Astria MontebelloDLX40TEN User manual

INSTALLATION INSTRUCTIONS
P/N 506023-22 Rev. NC 12/2013
This manual is one of a set of two supporting this product.
Refer to P/N 506025-14 for Care and Operation Instructions.
Ce manuel est disponible en francais, simplement
en faire la demande. Numéro de la pièce 506023-23.
This appliance may be installed in an aftermarket permanently located, manufactured home (USA only) or mobile
home, where not prohibited by local codes. This appliance is only for use with the type of gas indicated on the rating
plate. This appliance is not convertible for use with other gases unless a certified kit is used.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
INSTALLATEUR : Laissez cette notice avec l'appareil.
CONSOMMATEUR : Conservez cette notice pour
consultation ultérieure.
Montebello DLX 40 and 45 in.
Direct Vent Gas Fireplaces
MODELS
AVERTISSEMENT : Assurez-vous de bien suivre les
instructions données dans cette notice pour réduire au
minimum le risque d’incindie ou d’explosion ou pour
éviter tout dommage matériel, toute blessure ou la mort.
WARNING: If the information in these instructions
is not followed exactly, a fire or explosion may
result, causing property damage, personal injury,
or death.
WARNING/AVERTISSEMENT/AVISO
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
UNE SURFACE VITRÉE CHAUDE
PEUT CAUSER DES BRÛLURES.
LAISSER REFROIDIR LA SURFACE
VITRÉE AVANT D'Y TOUCHER.
NE PERMETTEZ JAMAIS À UN ENFANT
DE TOUCHER LA SURFACE VITRÉE.
EL VIDRIO CALIENTE
CAUSARÁ QUEMADURAS.
USTED DEBE NUNCA
TOCAR EL VIDRIO CALIENTE.
LOS NIÑOS DEBEN NUNCA
TOCAR EL VIDRIO.
- Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
- WHAT TO DO IF YOU SMELL GAS:
 s$ONOTTry to light any appliance.
 s$ONOTTOUCHANYELECTRICALSWITCHDONOTUSEANY
phone in your building.
 s)MMEDIATELYCALLYOURGASSUPPLIERFROMA
neighbor’s phone. Follow the gas supplier’s
instructions.
 s)FYOUCANNOTREACHYOURGASSUPPLIERCALLTHEFIRE
department.
- Installation and service must be performed by a
qualified installer, service agency or the gas supplier.
- Ne pas entreposer ni utilizer d’essence ni d’autres vapeurs
ou liquides inflammables dans le voisinage de cet appareil
ou de tout autre appareil.
- QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ :
 s.EPASTENTERDALLUMERDAPPAREIL
 s.ETOUCHEZÜAUCANINTERRUPTEUr. Ne pas vous servir des
téléphones se trouvant dans le bâtiment où vous trouvez.
 s!PPELEZIMM£DIATEMENTVOTREFOURNISSEURDEGAZDEPUIS
un voisin. Suivez les instructions du fournisseur.
 s3IVOUSNEPOUVEZREJOINDRELEFOURNISSEURDEGAZ
appelez le service des incindies.
- L’installation et l’entretien doivent être assurés par un
installateur ou un service d’entretien qualifié ou par le
fournisseur de gaz.
Decorative Product: Not for use as a heating appliance.
NOTICE: Fireplace is not to be operated by a thermostat.
MontebelloDLX45TEN
MontebelloDLX45TEP
MontebelloDLXCD45TEN
MontebelloDLXCD45TEP
MontebelloDLX40TEN
MontebelloDLX40TEP
MontebelloDLXCD40TEN
MontebelloDLXCD40TEP
Intertek Report No.
100513650

2
)../6!4)6%(%!24(02/$5#43s$)2%#46%.4'!3&)2%0,!#%3-ONTEBELLO$,8-ONTEBELLO$,8#$s).34!,,!4)/.).3425#4)/.3
INTRODUCTION
The Signature Series direct-vent, sealed-
COMBUSTIONGASlREPLACESOPERATEONNATURAL
or propane gas. These appliances feature a
remotely controlled electronic intermittent pilot
IGNITIONSYSTEMMANUALADJUSTMENTOFTHEGAS
VALVESETTINGSISNOTPOSSIBLE
4HE3IGNATURE3ERIESISADECORATIVElREPLACE
ANDMAYNOTBEINSTALLEDANDOPERATEDASTHE
primary heat source in a dwelling.
%LECTRICALPOWER120 VACLINEVOLTAGEISREC-
OMMENDEDTOOPERATETHElREPLACEHOWEVER
FOUR!!BATTERIESCANBEUSEDFORFULLTIME
OPERATIONORASABACKUPINCASEOFAPOWER
outage.
Approved Vent Components
4HESE lREPLACES ARE DESIGNED TESTED AND
listed for operation and installation with Secure
Vent®DIRECTVENTSYSTEMCOMPONENTSINNER
OUTERMANUFACTUREDBY3ECURITY#HIMNEYS
International.
These approved vent system components
ARELABELEDFORIDENTIlCATIONUSE ONLY AP-
PROVED VENT COMPONENTS. Do NOT use
any other manufacturer’s vent components
with these appliances.
Codes and Standards
These appliances comply with National Safety
3TANDARDSANDARETESTEDANDLISTEDBY)NTERTEK
2EPORT.OTO:IN#ANADA
#3! AND #!.#'!- IN BOTH
53!AND#ANADAASVENTEDGASlREPLACES
These appliances are listed by Intertek for
installation in bedrooms and mobile homes.
Installation must conform to local codes. In
THEABSENCEOFLOCALCODESINSTALLATIONMUST
COMPLY WITH THE CURRENT .ATIONAL &UEL 'AS
#ODE !.3) : IN #ANADA THE CURRENT
#!.#'!"INSTALLATIONCODE
4HEAPPLIANCEWHENINSTALLEDMUSTBEELECTRI-
cally grounded in accordance with local codes
OR IN THE ABSENCE OF LOCAL CODES WITH THE
.ATIONAL%LECTRICAL#ODE!.3).&0!LATEST
EDITIONORTHE#ANADIAN%LECTRICAL#ODE#3!
#LATESTEDITION
TABLE OF CONTENTS
0ACKAGING ......................... 2
Introduction ........................ 2
'ENERAL)NFORMATION.................. 
-ASSACHUSETTS2EQUIREMENTS .......... 4
Cold Climate Insulation . . . . . . . . . . . . . . . 5
-ANUFACTURED(OME2EQUIREMENTS ...... 5
,OCATION. . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Vent Termination Clearances ........... 6
-INIMUM#LEARANCESTO#OMBUSTIBLES ..... 
Detailed Installation Steps . . . . . . . . . . . . . 
4YPICAL)NSTALLATION3EQUENCE .......... 
3TEP &RAMING .................... 
&IREPLACEAND&RAMING3PECIlCATIONS......10
3TEP 2OUTING'AS,INE .............11
0ROPER3IZINGOF'AS,INE..............11
3TEP )NSTALLTHE6ENT3YSTEM ........12
Vertical Termination Systems...........
6ENT3ECTION,ENGTH#HART .............
6ERTICAL6ENT4ABLESAND&IGURES.........16
Horizontal Termination System . . . . . . . . .
(ORIZONTAL6ENT4ABLESAND&IGURES ......
3TEP &IELD7IRING .................21
3TEP 2EMOVING'LASS$OOR
&RAME!SSEMBLY ..................
3TEP #ONNECTING'AS,INE ..........
3TEP #HECKING!PPLIANCE
Operation ........................
3TEP )NSTALLING,OGSAND0ANELS......24
3TEP )NSTALLING'LASS$OOR..........26
3TEP "URNER!DJUSTMENTS ...........26
&INISHING2EQUIREMENTS ...............
Step 11. Attaching Safety-in-
/PERATION7ARNINGS ................
Installation Accessories ...............
'AS#ONVERSION+ITS..................
Please read and understand these
instructions before beginning your
installation.
PACKAGING
4HEASSEMBLEDlREPLACEISPACKAGEDWITHTHE
following:
s Literature Kit PLASTIC BAG SHIPPED INSIDE
lREBOX CONTAINING Care and Operation
Instructions, Installation Instructions THIS
MANUAL 3AFETYIN/PERATION 7ARNING ,A-
BELSAND7ARRANTY
s /NEBAGGlowing Embers
s /NEBAGPlatinum Embers
s /NEBAGVolcanic Stone
s Pull Screen Kit
s Remote Control and Wall Receiver
Switch Kit
s Door Modesty Shield
s Log Grate
NOTE: For use with fireplace as shipped from fac-
tory only. Not for use with Contemporary Burner/
Floor Kit.
REQUIRED ACCESSORIES
One of the following Firebox Liner Kits:
a. Ceramic Firebox Liner Kit–
Buff Rustic
B Ceramic Firebox Liner Kit–
Red Rustic
c. Porcelain Firebox Liner Kit–
Black
d. Ceramic Firebox Liner Kit–
Red Herringbone
e. Ceramic Firebox Liner Kit–
Buff Herringbone
NOTE: Porcelain kits include side and back panels.
Optional for use with log sets. Required when
using the contemporary burner/floor kit.

3
)../6!4)6%(%!24(02/$5#43s$)2%#46%.4'!3&)2%0,!#%3-ONTEBELLO$,8-ONTEBELLO$,8#$s).34!,,!4)/.).3425#4)/.3
WARNING
Young children should be care-
fully supervised when they are
in the same room as the appli-
ance. Toddlers, young children
and others may be susceptible
to accidental contact burns. A
physicalbarrierisrecommended
if there are at risk individuals in
the house. To restrict access to
a fireplace or stove, install an
adjustable safety gate to keep
toddlers, young children and
other at risk individuals out of
the room and away from hot
surfaces.
AVERTISSEMENT
Lesjeunesenfantsdevraientêtre
surveillésétroitementlorsqu’ils
se trouvent dans la même pièce
que l’appareil. Les tout petits,
lesjeunesenfantsoulesadultes
peuvent subir des brûlures s’ils
viennent en contact avec la sur-
face chaude. Il est recommandé
d’installerunebarrièrephysique
si des personnes à risques habi-
tent la maison. Pour empêcher
l’accès à un foyer ou à un poêle,
installez une barrière de sécu-
rité;cettemesureempêcherales
tout petits, les jeunes enfants et
toute autre personne à risque
d’avoir accès à la pièce et aux
surfaces chaudes.
GENERAL INFORMATION
Children and adults should be alerted to the
hazards of high surface temperature and
should stay away to avoid burns or clothing
ignition.
Les enfants et les adultes devraient être
infor-més des dangers que posent les
températures de surface élevées et se
tenir à distance afin d’éviter des brûlures
ou que leurs vêtements ne s’enflamment.
DO NOT ATTEMPT TO ALTER OR MODIFY
THE CONSTRUCTION OF THE APPLIANCE OR
ITS COMPONENTS. ANY MODIFICATION OR
ALTERATION MAY VOID THE WARRANTY,
CERTIFICATION ANDLISTINGSOFTHISUNIT.
Installation and repair should be done by
a qualified service person. The appliance
should be inspected before use and at least
annually by a professional service person.
More frequent cleaning may be required due
to excessive lint from carpeting, bedding ma-
terial, etcetera. It is imperative that control
compartments, burners and circulating air
passageways of the appliance be kept clean.
L’installation et la réparation devrait
être confiées à un technicien qualifié.
L’appareil devrait faire l’objet d’une in-
spection par un technicien professionnel
avant d’être utilisé et au moins une fois
l’an par la suite. Des nettoyages plus
fréquents peuvent être nécessaires si les
tapis, la literie, et cetera produisent une
quantité importante de pous-sière. Il est
essentiel que les compartiments abritant
les commandes, les brûleurs et les con-
duits de circulation d’air de l’appareil
soient tenus propres.
Do not use this appliance if any part has
been under water. Immediately call a
qualified service technician to inspect the
appliance and to replace any parts of the
control system and any gas control which
have been under water.
Ne pas se servir de cet appareil s'il a été
plongé dans l'eau, complètement ou en
partie. Appeler un technicien qualifié
pour inspecter l'appareil et remplacer
toute partie du système de contrôle et
toute commande qui ont été plongés
dans l'eau.
Only trim kit(s) supplied by the manufacturer
shall be used in the installation of this ap-
pliance.
Seules les trousses de garniture fournies
par le fabricant doivent être utilisées pour
l’installation de cet appareil.
0ROVIDEADEQUATECLEARANCESAROUNDAIROPEN-
INGSANDADEQUATEACCESSIBILITYCLEARANCEFOR
SERVICEANDPROPEROPERATION.EVEROBSTRUCT
the front openings of the appliance.
These appliances are designed to operate on
natural or propane gas only. The use of other
fuels or combination of fuels will degrade
the performance of this system and may be
dangerous.
4HESEAPPLIANCESMUSTNOTBECONNECTEDTOA
chimney or flue serving a separate solid fuel
BURNINGAPPLIANCE
WARNING
Improper installation, adjust-
ment, alteration, service or
maintenance can cause injury
or property damage. Refer to
this manual. For assistance or
additional information consult
a qualified installer, service
agency or the gas supplier.
WARNING
Failure to comply with these
installationinstructionswillresult
in an improperly installed and
operating appliance, voiding its
warranty.Anychangetothisappli-
anceand/oritsoperatingcontrols
is dangerous.
WARNING
Clothing or other flammable
material should not be placed
on or near the appliance.
AVERTISSEMENT
On ne devrait pas placer de
vêtements ni d’autres matières
inflammables sur l’appareil ni à
proximité.
WARNING
Any safety screen or guard
removed for servicing the appli-
ance must be replaced prior to
operating the appliance.
AVERTISSEMENT
Tout écran ou protecteur retiré
pour permettre l’entretien de
l’appareil doit être remis en
place avant de mettre l’appareil
en marche.
WARNING
Improper installation or use of
thisappliancecancauseserious
injury or death from fire, burns,
explosion or carbon monoxide
poisoning.

4
./4%$)!'2!-3),,5342!4)/.3!2%./44/3#!,%
)../6!4)6%(%!24(02/$5#43s$)2%#46%.4'!3&)2%0,!#%3-ONTEBELLO$,8-ONTEBELLO$,8#$s).34!,,!4)/.).3425#4)/.3
The appliance and its appliance main gas
VALVEMUST BE DISCONNECTEDFROM THEGAS
supply piping system during any pressure
testing of that system at test pressures in
excess ofPSIK0A
4HEAPPLIANCEMUSTBEISOLATEDFROMTHEGAS
SUPPLYPIPINGSYSTEMBYCLOSINGITSEQUIPMENT
shutoff valve during any pressure testing of
thegassupplypiping systemattestpressures
equal to or less thanPSIK0A
Orifice Sizes—Sea Level To High Altitude
(All Models)
These appliances are tested and approved
for installation at elevations of 0–4500 feet
n METERS ABOVE SEA LEVEL USING THE
STANDARDBURNERORIlCESIZESMARKEDWITHAN
ASTERISKINTable 4)&ORELEVATIONSABOVE
FEETCONTACTYOURGASSUPPLIERORQUALIlED
service technician.
Deration—At higher elevations, the amount
OF"45FUELVALUEDELIVEREDMUSTBEREDUCED
BYEITHER
s USINGGASTHATHASBEENDERATEDBYTHEGAS
COMPANYOR
s CHANGINGTHEBURNERORIlCETOASMALLERSIZE
ASREGULATEDBYTHELOCALAUTHORITIESHAVING
JURISDICTIONANDBYTHE53!.ATIONAL&UEL
'AS #ODE .&0! !.3) :LATEST
EDITIONORIN#ANADATHE#!.#'!"
CODESLATESTEDITION
Installtheapplianceaccordingtotheregulations
OFTHELOCALAUTHORITIESHAVINGJURISDICTIONAND
INTHE53!THE.ATIONAL&UEL'AS#ODE.&0!
!.3):LATESTEDITIONORIN#ANADA
THE#!.#'!"LATESTEDITION
NOTE: Flame appearance will diminish 4% per
thousand feet of altitude.
Burner Orifice Sizes
Elevation 0–4500 ft ( 0–1372 m)
Model Nat.Gas
drill size (inches) Propane drill size (inches)
40 in. 0.1405" (#28)*
s(
0.086" (#44)*
s(
45 in. 0.154" (#23)*
s(
0.093" (#42)*
s(
Table 4 * Standard size installed at factory
s0ART#AT.UMBER
Test gauge connections are provided on the
FRONTOFTHEGASCONTROLVALVEIDENTIlED).FOR
THEINLETAND/54FORTHEMANIFOLDSIDE
0ROPANETANKSAREATPRESSURESTHATWILLCAUSE
damage to valve components. Verify that the
TANKSHAVESTEPDOWNREGULATORSTOREDUCETHE
pressure to safe levels.
Gas Pressure—All Models
Appliance inlet and manifold gas pressure
REQUIREMENTSARELISTEDINTables 2 and 3.
Inlet Gas Supply Pressure
Fuel # Minimum Maximum
Natural
Gas
5.5" WC
(1.37 kPa)
10.5" WC
(2.61 kPa)
Propane 11.0" WC
(2.74 kPa)
13.0" WC
(3.23 kPa)
Table 2
Manifold Gas Supply Pressure
Fuel # Low High
Natural
Gas
1.6" WC
(.4 kPa)
3.5" WC
(.87 kPa)
Propane 6.3" WC
(1.57 kPa)
10.0" WC
(2.49 kPa)
Table 3
REQUIREMENTS FOR THE COMMON-
WEALTH OF MASSACHUSETTS
4HESElREPLACESAREAPPROVEDFORINSTALLATIONIN
THE53STATEOF-ASSACHUSETTSIFTHEFOLLOWING
ADDITIONALREQUIREMENTSAREMET
s )NSTALL THIS APPLIANCE IN ACCORDANCE WITH
-ASSACHUSETTS2ULESAND2EGULATIONS
#-2
s )NSTALLATIONANDREPAIRMUSTBEDONEBYA
PLUMBERORGASlTTERLICENSEDINTHE#OM-
MONWEALTHOF-ASSACHUSETTS
s 4HEmEXIBLEGASLINECONNECTORUSEDSHALL
NOTEXCEEDINCHESCENTIMETERS IN
length.
s 4HEINDIVIDUALMANUALSHUTOFFMUSTBEA
T-handle type valve.
Massachusetts Horizontal Vent Requirements
Inthe CommonwealthofMassachusetts,hori-
zontal terminations installed less than seven
(7) feet above the finished grade must comply
with the following additional requirements:
s ! HARD WIRED CARBON MONOXIDE DETECTOR
WITHANALARMANDBATTERYBACKUPMUSTBE
installed on the floor level where the gas
lREPLACEISINSTALLED4HECARBONMONOXIDE
DETECTORMUSTCOMPLYWITH.&0!BE
!.3)5,LISTEDANDBE)3!CERTIlED
s !METALORPLASTICIDENTIlCATIONPLATEMUST
BEPERMANENTLYMOUNTEDTOTHEEXTERIOROF
THEBUILDINGATAMINIMUMHEIGHTOFEIGHT
FEETABOVEGRADEANDBEDIRECTLYINLINEWITH
the horizontal termination. The sign must
READINPRINTSIZENOLESSTHANONEHALF
INCHINSIZE'!36%.4$)2%#4,9"%,/7
+%%0#,%!2/&!,,/"3425#4)/.3
Gas Valve Diagram
The SIT Proflame gas valve is shown in Figure
1.
Input (BTU/HR)
Model Input (BTU/Hr)
Natural Gas
40 in. 32,000 to 50,000
45 in. 38,500 to 60,000
Propane Gas
40 in. 32,000 to 50,000
45 in. 38,500 to 60,000
Table 1
These electronic appliances are remotely
controlled and feature an electronic intermit-
tent pilot ignition system or standing pilot.
%XTERNALELECTRICALPOWERISREQUIREDTOOPERATE
these units.
These electronic models come standard with a
REMOTELYMODULATEDGASVALVEmAMEAPPEAR-
ANCEANDHEATOUTPUTCANNOTBECONTROLLEDAT
THEGASVALVE4HE"45)NPUTFORTHESEAPPLI-
ances is shown in Table 1.
Wire
(From DFC Wire
Harness)
Pressure
Regulator
Tower
Yellow Ground Wire
(From DFC Wire
Harness)
Green Wire
(From DFC Wire
Harness)
Inlet (In) Test Port
Manifold (Out)
Test Port
Connect GTMS
Wire Harness
Figure 1—SIT Proflame Valve
Main Gas Inlet
3/8" NPT

./4%$)!'2!-3),,5342!4)/.3!2%./44/3#!,%
5
)../6!4)6%(%!24(02/$5#43s$)2%#46%.4'!3&)2%0,!#%3-ONTEBELLO$,8-ONTEBELLO$,8#$s).34!,,!4)/.).3425#4)/.3
LOCATION
In selecting the location, the aesthetic and
functional use of the appliance are primary
concerns. However, vent system routing to
THEEXTERIORANDACCESSTOTHEFUELSUPPLYARE
also important.
Due to high temperatures, the appliance
should be located out of traffic and away from
furniture and draperies (Figure 2).
En raison des températures élevées,
l’appareil devrait être installé dans un
endroit où il y a peu de circulation et loin
du mobilier et des tentures (Figure 2).
4HELOCATIONSHOULDALSOBEFREEOFELECTRICAL
PLUMBING OR OTHER HEATINGAIR CONDITIONING
ducting.
4HESE DIRECTVENT APPLIANCES ARE UNIQUELY
SUITEDFORINSTALLATIONSREQUIRINGAUTILITYSHELF
POSITIONEDDIRECTLYABOVETHElREPLACE5TILITY
SHELVES LIKE THESE ARE COMMONLY USED FOR
locating television sets and decorative plants.
Drywall
Top Of Fireplace
Opening Non-Combustible
Figure 2—Typical Installation
When the unit is installed with one side flush with
a wall, the wall on the other side of the unit must
not extend beyond the front edge of the unit.
HORIZONTAL VENT VERTICAL VENT
HORIZONTAL VENT VERTICAL VENT
CROSS CORNER
APPLICATION
RECESSED
APPLICATION
FLAT
APPLICATION
ROOM DIVIDER
APPLICATION
FLAT ON WALL
APPLICATION
ISLAND
APPLICATION
COLD CLIMATE INSULATION
&ORCOLD CLIMATEINSTALLATIONSSEALALLCRACKS
AROUND YOUR APPLIANCE WITH NONCOMBUSTIBLE
material and wherever cold air could enter
the room. It is especially important to insulate
OUTSIDECHASECAVITYBETWEENSTUDSANDUNDER
mOORONWHICHAPPLIANCERESTSIFmOORISABOVE
GROUNDLEVEL'ASLINEHOLESANDOTHEROPENINGS
SHOULD BE CAULKED OR STUFFED WITH UNFACED
lBERGLASSINSULATION
)FTHElREPLACEISBEINGINSTALLEDONACEMENT
SLABINCOLDCLIMATESASHEETOFPLYWOODOR
OTHERRAISEDPLATFORMCANBEPLACEDUNDERNEATH
TOPREVENT COLDTRANSFERTO THElREPLACE AND
INTOTHEROOM)TALSOHELPSTOSHEETROCKINSIDE
SURFACESANDTAPEFORMAXIMUMAIRTIGHTNESS
ANDCAULKlRESTOPS
MANUFACTUREDHOMEREQUIREMENTS
4HISAPPLIANCEMAYBEINSTALLEDINANAFTERMARKET
permanently located, manufactured home and
MUSTBEINSTALLEDINACCORDANCEWITHTHEMANU-
FACTURERgSINSTRUCTIONSANDTHE-ANUFACTURED
Home Construction and Safety Standard, Title
#&20ARTINTHE5NITED3TATESORTHE
3TANDARDFOR)NSTALLATIONIN-OBILE(OMES#!.
#3!:-(3ERIESIN#ANADA
Cet appareil peut être installé cómme
du matéri-el d'origine dans une maison
PR£FABRIQU£E »5 SEULEMENT OU MOBILE
et doit être installé selon les instructions
DUFABRICANTETCONFORM£MENTÜLANORME
-ANUFACTURED (OME #ONSTRUCTIONS AND
3AFETY4ITLE#&2 0ART AUX 5NIS
OU Ü LA NORME #AN#3!: 3£RIE --
-AISONSMOBILESAU#ANADA
This appliance is only for use with the type of
gas indicated on the rating plate. This appliance
ISNOTCONVERTIBLEFORUSEWITHOTHERGASESUN-
LESSACERTIlEDKITISUSED
#ET APPAREIL DOIT äTRE UTILIS£ UNIQUEMENT
AVECLETYPEDEGAZINDIQU£SURLAPLAQUE
SIGNAL£TIQUE#ETAPPAREILNEPEUTäTRECON-
VERTIÜDgAUTRESGAZSAUFSIUNETROUSSEDE
conversion est utilisée.
CAUTION: Ensure that the cross members
are not cut or weakened during installa-
tion. The structural integrity of the manu-
facturedhomefloor, wall,and ceiling /roof
must be maintained.
CAUTION: This appliance must be ground-
ed to the chassis of the manufactured
home in accordance with local codes or
in the absence of local codes, with the
National Electrical Code ANSI / NFPA 70—
latest edition or the Canadian Electrical
Code CSA C22.1—latest edition.
Be aware that this is a heat producing ap-
pliance. Objects placed above the unit are
exposed to elevated temperatures.
Do not insulate the space between the
appliance and the area above itsee Figure
7 on Page 8).
4HE MINIMUM HEIGHT FROM THE BASE OF THE
APPLIANCE TO THE UNDERSIDE OF COMBUSTIBLE
materials used to construct a utility shelf in
this fashion is shown in Figure 7 on Page 8.
4HE APPLIANCE MUST BE MOUNTED ON A FULLY
SUPPORTED BASE EXTENDING THE FULL WIDTH
ANDDEPTHOFTHEUNIT4HEAPPLIANCEMAYBE
located on or near conventional construction
MATERIALS(OWEVERIFINSTALLEDONCOMBUSTIBLE
materials, such as carpeting, vinyl tile, or other
COMBUSTIBLEMATERIALOTHERTHANWOODmOORING
THEAPPLIANCESHALLBEINSTALLEDONAMETALOR
WOODPANELEXTENDINGTHEFULLWIDTHANDDEPTH
of the appliance.
Recessed
Application
Cross Corner
Application
Flat
Application
Flat on Wall
Application
Room Divider
Application
Island
Application

6
./4%$)!'2!-3),,5342!4)/.3!2%./44/3#!,%
)../6!4)6%(%!24(02/$5#43s$)2%#46%.4'!3&)2%0,!#%3-ONTEBELLO$,8-ONTEBELLO$,8#$s).34!,,!4)/.).3425#4)/.3
3"
(76 mm)
Termination Kit
Combustible Projection
greater than 2-1/2” in length
Horizontal Vent Termination Clearances
Combustible Projection
2-1/2” or less in length
24"
(610 mm)
Ventilated Or
Unventilated Soffit
SeeFigure 28 onPage18 for therecessallowances,into
exterior walls, of the square horizontal terminations.
Termination Heights For Vents
Above Flat Or Sloped Roofs
Ref. NFPA 54 / ANSI Z223.1
Roof Pitch * Feet * Meters
&LATTO 1.0 
TO 1.25 
TO 1.5 0.46
TO 2.0 0.61
TO 2.5 
10/12 to 11/12  
11/12 to 12/12 4.0 1.22
12/12 to 14/12 5.0 1.52
14/12 to 16/12 6.0 
TO  
TO  
20/12 to 21/12  2.44
4HEVENTAIRINTAKETERMINATIONCLEARANCES
ABOVETHEHIGHSIDEOFANANGLEDROOFISAS
shown in the following chart:
12
X
Roof Pitch is X/12
2 FT
MIN.
2 FT MIN.
Lowest
Discharge
Opening
H*
*H = MINIMUM HEIGHT FROM ROOF TO
LOWEST DISCHARGE OPENING OF VENT
TERMINATION HEIGHTS FOR VENTS ABOVE
FLAT OR SLOPED ROOFS
Horizontal Overhang
Vertical
Wall
Vent
Termination
Storm Collar
Concentric
Vent Pipe
Flashing
1” (25.4 mm) Minimum
Clearance to Combustibles
Vertical Vent Termination Clearances
Figure 4
VENT TERMINATION CLEARANCES
These instructions should be used as a
guideline and do not supersede local codes
in any way. Install vent according to local
codes,theseinstructions,thecurrentNational
Fuel Gas Code (ANSI-Z223.1) in the USA or
the current standards of CAN/CGA-B149.1 in
Canada.
Vertical Vent Termination Clearances
Terminate multiple vent terminations according
TOTHEINSTALLATIONCODESLISTEDABOVE!LSOSEE
Figure 3.
4ERMINATESINGLEVENTCAPSRELATIVETOBUILDING
components according to Figures 3 and 4.
Horizontal Vent Termination Clearances
4HEHORIZONTALVENTTERMINATIONMUSTHAVEAMINIMUMOFMMCLEARANCETOANYOVERHEAD
COMBUSTIBLEPROJECTIONOFMMORLESSSEEFigure 5). &ORPROJECTIONSEXCEEDING
MMSEEFigure 5&ORADDITIONALVENTLOCATIONRESTRICTIONSREFERTOFigure 6 on Page 7.
12”
(305mm)
Minimum
Figure 3—Multiple Terminations
Figure 5—Side Elevation View

./4%$)!'2!-3),,5342!4)/.3!2%./44/3#!,%
7
)../6!4)6%(%!24(02/$5#43s$)2%#46%.4'!3&)2%0,!#%3-ONTEBELLO$,8-ONTEBELLO$,8#$s).34!,,!4)/.).3425#4)/.3
Minimum Clearances Canadian Installation * US Installation **
!#LEARANCEABOVE GRADE VERANDAPORCHDECK
ORBALCONY
CM CM
"#LEARANCETOWINDOWORDOORTHATMAYBEOPENED CMFORAPPLIANCES"45HRK7
CMFORAPPLIANCES"45HRK7AND
"45HRK7CMFORAPPLIANCES
"45HRK7
CMFORAPPLIANCES"45HRK7
CMFORAPPLIANCES"45HRK7AND
"45HRK7CMFORAPPLIANCES
"45HRK7
C = Clearance to permanently closed window MMRECOMMENDEDTOPREVENTWINDOWCONDEN-
sation
  MM RECOMMENDED TO PREVENT WINDOW CON-
densation
$6ERTICALCLEARANCETOVENTILATEDSOFlTLOCATED
ABOVETHETERMINALWITHINAHORIZONTALDISTANCEOF
CMFROMTHECENTERLINEOFTHETERMINAL
CM CM
%#LEARANCETOUNVENTILATEDSOFlT CM CM
&#LEARANCETOOUTSIDECORNER CM CM
'#LEARANCETOINSIDECORNER CM CM
(#LEARANCETOEACHINSIDEOFCENTERLINEEXTENDED
ABOVEMETERREGULATORASSEMBLY
FEETCMWITHINAHEIGHTOFFEETABOVETHEMETER
REGULATORASSEMBLY
FEETCMWITHINAHEIGHTOFFEETABOVETHEMETER
REGULATORASSEMBLY
I = Clearance to service regulator vent outlet FEETCM FEETCM
J = Clearance to non-mechanical air supply inlet
TOBUILDINGORTHECOMBUSTIONAIRINLETTOANYOTHER
appliance
CMFORAPPLIANCES"45HRK7
CMFORAPPLIANCES"45HRK7AND
"45HRK7CMFORAPPLIANCES"45
HRK7
CMFORAPPLIANCES"45HRK7
CMFORAPPLIANCES"45HRK7AND
 "45HR K7CMFORAPPLIANCES
"45HRK7
+#LEARANCETOMECHANICALAIRSUPPLYINLET FEETMETERS FEETCMABOVEIFWITHINFEETMHORIZONTALLY
,  #LEARANCE ABOVE PAVED SIDEWALK OR PAVED
DRIVEWAYLOCATEDONPUBLICPROPERTY
FEETMp FEETMp
-  #LEARANCE UNDER VERANDA PORCH DECK OR
BALCONY
CMp CMp
)NACCORDANCEWITHTHECURRENT#!.#'!".ATIONAL'ASAND"0ROPANE)NSTALLATION#ODE,ATEST%DITIONS
)NACCORDANCEWITHTHECURRENT!.3):.&0!.ATIONAL&UEL#ODES,ATEST%DITION
p!VENTSHALLNOTTERMINATEDIRECTLYABOVEASIDEWALKORPAVEDDRIVEWAYWHICHISLOCATEDBETWEENTWOSINGLEFAMILYDWELLINGSANDSERVESBOTHDWELLINGS
p/NLYPERMITTEDIFVERANDAPORCHDECKORBALCONYISFULLYOPENONAMINIMUMSIDESBENEATHTHEmOOR
Figure 6—Exterior Horizontal Vent Termination Clearance Requirements
NOTE: Local Codes Or Regulations May Require
Different Clearances.
NOTE: Location Of The Vent Termination Must Not
Interfere With Access To The Electrical Service.
V
V V
V
V
F
C
B
B
A
B
H
M
I
X V
D
V
A A
A
V
L
B
J
X E
V
A
G
*18”
18”
B
C
C
C
K
X
!
!
!
* See Item D in the Text Below.
Center Line
of Termination
Exterior Wall
Horizontal
Termination
Ventilated Soffit
Inside Corner
DETAIL D
Inside
Corner Detail
Operable
Window
Fixed
Closed
Window
= 9" in U.S.
=12" in Canada
3 ft.
3 ft.
= Air Supply Inlet = Vent Terminal = Area where Terminal is NOT permitted
24"
36"

8
./4%$)!'2!-3),,5342!4)/.3!2%./44/3#!,%
)../6!4)6%(%!24(02/$5#43s$)2%#46%.4'!3&)2%0,!#%3-ONTEBELLO$,8-ONTEBELLO$,8#$s).34!,,!4)/.).3425#4)/.3
*NOTE: 3" (75 mm) above any horizontal/inclined vent component.
**NOTE: See Page 9, Step 1 for clearance requirements to the nailing
flange located at each side of the unit and any screw heads adjacent
to it. See Page 28 for hearth extension requirements.
Shelf Height
4OPROVIDEFORTHELOWESTPOSSIBLESHELFSURFACETHEVENTINGATTACHEDTO
THETOPVENTSHOULDBEROUTEDINAWAYTOMINIMIZEOBSTRUCTIONSTOTHE
SPACEABOVETHEAPPLIANCEDo not insulate the space between the ap-
pliance and the area above itSEEFigure 7). The minimum height from
THEBASEOFTHEAPPLIANCETOTHEUNDERSIDEOFCOMBUSTIBLEMATERIALSUSED
to construct a utility shelf in this fashion is shown in Figure 7.
Wall Finishes / Surrounds / Mantels
NOTE: Combustible wall finish materials and/or surround materials must
not be allowed to encroach the area defined by the appliance front face
(black sheet metal). Never allow combustible materials to be positioned
in front of or overlapping the appliance face. See Figure 9 and Figure
51 on Page 28.
.ONCOMBUSTIBLEMATERIALSSUCHASSURROUNDSANDOTHERAPPLIANCETRIM
MAYBEINSTALLEDONTHEAPPLIANCEFRONTFACEWITHTHESEEXCEPTIONSTHEY
MUSTNOTCOVERANYPORTIONOFTHEREMOVABLEGLASSPANEL
6ERTICALINSTALLATIONCLEARANCESTOCOMBUSTIBLEMANTELSVARYACCORDING
to the depth of the mantel. See Figure 8-ANTELSCONSTRUCTEDOFNON
COMBUSTIBLEMATERIALSMAYBEINSTALLEDATANYHEIGHTABOVETHEAPPLIANCE
OPENING-INIMUMCLEARANCEREQUIREMENTSINCLUDEANYPROJECTIONSSUCH
ASSHELVESWINDOWSILLSMANTELSETCABOVETHEAPPLIANCE
NOTE: We recommend the use of high temperature paint (rated 175° F
or higher) on the underside of the mantel.
MINIMUM CLEARANCES TO COMBUSTIBLES
4HEAPPLIANCEISAPPROVEDWITHZEROCLEARANCETOCOMBUSTIBLEMATERIALS
ONALLSIDESASDETAILEDINTable 5)WITHTHEFOLLOWINGEXCEPTIONWhen
the unit is installed with one side flush with a wall, the wall on the
other side of the unit must not extend beyond the front edge of the
unit. In addition, when the unit is recessed, the side walls surrounding
THEUNITMUSTNOTEXTENDBEYONDTHEFRONTEDGEOFTHEUNITSEEFigure 2).
Figure 9
17 in.
(432 mm)
14 in.
(356 mm)
8-1/4 in.
(210 mm)
45°
12 in.
(305 mm)
5 in.
(127 mm)
12 (305)
10 (254)
8 (203)
6 (152)
4 (102)
7
(178)
17
(432)
15
(381) 13
(330) 2 (51)
9
(229)
11
(279)
Figure 8
Combustible Materials
Allowed In Shaded Area
"Safe Zone" Top View of
Fireplace
Minimum Distance to
Protected Side Wall
Minimum Distance to
Unprotected Side Wall
Side
Wall
Side
Wall
MANTEL
CLEARANCES
Inches (mm)
Top of Appliance
MANTEL
MANTEL
MANTEL
MANTEL
MANTEL
MANTEL
Fireplace
(side view)
Figure 7
APPLIANCE MINIMUM CLEARANCES*
Inches (millimeters)
Sides 1/2 (13), 0 (0) Spacers **
Top Spacers 0 (0)
Floor 0 (0)
Back 1/2 (13), 0 (0) Spacers
Bottom of Appliance To Ceiling 69 (1743)
Vent 3 (76) Top* / 1 (25.4) Sides & Bottom
SERVICE CLEARANCES Feet (meters)
Front 3 feet (0.9 meters)
Table 5
Combustible Shelf Height—Inches (millimeters)
Top Vent—with 2 Feet Vertical Vent and One 90 Degree Elbow
Model Secure Vent
®
40 in. *84-1/16 (2135)
45 in. *89-1/16 (2252)
* Includes 3" clearance to combustibles (required above vent components)
Do not insulate the
space between the
appliance and the
area above it.
2-1/2 ft
(to centerline)
Vertical
Vent (minimum)
Shelf Height
(see table)
Shelf Above Fireplace With Top Venting

./4%$)!'2!-3),,5342!4)/.3!2%./44/3#!,%
9
)../6!4)6%(%!24(02/$5#43s$)2%#46%.4'!3&)2%0,!#%3-ONTEBELLO$,8-ONTEBELLO$,8#$s).34!,,!4)/.).3425#4)/.3
TYPICAL INSTALLATION SEQUENCE
4HETYPICALSEQUENCEOFINSTALLATIONISOUTLINED
BELOW(OWEVEREACHINSTALLATIONISUNIQUEAND
MAYRESULTINVARIATIONSTOTHESTEPSDESCRIBED
3EETHE0AGENUMBERSREFERENCESINTHEFOLLOW-
ing steps for detailed procedures.
Step 1. (Page 9) Construct the appliance
framing. Position the appliance within
the framing and secure with nailing
BRACKETS
Step 2. (Page 11) Route gas supply line to the
right side.
Step 3. (Page 12)Install the vent system and
EXTERIORTERMINATION
Step 4. (Page 21) Connect 120 VAC electrical
power to the appliance receptacle.
Step 5. (Page 23)Remove glass door assem-
BLY
Step 6. (Page 23) -AKE CONNECTION TO GAS
supply.
Step 7. (Page 23)Verifying appliance opera-
tion.
Step 8. (Page 24))NSTALLlREBOXLINERPANELS
LOGSANDGLOWINGEMBERS
OR
 CONTEMPORARYBURNERmOORKITPORCE-
lain panels, and media.
Step 9. (Page 26))NSTALLGLASSDOORASSEMBLY
Step 10. (Page 26) !DJUST BURNER TO ENSURE
proper flame appearance.
Step 11. (Page 29) Attach safety in operation
warnings.
Left Side Front Corner of Fireplace Shown
(Right Side Requirements the Same)
Unit Being Secured By Its Nailing Flanges
To The Framing
NOTE: The nailing flanges, combustible members and
screw heads located in areas directly adjacent to
the nailing flanges, are EXEMPT from the 1/2” clear-
ance to combustible requirements for the firebox
outer wrapper. Combustible framing may be in direct
contact with the nailing flanges and may be located
closer than 1/2” from screw heads and the firebox
wrapper in areas adjacent to the nailing flanges.
Frame the opening to the exact dimensions speci-
fied in the framing details of this manual.
Unit Being Secured by Its Nailing
Flanges to the Framing
Unit Being Secured by Its Nailing
Flanges to the Framing
Note: The nailing flanges, combustible members
and screw heads located in areas directly adjacent
to the nailing flanges, are EXEMPT from the 1/2”
clearance to combustible requirements for the
firebox outer wrapper. Combustible framing may be
in direct contact with the nailing flanges and may
be located closer than 1/2” from screw heads and
the firebox wrapper in areas adjacent to the nailing
flanges. Frame theopening to the exact dimensions
specified in the framing details of this manual.
Use Top Flange For
1/2” Thick Drywall
Use Bottom Flange For
5/8” Thick Drywall
Front Of
Fireplace
Use Center Flange
For Flush Mount
Left Side Front Corner of Fireplace Shown
(Right Side Requirements the Same)
Unit Being Secured By Its Nailing Flanges
To The Framing
Step 1. FRAMING
&RAMETHESEAPPLIANCESASILLUSTRATEDINFigure
11 on Page 10, UNLESSTHEAPPLIANCEISTOBE
installed in a corner. See Figure 12 on Page
11 for corner framing installations. All framing
details must allow for a minimum clearance to
COMBUSTIBLE FRAMING MEMBERS AS SHOWN IN
Table 5 on Page 8.
)FTHEAPPLIANCEISTOBEELEVATEDABOVEmOOR
LEVEL A SOLID CONTINUOUS PLATFORM MUST BE
CONSTRUCTEDBELOWTHEAPPLIANCE
(EADERS MAY BE IN DIRECT CONTACT WITH THE
APPLIANCETOPSPACERSBUTMUSTNOT BE SUP-
PORTEDBYTHEMORNOTCHEDTOlTAROUNDTHEM
!LLCONSTRUCTIONABOVETHEAPPLIANCEMUSTBE
self-supporting, DO NOT use the appliance for
structural support.
4HE lREPLACE SHOULD BE SECURED TO THE SIDE
FRAMING MEMBERS USING THE UNITgS NAILING
mANGESONETOPANDBOTTOMONEACHSIDEOF
THElREPLACEFRONTSEEFigure 10). 5SEDNAILS
ORTHEIREQUIVALENT
Figure 10
DETAILED INSTALLATION STEPS
The appliance is shipped with all gas
controls and components installed and pre-
wired.
 2EMOVETHESHIPPINGCARTONEXPOSINGTHE
front glass door on the valve access side.
2. Using a Phillips screwdriver, unfasten two
SCREWSLOCATEDATTHETOPOFTHEGLASS
FRAMEsee Figure 46 on page 26). Tilt the
top of the glass frame away from the unit.
,IFTITCAREFULLYOFFTHEBOTTOMDOORTRACK
and set the door aside, protecting it from
inadvertent damage.
WARNING
Failure to position the parts in
accordance with these diagrams
orfailure to use only partsspecifi-
callyapprovedwiththisappliance
may result in property damage or
personal injury.
AVERTISSEMENT
Risque de dommages ou de
blessures si les pièces ne sont
pas installées conformément à
ces schémas et ou si des pièces
autres que celles spécifiquement
approuvéesaveccetappareilsont
utilisées.

10
./4%$)!'2!-3),,5342!4)/.3!2%./44/3#!,%
)../6!4)6%(%!24(02/$5#43s$)2%#46%.4'!3&)2%0,!#%3-ONTEBELLO$,8-ONTEBELLO$,8#$s).34!,,!4)/.).3425#4)/.3
Figure 11—Fireplace and Framing Specifications
E
A
B
D
Top View
Front View
5-3/32 (129)
Right Side View
14-1/8
8-1/2”
(216)
5-1/4”
(133)
(359) 26-15/32
(672)
C
25-29/32
(658)
25-1/2
(648)
7
2-1/2 (64)
(178)
19-5/8
(498)
Gas Inlet
(This
Side
Only)
Electrical
Inlet
8-3/8
(213)
F
G
H
J
Fireplace Dimensions
Model A B C D E F G H J
40 in. in. 50-5/8 37-1/4 42-7/8 25-5/16 34 37-5/8 33-3/32 29-9/32 34-3/4
mm 1286 946 1089 643 864 956 840 744 883
45 in. in. 56-11/16 42-1/4 47-7/8 28-3/8 40-1/8 43-5/8 38-3/32 34-1/2 40-59/64
mm 1440 1073 1216 721 1019 1108 968 876 1039
Notes
Diagrams, illustrations and photo-
graphs are not to scale — consult
installation instructions. Product
designs, materials, dimensions,
specifications, colors and prices are
subject to change or discontinuance
without notice.
Vent Size
Coaxial DV
Vent Size
8" Inner
11" Outer
Framing Dimensions
Model A B C
40 in. in. 50-3/4 43 75-1/8
mm 1289 1092 1908
45 in. in. 56-7/8 48 80-1/16
mm 1445 1219 2034
A
BC
8-1/2
(216)
13
(330)
VENT FRAMING
TOP VENT WITH 2 FEET
VERTICAL VENT AND
ONE 90° ELBOW
Framing should be constructed
of 2x4 or larger lumber.
Inches (mm)
(641)
25-1/4
15
(381)
6-1/2
(165)
1/2 A
PIPE CENTERLINE
A
BC
8-1/2
(216)
13
(330)
VENT FRAMING
TOP VENT WITH 2 FEET
VERTICAL VENT AND
ONE 90° ELBOW
Framing should be constructed
of 2x4 or larger lumber.
Inches (mm)
(641)
25-1/4
15
(381)
6-1/2
(165)
1/2 A
PIPE CENTERLINE
Thermal Efficiency (%)
Natural Gas Propane
Model P4 P4
40 in. 35.8 TBD
45 in. 51.2 TBD

./4%$)!'2!-3),,5342!4)/.3!2%./44/3#!,%
11
)../6!4)6%(%!24(02/$5#43s$)2%#46%.4'!3&)2%0,!#%3-ONTEBELLO$,8-ONTEBELLO$,8#$s).34!,,!4)/.).3425#4)/.3
Figure 12—Corner Framing with Square Termination (SV8HTS)
Proper Sizing of Gas Line
Properly size and route the gas supply
line from the supply regulator to the area
WHERE THE APPLIANCE IS TO BE INSTALLED PER
REQUIREMENTSOUTLINEDINTHE.ATIONAL&UEL'AS
#ODE.&0!LATESTEDITION53!OR#!.
#'!"LATESTEDITION#ANADA
NOTES:
s !LLAPPLIANCESAREFACTORYEQUIPPEDWITHA
mEXIBLEGASLINECONNECTORANDSHUTOFF
VALVESEEFigure 36 on Page 23).
s 3EEMassachusetts Requirements on Page
4FORADDITIONALREQUIREMENTSFORINSTALLATIONS
INTHESTATEOF-ASSACHUSETTSINTHE53!
s 4HEGASSUPPLYLINESHOULD.OTBECONNECTED
to the appliance until Step 6Page 23).
s !PIPEJOINTCOMPOUNDRATEDFORGASSHOULDBE
USEDONTHETHREADEDJOINTSEnsurepropane
resistant compounds are used in propane
applications"EVERYCAREFULTHATTHEPIPE
compound does not get inside the pipe.
s )TISRECOMMENDEDTOINSTALLASEDIMENTTRAP
INTHESUPPLYLINEASCLOSEASPOSSIBLETOTHE
APPLIANCESEEFigure 36 on Page 23).
s #HECKWITHLOCALBUILDINGOFlCIALFORLOCAL
CODEREQUIREMENTS
IMPORTANT: If propane is used, be aware that
if tank size is too small (i.e. under 100 lbs, if
this is the only gas appliance in the dwelling.
Ref. NPFA 58), there may be loss of pressure,
resulting in insufficient fuel delivery (which
can result in sooting, severe delayed ignition
or other malfunctions). Any damage resulting
from an improper installation, such as this,
is not covered under the limited warranty.
Right Side
Front Corner
Of Fireplace
Framing
6-1/4”
(159 mm)
19-5/8”
(498 mm)
Step 2. ROUTING GAS LINE
2OUTEAMMGASLINEALONGTHEINSIDE
of the right side framing as shown in Figure
13'ASLINESMUSTBEROUTEDCONSTRUCTEDAND
made of materials that are in strict accordance
with local codes and regulations.
!LL APPLIANCES ARE FACTORYEQUIPPED WITH A
mEXIBLE GAS LINE CONNECTOR AND  SHUTOFF
valve. (See Step 6 on Page 22).
4HEINCOMINGGASLINESHOULDBEPIPEDINTOTHE
valve compartment and connected in one of the
two methods as shown in Figure36 o n Page 23.
Never use galvanized or plastic pipe. Refer to
Table 6 for proper sizing of the gas supply
LINEIFBLACKIRONPIPEISBEINGUSED'ASLINES
MUST BE ROUTED CONSTRUCTED AND MADE OF
materials that are in strict accordance with
LOCALCODESANDREGULATIONS7ERECOMMEND
THATAQUALIlEDINDIVIDUALSUCHASAPLUMBER
ORGASlTTERBEHIREDTOCORRECTLYSIZEANDROUTE
the gas supply line to the appliance. Installing
a gas supply line from the fuel supply to the
appliance involves numerous considerations of
materials, protection,sizing,locations, controls,
pressure, sediment, and more. Certainly no one
UNFAMILIARANDUNQUALIlEDSHOULDATTEMPTSIZING
or installing gas piping.
Figure 13
Schedule 40—Black Iron Pipe
Inside Diameter (Inches)
Schedule 40 Pipe
Length (feet) Natural Gas Propane Gas
0–10  
10–40  
40–100  
100–150  
150–200  
Table 6
C
Back wall of chase/enclosure
(including any finishing materials)
D
A
B
Model A B C D
40 in. in. 50-5/8 83-5/8 59-1/8 41-7/8
mm 1286 2124 1502 1064
45 in. in. 56-3/4 89-7/8 63-1/2 44-7/8
mm 1441 2283 1613 1140

12
./4%$)!'2!-3),,5342!4)/.3!2%./44/3#!,%
)../6!4)6%(%!24(02/$5#43s$)2%#46%.4'!3&)2%0,!#%3-ONTEBELLO$,8-ONTEBELLO$,8#$s).34!,,!4)/.).3425#4)/.3
RESTRICTOR
APPLIANCE VENT OUTLET
When vertically terminating the vent system above
the roof, install a vent restrictor in the top vent of
the fireplace outlet. Install the restrictor as shown
from inside the unit, in the inner fireplace collar
Figure 14—Vent Restrictor Installation
Step 3. INSTALL THE VENT SYSTEM
General Information
These instructions should be used as a guide-
line and do not supersede local codes in any
way. Install vent according to local codes,
these instructions, the current National Fuel
Gas Code (ANSI-Z223.1) in the USA or the
current standards of CAN/CGA-B149.1 and
-B149.2 in Canada.
Ensure clearances are in accordance with
local installation codes and the requirements
of the gas supplier.
Dégagement conforme aux codes
d'installation locaux et aux exigences du
foumisseunde gaz.
Use only approved venting components.
See Approved Vent Components on
Page 2.
These fireplaces must be vented directly
to the outside.
The vent system may not service multiple
APPLIANCESANDMUSTNEVERBECONNECTEDTOA
mUESERVINGASEPARATESOLIDFUELBURNINGAP-
PLIANCE4HEVENTPIPEISTESTEDTOBERUNINSIDE
ANENCLOSINGWALLSUCHASACHASE4HEREIS
NOREQUIREMENTFORINSPECTIONOPENINGSINTHE
ENCLOSINGWALLATANYOFTHEJOINTSINTHEVENTPIPE
Installation of Vent Restrictor
! VENT RESTRICTOR MAY BE NEEDED WITH THIS
appliance. The restrictor is installed in the
appliance top flue outlet as shown in Figure 14,
For vertical venting from 6 feet to 12 feet or
more, from the top of the fireplace to the top
of the termination, the installation of a vent
restrictor is required.
If necessary, install a vent restrictor in the
appliance flue outlet as shown in Figure 14. The
VENTRESTRICTORISHELDINPLACEBYFRICTIONONLY
NOTE: The restrictor is included within the
firebox.
SelectVentingSystem—Horizontal orVertical
7ITH THE APPLIANCE SECURED IN FRAMING DE-
TERMINEVENTROUTINGANDIDENTIFYTHEEXTERIOR
termination location. The following sections
DESCRIBEVERTICALROOFANDHORIZONTALEXTERIOR
WALLVENTAPPLICATIONS2EFERTOTHESECTION
relating to your installation. A list of approved
venting components is shown on Page 30.

./4%$)!'2!-3),,5342!4)/.3!2%./44/3#!,%
13
)../6!4)6%(%!24(02/$5#43s$)2%#46%.4'!3&)2%0,!#%3-ONTEBELLO$,8-ONTEBELLO$,8#$s).34!,,!4)/.).3425#4)/.3
Figure 15
Table 7: Vent Section Length Chart
Termination
Flashing And
Storm Collar
Firestop/Spacer
SV86/12/24/36/48
Vent Sections
40' Max
(12.2 M)
6' Min
(1.8 M)
1" (25 mm)
Minimum
Clearance to
Combustibles
VERTICAL TERMINATION SYSTEMS (ROOF)
See Figure 15 and Figures 23 through 25 on
Page 16 and their associated Vertical Vent
4ABLESWHICHILLUSTRATETHEVARIOUSVERTICALVENTING
CONlGURATIONSTHATAREPOSSIBLEFORUSEWITHTHESE
appliances. Secure Vent®pipe applications
ARE SHOWN IN THESE lGURES A Vertical Vent
4ABLESUMMARIZESEACHSYSTEMSMINIMUMAND
MAXIMUMVERTICALANDHORIZONTALLENGTHVALUES
THATCANBEUSEDTODESIGNANDINSTALLTHEVENT
components in a variety of applications.
The vertical vent system terminates through
THEROOF4HEMINIMUMVENTHEIGHTABOVETHE
ROOFANDORADJACENTWALLSISSPECIlEDIN!.3)
:LATESTEDITION)N#ANADATHECURRENT
#!.#'!"INSTALLATIONCODEBYMAJOR
BUILDING CODES !LWAYS CONSULT YOUR LOCAL
CODES FOR SPECIlC REQUIREMENTS ! GENERAL
GUIDETOFOLLOWISTHE'AS6ENT2ULEREFERTO
Figure 4 on Page 6).
Vertical (Straight) Installation
(Figure 15)
$ETERMINETHENUMBEROFSTRAIGHTVENTSECTIONS
REQUIREDMMMM
  MM   MM AND
  MM NET SECTION LENGTHS ARE
AVAILABLESEETables on this page and Page
30—Vent Sections0LANTHEVENTLENGTHSSO
THATAJOINTDOESNOTOCCURATTHEINTERSECTIONOF
CEILINGORROOFJOISTS2EFERTOTHE6ENT3ECTION
,ENGTH#HART
NOTE: Convert inches into metric equivalent
measurement, as follows:
Millimeters (mm) = Inches x 25.4
Centimeters (cm) = Inches x 2.54
Meters (M) = Inches x .0254
Model Effective Length
SV8L6 4-1/2"
SV8L12 10-1/2"
SV8L24 22-1/2"
SV8L36 34-1/2"
SV8L48 46-1/2"
Table 8—Effective Vent Length
lanimoN
htgneLnoitceS )sehcni( 621426
38
4T
O
T
A
L
Q
T
Y
noitceSteN )sehcni(htgneL 2/1-42/1-012/1-2
22
/1-4
32
/1-64
tneVfothgie
Hs
noitceStneVforebmuN
sehcnitf
5.4573.0100001
957.0200002
5.01578.0010001
5152.1110002
5.91526.1210003
1257.1020002
5.22578.1001001
5.52521.2120003
5.13526.2030003
5.43578.2000101
5.73521.3111003
5.34526.3021003
5457.3002002
5.64578.3000011
5.94521.4102003
1552.4100012
5.55526.4012003
7557.4001102
6652.5022004
5.76526.5003003
9657.5000202
2761030
04
5.37521.6100203
5.97526.6010203
1857.6000112
095.7021014
5.19526.7002013
3957.7000022
6981012
04
5.79521.8100023
2015.8200024
5.301526.8000303
80191003
04
4115.9020024
71157.9105006
5.811578.9110305
6215.01001304
5.031578.01101305
53152.11006006
8315.11000404
5.931526.11000033
5.241578.11100405
noitceSlanimoN )sehcni(htgneL 621426384T
O
T
A
L
Q
T
Y
noitceSteN )sehcni(htgneL 2/1-42/1-012/1-222/1-432/1-64
tneVfothgieHsnoitceStneVforebmuN
sehcnitf
44121100034
0515.21010034
5.451578.21110035
5.061573.31020035
5.271573.41000505
77157.41100506
38152.51010506
6815.51000044
5.091578.51100045
5.691573.61010045
5.502521.71011507
70252.71000606
5.112526.71100607
5.712521.81010607
5.922521.91001607
5.232573.91000055
73257.91100056
5.142521.02000707
6425.02100708
25212010708
46222001708
67232000808
97252.32000066
5.082573.32100809
5.382526.32100067
5.982521.42010067
5.103521.52001067
5.013578.52000909
5135.621009001
5.523521.72000077
0335.72100078
63382010078
54357.82000 01001
5.943521.92100 01011
27313000088
5.673573.13100089
5.973526.13000 11011
5.814578.43000099
32452.531000901
56457.8300000101

14
./4%$)!'2!-3),,5342!4)/.3!2%./44/3#!,%
)../6!4)6%(%!24(02/$5#43s$)2%#46%.4'!3&)2%0,!#%3-ONTEBELLO$,8-ONTEBELLO$,8#$s).34!,,!4)/.).3425#4)/.3
Figure 16
Vertical (Offset) Installation
Analyze the vent routing and determine the
QUANTITIESOFVENTSECTIONSANDNUMBEROFELBOWS
REQUIRED2EFERTOVertical Vent Figures and
Tables on Page 16 to select the type of vertical
INSTALLATIONDESIRED6ENTSECTIONSAREAVAILABLE
INNETLENGTHSOFMM
MMMMMMAND
MM2EFERTOTHEVent Section
Length Chart on Page 13 for an aid in select-
INGLENGTHCOMBINATIONS%LBOWSAREAVAILABLE
INANDCONlGURATIONS2EFERTOFigure
20 on Page 15 FORTHE36%AND36%
ELBOWDIMENSIONALSPECIlCATIONS
7HERE REQUIRED A telescopic vent section
(SV8LA)MAYBEUSEDTOPROVIDETHEINSTALLER
WITHANOPTIONININSTALLINGINTIGHTANDCONlNED
SPACESORWHERETHEVENTRUNMADEUPOFlXED
LENGTHPIECESDEVELOPSAJOINTINAUNDESIRABLE
LOCATIONORWILLNOTBUILDUPTOTHEREQUIRED
LENGTH4HE36,!4ELESCOPIC6ENT3ECTIONHAS
ANEFFECTIVELENGTHOFFROMMMTO
MM4HE36,!ISlTTEDWITHA
DIMPLEDENDIDENTICALTOANORMALVENTSECTION
COMPONENTANDAPLAINENDWITHPILOTHOLES
3LIPTHEDIMPLEDENDOVERTHELOCKINGCHANNEL
END OF A STANDARD 36 VENT COMPONENT THE
REQUIREDDISTANCEANDSECUREWITHTHREESCREWS
Maintain a minimum 1" (25 mm) clearance
to combustible materials for all vertical ele-
ments.Clearancesforallhorizontalelements
are 3" (76 mm) on top, 1" (25 mm) on sides
and 1" (25 mm) on the bottom.
A. Frame ceiling opening—5SEAPLUMBLINE
FROMTHECEILINGABOVETHEAPPLIANCETOLOCATE
center of the vertical run. Cut and/or frame an
OPENINGXMMXMMINSIDE
DIMENSIONSABOUTTHISCENTERMARK(Figure 16).
Figure 17
Align the dimple (four places) of the
upper vent section with the opening
of the locking incline channel on the
lower vent section or appliance col-
lar. Twist vent component clockwise
to engage and seal until arrow and
dimple align.
Dimple
Locking Incline
Channel
Connected Vent
Sections Arrow
Arrow
Appliance Collar or
Vent Section
Blocking
Support Straps
(Plumber's tape)
8 feet (2.4 m)
Maximum
1" (25.4 mm)
minimum
clearance to
combustibles
Roof
Framing
Ceiling
Framing Plumb
Bob
Minimum
13”
(330 mm)
Minimum
13”
(330 mm)
Figure 18
Push the vent component against the previous
section until it fully engages, then twist the
COMPONENTCLOCKWISERUNNINGTHEDIMPLESDOWN
and along the incline channels until they seat at
the end of the channels. This seating position
is indicated by the alignment of the arrow and
dimple as shown in Figure 17.
D. Install firestop/spacer at ceiling—7HEN
USING3ECURE6ENTUSE36"&lRESTOPSPACER
ATCEILINGJOISTS)FTHEREISLIVINGSPACEABOVE
THECEILINGLEVELTHElRESTOPSPACERMUSTBE
INSTALLEDONTHEBOTTOMSIDEOFTHECEILING)FATTIC
SPACEISABOVETHECEILINGTHElRESTOPSPACER
MUSTBEINSTALLEDONTHETOPSIDEOFTHEJOIST
Route the vent sections through the framed
OPENINGAND SECURETHElRESTOPSPACER WITH
DNAILSOROTHERAPPROPRIATEFASTENERSATEACH
corner. Remember to maintain 1" (25 mm)
clearancetocombustibles,framingmembers,
and attic or ceiling insulation when running
vertical chimney sections. Attic insulation
shield (H3908) may be used to obtain the
required clearances indicated here. See
installation accessories on Page 30. The gap
BETWEENTHEVENTPIPEANDAVERTICALlRESTOP
CANBESEALEDWITHNONCOMBUSTIBLECAULKING
E. Support the vertical vent run sections—
NOTE:Properventingsupportisveryimportant.
The weight of the vent must not be supported
by the fireplace in any degree.
Support the vertical portion of the venting
SYSTEMEVERYFEETMABOVETHElREPLACE
vent outlet.
B.Attach vent components toappliance—Se-
cureVent®36DIRECTVENTSYSTEMCOMPONENTS
are unitized concentric pipe components
FEATURINGPOSITIVETWISTLOCKCONNECTIONSsee
Figure 17).
All of the appliances covered in this document
ARElTTEDWITHCOLLARSHAVINGLOCKINGINCLINED
channels. The dimpled end of the vent compo-
NENTSlTOVERTHEAPPLIANCECOLLARTOCREATETHE
POSITIVETWISTLOCKCONNECTION
To attach a vent component to the appliance
collar, align the dimpled end over the collar,
ADJUSTING THE RADIAL ALIGNMENT UNTIL THE FOUR
LOCKINGDIMPLESARE ALIGNEDWITHTHEINLETOF
THEFOURINCLINEDCHANNELSONTHECOLLARrefer
to Figure17). Push the vent component against
the collar until it fully engages, then twist the
COMPONENT CLOCKWISE RUNNING THE DIMPLES
down and along the incline channels until they
seat at the end of the channels. The unitized
design of the Secure Vent components will
ENGAGEANDSEALBOTHTHEINNERANDOUTERPIPE
without theneedforsealant orscrews.If desired
AXSCREWMAYBEUSEDATTHEJOINTBUT
ITISNOTREQUIREDASTHEPIPEWILLSECURELYLOCK
when twisted.
C. Attach vent components to each other—
/THER VENT SECTIONS MAY BE ADDED TO THE
previously installed section in accordance with
THEREQUIREMENTSOFTHEVERTICALVENT lGURES
AND TABLES 4O ADD ANOTHER VENT COMPONENT
to a length of vent run, align the dimpled end
over the inclined channel end of the previously
INSTALLEDSECTIONADJUSTINGTHERADIALALIGNMENT
UNTILTHEFOURLOCKINGDIMPLESAREALIGNEDWITH
the inlets of the four incline channels of the
previous section.

./4%$)!'2!-3),,5342!4)/.3!2%./44/3#!,%
15
)../6!4)6%(%!24(02/$5#43s$)2%#46%.4'!3&)2%0,!#%3-ONTEBELLO$,8-ONTEBELLO$,8#$s).34!,,!4)/.).3425#4)/.3
Framing Dimensions for Roof
Inches (millimeters)
Pitch C D
0/12 13"
(330 mm)
13"
(330 mm)
6/12 13"
(330 mm)
15-1/2"
(394 mm)
12/12 13"
(330 mm)
20-1/2"
(541 mm)
C
D
Figure 20—Roof Framing
Figure 22
G.Continueinstallationofhorizontal/inclined
sections—Continue with the installation of the
straight vent sections in horizontal/inclined run
ASDESCRIBEDINStep C. Install support straps
EVERYFTMMALONGHORIZONTALINCLINED
VENTRUNSUSINGCONVENTIONALPLUMBERSTAPE
See Page 17, Figure 26. It is very important
thatthehorizontal/inclinedRUNBEMAINTAINEDIN
ASTRAIGHTNODIPSSLIGHTLYELEVATEDPLANE4HE
RECOMMENDEDINCLINEISAPPROXIMATELYPER
FOOTMMPERMETERHORIZONTALINADIRECTION
AWAYFROMTHElREPLACE4HERISEPERFOOTRUN
RATIOSTHATARESMALLERAREACCEPTABLEALLTHEWAY
DOWNTOATORNEARLEVEL5SEACARPENTERSLEVEL
TOMEASUREFROMACONSTANTSURFACEANDADJUST
the support straps as necessary.
It is important to maintain the required clear-
ances to combustibles: 1" (25 mm) at all sides
for all vertical runs; and 3" (76 mm) at the
top, 1" (25 mm) at sides, and 1" (25 mm) at
the bottom for all horizontal/inclined runs.
H. Frame roof opening—Identify location for
vent at the roof. Cut and/or frame opening per
2OOF&RAMING#HART(Figure 20).
/NEMETHODOFSUPPORTISBYUTILIZINGlELDPRO-
VIDEDSUPPORTSTRAPSCONVENTIONALPLUMBERgS
TAPE3ECURETHEPLUMBERgSTAPETOTHEFRAMING
MEMBERSWITHNAILSORSCREWS Strap the tape
around the vent, securing the ends of the tape
to the framing. If desired, sheet metal screws
XLENGTHMAY BE USED TOSECURE THE
support straps to the vent pipe. See Figure 18
on Page 14.
F.Changeventdirectiontohorizontal/inclined
run—At transition from or to a horizontal/
INCLINEDRUNINSTALLTHE36%AND36%
ELBOWSINTHESAMEMANNERASTHESTRAIGHTVENT
SECTIONS4HEELBOWSFEATUREATWISTSECTIONTO
ALLOWTHEMTOBEROUTEDABOUTTHECENTERAXIS
of their initial collar section to align with the
REQUIREDDIRECTIONOFTHENEXTVENTRUNELEMENT
Twist elbow sections in a clockwise direction
onlyso as toavoidthe possibility ofunlocking
anyof thepreviouslyconnectedventsections.
See Figure 17 on Page 14 and Figure 19.
Figure 19
)FTHEVENTSYSTEMEXTENDSMORETHANFEET
MABOVETHEROOFmASHINGSTABILIZERSMAYBE
NECESSARY!DDITIONALSCREWSMAYBEUSEDAT
SECTIONJOINTSFORADDEDSTABILITY'UIDEWIRES
MAYBEATTACHEDTOTHEJOINTFORADDITIONALSUP-
PORTONMULTIPLEJOINTCONlGURATIONS
Swivel Joint
(360° swivel)
SV8E45
(45° Elbow)
Swivel Joint
(360° swivel)
SV8E90
(90° Elbow)
6"
(153mm)
10"
(254mm)
K. Install the vertical termination—4HElNAL
stepinvolves installation ofthe VerticalTermina-
TION%XTENDTHEVENTSECTIONSTOTHEHEIGHTAS
SHOWNINTHE6ERTICALVENTTERMINATIONSECTION
on Page 64HE366426ERTICAL4ERMINATION
Figure 22)CANBEINSTALLEDINTHEEXACTSAME
fashionas any otherSecureVent®section.Align
the termination over the end of the previously
INSTALLEDSECTIONADJUSTINGTHERADIALALIGNMENT
UNTILTHEFOURLOCKINGDIMPLESOFTHETERMINATION
are aligned with the inlets of the four incline
channels of the last vent section. Push the ter-
mination down until it fully engages, then twist
THETERMINATIONCLOCKWISERUNNINGTHEDIMPLES
down and along the incline channels until they
seat at the end of the channels.
I. Install the roof flashing—%XTENDTHEVENT
sections through the roof structure. Install the
roof flashing over the vent section and posi-
tion such that the vent column rises vertically
USECARPENTERSLEVEL(Figure 21). Nail along
PERIMETERTOSECUREmASHINGORADJUSTROOlNGTO
overlap the flashing edges at top and sides only
ANDTRIMWHERENECESSARY3EALTHETOPANDBOTH
SIDESOFTHEmASHINGWITHWATERPROOFCAULKING
J. Install the storm collar—Install the storm
collar, supplied with the flashing, over the vent/
mASHINGJOINTSEEFigure 21). ,OOSENTHESTORM
collar screw. Slide collar down until it meets
THETOPOFTHEmASHING4IGHTENTHEADJUSTING
SCREW !PPLY NONCOMBUSTIBLE CAULKING OR
MASTICAROUNDTHECIRCUMFERENCEOFTHEJOINT
to provide a water tight seal.
Figure 21
Storm
Collar
Storm
Collar
Flashing

16
./4%$)!'2!-3),,5342!4)/.3!2%./44/3#!,%
)../6!4)6%(%!24(02/$5#43s$)2%#46%.4'!3&)2%0,!#%3-ONTEBELLO$,8-ONTEBELLO$,8#$s).34!,,!4)/.).3425#4)/.3
Figure 25—Top Vent—Three Elbows
V
H1
H
V1
Ceiling
Firestop/Spacer
(SV8BF) Wall
Firestop/Spacer
(SV8HF)
Table B
H + H1Maximum V Minimum
feet (meter) feet (meter)
10 (3.1) 2.5 (0.762)
15 (4.65) 3.5 (1.06)
20 (6.2) 4.5 (1.37)
H + H1= 20 feet (6.2 m) Max.
V + V1+ H + H1= 40 ft. (12.4 m) Max.
V + V1 = 11 feet (3.3 meters) Min. for 40 in. units
V + V1 = 10.5 feet (3.2 meters) Min. for 45 in. units
Figure 24—Top Vent—Two 90 Degree Elbows (Corner Framing with Square
Termination (SV8HTS))
H
V
V1
Ceiling
Firestop/Spacer
(SV8BF)
Table A
H Maximum V Minimum
feet (meter) feet (meter)
10 (3.1) 2.5 (0.762)
15 (4.65) 3.5 (1.07)
20 (6.2) 4.5 (1.37)
V + V1+ H = 40 feet (12.4 meters) Max.
V + V1= 11 feet (3.3 meters) Minimum for 40 in. units
V + V1= 10.5 feet (3.2 meters) Minimum for 45 in. units
40 feet (12.2 meters)
Maximum
6 feet (1.8 meters)
Minimum
Ceiling
Firestop/Spacer
(SV8BF)
Figure 23—Top Vent—Straight
VERTICAL VENT FIGURES/TABLES
NOTES:
s 3ECURE6ENT®(rigid vent pipe) is shown in
the figures.
s )T IS VERY IMPORTANT THAT THE HORIZONTAL
inclined run be maintained in a straight
(no dips), slightly elevated plane. The
recommended incline is approximately
1/4" per foot (20 mm per meter) horizontal,
in a direction away from the fireplace. The
rise per foot run ratios that are smaller are
acceptable all the way down to at or near
level.
s SV8BF (Secure Vent) firestop/spacer must
be used anytime vent pipe passes through a
combustible floor or ceiling. SV8HF (Secure
Vent) firestop/spacer must be used anytime
ventpipe passes througha combustible wall.
s Two 45º elbows may be used in place of one
90º elbow. The same rise to run ratios, as
shown in the venting figures for 90º elbows,
must be followed if 45º elbows are used.
A Vent Restrictor, as shown in Figure 15 on Page
12, may need to be used in this application
Example: If 20 feet of (H) horizontal
vent run is needed, then 4-1/2 feet
minimum of (V) vertical vent will be
required.
A Vent Restrictor, as shown in
Figure 14 on Page 12, must be used
in this application.
Example: If 20 feet of (H+ H1) horizon-
tal vent run is needed, then 4-1/2 feet
minimum of (V) vertical vent will be
required.
A Vent Restrictor, as
shown in
Figure 14 on Page 12,
must be used in this
application.

./4%$)!'2!-3),,5342!4)/.3!2%./44/3#!,%
17
)../6!4)6%(%!24(02/$5#43s$)2%#46%.4'!3&)2%0,!#%3-ONTEBELLO$,8-ONTEBELLO$,8#$s).34!,,!4)/.).3425#4)/.3
Figure 26—Typical Horizontal Vent Installation
Support the vertical portion of the venting system
every 8 feet (2.4m) above the fireplace vent outlet.
Vertical
Rise
SV8E90
Elbow
Horizontal / Inclined Run SV8HTS
Termination
Shown
Firestop/Spacer
SV8 L6/12/24/36/48
Vent Sections
Support Bracket Spacing
Every 3 ft (914 mm)
SV8HTS
Termination
Shown
Support
Brackets
Building
Support
Framing
Ceiling
Fireplace
Exterior
Wall
Exterior
Wall
2-1/2 Foot Vertical
Vent (min.)
Push the vent component against the collar
until it fully engages, then twist the component
CLOCKWISERUNNINGTHEDIMPLESDOWNANDALONG
the incline channels until they seat at the end of
the channels. The unitized design of the Secure
VentCOMPONENTSWILLENGAGEANDSEALBOTHTHE
inner and outer pipe elements with the same
procedure. Sealant and securing screws are
NOTREQUIRED
E. Attach vent components to each other—
/THERVENTSECTIONSMAYBEADDEDTOTHEPREVI-
ously installed section in accordance with the
REQUIREMENTSOFTHEVENTTABLES4OADDANOTHER
vent component to a length of vent run, align
the dimpled end of the component over the
inclined channel end of the previously installed
SECTIONADJUSTINGTHERADIALALIGNMENTUNTILTHE
FOURLOCKINGDIMPLESAREALIGNEDWITHTHEINLETS
of the four incline channels of the previous
section. Push the vent component against the
previous section until it fully engages, then
TWIST THE COMPONENT CLOCKWISE RUNNING THE
dimples down and along the incline channels
until they seat at the end of the channels. This
seatingposition is indicated bythe alignment
of the arrow and dimple as shown in Figure
17 on Page 14.
F. Install firestop/spacer at ceiling—7HEN
using Secure VentUSE36"&lRESTOPSPACER
ATCEILINGJOISTS)FTHEREISLIVINGSPACEABOVE
THECEILINGLEVELTHElRESTOPSPACERMUSTBE
INSTALLEDONTHEBOTTOMSIDEOFTHECEILING)F
ATTICSPACEISABOVETHECEILINGTHElRESTOP
SPACER MUST BE INSTALLED ON THE TOP SIDE OF
THEJOIST2OUTETHEVENTSECTIONSTHROUGHTHE
FRAMEDOPENINGANDSECURETHElRESTOPSPACER
WITHDNAILSOROTHERAPPROPRIATEFASTENERSAT
each corner.
Remember to maintain 1" (25 mm) clearance
to combustibles, framing members, and attic
or ceiling insulation when running vertical
chimney sections.
G. Support the vertical run sections—See
Step E on Page 14.
H.Changeventdirection—Attransitionfromor
TOAHORIZONTALINCLINEDRUNINSTALLTHE36%
AND36%ELBOWSINTHESAMEMANNERASTHE
STRAIGHTVENTSECTIONS4HEELBOWSFEATUREATWIST
SECTIONTOALLOWTHEMTOBEROUTEDABOUTTHE
CENTERAXISOFTHEIRINITIALCOLLARSECTIONTOALIGN
WITHTHEREQUIREDDIRECTIONOFTHENEXTVENTRUN
element. Twist elbow sections in a clockwise
direction only so as to avoid the possibility
of unlocking any of the previously connected
vent sections (see Figure 17 on Page 14).
I. Continue installation of horizontal/inclined
sections—Continue with the installation of the
straight vent sections in horizontal/inclined
RUNASDESCRIBEDINStep E on Page 14. Install
SUPPORTSTRAPSEVERYFEETMMALONG
horizontal/inclined ventrunsusingconventional
PLUMBERSTAPE
See Figure 26,It is very important that the
horizontal/inclined run be maintained in a
straight (nodips),slightlyelevatedplane.The
recommended incline is approximately 1/4"
per foot (20 mm per meter) horizontal, in a
directionaway from thefireplace. The riseper
foot run ratios that are smaller are acceptable
all the way down to at or near level.
It is important to maintain the required clear-
ances to combustibles: 1" (25 mm) at all sides
for all vertical runs; and 3" (76 mm) at the
top, 1" (25 mm) at sides, and 1" (25 mm) at
the bottom for all horizontal/inclined runs.
5SE A CARPENTERS LEVEL TO MEASURE FROM A
CONSTANTSURFACEANDADJUSTTHESUPPORTSTRAPS
as necessary.
HORIZONTAL(OUTSIDEWALL)TERMINATION
SYSTEM
See Figures 26–31 and their associated
(ORIZONTAL6ENTTABLESTHATILLUSTRATETHEVARI-
OUSHORIZONTALVENTINGCONlGURATIONSTHATARE
POSSIBLEFORUSEWITHTHESEAPPLIANCESSecure
Vent®pipe applications are shown in these
&IGURES!(ORIZONTAL6ENTTABLESUMMARIZES
EACHSYSTEMSMINIMUMANDMAXIMUMVERTICAL
ANDHORIZONTALLENGTHVALUESTHATCANBEUSED
to design and install the vent components in a
variety of applications.
The horizontal vent system terminates through
ANOUTSIDEWALL"UILDING#ODESLIMITORPROHIBIT
TERMINATINGINSPECIlCAREAS2EFERTOFigure 6
on Page 7 for location guidelines.
Secure Vent36DIRECTVENTSYSTEMCOMPO-
nents are unitized concentric pipe components
FEATURINGPOSITIVETWISTLOCKCONNECTIONrefer
to Figure 17 on Page 14). All of the appli-
ANCESCOVEREDINTHISDOCUMENTARElTTEDWITH
COLLARSHAVINGLOCKINGINCLINEDCHANNELS4HE
DIMPLEDENDOFTHEVENTCOMPONENTSlTOVER
the appliance collar to create the positive twist
LOCKCONNECTION
A. Plan the vent run.
Analyze the vent routing and determine the
TYPES AND QUANTITIES OF SECTIONS REQUIRED
MMMM
MMMMANDMMNET
SECTIONLENGTHSAREAVAILABLE)TISRECOMMENDED
THATYOUPLANTHEVENTINGSOTHATAJOINTDOESNOT
OCCURINTHECEILINGORROOFJOISTS!LLOWFORELBOWS
as indicated in Figure 20 on Page 15.
Maintain a minimum 1" (25 mm) clearance
to combustibles on the vertical sections.
Clearances for the horizontal runs are; 3"
(76 mm) on top, 1" (25 mm) on sides, and
1" (25 mm) at the bottom.
B. Frame exterior wall opening—,OCATETHE
CENTEROFTHEVENTOUTLETONTHEEXTERIORWALL
according to the dimensions shown in Figure
11 on Page 10. Cut and/or frame an opening,
XMMXMMINSIDEDIMEN-
SIONSWITHABOVECENTERANDBELOWCENTER
C. Frame ceiling opening—If the vertical
ROUTEISTOPENETRATEACEILINGUSEPLUMBLINE
TOLOCATETHECENTERABOVETHEAPPLIANCE#UT
ANDORFRAMEANOPENINGXMMX
MMINSIDEDIMENSIONSABOUTTHISCENTER
REFERTOFigure 17 on Page 14).
D. Attach vent components to appliance—To
attach a vent component to the appliance collar,
ALIGNTHEDIMPLEDENDOVERTHECOLLARADJUST-
INGTHERADIALALIGNMENTUNTILTHEFOURLOCKING
dimples are aligned with the inlets of the four
INCLINECHANNELSONTHECOLLARrefer to Figure
16 on Page 14).

18
)../6!4)6%(%!24(02/$5#43s$)2%#46%.4'!3&)2%0,!#%3-ONTEBELLO$,8-ONTEBELLO$,8#$s).34!,,!4)/.).3425#4)/.3
./4%$)!'2!-3),,5342!4)/.3!2%./44/3#!,%
Horizontal terminations have been designed to perform in a wide range of weather condi-
tions. Our terminations meet or exceed industry standards.
When selecting the locations of your horizontal terminations, do not place the termination
where water from eaves and adjoining rooflines may create a heavy flow of cascading water
onto the termination cap. If the cap must be placed where the possibility of cascading water
exists, it is the responsibility of the builder to direct the water away from the termination cap
by using gutters or other means.
Take care to carefully follow the installation instructions for the termination, including the
use of silicone caulking where required.
Figure 27—Installing the Square Horizontal Termination (SV8HTS)
SV8HTS
Termination
Shown.
13 in.
(330mm)
8-1/2 in.
(216 mm)
(165 mm)
15 in.
(381 mm)
NOTE: Centerline of Vent Piping is NOT
the Same as the Centerline of the
Framed Opening.
6–48 in. Vent Section,
Telescopic vent section. Base of Appliance
3 in.
(76 mm)
Adaptor
SV8RCH 1 in.
(25 mm)
1 in.
(25 mm)
6-1/2 in.
See other side for minimum
distance to base of appliance.
To help minimize water infiltration
install the Firestop/Spacer (SV4.5HF)
on the exterior side of the wall.
Figure 28—Wall Thickness and Horizontal Termination Requirements
For wall thicknesses greater than
8-1/2", see Table 9

Siding
Stucco 1-1/4” Maximum Recess of
Square Termination into
Exterior Finishing Material
Exterior Surface of
Framing
5” to 8-1/2”
(127 to 216 mm)
Exterior Surface of Siding
Minimum wall thickness
5” (127 mm)
Interior Surface of
Finished Wall
Maximum wall thickness
8-1/2” (216 mm)
SV8HTS
Square Termination
shown
Maximum Extent of Vent
Run Sections to Exterior
Surface of Framing
Last Vent Section. Use
Telescopic Vent Section
(SV8LA), If Necessary
Adaptor
SV8RCH
SV8HTS
Square Termination
Shown
Venting Connection and Exterior Wall Recessing
of the Horizontal Square Termination (SV8HTS).
See Figure 12 on Page 10 for Minimum
Distance to Base of Appliance
To help minimize water infiltration it
is recommended that the Firestop/
Spacer (SV4.5HF) be installed on the
exterior side of the wall.
J. Assemble vent run to exterior wall—If not
previously measured, locate the center of the
VENTATTHEEXTERIORWALL0REPAREANOPENINGAS
DESCRIBEDINStep B on Page 17!SSEMBLETHE
vent system to point where the terminus of the
LASTSECTIONISWITHINMMTO
MMINBOARDOFTHEEXTERIORSURFACETOWHICH
THE36(43TERMINATIONISTOBEATTACHEDSEE
Figure 29 and Table 9 on Page 19.
If the terminus of the last section is not within
this distance, use the telescopic vent section
SV8LA, ASTHELASTVENTSECTION&ORWALLTHICK-
nesses greater than that shown in Figure 28,
refer to Table 9 on Page 194HISTABLELISTS
THEADDITIONALVENTINGCOMPONENTSNEEDEDIN
ADDITIONTOTHETERMINATIONANDADAPTORFORA
PARTICULARRANGEOFWALLTHICKNESSES
K. Attach termination adaptor—Attach the
ADAPTORADAPTOR362#(PROVIDEDWITHTHE
TERMINATIONTOTHEVENTSECTIONORTELESCOPING
VENTSECTIONORELBOWASSHOWNINFigure 27
in the same manner as any SV vent component
REFERTOStep E on Page 17).
L. Install Firestop/Spacer at exterior wall
—7HENUSINGTHESQUARE termination, install
36(&&IRESTOP3PACEROVERTHEOPENINGATTHE
EXTERIORSIDEOFTHEFRAMINGLONGSIDEUPWITH
THESPACERCLEARANCEATTHETOPASSHOWNIN
Figure 27, and nail into place.
4HE&IRESTOP3PACERMAYALSOBEINSTALLEDOVER
THEOPENINGATTHEINTERIORSIDEOFTHEFRAMING
M.Install thesquaretermination(SV8HTS)—
&OR THE LAST STEP FROM OUTSIDE THE EXTERIOR
wall, slide the collars of the termination onto
THEADAPTORTHEOUTEROVERTHEOUTERANDTHE
INNER INSIDE THE INNER UNTIL THE TERMINATION
SEATSAGAINSTTHEEXTERIORWALLSURFACETOWHICH
ITWILLBEATTACHED/RIENTTHEHOUSINGOFTHE
termination with the arrow pointed upwards.
3ECURETHETERMINATIONTOTHEEXTERIORWALLThe
horizontal termination must not be recessed
into the exterior wall or siding by more than
the 1-1/4" (32 mm) as shown in Figure 28.
IMPORTANT: The vent termination is hot
whileinoperationandforaperiodoftime
following the use of the fireplace. Young
children should be carefully supervised
when they are in the same area as a hot
termination.

./4%$)!'2!-3),,5342!4)/.3!2%./44/3#!,%
19
)../6!4)6%(%!24(02/$5#43s$)2%#46%.4'!3&)2%0,!#%3-ONTEBELLO$,8-ONTEBELLO$,8#$s).34!,,!4)/.).3425#4)/.3
Venting Components Required for Various Exterior
Wall Thicknesses, when using Square Termination Kit
(SV8HTS—see Figure 28)
Vent Components Required Exterior Wall Thickness—inches (mm)
4ERMINATION+IT/NLY TOTO
4ERMINATION+ITAND6ENT
3ECTION36, TOTO
4ERMINATION +IT AND 4ELE-
SCOPIC3ECTION36,! TOTO
4ERMINATION +IT AND 4ELE-
SCOPIC3ECTION36,!AND
VENTSECTION36,
TOTO
Table 9
See Table 9 as an aid in venting component selection for a particular
range of exterior wall thicknesses.
Example: If 20 feet of (H)
horizontal vent run is needed,
then 10 feet minimum of (V)
vertical vent will be required.
H
V
Wall Firestop/Spacer
(SV8HF)
Ceiling
Firestop/Spacer
(SV8BF)
Table C
H Maximum V Minimum
feet (meter) feet (meter)
3.5 (1.07) 2.5 (0.762)
6.5 (1.98) 3.5 (1.07)
8.5 (2.6) 4.5 (1.37)
10.5 (3.2) 5.5 (1.68)
12.5 (3.8) 6.5 (1.98)
14.5 (4.4) 7.5 (2.3)
16.5 (5.0) 8.5 (2.6)
18.5 (5.6) 9.5 (2.9)
20 (6.0) 10 (3.0)
V + H = 40 feet (12.4 m) Max.
H = 20 ft. (6.2 m) Max.
HORIZONTAL VENT FIGURES/TABLES
NOTES:
s 3ECURE6ENT®components (rigid vent pipe and terminal) are shown
in the figures.
s Two 45º elbows may be used in place of one 90º elbow. The same rise
to run ratios, as shown in the venting figures for 90º elbows, must be
followed if 45º elbows are used.
s SV8BF (Secure Vent) firestop/spacer must be used anytime vent pipe
passes through a combustible floor or ceiling. SV8HF (Secure Vent)
firestop/spacer must be used anytime vent pipe passes through a
combustible wall.
s )TISVERYIMPORTANTTHATTHEHORIZONTALINCLINEDRUNBEMAINTAINED
in a straight (no dips), slightly elevated plane. The recommended
incline is approximately 1/4" per foot (20 mm per meter) horizontal,
in a direction away from the fireplace. The rise per foot run ratios
that are smaller are acceptable all the way down to at or near level.
Figure 29—Top Vent—One 90 Degree Elbow (Elbow Connection Not Directly at Appliance)
See Table 9 as an aid in venting component selection for
APARTICULARRANGEOFEXTERIORWALLTHICKNESSES
Square termination (SV8HTS) shown.

20
./4%$)!'2!-3),,5342!4)/.3!2%./44/3#!,%
)../6!4)6%(%!24(02/$5#43s$)2%#46%.4'!3&)2%0,!#%3-ONTEBELLO$,8-ONTEBELLO$,8#$s).34!,,!4)/.).3425#4)/.3
Figure 31—Top Vent—Three 90 Degree Elbows
See Table 9 on Page 19ASANAIDINVENTINGCOMPONENTSELECTIONFORAPARTICULARRANGEOFEXTERIORWALLTHICKNESSES
V
H
H1
Wall Firestop/Spacer
(SV8HF)
Wall Firestop/Spacer
(SV8HF)
Ceiling
Firestop/Spacer
(SV8BF)
V
H
H1
V1
Wall Firestop/Spacer
(SV8HF)
Ceiling
Firestop/Spacer
(SV8BF)
Wall
Firestop/Spacer
(SV8HF)
Ceiling
Firestop/Spacer
(SV8BF)
Table D
H + H1 Maximum V Minimum
feet (meter) feet (meter)
3.5 (1.07) 2.5 (0.762)
6.5 (1.98) 3.5 (1.07)
8.5 (2.6) 4.5 (1.37)
10.5 (3.2) 5.5 (1.68)
12.5 (3.8) 6.5 (1.98)
14.5 (4.4) 7.5 (2.3)
16.5 (5.0) 8.5 (2.6)
18.5 (5.6) 9.5 (2.9)
20 (6.0) 10 (3.0)
V + H + H1= 40 feet (12.4 m) Max.
H + H1= 20 ft. (6.2 m) Max.
Table E
H + H1= 20 feet (6.2 m) Max.
V + V1+ H + H1= 40 ft. (12.4 m) Max.
V = 2.5 feet Min. (0.762 m)
V + V1 = 11 feet (3.35 m) Min. for 40 in. units
V + V1 = 10.5 feet (3.2 m) Min. for 45 in. units
HORIZONTAL VENT FIGURES/TABLES
(continued)
Figure 30—Top Vent—Two 90 Degree Elbows
See Table 9 on Page 19 as an aid in venting component selection for a particular range of
EXTERIORWALLTHICKNESSES
