Asus MAXIMUS VII GENE User manual

Motherboard
MAXIMUS VII
GENE

ii
E9752
Revised Edition V2
October 2014
Copyright © 2014 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means, except documentation kept by the purchaser for backup purposes, without the express written
permission of ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless
such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identication or explanation and to the
owners’ benet, without intent to infringe.
Offer to Provide Source Code of Certain Software
This product contains copyrighted software that is licensed under the General Public License (“GPL”),
under the Lesser General Public License Version (“LGPL”) and/or other Free Open Source Software
Licenses. Such software in this product is distributed without any warranty to the extent permitted by the
applicable law. Copies of these licenses are included in this product.
Where the applicable license entitles you to the source code of such software and/or other additional data,
you may obtain it for a period of three years after our last shipment of the product, either
(1) for free by downloading it from http://support.asus.com/download
or
(2) for the cost of reproduction and shipment, which is dependent on the preferred carrier and the location
where you want to have it shipped to, by sending a request to:
ASUSTeK Computer Inc.
Legal Compliance Dept.
15 Li Te Rd.,
Beitou, Taipei 112
Taiwan
In your request please provide the name, model number and version, as stated in the About Box of the
product for which you wish to obtain the corresponding source code and your contact details so that we
can coordinate the terms and cost of shipment with you.
The source code will be distributed WITHOUT ANY WARRANTY and licensed under the same license as
the corresponding binary/object code.
This offer is valid to anyone in receipt of this information.
ASUSTeK is eager to duly provide complete source code as required under various Free Open Source
Software licenses. If however you encounter any problems in obtaining the full corresponding source
code we would be much obliged if you give us a notication to the email address [email protected], stating
the product and describing the problem (please DO NOT send large attachments such as source code
archives, etc. to this email address).

iii
Contents
Safety information...................................................................................................... vi
About this guide........................................................................................................ vii
MAXIMUS VII GENE specifications summary.......................................................... ix
Package contents..................................................................................................... xiii
Installation tools and components......................................................................... xiv
Chapter 1: Product Introduction
1.1 Special features..........................................................................................1-1
1.1.1 Product highlights........................................................................ 1-1
1.1.2 ROG Gaming Features ............................................................... 1-3
1.1.3 ROG Exclusive Features............................................................. 1-4
1.1.4 ASUS Special Features .............................................................. 1-5
1.1.5 ROG rich bundled software......................................................... 1-6
1.2 Motherboard overview............................................................................... 1-7
1.2.1 Before you proceed..................................................................... 1-7
1.2.2 Motherboard layout ..................................................................... 1-8
1.2.3 Central Processing Unit (CPU) ................................................. 1-10
1.2.4 System memory ........................................................................ 1-11
1.2.5 Expansion slots......................................................................... 1-25
1.2.6 Onboard buttons ....................................................................... 1-28
1.2.7 Onboard LEDs .......................................................................... 1-31
1.2.8 Jumper ...................................................................................... 1-39
1.2.9 Internal connectors.................................................................... 1-40
1.2.10 ProbeIt....................................................................................... 1-50
1.2.11 SupremeFX Impact II audio card .............................................. 1-51
Chapter 2: Basic Installation
2.1 Building your PC system...........................................................................2-1
2.1.1 Motherboard installation.............................................................. 2-1
2.1.2 CPU installation........................................................................... 2-3
2.1.3 CPU heatsink and fan assembly installation............................... 2-4
2.1.4 SupremeFX Impact II audio card installation .............................. 2-7
2.1.5 DIMM installation......................................................................... 2-8
2.1.6 ATX Power connection................................................................2-9
2.1.7 SATA device connection........................................................... 2-10
2.1.8 Front I/O Connector .................................................................. 2-11
2.1.9 Expansion Card installation....................................................... 2-12
2.2 BIOS update utility...................................................................................2-13
2.3 Motherboard rear and audio connections ............................................. 2-14
2.3.1 Rear I/O connection .................................................................. 2-14
2.3.2 Audio I/O connections............................................................... 2-16

iv
2.4 Starting up for the first time.................................................................... 2-19
2.5 Turning off the computer ........................................................................ 2-19
Chapter 3: BIOS setup
3.1 Knowing BIOS ............................................................................................3-1
3.2 BIOS setup program ..................................................................................3-2
3.2.1 EZ Mode...................................................................................... 3-3
3.2.2 Advanced Mode .......................................................................... 3-4
3.2.3 QFan Control............................................................................... 3-7
3.2.4 EZ Tuning Wizard ....................................................................... 3-9
3.3 My Favorites .............................................................................................3-11
3.4 Extreme Tweaker menu ...........................................................................3-12
3.5 Main menu ................................................................................................3-32
3.6 Advanced menu .......................................................................................3-35
3.6.1 CPU Conguration .................................................................... 3-36
3.6.2 PCH Conguration .................................................................... 3-39
3.6.3 PCH Storage Conguration....................................................... 3-40
3.6.4 System Agent Conguration ..................................................... 3-42
3.6.5 USB Conguration .................................................................... 3-44
3.6.6 Platform Misc Conguration...................................................... 3-45
3.6.7 Onboard Devices Conguration................................................ 3-46
3.6.8 APM Conguration.................................................................... 3-48
3.6.9 Network Stack Conguration..................................................... 3-49
3.6.10 ROG Effects.............................................................................. 3-49
3.7 Monitor menu ...........................................................................................3-50
3.8 Boot menu ................................................................................................3-53
3.9 Tool menu.................................................................................................3-59
3.9.1 ASUS EZ Flash 2 Utility ............................................................ 3-59
3.9.2 ROG SSD Secure Erase........................................................... 3-59
3.9.3 Setup Animator ......................................................................... 3-60
3.9.4 Graphics Card Information........................................................ 3-61
3.9.5 ASUS Overclocking Prole ....................................................... 3-61
3.9.6 ASUS SPD Information............................................................. 3-62
3.9.7 ROG OC Panel H-Key Congure.............................................. 3-63
3.10 Exit menu..................................................................................................3-64
3.11 Updating BIOS..........................................................................................3-65
Chapter 4: Software support
4.1 Installing an operating system ................................................................. 4-1
4.2 Support DVD information.......................................................................... 4-1
4.2.1 Running the support DVD ........................................................... 4-1
4.2.2 Obtaining the software manuals.................................................. 4-2
4.3 Software information .................................................................................4-3
Contents

v
4.4 AI Suite 3.....................................................................................................4-3
4.5 Dual Intelligent Processors 5.................................................................... 4-6
4.5.1 5-Way Optimization..................................................................... 4-6
4.5.2 Turbo Processing Unit (TPU)...................................................... 4-7
4.5.3 Energy Processing Unit (EPU).................................................... 4-9
4.5.4 DIGI+ Power Control................................................................. 4-11
4.5.5 Fan Xpert 3 ............................................................................... 4-13
4.5.6 Turbo App ................................................................................. 4-15
4.5.7 USB 3.0 Boost...........................................................................4-16
4.5.8 EZ Update................................................................................. 4-17
4.5.9 System Information ................................................................... 4-18
4.5.10 USB BIOS Flashback................................................................ 4-20
4.5.11 USB Charger+........................................................................... 4-21
4.5.12 Push Notice............................................................................... 4-22
4.5.13 Ai Charger+............................................................................... 4-25
4.6 ROG Audio features................................................................................. 4-26
4.6.1 Sonic Studio.............................................................................. 4-26
4.6.2 Sonic SenseAmp....................................................................... 4-28
4.6.3 Sonic SoundStage .................................................................... 4-30
4.6.4 DTS Connect............................................................................. 4-31
4.7 Sonic Radar II ...........................................................................................4-32
4.8 GameFirst III .............................................................................................4-34
4.9 KeyBot.......................................................................................................4-37
4.10 ASUS Media Streamer .............................................................................4-39
4.11 ASUS Disk Unlocker ................................................................................ 4-41
4.12 RAMDisk ...................................................................................................4-42
4.13 MemTweakIt..............................................................................................4-45
4.14 ROG CPU-Z...............................................................................................4-47
Chapter 5: RAID support
5.1 RAID configurations ..................................................................................5-1
5.1.1 RAID denitions .......................................................................... 5-1
5.1.2 Installing Serial ATA hard disks .................................................. 5-2
5.1.3 Setting the RAID item in BIOS .................................................... 5-2
5.1.4 Intel®Rapid Storage Technology Option ROM utility.................. 5-3
5.2 Creating a RAID driver disk ......................................................................5-7
5.2.1 Creating a RAID driver disk without entering the OS.................. 5-7
5.2.2 Creating a RAID driver disk in Windows®.................................... 5-8
5.2.3 Installing the RAID driver during Windows®OS installation........ 5-8
Appendices
Notices .................................................................................................................... A-1
ASUS contact information...................................................................................... A-4
Contents

vi
Safety information
Electrical safety
• To prevent electrical shock hazard, disconnect the power cable from the electrical outlet
before relocating the system.
• When adding or removing devices to or from the system, ensure that the power cables
for the devices are unplugged before the signal cables are connected. If possible,
disconnect all power cables from the existing system before you add a device.
• Before connecting or removing signal cables from the motherboard, ensure that all
power cables are unplugged.
• Seek professional assistance before using an adapter or extension cord. These devices
could interrupt the grounding circuit.
• Ensure that your power supply is set to the correct voltage in your area. If you are not
sure about the voltage of the electrical outlet you are using, contact your local power
company.
• If the power supply is broken, do not try to x it by yourself. Contact a qualied service
technician or your retailer.
Operation safety
• Before installing the motherboard and adding devices on it, carefully read all the manuals
that came with the package.
• Before using the product, ensure all cables are correctly connected and the power
cables are not damaged. If you detect any damage, contact your dealer immediately.
• To avoid short circuits, keep paper clips, screws, and staples away from connectors,
slots, sockets and circuitry.
• Avoid dust, humidity, and temperature extremes. Do not place the product in any area
where it may become wet.
• Place the product on a stable surface.
• If you encounter technical problems with the product, contact a qualied service
technician or your retailer.

vii
About this guide
This user guide contains the information you need when installing and conguring the
motherboard.
How this guide is organized
This guide contains the following parts:
• Chapter1:Productintroduction
This chapter describes the features of the motherboard and the new technology it
supports. It includes description of the switches, jumpers, and connectors on the
motherboard.
• Chapter2:BasicInstallation
This chapter lists the hardware setup procedures that you have to perform when
installing system components.
• Chapter3:BIOSsetup
This chapter tells how to change system settings through the BIOS Setup menus.
Detailed descriptions of the BIOS parameters are also provided.
• Chapter4:Softwaresupport
This chapter describes the contents of the support DVD that comes with the
motherboard package and the software.
• Chapter5:RAIDsupport
This chapter describes the RAID congurations.
Where to find more information
Refer to the following sources for additional information and for product and software
updates.
1. ASUS website
The ASUS website (www.asus.com) provides updated information on ASUS hardware
and software products.
2. Optional documentation
Your product package may include optional documentation, such as warranty yers,
that may have been added by your dealer. These documents are not part of the
standard package.

viii
Conventions used in this guide
To ensure that you perform certain tasks properly, take note of the following symbols used
throughout this manual.
DANGER/WARNING: Information to prevent injury to yourself when trying to
complete a task.
CAUTION: Information to prevent damage to the components when trying to
complete a task
IMPORTANT: Instructions that you MUST follow to complete a task. .
NOTE: Tips and additional information to help you complete a task.
Typography
Bold text Indicates a menu or an item to select.
Italics Used to emphasize a word or a phrase.
<Key> Keys enclosed in the less-than and greater-than sign
means that you must press the enclosed key.
Example: <Enter> means that you must press the Enter or
Return key.
<Key1> + <Key2> + <Key3> If you must press two or more keys simultaneously, the key
names are linked with a plus sign (+).

ix
MAXIMUS VII GENE specifications summary
(continued on the next page)
CPU
LGA1150 socket for 4th, New 4th, and 5th Generation Intel®
Core™ i7/Intel®Core™ i5/ Intel®Core™ i3, Pentium®, and Celeron®
processors
Supports 22nm CPU
Supports Intel®Turbo Boost Technology 2.0
*The Intel®Turbo Boost Technology 2.0 support depends on the CPU
types.
*Refer to www.asus.com for Intel CPU support list
Chipset Intel®Z97 Express Chipset
Memory
Dual channel memory architecture
4 x DIMM, max. 32GB, DDR3 3300 (O.C.) / 3200 (O.C.) / 3100
(O.C.) / 3000 (O.C.) / 2933 (O.C.) / 2800 (O.C.) / 2666 (O.C.) / 2600
(O.C.) / 2500 (O.C.) / 2400 (O.C.) / 2200 (O.C.) / 2133 (O.C.) / 2000
(O.C.) / 1866 (O.C.) / 1800 (O.C.) / 1600 / 1333 MHz, non-ECC,
un-buffered memory
Supports Intel® Extreme Memory Prole (XMP)
* Hyper DIMM support is subject to the physical characteristics of
individual CPUs.
** Please refer to Memory QVL (Qualified Vendors List) for details.
Expansion slots
2 x PCIe 3.0/2.0 x16 slots (Red, single at x16 or dual at x8/x8
mode)
1 x PCIe 2.0 x4 slot (Black)*
* The PCIe 2.0 x4 slot (PCIEX4_1) shares bandwidth with M.2 and mPCIe
connector. For more information, refer to the Expansion slots section
in Chapter 1.
VGA
Integrated Intel®HD Graphics Processor
HDMI with maximum resolution of 4096 x 2160 @ 24Hz / 2560 x
1600 @ 60Hz
Intel®InTru™ 3D, Intel®Quick Sync Video, Intel®Clear Video HD
Technology, and Intel®Insider™
Multi-GPU support Quad-GPU NVIDIA®SLI™ Technology
Quad-GPU AMD CrossFireX™ Technology
LAN
1 x Intel® I218-V Gigabit LAN
Anti-surge Ethernet port
ROG GameFirst III
USB
Intel®Z97 Express Chipset
4 x USB 3.0 ports (2 ports at back panel [blue], 2 ports at mid-board
[red])*
7 x USB 2.0 ports (4 ports at back panel, 3 ports at mid-board)**
ASMedia®USB 3.0 controller
2 x USB 3.0 ports (2 ports at back panel [blue])
* Supports ASUS USB 3.0 Boost, UASP standard on the Intel®native
USB 3.0 is only supported under Windows®8 / 8.1.
** 1 x USB 2.0 port (USB13) shares with ROG extension (ROG_EXT) port.

x
(continued on the next page)
Storage
Intel®Z97 Express Chipset:
6 x SATA 6 Gb/s ports*
- Intel®Rapid Storage Technology 13 supports RAID 0, 1, 5, and 10
- Intel®Smart Response Technology, Intel®Rapid Start Technology,
and Intel®Smart Connect Technology*
1 x M.2 Socket 3 with M Key, type 2260/2280 storage devices support**
ASMedia®SATA 6Gb/s controller:
2 x SATA 6 Gb/s ports***
* The supported functions depend on the CPU installed.
** Supports PCIe interface only.
*** These SATA ports are for data hard drives only. ATAPI devices are not
supported.
Audio
ROG SupremeFX Impact II Audio 8-Channel High Definition
Audio
- SupremeFX Shielding Technology
- ELNA®Premium Audio Capacitors
- Content Protection for Full Rate lossless DVD Audio, Blu-ray DVD,
and HD-DVD audio content playback
- Jack-detection, Multi-streaming, Front Panel Jack-retasking, Gold
Plated Audio Jacks
- Optical S/PDIF out port at back panel
Audio Feature:
- Sonic Radar II
- Sonic Studio
- Sonic SoundStage
- Sonic SenseAmp
- DTS Connect
Back I/O Ports
1 x PS/2 keyboard/mouse combo port
4 x USB 2.0 ports
1 x ROG Connect button
1 x Clear CMOS button
1 x Optical S/PDIF out
1 x HDMI port
4 x USB 3.0 ports [blue]
1 x Anti-surge LAN (RJ45) port
3 x golden plated audio jacks
MAXIMUS VII GENE specifications summary

xi
(continued on the next page)
ROG Exclusive Features
Extreme Engine Digi+ III
- Full digital CPU/DRAM power
- NexFETTM Power Block MOSFET
- 60A Ferrite Choke
- 10K Black Metallic Capacitors
KeyBot
- CPU Level Up
- X.M.P.
- DirectKey
ROG RAMDisk
UEFI BIOS features
- Extreme Tweaker
- Tweaker’s Paradise
- ROG SSD Secure Erase
- GPU.DIMM Post
- O.C. Prole
- Graphics Card Information Preview
Special Features
ASUS Dual Intelligent Processors 5
- Perfectly consolidates TPU, EPU, DIGI+ Power Control, Fan
Xpert 3, and Turbo App
ASUS Exclusive Features
- AI Suite 3
- USB 3.0 Boost
- USB Charger+
- AI Charger+
- Disk Unlocker
ASUS EZ DIY
- Push Notice
- X.M.P.
- USB BIOS Flashback
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 2
- ASUS C.P.R. (CPU Parameter Recall)
MemOK!
ASUS Q-Design
- ASUS Q-Code
- ASUS Q-Shield
- ASUS Q-Connector
- ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)
- ASUS Q-Slot
- ASUS Q-DIMM
MAXIMUS VII GENE specifications summary

xii
Internal Connectors
1 x USB 3.0 connector (supports additional two USB 3.0 ports)
2 x USB 2.0 connectors (support additional three USB 2.0 ports,
one connector shares with ROG_EXT header)
1 x ROG Extension (ROG_EXT) header
8 x SATA 6Gb/s connectors
1 x 4-pin CPU fan connector
1 x 4-pin CPU optional fan connector
3 x 4-pin Chassis fan connectors
1 x 24-pin EATX power connector
1 x 8-pin EATX 12V Power connector
1 x Temperature Sensor (T_SENSOR1)
1 x LN2 jumper
1 x Power-on button
1 x Reset button
1 x MemOK! button
1 x Front panel audio connector (AAFP)*
1 x System panel connector
1 x TPM connector
1 x Sonic SoundStage button
1 x KeyBot button
*AAFP connector is built-in on the SupremeFX Impact II card
BIOS Features
64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI 2.7, WfM 2.0, SM
BIOS 2.8, ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 2, ASUS
CrashFree BIOS 3, My Favorites, Quick Note, Last Modied log,
F12 PrintScreen, F3 Shortcut functions, and ASUS DRAM SPD
(Serial Presence Detect) memory information
Manageability WfM2.0, DMI2.7, WOL by PME, PXE
Software
Drivers
ROG GameFirst III
ROG RAMDisk
ROG CPU-Z
ROG MemTweakIt
Kaspersky®Anti-Virus
DAEMON Tools Pro Standard
ASUS WebStorage
Home Cloud
ASUS Utilities
Form Factor µATX Form Factor, 9.6 in. x 9.6 in. (24.4 cm x 24.4 cm)
Specications are subject to change without notice.
MAXIMUS VII GENE specifications summary

xiii
Package contents
Check your motherboard package for the following items.
Motherboard ROG MAXIMUS VII GENE
Cables 3 x 2-in-1 SATA 6 Gb/s cables
1 x SLI®bridge
Accessories
1 x I/O Shield
1 x 12-in-1 ROG cable label
1 x 2-in-1 Q-Connector kit
1 x ROG Door Hanger
1 x SupremeFX Impact II audio card
Application DVD ROG motherboard support DVD
Documentation User guide
If any of the above items is damaged or missing, contact your retailer.

xiv
Installation tools and components
1 bag of screws Philips (cross) screwdriver
PC chassis Power supply unit
Intel LGA 1150 CPU Intel LGA 1150 compatible CPU Fan
DDR3 DIMM SATA hard disk drive
SATA optical disc drive (optional) Graphics card (optional)
The tools and components in the table above are not included in the motherboard package.

ASUS MAXIMUS VII GENE 1-1
Chapter 1
Product introduction
1
1.1 Special features
1.1.1 Product highlights
Republic of Gamers
The Republic of Gamers offers you the best of the best. We offer the best hardware
engineering, the fastest performance, the most innovative ideas, and we welcome the best
gamers to join in. In the Republic of Gamers, mercy rules are only for the weak, and bragging
rights means everything. We believe in making statements and we excel in competitions.
If your character matches our trait, then join the elite Republic of Gamers and make your
presence felt.
LGA1150 socket for 4th, New 4th, and 5th generation Intel®Core™ i7/Intel®
Core™ i5/Intel®Core™ i3, Pentium®and Celeron®processors
This motherboard supports 4th, New 4th, and 5th generation Intel®Core™ i7/Intel®Core™
i5/Intel®Core™ i3, Pentium®, and Celeron®processors in the LGA1150 package. It provides
great graphics and system performance with its GPU, dual-channel DDR3 memory slots, and
PCI Express 2.0/3.0 expansion slots.
Intel®Z97 Express Chipset
Intel®Z97 Express Chipset is a single chipset that supports the LGA1150 socket for 4th,
New 4th, and 5th generation Intel®Core™ i7/Intel®Core™ i5/Intel®Core™ i3, Pentium®, and
Celeron®processors. It utilizes the serial point-to-point links, which increases bandwidth and
enhances the system’s performance. It natively supports up to six USB 3.0 ports, six SATA 6
Gb/s ports, and M.2 support for faster data retrieval.
PCI Express®3.0
PCI Express®3.0 (PCIe 3.0) is the PCIe bus standard that provides twice the performance
and speed of PCIe 2.0. It provides an optimal graphics performance, unprecedented data
speed and seamless transition with its complete backward compatibility to PCIe 1.0/2.0
devices.
SLI®/CrossFire™ On-Demand
This motherboard supports multi-GPU SLI®/CrossFireX™graphics cards for an unrivalled
gaming performance. With the Intel®Z97 platform to optimize the PCIe allocation of multiple
GPUs, it supports up to 2-WAY Quad-GPU SLI® or CrossFireX™ conguration.
Chapter 1: Product Introduction

1-2 Chapter 1: Product introduction
Chapter 1
M.2 Support
This motherboard features the M.2 slot, which shares bandwidth with PCIe x2 slot to speed
up data transfer up to 10 Gb/s. This helps enhance the performance of your Solid State Drive
(SSD) that is dedicated only to the operating system. The M.2 slot provides support for faster
access to data and applications, and quicker wake up time for your system.
• Supports PCIe interface only.
• Supports 2260 (22 mm x 60 mm) and 2280 (22 mm x 80 mm) SSD cards.
Complete USB 3.0 integration
This motherboard offers you the strategic USB 3.0 accessibility for both the front and rear
panels, allowing you to experience the convenience of the latest plug and play connectivity
solution at speed up to ten times faster than USB 2.0.

ASUS MAXIMUS VII GENE 1-3
Chapter 1
1.1.2 ROG Gaming Features
SupremeFX Impact II
ROG knows the importance of awless audio – pristine effects and full-range soundtracks
make the game. This devotion to the best audio is applied to all our Maximus VII boards,
including micro ATX (mATX) models. SupremeFX Impact II is our dedicated audio hardware
for mATX. Cutting-edge isolation technologies minimize electromagnetic interference (EMI)
and exceptionally premium components deliver best-in-class audio. The original SupremeFX
Impact was acclaimed by both our customers and the media: SupremeFX Impact II employs
even ner components and superbly clever software innovations for gaming and multimedia
experiences beyond compare!
Sonic Radar II
Sonic Radar II technology displays a stealthy overlay that lets you pinpoint the direction and
origin of in-game sounds such as gunshots, footsteps and call-outs, so you practice your
enemy-pinpointing skills! In 2014 version, you can install your favorite FPS games and
customize settings of overlay, shortcut keys and audio enhancer!
Sonic Studio
Sonic Studio is an audio tuning software that simulates 7.1 channels even through a stereo
(2.0-channel) headset with its virtual surround-sound function. It comes with six superb audio
controls including Reverb, Bass Boost, Equalizer, Voice Clarity, Smart EQ (Smart Volume),
and Virtual Surround.
Sonic SoundStage
Sonic SoundStage is an on-board solution that improves audio experience when you connect
your front-panel headset. It works with any operating system and on any game. You can
choose from any of the four presets or manually ne tune your own setting to re up your
game.
Sonic SenseAmp
Sonic SenseAmp is an exclusive ROG invention that automatically detects your headset’s
impedance and adjusts the built-in amp accordingly. Sonic SenseAmp makes tuning your
high-quality headphones as simple as plugging them in.
GameFirst III
ASUS GameFirst III is a network management software that features four preset packet
prioritized proles (Optimization, Game, Media Streaming and File Sharing) facilitating
user’s need. Users can also manually allocate bandwidth and adjust priority settings of each
application to run faster and smoother.
Intel®Ethernet
This LAN solution from Intel features high TCP and UDP throughput with lower CPU
utilization for a smooth networking experience. It has advanced features including advanced
interrupt-handling, low-power consumption, and Intel Stable Image Platform Program (SIPP)
support thanks to its compatibility with the Intel CPU and chipset.
KeyBot
KeyBot is a built-in microprocessor that provides instant upgrade to your keyboard. You can
congure and assign macros to specic keys on your keyboard to perform specic or several
task at the same time. You can also congure your PC to wake up in CPU Level UP, XMP, or
directly to BIOS mode.
This feature supports USB keyboards only.

1-4 Chapter 1: Product introduction
Chapter 1
1.1.3 ROG Exclusive Features
Extreme Engine Digi+ III
Extreme Engine Digi+ III offers you a hardcore power delivery for a challenging and
extreme gaming enjoyment. It utilizes the best components such as NexFET™MOSFETs,
60A Ferrite Choke, and super-premium 10K black metallic solid state capacitors. The
NexFET™ Power Block MOSFETs combine great durability and up to 90% efciency under
normal operation. Super-premium 10K Black Metallic solid state capacitors are forged for
overclocking and the most extreme demands, lasting up to ve times longer than generic
capacitors with 20% wider temperature tolerance.
CPU Level Up
With ROG’s CPU Level Up, overclocking has never been so easy, or cost-free. Simply select
the processor that you want to overclock to, and the motherboard will do the rest.
ROG Connect
ROG Connect allows you to monitor the status of your desktop PC and tweak its parameters
in real time via a notebook. ROG Connect links your main system to a notebook through a
USB cable, allowing you to view real-time POST code and hardware status readouts on your
notebook, as well as make on-the-y parameter adjustments at a purely hardware level.
The ROG Connect cable is sold separately.
iROG
The iROG is a special IC that fully maximizes ROG’s unique functions, providing you with full
control of your motherboard at any stage. It increases your overclocking, and offers you with
advanced system control and management features purely at a hardware level.
LANGuard
ROG revolutionizes the LAN port with its advanced signal-coupling technology and
premium surface-mounted components that improve throughput, while surge-protected and
electrostatic-guarded components (ESD Guards) protect your motherboard from lightning
strikes and static electricity.
ProbeIt
Your motherboard consists of ten (10) ProbeIt measurement points that help you detect the
amount of voltage currently running in your system. Use a multi-tester device to measure the
voltage of your system and its components and peripherals.

ASUS MAXIMUS VII GENE 1-5
Chapter 1
1.1.4 ASUS Special Features
AI Suite 3
With its user-friendly interface, ASUS AI Suite 3 consolidates all the exclusive ASUS
features into one simple-to-use software package. It allows you to supervise fan speed
control, voltage and sensor readings. This all-in-one software offers diverse and ease to use
functions, with no need to switch back and forth between different utilities.
USB 3.0 Boost
ASUS USB 3.0 Boost, which supports USB 3.0 standard UASP (USB Attached SCSI
Protocol), signicantly increases a USB device’s transfer speed up to 170% faster than the
already impressive USB 3.0 transfer speed. It automatically accelerates data speeds for
compatible USB 3.0 peripherals without the need for any user interaction.
USB BIOS Flashback
USB BIOS Flashback offers a hassle-free updating solution for your ultimate convenience.
Install a USB storage device containing the BIOS le, press the ROG Connect button for
about three seconds, and the UEFI BIOS is automatically updated even without entering
the existing BIOS or operating system. It also allows you to regularly check for UEFI BIOS
updates, and download the latest BIOS automatically.

1-6 Chapter 1: Product introduction
Chapter 1
1.1.5 ROG rich bundled software
Kaspersky®Anti-Virus
Kaspersky®Anti-Virus Personal offers premium anti virus protection for individual users and
home ofces. It is based on advanced anti virus technologies. The product incorporates the
Kaspersky®Anti-Virus engine, which is renowned for malicious program detection rates that
are among the industry’s highest.
DAEMON Tools Pro Standard
DAEMON Tools Pro offers essential functionality to backup CD, DVD and Blu-ray discs. It
converts optical media into virtual discs and emulates devices to work with the virtual copies.
DAEMON Tools Pro organizes data, music, video, and photo collections on a PC, notebook,
or netbook.
ROG CPU-Z
ROG CPU-Z is a customized ROG version utility authorized by Intel’s CPU Identication
(CPUID) that allows you to gather information of the main devices of your system. It
gives you the information and status of your CPU, motherboard, memory, and the whole
component. Use the ROG look of reporting your system’s current information with ROG
CPU-Z.
MemTweakIt
MemTweakIt is a DRAM efciency tool that allows you to read DRAM timings and allows you
to post and share your DRAM conguration scores to the ROG website.
DTS Connect
To get the most out of your audio entertainment across all formats and quality levels, DTS
Connect combines two enabling technologies, DTS Neo:PC™ up mixes stereo sources (CDs,
MP3s, WMAs, internet radio) into as many as 7.1 channels of incredible surround sound.
Consumers can connect their PC to a home theatre system. DTS Interactive is capable of
performing multichannel encoding of DTS bitstreams on personal computers, and sending
encoded bitstreams out of a digital audio connection (such as S/PDIF or HDMI) designed to
deliver audio to an external decoder.
SSD Secure Erase
Your ROG motherboard comes with SSD Secure Erase that deletes all data from an SSD
while recovering lost performance and restores factory speeds. The SSD Secure Erase
embedded to the UEFI BIOS for better compatibility and easy use.
RAMDisk
RAMDisk reserves part of system memory and turns it into actual storage, so you can
place favorite app and game cache les in it to enjoy high-speed RAM performance while
accessing them. With the Dynamic Memory Allocation function, it can also release the
unused memory of RAMDisk back to the system when needed. Plus, this extends SSD
lifespan and keeps your main storage optimized for really important tasks, and you get auto
data backup and restore.
RAMDisk only supports 64-bit operating systems.
