Asus A7V266-E AA User manual

®
A7V266-E
JumperFree™DDR DRAM
266MHz FSB AGP Pro/4X
Socket A Motherboard
USER’S MANUAL

ASUS A7V266-E User’s Manual
2
USER'S NOTICE
Product Name: ASUS A7V266-E
Manual Revision: 1.00 E883
Release Date: October 2001
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or
by any means, except documentation kept by the purchaser for backup purposes, without the express
written permission of ASUSTeK COMPUTER INC. (“ASUS”).
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER
EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES
OR CONDITIONS OF MERCHANTABILITY OR FITNESS FORAPARTICULAR PURPOSE. IN
NO EVENT SHALLASUS, ITS DIRECTORS, OFFICERS, EMPLOYEES ORAGENTS BE LIABLE
FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES
(INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE OR
DATA, INTERRUPTION OF BUSINESSAND THE LIKE), EVEN IFASUS HAS BEENADVISED
OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR ERROR IN
THIS MANUAL OR PRODUCT.
Product warranty or service will not be extended if: (1) the product is repaired, modified or altered,
unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial
number of the product is defaced or missing.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identification or explanation and to
the owners’ benefit, without intent to infringe.
• Intel and Pentium are registered trademarks of Intel Corporation.
• VIAis a registered trademark of VIATechnologies, Inc.
• 3Com is a registered trademark of 3Com Corporation.
• C-Media is a registered trademark of C-Media Electronics Inc.
• Windows and MS-DOS are registered trademarks of Microsoft Corporation.
• Adobe and Acrobat are registered trademarks of Adobe Systems Incorporated.
• Trend and ChipAwayVirus are trademarks of Trend Micro, Inc.
• Symbios is a registered trademark of Symbios Logic Corporation.
The product name and revision number are both printed on the product itself. Manual revisions are
released for each product design represented by the digit before and after the period of the manual
revision number. Manual updates are represented by the third digit in the manual revision number.
For previous or updated manuals, BIOS, drivers, or product release information, contact ASUS at
http://www.asus.com.tw or through any of the means indicated on the following page.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED
FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME
WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS.
ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR
INACCURACIES THATMAYAPPEAR IN THIS MANUAL, INCLUDINGTHE PRODUCTSAND
SOFTWARE DESCRIBED IN IT.
Copyright © 2001ASUSTeK COMPUTER INC.All Rights Reserved.

ASUS A7V266-E User’s Manual 3
ASUS CONTACT INFORMATION
ASUSTeK COMPUTER INC. (Asia-Pacific)
Marketing
Address: 150 Li-Te Road, Peitou, Taipei, Taiwan 112
Telephone: [phone]
Fax: [phone]
Email: [email protected]
Technical Support
MB/Others (Tel): [phone] (English)
Notebook (Tel): [phone] (English)
Desktop/Server (Tel):[phone] (English)
Fax: [phone]
Email: [email protected]
WWW: www.asus.com.tw
FTP: ftp.asus.com.tw/pub/ASUS
ASUS COMPUTER INTERNATIONAL (America)
Marketing
Address: 6737 Mowry Avenue, Mowry Business Center, Building 2
Newark, CA 94560, USA
Fax: [phone]
Email: [email protected]
Technical Support
Fax: [phone]
Email: [email protected]
WWW: www.asus.com
FTP: ftp.asus.com/Pub/ASUS
ASUS COMPUTER GmbH (Europe)
Marketing
Address: Harkortstr. 25, 40880 Ratingen, BRD, Germany
Fax: [phone]
Email: [email protected] (for marketing requests only)
Technical Support
Hotline: MB/Others: [phone] Notebook:[phone]
Fax: [phone]
Support (Email): www.asuscom.de/de/support (for online support)
WWW: www.asuscom.de
FTP: ftp.asuscom.de/pub/ASUSCOM

ASUS A7V266-E User’s Manual
4
CONTENTS
1. INTRODUCTION ............................................................................. 7
1.1 How This Manual Is Organized ................................................... 7
1.2 Item Checklist .............................................................................. 7
2. FEATURES ........................................................................................ 8
2.1 ASUS A7V266-E Motherboard ................................................... 8
2.1.1 Specifications ..................................................................... 8
2.1.2 Performance...................................................................... 10
2.1.3 Intelligence ....................................................................... 11
2.2 Motherboard Components.......................................................... 12
2.2.1 Component Locations....................................................... 13
3. HARDWARE SETUP ...................................................................... 14
3.1 Motherboard Layout .................................................................. 14
3.2 Layout Contents ......................................................................... 15
3.3 Hardware Setup Procedure......................................................... 17
3.4 Motherboard Settings ................................................................. 17
3.5 System Memory ......................................................................... 25
3.5.1 DDR DIMM Support........................................................ 25
3.5.1 General DIMM Notes....................................................... 26
3.5.2 Memory Installation ......................................................... 26
3.6 Central Processing Unit (CPU) .................................................. 27
3.7 Expansion Cards ........................................................................ 28
3.7.1 Installing an Expansion Card ........................................... 28
3.7.2 Assigning IRQs for Expansion Cards .............................. 29
3.7.3 Accelerated Graphics Port (AGP) Pro Slot ...................... 30
3.7.4 Advanced Communication Riser (ACR) Slot .................. 30
3.8 Connectors ................................................................................ 31
3.8.1 External Connectors ......................................................... 31
3.9 Starting Up the First Time.......................................................... 44
4. BIOS SETUP..................................................................................... 45
4.1 Managing and Updating Your BIOS .......................................... 45
4.1.1 Upon First Use of the Computer System.......................... 45
4.1.2 Updating BIOS Procedures .............................................. 47
4.2 BIOS Setup Program.................................................................. 49
4.2.1 BIOS Menu Bar................................................................ 50
4.2.2 Legend Bar ....................................................................... 50

ASUS A7V266-E User’s Manual 5
CONTENTS
4.3 Main Menu ................................................................................. 52
4.3.1 Primary & Secondary Master/Slave ................................. 53
4.3.2 Keyboard Features............................................................ 56
4.4 Advanced Menu ......................................................................... 58
4.4.1 Chip Configuration........................................................... 62
4.4.2 I/O Device Configuration ................................................. 65
4.4.3 PCI Configuration ............................................................ 67
4.5 Power Menu ............................................................................... 69
4.5.1 Power Up Control............................................................. 71
4.5.2 Hardware Monitor ............................................................ 73
4.6 Boot Menu ................................................................................. 74
4.7 Exit Menu................................................................................... 76
5. SOFTWARE SETUP....................................................................... 79
5.1 Install Operating System............................................................ 79
5.2 Start Windows ............................................................................ 79
5.3 A7V266-E Motherboard Support CD ........................................ 80
5.3.1 Installation Menu.............................................................. 80
5.4 Using the Promise Chip for RAID 0 or 1................................... 82
6. SOFTWARE REFFERENCE......................................................... 91
6.1 Winbond Smart Manager ........................................................... 91
6.2 ASUS PC Probe ......................................................................... 95
6.3 Multi-Channel Audio Feature Setup......................................... 100
6.4 ASUS Live Update................................................................... 102
6.5 3Deep Color Tuner................................................................... 103
6.6 CyberLink PowerPlayer SE ..................................................... 105
6.7 CyberLink VideoLive Mail ...................................................... 106
7. APPENDIX..................................................................................... 109
7.1 Modem Riser............................................................................ 109
7.1.1 56K Software Modem .................................................... 109
7.1.2 Primary/Seconday MR ................................................... 109
7.1.3 Hardware Installation Procedure .................................... 109
7.1.4 Software Setup in Windows 98 ...................................... 110
7.2 Glossary ................................................................................... 111
INDEX ................................................................................................. 115

ASUS A7V266-E User’s Manual
6
FCC & DOC COMPLIANCE
Federal Communications Commission Statement
This device complies with FCC Rules Part 15. Operation is subject to the following
two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received, including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with manufacturer's instructions, may
cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Re-orient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
WARNING!Any changes or modifications to this product not expressly approved
by the manufacturer could void any assurances of safety or performance and
could result in violation of Part 15 of the FCC Rules.
Reprinted from the Code of Federal Regulations #47, part 15.193, 1993. Washington DC: Office of the
Federal Register, NationalArchives and Records Administration, U.S. Government Printing Office.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for radio noise emissions
from digital apparatus set out in the Radio Interference Regulations of the Canadian
Department of Communications.
This Class B digital apparatus complies with Canadian ICES-003.
Cetappareilnumériquedelaclasse Bestconformeàlanorme NMB-003 duCanada.

ASUS A7V266-E User’s Manual 7
1.1 How This Manual Is Organized
This manual is divided into the following sections:
1. INTRODUCTION Manual information and checklist
2. FEATURES Production information and specifications
3. HARDWARE SETUP Instructions on setting up the motherboard.
4. BIOS SETUP Instructions on setting up the BIOS
5. SOFTWARE SETUP Instructions on setting up the included software
6. SOFTWARE REFERENCE Reference material for the included software
7. APPENDIX Optional items and general reference
1.2 Item Checklist
Check that your package is complete. If you discover damaged or missing items,
contact your retailer.
1. INTRODUCTION
1. INTRODUCTION
Manual / Checklist
Package Contents
(1) ASUS Motherboard
(1) 40-pin 80-conductor ribbon
cable for internal
UltraDMA100/66//33 IDE
drives
(1) Ribbon cable for two 3.5”
floppy disk drives
(1) ASUS Support CD with drivers
and utilities
(1) Bag of spare jumper caps
(1) ASUS 2-port USB Connector
Set
(1) User’s Manual
Optional Items
ASUS IrDA-compliant infrared
module

8ASUS A7V266-E User’s Manual
2.1 ASUS A7V266-E Motherboard
TheASUSA7V266-E motherboard is the perfect answer for home PCs, workstations
and servers. The A7V266-E is powered by the AMD
®
Athlon
™
/Duron
™
processor
and is bundled with advanced features to provide superlative performance.
2.1.1 Specifications
•AMD
®
Athlon
™
/Athlon XP
™
and Duron
™
Processor Support
•North Bridge System Chipset: Features the VIA
®
KT266A North Bridge that
supports AGP 4X/2X mode, 133/100MHz Front Side Bus (FSB), and
266/200MHz memory bus.
•South Bridge System Chipset: VIA
®
VT8233 integrated peripheral controller
supportsUltraDMA/100/66/33forburst mode data transfer ratesofup to 100MB/
sec, and USB controller with three root hubs for six USB ports.
•PC2100 / PC1600 DDR Support: Equipped with three Double Data Rate Dual
Inline Memory Module (DDR DIMM) sockets to support up to 3GB of DDR
DRAM. DDRDRAMis the newest memory standard with the highest bandwidth
and lowest latency currently available and dramatically improves the memory
system’s abilitytoservice,amongothers,highmultimediarequirements. (Caution:
Do not attempt to use SDRAM modules.)
•JumperFree™Mode: Allows processor settings and easy overclocking of
frequency and Vcore voltage through BIOS. Easy-to-use DIP switches come
withthe motherboard board to allowmanualadjustmentof the processor external/
internal frequency.
•UltraDMA/100Support:ComeswithanonboardPCIBusMasterIDEcontroller
with two connectors that support four IDE devices on two channels. Supports
UltraDMA/100, UltraDMA/66, UltraDMA/33, PIO Modes 3 & 4, Bus Master
IDE DMA Mode 2, and Enhanced IDE devices, such as DVD-ROM, CD-ROM,
CD-R/RW, LS-120, and Tape Backup drives.
•SuperMulti-I/O: The multi-I/O chipset offers complete support for a variety of
I/O functions. Provides two high-speed UART compatible serial ports and one
parallel port with EPP and ECP capabilities. UART2 can also be directed from
COM2 to the Infrared Module for wireless connections.The Super I/O controller
also supports a floppy disk drive, PS/2 keyboard, and PS/2 mouse.
•Promise
®
chip: The Promise IDE controller chip supports theATA-100 protocol
and Ultra DMA/100 data transfer speeds. The chip also delivers reliable
redundancy and stable performance for RAID levels 0 or 1. Data “striping,”or
RAID 0, improves speed performance as I/O tasks are spread between two hard
disk drives. Data “mirroring,”or RAID 1, improves system fault tolerance as
the protocol optimizes two identical hard disks to write data to each other.
2. FEATURES
Specifications
2. FEATURES

ASUS A7V266-E User’s Manual 9
2. FEATURES
2. FEATURES
Specifications
•Smart BIOS: 2Mb firmware enables Vcore and CPU/DDR SDRAM frequency
adjustments,bootblock write protection, and HD/SCSI/MO/ZIP/CD/Floppy boot
selection.
2.1.2 Connections
•CPU socket: Socket A (462) for AMD
®
processors.
•PCI Expansion Slots: Provides five 32-bit Legacy Free PCI slots, (PCI 2.2
compliant) with no ISA, eliminating bottlenecks and system memory
management issues. All PCI slots can support Bus Master PCI cards, such as
SCSI or LAN cards. (PCI supports up to 133MB/s maximum throughput.) The
MB supports Concurrent PCI, which allows multiple PCI transfers from PCI
master bus to the memory and processor.
•IDE connectors: Dual-channel bus master IDE connectors support up to four
Ultra DMA/100/66, PIO Modes 3 & 4 IDE devices like two HDDs, one DVD
and an R/W CD.
•AGP Pro Slot: Comes with an Accelerated Graphics Port Pro slot that
supports AGP cards for high performance, component level interconnect
targeted at 3D graphical applications using a 4X mode bus. The slot is keyed to
support only the latest 1.5 volt AGP cards.
•Floppy disk connector: Supports the floppy disk drive.
•Wake-On-LAN: Supports Wake-On-LAN activity through an optional ASUS
PCI-L101 10 /100 Fast Ethernet PCI card.
•Wake-On-Ring: Supports Wake-On-Ring activity through a PCI modem card.
•Smartcard Reader Connector: Supports a PS/SC compatible Smart Card
•USB ports: Four Universal Serial Bus (USB) ports are available for connecting
USB devices such as a mouse and PDA.
•Serial ports: Two 9-pin COM1/COM2 ports are for all serial devices.
•IrDA: Supports an optional infrared port module for a wireless interface.
•Microphone: Pink jack connects a microphone (or 6 channel speaker).
•Line In: Light blue jack connects a tape player (or 6 channel speaker).
•Line Out: Lime jack connects a headphone, a speaker (or 6 channel speaker).
•Game/MIDI connector. This connector supports a joystick or a game pad for
playing games, and MIDI devices for playing or editing audio files.
•Parallel port: 25-pin port connects a parallel printer or other devices.
•PS/2 mouse port: Green 6-pin connector is for a PS/2 mouse.
•PS/2 keyboard port: Purple 6-pin connector is for a PS/2 keyboard.
•Onboard LED: Signals AC power is okay.
•ATX power connector. Supplies the MB with ATX 12V power. The power
supply must have at least 1A on the +5V standby lead (+5VSB).

10 ASUS A7V266-E User’s Manual
2. FEATURES
Performance
2. FEATURES
2.1.2 Performance
•DDR DRAM Optimized Performance: This motherboard supports a new
generation memory, Double Data Rate (DDR) Dynamic RandomAccess Memory
(DDR DRAM). This new memory technology increases performance by
executing two actions per clock cycle, resulting in data transfer rates of up to 2.1
GB/s for 133MHz DDR SDRAM and 1.6GB/s for 100MHz DDR SDRAM.
•OnboardAudio: Audio models come with the six-channel C-Media CMI8738
PCI audio controller that supplies HRTF 3D positional audio functions. The
chip supports software access to PC DVD 5.1/6.1 and AC-3/DTS via SPDIF.
Other integrative featues include: full DVD playback, PCtel 56K modem, and
even Karaoke echo effects. The chip offers 24-bit SPDIF digital recording and
playback with additional support for legacy audio SBPRO™and FM emulator/
DLS wavetable music synthesis. A software package helps setup the multi-
channel PC sound system.
•ACPI Ready: Advanced Configuration Power Interface (ACPI) provides more
Energy Saving Features for operating systems that support OS Direct Power
Management (OSPM) functionality. With these features employed in the OS,
PCs can be ready around the clock but comply with energy saving standards. To
fully utilize theACPI benefits, use anACPI-supported OS such as Windows 98.
•Smartcard Reader Connector: This connector that provides the convenience
of PS/SC compatible Smart Card security plus support for a multitude of new
financial, telephonic, and mobile access services.
•PC’99 Compliant: Both the BIOS and hardware levels of ASUS smart series
motherboards are PC’99 compliant. The new PC’99 requirements for systems
and components are based on the following high-level goals: Support for Plug-
n-Play compatibility and power management for configuring and managing all
system components, and 32-bit device drivers and installation procedures for
Windows95/98/NT. Color-coded connectors and descriptive icons make
identification easy as required by PC’99.
•High-Speed Data Transfer Interface: Support for UltraDMA/100 through the
onboard IDE bus master controller triples the UltraDMA/33 burst transfer rate.
UltraDMA/100 is backward compatible with DMA/66, DMA/33, and other
existing DMA devices to save the need to upgrade current EIDE/IDE drives.
(UltraDMA/66 requires a 40-pin 80-conductor cable).
•ConcurrentPCI: ConcurrentPCIallows multiple PCI transfers fromPCImaster
busses to the memory and processor.

ASUS A7V266-E User’s Manual 11
2. FEATURES
2. FEATURES
Intelligence
2.1.3 Intelligence
•Auto Fan Off: The system fans powers off automatically even in sleep mode.
This function reduces both energy consumption and system noise, and is an
important feature in implementing silent PC systems.
•Dual Function PowerButton: Pushing the power button for less than 4 seconds
when the system is in the working state places the system into one of two states:
sleep mode or soft-off mode, depending on the BIOS or OS setting (See PWR
Button < 4 Secs in 4.5 Power Menu). When the power button is pressed for
more than 4 seconds, the system enters the soft-off mode regardless of the BIOS
setting.
•Fan Status Monitoring and Alarm: To prevent system overheat and system
damage, the CPU and system fans can be monitored for RPM and failure. All
fans are set for its normal RPM range and alarm thresholds.
•PowerLED (requiresACPIOS support):The power LEDindicates the system
status.
•Remote Ring-On (requires modem): This allows a computer to be turned on
remotely through an internal or external modem. With this benefit on-hand, users
can access vital information from their computers anywhere.
•Temperature Monitoring and Alert: CPU temperature is monitored by the
ASUS ASIC through the CPU’s internal thermal diode (on Pentium III and
Celeron) to prevent system overheat and system damage.
•Voltage Monitoring andAlert: System voltage levels are monitored to ensure
stable voltage to critical motherboard components. Voltage specifications are
more critical for future processors, so monitoring is necessary to ensure proper
system configuration and management.
•Chassis Intrusion Detection: Supports chassis-intrusion monitoring through
the ASUS ASIC. A chassis intrusion event is kept in memory on battery power
for more protection.

12 ASUS A7V266-E User’s Manual
2. FEATURES
2. FEATURES
M/B Components
Location
Processor Support Socket A for AMD
®
Athlon
™
and Duron
™
Processors.............. 2
Feature Setting DIP Switches ................................................... 3
Chipsets VIA
®
KT266A North Bridge .................................................... 1
VIA
®
VT8233 South Bridge ................................................... 11
Promise IDE / RAID controller ................................................ 8
ASUS System Monitor controller ............................................ 9
Multi-I/O controller ................................................................ 20
2Mbit Programmable Flash EEPROM ................................... 19
Main Memory Maximum 3GB support
3 DDR DIMM Sockets ............................................................. 4
Expansion Slots 5 PCI Slots .............................................................................. 17
1 Accelerated Graphics Port (AGP) Pro/4X Slot ................... 22
1 Advanced Communication Riser ......................................... 14
System I/O 1 Floppy Disk Drive Connector ............................................. 12
2 IDE Connectors (UltraDMA/100 / RAID Support) .............. 6
2 IDE Connectors (UltraDMA/100 Support) ........................... 7
1 ASUS iPanel Connector ...................................................... 10
1 Smart Card Connector ......................................................... 18
1 Parallel Port ............................................................... (Top) 25
2 Serial Ports (COM1/COM2) ......................... (Bottom) 24, 26
USB Connectors (Port 0 & Port 1) ........................ (Bottom) 27
USB Connectors (Ports 2/3/4/5) ............................................. 13
1 PS/2 Mouse Connector .............................................. (Top) 28
1 PS/2 Keyboard Connector ................................... (Bottom) 28
Hardware Monitoring System Voltage Monitoring (integrated in ASUS ASIC) ......... 9
Special Feature Onboard LED ......................................................................... 21
Audio Features (on audio models only)
CMI8738 6-Channel Audio Controller Chipset ..................... 15
1 ASUS iPanel Audio Connector............................................ 16
1 Game/MIDI Port........................................................ (Top) 23
1 Line Out Connector ..................................... (Bottom, left) 23
1 Line In Connector................................... (Bottom, center) 23
1 Microphone Connector ............................. (Bottom, right) 23
Internal Audio Connectors
Power ATX Power Supply Connector ................................................. 5
Form Factor ATX
2.2 Motherboard Components
See opposite page for locations.

ASUS A7V266-E User’s Manual 13
2. FEATURES
2. FEATURES
Motherboard Parts
2.2.1 Component Locations
4
26
23
27
25
21
9
15
19
22
24
28
27
14
1011
6
15
20
17
3
8
18
16
1213

14 ASUS A7V266-E User’s Manual
3. HARDWARE SETUP
3.1 Motherboard Layout
Motherboard Layout
3. H/W SETUP
24.5cm (9.64in)
30.5cm (12.0in)
PR0MISE IDE2
Secondary IDE
PANEL
FLOPPY
VIA
VT8233
Chipset
ASUS
ASIC
with Hardware
Monitor
PCI 1
Accelerated Graphics Port (AGP Pro)
VIA
KT266A
Chipset
CR2032 3V
Lithium Cell
CMOS Power
GAME_AUDIO
Mic
In
Line
Out
Line
In
AUX
MODEM
CD
LED
JEN
COM1
PARALLEL PORT
COM2
CPU_RATIO
Socket 462
01
DDR DIMM1 (64/72 bit, 184-pin module)
0 1
01
DDR DIMM2 (64/72 bit, 184-pin module)
2 3
CHASSIS
PS/2
T: Mouse
B: Keyboard
USB1
USB2
ATX Power Connector
CPU_FAN
PWR_FAN
CHA_FAN
CLR_RTC
JTPWR
DSW
USB2_3
IR_CON IDELED
SMARTCARD
USB4_5
USB45_PWR
USB23_PWR
MIC2
HPHOME
ACR
PCI 2
PCI 3
PCI 4
PCI 5
Super
I/O
2Mb
BIOS
C-Media
CMI8738 6CH
Audio Controller
SYSCLK
DSW
BCS
SMB_CON
SPDIF OUT
CDSPDIF IN
VID1
VID2
VID3
VID4
USB01_PWR
KBWK
JP1
JP2
ACRUSB CHA
01
DDR DIMM3 (64/72 bit, 184-pin module)
4 5
PALO_FREQ
THEMCPU
AAPANEL
AFPANEL
PROMISE
IDE
Controller
Primary IDE
PR0MISE IDE1
A7V266-E
RAID / IDE

ASUS A7V266-E User’s Manual 15
3. HARDWARE SETUP
3. HARDWARE SETUP
3.2 Layout Contents
Motherboard Settings
1) JEN p. 18 JumperFree Mode Setting (Disable / Enable)
2) DIP_SW p. 19 CPU External Frequency Selection (Switches 1–4)
3) DSW p. 20 Manual CPU Ratio Settings (Switches 1-5)
4) PALO_FREQ p. 20 FID setting (FID0-3)
5) JP1, JP2 p. 20 I/O Voltage Settings (2.5V/2.65V/2.75V/2.8V)
6) VID1, 2, 3, 4 p. 21 Voltage Regulator Output Volt. Setting (1.675V-1.85 V)
7) CENTER/BASS, p. 21 Bass Center Setting (Type 1 or Type 2)
BASS/CENTER
8) KBWK p. 22 Keyboard Power Up (Enable / Disable)
9) ACRUSB1, ACRUSB2 p. 22 ACR/USB Selection (USB to Conn. / USB on ACR)
10) USB01, 23, 45_PWR p. 23 Three USB Device Wake-ups (+5V / +5VSB)
11) JP2601 p. 23 IDE Channel Setting (ATA100 or RAID 1/0)
12) CLR_RTC p. 24 Clear RTC RAM (2 pin contact)
13) THEMCPU p. 24 Thermal Sensor CPU Setting (Athlon-Duron / Reserved)
Expansion Slots/Sockets
1) DIMM 1/2/3 p. 25 System Memory Support
2) Socket 462 p. 27 CPU Support
3) PCI 1/2/3/4/5 p. 28 32-bit PCI Bus Expansion Slots
4) AGP Pro p. 30 Accelerated Graphics Port Slot
5) ACR Slot p. 30 Advanced Communication Riser Slot
Connectors
1) PS2KBMS p. 31 PS/2 Mouse Port (6 pin female)
2) PS2KBMS p. 31 PS/2 Keyboard Port (6 pin female)
3) USB p. 32 Universal Serial Bus Ports 1&2(Two4 pin female)
4) PRINTER p. 32 Parallel Port (25 pin female)
5) COM1/COM2 p. 32 Serial Ports (9 pin /10-1 pin male)
6) GAME_AUDIO p. 33 Game/MIDI Port (15-pin female) (optional)
7) AUDIO p. 33 Audio Connectors (Three 1/8”AUDIO) (optional)
8) IDELED p. 34 IDE Activity LED (2 pin)
9) FLOPPY p. 34 Floppy Disk Drive Connector (34 pin)
10) PRIMARY / SEC. IDE p. 35 IDE Connectors (Two 40-1 pin)
11) CPU/PWR/CHA_FAN p. 36 CPU, Power, and Chassis Fan Connectors (Three 3 pin)
12) USB2_3 / USB4_5 p. 36 USB Headers (10-1 pin)
13) IR_CON p. 37 Standard Infrared Module Connector (10-1 pin)
14) AFPANEL p. 37 ASUS iPanel Connector (12-1 pin)
15) ATXPWR p. 38 ATX Power Supply Connector (20 pin)
Layout Contents
3. H/W SETUP

16 ASUS A7V266-E User’s Manual
3. HARDWARE SETUP
Layout Contents
3. H/W SETUP
16) SMB p. 38 SMBus Connector (5-1 pin)
17) CD/AUX/MODEM p. 39 Internal Audio Connectors (Three 4-1 pin) (optional)
18) MIC2 p. 39 Internal Microphone Connector (3 pin) (optional)
19) HPHONE p. 40 Headphone Line Out connector (3 pin) (optional)
20) JTPWR p. 40 Power Supply Thermal Sensor (2 pin)
21)
SPDIFOUT / CDSPDIFIN p. 41 Digital audio Interfaces (2 pin) (optional)
22) CHASSIS p. 41 Chassis Intrusion Lead (2 pin)
23) AAPANEL p. 42 ASUS iPanel Audio Connector (10-1 pin)
24) SMARTCON p. 42 ASUS SmartCard Connector (14-1 pin)
25)
PWR.LED ( PANEL ) p. 43 System Power LED Lead (3 pin)
26) KEYLOCK
( PANEL ) p. 43 System Keyboard Lock Switch Lead (2 pin)
27) SPEAKER (PANEL) p. 43 System Warning Speaker Lead (4 pin)
28) MSG.LED (PANEL) p. 43 System Message LED Lead (2 pin)
29) SMI (PANEL) p. 43 System Management Interrupt Lead (2 pin)
30) PWR.SW (PANEL) p. 43 ATX / Soft-Off Switch Lead (2 pin)
31) RESET (PANEL) p. 43 Reset Switch Lead (2 pin)

ASUS A7V266-E User’s Manual 17
3. HARDWARE SETUP
3.3 Hardware Setup Procedure
Complete the following steps before using your computer:
1. Check motherboard settings
2. Install memory modules
3. Install the Central Processing Unit (CPU)
4. Install Expansion Cards
5. Connect ribbon cables, panel wires, and power supply cables
6. Configure the BIOS parameter settings
3.4 Motherboard Settings
This section tells you how to change motherboard function settings through the
switches and/or jumpers.
3. H/W SETUP
Motherboard Settings
WARNING! Computer motherboards and expansion cards contain very delicate
Integrated Circuit (IC) chips. To avoid damaging them due to static electricity,
follow these precautions whenever you work on your computer.
1. Unplug the computer when working on the internal components.
2. Use a grounded wrist strap or touch a safely grounded object or to a metal
object, suchas thepower supplycase, before handling computercomponents.
3. Hold components by the edges and try not to touch the IC chips on them.
4. Wheneveryou uninstall any component, placethe componentsonagrounded
antistatic pad or in the bag that came with the components.
5. Beforeyouinstallorremoveanycomponent,ensurethattheATX power
supply is switched off or the power cord is detached from the power
supply. Failure to do so may cause severe damage to the motherboard,
peripherals, and/or components.
(TIP:When lit, the onboard LED indicates that the system is in suspend or
soft-off mode, not powered OFF. See illustration below.)
A7V266-E
0 10 10 1
A7V266-E Onboard LED
ON OFF
Standby
Power Powered
Off
LED

18 ASUS A7V266-E User’s Manual
3. HARDWARE SETUP
3. H/W SETUP
Motherboard Settings
Motherboard Frequency Settings (DIP Switches)
The motherboard frequency is adjusted through the DIP switches. The white block
represents the switch’s position. The illustration below shows all the switches in the
OFF position.
1) JumperFree™Mode (JEN)
This jumper allows you to enable or disable the JumperFree™mode. The
JumperFree™mode allows processor settings to be made through the BIOS
setup (see 4.4 Advanced Menu).
Setting JEN
Enable (JumperFree) [2-3] (default)
Disable (Jumper Mode) [1-2]
NOTE: In JumperFree™mode, set all DIP switches (DIP_SW) to OFF.
A7V266-E
0 10 10 1
A7V266-E Jumper Mode Setting
JEN
ON
1234
OFF
ON
CPU_RATIO
Jumper Free
(Default)
23
Jumper Mode
12
ON
12345
OFF
ON
SYSCLK
A7V266-E
0 10 10 1
A7V266-E DIP Switch
ON
1234
ON
12345
CPU_RATIO
SYSCLK
OFF
ON
OFF
ON

ASUS A7V266-E User’s Manual 19
3. HARDWARE SETUP
3. H/W SETUP
Motherboard Settings
2) CPU External Frequency Selection (DIP_SW Switches 1–4)
This option tells the clock generator what frequency to send to the CPU, DRAM,
and the PCI bus. This allows the selection of the CPU’s External frequency (or
BUS Clock). The BUS Clock multiplied by the Frequency Multiple equals the
CPU’s Internal frequency (the advertised CPU speed).
A7V266-E
0 10 10 1
A7V266-E CPU External
Frequency Selection
SYSCLK
CPU
AGP
PCI
100MHz
60.67MHz
33.33MHz (JumperFree Mode)
140MHz
70MHz
35MHz
133.33MHz
66.67MHz
33.33MHz
ON
1234
ON
1234
ON
1234
ON
1234
A7V266-E
0 10 10 1
A7V266-E CPU External
Clock (BUS) Frequency
Selection
CPU_RATIO
ON
12345
ON
12345
ON
12345
ON
12345
ON
12345
ON
12345
ON
12345
CPU_RATIO 8X
CPU_RATIO 10X 10.5X
8.5X 9X 9.5X
(JumperFree Mode)
3) Manual CPU Ratio Settings (DSW Switches 5-10)
Set DSW switches (5-10) to use the clock multiplier to coordinate the ratio of
bus speeds with CPU settings. Set the DSW switches according to the internal
speed of your processor and the bus frequency (133/100MHz).
IMPORTANT:
1. To use this feature, JEN must be set to Jumper Mode, [1-2].
(See 1, JumperFree™ Mode (JEN) in 3, HARDWARE SETUP.)
2. When JumperFree mode is enabled,useBIOSsetupin place of these switches.
(SetOperatingFrequency Settingto User Define under 4.4AdvancedMenu
in BIOS Setup so you can set the CPU Frequency.)
WARNING!SettheCPUfrequencyonlytotherecommendedsettings.Frequencies
other than the recommended CPU bus frequencies are not guaranteed to be stable.
Overclocking the processor is not recommended. It may result in a slower speed.

20 ASUS A7V266-E User’s Manual
3. HARDWARE SETUP
3. H/W SETUP
Motherboard Settings
5) I/O Voltage Settings (JP1, JP2)
These jumpers allow you to select the voltage supplied to the DRAM, chipset,
AGP, and PCI. The default setting for the jumpers is: JP1 [2-3] and JP2 [1-2],
2.65 volts. Use the default setting for better system reliability.
A7V266-E
0 10 10 1
A7V266-E Voltage Setting
JP1/JP2
2.5V 2.65V
12323
1
23
123 1
2.75V 2.8V
JP1
JP2
(Default)
4) CPU Type Frequency Setting (PALO_FREQ)
This jumper setting accomodates the difference between the internal frequency
between standard and new AMD CPUs. If changing from one type of CPU to
another, the jumper caps must be adjusted. The factory default setting, [2-3], is
for standard Athlon/Duron CPUs. The Palomino processor will only function
on this motherboard after the jumpers are adjusted to [1-2].
A7V266-E
0 10 10 1
A7V266-E PALO_FREQ Setting
PALOMINO
FID2
FID1
FID3
FID0
ATHLON/DURON
PALO_FREQ
FID2
FID1
FID3
FID0
321 321
(Default)
