Asus P8B-C/4L Technical manual

ASUS P8B-C Series 1
IE6852
Processor Support / System Bus Intel®Xeon®E3-1200 v2 Processor Family
Intel®Xeon®E3-1200 Processor Family
Intel®Core™ i3-2100 Processor Family
Intel®Pentium™ G8x0/G6x0
Intel®Celeron™ G5x0/G4x0
Memory Total Slots 4 (2 Channels)
Capacity Maximum up to 32GB
Memory Type DDR3 1066/1333/1600* ECC UDIMM
* DDR3 1600 can only be supported with Intel®Xeon®E3-1200 v2
Processor
Expansion
Slots
(follow SSI
Location #)
Total PCI/PCI-
X/ PCI-E Slots
7
Slot Location 1 1 x PCI 32bit/33 MHz
Slot Location 2 1 x PCI 32bit/33 MHz
Slot Location 3 1 x PCI 32bit/33 MHz
Slot Location 4 1 x PCI 32bit/33 MHz
Slot Location 5 1 x PCI 32bit/33 MHz
Slot Location 6 1 x PCI-E x16 (Gen3*/Gen2 x16 link)
* Gen3 link can only be supported with Intel®Xeon®E3-1200 v2
Processor
Slot Location 7 1 x PCI-E x8 (Gen2 x4 link)
ASUS P8B-C Series Technical Updates
This is an information update for the user guide that comes with your motherboard package.
P8B-C Series specications summar (page xi)
A.1 P8B-C series block diagram (page A-3 ~ A-5)
P8B-C/4L (R1.0x/R2.0x)

2 ASUS P8B-C SeriesP8B-C Series
P8B-C/SAS/4L (R1.0x/R2.0x)
P8B-C/SAS/2L (R1.0x/R2.0x)
15060-11750000
