Asus P5GC User manual

Motherboard
P5GC

ii
E3462
First Edition
September 2007
Copyright © 2007 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means, except documentation kept by the purchaser for backup purposes, without the express written
permission of ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modied or
altered, unless such repair, modication of alteration is authorized in writing by ASUS; or (2)
the serial number of the product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER
EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES
OR CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE
LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES
(INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE
OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF ASUS HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR
ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED
FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME
WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY
ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR
INACCURACIES THAT MAY APPEAR IN THIS MANUAL, INCLUDING THE PRODUCTS
AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered
trademarks or copyrights of their respective companies, and are used only for identication or
explanation and to the owners’ benet, without intent to infringe.

iii
Contents
Notices......................................................................................................... vi
Safety information ..................................................................................... vii
About this guide ....................................................................................... viii
P5GC specications summary................................................................... x
Chapter 1: Product introduction
1.1 Welcome! ...................................................................................... 1-1
1.2 Package contents......................................................................... 1-1
1.3 Special features............................................................................ 1-2
1.3.1 Product highlights ........................................................... 1-2
1.3.2 Innovative ASUS features ............................................... 1-4
Chapter 2: Hardware information
2.1 Before you proceed ..................................................................... 2-1
2.2 Motherboard overview................................................................. 2-2
2.2.1 Placement direction ........................................................ 2-2
2.2.2 Screw holes .................................................................... 2-2
2.2.3 Motherboard layout ......................................................... 2-3
2.2.4 Layout contents............................................................... 2-4
2.3 Central Processing Unit (CPU) ................................................... 2-6
2.3.1 Installing the CPU ........................................................... 2-6
2.3.2 Installing the CPU heatsink and fan................................ 2-9
2.3.3 Uninstalling the CPU heatsink and fan ..........................2-11
2.4 System memory ......................................................................... 2-13
2.4.1 Overview ....................................................................... 2-13
2.4.2 Memory congurations.................................................. 2-13
2.4.3 Installing a DIMM .......................................................... 2-16
2.4.4 Removing a DIMM ........................................................ 2-16
2.5 Expansion slots.......................................................................... 2-17
2.5.1 Installing an expansion card ......................................... 2-17
2.5.2 Conguring an expansion card ..................................... 2-17
2.5.3 Interrupt assignments ................................................... 2-18
2.5.4 PCI slots........................................................................ 2-19
2.5.5 PCI Express x16 slot..................................................... 2-19
2.6 Jumpers ...................................................................................... 2-20

iv
Contents
2.7 Connectors ................................................................................. 2-22
2.7.1 Rear panel connectors.................................................. 2-22
2.7.2 Internal connectors ....................................................... 2-23
Chapter 3: Powering up
3.1 Starting up for the rst time........................................................ 3-1
3.2 Powering off the computer.......................................................... 3-2
3.2.1 Using the OS shut down function.................................... 3-2
3.2.2 Using the dual function power switch.............................. 3-2
Chapter 4: BIOS setup
4.1 Managing and updating your BIOS ............................................ 4-1
4.1.1 Creating a bootable oppy disk....................................... 4-1
4.1.2 AFUDOS utility................................................................ 4-2
4.1.3 ASUS CrashFree BIOS 3 utility ...................................... 4-5
4.1.4 ASUS EZ Flash 2 utility................................................... 4-7
4.1.5 ASUS Update utility ........................................................ 4-8
4.2 BIOS setup program .................................................................. 4-11
4.2.1 BIOS menu screen........................................................ 4-12
4.2.2 Menu bar....................................................................... 4-12
4.2.3 Navigation keys............................................................. 4-12
4.2.4 Menu items ................................................................... 4-13
4.2.5 Sub-menu items............................................................ 4-13
4.2.6 Conguration elds ....................................................... 4-13
4.2.7 Pop-up window ............................................................. 4-13
4.2.8 Scroll bar....................................................................... 4-13
4.2.9 General help ................................................................. 4-13
4.3 Main menu .................................................................................. 4-14
4.3.1 System Time ................................................................ 4-14
4.3.2 System Date ................................................................ 4-14
4.3.3 Legacy Diskette A ........................................................ 4-14
4.3.4 Primary, Third and Fourth IDE Master/Slave ................ 4-15
4.3.5 IDE Conguration.......................................................... 4-16
4.3.6 System Information ....................................................... 4-17
4.4 Advanced menu ......................................................................... 4-18
4.4.1 JumperFree Conguration ............................................ 4-18

v
Contents
4.4.2 USB Conguration ........................................................ 4-20
4.4.3 CPU Conguration ........................................................ 4-21
4.4.4 Chipset ......................................................................... 4-23
4.4.5 Onboard Devices Conguration.................................... 4-25
4.4.6 PCI PnP ........................................................................ 4-26
4.5 Power menu................................................................................ 4-28
4.5.1 Suspend Mode ............................................................. 4-28
4.5.2 ACPI 2.0 Support ......................................................... 4-28
4.5.3 ACPI APIC Support ..................................................... 4-28
4.5.4 APM Conguration........................................................ 4-29
4.5.5 Hardware Monitor ......................................................... 4-31
4.6 Boot menu .................................................................................. 4-32
4.6.1 Boot Device Priority ...................................................... 4-32
4.6.2 Boot Settings Conguration .......................................... 4-33
4.6.3 Security ......................................................................... 4-34
4.7 Tools menu ................................................................................. 4-36
ASUS EZ Flash 2......................................................................... 4-36
4.8 Exit menu.................................................................................... 4-37
Chapter 5: Software support
5.1 Installing an operating system ................................................... 5-1
5.2 Support CD information .............................................................. 5-1
5.2.1 Running the support CD ................................................. 5-1
5.2.2 Drivers menu................................................................... 5-2
5.2.3 Utilities menu .................................................................. 5-3
5.2.4 Make Disk menu ............................................................. 5-5
5.2.5 Manual menu .................................................................. 5-6
5.2.6 ASUS Contact information .............................................. 5-6
5.2.7 Other information ............................................................ 5-7
Appendix: CPU features
A.1 Enhanced Intel SpeedStep®Technology (EIST) ........................A-1
A.1.1 System requirements ......................................................A-1
A.1.2 Using the EIST................................................................A-1
A.2 Intel®Hyper-Threading Technology ...........................................A-2
Using the Hyper-Threading Technology ........................................A-2

vi
Notices
Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with manufacturer’s
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for radio noise emissions
from digital apparatus set out in the Radio Interference Regulations of the
Canadian Department of Communications.
This class B digital apparatus complies with Canadian
ICES-003.
The use of shielded cables for connection of the monitor to the graphics card is
required to assure compliance with FCC regulations. Changes or modications
to this unit not expressly approved by the party responsible for compliance
could void the user’s authority to operate this equipment.

vii
Safety information
Electrical safety
• To prevent electrical shock hazard, disconnect the power cable from the
electrical outlet before relocating the system.
• When adding or removing devices to or from the system, ensure that the
power cables for the devices are unplugged before the signal cables are
connected. If possible, disconnect all power cables from the existing system
before you add a device.
• Before connecting or removing signal cables from the motherboard, ensure
that all power cables are unplugged.
• Seek professional assistance before using an adpater or extension cord.
These devices could interrupt the grounding circuit.
• Make sure that your power supply is set to the correct voltage in your area.
If you are not sure about the voltage of the electrical outlet you are using,
contact your local power company.
• If the power supply is broken, do not try to x it by yourself. Contact a
qualied service technician or your retailer.
Operation safety
• Before installing the motherboard and adding devices on it, carefully read all
the manuals that came with the package.
• Before using the product, make sure all cables are correctly connected and the
power cables are not damaged. If you detect any damage, contact your dealer
immediately.
• To avoid short circuits, keep paper clips, screws, and staples away from
connectors, slots, sockets and circuitry.
• Avoid dust, humidity, and temperature extremes. Do not place the product in
any area where it may become wet.
• Place the product on a stable surface.
• If you encounter technical problems with the product, contact a qualied
service technician or your retailer.
The symbol of the crossed out wheeled bin indicates that the
product (electrical, electronic equipment, Mercury-containing button
cell battery) should not be placed in municipal waste. Check local
regulations for disposal of electronic products.

viii
About this guide
This user guide contains the information you need when installing and conguring
the motherboard.
How this guide is organized
This guide contains the following parts:
• Chapter 1: Product introduction
This chapter describes the features of the motherboard and the new
technology it supports.
• Chapter 2: Hardware information
This chapter lists the hardware setup procedures that you have to perform
when installing system components. It includes description of the switches,
jumpers, and connectors on the motherboard.
• Chapter 3: Powering up
This chapter describes the power up sequence, the vocal POST messages,
and ways of shutting down the system.
• Chapter 4: BIOS setup
This chapter tells how to change system settings through the BIOS Setup
menus. Detailed descriptions of the BIOS parameters are also provided.
• Chapter 5: Software support
This chapter describes the contents of the support CD that comes with the
motherboard package.
• Appendix: CPU features
The Appendix describes the CPU features that the motherboard supports.
Where to nd more information
Refer to the following sources for additional information and for product and
software updates.
1. ASUS websites
The ASUS website provides updated information on ASUS hardware and
software products. Refer to the ASUS contact information.
2. Optional documentation
Your product package may include optional documentation, such as warranty
yers, that may have been added by your dealer. These documents are not
part of the standard package.

ix
Conventions used in this guide
To make sure that you perform certain tasks properly, take note of the following
symbols used throughout this manual.
Typography
Bold text Indicates a menu or an item to select.
Italics Used to emphasize a word or a phrase.
<Key> Keys enclosed in the less-than and greater-than sign
means that you must press the enclosed key.
Example: <Enter> means that you must press the
Enter or Return key.
<Key1>+<Key2>+<Key3> If you must press two or more keys simultaneously, the
key names are linked with a plus sign (+).
Example: <Ctrl>+<Alt>+<D>
Command Means that you must type the command exactly
as shown, then supply the required item or value
enclosed in brackets.
Example: At the DOS prompt, type the command line:
afudos /i[lename]
afudos /iP5GC.ROM
DANGER/WARNING: Information to prevent injury to yourself
when trying to complete a task.
CAUTION: Information to prevent damage to the components
when trying to complete a task.
NOTE: Tips and additional information to help you complete a
task.
IMPORTANT: Instructions that you MUST follow to complete a
task.

x
P5GC specications summary
(continued on the next page)
LGA775 socket for Intel® CoreTM 2 Extreme / CoreTM 2 Duo /
Pentium®Extreme/ Pentium®D/ Pentium®4, and Celeron®D
processors.
Support Intel®next generation 45nm multi-core CPU.
Supports Intel®EIST/Hyper-Threading Technology
Northbridge: Intel®945GC
Southbridge: Intel®ICH7R
1333(O.C)/1066/800/533 MHz
4 x 240-pin DIMM sockets support unbuffered non-ECC
DDR2 533/667 memory modules
Supports up to 2 GB system memory
1 x PCIe x16 slot for discrete graphic card
6 x PCI slots
Intel®ICH7R South Bridge supports:
- 1 x Ultra DMA 100/66
- 4 x Serial ATA 3Gb/s devices supporting RAID0,
RAID1, RAID5, and RAID10
ALC662 High Denition Audio 6-channel CODEC
Supports S/PDIF out interface and Jack-detect Technology
Supports up to 8 USB 2.0/USB 1.1 ports
PCIe Gb LAN
SFS (Stepless Frequency Selection) from 100MHz to
450MHz at 1 MHz increment
ASUS C.P.R. (CPU Parameter Recall)
ASUS CrashFree BIOS 3
ASUS MyLogo2
ASUS EZ Flash2
ASUS Q-fan
ASUS CPU Lock Free
ASUS CPU multiplier
8 Mb Flash ROM, AMI BIOS
Special H/W write production, PnP, DMI v2.0, WfM2.0
SM BIOS v2.4, ACPI v2.0
1 x Parallel port
2 x COM ports
1 x PS/2 keyboard port
1 x PS/2 mouse port
1 x LAN (RJ-45) port
4 x USB 2.0/1.1 ports
6-channel Audio I/O port
CPU
Chipset
Front Side Bus
Memory
Expansion slots
Storage
Audio
USB
LAN
Overclocking Features
ASUS special features
BIOS features
Back Panel I/O Ports

xi
1 x Azalia High Denition Analog Front Panel Audio connector
1 x 3-pin SPDIF OUT connector
1 x 3-pin Chassis Intrusion connector
1 x 12-pin System Panel connector
1 x 24-pin EPS12V power connector
1 x 4-pin ATX 12V power connector
2 x USB connectors for 4 additional USB 2.0 ports
1 x CD audio-in connector
CPU/Chassis/Power fan connectors
WOL by PME, WOR by PME, WOR by Ring
Womdows®Vista/XP/2000/2000 server/2003 server
Drivers
ASUS PC Probe II
ASUS LiveUpdate Utility
2 x SATA cables
2 x SATA power cables
1 x FDD cable
1 x UltraDMA 100/66 cable
1 x I/O Shield
User’s manual
ATX Form Factor, 12”x8.95” (30.5cm x 22.7cm)
P5GC specications summary
Internal I/O connectors
Manageability
Supported OS
Support CD contents
Accessories
Form Factor
*Specications are subject to change without notice.

xii

1
Product
introduction
This chapter describes the motherboard
features and the new technologies
it supports.

ASUS P5GC
Chapter summary 1
1.1 Welcome! ...................................................................................... 1-1
1.2 Package contents......................................................................... 1-1
1.3 Special features............................................................................ 1-2

ASUS P5GC 1-1
1.1 Welcome!
Thank you for buying an ASUS®P5GC motherboard!
The motherboard delivers a host of new features and latest technologies, making it
another standout in the long line of ASUS quality motherboards!
Before you start installing the motherboard, and hardware devices on it, check the
items in your package with the list below.
1.2 Package contents
Check your motherboard package for the following items.
Motherboard ASUS P5GC motherboard
Cables 1 x FDD cable
2 x SATA cables
2 x SATA power cables
1 x UltraDMA 100/66 cable
Accessories I/O shield
Application CDs ASUS motherboard support CD
Documentation User guide
If any of the above items is damaged or missing, contact your retailer.

1-2 Chapter 1: Product introduction
1.3 Special features
1.3.1 Product highlights
Latest processor technology
The motherboard comes with a 775-pin surface mount Land Grid Array (LGA)
socket designed for the Intel®Prescott, Intel® Smitheld, Intel®Cedarmill, Intel®
Conroe, Intel®Conroe L or Intel®Presler processor in the 775-land package. The
motherboard supports the processors with 1333 (O.C)/1066/800/533 MHz Front
Side Bus (FSB). The motherboard also supports the Intel®Hyper-Threading
Technology and Enhanced Intel®SpeedStep Technology (EIST). See pages 2-6,
A-1 and A-2 for details.
Intel®Core™2
This motherboard supports the latest Intel® Core™2 processor in the LGA775
package. With the new Intel® Core™ microarchitecture technology and 1333
(O.C)/1066/800/533 MHz FSB, Intel® Core™2 processor is one of the most
powerful and energy efcient CPU in the world.
Intel®65nm Dual-Core CPU support
This motherboard support Intel®Prescott, Intel® Smitheld, Intel®Cedarmill, Intel®
Conroe, Intel®Conroe L or Intel®Presler processors built on the 65-nanometer
(nm) process technology with copper interconnect. Dual-core processors contain
two physical CPU cores with dedicated L2 caches to meet demands for more
powerful processing. The 65nm process of Intel®is the most advanced chip
manufacturing technology, delivering breakthrough performance, enhanced media
experience, and low power consumption. Intel® 65nm dual-core processors utilize
the latest package technologies for a thinner, lighter design without compromising
performance.
64-bit CPU support
64-bit computing, the next generation technology to replace current 32-bit
architecture, delivers advanced system performance, faster memory access and
increased productivity. This motherboard provides excellent compatibility and
exibility by supporting either 64-bit or 32-bit architecture.

ASUS P5GC 1-3
DDR2 memory support
The motherboard supports DDR2 memory that features data transfer rates of
667/533/400 MHz to meet the higher bandwidth requirements of the latest
3D graphics, multimedia, and Internet applications. The dual-channel DDR2
architecture doubles the bandwidth of your system memory to boost system
performance, eliminating bottlenecks with peak bandwidths of up to10.6 GB/s. See
page 2-13 for details.
High Denition Audio
The onboard 6-channel ALC662 High Denition audio CODEC enables high-quality
audio which automatically detects peripherals are plugged into the audio I/O jacks.
ALC662 also supports Windows®Vista Premium. See pages 2-23 for details.
Serial ATA 3.0 Gb/s technology
This motherboard supports the next-generation hard drives based on the Serial
ATA (SATA) 3Gb/s storage specication, delivering enhanced scalability and
doubling the bus bandwidth for high-speed data retrieval and saves. Easily backup
photos, videos and other entertainment contents to external devices. See page
2-25 for details.
S/PDIF digital sound ready
The motherboard supports the S/PDIF technology through the S/PDIF interfaces
on the rear panel. The S/PDIF technology turns your computer into a high-end
entertainment system with digital connectivity to powerful audio and speaker
systems. See page 2-26 for details.
PCI Express™ interface
The motherboard fully supports PCI Express, the latest I/O interconnect technology
that speeds up the PCI bus. PCI Express features point-to-point serial
interconnections between devices and allows higher clockspeeds by carrying data
in packets. This high speed interface is software compatible with existing PCI
specications. See page 2-20 for details.
USB 2.0 technology
The motherboard implements the Universal Serial Bus (USB) 2.0 specication,
dramatically increasing the connection speed from the 12 Mbps bandwidth on USB
1.1 to a fast 480 Mbps on USB 2.0. USB 2.0 is backward compatible with USB 1.1.
See pages 2-24 and 2-27 for details.

1-4 Chapter 1: Product introduction
Green ASUS
The motherboard and its packaging comply with the European Union’s Restriction
on the use of Hazardous Substances (RoHS). This is in line with the ASUS
vision of creating environment-friendly and recyclable products and packaging to
safeguard consumers’ health while minimizing the impact on the environment.
1.3.2 Innovative ASUS features
ASUS CrashFree BIOS 3
The ASUS CrashFree BIOS 3 allows users to restore corrupted BIOS data from a
USB ash disk containing the BIOS le. See page 4-5 for details.
ASUS EZ Flash 2
EZ Flash 2 is a user-friendly BIOS update utility. Simply press the predened
hotkey to launch the utility and update the BIOS without entering the OS. Update
your BIOS easily without preparing a bootable diskette or using an OS-based ash
utility. See page 4-7 for details.
ASUS Q-Fan technology
The ASUS Q-Fan technology smartly adjusts the fan speeds according to the
system loading to ensure quiet, cool, and efcient operation. See page 4-31 for
details.
C.P.R. (CPU Parameter Recall)
The C.P.R. feature of the motherboard BIOS allows automatic re-setting to the
BIOS default settings in case the system hangs due to overclocking. When the
system hangs due to overclocking, C.P.R. eliminates the need to open the system
chassis and clear the RTC data. Simply shut down and reboot the system, and the
BIOS automatically restores the CPU default setting for each parameter.
ASUS CPU Lock Free
This feature allows you to adjust the CPU multiplier to 14x. Setting the appropriate
BIOS setting automatically reduces the CPU multiplier value for more exibility
when increasing external FSB.

ASUS P5GC 1-5
ASUS MyLogo2™
This feature allows you to convert your favorite photo into a 256-color boot logo for
a more colorful and vivid image on your screen. See page 4-33 for details.

1-6 Chapter 1: Product introduction
