Asus TUV4X User manual

®
TUV4X
JumperFree™PC133/VC133
133MHz FSB AGP Pro/4X
Socket 370 Motherboard
USER’S MANUAL

ASUS TUV4X User’s Manual
2
USER'S NOTICE
Product Name: ASUS TUV4X
Manual Revision: 1.01 E765
Release Date: July 2001
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form
or by any means, except documentation kept by the purchaser for backup purposes, without the
express written permission of ASUSTeK COMPUTER INC. (“ASUS”).
ASUSPROVIDESTHISMANUAL“ASIS”WITHOUTWARRANTYOFANYKIND,EITHER
EXPRESSORIMPLIED, INCLUDINGBUT NOTLIMITEDTOTHEIMPLIEDWARRANTIES
OR CONDITIONS OF MERCHANTABILITYOR FITNESS FORAPARTICULAR PURPOSE.
IN NO EVENT SHALLASUS, ITS DIRECTORS, OFFICERS, EMPLOYEES ORAGENTS BE
LIABLEFORANYINDIRECT, SPECIAL,INCIDENTAL, ORCONSEQUENTIALDAMAGES
(INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE
OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF ASUS HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT
OR ERROR IN THIS MANUAL OR PRODUCT.
Product warranty or service will not be extended if: (1) the product is repaired, modified or altered,
unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial
number of the product is defaced or missing.
Products and corporate names appearing in this manual may or may not be registered trademarks
or copyrights of their respective companies, and are used only for identification or explanation
and to the owners’ benefit, without intent to infringe.
• VIAand Apollo Pro133Aare trademarks of VIA Technologies, Inc.
• Intel, LANDesk, Pentium, and Celeron are trademarks of Intel Corporation.
• IBM and OS/2 are registered trademarks of International Business Machines.
• Symbios is a registered trademark of Symbios Logic Corporation.
• Windows and MS-DOS are registered trademarks of Microsoft Corporation.
• Adobe and Acrobat are registered trademarks of Adobe Systems Incorporated.
• Trend and ChipAwayVirus are trademarks of Trend Micro, Inc.
The product name and revision number are both printed on the product itself. Manual revisions
are released for each product design represented by the digit before and after the period of the
manual revision number. Manual updates are represented by the third digit in the manual revision
number.
For previous or updated manuals, BIOS, drivers, or product release information, contact ASUS at
http://www.asus.com.tw or through any of the means indicated on the following page.
SPECIFICATIONSAND INFORMATION CONTAINED INTHISMANUALARE FURNISHED
FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME
WITHOUTNOTICE,ANDSHOULDNOTBE CONSTRUEDASACOMMITMENTBYASUS.
ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR
INACCURACIES THAT MAYAPPEAR IN THIS MANUAL, INCLUDING THE PRODUCTS
AND SOFTWARE DESCRIBED IN IT.
Copyright © 2001 ASUSTeK COMPUTER INC. All Rights Reserved.

ASUS TUV4X User’s Manual 3
ASUS CONTACT INFORMATION
ASUSTeK COMPUTER INC. (Asia-Pacific)
Marketing
Address: 150 Li-Te Road, Peitou, Taipei, Taiwan 112
Telephone: [phone]
Fax: [phone]
Email: [email protected]
Technical Support
MB/Others (Tel): [phone] (English)
Notebook (Tel): [phone] (English)
Desktop/Server (Tel):[phone] (English)
Fax: [phone]
Email: [email protected]
WWW: www.asus.com.tw
FTP: ftp.asus.com.tw/pub/ASUS
ASUS COMPUTER INTERNATIONAL (America)
Marketing
Address: 6737 Mowry Avenue, Mowry Business Center, Building 2
Newark, CA 94560, USA
Fax: [phone]
Email: [email protected]
Technical Support
Fax: [phone]
Email: [email protected]
WWW: www.asus.com
FTP: ftp.asus.com/Pub/ASUS
ASUS COMPUTER GmbH (Europe)
Marketing
Address: Harkortstr. 25, 40880 Ratingen, BRD, Germany
Fax: [phone]
Email: [email protected] (for marketing requests only)
Technical Support
Hotline: MB/Others: [phone] Notebook:[phone]
Fax: [phone]
Support (Email): www.asuscom.de/de/support (for online support)
WWW: www.asuscom.de
FTP: ftp.asuscom.de/pub/ASUSCOM

ASUS TUV4X User’s Manual
4
CONTENTS
1. INTRODUCTION ............................................................................. 7
1.1 How This Manual Is Organized ................................................... 7
1.2 Item Checklist .............................................................................. 7
2. FEATURES ........................................................................................ 8
2.1 ASUS TUV4X Motherboard ....................................................... 8
2.1.1 Specifications ..................................................................... 8
2.1.2 Performance...................................................................... 10
2.1.3 Intelligence ....................................................................... 11
2.2 Motherboard Components.......................................................... 12
2.2.1 Component Locations....................................................... 13
3. HARDWARE SETUP ...................................................................... 14
3.1 Motherboard Layout .................................................................. 14
3.2 Layout Contents ......................................................................... 15
3.3 Hardware Setup Procedure......................................................... 16
3.4 Motherboard Settings ................................................................. 16
3.5 System Memory ......................................................................... 23
3.5.1 General DIMM Notes....................................................... 23
3.5.2 Memory Installation ......................................................... 24
3.6 Central Processing Unit (CPU) .................................................. 25
3.6.1 CPU Installation ............................................................... 26
3.7 Expansion Cards ........................................................................ 27
3.7.1 Installing an Expansion Card ........................................... 27
3.7.2 Assigning IRQs for Expansion Cards .............................. 28
3.7.3 Accelerated Graphics Port (AGP) Pro Slot ...................... 29
3.7.4 Audio Modem Riser (AMR) Slot ..................................... 30
3.8 Connectors ................................................................................ 31
3.8.1 External Connectors ......................................................... 31
3.8.2 Internal Connectors .......................................................... 34
3.9 Starting Up the First Time.......................................................... 44

ASUS TUV4X User’s Manual 5
CONTENTS
4. BIOS SETUP..................................................................................... 45
4.1 Managing and Updating Your BIOS .......................................... 45
4.1.1 Upon First Use of the Computer System.......................... 45
4.1.2 Updating BIOS Procedures .............................................. 47
4.2 BIOS Setup Program.................................................................. 49
4.2.1 BIOS Menu Bar................................................................ 50
4.2.2 Legend Bar ....................................................................... 50
4.3 Main Menu ................................................................................. 52
4.3.1 Primary & Secondary Master/Slave ................................. 53
4.3.2 Keyboard Features............................................................ 56
4.4 Advanced Menu ......................................................................... 58
4.4.1 Chip Configuration........................................................... 62
4.4.2 I/O Device Configuration ................................................. 65
4.4.3 PCI Configuration ............................................................ 67
4.4.4 Shadow Configuration ...................................................... 70
4.5 Power Menu ............................................................................... 71
4.5.1 Power Up Control............................................................. 73
4.5.2 Hardware Monitor ............................................................ 75
4.6 Boot Menu ................................................................................. 76
4.7 Exit Menu................................................................................... 78
5. SOFTWARE SETUP....................................................................... 81
5.1 Operating Systems ..................................................................... 81
5.1.1 Windows 98 First Time Installation ................................. 81
5.2 TUV4X Motherboard Support CD ............................................ 81
5.2.1 Installation Menus ............................................................ 81
5.2.2 Applications...................................................................... 82
6. SOFTWARE REFERENCE ........................................................... 85
6.1 ASUS PC Probe ......................................................................... 85
INDEX ................................................................................................... 91

ASUS TUV4X User’s Manual
6
FCC & DOC COMPLIANCE
FederalCommunications Commission Statement
This device complies with FCC Rules Part 15. Operation is subject to the following
two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received, including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
providereasonable protectionagainst harmfulinterference ina residentialinstallation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with manufacturer's instructions, may cause harmful
interferenceto radiocommunications.However,there isnoguarantee thatinterference
will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
• Re-orient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
WARNING!Any changesor modificationsto thisproduct not expressly approved
by the manufacturer could void any assurances of safety or performance and
could result in violation of Part 15 of the FCC Rules.
Reprinted from the Code of Federal Regulations #47, part 15.193, 1993. Washington DC: Office of the
Federal Register, National Archives and Records Administration, U.S. Government Printing Office.
CanadianDepartment of CommunicationsStatement
This digital apparatus does not exceed the Class B limits for radio noise emissions
from digital apparatus set out in the Radio Interference Regulations of the Canadian
Department of Communications.
This Class B digital apparatus complies with Canadian ICES-003.
CetappareilnumériquedelaclasseBestconformeàlanormeNMB-003duCanada.

ASUS TUV4X User’s Manual 7
1.1 How This Manual Is Organized
This manual is divided into the following sections:
1. INTRODUCTION Manual information and checklist
2. FEATURES Production information and specifications
3. HARDWARE SETUP Instructions on setting up the motherboard.
4. BIOS SETUP Instructions on setting up the BIOS
5. SOFTWARE SETUP Instructions on setting up the included software
6. SOFTWARE REFERENCE Reference material for the included software
7. APPENDIX Optional items and general reference
1.2 Item Checklist
Check that your package is complete. If you discover damaged or missing items,
contact your retailer.
1. INTRODUCTION
1. INTRODUCTION
Manual / Checklist
Package Contents
(1) ASUS Motherboard
(1) 40-pin 80-conductor ribbon
cable for internal UltraDMA/66
or UltraDMA/33 IDE drives
(1) Ribbon cable for two 3.5”
floppy disk drives
(1) ASUS Support CD with drivers
and utilities
(1) Bag of spare jumper caps
(1) ASUS 2-port USB Connector
Set
(1) User’s Manual
Optional Items
ASUS Modem MR
ASUS IrDA-compliant infrared
module
ASUS PCI-L101 Wake-On-LAN
10/100 Ethernet Card

8ASUS TUV4X User’s Manual
2.1 ASUS TUV4X Motherboard
Powered by Intel
®
Pentium
®
III/Coppermine processors, the TUV4X motherboard
comes bundled with advanced features to provide outstanding performance. The
TUV4X packs in more value by offering plenty of room for expansion making it
truly flexible.
2.1.1 Specifications
•Latest Processor Support
Intel Pentium
®
III 133MHz FSB Tualatin core FC-PGA2
Intel Pentium
®
III 133/100MHz FSB Coppermine core FC-PGA
Intel Celeron™100/66MHz FSB Coppermine core FC-PGA
•NorthBridge SystemChipset: Features the VIAVT82C694T system controller
with support forAGP4X/2X mode; 133/100/66MHz Front Side Bus (FSB); and
133/100/66MHz memory bus.
•South Bridge System Chipset: VIAVT82C686B PCI-to-ISA bridge with PCI
Super I/O integrated peripheral controller supports UltraDMA/100/66/33 for
burst mode data transfer rates of up to 100MB/sec, and USB controller with root
hub for four USB ports.
•PC133 SDRAM / VC133 VCM Support: Equipped with four Dual Inline
Memory Module (DIMM) sockets to support up to 1.5GB of memory using
Intel PC133/100-compliant or NEC’s VC133-compliant Virtual Channel (VC)
SDRAMs - the new DRAM core architecture that dramatically improves the
memory system’s ability to service high multimedia requirements.
•JumperFree™Mode: Allows processor settings and easy overclocking of
frequency and Vcore voltage through BIOS setup when the JumperFree™mode
is enabled. Easy-to-use DIP switches come with the motherboard board to allow
manual adjustment of the processor external/internal frequency.
•UltraDMA/100Support:Comes withan onboard PCIBus MasterIDEcontroller
with two connectors that support four IDE devices on two channels. Supports
UltraDMA/100, UltraDMA/66, UltraDMA/33, PIO Modes 3 & 4, Bus Master
IDE DMA Mode 2, and Enhanced IDE devices, such as DVD-ROM, CD-ROM,
CD-R/RW, LS-120, and Tape Backup drives.
•AGP Pro Slot: Comes with an Accelerated Graphics Port (AGP) Pro slot that
supports high performance AGP cards targeted at 3D graphical applications
supporting 4X mode. The slot is backward compatible withAGP 4X/2X cards.
•Wake-On-LAN: Supports Wake-On-LAN activity through a WOL connector.
•Wake-On-Ring: Supports Wake-On-Ring activity through a PCI modem card
that supports a WOR connector, or an external modem through the COM port.
2. FEATURES
Specifications
2. FEATURES

ASUS TUV4X User’s Manual 9
2. FEATURES
2. FEATURES
Specifications
•PC Health Monitoring: Provides an easy way to examine and manage system
status information, such as CPU and system voltages, temperatures, and fan
status through the onboard hardware ASUS ASIC and the bundled ASUS PC
Probe.
•SMBus: Features the System Management Bus interface used to physically
transport commands and information between SMBus devices.
•PCI/AMR Expansion Slots: Includes six 32-bit PCI (Rev. 2.2) expansion slots
that support Bus Master PCI cards, such as SCSI or LAN cards, with 133MB/s
maximum throughput. The motherboard also includes one Audio Modem Riser
(AMR) slot that supports an audio or modem card.
•Super Multi-I/O: Provides two high-speed UART compatible serial ports and
one parallel port with EPP and ECP capabilities. UART2 can also be directed
from COM2 to the Infrared Module for wireless connections.
•Smart BIOS: 2Mb firmware provides Vcore and CPU/SDRAM frequency
adjustments,boot blockwrite protection,and HD/SCSI/MO/ZIP/CD/Floppyboot
selection.
•EnhancedACPIandAnti-BootVirus Protection:Programmable BIOS (Flash
EEPROM) that offers enhancedACPI for Windows 98/ME/2000 compatibility,
built-in firmware-based virus protection, and autodetection of most devices for
a virtual automatic setup.
•IntegratedInfrared(IrDA)Support:Supports anoptional infraredport module
for wireless interface.
•Desktop Management Interface (DMI): Supports DMI through BIOS that
allows hardware to communicate within a standard protocol and create a higher
level of compatibility. (Requires DMI-enabled components.)
•Onboard LED: Comes with a power LED that lights up if there is any standby
power on the motherboard. This LED acts as a reminder to turn off the system
power before plugging or unplugging devices to prevent damage to the
motherboard, peripherals, and other system components.
•Onboard Audio (optional): Audio models come with the C-Media CMI8738
4-channel audio chip to support HRTF-based 3D positional audio through a
DirectSound 3D interface. The audio chipset also supports legacy audio SB16-
compatible devices.
•Easy Connectivity and System Information Access: Supports an optional
ASUS iPanel, an easy-to-access box with system diagnostic display area, system
status LEDs, USB ports, and hot keys. The AFPANEL connector on the
motherboard accommodates theASUS iPanel to allow convenient connectivity
and system monitoring.

10 ASUS TUV4X User’s Manual
2. FEATURES
Features
2. FEATURES
2.1.2 Performance
•ACPI Ready: Advanced Configuration Power Interface (ACPI) provides more
Energy Saving Features for operating systems that support OS Direct Power
Management (OSPM) functionality. With these features employed in the OS,
PCs can be ready around the clock but comply with energy saving standards. To
fully utilize the ACPI benefits, use an ACPI-supported OS such as Windows
98/ME/2000.
•PC’99 Compliant: Both the BIOS and hardware levels of ASUS smart series
motherboards are PC’99 compliant. The new PC’99 requirements for systems
and components are based on the following high-level goals: Support for Plug-
n-Play compatibility and power management for configuring and managing all
system components, and 32-bit device drivers and installation procedures for
Windows 98/ME/2000. Color-coded connectors and descriptive icons make
identification easy as required by PC’99.
•High-Speed Data Transfer Interface: Support for UltraDMA/100 through the
onboard IDE bus master controller. doubles the UltraDMA/33 burst transfer
rate to 66.6MB/s. UltraDMA/100 is backward compatible with DMA/66,
DMA/33, and other existing DMA devices to save the need to upgrade current
EIDE/IDE drives. (UltraDMA/100/66 requires a 40-pin 80-conductor cable).
•Concurrent PCI:ConcurrentPCI allowsmultiple PCI transfers from PCImaster
busses to the memory and processor.
•VCM/SDRAM Optimized Performance: This motherboard supports the new
generation memory, NEC 64Mb Virtual Channel Memory (VCM) Synchronous
Dynamic RandomAccess Memory (SDRAM), that is compatible to the industry
standard SDRAM. The VCM core design provides up to 50% higher SDRAM
speed at reduced power consumption of about 30%. This motherboard also
supportsthe standard SDRAM for a the data transfer rate of up to 1.067GB/s using
PC133-compliant SDRAMs and up to 800MB/s using PC100-compliant
SDRAMs.
•Power Saving Feature: Suspend-to-RAM (STR) provides maximum power
savings as an alternative to leaving the computer ON. STR allows QuickStart™
when you get back , so you don’t have to go through the long boot process.
(NOTE:This motherboard does not support the Suspend-to-RAM (STR) feature
when you install a DIMM into the DIMM4 socket.)

ASUS TUV4X User’s Manual 11
2. FEATURES
2. FEATURES
Intelligence
2.1.3 Intelligence
•Auto Fan Off: The system fans powers off automatically even in sleep mode.
This function reduces both energy consumption and system noise, and is an
important feature in implementing Silent PC systems.
•DualFunctionPower Button: Pushing the power button for less than 4 seconds
when the system is in the working state places the system into one of two states:
sleep mode or soft-off mode, depending on the BIOS or OS setting (see PWR
Button < 4 Secs in 4.5 Power Menu). When the power button is pressed for
more than 4 seconds, the system enters the soft-off mode regardless of the BIOS
setting.
•Fan Status Monitoring and Alarm: To prevent system overheat and system
damage, the CPU and system fans can be monitored for RPM and failure. All
fans are set for its normal RPM range and alarm thresholds.
•PowerLED(requiresACPI OSsupport):The power LEDindicates the system
status.
•Remote Ring-On (requires modem): This allows a computer to be turned on
remotely through an internal or external modem. With this benefit on-hand, users
can access vital information from their computers anywhere.
•System Resources Alert: Today’s operating systems such as Windows 95/98/
2000/NT and OS/2, require much more memory and hard drive space to present
enormoususer interfacesand runlargeapplications. The system resource monitor
warns the user before the system resources are used up to prevent possible
application crashes. Suggestions provide the user some information on managing
their limited resources more efficiently.
•Temperature Monitoring and Alert: CPU temperature is monitored by the
ASUS ASIC through the CPU’s internal thermal diode (on Pentium III and
Celeron) to prevent system overheat and system damage.
•Voltage Monitoring andAlert: System voltage levels are monitored to ensure
stable voltage to critical motherboard components. Voltage specifications are
more critical for future processors, so monitoring is necessary to ensure proper
system configuration and management.
•Chassis Intrusion Detection: Supports chassis-intrusion monitoring through
the ASUS ASIC. A chassis intrusion event is kept in memory on battery power
for more protection.

12 ASUS TUV4X User’s Manual
2. FEATURES
2. FEATURES
Motherboard Parts
Location
Processor Support Socket 370 for Pentium III/Celeron Processors ....................... 2
Feature Setting DIP Switches ................................................... 8
Chipsets VIAVT82C694T System Controller ........................................ 3
VIAVT82C686B PCIset......................................................... 13
2Mbit Programmable Flash EEPROM ..................................... 9
Main Memory Maximum 1.5GB support
4 DIMM Sockets ...................................................................... 4
PC133 SDRAM support
Expansion Slots 6 PCI Slots .............................................................................. 18
1 Accelerated Graphics Port (AGP) Pro/4X Slot ................... 19
1 Audio Modem Riser Slot ..................................................... 16
System I/O 1 Floppy Disk Drive Connector ............................................... 5
2 IDE Connectors ..................................................................... 7
1 Parallel Port ............................................................... (Top) 22
2 Serial Ports (COM1/COM2) ............................... (Bottom) 22
USB Connectors (Port 0 & Port 1) ......................................... 24
USB Connectors (Port 2 & Port 3) ........................................ 10
1 PS/2 Mouse Connector .............................................. (Top) 25
1 PS/2 Keyboard Connector ................................... (Bottom) 25
Hardware Monitoring System Voltage Monitoring (integrated in ASUS ASIC) ....... 11
Fan Power and Speed Monitoring Connectors
Onboard Audio (on audio models only)
Audio Chipset ......................................................................... 17
1 Game/MIDI Connector.............................................. (Top) 20
1 Line Out Connector ............................................. (Bottom) 20
1 Line In Connector................................................ (Bottom) 20
1 Microphone Connector ........................................ (Bottom) 20
Special Features Onboard LED ........................................................................... 6
ASUS iPanel Connector ......................................................... 12
Wake-on-Ring Connector ....................................................... 14
Wake-on-LAN Connector ...................................................... 15
Power ATX Power Supply Connector ................................................. 1
Form Factor ATX
2.2 Motherboard Components
See opposite page for locations.

ASUS TUV4X User’s Manual 13
2. FEATURES
2. FEATURES
Motherboard Parts
2.2.1 Component Locations
7
18
22
20
25
24
2
19
34 56
911121516
17
1314 10
1 8
21
23

14 ASUS TUV4X User’s Manual
3. HARDWARE SETUP
3.1 Motherboard Layout
Motherboard Layout
3. H/W SETUP
20.9cm (8.22in)
30.5cm (12.0in)
PCI 6
CLRTC
Primary IDE
Secondary IDE
ATX Power Connector
PCI 2
WOL_CON
SMB
FLOPPY
TUV4X
Audio Modem Riser
(AMR)
CHA_FAN
PWR_FAN
Socket 370
USBPORT
VIA
VT82C686B
Chipset
ASUS
ASIC
with Hardware
Monitor
JTPWR
PCI 1
DIMM Socket 1 (64/72-bit, 168-pin module)
01
DIMM Socket 2 (64/72-bit, 168-pin module)
23
DIMM Socket 3 (64/72-bit, 168-pin module)
45
CPU_FAN
IR
Accelerated Graphics Port (AGP Pro)
VIA
VT82C694T
Chipset
Flash EEPROM
(Programable BIOS)
CR2032 3V
Lithium Cell
CMOS Power
PCI 4
PCI 3
PCI 5
GAME_AUDIO
Mic
In
Line
Out
Line
In
WOR
AUX MODEM
CD1
LED
JEN
VIO
PS/2
T: Mouse
B: Keyboard
USB1
USB2
COM1
PARALLEL PORT
COM2
DIP_SW
DIMM Socket 4 (64/72-bit, 168-pin module)
67
AFPANEL
C-Media
CMI-8738
MIC2
USB_PWR0
®
USBPWR1
CHASSIS PANEL
IDELED
NOTE: The audio chipset, external GAME/AUDIO connectors, and internal
audio connectors are optional components, and present in audio models
only. The components are grayed in the above motherboard layout.

ASUS TUV4X User’s Manual 15
3. HARDWARE SETUP
3.2 Layout Contents
Motherboard Settings
1) JEN p. 17 JumperFree Mode Setting
2) DIP_SW 5–8 p. 18 CPU External Frequency Selection
3) DIP_SW 1-4 p. 19 CPU Core:BUS Frequency Multiple Selection
4) CLRTC p. 21 Clear RTC RAM
5) USBPWR0/1 p. 22 USB Wake-up Jumpers
Expansion Slots/Sockets
1) DIMM 1/2/3/4 p. 24 System Memoy Support
2) Socket 370 p. 25 CPU Support
3) PCI 1/2/3/4/5/6 p. 27 32-bit PCI Bus Expansion Slots
4) AGP Pro p. 29 Accelerated Graphics Port
5) AMR p. 30 Audio Modem Riser (AMR) Slot
Connectors
1) PS2KBMS p. 31 PS/2 Mouse Port Connector (6-pin female)
2) PS2KBMS p. 31 PS/2 Keyboard Port Connector (6-pin female)
3) USB p. 32 Universal Serial Bus Connectors 1 & 2 (two 4-pin female)
4) PRINTER p. 32 Parallel Port Connector (25-pin female)
5) COM1/COM2 p. 32 Serial Port Connectors (two 9-pin /10-1 pin male)
6) GAME_AUDIO p. 33 Game/MIDI Connector (15-pin female)
7) AUDIO p. 33 Audio Connectors (three 1/8”jacks)
8) IDELED p. 34 IDE Activity LED (2-pin)
9) FLOPPY p. 34 Floppy Disk Drive Port Connector (34-1 pin)
10) PRIMARY IDE p. 35 IDE Connectors (two 40-1 pin)
SECONDARY IDE
11) WOL_CON p. 36 Wake-On-LAN Connector (3-pin)
12) WOR p. 36 Wake-On-Ring Connector (2-pin)
13) CPU/PWR/CHA_FAN p. 37 Chassis and CPU Fan Connectors (three3-pin)
14) CHASSIS p. 38 Chassis Intrusion Lead (4-1 pin)
15) SMB p. 38 SMBus Connector (5-1 pin)
16) IR p. 39 Infrared Module Connector (5-pin)
17) USBPORT p. 39 USB Header (10-1 pin)
18) ATXPWR p. 40 ATX Power Supply Connectors (20-pin)
19) AFPANEL p. 41 ASUS iPanel Connector (12-1 pin)
20) MIC2 p. 41 Internal Microphone Connector (3-pin)
21) CD/AUX/MODEM p. 42 Internal Audio Connectors (three 3-pin)
22)
PWR.LED ( PANEL ) p. 43 System Power LED Lead (3-pins)
23) SPEAKER (PANEL) p. 43 System Warning Speaker Connector (4-pin)
24) MSG.LED (PANEL) p. 43 System Message LED (2-pin)
25) SMI (PANEL) p. 43 System Management Interrupt Lead (2-pin)
26) PWR.SW (PANEL) p. 43 ATX / Soft-Off Switch Lead (2-pin)
27) RESET (PANEL) p. 43 Reset Switch Lead (2-pin)
Layout Contents
3. H/W SETUP

16 ASUS TUV4X User’s Manual
3. HARDWARE SETUP
Motherboard Settings
3. H/W SETUP
3.3 Hardware Setup Procedure
Before using your computer, you must complete the following steps:
1. Check motherboard settings
2. Install memory modules
3. Install the Central Processing Unit (CPU)
4. Install Expansion Cards
5. Connect Ribbon Cables, Panel Wires, and Power Supply
6. Setup the BIOS Software
3.4 Motherboard Settings
This section tells you how to change motherboard function settings through the
switches and/or jumpers.
WARNING! Computer motherboards and expansion cards contain very delicate
Integrated Circuit (IC) chips. To avoid damaging them due to static electricity,
follow these precautions whenever you work on your computer.
1. Unplug the computer when working on the internal components.
2. Use a grounded wrist strap or touch a safely grounded object or to a metal
object,suchasthe powersupplycase, beforehandlingcomputercomponents.
3. Hold components by the edges and try not to touch the IC chips on them.
4. Wheneveryou uninstallany component,placethe componentsonagrounded
antistatic pad or in the bag that came with the components.
5. Beforeyouinstallorremoveanycomponent,ensurethattheATXpower
supply is switched off or the power cord is detached from the power
supply. Failure to do so may cause severe damage to the motherboard,
peripherals, and/or components.
(TIP:When lit, the onboard LED indicates that the system is in suspend or
soft-off mode, not powered OFF.)
TUV4X Onboard LED
ON OFF
Standby
Power Powered
Off
LED
TUV4X
®

ASUS TUV4X User’s Manual 17
3. HARDWARE SETUP
3. H/W SETUP
Motherboard Settings
Motherboard Frequency Settings (DIP Switches)
The motherboard frequency is adjusted through the DIP switches. The white block
represents the switch’s position. The example below shows all the switches in the
OFF position.
1) JumperFree™Mode (JEN)
This jumper allows you to enable or disable the JumperFree™mode. The
JumperFree™mode allows processor settings to be made through the BIOS
setup (see 4.4 Advanced Menu).
Setting JEN
Enable (JumperFree) [2-3] (default)
Disable (Jumper) [1-2]
NOTE: In JumperFree™mode, set all DIP switches (DIP_SW) to OFF.
TUV4X DIP Switches
ON
12345678
OFF
ON
< Frequency Multiple < Frequency Multiple < Frequency Multiple < Frequency Multiple < Frequency Selection < Frequency Selection < Frequency Selection < Frequency Selection
TUV4X
®
TUV4X JumperFree™ Mode Setting
Jumper
Mode JumperFree Mode
(Default)
23
JEN
12
ON
12345678
OFF
DIP_SW
TUV4X
®

18 ASUS TUV4X User’s Manual
3. HARDWARE SETUP
2) CPU External Frequency Selection (DIP_SW Switches 5–8)
This option tells the clock generator what frequency to send to the CPU, DRAM,
and the PCI bus. This allows the selection of the CPU’s External frequency (or
BUS Clock). The BUS Clock multiplied by the Frequency Multiple equals the
CPU’s Internal frequency (the advertised CPU speed).
3. H/W SETUP
Motherboard Settings
WARNING!Setthe CPU frequencyonly tothe recommended settings.Frequencies
other than the recommended CPU bus frequencies are not guaranteed to be stable.
Overclocking the processor is not recommended. It may result in a slower speed.
TUV4X CPU External
Frequency Selection
83MHz
42MHz
ON
12345678
66MHz
33MHz
ON
12345678 68MHz
34MHz
ON
12345678 75MHz
37MHz
ON
12345678
80MHz
40MHz
ON
12345678
CPU
PCI
CPU
PCI 100MHz 33MHz
ON
12345678
CPU
PCI 103MHz 34MHz
ON
12345678 105MHz
35MHz
ON
12345678 112MHz
37MHz
ON
12345678
133MHz
33MHz
ON
12345678 140MHz
35MHz
ON
12345678 150MHz
37MHz
ON
12345678
120MHz
40MHz
ON
12345678 124MHz
31MHz
ON
12345678
CPU
PCI 115MHz 38MHz
ON
12345678
CPU
PCI
TUV4X
®

ASUS TUV4X User’s Manual 19
3. HARDWARE SETUP
3. H/W SETUP
Motherboard Settings
3) CPU Core:BUS Frequency Multiple (DIP_SW Switches 1–4)
This option sets the frequency multiple between the Internal frequency of the
CPU and the CPU’s Externalfrequency.These must be set in conjunction with the
CPU Bus Frequency.
TUV4X CPU Frequency
Multiple Selection
2.0x
ON
12345678
2.5x
ON
12345678
3.0x
ON
12345678
3.5x
ON
12345678
4.0x
ON
12345678
4.5x
ON
12345678
5.0x
ON
12345678
5.5x
ON
12345678
6.0x
ON
12345678
6.5x
ON
12345678
7.0x
ON
12345678
7.5x
ON
12345678
8.0x
ON
12345678
Test
ON
12345678
TUV4X
®

20 ASUS TUV4X User’s Manual
3. HARDWARE SETUP
3. H/W SETUP
Motherboard Settings
Manual CPU Settings
NOTE: Disable the JumperFree™mode when you are manually setting the
CPU frequency through the DIP switches.
Set the DIP switches by the Internal speed of your processor asfollows:
(CPU BUS Freq.) (Freq. Multiple)
Intel CPU Model Freq. Mult. Bus F. 5 6 7 8 1 2 3 4
Pentium III 1GHz 7.5x 133MHz [OFF] [OFF] [OFF] [OFF] [OFF] [OFF] [ON] [OFF]
Pentium III 933MHz 7.0x 133MHz [OFF] [OFF] [OFF] [OFF] [ON] [OFF] [ON] [OFF]
Pentium III 866MHz 6.5x 133MHz [OFF] [OFF] [OFF] [OFF] [OFF] [ON] [ON] [OFF]
Pentium III 800MHz 6.0x 133MHz [OFF] [OFF] [OFF] [OFF] [ON] [ON] [ON] [OFF]
Pentium III 733MHz 5.5x 133MHz [OFF] [OFF] [OFF] [OFF] [OFF] [OFF] [OFF] [ON]
Pentium III 667MHz 5.0x 133MHz [OFF] [OFF] [OFF] [OFF] [ON] [OFF] [OFF] [ON]
Pentium III 600MHz 4.5x 133MHz [OFF] [OFF] [OFF] [OFF] [OFF] [ON] [OFF] [ON]
Pentium III 533MHz 4.0x 133MHz [OFF] [OFF] [OFF] [OFF] [ON] [ON] [OFF] [ON]
Pentium III 800MHz 8.0x 100MHz [OFF] [OFF] [OFF] [ON] [ON] [ON] [OFF] [OFF]
Pentium III 750MHz 7.5x 100MHz [OFF] [OFF] [OFF] [ON] [OFF] [OFF] [ON] [OFF]
Pentium III 700MHz 7.0x 100MHz [OFF] [OFF] [OFF] [ON] [ON] [OFF] [ON] [OFF]
Pentium III 650MHz 6.5x 100MHz [OFF] [OFF] [OFF] [ON] [OFF] [ON] [ON] [OFF]
Pentium III 600MHz 6.0x 100MHz [OFF] [OFF] [OFF] [ON] [ON] [ON] [ON] [OFF]
Pentium III 550MHz 5.5x 100MHz [OFF] [OFF] [OFF] [ON] [OFF] [OFF] [OFF] [ON]
Pentium III 500MHz 5.0x 100MHz [OFF] [OFF] [OFF] [ON] [ON] [OFF] [OFF] [ON]
Pentium III 450MHz 4.5x 100MHz [OFF] [OFF] [OFF] [ON] [OFF] [ON] [OFF] [ON]
Celeron 533MHz 8.0x 66MHz [OFF] [OFF] [ON] [ON] [ON] [ON] [OFF] [OFF]
Celeron 500MHz 7.5x 66MHz [OFF] [OFF] [ON] [ON] [OFF] [OFF] [ON] [OFF]
Celeron 466MHz 7.0x 66MHz [OFF] [OFF] [ON] [ON] [ON] [OFF] [ON] [OFF]
Celeron 433MHz 6.5x 66MHz [OFF] [OFF] [ON] [ON] [OFF] [ON] [ON] [OFF]
Celeron 400MHz 6.0x 66MHz [OFF] [OFF] [ON] [ON] [ON] [ON] [ON] [OFF]
Celeron 366MHz 5.5x 66MHz [OFF] [OFF] [ON] [ON] [OFF] [OFF] [OFF] [ON]
Celeron 333MHz 5.0x 66MHz [OFF] [OFF] [ON] [ON] [ON] [OFF] [OFF] [ON]
Celeron 300MHz 4.5x 66MHz [OFF] [OFF] [ON] [ON] [OFF] [ON] [OFF] [ON]
Celeron 266MHz 4.0x 66MHz [OFF] [OFF] [ON] [ON] [ON] [ON] [OFF] [ON]
