Asus p4p800s User manual

Motherboard
P4P800S SE
User Guide

ii
Checklist
Copyright © 2003 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any
language in any form or by any means, except documentation kept by the purchaser for
backup purposes, without the express written permission of ASUSTeK COMPUTER INC.
(“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modified or
altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2)
the serial number of the product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER
EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES
OR CONDITIONS OF MERCHANTABILITY OR FITNESS FORA PARTICULAR PURPOSE.
IN NO EVENT SHALLASUS, ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE
LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES
(INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE
OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF ASUS HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR
ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUALARE FURNISHED
FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGEATANY TIME
WITHOUT NOTICE,AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BYASUS.
ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR
INACCURACIES THAT MAY APPEAR IN THIS MANUAL, INCLUDING THE PRODUCTS
AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered
trademarks or copyrights of their respective companies, and are used only for identification or
explanation and to the owners’ benefit, without intent to infringe.
E1483
First Edition
November 2003

iii
Features
Contents
Notices........................................................................................................ v
Safety information...................................................................................... vi
About this guide .........................................................................................vii
ASUS contact information.........................................................................viii
P4P800S SE specifications summary ....................................................... ix
Chapter 1: Product introduction
1.1 Welcome!.......................................................................................1-2
1.2 Package contents ..........................................................................1-2
1.3 Special features .............................................................................1-2
1.4 Motherboard components..............................................................1-4
1.5 Motherboard layout........................................................................1-7
1.6 Before you proceed .......................................................................1-8
1.7 Motherboard installation ................................................................1-9
1.7.1 Placement direction .........................................................1-9
1.7.2 Screw holes .....................................................................1-9
1.8 Central Processing Unit (CPU) ....................................................1-10
1.8.1 Overview........................................................................ 1-10
1.8.2 Installing the CPU .......................................................... 1-11
1.9 System memory........................................................................... 1-12
1.9.1 Memory configurations ..................................................1-12
1.9.2 Installing a DIMM ...........................................................1-14
1.10 Expansion slots ...........................................................................1-15
1.10.1 Standard interrupt assignments ..................................... 1-15
1.10.2 IRQ assignments for this motherboard ..........................1-15
1.10.3 PCI slots ........................................................................ 1-16
1.10.4 AGP slot......................................................................... 1-16
1.11 Jumpers .......................................................................................1-17
1.12 Connectors ..................................................................................1-19
Chapter 2: BIOS information
2.1 Managing and updating your BIOS ...............................................2-2
2.1.1 Creating a bootable floppy disk .......................................2-2
2.1.2 Using AFUDOS to update the BIOS ................................ 2-2
2.1.3 Using AFUDOS to copy BIOS from PC ...........................2-4
2.1.4 Using ASUS EZ Flash to update the BIOS ......................2-5
2.1.5 Recovering the BIOS with CrashFree BIOS 2 .................2-6
2.2 BIOS Setup program .....................................................................2-8
2.2.1 BIOS menu screen ..........................................................2-9
2.2.2 Menu bar..........................................................................2-9

iv
Safeguards
Contents
2.2.3 Navigation keys ...............................................................2-9
2.2.4 Menu items ....................................................................2-10
2.2.5 Sub-menu items.............................................................2-10
2.2.6 Configuration fields ........................................................2-10
2.2.7 Pop-up window ..............................................................2-10
2.2.8 Scroll bar........................................................................2-10
2.2.9 General help ..................................................................2-10
2.3 Main menu ................................................................................... 2-11
2.3.1 System Time [xx:xx:xxxx]............................................... 2-11
2.3.2 System Date [Day xx/xx/xxxx] ....................................... 2-11
2.3.3 Legacy Diskette A [1.44M, 3.5 in.] ................................. 2-11
2.3.4 Primary and Secondary IDE Master/Slave;
Third and Fourth IDE Master .........................................2-12
2.3.5 IDE Configuration ..........................................................2-13
2.3.6 System Information ........................................................2-15
2.4 Advanced menu...........................................................................2-15
2.4.1 JumperFree Configuration .............................................2-16
2.4.2 CPU Configuration ......................................................... 2-18
2.4.3 Chipset...........................................................................2-18
2.4.4 Onboard Devices Configuration.....................................2-20
2.4.5 PCI PnP .........................................................................2-22
2.4.6 USB Configuration .........................................................2-23
2.4.7 Instant Music Configuration ...........................................2-25
2.5 Power menu ................................................................................2-26
2.5.1 Suspend Mode [Auto] ....................................................2-26
2.5.2 Repost Video on S3 Resume [No] ................................. 2-26
2.5.3 ACPI 2.0 Support [No] ...................................................2-26
2.5.4 ACPI APIC Support [Enabled] .......................................2-26
2.5.5 BIOS -> AMLACPI Table [Enabled] ...............................2-26
2.5.6 Advanced Power Management (APM) Configuration ....2-27
2.5.7 Hardware Monitor ..........................................................2-29
2.6 Boot menu ...................................................................................2-30
2.6.1 Boot Device Priority .......................................................2-30
2.6.2 Removable Drives .........................................................2-31
2.6.3 Boot Settings Configuration ...........................................2-31
2.6.4 Security..........................................................................2-33
2.7 Exit menu.....................................................................................2-35
Chapter 3: Software support
3.1 Install an operating system ............................................................3-2
3.2 Support CD information .................................................................3-2
3.3 ASUS Instant Music Lite................................................................ 3-5

v
Notices
Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received including interference
that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
manufacturer’s instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for radio noise
emissions from digital apparatus set out in the Radio Interference
Regulations of the Canadian Department of Communications.
This class B digital apparatus complies with Canadian ICES-003.
The use of shielded cables for connection of the monitor to the
graphics card is required to assure compliance with FCC regulations.
Changes or modifications to this unit not expressly approved by the
party responsible for compliance could void the user’s authority to
operate this equipment.

vi
Safety information
Electrical safety
• To prevent electrical shock hazard, disconnect the power cable from
the electrical outlet before relocating the system.
• When adding or removing devices to or from the system, ensure that
the power cables for the devices are unplugged before the signal
cables are connected. If possible, disconnect all power cables from the
existing system before you add a device.
• Before connecting or removing signal cables from the motherboard,
ensure that all power cables are unplugged.
• Seek professional assistance before using an adpater or extension
cord. These devices could interrupt the grounding circuit.
• Make sure that your power supply is set to the correct voltage in your
area. If you are not sure about the voltage of the electrical outlet you
are using, contact your local power company.
• If the power supply is broken, do not try to fix it by yourself. Contact a
qualified service technician or your retailer.
Operation safety
• Before installing the motherboard and adding devices on it, carefully
read all the manuals that came with the package.
• Before using the product, make sure all cables are correctly connected
and the power cables are not damaged. If you detect any damage,
contact your dealer immediately.
• To avoid short circuits, keep paper clips, screws, and staples away from
connectors, slots, sockets and circuitry.
• Avoid dust, humidity, and temperature extremes. Do not place the
product in any area where it may become wet.
• Place the product on a stable surface.
• If you encounter technical problems with the product, contact a
qualified service technician or your retailer.

vii
About this guide
Conventions used in this guide
To make sure that you perform certain tasks properly, take note of the
following symbols used throughout this manual.
Where to find more information
Refer to the following sources for additional information and for product
and software updates.
1. ASUS Websites
The ASUS websites worldwide provide updated information on ASUS
hardware and software products. The ASUS websites are listed in the
ASUS Contact Information on page viii.
2. Optional Documentation
Your product package may include optional documentation, such as
warranty flyers, that may have been added by your dealer. These
documents are not part of the standard package.
WARNING: Information to prevent injury to yourself when trying
to complete a task.
CAUTION: Information to prevent damage to the components
when trying to complete a task.
IMPORTANT: Information that you MUST follow to complete a
task.
NOTE: Tips and additional information to aid in completing a task.

viii
ASUS contact information
ASUSTeK COMPUTER INC. (Asia-Pacific)
Address 150 Li-Te Road, Peitou, Taipei, Taiwan 112
Telephone [phone]
Web site www.asus.com.tw
Technical Support
Telephone(MB/Component) [phone] (English)
(Notebook) [phone] (English)
(Server/PC) [phone] (English)
(Networking) [phone] (English)
Support fax [phone]
ASUS COMPUTER INTERNATIONAL (America)
Address 44370 Nobel Drive, Fremont, CA 94538, USA
Fax [phone]
E-mail [email protected]
Web site usa.asus.com
Technical Support
Telephone (General) [phone]
(Notebook) [phone]
Support fax [phone]
Support e-mail [email protected]
ASUS COMPUTER GmbH (Germany and Austria)
Address Harkort Str. 25, D-40880 Ratingen, Germany
Telephone [phone]
Fax [phone]
Online contact www.asuscom.de/sales
Technical Support
Telephone [phone]
Fax [phone]
Online support www.asuscom.de/support
Web site www.asuscom.de/news
ASUS COMPUTER (Middle East and North Africa)
Address P.O. Box 64133, Dubai, U.A.E.
Telephone [phone]
Fax [phone]
Web site www.ASUSarabia.com

ix
P4P800S SE specifications summary
(continued on the next page)
CPU
Chipset
Front Side Bus (FSB)
Memory
Expansion slots
Storage
Audio
LAN
Special features
AI Overclocking
Rear panel I/O
Socket 478 for Intel
®
Pentium
®
4 / Celeron
with speeds up to 3.6+GHz
Supports Intel
®
Hyper-Threading technology
New power design supports next generation Intel Prescott CPU
Intel 848P MCH
Intel ICH5
800/533/400 MHz
2 x 184-pin DDR DIMM sockets for up to 2GB memory
Supports PC3200/PC2700/PC2100 unbuffered
non-ECC DDR DIMMs
1 x AGP 8X/4X
5 x PCI
2 x UltraDMA 100/66/33 connectors
2 x Serial ATA connectors
ADI AD1888 SoundMAX 6-channel audio CODEC
support S/PDIF out interface
Realtek RTL8100C 10/100 Mbps Fast Ethernet controller
Support S/PDIF out interface
ASUS MyLogo
ASUS EZ Flash
ASUS C.P.R. (CPU Parameter Recall)
ASUS Instant Music-Lite
ASUS CrashFree BIOS 2
AI Overclocking
ASUS JumperFree
Adjustable CPU voltage
SFS (Stepless Frequency Selection) at 1Mhz increment
Adjustable FSB/DDR ratio. Fixed AGP/PCI frequencies
ASUS C.P.R. (CPU Parameter Recall)
1 x Parallel port
1 x Serial port
1 x PS/2 keyboard port
1 x PS/2 mouse port
4 x USB 2.0 ports
1 x RJ-45 port
1 x S/PDIF out interface
Line In/Line Out/Microphone ports

x
P4P800S SE specifications summary
* Specifications are subject to change without notice.
Internal I/O
BIOS features
Industry standard
Manageability
Power Requirement
Form Factor
Support CD contents
2 x USB 2.0 connector for 4 additional USB ports
CPU/Chassis fan connectors
20-pin/4-pin ATX 12V power connectors
CD/AUX/MODEM connectors
Game/MIDI port connector
20-pin panel connector
Front panel audio connector
3Mb Flash ROM, AMI BIOS, ACPI, PnP, DMI2.0, WfM 2.0,
SM BIOS 2.3, DMI 2.0,ASUS CrashFree BIOS 2, ASUS EZ
Flash, ASUS MyLogo
PCI 2.3, USB 2.0/1.1
DMI 2.0, WOL/WOR by PME, SMBus
ATX power supply (with 4-pin 12V plug)
ATX form factor: 12 in x 8.2 in (30.5 cm x 20.8 cm)
Device drivers
ASUS PC Probe
ASUS LiveUpdate
Trend Micro™ PC-cillin 2002 anti-virus software
