P6-P5G41E
ASUS PC (Desktop Barebone)
User’s Manual

ii
Copyright © 2009 ASUSTeK Computer Inc. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means, except documentation kept by the purchaser for backup purposes, without the express written
permission of ASUSTeK Computer Inc. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless
such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identication or explanation and to the
owners’ benet, without intent to infringe.
E5240
First Edition V1
December 2009

iii
Table of contents
Notices......................................................................................................... vi
About this guide ....................................................................................... viii
System package contents........................................................................... x
Chapter 1: System introduction
1.1 Welcome! ...................................................................................... 1-2
1.2 Front panel ................................................................................... 1-2
1.3 Rear panel..................................................................................... 1-4
1.4 Internal components.................................................................... 1-7
1.5 QualiedVendorsLists(QVL) .................................................... 1-8
Chapter 2: Starting up
2.1 Installing an operating system ................................................... 2-2
2.2 Powering up.................................................................................. 2-2
2.3 SupportDVDinformation............................................................ 2-2
2.3.1 Running the support DVD ............................................... 2-3
2.3.2 Utilities menu .................................................................. 2-4
2.3.3 ASUS Contact information .............................................. 2-5
2.3.4 Other information ............................................................ 2-6
Chapter 3: Motherboardinfo
3.1 Introduction .................................................................................. 3-2
3.2 Motherboard layout...................................................................... 3-2
3.3 Jumpers ........................................................................................ 3-3
3.4 Connectors ................................................................................... 3-5
Chapter 4: BIOS setup
4.1 Managing and updating your BIOS ............................................ 4-2
4.1.1 ASUS Update utility ........................................................ 4-2
4.1.2 ASUS EZ Flash 2 utility................................................... 4-5
4.1.3 ASUS CrashFree BIOS .................................................. 4-6

iv
Table of contents
4.2 BIOS setup program .................................................................... 4-7
4.2.1 BIOS menu screen.......................................................... 4-8
4.2.2 Menu bar......................................................................... 4-8
4.2.3 Navigation keys............................................................... 4-8
4.2.4 Menu items ..................................................................... 4-9
4.2.5 Sub-menu items.............................................................. 4-9
4.2.6 Conguration elds ......................................................... 4-9
4.2.7 Pop-up window ............................................................... 4-9
4.2.8 Scroll bar......................................................................... 4-9
4.2.9 General help ................................................................... 4-9
4.3 Main menu .................................................................................. 4-10
4.3.1 System Time ................................................................. 4-10
4.3.2 System Date ................................................................. 4-10
4.3.3 SATA1~4 ........................................................................4-11
4.3.4 Storage Conguration ................................................... 4-12
4.3.5 System Information ....................................................... 4-13
4.4 Advanced menu ......................................................................... 4-14
4.4.1 CPU Conguration ........................................................ 4-14
4.4.2 Chipset.......................................................................... 4-16
4.4.3 Onboard Devices Conguration.................................... 4-18
4.4.4 USB Conguration ........................................................ 4-19
4.4.5 PCI PnP ........................................................................ 4-20
4.5 Power menu................................................................................ 4-21
4.5.1 Suspend Mode.............................................................. 4-21
4.5.2 ACPI 2.0 Support ......................................................... 4-21
4.5.3 ACPI APIC Support ...................................................... 4-21
4.5.4 APM Conguration........................................................ 4-22
4.5.5 Hardware Monitor ......................................................... 4-23
4.6 Boot menu .................................................................................. 4-24
4.6.1 Boot Device Priority ...................................................... 4-24
4.6.2 Boot Settings Conguration .......................................... 4-25

v
Table of contents
4.6.3 Security ......................................................................... 4-26
4.7 Tools menu ................................................................................. 4-28
4.7.1 ASUS EZ Flash 2.......................................................... 4-28
4.7.2 Express Gate [Auto]...................................................... 4-28
4.8 Exit menu.................................................................................... 4-29

vi
Notices
Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with manufacturer’s
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CanadianDepartmentofCommunicationsStatement
This digital apparatus does not exceed the Class B limits for radio noise emissions
from digital apparatus set out in the Radio Interference Regulations of the
Canadian Department of Communications.
This class B digital apparatus complies with Canadian ICES-003.
WARNING! The use of shielded cables for connection of the monitor to the
graphics card is required to assure compliance with FCC regulations. Changes
or modications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate this equipment.
REACH
Complying with the REACH (Registration, Evaluation, Authorisation, and
Restriction of Chemicals) regulatory framework, we published the chemical
substances in our products at ASUS REACH website at
http://green.asus.com/english/REACH.htm.

vii
Operationsafety
• Before installing the motherboard and adding devices on it, carefully read all the manuals
that came with the package.
• Before using the product, ensure that all cables are correctly connected and the power
cables are not damaged. If you detect any damage, contact your dealer immediately.
• To avoid short circuits, keep paper clips, screws, and staples away from connectors,
slots, sockets and circuitry.
• Avoid dust, humidity, and temperature extremes. Do not place the product in any area
where it may become wet.
• Place the product on a stable surface.
• If you encounter technical problems with the product, contact a qualied service
technician or your retailer.
Safetyinformation
Electricalsafety
• To prevent electric shock hazard, disconnect the power cable from the electric outlet
before relocating the system.
• When adding or removing devices to or from the system, ensure that the power cables
for the devices are unplugged before the signal cables are connected. If possible,
disconnect all power cables from the existing system before you add a device.
• Before connecting or removing signal cables from the motherboard, ensure that all
power cables are unplugged.
• Seek professional assistance before using an adapter or extension cord. These devices
could interrupt the grounding circuit.
• Ensure that your power supply is set to the correct voltage in your area. If you are not
sure about the voltage of the electrical outlet you are using, contact your local power
company.
• If the power supply is broken, do not try to x it by yourself. Contact a qualied service
technician or your retailer.
DO NOT throw the motherboard in municipal waste. This product has been
designed to enable proper reuse of parts and recycling. This symbol of the
crossed out wheeled bin indicates that the product (electrical and electronic
equipment) should not be placed in municipal waste. Check local regulations for
disposal of electronic products.
DO NOT throw the mercury-containing button cell battery in municipal waste.
This symbol of the crossed out wheeled bin indicates that the battery should not
be placed in municipal waste.

viii
About this guide
Audience
This guide provides general information and installation instructions about the
ASUS P6-P5G41E barebone system. This guide is intended for experienced users
and integrators with hardware knowledge of personal computers.
How this guide is organized
This guide contains the following parts:
1. Chapter 1: System introduction
This chapter gives a general description of the ASUS
P6-P5G41E. The chapter lists the system features, including introduction on
the front and rear panel, and internal components.
2. Chapter 2: Starting up
This chapter helps you power up the system and install drivers and utilities
from the support DVD.
3. Chapter3:Motherboardinfo
This chapter gives information about the motherboard that comes with the
system. This chapter includes the motherboard layout, jumper settings, and
connector locations.
4. Chapter 4: BIOS setup
This chapter tells how to change system settings through the BIOS Setup
menus and describes the BIOS parameters.

ix
Conventions used in this guide
WARNING: Information to prevent injury to yourself when trying to
complete a task.
CAUTION: Information to prevent damage to the components when
trying to complete a task.
IMPORTANT: Instructions that you MUST follow to complete a task.
NOTE: Tips and additional information to aid in completing a task.
Wheretondmoreinformation
Refer to the following sources for additional information and for product and
software updates.
1. ASUS Websites
The ASUS websites worldwide provide updated information on ASUS
hardware and software products. Refer to the ASUS contact information.
2. Optional Documentation
Your product package may include optional documentation, such as warranty
yers, that may have been added by your dealer. These documents are not
part of the standard package.

x
System package contents
Check your P6-P5G41E system package for the following items.
If any of the items is damaged or missing, contact your retailer immediately.
Item description
1. ASUS P6-P5G41E barebone system with
• ASUS motherboatd
• Power supply unit
• ASUS chassis
2. Cable
• AC power cable
3. Support DVD
4. Quick Installation Guide

System introduction
This chapter gives a general
description of the ASUS P6-P5G41E.
The chapter lists the system features
including introduction on the front and
rear panel, and internal components.
Chapter 1

1-2 Chapter 1: System introduction
1.1 Welcome!
Thank you for choosing the ASUS P6-P5G41E!
The ASUS P6-P5G41E is an all-in-one barebone system with a versatile home
entertainment feature.
The system comes in a stylish casing and powered by the ASUS motherboard that
supports the Intel®Core™2 Extreme / Core™2 Duo / Core™2 Quad / Pentium®
dual-core / Celeron®processors in the 775-land package.
The system supports up to 8 GB of system memory using
DDR3-1333/1066 DIMMs. High-resolution graphics via integrated graphics
controller or PCI Express x16 slot, Serial ATA, USB 2.0, and 8-channel audio
feature the system and take you ahead in the world of power computing.
1.2 Front panel
The front panel includes the optical drive bays, power button, and several I/O ports
are located at the front panel.
Front panel
1
2
3
1
4
3
5
6
7

1-3ASUS P6-P5G41E
1. Power button. Press this button to turn the system on.
2. Front panel cover. Push to open the front panel cover.
3. Optical disk drive cover. Push to eject the optical disk drive.
4. Microphone port. This Mic (pink) port connects a microphone.
5. Headphone port. This Line out (lime) port connects a headphone with a
stereo mini-plug.
6. USB 2.0 ports. These Universal Serial Bus 2.0 (USB 2.0) ports are available
for connecting USB 2.0 devices such as a mouse, printer, scanner, camera,
PDA, and others.
7. Multimedia Card / Secure Digital™ / MemoryStick® / Memory Stick Pro™
card slot

1-4 Chapter 1: System introduction
4
1.3 Rear panel
The system rear panel includes the power connector and several I/O ports that
allow convenient connection of devices.
1. Chassis air vent. The vent is for ventilation inside the system chassis.
2. Powersupplyunitfanvent.This vent is for the PSU fan that provides
ventilation inside the power supply unit.
3. Chassisfanvent.This vent is for the fan that provides ventilation inside the
system chassis.
4. Power connector. This connector is for the power cable and plug.
1
2
7
15
14
6
Do NOT cover the rear vent , and the ambient temperature is limited up to 35oC
to prevent the system from overheating.
8
9
12
5
10
11
13
3

1-5ASUS P6-P5G41E
5. LineInport(lightblue).This port connects the tape, CD, DVD player, or
other audio sources.
6. LineOutport(lime). This port connects a headphone or a speaker. In
4-channel, 6-channel, and 8-channel conguration, the function of this port
becomes Front Speaker Out.
7. Microphoneport(pink). This port connects a microphone.
8. SideSpeakerOutport(gray).This port connects the side speaker in an
8-channel audio conguration.
9. RearSpeakerOutport(black). This port connects the rear speakers in a
4-channel, 6-channel, or 8-channel audio conguration.
10. Center/Subwooferport(orange). This port connects the center/subwoofer
speakers.
 Activity/Link SpeedLED
Status Description Status Description
OFF No link OFF 10 Mbps connection
ORANGE Linked ORANGE 100 Mbps connection
BLINKING Data activity GREEN 1 Gbps connection
LANportLEDindications
SPEED
LED
ACT/LINK
LED
LANport
11. LAN(RJ-45)port. This port allows gigabit connection to a Local Area
Network (LAN) through a network hub. Refer to the table below for the LAN
port LED indications.
Refer to the audio conguration table below for the function of the audio ports in
2, 4, 6, or 8-channel conguration.
Audio2,4,6,or8-channelconguration
Port Headset
2-channel 4-channel 6-channel 8-channel
Light Blue Line In Line In Line In Line In
Lime Line Out Front Speaker Out Front Speaker Out Front Speaker Out
Pink Mic In Mic In Mic In Mic In
Orange – – Center/Subwoofer Center/Subwoofer
Black – Rear Speaker Out Rear Speaker Out Rear Speaker Out
Gray – – – Side Speaker Out

1-6 Chapter 1: System introduction
12. USB 2.0 ports 1 ~ 4. These 4-pin Universal Serial Bus (USB) ports are
available for connecting USB 2.0 devices.
13. VideoGraphicsAdapter(VGA)port. This 15-pin port is for a VGA monitor or
other VGA-compatible devices.
14. HDMI port. This is a High-Denition Mulltimedia Interface (HDMI) connector,
and is HDCP compliant allowing playback of HD DVD, Blu-Rau discs, and
other protected content.
15. Expansion slot covers. Remove these covers when installing expansion
cards.

1-7ASUS P6-P5G41E
1.4 Internal components
The illustration below is the internal view of the system when you remove the side
cover and the power supply unit. The installed components are labeled for your
reference.
• Refer to the bundled Quick Installation Guide for installing additional
system components and get assistance from professionals when you
disassemble or assemble the system.
• Refer to the Chapter 4 in this user guide for motherboard details.
1. Front panel cover
2. 5.25-inch optical drive bays
3. Hard disk drive bay
4. Power supply unit (under the HDD bay)
5. ASUS motherboard
6. Expansion slot metal brackets
7. Metal bracket lock
1
3
4
5
2
6
5
7

1-8 Chapter 1: System introduction
1.5 QualiedVendorsLists(QVL)
DDR3-1067MHz capability
Vendor Part No. Size SS/
DS Chip Brand Chip No. Timing Voltage
DIMM
support
A* B*
Crucial CT12864BA1067.8FF 1GB SS MICRON D9KPT 7 - • •
Crucial CT12864BA1067.8SFD 1GB SS MICRON D9JNL 7 - • •
Crucial CT12872BA1067.9FF 1GB SS MICRON D9KPT(ECC) 7 - • •
Crucial CT25664BA1067.16FF 2GB DS MICRON D9KPT 7 - • •
Crucial CT25664BA1067.16SFD 2GB DS MICRON D9JNL 7 - • •
Crucial CT25672BA1067.18FF 2GB DS MICRON D9KPT(ECC) 7 - • •
ELPIDA EBJ10UE8BAW0-AE-E 1GB SS ELPIDA J1108BABG-DJ-E 7 - • •
ELPIDA EBJ10UE8EDF0-AE-F 1GB SS ELPIDA J1108EDSE-DJ-F - - • •
ELPIDA EBJ11RD8BAFA-AE-E 1GB DS ELPIDA J5308BASE-AC-E(ECC) 7 -
ELPIDA EBJ11UD8BAFA-AG-E 1GB DS ELPIDA J5308BASE-AC-E 8 - • •
ELPIDA EBJ21UE8BAW0-AE-E 2GB DS ELPIDA J1108BABG-DJ-E 7 - • •
ELPIDA EBJ21UE8EDF0-AE-F 2GB DS ELPIDA J1108EDSE-DJ-F - - • •
Hynix HMT112U6AFP8C-G7N0 1GB SS HYNIX H5TQ1G83AFPG7C 7 - • •
Hynix HYMT112U64ZNF8-G7 1GB SS HYNIX HY5TQ1G831ZNFP-G7 7 - • •
Hynix HMT125U6AFP8C-G7N0 2GB DS HYNIX H5TQ1G83AFPG7C 7 - • •
Hynix HYMT125U64ZNF8-G7 2GB DS HYNIX HY5TQ1G831ZNFP-G7 7 - • •
KINGSTON KVR1066D3N7/1G 1GB SS KINGSTON D1288JEKAPA7U 7 1.5 • •
KINGSTON KVR1066D3N7/2G 2GB DS KINGSTON D1288JEKAPGA7U 7 1.5 • •
KINGSTON KVR1066D3N7/2G 2GB DS ELPIDA J1108BABG-DJ-E - 1.5 • •
KINGSTON KVR1066D3N7/4G 4GB DS SAMSUNG K4B2G0846B-HCF8 - 1.5 • •
MICRON MT8JTF12864AY-1G1D1 1GB SS MICRON 7VD22 7 - • •
MICRON MT8JTF12864AZ-1G1F1 1GB SS MICRON 8ZF22 D9KPV 7 - • •
MICRON MT8JTF12864AZ-1G1F1 1GB SS MICRON D9KPT 7 - • •
MICRON MT9JSF12872AZ-1G1F1 1GB SS MICRON D9KPT(ECC) 7 - • •
MICRON MT16JTF25664AY-1G1D1 2GB DS MICRON 7VD22 7 - • •
MICRON MT16JTF25664AZ-1G1F1 2GB DS MICRON 8ZF22 D9KPV 7 - • •
MICRON MT16JTF25664AZ-1G1F1 2GB DS MICRON D9KPT 7 - • •
MICRON MT18JSF25672AZ-1G1F1 2GB DS MICRON D9KPT(ECC) 7 - • •
SAMSUNG M378B5273BH1-CF8 4GB DS SAMSUNG K4B2G0846B-HCF8 8 1.5 •
Transcend TS256MLK64V1U 2GB DS ELPIDA J1108BABG-AE-E 7 - • •
Asint SLY3128M8-EAE 1GB SS Asint DDRIII1208-AE - - • •
Asint SLZ3128M8-EAE 2GB DS Asint DDRIII1208-AE - - • •
Elixir M2Y2G64CB8HA9N-BE 2GB DS - - - - • •
WINTEC 3DU3191A-10 1GB DS Qimonda IDSH51-03A1F1C-10F 7 - • •

1-9ASUS P6-P5G41E
DDR3-1333MHz capability
continued on the next page
Vendor Part No. Size SS/
DS Chip Brand Chip No. Timing Voltage
DIMM
support
A* B*
A-DATA AD3133301GOU 1GB SS A-DATA AD30908C8D-15IG - - • •
A-DATA AD31333002GOU 2GB DS A-DATA AD30908C8D-15IG - - • •
A-DATA AD3U1333B2G9-2 2GB DS A-DATA AD30908C8D-15IG - - • •
A-DATA AX3U1333PB2G7-2P 4GB(2 x 2GB) DS - - 7-7-7-20 1.65-
1.85
• •
A-DATA AD3U1333C4G9-B 4GB DS Hynix H5TQ2G83AFRH9C 1333-9-9-
9-24
- • •
A-DATA AD31333E002G0U 6GB(3 x 2GB) DS - - 7-7-7-20 1.65-
1.85
• •
A-DATA AX3U1333PB2G7-3P 6GB(3 x 2GB) DS - - 7-7-7-20 1.65-
1.85
• •
CORSAIR TR3X3G1333C9 (Ver2.1) 3GB(3 x 1GB) SS - - 9-9-9-24 1.5 • •
CORSAIR CM3X1024-1333C9DHX 1GB DS - - - 1.1 • •
CORSAIR “BoxP/N:TWIN3X2048-
1333C9
(CM3X1024-1333C9)Ver1.1”
2GB(2 x 1GB) DS - - 9-9-9-24 1.70 • •
CORSAIR CM3X2G1333C9 2GB DS - - 9-9-9-24 1.5 • •
CORSAIR “BoxP/N:
TW3X4G1333C9DHX
(CM3X2048-
1333C9DHX)Ver3.2”
4GB(2 x 2GB) DS - - 9-9-9-24 1.70 • •
CORSAIR TR3X6G1333C9 (Ver2.1) 6GB(3 x 2GB) DS - - 9-9-9-24 1.5 • •
CORSAIR CMX8GX3M4A1333C9 8GB(4 x 2GB) DS - - 9-9-9-24 1.5 • •
Crucial CT12864BA1339.8FF 1GB SS MICRON D9KPT 9 - • •
Crucial CT12864BA1339.8SFD 1GB SS MICRON MT8JF12864AY-1G4D1 - - • •
Crucial CT12872BA1339.9FF 1GB SS MICRON D9KPT(ECC) 9 - • •
Crucial BL25664BN1337.16FF(XMP) 2GB DS - - 7-7-7-24 1.65 • •
Crucial CT25664BA1339.16FF 2GB DS MICRON D9KPT 9 - • •
Crucial CT25664BA1339.16SFD 2GB DS MICRON D9JNM - - • •
Crucial CT25672BA1339.18FF 2GB DS MICRON D9KPT(ECC) 9 - • •
Crucial BL25664BA1336.16SFB1 4GB(2 x 2GB) DS NA - 6-6-6-20 1.8 • •
ELPIDA EBJ10UE8BAW0-DJ-E 1GB SS ELPIDA J1108BABG-DJ-E 9 - • •
ELPIDA EBJ10UE8BDF0-DJ-F 1GB SS ELPIDA J1108BDSE-DJ-F - - • •
ELPIDA EBJ10UE8EDF0-DJ-F 1GB SS ELPIDA J1108EDSE-DJ-F - - • •
ELPIDA EBJ21UE8BAW0-DJ-E 2GB DS ELPIDA J1108BABG-DJ-E 9 - • •
ELPIDA EBJ21UE8BDF0-DJ-F 2GB DS ELPIDA J1108BDSE-DJ-F - - • •
ELPIDA EBJ21UE8EDF0-DJ-F 2GB DS ELPIDA J1108EDSE-DJ-F - - • •
G.SKILL F3-10600CL7D-2GBPI 2GB(2 x 1GB) SS - - - 1.65 • •
G.SKILL F3-10600CL8D-2GBHK 2GB(2 x 1GB) SS - - - 1.65 • •
G.SKILL F3-10666CL7T-
6GBPK(XMP)
2GB DS - - 7-7-7-18 1.5-1.6 • •
G.SKILL F3-10666CL7D-
4GBPI(XMP)
4GB(2 x 2GB) DS - - 7-7-7-21 1.5 • •
G.SKILL F3-10666CL7D-
4GBRH(XMP)
4GB(2 x 2GB) DS - - 7-7-7-21 1.5 • •
G.SKILL F3-10666CL8D-
4GBHK(XMP)
4GB(2 x 2GB) DS - - 8-8-8-21 1.5-1.6 • •
G.SKILL F3-10666CL8D-
4GBRM(XMP)
4GB(2 x 2GB) DS - - 8-8-8-21 1.5-1.6 • •

1-10 Chapter 1: System introduction
DDR3-1333MHz capability
Vendor Part No. Size SS/
DS Chip Brand Chip No. Timing Voltage
DIMM
support
A* B*
G.SKILL F3-10666CL9T-6GBNQ 6GB(3 x 2GB) DS - - 9-9-9-24 1.5 • •
GEIL GG34GB1333C9DC 4GB(2 x 2GB) DS GEIL GL1L128M88BA12N 9-9-9-24 1.3 • •
GEIL GV34GB1333C7DC 4GB(2 x 2GB) DS - - 7-7-7-24 1.5 • •
Hynix HMT112U6BFR8C-H9 1GB SS Hynix H5TQ1G83BFR 9 - •
Hynix HMT125U6BFR8C-H9 2GB DS Hynix H5TQ1G83BFR 9 - • •
Hynix HMT125U6BFR8C-H9 2GB DS Hynix H5TQ1G83BFRH9C 9 - • •
KINGSTON KVR1333D3N9/2G 2GB DS Qimonda IDSH1G-03A1F1C-13H 9 1.5 • •
KINGSTON KVR1333D3N9/4G 4GB DS SAMSUNG K4B2G0846B-HCH9 9 1.5 • •
MICRON MT8JTF12864AZ-1G4F1 1GB SS MICRON 9FF22 D9KPT 9 - • •
MICRON MT8JTF12864AZ-1G4F1 1GB SS MICRON D9KPT 9 - • •
MICRON MT9JSF12872AZ-1G4F1 1GB SS MICRON D9KPT(ECC) 9 - • •
MICRON MT16JF25664AZ-1G4F1 2GB DS MICRON D9KPT 9 - • •
MICRON MT16JTF25664AZ-1G4F1 2GB DS MICRON 9FF22 D9KPT 9 - • •
MICRON MT18JSF25672AZ-1G4F1 2GB DS MICRON D9KPT(ECC) 9 - • •
OCZ OCZ3RPX1333EB2GK 2GB(2 x 1GB) SS NANYA - 6-5-5 1.85 • •
OCZ OCZ3G1333LV3GK 3GB(3 x 1GB) SS - - 9-9-9 1.65 • •
OCZ OCZ3P1333LV3GK 3GB(3 x 1GB) SS - - 7-7-7 1.65 • •
OCZ OCZ3P13332GK 1GB DS - - 7-7-7-20 - • •
OCZ OCZ3G13334GK 4GB(2 x 2GB) DS - - 9 1.7 • •
OCZ OCZ3G1333ULV4GK 4GB(2 x 2GB) DS - - 8-8-8 1.65 •
OCZ OCZ3G1333LV6GK 6GB(3 x 2GB) DS - - 9-9-9 1.65 • •
OCZ OCZ3P1333LV6GK 6GB(3 x 2GB) DS - - 7-7-7 1.65 • •
OCZ OCZX1333LV6GK(XMP) 6GB(3 x 2GB) DS NA - 8-8-8 1.6 • •
PSC AL7F8G73D-DG1 1GB SS PSC A3P1GF3DGF - - • •
PSC AL8F8G73D-DG1 2GB DS PSC A3P1GF3DGF - - • •
SAMSUNG M378B2873DZ1-CH9 1GB SS SAMSUNG K4B1G0846D 9 - • •
SAMSUNG M378B2873EH1-CH9 1GB SS SAMSUNG K4B1G0846E - - • •
SAMSUNG M391B2873DZ1-CH9 1GB SS SAMSUNG K4B1G0846D(ECC) 9 - • •
SAMSUNG M378B5673DZ1-CH9 2GB DS SAMSUNG K4B1G0846D 9 - • •
SAMSUNG M378B5673EH1-CH9 2GB DS SAMSUNG K4B1G0846E - - • •
SAMSUNG M391B5673DZ1-CH9 2GB DS SAMSUNG K4B1G0846D(ECC) 9 - • •
SAMSUNG M378B5273BH1-CH9 4GB DS SAMSUNG K4B2G0846B-HCH9 9 - • •
Super Talent W1333UX2GB(XMP) 2GB(2 x 1GB) SS - - 8 1.8 • •
Transcend TS128MLK64V3U 1GB SS SAMSUNG K4B1G0846D 9 - • •
Transcend TS256MLK64V3U 2GB DS SAMSUNG K4B1G0846D 9 - • •
Asint SLY3128M8-EDJ 1GB SS Asint DDRIII1208-DJ - - • •
Asint SLY3128M8-EDJE 1GB SS ELPIDA J1108BASE-DJ-E - - • •
Asint SLZ3128M8-EDJ 2GB DS Asint DDRIII1208-DJ - - • •
Asint SLZ3128M8-EDJE 2GB DS ELPIDA J1108BASE-DJ-E - - • •
ASUS N/A 1GB DS - - - - • •
ATP AQ28M64A8BJH9S 1GB SS SAMSUNG K4B1G0846E - - • •
ATP AQ28M72D8BJH9S 1GB SS SAMSUNG K4B1G0846D(ECC) - - • •
ATP AQ56M64B8BJH9S 2GB DS SAMSUNG K4B1G0846D - - • •
ATP AQ56M72E8BJH9S 2GB DS SAMSUNG K4B1G0846D(ECC) - - • •
BUFFALO FSX1333D3G-1G 1GB SS - - - - • •
BUFFALO FSH1333D3G-T3G(XMP) 3GB(3 x 1GB) SS - - 7-7-7-20 - • •
