Asus PA329CV Series User manual

PA329CV Series
LCD Monitor
User Guide
Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Asus ProArt
PA329CV o cerca il tuo prodotto tra le migliori offerte di Monitor

ii
Copyright © 2020 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means, except documentation kept by the purchaser for backup purposes, without the express written
permission of ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless
such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identication or explanation and to the
owners’ benet, without intent to infringe.
Table of contents
TCO Certied............................................................................................... iii
Notices......................................................................................................... iv
Safety information ...................................................................................... vi
Care & Cleaning........................................................................................... x
1.1 Welcome! ...................................................................................... 1-1
1.2 Package contents......................................................................... 1-1
1.3 Assembling the monitor.............................................................. 1-2
1.4 Assembling the C-Clamp ............................................................ 1-3
1.5 Connect cables............................................................................. 1-4
1.5.1 Rear of the LCD monitor ................................................. 1-4
1.6 Monitor introduction .................................................................... 1-5
1.6.1 Using the Controls button .............................................. 1-5
2.1 Adjusting the monitor.................................................................. 2-1
2.2 Detaching the arm/stand (for VESA wall mount) ...................... 2-2
2.3 Outline dimension........................................................................ 2-3
3.1 OSD (On-Screen Display) menu ................................................. 3-1
3.1.1 Howtorecongure.......................................................... 3-1
3.1.2 OSD Function Introduction.............................................. 3-2
3.2 Specications............................................................................. 3-12
3.3 Troubleshooting (FAQ).............................................................. 3-13
3.4 Supported Timing List ............................................................... 3-14

iii
TCO Certied
A third-party certification according to ISO 14024
Say hello
to a more sustainable product
IT products are associated with a wide range of sustainability risks
throughout their life cycle. Human rights violations are common in the
factories. Harmful substances are used both in products and their
manufacture. Products can often have a short lifespan because of poor
ergonomics, low quality and when they are not able to be repaired or
upgraded.
This product is a better choice. It meets all the criteria in TCO Certified,
the world’s most comprehensive sustainability certification for IT
products. Thank you for making a responsible product choice, that help
drive progress towards a more sustainable future!
Criteria in TCO Certified have a life-cycle perspective and balance
environmental and social responsibility. Conformity is verified by
independent and approved verifiers that specialize in IT products, social
responsibility or other sustainability issues. Verification is done both
before and after the certificate is issued, covering the entire validity
period. The process also includes ensuring that corrective actions are
implemented in all cases of factory non-conformities. And last but not
least, to make sure that the certification and independent verification is
accurate, both TCO Certified and the verifiers are reviewed regularly.
Want to know more?
Read information about TCO Certified, full criteria documents, news and
updates at tcocertified.com. On the website you’ll also find our Product
Finder, which presents a complete, searchable listing of certified
products.
Toward sustainable IT products

iv
Notices
Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance
with manufacturer’s instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
NOTE:ThismonitorisENERGYSTARcertied.
ThisproductqualiesforENERGYSTAR®in the factory
default(Homeconguration)setting.Changingthefactory
default settings or enabling other features may increase
power consumption that could exceed the limits necessary
toqualifyforENERGYSTAR®.RefertoENERGYSTAR.gov
(www.energystar.gov)formoreinformationontheENERGY
STAR®program.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for radio
noise emissions from digital apparatus set out in the Radio Interference
Regulations of the Canadian Department of Communications.
ThisclassBdigitalapparatuscomplieswithCanadianICES-003.

v
The device may fall, causing serious personal injury or death. To prevent
injury,thisdevicemustbesecurelyattachedtotheoor/wallinaccordance
with the installation instructions.

vi
Safety information
• Before setting up the monitor, carefully read all the documentation that
came with the package.
• To prevent fire or shock hazard, never expose the monitor to rain or
moisture.
• Nevertrytoopenthemonitorcabinet.Thedangeroushighvoltages
inside the monitor may result in serious physical injury.
• If the power supply is broken, do not try to fix it by yourself. Contact a
qualified service technician or your retailer.
• Before using the product, make sure all cables are correctly connected
and the power cables are not damaged. If you detect any damage,
contact your dealer immediately.
• Slots and openings on the back or top of the cabinet are provided for
ventilation.Donotblocktheseslots.Neverplacethisproductnearor
over a radiator or heat source unless proper ventilation is provided.
• The monitor should be operated only from the type of power source
indicated on the label. If you are not sure of the type of power supply to
your home, consult your dealer or local power company.
• Use the appropriate power plug which complies with your local power
standard.
• Do not overload power strips and extension cords. Overloading can
result in fire or electric shock.
• Avoiddust,humidity,andtemperatureextremes.Donotplacethe
monitor in any area where it may become wet. Place the monitor on a
stable surface.
• Unplug the unit during a lightning storm or if it will not be used for a
long period of time. This will protect the monitor from damage due to
power surges.
• Neverpushobjectsorspillliquidofanykindintotheslotsonthe
monitor cabinet.
• To ensure satisfactory operation, use the monitor only with UL listed
computers which have appropriate configured receptacles marked
between100~240VAC.
• The socket-outlet shall be installed near the equipment and shall be
easily accessible
• If you encounter technical problems with the monitor, contact a
qualified service technician or your retailer.
• Provide an earthing connection before the mains plug is connected to
themains.And,whendisconnectingtheearthingconnection,besure
to disconnect after pulling out the mains plug from the mains.

vii
WARNING
Usageofotherthanspeciedhead-orearphonescanresultinhearing
loss due to excessive sound pressures.
Pleaseconrmthedistributionsysteminbuildinginstallationshallprovide
thecircuitbreakerrated120/240V,20A(maximum).
If provided with a 3-pin attachment plug on the power cord, plug the cord
intoagrounded(earthed)3-pinoutlet.Donotdisablethepowercord
grounding pin, for example, by attaching a 2-pin adapter. The grounding
pin is an important safety feature.
Stability Hazard.
The product may fall, causing serious personal injury or death. To
preventinjury,thisproductmustbesecurelyattachedtotheoor/wallin
accordance with the installation instructions.
Aproductmayfall,causingseriouspersonalinjuryordeath.Manyinjuries,
particularly to children, can be avoided by taking simple precautions such
as:
ALWAYSusecabinetsorstandsorinstallationmethodsrecommendedby
the manufacturer of the product set.
ALWAYSusefurniturethatcansafelysupporttheproduct.
ALWAYSensuretheproductisnotoverhangingtheedgeofthesupporting
furniture.
ALWAYSeducatechildrenaboutthedangersofclimbingonfurnitureto
reach the product or its controls.
ALWAYSroutecordsandcablesconnectedtoyourproductsotheycannot
be tripped over, pulled or grabbed.
NEVERplaceaproductinanunstablelocation.
NEVERplacetheproductontallfurniture(forexample,cupboardsor
bookcases)withoutanchoringboththefurnitureandtheproducttoa
suitable support.
NEVERplacetheproductonclothorothermaterialsthatmaybelocated
between the product and supporting furniture.
NEVERplaceitemsthatmighttemptchildrentoclimb,suchastoysand
remote controls, on the top of the product or furniture on which the product
is placed.
If the existing product is going to be retained and relocated, the same
considerations as above should be applied.

viii
Excessivesoundpressurefromearphonesandheadphonescancause
hearingloss.Adjustmentoftheequalizertomaximumincreasesthe
earphones and headphones output voltage and therefore the sound
pressure level.
1. Do not dispose of electrical appliances as unsorted
municipal waste, use separate collection facilities.
2. Contact your local government for information regarding the
collection systems available.
3.Ifelectricalappliancesaredisposedofinlandllsordumps,
hazardous substances can leak into the groundwater and get
into the food chain, damaging your health and well-being.
4.Whenreplacingoldapplianceswithnewonce,theretaileris
legally obligated to take back your old appliance for disposal
at least for free of charge.
Excessivesoundpressurefromearphonesandheadphonescancause
hearingloss.Adjustmentoftheequalizertomaximumincreasesthe
earphones and headphones output voltage and therefore the sound
pressure level.
Do not dispose of electrical appliances as unsorted municipal waste, use
separate collection facilities.
Contact your local government for information regarding the collection
systems available.
Ifelectricalappliancesaredisposedofinlandllsordumps,hazardous
substances can leak into the groundwater and get into the food chain,
damaging your health and well-being.
Whenreplacingoldapplianceswithnewonce,theretailerislegally
obligated to take back your old appliance for disposal at least for free of
charge.

ix
Prevent Tipping
Whenusingthedisplay,fastentheLCDtoawallusingacordorchainthatcan
support the weight of the monitor in order to prevent the monitor from falling.
Cord or chain
M4 or M6 Screw
Cord
1
2
• Display design may differ from those illustrated.
• Installing must be done by a qualified technician , and please
contact your supplier for more information.
• FortheModelswithnetweight>=7kg.Pleaseselectthesuitable
way to Prevent Tipping.
• ForthemodelswithVESAMount,pleaseusemethod , install
thescrewswithringtotheVESAMounthole,thentiethecord
or chain to the wall. Otherwise, please use method to tie the
cord or chain to the stand and then fix it to the wall.

x
Care & Cleaning
• Before you lift or reposition your monitor, it is better to disconnect the
cables and power cord. Follow the correct lifting techniques when
positioningthemonitor.Whenliftingorcarryingthemonitor,graspthe
edges of the monitor. Do not lift the display by the stand or the cord.
• Cleaning. Turn your monitor off and unplug the power cord. Clean the
monitor surface with a lint-free, non-abrasive cloth. Stubborn stains
may be removed with a cloth dampened with mild cleaner.
• Avoidusingacleanercontainingalcoholoracetone.Useacleaner
intendedforusewiththeLCD.Neverspraycleanerdirectlyonthe
screen, as it may drip inside the monitor and cause an electric shock.
The following symptoms are normal with the monitor:
• The screen may flicker during the initial use due to the nature of the
fluorescent light. Turn off the Power Switch and turn it on again to
make sure that the flicker disappears.
• Youmayfindslightlyunevenbrightnessonthescreendependingon
the desktop pattern you use.
• Whenthesameimageisdisplayedforhours,anafterimageofthe
previous screen may remain after switching the image. The screen will
recover slowly or you can turn off the Power Switch for hours.
• Whenthescreenbecomesblackorflashes,orcannotworkanymore,
contact your dealer or service center to fix it. Do not repair the screen
by yourself!
Conventions used in this guide
WARNING:Informationtopreventinjurytoyourselfwhentryingto
complete a task.
CAUTION:Informationtopreventdamagetothecomponents
when trying to complete a task.
IMPORTANT:InformationthatyouMUSTfollowtocompletea
task.
NOTE:Tipsandadditionalinformationtoaidincompletingatask.

xi
Wheretondmoreinformation
Refer to the following sources for additional information and for product
and software updates.
1. ASUS websites
TheASUSwebsitesworldwideprovideupdatedinformationonASUS
hardware and software products. Refer to http://www.asus.com
2. Optional documentation
Yourproductpackagemayincludeoptionaldocumentationthatmay
have been added by your dealer. These documents are not part of
the standard package.
Takeback Services
ASUSrecyclingandtakebackprogramscomefromourcommitmenttothe
higheststandardsforprotectingourenvironment.Webelieveinproviding
solutions for our customers to be able to responsibly recycle our products,
batteries and other components as well as the packaging materials.
Please go to http://csr.asus.com/english/Takeback.htm for detail recycling
information in different region.

1-1
ASUS LCD Monitor PA329 Series
1.1 Welcome!
ThankyouforpurchasingtheASUS®LCD monitor!
ThelatestwidescreenLCDmonitorfromASUSprovidesacrisper,
broader, and brighter display, plus a host of features that enhance your
viewing experience.
Withthesefeatures,youcanenjoytheconvenienceanddelightfulvisual
experience that the monitor brings you!
1.2 Package contents
Check your package for the following items:
 LCDMonitor
Stand/Base
 QuickStartGuide
 WarrantyCard
 1xUSBType-CCable(optional)
1x Power Cord
 1xHDMICable(optional)
 1xDPCable(optional)
Color calibration testing report
 ProArtwelcomecard
C-Clamp
• If any of the above items is damaged or missing, contact your retailer
immediately.
• * AlsotheReplaceablepartsrequiredbytheTCOCertified.

1-2 Chapter 1: Product Introduction
1.3 Assembling the monitor
To assemble the monitor:
1. Insertthestandintothemonitorhead,Alignthescrewholeonthearm
with the bundled screw on the base. Then insert the base into the
arm.
2. Fix the base to the arm by fastening the bundled screw.
*Basescrewsize:M6x17mm

1-3
ASUS LCD Monitor PA329 Series
1.4 Assembling the C-Clamp
1. The C-Clamp attaches the monitor to surfaces up to 8cm
thick, Before starting, make sure you have enough room
tottheentireclampandthesurfacesissturdyandat.
2. Follow the illustrations below to mount the monitor.
123
456

1-4 Chapter 1: Product Introduction
1.5 Connect cables
1.5.1 Rear of the LCD monitor
5V 1.5A 5V 1.5A
1 2 3 4 5 6 7 8 9
10
11
20V 4.5A
5V 0.9A 5V 0.9A
1. AC-INPort
2. Power Switch
3. HDMI1Port
4. HDMI2Port
5. DP - in Port
6. USB3.1 Type-C
7. Earphone-outPort
8. USB3.1TypeA
9. USB3.1TypeA
10. USB3.1TypeA
11. USB3.1TypeA
ThismonitorisSuper-SpeedUSB3.1compatible(5Gbps).Theportoffers
Max.65Wpowerdeliverywithoutputvoltage5V/3A,9V/3A,12V/3A,
15V/3Aand20V/3.25A.ConnectingtheUSBType-Ccablecaninput
theDisplayPortsource,outputpowerandenabletheUSBType-Aports
(downstream)onthemonitor.ConnectingtheUSBType-CtoType-A
cableonlyenablestheUSBType-Aports(downstream)onthemonitor.

1-5
ASUS LCD Monitor PA329 Series
1.6 Monitor introduction
1.6.1 Using the Controls button
Use the control button on the bottom of the monitor to adjust the image
settings.
1
25 4367
Menu
Exit
Brightness
Blue Light
Signal
Power
Preset
1. Menu(5-way)button:
• Press this button to enter the OSD menu.
• EnactstheselectedOSDmenuitems.
• Increases/Decreases values or moves your selection up/down/left/right.
2. Close Button:
• ExittheOSDmenu.
3. Shortcut 1:
• Default: Brightness hotkey
• Tochangethehotkeyfunction,gototheShortcut>Shortcut1menu.
4. Shortcut 2:
• Default: Blue light filter hotkey
• Tochangethehotkeyfunction,gototheShortcut>Shortcut2menu.
5. Input Select Button
• UsethishotkeytoswitchfromHDMI-1,HDMI-2,DisplayPort,USB
Tpye-C
6. ProArtPreset
• PressthisbuttontoselectProArtPresetmode.

1-6 Chapter 2: Setup
7. Power button/power indicator:
• Turns the monitor on/off.
• The color definition of the power indicator is as the below table.
Status Description
White ON
Amber Standby mode
OFF OFF

2-1
ASUS LCD Monitor PA329 Series
2.1 Adjusting the monitor
• For optimal viewing, we recommend that you look at the full face of the
monitor, then adjust the monitor to the angle that is most comfortable
for you.
• Hold the stand to prevent the monitor from falling
when you change its
angle.
• Youcanadjustthemonitor’sanglefrom+23˚to-5˚anditallows30˚
swivel adjustment from either left or right.
90°
90°
-5 ~ 23
-30° +30°
130mm

2-2 Chapter 2: Setup
2.2 Detaching the arm/stand (for VESA wall
mount)
ThedetachablestandofthismonitorisspeciallydesignedforVESAwall
mount.
To detach the arm/stand
1. Disconnect power and signal cables. Carefully put the monitor
facedownonitsEPSpackaging.
2. Press the quick release button from rear cover.
3. Detachthestand(armandbase)fromthemonitor.
• TheVESAwallmountkit(100x100mm)ispurchasedseparately.
• UseonlytheULListedWallMountBracketwithminimumweight/load28.8 kg
(Screwsize:M4x10mm).

2-3
ASUS LCD Monitor PA329 Series
2.3 Outline dimension
Unit: mm
