Astone EVO X User manual

EVOX
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

TheauthorofthisusermanualisAstoneHoldingsPtyLtd.Thecopyright
proprietorAstoneHoldingsPtyLtd.thecopyrightandall
rightsreserved. owns
Thecontentsofthismanualareheretoexplaintheoperationmethodsof
multimediaMPEG4videorecorderoftheproprietor.Theproprietorwill
nottakeanyresponsibilityofanyclearindication'sorhint'sassurance.
CopyrightAnnouncement
ResponsibilityAnnouncement
EVOX Page1
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

TableofContents
Preface.........................................................................03
Packagecontents.........................................................04
Introduction.................................................................05
Operation.....................................................................06
Batterychargingmode...................................................17
Introductiontovideoplayingmode................................18
Introductiontovideorecordingmode...........................20
Introductiontomusicplayingmode..............................23
Introductiontophotobrowsingfunction........................25
Howtouseunitproperly................................................29
Howtousepowercharger.............................................30
Safetyandpre-warning..................................................31
Troubleshooting..........................................................32
Warningforexternalstoragemedia..............................33
Warningforexternalharddriveinstallation................33
Thecontentsofinstallationcompactdisk....................36
Attachment1:Compatibleexternalmemorycards........41
Attachment2:CompatiblefileformatsforMP3/MP4/Jpeg.42
Attachment3:HowtouseUleadVideoToolBox.............43
Productspecification.....................................................46
EVOX Page2
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

Preface
TheEVOXproductisapersonalvideorecorder.Itcanplay
.AVI(MP4)and.ASF(MP4)videoformats,playMP3anddigitalimages
.ItcanalsorecordTVprogramsdirectlyorrecorddifferentkindsof
videoproducts'imagesandsounds.
Theproductsaveimagesas.ASF(Mp4)formatwhichcanbeeasily
playednotonlyonthebutalsoonacomputer.
UsingaUSB2.0porttoconnectthisproducttocomputerallowsthe
transferofimagesanddataquickly.
EVOX
EVOX Page3
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

Packagecontent
Afterunpacking,besidesthemainproduct,youwillseethefollowing
accessories.Ifanyoftheseaccessoriesismissing,pleasecontactyour
retailer.
RCACable
Earphone PowerCharger
USBCable
Installationcompactdisk UserManual
CarryingcaseHandstrap1.8"externalHDD
OPTIONAL
EVOXMPEG4Player
EVOX Page4
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

Introduction
PleaserefertothebelowpictureinordertobefamiliarwithyourEVOX
appearanceandfunctions.
Snaphookclip
AudioJack&AVOUT
TERMINAL
AVINTERMINAL
Markbutton
/ESCbutton
SETUPbutton
CF~HDDswitch
LCDDisplay
Resetbutton
USBport
Powerjack
Enter&pausebutton
Poweron/offbutton
Lock/record
Volumecontrolbutton
Recordingstatusindicator
Chargingstatusindicator
CF(TypeI)slot
EVOX Page5
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

setup:
storagemediaswitchingdevice:
Selectfile:
Exit:
Frommainmenutoanyfunction'ssettingsandinitial
settings. betweenCFcardandHDDswitch.
Byselectingthefileyouwanttoedit,Markitandthen
youcanrepeat,copyanddeletefileetc..
leavethecurrentrunningscreen,andgobacktotheprevious
screen.
Selectfunctionsandenterbutton
Introductiontooperation-mainmenu
Introductiontocontrolpanel'sfunctions
Therearefourfunctionstochoose:Videoplaying,MP3playing,photo
browsingandvideorecording.
Batterylevelindicator
Functionindicator
Dateandtimeindicator
MP3musicplaying
Digitalphotosdisplay Videorecordingmode
Mp4playing
Videoplaying:Youcanplay.AVIand.ASFformatsforMP4video.
(Fordetailspleaserefertospecification).Uleadsoftwarewill
allowothervideoMP4formatstobesaved/convertedto.AVI
whichwillplayontheunit.
MP3playing:YoucanplayMpeg1Layer3formatofmusic.
(Fordetailspleaserefertospecification)
Photobrowsing:YoucanviewJpegfiles.
(Fordetailspleaserefertospecification)
Videorecording:Youcanrecord.ASFformatforMP4video.
(FordetailspleaserefertoAttachment2)
Note:youcanplayallthefunctionsbackthroughaTVviavideoout
EVOX Page6
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

Introductionofoperation-filemanagement
Filereadingdrive(CForHDD)Timeindicator
Statusindicator
Lockedfile
Selectfile
Lockedfile
Directory
Selectfile
Therearetwomethodstomanagefiles.Oneistolistitembyitem(Video
playing,MP3playing)andtheotheroneistobrowsephotos(Photobrows-
ing).Underfilemanagementyoucanrunfileeditingfunctions.Fordetails
pleaserefertorelatedfunctionexplanation.
PoweronScreen
Turnonthedevice:PleasepressonEVOX'spoweron/offbutton
for2seconds.Initiallythewelcomingpicturewilldisplayonthescreen,
andthenthefunctionselectionmenu.
Openwelcomingpicture Functionselectionmenu
EVOX Page7
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

Basicoperation
Functionselection:Youcanusetheup,down,rightandleftarrowbuttonsto
selectfunctions.Afterselection,pleasepressthe"enter"button.
Using4-directional SelectFuntionKey
Basicoperation-functionsettings
Functionsettings:Undermainmenu,youcanpressbuttontosetup
basicfunctions Mark
Enteringfunctionsettings
Timesettings:Date/timesetupbutton.Afterenteringtimesettingscreen,
pleaseuseup/downarrowbuttontochoosetherelateditemanduseright/
leftbuttontosetthecorrectdateandtime.
EVOX Page8
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

Basicoperation-setupfunction
Screendisplays:SwitchbetweenLCDdisplayandTV.[whenunitisconnected
toaTV]
Languageselection:Usinglanguageselectingbuttontoselectlanguage
version.(built-inwith3languageoptions)
Formatting:Pleaseselectthedrivetoformat.(CFcardorHDD).
EVOX Page9
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

Basicoperation-setupfunction
Driveduplicating:Drivetodrivecopying.YoucancopyfromCFcardtoHDD
ortheotherwayaroundfromHDDtoCFcard.
Caution:
Duringdrivetodrivecopying,pleaseconfirmthesizeofthefilesandthe
availabledrive'scapacityfirst.Becauseifthedrive'sfreecapacityisnot
largeenough,itmaycausefilesnotbecopiedorcopypartially.
Afterdrivetodrivecopying,filenamewillappearasDCP_CForDCP-HDD
directoryontherelateddrive.Afteranothercopying,thefilenamewillbe
DCP_CF02insequenceontherelateddriveandsoon.
TVOut:SelectTVOutputandInputsystem(NTSCorPALsystem).
EVOX Page10
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

Softwareupgrades:Usingthesoftwareupgradebuttonyoucanupgradethe
program.ToupgradepleaseplugaCFcardwhichcontainstheMain.hexfile
intotheproduct,andthenselectupgradesystem.Afterpressingtheenter
button(ifupgradeissuccessful),thesystemwillreboot.
Warning:
1.Beforeupgradesystempleasemakesurewhetherthebattery's
supplementisokayorusepowerchargertoconnectthisproduct,
duringupgradepleasedonotshutdownorreboot.Theupgradewill
takeabout3to5minutes.
2.DuringupgradepleasedonotunplugCFcard,oritwillcausedead
end.
Color:Changethecolorofthesystemfont.
(Built-in7colors,thedefaultcolorisblack)
Returntodefaultsettings:Afterselectingtheenterbutton,thesystemwill
returntofactorydefaultsettingsandpromptdirectlytofunctionsselection
screen.
Basicoperation-setupfunction
EVOX Page11
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

Basicoperation-switchingbetweenstoragedevices
Atanytime,youcanpressthebuttontoswitchbetweenCFCARD
andHDD.Inplaymode,pressingthebutton,itwillpromptoutof
theplayinginterfaceandswitchthestoragedevice.
CF~HDD
CF~HDD
Basicoperation-fileselectionfunction
Underfileselection,youcanpressthisbuttontochooseoneormorefiles:
Underbrowsingpictures(photobrowsing)mode,theselectedfileswill
appearwithwhiteframes.Initembyitemmode,theselectedfilenames
willturnred.
appearwithwhiteframes
filenameswillturnred
EVOX Page12
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

Microphone
VHS
DVD
TV
TV
CF
CF
CFCARD
Camera
PC
Computer
HDD
DigitalVideo
DV
Basicoperation-backtopreviousscreen
/ESC:Leavethecurrentrunningscreen,backtothepreviousscreen.During
fileplayingprocess,pressingthisbutton,willreturntheplaying
interfacebacktothefileselectionlist.
Basicoperation-connectingwithotherdevices
Connectingwithotherdevices:EVOXcanconnectwithotherdevices
whicharelistedbelowandexpanditsfunctionality.
EVOX Page13
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

Basicoperation-connectingwithotherdevices
ConnectingwithTV:PleaseconnectTVAudio/VideooutwithEVOX
youcanrecordTVprogramasMPEG4format(.ASF):ConnectTVAudio/Video
InwithEVOXyoucanplayMPEG4videotoTVdirectly.
AV,
AVOut
RecordTVprogramasMPEG4videoformat
Youneedto
changethe
screensettings
toTV.
YoucanplayMPEG4videoonTVdirectly.
Caution:
YoucanalsoconnectEVOXwithTVsincludingFlatScreenTV,
PlasmaTV,LCDTV(needtorefreshthefrequency)..etc.Ifyouwantto
recordfromTV,theremustbeanAVOutTerminalonyourTV.
EVOX Page14
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

DVDVCD
DV
Basicoperation-connectingwithotherdevices
ConnectwithVCDorDVDPlayer:EVOXcanconnectwithDVDorVCD
Playerorrelatedproducts.ItwillsavethevideoasMPEG4format(.ASF)
ConnectwithDV,DigitalCameraorMicrophone:ThroughEVOXAVIN
TerminalyoucanconnectwithDVC,DigitalCameraorMicrophonetorecord
videoandsoundasMPEG4format(.ASF).
EVOX Page15
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

PC
USBCABLE
Basicoperation-connectingwithotherdevices
ConnectingwithPC:ThroughtheUSBcable,youcanconnectEVOX
withyourPCandyoucantransferyourPC'sMP4(video),MP3(music)and
Jpeg(Photos)directlytoeithertheCFCARDor20GBexternalHDDand
playitontheEVOX.
Warning:
1.OnlycertainvideoformatsareplayableontheEVOX.Pleasereferto
Attachment2andAttachment3.
2.Becausetherearesomanydifferentkindsofexternalmemorycards,the
manufacturercannotassurethatallexternalmemorycardswillbe
compatibletoEVOX.Astothecompatibleexternalmemorycards
pleaserefertotheAttachment1.
3.Whenconnectingbothexternalstoragedevices(CFCardandHDD)with
yourEVOX,PCcannotidentifymultipleexternalstoragedevicesat
thesametime.BeforeconnectingtoyourPC,pleasemakesurethere
isonlyoneexternalstoragedeviceconnected.
EVOX Page16
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

Batterychargingmode
EVOXhasabuilt-inLi-Batteryandtakesabout4hourstorecharge.For
playingtimepleaserefertoattachmentone;whenthebatteryislow,
EVOXwilldisplayanalertmessage,pleaseimmediatelyshutdownfirst,
andthenrechargethebattery.
Underchargingstatus,
LEDwillturngreen.
Caution:
IfthechargingLEDturnsorange,thisindicatesthattheLi-Battery's
temperatureistoohigh,atthismomentpleasestopcharging,butthePAV
stillcanbeoperatednormally.IftheLEDkeepsonturningredeventhe
batterypowerisnotbeingcharged,thisindicatesthattheLi-Batterycannot
workanylonger,atthismomentpleasecontactyourdealer.
Checksoftwareversion
EVOX'sbuilt-insoftwarecanbecontinuallyupgraded.Beforeupgrade
pleasecheckthesoftwareversionontheplayerfirst,accordingtothe
followingsteps:
EVOX Page17
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

Introductionofvideoplayingmode
ThevideoplayingmodeisoneofthemainfunctionsonyourEVOX.It
canplayseveralkindsofMPEG4compatibleformats.Theintroductionbelow
willexplainhowtheEVOXwillbringyouintothemultimediaworld.
Videoplayingfunction:
Videoformats&sources:
1..ASFformat:
2..AVIformat:
1.Undermainmenu,youcanusearrowbuttons
tochoosevideoplayingfunction,afterselection
,press"enter"button.
2.Entervideofileselectionscreen
3.Youcanuseup/downarrowbuttontoselectfiles
,afterselection,press"enter"button.
4.Starttoplaytheselectedfiles.
5.Whileplaying,pressup/downarrowbuttonto
select"previous",or"next"videotoplay
6.Whileplaying,pressleft/rightbuttontoselect
"rewind",or"forward"video
derivesmainlyfromtherecordingprogramon
yourEVOX.Astotherecordingmethods
pleaserefertothenextchapter"Videorecording
"andfor.ASFformatpleaserefertoattachment
two.
UsingUlead(thebundledsoftwareonthe
installationCD)orothersoftwareinthemarket,
youcantransferyourlegalvideosintoEVOX
compatibleformats(e.g.theAVIformat).For
detailspleaserefertoAttachment2&3.
Warnings:
1.TherearemanykindsofMPEG4formats,ifyouwanttoknowmoreabout
MPEG4relatedspecificationortolearnabouthowtotransferformats,
pleaserefertotherelatedInternetwebsites.
2.Therearenumerousformattransferringprogramsinthemarket.The
manufacturercannotassurethatotherformattransferringprogramswill
transferthevideoformatwithouthavinganycompatibilityorplaying
problemsonyourEVOX.
EVOX Page18
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

Introductionofvideoplayingmode
Videoeditingfunction:
1.YoucanselectpartoforallfilestosetupRepeatfunction.Duringvideo
replaying,ifanyfileformatisnotsupportbytheplayer,thisprogramwill
jumpoutautomatically.
2.Youcanselectpartoforallfilestolock.Afterafileislocked,youcannot
deleteorcopythislockedfile.Butyoustillcanplaythesefilesnormally.
3.Youcanselectpartoforentirefilestounlock.
4.Youcanselectpartoforallfilestodelete.Afterdeletionthesefilescannot
berecovered.
5.Youcanselectpartoforallfilestocopy.YoucancopytoCFCARDorto1.8"
externalHDD(optionalproduct).Afterdrivetodrivecopying,anewfilewill
appearasCFTOHDD1orHDTOCF01directoryontherelateddrive.A
subsequentcopywillappearasanewdirectoryinsequencenumberonthe
relateddriveandifyoukeeponcopying,thefilenumberwillbeincreased.
Warning:
1.Afterfiledeletionthefilescannotberecovered.Pleasebackupthefiles
andconfirmthedeletionbeforedeleting.
2.Beforecopying,checkifthefilenameontherelateddrivealreadyexists,
asthefilewillbeoverwrittendirectly.Beforecopying,pleasemakesure
thatthesamefilenamedoesnotexistontherelateddrive.
EVOX Page19
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com
