Astro Pneumatic Tool 30570 User manual

30570 20V 7" BRUSHLESS VARIABLE SPEED
ROTARY POLISHER W/ 2 BATTERIES
Product Type:Model:
Page 1
Study, understand and follow all instructions provided
with this product. Read these instructions carefully
before installing, operating, servicing or repairing this
tool. Keep these instructions in a safe accessible place.
INTENDED USE OF THE TOOL
The 30570 7" Cordless Polisher is designed to be used
by qualified professionals to detail, wax, polish and buff
painted panels using appropriate compounds and speeds
so as to not over-heat or damage the paint. Do not use
this tool outside of the designed intent. Never modify the
tool for any other purpose or use.
Caution: To help prevent personal injury
• Normal use of this product is likely to expose the
user to dust and/or microscopic particles
containing chemicals known to the State of
California to cause cancer, birth defects or other
reproductive harm. Always wear appropriate
safety equipment and clothing when using this
product. Study, understand and follow all
instructions provided with this product. Failure to
read and follow all warnings and operating
instructions may result in damages and serious
injury or death.
• Always wear ANSI approved goggles when using
this product. (Users and By standers).
• Never use this tool for any application other than
for which it was designed.
• Only use accessories designed for this tool.
• Never alter or modify this tool in any way.
• Improper operation and/or maintenance of the
tool, modification of the tool, or use of the tool
with accessories not designed for it could result
in serious injury or death.
• Always select the correct accessories of the
correct size and design for the job that you are
attempting to perform.
• Always work in a clean, safe, well-lit, organized
and adequately equipped area.
• Do not begin repairs without assurance that
vehicle is in secure position, and will not move
during repair.
WARNING
WARNING
www.astrotools.com
1 YEAR LIMITED WARRANTY
• Astro Pneumatic Tool Co. warrants our products to the
original user against defective material or workman-
ship for a period of 1 year (except where noted on our
price schedule) from the date of 1st use. Astro
reserves the right to determine whether the product
failed because of defective material, workmanship or
other causes and to charge back for missing parts.
Astro Pneumatic Tool Co., at its discretion, will repair
products covered under this warranty free of charge.
The distributor should direct the original user to return
the product (with the exceptions listed below) with the
distributor’s name, address, adequate proof of date of
purchase or a copy of warranty card, and a short note
explaining the problem. Failures caused by
accident, alteration, or misuse are not covered by
this warranty.
• Astro Pneumatic Tool Co. or its authorized service
representatives must perform all warranty repairs. Any
repair to the product by unauthorized service
representatives voids this warranty. The rights under
this warranty are limited to the original user and may
not be transferred to subsequent owners.
• This warranty is in lieu of all other warranties,
expressed or implied, including warranties of
merchantability and fitness for a particular purpose.
Some states do not allow the exclusion of limitations
of incidental or consequential damages so the above
limitations may not apply to you.
PLEASE DO NOT RETURN ANY PRODUCT WITHOUT CALLING
1-800-221-9705 FOR INSTRUCTIONS
PRODUCT INFORMATION
BEFORE USE
DO NOT DISCARD – GIVE TO USER
• Brushless 20V motor for efficiency and power with
6 adjustable soft-start speed settings from 400-2,200RPM
• Perfectly balanced at the hand and weighs 1lb less with
battery attached than industry leading 7" corded polishers
• Includes two batteries and quick charger for zero downtime
• Bale handle design for vertical or horizontal gripping
Specification:
When unpacking, check the parts diagram and part
number listing on page 9 to make sure all parts are
included. If any parts are missing or damaged,
please call your distributor.
Motor: Brushless DC-20V
Battery: 4.0Ah (X2)
Run Time: speed 6 (highest speed): around 45 min.
speed 1 (lowest speed): around 5 hours
No Load Speed: (soft start) 400, 760, 1,120,
1,480, 1,840, 2,200 RPM
Weight: 5.86lbs w/ battery, 4.1lbs tool only
Arbor Size: 5/8"-11
Pad Dia.: 180mm (7")
Switch Type: Slide Switch w/ lock
Charge Time: 80 min.

30570 20V 7" BRUSHLESS VARIABLE SPEED
ROTARY POLISHER W/ 2 BATTERIES
Product Type:Model:
Page 2
MEANING OF SYMBOLS
Read the user manual before using this tool. Warning! Danger! Note!
Whenever the tool is in use, safety
goggles must be worn to safeguard
against flying object, operator also must
wear ear protectors, such as a soundproof
helmet, in order to protect the operators
hearing. If the operator is working in an
area where there is a risk of falling
objects, a safety helmet must be worn.
Do not dispose electric tools, batteries/rechargeable batteries together with household
waste material. Electric tools and batteries that have reached the end of their life must be
collected separately and returned to an environmentally compatible recycling facility.
Check with your local authority or retailer for recycling advice and collection point.
Do not expose to rain.
Wear safety boots to protect against
electric shock.
Wear gloves to protect your hands.
GENERAL POWER TOOL
SAFETY WARNINGS
WORK AREA SAFETY
a) Keep work area clean and well lit.
Cluttered and dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust.
Power tools create sparks which may ignite
the dust or fumes.
c) Keep children and bystanders away while
operating a power tool.
Distractions can cause you to lose control.
PERSONAL SAFETY
a) Stay alert. Watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired or
under the influence of drugs, alcohol or
medication. A moment of inattention while
operating power tools may result in serious
personal injury.
b) Use personal protective equipment. Always
wear eye protection. Protective equipment such
as dust mask, non-skid safety shoes, hard hat,
or hearing protection used for appropriate
conditions will reduce personal injuries.
POWER TOOL USE AND CARE
a) Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at the
rate for which it was designed.
b) Do not use the power tool if the switch does not
turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must
be repaired.
c) Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the
power tool or these instructions to operate the
power tool. Power tools are dangerous in the
hands of untrained users.
d) Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and
any other condition that may affect the power
tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused
by poorly maintained power tools.
c) Prevent unintentional starting, ensure the switch
is in the off-position before connecting to battery
pack, picking up or carrying the tool.
d) Remove any adjusting key or wrench before
turning on the power tool. A wrench or parts left
attached to a rotating part of the power tool may
result in personal injury.
e) Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the power tool in unexpected situations.
ELECTRICAL SAFETY
Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.

30570 20V 7" BRUSHLESS VARIABLE SPEED
ROTARY POLISHER W/ 2 BATTERIES
Product Type:Model:
Page 3
IMPORTANT SAFETY INSTRUCTIONS
FOR BATTERY PACK
a) Before using the battery pack, read all
instructions and cautionary markings on battery
pack,charger and product using battery pack.
b) If operating time has become excessively
shorter, stop operating immediately. It may result
in a risk of overheating and possible burns.
c) Do not short the battery pack:
1) Do not touch the terminals with any
conductive material.
2) Do not expose the battery pack to water or
rain. A short circuit of the battery can cause
a large current flow, overheating, possible
burns and even a breakdown.
d) Do not store the tool and battery pack in
locations where the temperature may exceed
140°F (60°C).
e) Do not incinerate the battery pack even if it is
severely damaged or is completely worn out.
The battery pack can explode in a fire.
f) Be careful not to drop or strike the battery.
g) Do not use a damaged battery.
FOR CHARGER
a) Before charging, study the instruction manual
carefully.
b) Before charging the battery, connect the power
cord into the power supply first and then connect
the battery pack with the charger. Once the
battery is fully charged, disconnect the power
supply after removing the battery pack from
the charger.
c) This device is for indoor use only. Water, rain or
moisture should be strictly prohibited.
d) Correct use: chargers are to be used exclusively
for charging 20V 7" brushless variable speed
rotary polisher rechargeable battery packs.
Any other application may result in risk of fire,
electric shock or electrocution.
The user bears sole responsibility for any
damage caused by inappropriate use.
The generally recognized accident prevention
regulations and the safety instructions which
accompany them must be adhered to.
e) The charger is specifically designed to charge
the ASTRO 30570 battery packs. Do not attempt
to charge any other battery with this charger.
f) Do not expose the charger to rain or snow and
other extreme climate conditions. Do not use
power tools in damp or wet locations.
g) The use of any attachment not recommended or
supplied by the battery charger manufacture may
result in a risk of fire, electric shock, or injury to
persons.
h) To reduce risk of damage to electric plug and
cord, pull by plug rather than cord when
disconnecting charger.
i) Make sure cord is appropriately located so that it
will not be stepped on, tripped over, or otherwise
subject to damage or stress.
j) Do not operate charger with damaged cord or
plug. Please replace them immediately if any
damage is found.
k) Do not operate charger if it has received a sharp
blow, been dropped, or otherwise damaged in
any way; take it to an authorized Service Center.
l) Do not disassemble charger; take it to an
authorized Service Center when service or repair
is required. Incorrect reassembly may result in
a risk of electric shock or fire.
m) To reduce risk of electric shock, unplug charger
from outlet before attempting any maintenance
or cleaning.
n) Charging must only be performed when the
battery pack temperature is between 32˚F (0˚C)
and 113˚F (45˚C).
o) The charger vents shall be strictly prohibited to
be covered or clogged by any foreign object.
p) The charger is designed to operate on standard
household electrical power. Do not attempt to use
it on any other voltage.
e) Use the power tool and accessories in
accordance with these instructions, taking into
account the working conditions and the work to
be performed. Use of the power tool for
operations different from those intended could
result in a hazardous situation.
SERVICE
Have your power tool serviced by a qualified repair
person using only identical replacement parts.
This will ensure that the safety of the power tool is
maintained.
Warning: Danger of explosion if the battery
is incorrectly replaced. Replace the battery only
with the same designed battery type.

Warning: The battery will not reach full
charge after the first charge. Please allow a few
charge cycles until constant Red and blinking
Green Lights status to ensure the battery is
charged to its fullest capacity.
Warning: The parts inside the charger are
live and can create a shock hazard! Do not stick
anything in the battery charger terminal slots.
q) Unplug the charger immediately if there is any
sign of smoke or flame.
r) Do not drill into the housing of the charger or
battery pack.
s) Keep the charger away from children.
30570 20V 7" BRUSHLESS VARIABLE SPEED
ROTARY POLISHER W/ 2 BATTERIES
Product Type:Model:
Page 4
SAFETY PRECAUTION WHEN USING
CHARGER AND BATTERY
a) Do not charge the battery when temperature is
blow 32°F (0°C) or above 113°F (45°C).
The most suitable temperature for charging is
that of 68-77°F (20-25°C).
b) Do not insert objects into the hole reserved for
the battery in charger stand.
c) Never short-circuit the battery. Short circuiting
the battery will severely damage the battery and
cause dangers of fire and explosion.
d) This appliance is not intended for use by
persons, including children, with reduced
physical, sensory or mental capabilities, or lack
of experience and knowledge, unless they have
been given supervision or instruction concerning
use of the appliance by a person responsible of
their safety.
CHARGER LED INDICATION
Fully
Charged
Blinking green light
Constant red light
Constant green light
Constant red light
Blinking red light
Battery
Over Heated
Charging
Battery
Damaged
Green light and red light
are blinking
Slide in
SYMBOLLED LIGHT
DISPLAY STATUS
CHARGING
STATUS
e) Children should be supervised to ensure that
they do not play with the appliance.
f) Do not dispose of electrical appliances as
unsorted municipal waste, use separate
collection facilities.
g) If electrical appliances are disposed of in
landfills or dumps, hazardous substances can
leak into the soil, damaging your health and
well-being.
h) When replacing old appliances with new ones
under warranty, the retailer is legally obligated
to take back your old appliance for disposal at
least for free of charge.
i) If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.

Warning: If any parts are missing, do not
operate tool until the missing parts are replaced.
Failure to do so could result in possible serious
personal injury.
The charging time may vary according to the
surrounding temperature and the power source
voltage.
Warning: Do not attempt to destroy or
disassemble the battery pack or remove any of
its components. Do not touch terminals with
metal objects as short-circuit may result. Keep
away from children. Failure to comply with these
warnings could result in fire and/or serious injury.
Warning: Do not use force when installing
the battery pack. If the battery pack does not
slide in easily, it is not being inserted correctly.
Verify that the switch is in OFF position before
inserting or removing the battery pack.
30570 20V 7" BRUSHLESS VARIABLE SPEED
ROTARY POLISHER W/ 2 BATTERIES
Product Type:Model:
Page 5
PREPARATION FOR RECYCLING OF
BATTERY PACK
SAFETY WARNINGS COMMON FOR
POLISHER OPERATINS
a) This power tool is intended to function as
a polisher. Read all safety warnings,
instructions and specifications provided
with this tool. Failure to follow all instructions
listed below may result in injury.
b) Operations such as grinding, sanding, wire
brushing or cutting-off are not
recommended to be performed with this
power tool. Operations for which the power tool
was not designed may create a hazard and
causer personal injury.
c) Do not use accessories which are not
specifically designed and recommended by
the tool manufacturer. Just because the
accessory can be attached to your power tool,
it does not assure safe operation.
d) The rated speed of the accessory must be at
least equal to the maximum speed marked
on the power tool. Accessories running faster
than their rated speed can break and fly apart.
e) The outside diameter of your accessory
must be within the capacity rating of your
power tool. Incorrectly sized accessories can
not be adequately guarded or controlled.
TIPS FOR MAINTAINING MAXIMUM
BATTERY LIFE
a) Charge the battery pack before completely
discharged. Always stop tool operation and
charge the battery pack when you notice a
decrease in tool power.
b) Never over discharge a fully charged battery
pack. Over discharging shortens the battery
service life.
c) Charge the battery pack under room temperature
between 32-113°F (0-45°C). Let a hot battery
pack cool down before charging it.
d) Charge the battery pack once every 3 months if
you do not use it for a long period of time. Li-ion
batteries are known to discharge over time.
Battery may be damaged if it is over discharged.
INSTALLING OR REMOVING BATTERY PACK
a) Hold the tool and the battery pack firmly when
installing or removing battery pack. Failure to
hold the tool and the battery pack firmly may
cause them to slip off your hands and result in
damage to the tools and battery pack and a
personal injury.
b) Always switch off the tool before installing or
removal of the battery pack.
c) To remove battery pack, press the release
button, and pull out.
d) To install the battery pack with the charger,
align the terminal pin on the charger and slide
the battery into the charger.
DISPOSAL OF THE EXHAUSTED BATTERY
For safety and to preserve natural resources,
please recycle or dispose of properly.
This product contains Lithium-ion batteries.
Must be disposed of properly.
Local, state, or federal laws may prohibit disposal
of Lithium-ion batteries in ordinary trash. Consult
your local waste authority for information regarding
available recycling and/or disposal options.

Warning: If battery pack case is cracked
or damaged, do not insert into charger. Danger
of electric shock, electrocution and leakage.
f) Threaded mounting of accessories must
match the polisher spindle thread. For
accessories mounted by flanges, the arbor
hole of the accessory must fit the locating
diameter of the flange. Accessories that do
not match the mounting hardware of the power
tool will run out of balance, vibrate excessively
and may cause loss of control.
g) Do not use a damaged accessory. Before
each use, inspect the accessory such as
abrasive wheels for chips and cracks. If
power tool or accessory is dropped, inspect
for damage or install an undamaged
accessory. After inspecting and installing an
accessory, position yourself and bystanders
away from the plane of the rotating accessory
and run the power tool at maximum no-load
speed for one minute. Damaged accessories
will normally break apart during this test time.
l) Do not run the power tool while carrying it at
your side. Accidental contact with the spinning
accessory could snag your clothing, pulling the
accessory into your body.
m) Regularly clean the power tool’s air vents.
The motor’s fan will draw the dust inside the
housing and excessive accumulation of
powdered metal may cause electrical hazards.
n) Do not operate the power tool near flammable
materials. Sparks could ignite these materials.
h) Wear personal protective equipment.
Depending on application use face shield,
safety goggles or safety glasses.
As appropriate, wear dust mask, hearing
protectors, gloves and workshop apron
capable of stopping small abrasive or
workpiece fragments. The eye protection must
be capable of stopping flying debris generated
by various operations. The dust mask or
respirator must be capable of filtrating particles
generated by your operation. Prolonged exposure
to high intensity noise may cause hearing loss.
i) Keep bystanders a safe distance away from
work area. Anyone entering the work area
must wear personal protective equipment.
Fragments of workpiece or of a broken accessory
may fly away and cause injury beyond immediate
area of operation.
j) Hold power tool by insulated gripping
surfaces only, when performing an operation
where the polishing accessory may contact
hidden wiring or its own cord. Polishing
accessory contacting a “live” wire may make
exposed metal parts of the power tool “live and
shock the operator.
k) Never lay the power tool down until the
accessory has come to a complete stop. The
spinning accessory may grab the surface and
pull the power tool out of your control.
30570 20V 7" BRUSHLESS VARIABLE SPEED
ROTARY POLISHER W/ 2 BATTERIES
Product Type:Model:
Page 6
KICKBACK AND RELATED WARNINGS
Kickback is a sudden reaction to a pinched or
snapping rotating wheel, backing pad, brush or
any other accessory.
Pinching or snapping causes rapid stalling of the
rotating accessory which in turn causes the
uncontrolled power tool to be forced in the direction
opposite of the accessory’s rotation at the point of
the binding.
For example, if an abrasive wheel is snapping or
pinched by the workpiece, the edge of the wheel
that is entering into the pinch point can dig into the
surface of the material causing the wheel to climb
out or kick out. The wheel may either jump toward
or away from the operator, depending on direction
of the wheel’s movement at the point of pinching.
Abrasive wheels may also break under these
conditions.
Kickback is the result of power tool misuse and/or
incorrect operating procedures or conditions and
can be avoided by taking proper precautions as
given below.
a) Maintain a firm grip on the power tool and
position your body and arm to allow you to
resist kickback forces. Always use auxiliary
handle, if provided, for maximum control
over kickback or torque reaction during
start-up. The operator can control torque
reactions or kickback forces, if proper
precautions are taken.
b) Never place your hand near the rotating
accessory. Accessory may kickback over
your hand.
c) Do not position your body in the area where
power tool will move if kickback occurs.
Kickback will propel the tool in direction
opposite to the wheel’s movement at the point
of snapping.

INSTRUCTION
Do not allow any loose portion of the polishing
bonnet or its attachment strings to spin freely.
Tuck away or trim any loose attachment strings.
Loose and spinning attachment strings can
entangle your fingers or snag on the workpiece.
a) lead from lead-based paint
b) crystalline silica from bricks and cement
and other masonry products, and
c) arsenic and chromium from
chemically-treated lumber.
Your risk from these exposures varies, depending
on how often you do this type of work. To reduce
your exposure to these chemicals: work in a well
ventilated area, and work with approved safety
equipment, such as those dust masks that are
specially designed to filter out microscopic
particles.
Warning: Some dust created by power
sanding, sawing, grinding, drilling, and other
construction activities contains chemicals
known to cause cancer, birth defects or other
reproductive harm. Some examples of these
chemicals are:
Warning: Recharge only with the charger
specified for the battery. For specific charging
instructions, read the operator’s manual supplied
with your charger and battery.
Removing/Inserting the battery to remove the
battery, push in the release buttons and pull the
battery pack away from the tool.
Always remove battery pack before changing or
removing accessories. To insert the battery, slide
the pack into the body of the tool. Make sure it
latches securely into place.
To reduce the risk of injury, always use a side
handle when using this tool. Hold securely.
d) Use special care when working corners,
sharp edges etc. Avoid bouncing and
snagging the accessory. Corners, sharp
edges or bouncing have a tendency to snag
the rotating accessory and cause loss of control
or kickback.
e) Do not attach a saw chain woodcarving
blade or toothed saw blade. Such blades
create frequent kickback and loss of control.
30570 20V 7" BRUSHLESS VARIABLE SPEED
ROTARY POLISHER W/ 2 BATTERIES
Product Type:Model:
Page 7
SAFETY WARNINGS SPECIFIC FOR
POLISHER OPERATIONS
Bale Handle
Arbor
Lock
On/Off Switch
Electronic
Speed Control
Detachable
Air Inlet Screen
INSTALLING THE HANDLE (FIG. 1)
a) Position the handle in the position (left or
right orientation) that offers best control.
b) Slide the handle around the front of the tool
and up onto the body of the tool.
c) Fit the handle into both handle sockets.
d) Select one of the three angle positions that
offers best control, forward or back.
e) Insert the hex screws into each side of the
handle and tighten securely with the hex
wrench provided.
Hex Screw
FIG. 1

POLISHING
Always use handle for proper control. Move the
polisher back and forth in long, sweeping strokes.
Too much pressure, the wrong angle or improper
motion may cause swirl marks or burning. For
detailed polishing instructions, read the instructions
provided with the finishes, waxes and polishes.
PREVENTING BURNING THROUGH PAINT
It is easy to burn through the paint on a surface.
This can occur if you polish at too high of a speed
or if you allow the polishing pad to stay in one spot
for even a short period of time. To prevent burning
through paint, use very light pressure and keep
the polisher moving constantly, especially when
working near edges or where there are abrupt
changes in the contour of the work surface. Be
particularly careful when using higher RPM's which
are more likely to burn through paint.
OPERATION
SWITCHING ON AND OFF (FIG. 5)
a) To start the machine, press the On/Off Switch
and keep it pressed.
b) To lock-on the pressed On/Off Switch, push the
On/Off Switch further forward.
c) To switch off the power tool, release the On/Off
Switch, or when it is locked, briefly press the
On/Off Switch and then release it.
d) To save energy, only switch the power tool on
when using it.
Warning: To reduce the risk of injury, always
wear safety goggles or glasses with side shields.
30570 20V 7" BRUSHLESS VARIABLE SPEED
ROTARY POLISHER W/ 2 BATTERIES
Product Type:Model:
Page 8
INSTALLING/REMOVING/CLEANING
THE DUST SCREEN (FIG. 2)
a) To attach the dust screen, snap the screen over
the tool’s handle.
b) To remove the dust screen, insert a flat
screwdriver into the notch at the top of the dust
screen and pry away from the tool.
c) To clean the dust screen, tap against a hard
surface, or blow clean with compressed air.
Using the dust screen will increase the
performance and extend the life of the tool.
Warning: Do not use tool without dust
screen installed.
Warning: Before any work on the machine
itself, turn off the tool.
Dust Screen
FIG. 2
Spindle
Lock Button
Spindle
FIG. 3
On/Off Switch
FIG. 5
INSTALLING POLISHING PADS/BONNETS
a) To install, place the tool on its tool rest
with the spindle upright.
b) Press and hold the spindle lock button (Fig. 3).
c) Thread the backing pad onto the spindle (Fig. 4).
Hand tighten securely.
Spindle
Polishing
Pad
Backing
Pad
FIG. 4
d) Press the polishing pad/bonnet securely onto
the backing pad. Use a centering tool, if provided,
to ensure the pad is aligned for proper balance.
e) To remove, remove the battery pack and reverse
the procedure.

1
2
3
4
5
6
911
PARTS BREAKDOWN Call 1.800.221.9705 for questions concerning
performance of the product or other inquiries.
PREVENTING SNAGGING
Snagging occurs when polishing pads get caught
on rough edges of a work surface. Snagging can
cause the tool to suddenly "kick back" and it may
cause the pad to burn through the paint. To reduce
the risk of snagging, use the polisher at low speeds
when polish-ing rough surfaces. For tricky areas
such as near trim or between a mirror and window
on a car, do not take chances with a polisher.
Polish these surfaces by hand.
After use, check tool to keep it in top condition,
a) Clean out accumulated dust.
b) The ventilation slots of the tool must be kept
clear at all times. Use only Astro 30570
accessories and spare parts.
c) Do not make any adjustment while the motor
is in motion.
d) Refer to the label for production date.
PRESELECTING SPEED (FIG. 6)
a) This tool is equipped with 6 belt speed controls
which can be found in the button of the tool.
b) The required belt speed depends on the material
being polished and on the working conditions,
and can be determined by practical testing.
c) When using a fleece belt, do not work with
a higher setting than speed stage 6 (max.).
Otherwise, the fleece belt will become too hot.
MAINTENANCE
Warning: When service is required, only use
the same or equivalent parts from Astro. Using
parts from different brands might cause danger
or tool damage.
When replacing parts, remove the battery from
the tool to avoid accidental start-up.
Warning: To avoid possible serious injury
always remove the battery before changing
any parts.
Warning: Operate with a belt speed adapted
to the application in order to prevent damage to
the material.
Warning: To reduce the risk of injury, follow
instructions for preventing snagging. Snagging
may cause the tool to kick back and the operator
to suddenly lose control of the tool. Always use
side handle to maintain control.
30570 20V 7" BRUSHLESS VARIABLE SPEED
ROTARY POLISHER W/ 2 BATTERIES
Product Type:Model:
Page 9
FIG. 6
2 3 1
5
6 4
Electronic
Speed Control
6 - speed selections
Parts List
Qty
1
2
3
4
5
6
30570-01
30570-02
30570-03
30570-04
30570-05
30570-06
Polisher
Battery
7" Pad
Charger
Bale Handle
Dust Screen
Index Part No. Description
1
2
1
1
1
2
