ASUS P8B-E/4L Technical Updates
This is an information update for the user guide that comes with your motherboard package.
P8B-E/4L specications summary (page xi)
Processor Support / System Bus 1 x Socket LGA1155
Intel®Xeon®E3-1200 v2 Processor Family
Intel®Xeon®E3-1200 Processor Family
Intel®Core™ i3-2100 Processor Family
Intel®Pentium™ G8x0/G6x0
Intel®Celeron™ G5x0/G4x0
Memory Total Slots 4 (2 Channels)
Capacity Maximum up to 32GB
Memory Type DDR3 1066/1333/1600* ECC UDIMM
* DDR3 1600 can only be supported with Intel® Xeon®E3-1200 v2
Processor
Expansion
Slots
(follow SSI
Location #)
Total PCI/PCI-X/
PCI-E Slots
6
Slot Location 1 1 x PCI 32bit/33 MHz
Slot Location 2 1 x PCI 32bit/33 MHz
Slot Location 3 1 x PCI-E x8 (x4 Gen2 link)
Slot Location 4 1 x PCI-E x16 (x8 Gen3*/Gen2 link)
* Gen3 link can only be supported with Intel® Xeon®E3-1200 v2
Processor
Slot Location 5 1 x PCI 32bit/33 MHz
Slot Location 6 1 x PCI-E x16 (x16 Gen3*/Gen2 link)
(Auto switch to x8 link if slot 4 is occupied)
* Gen3 link can only be supported with Intel® Xeon®E3-1200 v2
Processor
Additional Slot 1 1 x PIKE Slot for Storage expansion

2 ASUS P8B-E/4L
15060-11740000
A.1 P8B-E/4L block diagram (page A-3)
