Asus A7S-VM User manual

®
A7S-VM
SiS730S Ultra-AGP
Socket A Motherboard
USER’S MANUAL

ASUS A7S-VM User’s Manual
2
USER'S NOTICE
Product Name: ASUS A7S-VM
Manual Revision: 1.02 E706
Release Date: February 2001
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form
or by any means, except documentation kept by the purchaser for backup purposes, without the
express written permission of ASUSTeK COMPUTER INC. (“ASUS”).
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EI-
THER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WAR-
RANTIES OR CONDITIONS OF MERCHANTABILITYOR FITNESS FORAPARTICULAR
PURPOSE. IN NO EVENT SHALLASUS, ITS DIRECTORS, OFFICERS, EMPLOYEES OR
AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUEN-
TIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS,
LOSS OF USE OR DATA, INTERRUPTION OF BUSINESSAND THE LIKE), EVEN IFASUS
HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
Product warranty or service will not be extended if: (1) the product is repaired, modified or al-
tered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the
serial number of the product is defaced or missing.
Products and corporate names appearing in this manual may or may not be registered trademarks
or copyrights of their respective companies, and are used only for identification or explanation
and to the owners’ benefit, without intent to infringe.
• AMD, AMD Athlon, and AMD Duron are trademarks of Advanced Micro Devices, Inc.
• SiS is a registered trademark of Silicon Integrated Systems Corp.
• Windows and MS-DOS are registered trademarks of Microsoft Corporation.
• Adobe and Acrobat are registered trademarks of Adobe Systems Incorporated.
• Trend and ChipAwayVirus are trademarks of Trend Micro Incorporated.
The product name and revision number are both printed on the product itself. Manual revisions
are released for each product design represented by the digit before and after the period of the
manual revision number. Manual updates are represented by the third digit in the manual revision
number.
For previous or updated manuals, BIOS, drivers, or product release information, contact ASUS at
http://www.asus.com.tw or through any of the means indicated on the following page.
SPECIFICATIONSANDINFORMATION CONTAINED INTHIS MANUALAREFURNISHED
FORINFORMATIONALUSEONLY,ANDARESUBJECTTOCHANGEATANYTIMEWITH-
OUTNOTICE,AND SHOULD NOTBE CONSTRUEDASACOMMITMENTBYASUS.ASUS
ASSUMES NO RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURA-
CIES THAT MAYAPPEAR IN THIS MANUAL, INCLUDING THE PRODUCTS AND SOFT-
WARE DESCRIBED IN IT.
Copyright © 2001 ASUSTeK COMPUTER INC. All Rights Reserved.

ASUS A7S-VM User’s Manual 3
ASUS CONTACT INFORMATION
ASUSTeK COMPUTER INC. (Asia-Pacific)
Marketing
Address: 150 Li-Te Road, Peitou, Taipei, Taiwan 112
Telephone: [phone]
Fax: [phone]
Email: [email protected]
Technical Support
MB/Others (Tel): [phone] (English)
Notebook (Tel): [phone] (English)
Desktop/Server (Tel):[phone] (English)
Fax: [phone]
Email: [email protected]
WWW: www.asus.com.tw
FTP: ftp.asus.com.tw/pub/ASUS
ASUS COMPUTER INTERNATIONAL (America)
Marketing
Address: 6737 Mowry Avenue, Mowry Business Center, Building 2
Newark, CA 94560, USA
Fax: [phone]
Email: [email protected]
Technical Support
Fax: [phone]
Email: [email protected]
WWW: www.asus.com
FTP: ftp.asus.com/Pub/ASUS
ASUS COMPUTER GmbH (Europe)
Marketing
Address: Harkortstr. 25, 40880 Ratingen, BRD, Germany
Fax: [phone]
Email: [email protected] (for marketing requests only)
Technical Support
Hotline: MB/Others: [phone] Notebook:[phone]
Fax: [phone]
Support (Email): www.asuscom.de/de/support (for online support)
WWW: www.asuscom.de
FTP: ftp.asuscom.de/pub/ASUSCOM

ASUS A7S-VM User’s Manual
4
CONTENTS
1. INTRODUCTION ............................................................................. 7
1.1 How This Manual Is Organized ................................................... 7
1.2 Item Checklist .............................................................................. 7
2. FEATURES ........................................................................................ 8
2.1 ASUS A7S-VM Motherboard ...................................................... 8
2.1.1 Specifications ..................................................................... 8
2.1.2 Performance...................................................................... 10
2.1.3 Intelligence ....................................................................... 11
2.2 Motherboard Components.......................................................... 12
2.2.1 Component Locations....................................................... 13
3. HARDWARE SETUP ...................................................................... 14
3.1 Motherboard Layout .................................................................. 14
3.2 Layout Contents ......................................................................... 15
3.3 Hardware Setup Procedure......................................................... 16
3.4 Motherboard Settings ................................................................. 16
3.5 System Memory ......................................................................... 21
3.5.1 General DIMM Notes....................................................... 21
3.5.2 Memory Installation ......................................................... 22
3.6 Central Processing Unit (CPU) .................................................. 23
3.6.1 CPU Installation ............................................................... 24
3.7 Expansion Cards ........................................................................ 25
3.7.1 Installing an Expansion Card ........................................... 25
3.7.2 Assigning IRQs for Expansion Cards .............................. 26
3.8 Connectors ................................................................................ 27
3.8.1 External Connectors ......................................................... 27
3.8.2 Internal Connectors .......................................................... 30
3.9 Starting Up the First Time.......................................................... 41
4. BIOS SETUP..................................................................................... 43
4.1 Managing and Updating Your BIOS .......................................... 43
4.1.1 Upon First Use of the Computer System.......................... 43
4.1.2 Updating BIOS Procedures .............................................. 45
4.2 BIOS Setup Program.................................................................. 47
4.2.1 BIOS Menu Bar................................................................ 48
4.2.2 Legend Bar ....................................................................... 48

ASUS A7S-VM User’s Manual 5
CONTENTS
4.3 Main Menu ................................................................................. 50
4.3.1 Primary & Secondary Master/Slave ................................. 51
4.3.2 Keyboard Features............................................................ 54
4.4 Advanced Menu ......................................................................... 56
4.4.1 Chip Configuration........................................................... 58
4.4.2 I/O Device Configuration ................................................. 61
4.4.3 PCI Configuration ............................................................ 63
4.4.4 Shadow Configuration...................................................... 67
4.5 Power Menu ............................................................................... 68
4.5.1 Power Up Control............................................................. 70
4.5.2 Hardware Monitor ............................................................ 71
4.6 Boot Menu ................................................................................. 72
4.7 Exit Menu................................................................................... 74
5. SOFTWARE SETUP....................................................................... 77
5.1 Operating Systems ..................................................................... 77
5.1.1 Windows 98 First Time Installation ................................. 77
5.2 A7S-VM Motherboard Support CD........................................... 77
5.2.1 Installation Menus ............................................................ 77
6. SOFTWARE REFERENCE ........................................................... 79
6.1 ASUS PC Probe ......................................................................... 79
7. APPENDIX........................................................................................ 85
7.1 PCI-L101 Fast Ethernet Card..................................................... 85
7.1.1 Features ............................................................................ 86
7.1.2 Software Driver Support .................................................. 86
7.1.3 Question and Answer........................................................ 86
7.2 Glossary ..................................................................................... 87
INDEX ................................................................................................... 91

ASUS A7S-VM User’s Manual
6
FCC & DOC COMPLIANCE
FederalCommunicationsCommissionStatement
This device complies with FCC Rules Part 15. Operation is subject to the following
two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received, including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
providereasonable protectionagainst harmful interferencein aresidential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with manufacturer's instructions, may cause harmful
interferenceto radiocommunications.However,there isnoguarantee thatinterference
will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
• Re-orient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
WARNING!Anychanges ormodifications tothis productnot expressly approved
by the manufacturer could void any assurances of safety or performance and
could result in violation of Part 15 of the FCC Rules.
Reprinted from the Code of Federal Regulations #47, part 15.193, 1993. Washington DC: Office of the
Federal Register, National Archives and Records Administration, U.S. Government Printing Office.
CanadianDepartmentofCommunications Statement
This digital apparatus does not exceed the Class B limits for radio noise emissions
from digital apparatus set out in the Radio Interference Regulations of the Canadian
Department of Communications.
This Class B digital apparatus complies with Canadian ICES-003.
CetappareilnumériquedelaclasseBestconformeàlanormeNMB-003duCanada.

ASUS A7S-VM User’s Manual 7
1.1 How This Manual Is Organized
This manual is divided into the following sections:
1. INTRODUCTION Manual information and checklist
2. FEATURES Production information and specifications
3. HARDWARE SETUP Instructions on setting up the motherboard.
4. BIOS SETUP Instructions on setting up the BIOS
5. SOFTWARE SETUP Instructions on setting up the included software
6. SOFTWARE REFERENCE Reference material for the included software
7. APPENDIX Optional items and general reference
1.2 Item Checklist
Check that your package is complete. If you discover damaged or missing items,
contact your retailer.
1. INTRODUCTION
1. INTRODUCTION
Manual / Checklist
Package Contents
(1) ASUS Motherboard
(1) 40-pin 80-conductor ribbon
cable for internal UltraDMA/66
or UltraDMA/33 IDE drives
(1) Ribbon cable for two 3.5”
floppy disk drives
(1) ASUS Support CD with drivers
and utilities
(1) Bag of spare jumper caps
(1) ASUS 2-port USB Connector
Set
(1) I/O Plate (on LAN models only)
(1) User’s Manual
Optional Items
ASUS Modem MR
ASUS IrDA-compliant infrared
module
ASUS PCI-L101 Wake-On-LAN
10/100 Ethernet Card

8ASUS A7S-VM User’s Manual
2.1 ASUS A7S-VM Motherboard
PoweredbyAMDAthlon /AMDDuron processors,theASUSA7S-VMmotherboard
bundles advanced technology to deliver outstanding performance. The motherboard
is designed with select features and interfaces to offer value and flexibility.
2.1.1 Specifications
•Processor:Supports SocketA-basedAMDAthlon™/AMD Duron™processors
running at 533MHz up to 1.2GHz with Front Side Bus (FSB) frequency of
100MHz.
•North/South Bridge System Chipset: Features the SiS730S single chip that
complements the powers of the SocketA-based processor.The chipset integrates
the Ultra-AGPtechnology and 128-bit 2D/3D graphic engine to deliverAGP4X
performance and up to 1GB/s memory bandwidth.
•PC133SDRAM /VC133VCM/HSDRAMSupport:Equipped with two Dual
Inline Memory Module (DIMM) sockets to support up to 1GB of memory using
unbuffered PC133/100-compliant or NEC’s VC133-compliant Virtual Channel
(VC) SDRAMs, and Enhanced Memory System’s High-speed DRAMs
(HSDRAMs).
•JumperFree™Mode: Allows processor settings and easy overclocking of
frequency and Vcore voltage through BIOS setup when the JumperFree™mode
is enabled. Easy-to-use DIP switches come with the motherboard board to allow
manual adjustment of the processor external/internal frequency.
•UltraDMA/100Support:Comes withanonboard PCIBusMaster IDEcontroller
with two connectors that support four IDE devices on two channels. Supports
UltraDMA/100, UltraDMA/66, UltraDMA/33, PIO Modes 3 & 4, Bus Master
IDE DMA Mode 2, and Enhanced IDE devices, such as DVD-ROM, CD-ROM,
CD-R/RW, LS-120, and Tape Backup drives.
•LAN Support: Features the RealTek RTL8100 Fast-Ethernet LAN controller
that fully supports 10BASE-T/100BASE-TX.
•Super Multi-I/O: Builts-in the iTE IT8705F chipset to support two high-speed
UARTcompatibleserial portsandone parallel portwithEPPandECPcapabilities.
UART2 can also be directed from COM2 to an external infrared module for
wireless connections.
•IrDA: Supports an optional infrared port module for wireless interface.
•Wake-On-LAN: Supports Wake-On-LAN activity through a WOL connector
or an optional ASUS PCI-L101 10/100 Fast Ethernet PCI card.
•Wake-On-Ring: Supports Wake-On-Ring activity through a PCI modem card
that supports a WOR connector.
2. FEATURES
Specifications
2. FEATURES

ASUS A7S-VM User’s Manual 9
2. FEATURES
2. FEATURES
Specifications
•PC Health Monitoring: Provides an easy way to test and manage system status
information, such as CPU and system voltages, temperatures, and fan status
through the onboard hardware ASUS ASIC and the bundled ASUS PC Probe.
•SMBus: Features the System Management Bus interface used to physically
transport commands and information between SMBus devices.
•PCI Expansion Slots: Provides four 32-bit PCI (Rev. 2.2) expansion slots that
support Bus Master PCI cards, such as SCSI or LAN cards, with 133MB/s
maximum throughput.
•Smart BIOS: 2Mb firmware provides Vcore and CPU/SDRAM frequency
adjustments,boot blockwrite protection, andHD/SCSI/MO/ZIP/CD/Floppy boot
selection.
•EnhancedACPIandAnti-BootVirusProtection:Programmable BIOS (Flash
EEPROM) that offers enhanced ACPI for Windows 98 compatibility, built-in
firmware-based virus protection, and autodetection of most devices for a virtual
automatic setup.
•Desktop Management Interface (DMI): Supports DMI through BIOS that
allows hardware to communicate within a standard protocol and create a higher
level of compatibility. (Requires DMI-enabled components.)
•Onboard Audio: Audio models come with the AC ‘97-compliant interfaces
that support integrated audio and modem features that comprise digital audio
engine with 3D-hardware accelerator, on-chip sample rate converter, and a
professional wavetable.
•Connectivity Interface: Supports an optional ASUS iPanel, an easy-to-access
box with system diagnostic display area, system status LEDs, USB ports, and
hotkeys.TheAFPANELconnector onthe motherboardaccommodates theASUS
iPanel.

10 ASUS A7S-VM User’s Manual
2. FEATURES
Performance
2. FEATURES
2.1.2 Performance
•ACPI Ready: Advanced Configuration Power Interface (ACPI) provides more
Energy Saving Features for operating systems that support OS Direct Power
Management (OSPM) functionality. With these features employed in the OS,
PCs can be ready around the clock but comply with energy saving standards. To
fully utilize the ACPI benefits, use an ACPI-supported OS such as Windows
98/2000/Millenium.
•PC’99 Compliant: Both the BIOS and hardware levels of ASUS smart series
motherboards are PC’99 compliant. The new PC’99 requirements for systems
and components are based on the following high-level goals: Support for Plug-
n-Play compatibility and power management for configuring and managing all
system components, and 32-bit device drivers and installation procedures for
Windows 95/98/NT. Color-coded connectors and descriptive icons make
identification easy as required by PC’99.
•High-Speed Data Transfer Interface: Support for UltraDMA/100 through the
onboard IDE bus master controller triples the UltraDMA/33 burst transfer rate.
UltraDMA/100 is backward compatible with DMA/66, DMA/33, and other
existing DMA devices to save the need to upgrade current EIDE/IDE drives.
(UltraDMA/100/66 requires a 40-pin 80-conductor cable).
•ConcurrentPCI:Concurrent PCIallows multiplePCI transfers fromPCI master
busses to the memory and processor.
•VCM/SDRAM Optimized Performance: This motherboard supports the new
generation memory, NEC 64Mb Virtual Channel Memory (VCM) Synchronous
Dynamic RandomAccess Memory (SDRAM), that is compatible to the industry
standard SDRAM. The VCM core design provides up to 50% higher SDRAM
speed at reduced power consumption of about 30%. This motherboard also
supportsthe standard SDRAM for a the data transfer rate of up to 1.067GB/s using
PC133-compliant SDRAMs and up to 800MB/s using PC100-compliant
SDRAMs.

ASUS A7S-VM User’s Manual 11
2. FEATURES
2. FEATURES
Intelligence
2.1.3 Intelligence
•Auto Fan Off: The system fans powers off automatically even in sleep mode.
This function reduces both energy consumption and system noise, and is an
important feature in implementing silent PC systems.
•DualFunctionPower Button:Pushing the power button for less than 4 seconds
when the system is in the working state places the system into one of two states:
sleep mode or soft-off mode, depending on the BIOS or OS setting (see PWR
Button < 4 Secs in 4.5 Power Menu). When you press the power button for
more than 4 seconds, the system enters the soft-off mode regardless of the BIOS
setting.
•Fan Status Monitoring and Alarm: To prevent system overheat and system
damage, the CPU and system fans can be monitored for RPM and failure. All
fans are set for its normal RPM range and alarm thresholds.
•PowerLED(requiresACPIOSsupport):The powerLED indicatesthe system
status.
•Remote Ring-On (requires modem): This feature allows you to turn off the
computer remotely through an internal or external modem. With this benefit on-
hand, users can access vital information from their computers anywhere.
•System Resources Alert: Today’s operating systems such as Windows 98/
Millenium and Windows NT/2000, require much more memory and hard drive
space to present enormous user interfaces and run large applications. The system
resourcemonitor warnstheuser beforethesystem resourcesareused uptoprevent
possible application crashes. Suggestions provide the user some information on
managing their limited resources more efficiently.
•Temperature Monitoring and Alert: CPU temperature is monitored by the
ASUSASIC through the thermal sensor of SocketAto prevent system overheat
and system damage.
•Voltage Monitoring andAlert: System voltage levels are monitored to ensure
stable voltage to critical motherboard components. Voltage specifications are
more critical for future processors, so monitoring is necessary to ensure proper
system configuration and management.
•Chassis Intrusion Detection: Supports chassis-intrusion monitoring through
the ASUS ASIC. A chassis intrusion event is kept in memory on battery power
for more protection.

12 ASUS A7S-VM User’s Manual
2. FEATURES
2. FEATURES
M/B Components
Location
Processor Support Socket 462 for AMD Athlon/AMD Duron Processors............. 3
Feature Setting DIP Switches ................................................... 6
Chipsets SiS730S System Controller....................................................... 2
iTE IT8705F Super I/O Controller ........................................... 9
2Mbit Programmable Flash EEPROM ................................... 11
Main Memory 2 DIMM Sockets for up to 2GB Memory Support .................. 4
PC133 SDRAM support
Expansion Slots 4 PCI Slots .............................................................................. 19
System I/O Floppy Disk Drive Connector .................................................. 7
IDE Connectors (UltraDMA/100 Support) .............................. 5
ASUS iPanel Connectors................................................... 10/17
Parallel Port .................................................................. (Top) 22
Serial Port 1 (COM1) ............................................. (Bottom) 22
Serial Port 2 (COM2) ............................................................. 15
Video Port ............................................................... (Bottom) 22
USB Connectors (Port 0 & Port 1) ........................ (Bottom) 23
USB Connectors (Port 2 & Port 3) ........................................ 12
USB Connectors (Port 4 & Port 5) ......................................... 14
PS/2 Mouse Connector ................................................. (Top) 24
PS/2 Keyboard Connector ...................................... (Bottom) 24
Network Features RealTek RTL8100 Fast Ethernet Controller ........................... 20
LAN Connector (RJ-45) ............................................... (Top) 23
Wake-On-LAN Connector...................................................... 13
Wake-On-Ring Connector ........................................................ 8
Hardware Monitoring System Voltage Monitoring ...................................................... 9
ASUS ASIC ............................................................................ 16
3 Fan Power Connectors
Audio Features (on audio models only)
AC ’97 v2.1 Audio Codec ...................................................... 18
Game/MIDI Port........................................................... (Top) 21
Line Out Connector ................................................ (Bottom) 21
Line In Connector................................................... (Bottom) 21
Microphone Connector ........................................... (Bottom) 21
Power ATX Power Connector ............................................................. 1
Form Factor Micro ATX
2.2 Motherboard Components
See opposite page for locations.

ASUS A7S-VM User’s Manual 13
2. FEATURES
2. FEATURES
M/B Components
2.2.1 Component Locations
21
1 2 345
9
11
12
17
18
19
20
22
24
6 7
8
10
15
23
131416

14 ASUS A7S-VM User’s Manual
3. HARDWARE SETUP
3.1 Motherboard Layout
Motherboard Layout
3. H/W SETUP
NOTE: The Audio Codec, external and internal audio connectors,RealTek
RTL8100 chipset, and RJ-45 LAN connector are optional components.
24.5cm (9.6in)
24.5cm (9.6in)
TV-LCD
FLOPPY
PRIMARY IDE
SECONDARY IDE
PANEL
A7S-VM
Audio
Codec
DIMM Socket 1 (64/72-bit, 168-pin module)
01
CPU_FAN
SiS730S
Chipset
CR2032 3V
Lithium Cell
CMOS Power
PS/2
T: Mouse
B: Keyboard
COM2
Socket A
AUX
Realtek
Fast
Enternet
COM1
PARALLEL PORT
VGA
CHASIS_FAN
Super
I/O
VIDEO
CD
MODEM
WOR
CHASSIS
SMB
IR
AFPANEL
AAPANEL
USBP1
USBP2
KB_UP USB_UP
FSW
CLR_CMOS
PWR_TMP
WOL_CON
Flash EEPROM
(Programable BIOS)
DIMM Socket
2
(64/72-bit, 168-pin module)
23
CIR
PWR_FAN
ATX Power Connector
11
PCI Slot 1
PCI Slot 2
PCI Slot 3
PCI Slot 4
USB
T: USB1
B: USB2
Top:
RJ-45
GAME_AUDIO
Mic
In
Line
Out
Line
In
ASUS
ASIC

ASUS A7S-VM User’s Manual 15
3. HARDWARE SETUP
3.2 Layout Contents
Motherboard Settings
1) FSW 1-5 p. 17 CPU External Frequency Selection
2) CLR_CMOS p. 19 Clear RTC RAM
3) USB_UP p. 20 USB Wake Up Jumper
4) KB_UP p. 20 Keyboard Wake-up Jumper
Expansion Slots/Sockets
1) DIMM 1/2 p. 22 System Memory Support
2) Socket A p. 23 CPU Support
3) PCI 1/2/3/4 p. 25 32-bit PCI Bus Expansion Slots
Connectors
1) PS2KBMS p. 27 PS/2 Mouse Port (6-pin female)
2) PS2KBMS p. 27 PS/2 Keyboard Port (6-pin female)
3) RJ-45 p. 28 Fast Ethernet LAN Port (RJ-45)
4) USB p. 28 Universal Serial Bus Ports 1&2(two4-pin female)
5) PRINTER p. 28 Parallel Port (25-pin female)
6) COM1 p. 29 Serial Ports (9-pin /10-1 pin male)
7) VGA p. 29 Video Port (15-pin female)
8) GAME_AUDIO p. 29 Game/MIDI Ports (15-pin female, 1/8”jacks)
8) IDELED p. 30 IDE Activity LED (2-pin)
9) FLOPPY p. 30 Floppy Disk Drive Connector (34-pin)
10) PRIMARY IDE p. 31 IDE Connectors (two 40-1 pin)
SECONDARY IDE
11) WOL_CON p. 32 Wake-On-LAN Connector (3-pin)
12) WOR p. 32 Wake-On-Ring Connector (2-pin)
13) CPU/PWR/CHA_FAN p. 33 CPU, Power, and Chassis Fan Connectors (3-pin)
14) CHASSIS p. 34 Chassis Intrusion Lead (4-1 pin)
15) SMB p. 34 SMBus Connector (5-1 pin)
16) IR p. 35 Standard Infrared Module Connector (5-pin)
17) CIR p. 35 Consumer Infrared Module Connector (5-pin)
18) AFPANEL p. 36 ASUS iPanel Connector (12-1 pin)
19) AAPANEL p. 36 Audio Panel Connector (12-1 pin)
20) USBP1/USBP2 p. 37 USB Headers (two 10-1 pin)
21) CD/VIDEO/AUX/MODEM p. 37 Internal Audio Connectors (4-1 pin)
22) TV-LCD p. 38 LCD Headers (two 20-pin)
23) COM2 p. 38 Serial Port 2 Connector (10-1 pin)
24) ATXPWR p. 39 ATX Power Supply Connector (20-pin)
25)
PWR.LED ( PANEL ) p. 40 System Power LED Lead (3-pin)
26) SPEAKER (PANEL) p. 40 System Warning Speaker Lead (4-pin)
27) MSG.LED (PANEL) p. 40 System Message LED Lead (2-pin)
28) SMI (PANEL) p. 40 System Management Interrupt Lead (2-pin)
29) PWR.SW (PANEL) p. 40 ATX / Soft-Off Switch Lead (2-pin)
30) RESET (PANEL) p. 40 Reset Switch Lead (2-pin)
Layout Contents
3. H/W SETUP

16 ASUS A7S-VM User’s Manual
3. HARDWARE SETUP
Motherboard Settings
3. H/W SETUP
3.3 Hardware Setup Procedure
Complete the following steps before using your computer:
1. Check motherboard settings
2. Install memory modules
3. Install the Central Processing Unit (CPU)
4. Install Expansion Cards
5. Connect ribbon cables, panel wires, and power supply cables
6. Configure the BIOS parameter settings
3.4 Motherboard Settings
This section tells you how to change motherboard function settings through the
switches and/or jumpers.
WARNING! Computer motherboards and expansion cards contain very delicate
Integrated Circuit (IC) chips. To avoid damaging them due to static electricity,
follow these precautions whenever you work on your computer.
1. Unplug the computer when working on the internal components.
2. Use a grounded wrist strap or touch a safely grounded object or to a metal
object,suchasthe powersupply case,beforehandling computer components.
3. Hold components by the edges and try not to touch the IC chips on them.
4. Wheneveryou uninstallany component,placethe componentsonagrounded
antistatic pad or in the bag that came with the components.
5. Beforeyouinstallorremoveanycomponent,ensurethattheATXpower
supply is switched off or the power cord is detached from the power
supply. Failure to do so may cause severe damage to the motherboard,
peripherals, and/or components.

ASUS A7S-VM User’s Manual 17
3. HARDWARE SETUP
3. H/W SETUP
Motherboard Settings
Motherboard Features Settings (DIP Switches - FSW)
Themotherboard frequencyis adjustedthroughthe DIPswitches (FSW).The position
of the white block represents the switch setting. The illustration below shows all the
switches in the OFF position.
IMPORTANT! In JumperFreemode, set all DIP switches (FSW) to OFF.
1) JumperFree™Mode
This motherboard has a JumperFree™feature that allows setting the CPU
frequency through the BIOS. Switch 5 is for jumper mode selection. When
switch 5 is set to ON, you can manually select the CPU frequency by setting
switches 1-4 (refer to the switch settings on the next page).
A7S-VM
ON
12345
A7S-VM JumperFree™ Mode Setting
ON
12345
JumperFree Mode
Jumper Mode
FSW1~FSW4 settings depend
on selected CPU frequency
A7S-VM
A7S-VM DIP Switches
OFF
ON
< Frequency Multiple (FS4)
< Frequency Multiple (FS1)
< Frequency Multiple (FS2)
< Frequency Multiple (FS3)
<Jumper Mode Selection
ON
12345

18 ASUS A7S-VM User’s Manual
2) CPU External Frequency Selection (FSW Switches 1–5)
This option tells the clock generator what frequency to send to the CPU, DRAM,
and the PCI and AGP buses. This allows the selection of the CPU’s External
frequency(or BUSClock).The BUSClockmultiplied bytheFrequency Multiple
equals the CPU’s Internal frequency (the advertised CPU speed).
3. HARDWARE SETUP
WARNING! Frequencies other than the recommended CPU bus frequencies are
not guaranteed to be stable.
3. H/W SETUP
Motherboard Settings
A7S-VM
A7S-VM CPU
External Frequency Selection
CPU
SDRAM
PCI
AGP
100.00MHz
100.00MHz
33.33MHz
66.67MHz
ON
1234
45.00MHz
60.00MHz
30.00MHz
60.00MHz
ON
1234
48.00MHz
48.00MHz
32.00MHz
64.00MHz
ON
1234
90.00MHz
90.00MHz
30.00MHz
60.00MHz
ON
1234
150.00MHz
150.00MHz
30.00MHz
60.00MHz
ON
1234
133.33MHz
133.33MHz
33.33MHz
66.67MHz
ON
1234
124.00MHz
124.00MHz
31.00MHz
62.00MHz
ON
1234
112.00MHz
112.00MHz
33.60MHz
67.20MHz
ON
1234
100.00MHz
150.00MHz
30.00MHz
60.00MHz
ON
1234
100.00MHz
133.33MHz
33.33MHz
66.67MHz
ON
1234
CPU
SDRAM
PCI
AGP
CPU
SDRAM
PCI
AGP
5 5 5 5
5
5
5
5
5
5
NOTE: Overclocking the processor is not recommended. It may result in a
slower speed.

ASUS A7S-VM User’s Manual 19
3. HARDWARE SETUP
3. H/W SETUP
Motherboard Settings
3) Clear RTC RAM
This jumper allows you to clear the Real Time Clock (RTC) RAM in CMOS.
You can clear the CMOS memory of date, time, and system setup parameters by
erasingthe CMOSRTCRAM data.The RAMdata inCMOS, thatinclude system
setup information such as system passwords, is powered by the onboard button
cell battery.
To erase the RTC RAM: (1) unplug the computer, (2) short the jumper, (3) turn
ON the computer, (4) hold down the <Del> key during the boot process and
enter BIOS setup to re-enter data.
For updated processor settings, visit the ASUS web site. See also ASUS CONTACT
INFORMATION at the beginning of this manual.
CPU SDRAM PCI AGP Frequency Selection Switches
(MHz) (MHz) (MHz) (MHz) 1 2 3 4 5
100.00 100.00 33.33 66.67 [OFF] [OFF] [OFF] [OFF] [ON]
100.00 133.33 33.33 66.67 [OFF] [OFF] [OFF] [ON] [ON]
100.00 150.00 30.00 60.00 [OFF] [OFF] [ON] [OFF] [ON]
112.00 112.00 33.60 67.20 [OFF] [ON] [OFF] [OFF] [ON]
124.00 124.00 31.00 62.00 [OFF] [ON] [ON] [OFF] [ON]
133.33 133.33 33.33 66.67 [ON] [OFF] [OFF] [OFF] [ON]
150.00 150.00 30.00 60.00 [ON] [OFF] [OFF] [ON] [ON]
90.00 90.00 30.00 60.00 [ON] [ON] [OFF] [ON] [ON]
48.00 48.00 32.00 64.00 [ON] [ON] [ON] [OFF] [ON]
45.00 45.00 30.00 60.00 [ON] [ON] [ON] [ON] [ON]
External Frequency Table
The following table is for experienced motherboard installers only. Overclocking
can result in system instability or even shortening the life of the processor.
A7S-VM
A7S-VM Clear RTC RAM
Short solder points
to Clear CMOS
CLR_CMOS

20 ASUS A7S-VM User’s Manual
3. HARDWARE SETUP
3. H/W SETUP
Motherboard Settings
4) USB Device Wake-up Jumper (3-pin USB_UP)
This jumper allows you to enable or disable the USB device wake up feature.
Set this jumper to ENABLE if you wish to use the USB devices to wake up the
computer. This feature requires anATX power supply that can supply at least 2A
on the +5VSB lead. The default setting is DISABLE.
NOTES:
1. Before setting either of this jumper to ENABLE, make sure that you have the
appropriate power supply, otherwise the computer will not power up.
2. The total current consumed must NOT exceed the power supply capability
(+5VSB) whether under normal working conditions or in sleep mode.
A7S-VM
A7S-VM Keyboard Wake Up
Disable
(Default) Enable
1
22
3
KB_UP
Disable
(Default) Enable
1
22
3
USB_UP
A7S-VM
A7S-VM USB Wake Up
5) Keyboard Wake-up Jumper (3-pin KB_UP)
This jumper allows you to enable or disable the keyboard wake up feature. Set
this jumper to ENABLE if you wish to use the keyboard to wake up the computer
when you press the <Spacebar>.This feature requires anATX power supply that
can supply at least 2A on the +5VSB lead. The default setting is DISABLE.
