timer
8. Timer Display
9. Children Safety Lock
10. Timer Indicator
11. Double Zone Indicator
12. Children Safety Lock Indicator
13. Burner Power Setting Indicator. If it is flash, can set power. It no flash, can’t set power.
14. single power indicator
Instruction
1. Touch Power Switch, all power setting show “0”, and Burner power setting indicator will keep
flashing. Need to make further operation in 10S, otherwise it will turn off automatically.
2. Set power through “Plus” and “Minus”. First touch plus, power will show “5”. First touch minus,

6
power will show “9”.
Remark:
1. Can operate one burner in one time.
2. If the burner is working, will show indicator closed to burner.
3. Set power to “0”, burner will stop working.
Children Safety Lock
For safety reason, you can lock the control by pressing children safety lock. If power was off before
turn off the lock. The lock will keep working when you restart power. Must turn off the lock for further
operation.
Stop Working
For safety reason, control panel will stop working if it worked too long because of customer forget to
turn off the control.
Power Setting Max Working Hour
1-2 6
3-4 5
5 4
6-9 1.5
After the control stop working, will show “H” residential heating for 20 minutes.
Auto Heating Mode
1. Set power to “9”, and then press plus, then burner display will show “A” and “9” in turn. Now it is
auto heating mode. Then set the power you need, for example, “6”, display will show “A” and “6”, for
2.5 minutes.
2. Auto heating mode will start when display show “A” and “9” the first time. If you set power “6” for
10S, then display will show “A” and “6” for 2 minutes and 20S, and finally show “6” only.
3. Auto heating time
Power Auto heating time (minutes)
1 1
2 3
3 4.8
4 6.5
5 8.5
6 2.5
7 3.5
8 4.5

7
9 ---
4. Auto heating setting. In this mode, when the heating is working not exceed for 30S, press minus, can
reduce power. If more than 30S, press minus, will stop auto heating mode, and turn to regular heat
mode. If more than 30S, and display keep flashing “A” and power, can press plus to have more power
and still under auto heating mode.
5. When you change power, the pasting time will be calculated into time of auto heating mode of new
power. For example, you choose power “1”, work for 30S, then change to power “4”, then auto heating
mode time will be 6 minutes only.
Heat Time for Each Power
1 minutes for 1 cycle
Power：1，Time：Work for 1S, Stop for 59 S
Power：2，Time：Work for 3S, Stop for 57 S
Power：3，Time：Work for 6S, Stop for 54S
Power：4，Time：Work for 10S, Stop for 50 S
Power：5，Time：Work for 14S, Stop for 46S
Power：6 Time：Work for 19S, Stop for 41S
Power：7，Time：Work for 26S, Stop for 34S
Power：8，Time：Work for 38S, Stop for 22S
Power：9，Time：Keep working…
Timer
1. Choose timer, display show “00”, press “Plus” to set working time (01 to 99 minutes), press “Minus”
to set working time (30 to 0 minutes), will confirm automatically in 10S.
2. Set timer for each burner. Press burner switch to choose the burner, and the burner indicator will
flash, set power range, then press “Timer”, will show “00”, then press “Plus” to set working time (01 to
99 minutes), press “Minus” to set working time (30 to 0 minutes), will confirm automatically in 10S.
Burner will stop working if time was up.
Remark: can set new time by pressing “Plus” or “Minus”.
3. Turn off timer. When time is up, timer will sound for 2 minutes, and you can turn off sound by
touching any button. If you wanted to turn off burner in advance, can set timer to “00”.
WARNING
• Do not use commercial simmering aids as these can create excessive heat that can damage the
appliance.
• Do not use the glass ceramic surface of the hob as a griddle.
• Do not leave hotplates on without a pan or an empty pan.
• Be aware that hotplates will retain heat whilst cooling down.
• When cooking foods with high sugar content, ensure that any spillage is removed immediately
to avoid damage to the ceramic surface.
HELPFUL HINTS

8
• Always use the correct diameter pan, one that is the same or slightly larger than the hotplate.
• The bottom of the pan must be flat.
• Whenever possible keep the lid on the pan when cooking.
• Avoid over-spill of liquid by reducing the heat when boiling has occurred.
CLEANING THE APPLIANCE
Always allow the appliance to cool down before cleaning to avoid a burn injury.
Do not use caustic or abrasive agents, coarse wire wool or hard tools as these can damage the surface
finish.
Normally, wiping with a soft cloth dampened with hot detergent and drying with a soft cloth is
sufficient but for stubborn marks the following is recommended:
Vitreous Enamel or Stainless Steel parts – use only a cleaner that is recommended for these types of
material – avoid chloride based products (such as bleach).
Glass Ceramic surfaces – if any spillage becomes burnt on, remove with a ceramic glass cleaner or
scraper and clean with a cleaner-conditioner containing silicone.
Do not allow the ceramic glass surface to become scratched or damaged as this could lead to a
hazard.
INSTRUCTIONS FOR INSTALLATION
This appliance must be installed by a competent person in accordance with the current version of the
following UK Regulations and Safety Standards or their European Norm replacements:
Building Regulations (issued by the Department of Environment)
Building Standards (issued by the Scottish Development Department)
IEE Wiring Regulations
Electricity at Work Regulations
POSITIONING THE APPLIANCE
A kitchen unit (depending on size) or 600mm worktop, providing the following minimum distance is
allowed:
- 650mm between the top surface and the underside of any horizontal surface above it.
- 50mm clearance around the appliance and any combustible materials.
The surface of any adjacent unit must be capable of withstanding a minimum temperature rise of
85°C. INSTALLATION NOTES
1 Cut the aperture to the dimensions shown in the table below or use the template provided on the
packaging.
2 Invert the hob and apply the sealing agent provided to match the outer perimeter edge.
3 If the sealing agent is a strip type, the protective covering must be removed from both sides.
Do not leave a gap in the sealing agent or overlap the thickness.
NOTE: do not use any Silicone based sealant, as this can damage the worktop surface if repairs are

9
required.
4 Insert the appliance into the aperture and fix into position via the clamps & screws, tightening the
screws evenly (see Fig.3).
Fig.3
HOB APERTURE DIMENSIONS
MODEL A B C D E MODEL A B C D E
RH940T-1E 900 350 880 330 53 RH940T-1W 900 350 880 330 53
RH740T-2E 770 510 750 490 53 RH740T-2W 770 510 750 490 53
RH640T-1E 580 510 560 490 53 RH640T-1W 580 510 560 490 53
RH640T-2E 580 510 560 490 53 RH640T-2W 580 510 560 490 53
RH640TA-E 580 510 560 490 53 RH640TA-W 580 510 560 490 53
RH640TB-E 580 510 560 490 53 RH640TB-W 580 510 560 490 53
RH614T-1E 580 510 560 490 53 RH614T-1W 580 510 560 490 53
RH614T-2E 580 510 560 490 53 RH614T-2W 580 510 560 490 53
RH320T-E 290 510 270 490 53 RH320T-W 290 510 270 490 53

10
ELECTRICAL CONNECTION
This appliance must be installed by a competent person.
Before connecting the appliance, make sure that the supply voltage marked on the rating Plate
corresponds with the mains supply voltage.
WARNING – THIS APPLIANCE MUST BE EARTHED
Depending on the Power Input of the model to be installed, connection will require a 16Amp or 30Amp
protected supply using a switched double pole isolating unit having a minimum 3mm contact
separation (see Technical Data at page 11 for full information).
Care must be taken to avoid the cable being in contact with hot parts of the appliance.
The isolating unit should be placed in an easily accessible position adjacent to the appliance.
NOTE
The appliance must be connected to the mains supply by means of not less than a 15A plug and
socket.
DISPOSAL: Do not dispose this product as unsorted municipal waste. Collection of such waste separately for
special treatment is necessary.
This marking indicates that this product should not be disposed with other household wastes
throughout the EU. To prevent possible harm to the environment or human health from uncontrolled
waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To
return your used device, please use the return and collection systems or contact the retailer where the
product was purchased. They can take this product for environmental safe recycling.
Technical data
Mains Supply Lead: 3 core x 2.5 mm²
MODEL Rated
Voltage Max Rated Inputs MODEL Rated Voltage Max Rated Inputs
RH940T-1E 6400W RH940T-1W 6400W
RH740T-2E 7200W RH740T-2W 7300W
RH640T-1E 6400W RH640T-1W 6300W
RH640T-2E 6300W RH640T-2W 6200W
RH640TA-E 6500W RH640TA-W 6500W
RH640TB-E 6000W RH640TB-W 6000W
RH614T-1E 6400W RH614T-1W 6300W
RH614T-2E 6300W RH614T-2W 6200W
RH320T-E
220-240 VAC
50/60HZ
3000W RH320T-W
220-240 VAC
50/60HZ
3000W

11
