Asus A7S333 User manual

Motherboard
®
A7S333
User Guide

ii
Checklist
Product Name: A7S333
Manual Revision: 1.00 E982
Release Date: March 2002
Copyright © 2002 ASUSTeK COMPUTER INC. All Rights Reserved.
Nopartofthismanual,includingtheproductsandsoftwaredescribedinit,maybereproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any
form or by any means, except documentation kept by the purchaser for backup purposes,
without the express written permission of ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modified or
altered, unless such repair, modification of alteration is authorized in writing byASUS; or (2)
the serial number of the product is defaced or missing.
Products and corporate names appearing in this manual may or may not be registered
trademarks or copyrights of their respective companies, and are used only for identification
or explanation and to the owners’benefit, without intent to infringe.
Theproductname and revision number are both printed on the product itself. Manual revisions
are released for each product design represented by the digit before and after the period of
the manual revision number. Manual updates are represented by the third digit in the manual
revision number.
For previous or updated manuals, BIOS, drivers, or product release information, contact
ASUS at: http://www.asus.com or through any of the means indicated on the following page.
ASUS PROVIDES THIS MANUAL “AS IS”WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALLASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM
ANY DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN
THIS MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

iii
Features
About this guide
This user manual contains complete information for installing the ASUS
A7S333 motherboard.
How this guide is organized
• Chapter 1: Product introduction. A summary of product features and
special attributes of new technologies.
• Chapter 2: Hardware information. A list of hardware setup procedures
and descriptions of all jumpers and connectors on the motherboard.
•Chapter 3: Powering up. Describes the power up sequence with
information on BIOS beep codes.
• Chapter 4: BIOS setup. How to change system settings using onboard
BIOSfirmware.DetaileddescriptionsoftheBIOSparametersaresupplied.
• Chapter 5: Software support. A summary of contents on the
motherboard support CD ROM.
• Appendix and Glossary. Optional componentsandtechnicaldefinitions.
• Index
Conventions used in this guide
Tomakesurethatyouperform set-up tasksproperly,takenoteofthefollowing
symbols used throughout this manual.
WARNING! Information to prevent injury to yourself.
CAUTION! Information to prevent damage to the components.
IMPORTANT! Information that youMUSTfollowtocomplete a task.
NOTE! Tips and helpful information.

iv
Safeguards
Contents
About this guide .............................................................................. iii
How this guide is organized.................................................... iii
Conventions used in this guide............................................... iii
Safety information ...........................................................................vi
FCC/CDC statements .................................................................... vii
ASUS contact information ............................................................. viii
Chapter 1: Product introduction ............................................. 1
Welcome! ........................................................................................ 1
1.1 Package contents .................................................................. 1
1.2 Core Specifications ................................................................ 2
1.3 Special Features .................................................................... 3
1.4 Motherboard Components...................................................... 4
1.4.1 Component Locations................................................ 5
Chapter 2: Hardware information ............................................ 1
2.1 Motherboard installation ......................................................... 7
2.1.1 Placement direction ................................................... 7
2.1.2 Screw holes............................................................... 7
2.2.1 Layout contents ......................................................... 9
2.3 Before you proceed...............................................................11
2.4 Central Processing Unit (CPU) ............................................. 12
2.4.1 Overview ..................................................................12
2.4.2 Installing the CPU .................................................... 13
2.5 System memory ....................................................................14
2.5.1 Overview ..................................................................14
2.5.2 Memory configurations ............................................ 15
2.5.3 DDR333 DIMM Qualified Vendor List ....................... 15
2.5.4 Installing a DIMM ..................................................... 16
2.6 Expansion slots.....................................................................17
2.6.1 Installing an expansion card..................................... 17
2.6.2 Configuring an expansion card ................................ 17
2.6.3 PCI slots ...................................................................19
2.6.4 AGP slot ...................................................................19
2.6.5 AMR slot (Optional) ................................................. 20
2.7 Switches and jumpers ...........................................................21
2.8 Connectors ...........................................................................27

v
Contents
Chapter 3: Powering up ......................................................... 41
3.1 Starting up for the first time................................................... 41
3.2 Powering off the computer.................................................... 42
Chapter 4: BIOS setup ........................................................... 43
4.1 Managing and updating your BIOS....................................... 43
4.1.1 Using the computer system for the first time ............ 43
4.1.2 Updating BIOS procedures ...................................... 45
4.2 BIOS Setup program.............................................................47
4.2.1 BIOS menu bar.........................................................48
4.2.2 Legend bar ...............................................................48
4.3 Main Menu ............................................................................50
4.3.1 Primary and Secondary Master/Slave...................... 51
4.3.2 Keyboard Features .................................................. 55
4.4 Advanced Menu ....................................................................57
4.4.1 Chip Configuration ................................................... 59
4.4.2 I/O Device Configuration.......................................... 61
4.4.3 PCI Configuration .................................................... 63
4.5 Power Menu..........................................................................67
4.5.1 Power Up Control .................................................... 69
4.5.2 Hardware Monitor .................................................... 71
4.6 Boot Menu ............................................................................72
4.7 Exit Menu..............................................................................74
Chapter 5: Software support ................................................. 77
5.1 Install an operating system................................................... 77
5.2 Support CD information.........................................................77
5.3 A7S333 Motherboard Support CD........................................ 78
5.4 ASUS PC Probe....................................................................81
5.5 ASUS Live Update ................................................................86
5.6 3Deep Color Tuner................................................................87
5.7 ITE GSM Editor.....................................................................89
5.8 Cyberlink PowerPlayer SE ................................................... 93
5.9 Cyberlink VideoLive Mail ...................................................... 94
Glossary .................................................................................. 97
Index ...................................................................................... 101

vi
Safety information
Electrical safety
•To prevent electrical shock hazard, disconnect the power cable from the
electrical outlet before relocating the system.
•When adding or removing devices to or from the system, ensure that the
power cables for the devices are unplugged before the signal cables are
connected. Disconnect all power cables from the existing system before
you add a device.
•Beforeconnectingor removingsignalcablesfromthemotherboard,ensure
that all power cables are unplugged.
•Seek professional assistance before using an adpater or extension cord.
These devices could interrupt the grounding circuit.
•Make sure that your power supply is set to the voltage available in your
area.
•If the power supply is broken, contact a qualified service technician or your
retailer.
Operational safety
•Before installing the motherboard and adding new devices, carefully read
all the manuals that came with the package.
•Before use ensure all cables are correctly connected and the power cables
arenotdamaged.Ifyoudetectanydamage,contactthedealerimmediately.
•To avoid short circuits, keep paper clips, screws, and staples away from
connectors, slots, sockets and circuitry.
•Avoid dust, humidity, and temperature extremes. Do not place the product
in any area where it may become wet.
•Mount the motherboard inside a standard PC enclosure.
•If you encounter technical problems with the product, contact a qualified
service technician or the dealer.

vii
FCC/CDC statements
Federal Communications Commission Statement
This device complies with FCC Rules Part 15. Operation is subject to the
following two conditions:
•This device may not cause harmful interference, and
•This device must accept any interference received including interference
that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
manufacturer’s instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment to an outlet on a circuit different from that to
which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
The use of shielded cables for connection of the monitor to the
graphics card is required to assure compliance with FCC regulations.
Changes or modifications to this unit not expressly approved by the
party responsible for compliance could void the user’s authority to
operate this equipment.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for radio noise
emissions from digital apparatus set out in the Radio Interference
Regulations of the Canadian Department of Communications.
This class B digital apparatus complies with Canadian ICES-003.

viii
ASUS contact information
ASUSTeK COMPUTER INC. (Asia-Pacific)
Marketing
Address: 150 Li-Te Road, Peitou, Taipei, Taiwan 112
Telephone: [phone]
Fax: [phone]
Email: [email protected]
Technical Support
Tel (English): [phone]
Tel (Chinese): [phone]
Fax: [phone]
Email: [email protected]
Newsgroup: cscnews.asus.com.tw
WWW: www.asus.com.tw
FTP: ftp.asus.com.tw/pub/ASUS
ASUS COMPUTER INTERNATIONAL (America)
Marketing
Address: 6737 Mowry Avenue, Mowry Business Center, Building 2
Newark, CA 94560, USA
Fax: [phone]
Email: [email protected]
Technical Support
Fax: [phone]
BBS: [phone]
Email: [email protected]
WWW: www.asus.com
FTP: ftp.asus.com/pub/ASUS
ASUS COMPUTER GmbH (Europe)
Marketing
Address: Harkortstr. 25, 40880 Ratingen, BRD, Germany
Fax: [phone]
Email: [email protected] (for marketing requests only)
Technical Support
Hotline: MB/Others: [phone]
Notebook: [phone]
Fax: [phone]
Support (Email): www.asuscom.de/de/support (for online support)
WWW: www.asuscom.de
FTP: ftp.asuscom.de/pub/ASUSCOM

Chapter 1
Product introduction

ASUS A7S333 motherboard

ASUS A7S333 motherboard user guide 1
Welcome!
Thank you for buying the ASUS
®
A7S333 motherboard!
TheA7S333ispoweredbyAMD
®
Athlon
™
,Athlon
™
XPandDuron
™
processors
and supplies advanced features to ensure long-lasting, superlative
performance. TheASUS
®
A7S333 motherboard is the prime choicefor home
PCs and workstations.
~ ASUS C.O.P. (CPU Overheating Protection)
~ Up to 3GB of system memory of the latest DDR SDRAM
~ High-resolution graphics via an AGP 4X slot
~ Digital Audio Interface for 3D sound
~ 6 USB ports
~ UltraDMA 100 data rates
The A7S333 is the perfect vehicle to get ahead in the world of power
computing!
1.1 Package contents
Check your A7S333 package for the following items.
ASUS A7S333 motherboard (ATX form factor: 12 in x 8.6 in)
ASUS A7S333 support CD
ASUS 2-port USB module
80-conductor ribbon cable for UltraDMA66/100 IDE drives
40-conductor IDE cable
Ribbon cable for a 3.5-inch floppy drive
Bag of extra jumper caps
User Guide
If any of the above items is damaged or missing, contact your retailer.

2 Chapter 1: Product introduction
1.2 Core Specifications
TheA7S333motherboardisdesignedandassembled accordingtothehighest
standards. This ASUS motherboard represents the latest advances and
offers users the finest componentry available today...
AMD
®
Athlon
™
XP, Athlon
™
and Duron Socket A (462) Processor
SiS
®
745 Chipset: supportsAGP 4X/2X mode, 133/100MHz Front Side Bus,
and the fastest 333/266/200MHz memory bus. The SiS
®
745 integrated
peripheral controller supports UltraDMA/100/66/33 for burst mode data
transfer rates of up to 100MB/sec, and USB controller with three root
hubs for six USB ports.
PC 2700 / 2100 / PC1600 DDR Support: Equipped with three Double Data
Rate Dual Inline Memory Module (DDR DIMM) sockets to support up to
3GB of DDR SDRAM, the newest memory standard with the highest
bandwidth and lowest latency currently available. This new memory
technology increases performance by executing two actions per clock
cycle, resulting in data transfer rates of up to 2.7 GB/s for 166MHz DDR,
2.1 GB/s for 133MHz DDR and 1.6GB/s for 100MHz DDR SDRAM.
UltraDMA/100 Support: Comes with an onboard PCI Bus Master IDE
controller with two connectors that support four IDE devices on two
channels. Supports UltraDMA100/66/33, PIO Modes 3 & 4, Bus Master
IDE DMA Mode 2, and Enhanced IDE devices, such as DVD-ROM, CD-
ROM, CD-R/RW, LS-120, and Tape Backup drives.
Multi-I/O Chipset: Offers complete support for a variety of I/O functions.
Provides two high-speed UART compatible serial ports and one parallel
port with EPP and ECP capabilities. UART2 can also be directed from
COM2 to the Infrared Module for wireless connections. The Super I/O
controller supports a floppy disk drive, PS/2 keyboard, and PS/2 mouse.
Smart BIOS: 2Mb firmware enables CPU/DDR SDRAM frequency
adjustments,bootblockwriteprotection,andHD/SCSI/MO/ZIP/CD/Floppy
boot selection.
Expansion: OneAGP 4X, sixUSB ports, five PCIslots,AMRslot (Optional),
SPDIFdigitalaudio connector, 1394header (Optional), game connector,
iPanel connector, front audio panel connector, smart card connector,
infrared port.
Connections: ParallelPort, PS/2 mouse Port,PS/2keyboard, 6 USB ports,
Microphone, Line In Jack, Line Out Jack, Standard ATX power.

ASUS A7S333 motherboard user guide 3
1.3 Special Features
Easy Overclocking
•Quickly adjust CPU frequency multiples with BIOS in JumperFree
™
Mode
•Adjustable FSB/MEM/PCI frequency ratio
•Stepless Frequency Selection (SFS) for fine-tuning system bus frequency
from at 1MHz increments
•Alternatively, easy-to-use DIP switches permit manual adjustment of the
processor external/internal frequency settings.
ASUS C.O.P. (CPU Overheating Protection): With AMD
®
Athlon XP
™
installed, the motherboard offers automatic CPU Overheating Protection
to prolong the life of the entire system. If the CPU temperature exceeds
the set criteria, the PC shuts down automatically.
Temperature, Fan and Voltage Monitoring:CPU temperature is monitored
by the ASIC through the CPU’s internal thermal diode to prevent
overheating and damage. The CPU and system fans can be monitored
for RPM and failure. System voltage levels are monitored to ensure
stable voltage to critical motherboard components.
ACPI Ready: AdvancedConfigurationPowerInterface(ACPI) providesmore
Energy Saving Features for operating systems that support OS Direct
Power Management (OSPM).
Concurrent PCI: Concurrent PCI allows multiple PCI transfers from PCI
master busses to the memory and processor.
Auto Fan Off: Thesystemfanspowersoffautomaticallyeveninsleepmode.
DualFunction Power Button:Pushthepowerbutton forlessthan4 seconds
when the system is operating places the system into sleep or soft-off
modes, depending on the BIOS or OS setting. If the power button is
pressed for more than 4 seconds, the system enters the soft-off mode
regardless of the BIOS setting.

4 Chapter 1: Product introduction
Location
Processor Support Socket A for AMD
®
Athlon
™
XP and Duron
™
Processors .1
Feature Setting DIP Switches .........................................6
Chipsets SiS
®
745 chipset..............................................................2
Realtek 1394 PHY (Optional) ........................................13
2Mbit programmable Flash EEPROM ........................... 18
Multi-I/O controller .........................................................19
6-CH Audio controller (Optional) ...................................22
Main Memory Maximum 3GB support
3 DDR DIMM Sockets .....................................................3
Expansion Slots 5 PCI Slots ....................................................................21
1 Accelerated Graphics Port (AGP) 4X Slot ....................5
1 Audio Modem Riser (AMR) Slot (Optional) ................ 17
System I/O 2 IDE Connectors ............................................................7
1 Floppy Disk Drive Connector .......................................8
1 System Panel Connector .............................................9
1 ASUS iPanel & Infrared Connector ............................10
3 1394 Headers (Optional) ............................................ 11
USB Headers (Ports 2/3) ..............................................12
Smart Card Connector ..................................................15
USB Headers (Ports 4/5) ..............................................16
1 PS/2 Mouse Connector .................................(green) 25
1 PS/2 Keyboard Connector .......................... (purple) 33
1 Parallel Port................................................................26
1 Game/MIDI Port (Optional) ........................................27
2 Serial Ports (COM1/COM2) .......................................31
USB Connectors (Ports 0/1).......................................... 32
Hardware Monitoring System Voltage Monitor ................................................19
Special Feature Onboard LED ................................................................14
Audio Features (on audio models only)
SPDIF Digital Audio Connector ..................................... 20
6-CH Audio Controller ...................................................22
1 ASUS Front Audio Panel Connectors.........................23
Audio Connectors..........................................................24
1 Line Out Connector ......................................... (lime) 30
1 Line In Connector ................................... (light blue) 29
1 Microphone Connector .................................... (pink) 28
Power ATX Power Supply Connector.........................................4
Form Factor ATX
1.4 Motherboard Components
Before installing the A7S333 motherboard, take time to familiarize yourself
withits configuration: understanding the motherboard makesupgradingeasy.
Sufficient knowledge of specifications prevents accidental damage.

ASUS A7S333 motherboard user guide 5
1.4.1 Component Locations
25 26 27
28
293032 3133
12 3
17
21 7
4
6
8
5
9
15
19
18
22
23
101216 1113
20
24
14

Chapter 2
Hardware information

ASUS A7S333 motherboard

ASUS A7S333 motherboard user guide 7
2.1 Motherboard installation
TheA7S333 usestheATXform factor, measuring 21.9 cm(8.6 in.) x30.5 cm
(12 in.) - a standard fit for most large chassis.
2.1.1 Placement direction
When installing the motherboard, take care to orient the chassis correctly:
Theedge with externalports goes to the rear part of the chassis. Refer to the
image below. It may be more convenient to install major cables, the CPU
andmodularcomponentsbeforefixingthe motherboardinsidethecaseframe.
2.1.2 Screw holes
Place six (6) screws into the holes indicated by circles to secure the
motherboard to the chassis.
Place this side towards
the rear of the chassis
CAUTION! Do not overtighten the screws! Doing so may damage the
motherboard.
WARNING! Unplug the power cord before installing the motherboard.
Failureto do so may cause you physical injury and damage motherboard
components.

8 Chapter 2: Hardware information
24cm (9.4in)
30.5cm (12.0in)
PWR_FAN
PCI1
FLOPPY
SEC_IDE
PRI_IDE
A7S333
®
CR2032 3V
Lithium Cell
CMOS Power
CPU_FAN
FP_LINE_IN
CDAUX
MODEM
USBPWR_34
FP_AUDIO
BCS1
IDELED
USB
T: USB1
B: USB2
PS/2KBMS
T: Mouse
B: Keyboard
Accelerated Graphics Port
AGP
AMR
BCS2
C-Media
CMI8738 6CH
Audio Controller
SPDIF
FP_LO_SWR
PCI2
PCI3
PCI4
PCI5
GAME_AUDIO
Mic
In
Line
Out
Line
In
PANEL
CHA_FAN
AFPANEL
SMB
SMARTCON
ATX Power Connector
Super
I/O
DSW
2Mbit
Firmware
Hub
IEEE1394_1
SiS
745
Chipset
USBPWR_12
KBPWR
USB_34
DDR DIMM1 (64/72 bit, 184-pin module)
0 1
DDR DIMM3 (64/72 bit, 184-pin module)
4 5
DDR DIMM2 (64/72 bit, 184-pin module)
2 3
JEN
AUDIO_EN
IEEE1394_2
IEEE1394_3
USB_56
USBPWR_56
PARALLEL PORT
COM1
COM2
CLRTC
Socket 462
RTL8801
LED
FP_LO_SWL
Optional components are grayed in the above motherboard layout.
