Asus VW197DR User manual

VW197 Series
LCD Monitor
User Guide
November
2011

ii
Copyright © 2011 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means, except documentation kept by the purchaser for backup purposes, without the express written
permission of ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless
such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identication or explanation and to the
owners’ benet, without intent to infringe.
Table of contents
Notices......................................................................................................... iii
Safety information ...................................................................................... iv
Care & Cleaning........................................................................................... v
1.1 Welcome! ...................................................................................... 1-1
1.2 Package contents......................................................................... 1-1
1.3 Assembling the monitor ............................................................. 1-2
1.4 Monitor introduction .................................................................... 1-3
1.4.1 Front of the LCD monitor.............................................. 1-3
1.4.2 Rear of the LCD monitor............................................... 1-5
1.4.3 WiringtocomplywithTCOCertied
(VW197TR/VW197NR/VW197SR/VW197DR)................1-6
2.1. Detaching the arm/stand
(for VESA wall mount) ................................................................. 2-1
2.2. Adjusting the monitor.................................................................. 2-2
3.1 OSD (On-Screen Display) menu ................................................. 3-1
3.1.1 Howtorecongure ....................................................... 3-1
3.1.2 OSD Function Introduction .......................................... 3-1
3.2 Specications............................................................................... 3-5
3.3 Troubleshooting (FAQ)................................................................ 3-6
3.4 Supported timing list ................................................................... 3-7

iii
Notices
Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance
with manufacturer’s instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
As an Energy Star® Partner, our company has determined
that this product meets the Energy Star® guidelines for
energyefciency.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for radio
noise emissions from digital apparatus set out in the Radio Interference
Regulations of the Canadian Department of Communications.
This class B digital apparatus complies with Canadian ICES-003.

iv
Safety information
• Before setting up the monitor, carefully read all the documentation that
came with the package.
• Topreventreorshockhazard,neverexposethemonitortorainor
moisture.
• Never try to open the monitor cabinet. The dangerous high voltages
inside the monitor may result in serious physical injury.
• Ifthepowersupplyisbroken,donottrytoxitbyyourself.Contacta
qualiedservicetechnicianoryourretailer.
• Before using the product, make sure all cables are correctly connected
and the power cables are not damaged. If you detect any damage,
contact your dealer immediately.
• Slots and openings on the back or top of the cabinet are provided for
ventilation. Do not block these slots. Never place this product near or
over a radiator or heat source unless proper ventilation is provided.
• The monitor should be operated only from the type of power source
indicated on the label. If you are not sure of the type of power supply to
your home, consult your dealer or local power company.
• Use the appropriate power plug which complies with your local power
standard.
• Do not overload power strips and extention cords. Overloading can
resultinreorelectricshock.
• Avoid dust, humidity, and temperature extremes. Do not place the
monitor in any area where it may become wet. Place the monitor on a
stable surface.
• Unplug the unit during a lightning storm or if it will not be used for a
long period of time. This will protect the monitor from damage due to
power surges.
• Never push objects or spill liquid of any kind into the slots on the
monitor cabinet.
• To ensure satisfactory operation, in case use at a PC then it should
use the monitor only with computers which have appropriate
conguredreceptaclesmarkedbetween100-240VAC.
• If you encounter technical problems with the monitor, contact a
qualiedservicetechnicianoryourretailer.
• The wall socket shall be installed near the equipment and shall be easily
accessible.

v
Care & Cleaning
• Before you lift or reposition your monitor, it is better to disconnect the cables
and power cord. Follow the correct lifting techniques when positioning the
monitor. When lifting or carrying the monitor, grasp the edges of the monitor.
Do not lift the display by the stand or the cord.
• Cleaning. Turn your monitor off and unplug the power cord. Clean the monitor
surface with a lint-free, non-abrasive cloth. Stubborn stains may be removed
with a cloth dampened with mild cleaner.
• Avoid using a cleaner containing alcohol or acetone. Use a cleaner intended
for use with the LCD. Never spray cleaner directly on the screen, as it may drip
inside the monitor and cause an electric shock.
The following symptoms are normal with the monitor:
• Thescreenmayickerduringtheinitialuseduetothenatureoftheuorescent
light. Turn off the Power Switch and turn it on again to make sure that the
ickerdisappears.
• Youmayndslightlyunevenbrightnessonthescreendependingonthe
desktop pattern you use.
• When the same image is displayed for hours, an afterimage of the previous
screen may remain after switching the image. The screen will recover slowly or
you can turn off the Power Switch for hours.
• Whenthescreenbecomesblackorashes,orcannotworkanymore,contact
yourdealerorservicecentertoxit.Donotrepairthescreenbyyourself!
Conventions used in this guide
WARNING: Information to prevent injury to yourself when trying to
complete a task.
CAUTION: Information to prevent damage to the components when
trying to complete a task.
IMPORTANT: Information that you MUST follow to complete a task.
NOTE: Tips and additional information to aid in completing a task.

vi
Wheretondmoreinformation
Refer to the following sources for additional information and for product and
software updates.
1. ASUS websites
The ASUS websites worldwide provide updated information on ASUS
hardware and software products. Refer to http://www.asus.com
2. Optional documentation
Your product package may include optional documentation that may have
been added by your dealer. These documents are not part of the standard
package.

1-1ASUS LCD Monitor VW197 Series
1.1 Welcome!
Thank you for purchasing the ASUS®VW197SeriesLCDmonitor!
The latest widescreen LCD monitor from ASUS provides a crisper, broader, and
brighter display, plus a host of features that enhance your viewing experience.
With these features, you can enjoy the convenience and delightful visual
experiencethattheVW197Seriesbringsyou!
1.2 Package contents
Check your VW197 Series LCD Monitor package for the following items:
9LCD monitor
9Monitor stand and base
9User manual CD
9Quick start guide
9Warranty card
9Power cord
9VGA cable
9Audio cable (VW197T/TR/S/SR)
9Cable holder (VW197TR/NR/SR/DR)
• If any of the above items is damaged or missing, contact your retailer
immediately.

1-2 Chapter 1: Product Introduction
1.3 Assembling the monitor
To assemble the monitor:
1. Have the front of the monitor face down on a table.
2. Insert the stand to the monitor which shows as below picture.
3. Connect the base with the monitor. A click indicates that the base has been
connected successfully.
4. Adjust the monitor to the angle that is most comfortable.
• We recommend that you cover the table surface with soft cloth to prevent
damage to the monitor.
12 3

1-3ASUS LCD Monitor VW197 Series
1.4 Monitor introduction
1.4.1 Front of the LCD monitor
1.4.1.1 VW197T/VW197TR/VW197S/VW197SR
5 6
1. Button:
• Automaticallyadjusttheimagetoitsoptimizedposition,clock,and
phasebylongpressingthisbuttonfor2-4seconds(forVGAmodeonly).
• Use this hot key to switch from six video preset modes (Scenery Mode,
Standard Mode, Theater Mode, Game Mode, Night View Mode, and
sRGB Mode) with SPLENDID™ Video Intelligence Technology.
• Exit the OSD menu or go back to the previous menu as the OSD menu
is active.
2. Button:
• Press this button to decrease the value of the function selected or move
to the next function.
• This is also a hot key for Volume adjustment.
3. MENU Button:
• Press this button to enter the OSD menu.
• Press this button to enter/select the icon (function) highlighted while the
OSD is activated.
4. Button:
• Press this button to increase the value of the function selected or move
right/up to the next function.
• This is also a hot key for Brightness adjustment.
5. Power Button:
• Press this button to turn the monitor on/off.

1-4 Chapter 1: Product Introduction
6. Power Indicator
• The color definition of the power indicator is as the below table.
Status Description
Blue ON
Amber Standby mode
OFF OFF
1.4.1.2 VW197N/VW197NR/VW197D/VW197DR
5 6
1. Button:
• Automaticallyadjusttheimagetoitsoptimizedposition,clock,and
phasebylongpressingthisbuttonfor2-4seconds(forVGAmodeonly).
• Use this hot key to switch from six video preset modes (Scenery Mode,
Standard Mode, Theater Mode, Game Mode, Night View Mode, and
sRGB Mode) with SPLENDID™ Video Intelligence Technology.
• Exit the OSD menu or go back to the previous menu as the OSD menu
is active.
2. Button:
• Press this button to decrease the value of the function selected or move
to the next function.
• This is also a hot key for Contrast adjustment.
3. MENU Button:
• Press this button to enter the OSD menu.
• Press this button to enter/select the icon (function) highlighted while the
OSD is activated.
4. Button:
• Press this button to increase the value of the function selected or move
right/up to the next function.
• This is also a hot key for Brightness adjustment.

1-5ASUS LCD Monitor VW197 Series
5. Power Button:
• Press this button to turn the monitor on/off.
6. Power Indicator
• The color definition of the power indicator is as the below table.
Status Description
Blue ON
Amber Standby mode
OFF OFF
1.4.2 Rear of the LCD monitor
1 AC-IN port
2 Audio Line-in port (VW197T/TR/S/SR)
3 DVI port (VW197T/TR/N/NR)
4 VGA port
5 Screw Holes for VESA Wall Mount

1-6 Chapter 1: Product Introduction
1.4.3 WiringtocomplywithTCOCertied(VW197TR/
VW197NR/VW197SR/VW197DR)
1. Connect the power cord and signal cable.
2. Tie the power cord and signal cable with cable holder.
• The location of holder should be about 10cm away from one end of the
power cord and cable.
10cm

2-1ASUS LCD Monitor VW197 Series
2.1. Detaching the arm/stand
(for VESA wall mount)
The detachable stand of the VW197 Series LCD monitor is specially designed for
VESA wall mount.
To detach the arm/stand:
1. Have the front of the monitor face down on a table.
2. Press the plastic release button on the rear of the monitor shows as below
picture.
3. Detach the stand from the monitor.
• We recommend that you cover the table surface with soft cloth to prevent
damage to the monitor.
• The VESA wall mount kit ( 100 x 100 mm) is purchased separately.

2-2 Chapter 2: Setup
2.2. Adjusting the monitor
• For optimal viewing, we recommend that you look at the full face of the
monitor, then adjust the monitor to the angle that is most comfortable for you.
• Hold the stand to prevent the monitor from falling while changing its angle.
• Youcanadjustthemonitor’sanglefrom-5˚to20˚.
-5 ~ 20

3-1ASUS LCD Monitor VW197 Series
3.1 OSD (On-Screen Display) menu
3.1.1 Howtorecongure
VW197
Splendid
Color
Input Select
Move Menu Exit
System Setup
Scenery Mode
Standard Mode
Theater Mode
Game Mode
Night View Mode
sRGB
1. Press the MENU button to activate the OSD menu.
2. Press and to navigate through the functions. Highlight and activate
the desired function by pressing the MENU button. If the function selected
has a sub-menu, press and again to navigate through the sub-menu
functions. Highlight and activate the desired sub-menu function by pressing
the MENU button.
3. Press and to change the settings of the selected function.
4. To exit the OSD menu, press the button. Repeat step 2 and step 3 to
adjust any other function.
3.1.2 OSD Function Introduction
1. Splendid
This function contains six sub-functions that you can select for your
preference. Each mode has the Reset selection, allowing you to maintain
your setting or return to the preset mode.
VW197
Splendid
Color
Input Select
Move Menu Exit
System Setup
Scenery Mode
Standard Mode
Theater Mode
Game Mode
Night View Mode
sRGB
• Scenery Mode: This is the best choice for scenery photo displaying with
SPLENDID™ Video Intelligence Technology.

3-2 Chapter 3: General Instruction
• Standard Mode: This is the best choice for document editing with
SPLENDID™ Video Intelligence Technology.
• Theater Mode: This is the best choice for movie watching with
SPLENDID™ Video Intelligence Technology.
• Game Mode: This is the best choice for game playing with SPLENDID™
Video Intelligence Technology.
• Night View Mode: This is the best choice for playing dark-scene game
or watching dark-scene movie with SPLENDID™ Video Intelligence
Technology.
• sRGB: This is the best choice for viewing photos and graphics from PCs.
• In the Standard Mode, the Saturation, Skin Tone, Sharpness, ASCR are
notuser-congurable.
• In the sRGB, the Brightness, Contrast, Saturation, Color Temp, Skin
Tone and ASCRarenotuser-congurable.
2. Color
Select the image color you like from this function.
VW197
Splendid
Color
Input Select
Move Menu Exit
System Setup
Brightness
Contrast
Saturation
Color Temp
100
80
User Mode
Skin Tone
Smart View
50
Natural
OFF
• Brightness: The adjusting range is from 0 to 100.
• Contrast: The adjusting range is from 0 to 100.
• Saturation: The adjusting range is from 0 to 100.
• Color Temp.: Contain three preset color modes (Cool, Normal, Warm)
and one User Mode.
• Skin Tone: Contain three color modes including Reddish, Natural, and
Yellowish.
• Smart View: Turn the Smart View Function on or off.
• In the User Mode, colors of R (Red), G (Green), and B (Blue) are user
configurable; the adjusting range is from 0 ~ 100.

3-3ASUS LCD Monitor VW197 Series
3. Image
You can adjust the image Sharpness, Aspect Control, ASCR, Position (VGA
only), and Focus (VGA only) from this main function.
VW197
Splendid
Color
Input Select
Move Menu Exit
System Setup Focus
Sharpness
Aspect Control
ASCR
40
1366x768
OFF
Position
• Sharpness: Adjust the picture sharpness. The adjusting range is from 0
to 100.
• Aspect Control: Adjust the aspect ratio to “1366x768”, “1360x768” or
“4:3”.
• ASCR: Select ON or OFF to enable or disable dynamic contrast ratio
function.
• Position:Adjustthehorizontalposition(H-Position)andthevertical
position (V-Position) of the image. The adjusting range is from 0 to 100
(Only available for VGA input).
• Focus:ReduceHorizonal-linenoiseandVertical-linenoiseoftheimage
by adjusting (Phase) and (Clock) separately. The adjusting range is from
0 to 100 (Only available for VGA input).
4. Input Select
Select the input source from VGA or DVI (VW197T/TR/N/NR).
VW197
Splendid
Color
Input Select
Move Menu Exit
System Setup
VGA
DVI

3-4 Chapter 3: General Instruction
5. System Setup
Adjust the system configuration.
VW197
Splendid
Color
Input Select
Move Menu Exit
System Setup Language
Information
Splendid Demo Mode OFF
83
OFF
English
Volume
ECO Mode
OSD Setup
1/2
VW197
Splendid
Color
Input Select
Move Menu Exit
System Setup
All Reset
2/2
• Splendid Demo Mode: Activate the demo mode for the Splendid
function.
• Volume: Adjust the Volume level of speakers (VW197T/TR/S/SR).
• ECO Mode: Turn the ECO Mode Function on or off.
• OSD Setup:Adjustthehorizontalposition(H-Position),verticalposition
(V-Position), OSD Timeout, DDC/CI, and Transparency of the OSD
screen.
• Language: Select OSD language. The selections are English, French,
German, Spanish, Italian, Dutch, Russian, Traditional Chinese, Simplified
Chinese, Japanese and Korean.
• Information: Display the monitor information.
• All Reset: Select “Yes” to revert all settings to the factory default mode.

3-5ASUS LCD Monitor VW197 Series
3.2 Specications
Model VW197T/TR/N/NR/S/SR/D/DR
PanelSize 18.5”W(47.0cm)
Max. Resolution 1366x768
Backlight Tech. LED Backlight Technology
Brightness (Typ.) 250cd/㎡
Intrinsic Contrast Ratio (Typ.) 1000:1
Viewing Angle (H/V), (CR≥10) 170°/160°
Display Colors 16.7 M
Response Time 5ms (Tr+Tf)
Analog Input D-Sub
Digital Input DVI(VW197T/TR/N/NR only)
Speaker (Build-in) 1W x 2 (VW197T/TR/S/SR only)
Tilt -5° ~ +20°
VESA Wall Mounting Yes (100mm x 100mm)
Phys. Dimension (WxHxD) 445x370x185mm
Box Dimension (WxHxD) 507x150x322mm
Net Weight (Esti.) 3.1 kg
Gross Weight (Esti.) 4.9kg
Voltage Rating AC100~240V(Built-in)

3-6 Chapter 3: General Instruction
3.3 Troubleshooting (FAQ)
Problem Possible Solution
Power LED is not ON • Press the button to check if the monitor is in the
ON mode.
• Check if the power cord is properly connected to the
monitor and the power outlet.
The power LED lights amber and
there is no screen image
• Check if the monitor and the computer are in the
ON mode.
• Make sure the signal cable is properly connected
the monitor and the computer.
• Inspect the signal cable and make sure none of the
pins are bent.
• Connect the computer with another available
monitor to check if the computer is properly working.
Screen image is too light or dark • Adjust the Contrast and Brightness settings via
OSD.
Screen image is not centered or
sizedproperly • Press the button for two seconds to
automatically adjust the image (for VGA input only).
• Adjust the H-Position or V-Position settings via OSD
(for VGA input only).
Screen image bounces or a wave
pattern is present in the image
• Make sure the signal cable is properly connected to
the monitor and the computer.
• Move electrical devices that may cause electrical
interference.
Screen image has color defects
(white does not look white)
• Inspect the signal cable and make sure that none of
the pins are bent.
• Perform All Reset via OSD.
• Adjust the R/G/B color settings or select the Color
Temperature via OSD.
Screenimageisblurryorfuzzy • Press the button for two seconds to
automatically adjust the image (for VGA input only).
• Adjust the Phase and Clock settings via OSD.
No sound or sound is low
(VW197T/TR/S/SR)
• Ensure that the audio cable is properly connected to
the monitor and the computer.
• Adjust the volume settings of both your monitor and
computer.
• Ensure that the computer sound card driver is
properly installed and activated.
