Frigidaire GLGC36S8K User manual

PRODUCT NO. BASE MODEL NO. FACTORY NO. SERIES COLOR
GLGC36S8KBA GLGC36S8K 3775642271061 Gallery black
GLGC36S8KSA GLGC36S8K 3775643271011 Gallery white
MARKET
North America
Publication No.
5995370045
020415
-EN/SERVICE /ECL
377
GAS
COOKTOP
Model No.
GLGC36S8K
©2002 Electrolux Home Products, Inc.
All rights reserved
FACTORY PARTS CATALOG
RANGE
WIRING DIAGRAM - # 318047106
OWNER’S GUIDE - # 318200663
INSTALLATION INSTRUCTIONS - # 318201450
ELECTROLUX HOME PRODUCTS, INC.
P.O. BOX 212378, Augusta, GA 30917

04/02 2
Publication No. GLGC36S8K
5995370045
COOK TOP

# = Functional Parts 3 04/02
* = Non-Illustrated Parts
GLGC36S8K Publication No.
5995370045
COOK TOP
A = GLGC36S8K (GLGC36S8KSA)
B = GLGC36S8K (GLGC36S8KBA)
POS. NO PART NO DESCRIPTION
3 318171400 A B Support
6 318180500 A B Bracket,element
15C# 316098202 A B Element,warmer zone ,100W
16 318218610 A - Main Top,glass ,white ,w/ nameplate
16 318218611 - B Main Top,glass ,black ,w/ nameplate
19 318168116 A - Pan,burner ,white ,medium
19 318168114 - B Pan,burner ,black ,medium
19A 318168126 A - Pan,burner ,white ,large
19A 318168124 - B Pan,burner ,black ,large
19B 318168106 A - Pan,burner ,white ,small
19B 318168104 - B Pan,burner ,black ,small
20 318120104 A - Grate,white ,(4)
20 318120103 - B Grate,black ,(4)
22 318076411 A - Cap,burner ,grey ,medium LF & LR
22 318076410 - B Cap,burner ,black ,medium LF & LR
22A 318076421 A - Cap,burner ,grey ,large RF
22A 318076420 - B Cap,burner ,black ,large RF
22B 318076401 A - Cap,burner ,grey ,small RR
22B 318076400 - B Cap,burner ,black ,small RR
31A 318053901 A B Gasket,burner pan
33 318172803 A B Bracket,switch
43 318215500 A - Knob,control ,white
43 318215501 - B Knob,control ,black
43A 318017110 A - Knob,control ,white
43A 318017106 - B Knob,control ,black
45 318146220 A B Bushing
46 318077001 A B Burner Box
47 # 5303303991 A B Cord,electric power
50 318218500 A - Nameplate,white ,Gallery
50 318218501 - B Nameplate,black ,Gallery
51 # 318044820 A - Light,indicator ,red
51 318044821 - B Light,indicator ,natural
52 5303317177 A B Spring,element mtg.
53 318172802 A B Bracket,indicator light
54B# 318078800 A B Switch,warmer ,drawer/zone
55 5303317178 A B Spacer,element
56 5303317179 A B Screw,element ,6 x 3/4
69 5303323134 A B Screw,switch mtg. ,8-32 x 0.188
130 318160303 A B Shield,insulation
132 3201437 A B Strain relief
136 5303935029 A B Support
137 5303323138 A B Screw,10-24x1/2
* # 318052124 A B Wiring Harness
* 5303211311 A B Screw,8 x 0.500

04/02 4
Publication No. GLGC36S8K
5995370045
BURNER

# = Functional Parts 5 04/02
* = Non-Illustrated Parts
GLGC36S8K Publication No.
5995370045
BURNER
A = GLGC36S8K (GLGC36S8KSA)
B = GLGC36S8K (GLGC36S8KBA)
POS. NO PART NO DESCRIPTION
1 # 318177204 A B Manifold Pipe
2 # 318087304 A B Valve,burner ,1200 BTU
2A # 318087305 A B Valve,burner ,1800 BTU
2B # 318087303 A B Valve,burner ,675 BTU
3 # 318163400 A B Switch,ignitor
4 # 318167704 A B Tube,burner ,FL
5 # 318167705 A B Tube,burner
6 # 318167706 A B Tube,burner
7 # 318167707 A B Tube,burner ,BL
8 # 316135701 A B Module,spark
10 # 318148001 A B Burner,top ,9100 BTU ,medium LF & LR
10A# 318148002 A B Burner,top ,13000 BTU ,large RF
10B# 318148000 A B Burner,top ,5000 BTU ,small RR
13 318054505 A B Connection,manifold tube
14 # 5308007974 A B Regulator,pressure
24 318054000 A B Elbow,fitting
35 318146300 A B Bushing
62 318160201 A B Cover,spark module
72 316134300 A B Screw,10-24 ,valve mounting
74 # 318148700 A B Ignitor,top burner
75 318148800 A B Clip,electrode
76 # 318167801 A B Tube,mixing ,medium & large
76A# 318167800 A B Tube,mixing ,small
77 318112010 A B Bracket,burner mtg ,medium & large
77A 318112000 A B Bracket,burner mtg ,small
77B 318180900 A B Bracket,burner tube
* # 318127410 A B LP Conversion Kit
* 5303211311 A B Screw,8 x 0.500

04/02 6
Publication No. GLGC36S8K
5995370045
WIRING DIAGRAM
