Asus ZenBook UX334F User manual

E15265
First Edition / May 2019
User Guide
E15265_UX334_434_534_UM_16pages.indd 1 2019/5/20 �� 04:19:37

2
Notebook PC User Guide
NOTE: The keyboard's layout may vary per region or country. The top view may also
vary in appearance depending on the Notebook PC model.
Top View
Touchpad/
Touch numeric keypad
(on selected models)/
Screenpad
Camera/IR Camera
Array microphones
Display panel
Keyboard
Power button
Power indicator
13” model
Capital lock indicator
Function key lock indicator
E15265_UX334_434_534_UM_16pages.indd 2 2019/5/20 �� 04:19:37

Notebook PC User Guide
3
14” model
Camera/IR Camera
Array microphones
Display panel
Keyboard
Power button
Power indicator
Capital lock indicator
Function key lock indicator
Touchpad/
Touch numeric keypad
(on selected models)/
Screenpad
E15265_UX334_434_534_UM_16pages.indd 3 2019/5/20 �� 04:19:37

4
Notebook PC User Guide
15” model
Touchpad/Screenpad
Camera/IR Camera
Array microphones
Display panel
Keyboard
Power button
Power indicator
Capital lock indicator
Function key lock indicator
Numeric keypad
E15265_UX334_434_534_UM_16pages.indd 4 2019/5/20 �� 04:19:38

Notebook PC User Guide
5
I/O ports and slots
Headphone/Headset/Microphone jack HDMI port
USB 2.0 port USB 3.1 Gen 2 port
MicroSD card slot USB 3.1 Gen 2 Type-C™ port
Power (DC) input port
13” model
14” model
Memory card reader HDMI port
USB 3.1 Gen 2 Type-C™/
DisplayPort* combo port Power (DC) input port
USB 3.1 Gen 2 port USB 3.1 Gen 1 port
Headphone/Headset/Microphone jack
15” model
* On selected models
E15265_UX334_434_534_UM_16pages.indd 5 2019/5/20 �� 04:19:39

6
Notebook PC User Guide
Getting started
1. Charge your Notebook PC
A. Connect the DC power connector into your Notebook PC’s power (DC) input port.
B. Plug the AC power adapter into a 100V~240V power source.
2. Lift to open the display panel
3. Press the power button
NOTE: The power adapter may vary in appearance, depending on models and your
region.
Charge the Notebook PC
for 3 hours before using
it in battery mode for the
rst time.
IMPORTANT! Use only the bundled power adapter to charge the battery pack and
supply power to your Notebook PC.
E15265_UX334_434_534_UM_16pages.indd 6 2019/5/20 �� 04:19:39

Notebook PC User Guide
7
WARNING!
The bottom of the Notebook PC can get warm to hot while in use or while charging the battery
pack. When working on your Notebook PC, do not place it on surfaces that can block the vents.
CAUTION!
• ThisNotebookPCshouldonlybeusedinenvironmentswithambienttemperaturesbetween
5°C (41°F) and 35°C (95°F).
• RefertotheratinglabelonthebottomofyourNotebookPCandensurethatyourpower
adapter complies with this rating.
• Thepoweradaptermaybecomewarmtohotwhileinuse.Donotcovertheadapterandkeep
it away from your body while it is connected to a power source.
IMPORTANT!
• EnsurethatyourNotebookPCisconnectedtoagroundedpoweradapterbeforeturningit
on for the rst time.
• WhenusingyourNotebookPConpoweradaptermode,thesocketoutletmustbeneartothe
unit and easily accessible.
• Locatetheinput/outputratinglabelonyourNotebookPCandensurethatitmatchesthe
input/output rating information on your power adapter. Some Notebook PC models may
have multiple rating output currents based on the available SKU.
• Poweradapterinformation:
 -Inputvoltage:100-240Vac
 -Inputfrequency:50-60Hz
 -Ratingoutputcurrent:13”/14”:3.42A(65W)
15”:3.42A(65W)UMA/6A(120W)dGPU
 -Ratingoutputvoltage:13”/14”:19V
15”:19V/20V
Safety notices for your Notebook PC
WARNING!
ReadthefollowingprecautionsforyourNotebookPC’sbattery:
• OnlyASUS-authorizedtechniciansshould
remove the battery inside the device
(for non-removable battery only).
• Thebatteryusedinthisdevicemaypresent
a risk of re or chemical burn if removed or
disassembled.
• Followthewarninglabelsforyourpersonal
safety.
• Riskofexplosionifbatteryisreplacedbyan
incorrect type.
• Donotdisposeofinre.
• Neverattempttoshort-circuityour
Notebook PC’s battery.
• Neverattempttodisassembleand
reassemble the battery
(for non-removable battery only).
• Discontinueusageifleakageisfound.
• Thisbatteryanditscomponentsmustbe
recycled or disposed of properly.
• Keepthebatteryandothersmall
components away from children.
E15265_UX334_434_534_UM_16pages.indd 7 2019/5/20 �� 04:19:39

8
Notebook PC User Guide
Avis concernant les batteries remplaçables
• Labatteriedel’appareilpeutprésenterunrisqued’incendieoudebrûluresicelle-ciest
retiréeoudésassemblée.
• Labatterieetsescomposantsdoiventêtrerecyclésdefaçonappropriée.
Copyright Information
You acknowledge that all rights of this Manual remain with ASUS. Any and all rights, including without
limitation,intheManualorwebsite,areandshallremaintheexclusivepropertyofASUSand/orits
licensors. Nothing in this Manual intends to transfer any such rights, or to vest any such rights to you.
ASUSPROVIDESTHISMANUAL“ASIS”WITHOUTWARRANTYOFANYKIND.SPECIFICATIONSAND
INFORMATIONCONTAINEDINTHISMANUALAREFURNISHEDFORINFORMATIONALUSEONLY,AND
ARESUBJECTTOCHANGEATANYTIMEWITHOUTNOTICE,ANDSHOULDNOTBECONSTRUEDASA
COMMITMENTBYASUS.
Copyright © 2019 ASUSTeK COMPUTER INC. All Rights Reserved.
Limitation of Liability
Circumstances may arise where because of a default on ASUS’part or other liability, you are entitled to
recover damages from ASUS. In each such instance, regardless of the basis on which you are entitled to
claim damages from ASUS, ASUS is liable for no more than damages for bodily injury (including death)
and damage to real property and tangible personal property; or any other actual and direct damages
resulted from omission or failure of performing legal duties under this Warranty Statement, up to the
listed contract price of each product.
ASUS will only be responsible for or indemnify you for loss, damages or claims based in contract, tort or
infringement under this Warranty Statement.
ThislimitalsoappliestoASUS’suppliersanditsreseller.ItisthemaximumforwhichASUS,itssuppliers,
and your reseller are collectively responsible.
UNDERNOCIRCUMSTANCESISASUSLIABLEFORANYOFTHEFOLLOWING:(1)THIRD-PARTYCLAIMS
AGAINSTYOUFORDAMAGES;(2)LOSSOF,ORDAMAGETO,YOURRECORDSORDATA;OR(3)SPECIAL,
INCIDENTAL,ORINDIRECTDAMAGESORFORANYECONOMICCONSEQUENTIALDAMAGES(INCLUDING
LOSTPROFITSORSAVINGS),EVENIFASUS,ITSSUPPLIERSORYOURRESELLERISINFORMEDOFTHEIR
POSSIBILITY.
Service and Support
ForcompleteE-Manualversion,refertoourmulti-languagewebsiteat:
https://www.asus.com/support/
E15265_UX334_434_534_UM_16pages.indd 8 2019/5/20 �� 04:19:39

Notebook PC User Guide
9
FCC Radio Frequency (RF) Exposure Caution
Statement
WARNING!Anychangesormodicationsnotexpresslyapprovedbytheparty
responsible for compliance could void the user’s authority to operate this equipment.
ThisequipmentcomplieswithFCCradiationexposurelimitssetforthforanuncontrolled
environment.TomaintaincompliancewithFCCRFexposurecompliancerequirements,please
avoid direct contact to the transmitting antenna during transmitting. End users must follow the
specicoperatinginstructionsforsatisfyingRFexposurecompliance.
RF Exposure Information (SAR)
Thisdevicemeetsthegovernment’srequirementsforexposuretoradiowaves.Thisdeviceis
designedandmanufacturednottoexceedtheemissionlimitsforexposuretoradiofrequency
(RF) energy set by the Federal Communications Commission of the U.S. Government.
TheexposurestandardforwirelessdeviceemploysaunitofmeasurementknownastheSpecic
Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg. Tests for SAR are conducted
using standard operating positions accepted by the FCC with the device transmitting at its
highest certied power level in all tested frequency bands.
Power Safety Requirement
Products with electrical current ratings up to 6A and weighing more than 3Kg must use
approvedpowercordsgreaterthanorequalto:H05VV-F,3G,0.75mm2or H05VV-F, 2G, 0.75mm2.
E15265_UX334_434_534_UM_16pages.indd 9 2019/5/20 �� 04:19:39

10
Notebook PC User Guide
UL Safety Notices
• DONOTusetheNotebookPCnearwater,forexample,nearabathtub,washbowl,kitchen
sink or laundry tub, in a wet basement or near a swimming pool.
• DONOTusetheNotebookPCduringanelectricalstorm.Theremaybearemoteriskof
electric shock from lightning.
• DONOTusetheNotebookPCinthevicinityofagasleak.
• DONOTdisposetheNotebookPCbatterypackinare,astheymayexplode.Checkwithlocal
codes for possible special disposal instructions to reduce the risk of injury to persons due to
reorexplosion.
• DONOTusepoweradaptersorbatteriesfromotherdevicestoreducetheriskofinjuryto
personsduetoreorexplosion.UseonlyULcertiedpoweradaptersorbatteriessupplied
bythemanufacturerorauthorizedretailers.
Global Environmental Regulation Compliance and
Declaration
ASUS follows the green design concept to design and manufacture our products, and
makes sure that each stage of the product life cycle of ASUS product is in line with global
environmental regulations. In addition, ASUS disclose the relevant information based on
regulation requirements.
Please refer to http://csr.asus.com/english/Compliance.htm for information disclosure based on
regulationrequirementsASUSiscompliedwith:Japan JIS-C-0950 Material Declarations, EU
REACH SVHC, Korea RoHS
Coating Notice
IMPORTANT! To provide electrical insulation and maintain electrical safety, a coating
isappliedtoinsulatethedeviceexceptontheareaswheretheI/Oportsarelocated.
E15265_UX334_434_534_UM_16pages.indd 10 2019/5/20 �� 04:19:39

Notebook PC User Guide
11
ASUS Recycling/Takeback Services
ASUS recycling and takeback programs come from our commitment to the highest standards for
protecting our environment. We believe in providing solutions for you to be able to responsibly
recycle our products, batteries, other components as well as the packaging materials. Please
go to http://csr.asus.com/english/Takeback.htm for detailed recycling information in dierent
regions.
Regional notice for Singapore
This ASUS product complies with IMDA Standards.
Complies with
IMDA Standards
DB103778
WARNING
Cancer and Reproductive Harm -
www.P65Warnings.ca.gov
Regional notice for California
E15265_UX334_434_534_UM_16pages.indd 11 2019/5/20 �� 04:19:39

12
Notebook PC User Guide
Regional notice for India
Thisproductcomplieswiththe“IndiaE-Waste(Management)Rules,2016”andprohibitsuseof
lead,mercury,hexavalentchromium,polybrominatedbiphenyls(PBBs)andpolybrominated
diphenylethers(PBDEs)inconcentrationsexceeding0.1%byweightinhomogenousmaterials
and0.01%byweightinhomogenousmaterialsforcadmium,exceptfortheexemptionslisted
in Schedule II of the Rule.
REACH
ComplyingwiththeREACH(Registration,Evaluation,Authorization,andRestrictionof
Chemicals) regulatory framework, we publish the chemical substances in our products at ASUS
REACH website at http://csr.asus.com/english/REACH.htm.
Prevention of Hearing Loss
To prevent possible hearing damage, do not listen at high volume levels for long
periods.
E15265_UX334_434_534_UM_16pages.indd 12 2019/5/20 �� 04:19:40

Notebook PC User Guide
13
Simplied EU Declaration of Conformity
ASUSTek Computer Inc. hereby declares that this device is in compliance with the essential
requirementsandotherrelevantprovisionsofDirective2014/53/EU.FulltextofEUdeclaration
of conformity is available at https://www.asus.com/support/.
TheWiFioperatingintheband5150-5350MHzshallberestrictedtoindooruseforcountries
listedinthetablebelow:
AT BE BG CZ DK EE FR
DE IS IE IT EL ES CY
LV LI LT LU HU MT NL
NO PL PT RO SI SK TR
FI SE CH UK HR
RF Exposure information (SAR)
ThisdevicemeetstheEUrequirements(2014/53/EU)onthelimitationofexposureofthe
general public to electromagnetic elds by way of health protection.
Thelimitsarepartofextensiverecommendationsfortheprotectionofthegeneralpublic.These
recommendationshavebeendevelopedandcheckedbyindependentscienticorganizations
through regular and thorough evaluations of scientic studies. The unit of measurement for the
EuropeanCouncil’srecommendedlimitformobiledevicesisthe“SpecicAbsorptionRate”(SAR),
and the SAR limit is 2.0 W/Kg averaged over 10 gram of body tissue. It meets the requirements
oftheInternationalCommissiononNon-IonizingRadiationProtection(ICNIRP).
Fornext-to-bodyoperation,thisdevicehasbeentestedandmeetstheICNIRPexposure
guidelines and the European Standard EN 50566 and EN 62209-2. SAR is measured with the
device directly contacted to the body while transmitting at the highest certied output power
level in all frequency bands of the mobile device.
A minimum separation distance of 1 cm must be maintained between the user’s body and the
device,includingtheantennaduringbody-wornoperationtocomplywiththeRFexposure
requirements in Europe.
E15265_UX334_434_534_UM_16pages.indd 13 2019/5/20 �� 04:19:40

14
Notebook PC User Guide
Federal Communications Commission Interference
Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment o and on, the user is encouraged to try to correct the interference by one or
moreofthefollowingmeasures:
• Reorientorrelocatethereceivingantenna.
• Increasetheseparationbetweentheequipmentandreceiver.
• Connecttheequipmentintoanoutletonacircuitdierentfromthattowhichthereceiveris
connected.
• Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
FCC COMPLIANCE INFORMATION
Per FCC Part 2 Section 2.1077
Responsible Party:
Asus Computer International
Address: 48720 Kato Rd., Fremont,CA 94538
Phone/Fax No: [phone]/[phone]
hereby declares that the product
Product Name :
ZenBook
Model Number : UX334F, U3600F, BX334F, UX434F, U4600F, BX434F,
UX534F, BX534F
compliance statement:
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Ver. 180125
E15265_UX334_434_534_UM_16pages.indd 14 2019/5/20 �� 04:19:40

Notebook PC User Guide
15
RED RF Output table
Function Frequency Maximum Output Power (EIRP)
WiFi
2412-2472MHz 15 dBm
5150-5350MHz 16 dBm
5470-5725MHz 15 dBm
5725-5850MHz 8 dBm
Bluetooth 2402-2480MHz 8 dBm
15” model
Function Frequency Maximum Output Power (EIRP)
WiFi
2412-2472MHz 12 dBm
5150-5350MHz 18 dBm
5470-5725MHz 20 dBm
5725-5850MHz 10 dBm
Bluetooth 2402-2480MHz 7 dBm
ForthestandardEN300440V2.1.1,ifthisdeviceoperatesin5725-5875MHz,itwillbe
considered as a receiver category 2.
14” model
Function Frequency Maximum Output Power (EIRP)
WiFi
2412-2472MHz 14 dBm
5150-5350MHz 13 dBm
5470-5725MHz 13 dBm
5725-5850MHz 6 dBm
Bluetooth 2402-2480MHz 10 dBm
13” model
E15265_UX334_434_534_UM_16pages.indd 15 2019/5/20 �� 04:19:40

16
Notebook PC User Guide
E15265_UX334_434_534_UM_16pages.indd 16 2019/5/20 �� 04:19:40
