Asus AP6000 Operating and maintenance manual

AP6000
Dual Pentium®II Server
Hardware Reference Guide

AP6000 Hardware Reference Guide
2
USER’S NOTICE
No part of this manual, including the products and software described in it, may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into
any language in any form or by any means, except documentation kept by the pur-
chaser for backup purposes, without the express written permission of ASUSTeK
COMPUTER INC. (“ASUS”).
ASUS PROVIDES THIS MANUAL“AS IS” WITHOUT WARRANTY OF ANY
KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED
TO THE IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABIL-
ITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL
ASUS, ITS DIRECTORS, OFFICERS, EMPLOYEES ORAGENTS BE LIABLE
FORANYINDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIALDAM-
AGES (INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSI-
NESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE
LIKE), EVEN IFASUS HAS BEENADVISED OF THE POSSIBILITYOF SUCH
DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL
OR PRODUCT.
Product warranty or service will not be extended if: (1) the product is repaired,
modified or altered, unless such repair, modification of alteration is authorized in
writing by ASUS; or (2) the serial number of the product is defaced or missing.
Products and corporate names appearing in this manual may or may not be regis-
tered trademarks or copyrights of their respective companies, and are used only for
identification or explanation and to the owners’ benefit, without intent to infringe.
• Intel, LANDesk, and Pentium are registered trademarks of Intel Corporation.
• IBM and OS/2 are registered trademarks of International Business Machines.
• Windows and MS-DOS are registered trademarks of Microsoft Corporation.
• Adobe and Acrobat are registered trademarks of Adobe Systems Incorporated.
Theproductnameandrevisionnumberarebothprintedontheproduct itself. Manual
revisions are released for each product design represented by the digit before and
after the period of the manual revision number. Manual updates are represented by
the third digit in the manual revision number.
For previous or updated manuals, BIOS, drivers, or product release information, con-
tact ASUS at http://www.asus.com.tw or through any of the means indicated on the
following page.
SPECIFICATIONSANDINFORMATION CONTAINED INTHIS MANUALARE
FURNISHED FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO
CHANGE ATANY TIME WITHOUT NOTICE,AND SHOULD NOT BE CON-
STRUED AS A COMMITMENT BYASUS. ASUS ASSUMES NO RESPONSI-
BILITYOR LIABILITY FORANYERRORS OR INACCURACIES THAT MAY
APPEARINTHIS MANUAL, INCLUDINGTHEPRODUCTSANDSOFTWARE
DESCRIBED IN IT.
Copyright © 1998 ASUSTeK COMPUTER INC. All Rights Reserved.
Product Name: AP6000
Manual Revision: 1.00
Release Date: July 1998

AP6000 Hardware Reference Guide 3
ASUS CONTACT INFORMATION
ASUSTeK COMPUTER INC.
Marketing
Address: 150 Li-Te Road, Peitou, Taipei, Taiwan 112
Telephone: [phone]
Fax: [phone]
Email: [email protected]
Technical Support
Fax: [phone]
BBS: [phone]
Email: [email protected]
WWW: www.asus.com.tw
FTP: ftp.asus.com.tw/pub/ASUS
ASUS COMPUTER INTERNATIONAL
Marketing
Address: 6737 Mowry Avenue, Mowry Business Center, Building 2
Newark, CA 94560, USA
Fax: [phone]
Email: [email protected]
Technical Support
Fax: [phone]
BBS: [phone]
Email: [email protected]
WWW: www.asus.com
FTP: ftp.asus.com.tw/pub/ASUS
ASUS COMPUTER GmbH
Marketing
Address: Harkort Str. 25, 40880 Ratingen, BRD, Germany
Telephone: [phone]
Fax: [phone]
Email: [email protected]
Technical Support
Hotline: [phone]
BBS: 49-2102-448690
Email: [email protected]
WWW: www.asuscom.de
FTP: ftp.asuscom.de/pub/ASUSCOM

AP6000 Hardware Reference Guide
4
CONTENTS
I. Introduction......................................................................................7
This Reference Guide.................................................................7
Server Component Checklist......................................................7
Server Features...........................................................................8
Motherboard Features: ASUS P2B-DS ................................8
Chassis Features: AS-50 .......................................................8
Electrical Safety .........................................................................9
Static-Sensitive Devices.............................................................9
Tools Required .........................................................................10
Server Preparation ....................................................................10
Starting the Server....................................................................11
II. System Components .....................................................................12
ATX Power Button .............................................................12
LED Indicators ...................................................................12
Server Back Side ......................................................................13
Power Supply......................................................................13
Chassis Panels ....................................................................14
Circulation System .............................................................15
Fan Replacement ................................................................15
Fixed Storage Device Tray.......................................................16
Fixed Device Bay Cover Clips ...........................................16
Fixed Device Bay Cover ....................................................16
Fixed Storage Devices..............................................................17
Floppy Drive and CD-ROM ...............................................17
Floppy Drive and Storage Device Spacers .........................17
Hot-Swap Trays........................................................................18
Hot-Swap Tray Interface ..........................................................18
Hot-Swap Tray Usage ..............................................................19
Hot-Swap Tray Front Connections.....................................19
Hot-Swap Tray Connector Board.............................................20
Hot-Swap Tray Rear Connections ......................................20
Motherboard Securing ........................................................21
Spacer Mounts ....................................................................21

AP6000 Hardware Reference Guide 5
SCSI Backplane .......................................................................22
SCSI Board Placement .......................................................22
SCSI ID Setting ..................................................................23
SCSI ID Dip Switches ........................................................23
SCSI Connections ....................................................................24
SCSI Termination .....................................................................24
SCSI ID Jumpers......................................................................24
SCSI ID Priority .......................................................................24
RAID card connections ............................................................24
Cables .......................................................................................26
Cable Connections ...................................................................26
Device Connections............................................................27
III. Power Information......................................................................28
Output Regulations...................................................................28
Minimum Cross-Loading & Load Range Graph .....................28
DC Load Requirements............................................................28
Power Supply Requirement Calculation Table ........................29
CONTENTS

AP6000 Hardware Reference Guide
6
FCC & DOC COMPLIANCE
FederalCommunicationsCommissionStatement
This device complies with FCC Rules Part 15. Operation is subject to the
following two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received, including interfer-
ence that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
manufacturer’s instructions, may cause harmful interference to radio com-
munications. However, there is no guarantee that interference will not oc-
cur in a particular installation. If this equipment does cause harmful inter-
ference to radio or television reception, which can be determined by turn-
ing the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
WARNING! The use of shielded cables for connection of the
monitor to the graphics card is required to assure compliance
with FCC regulations. Changes or modifications to this unit not
expressly approved by the party responsible for compliance could void
the user’s authority to operate this equipment.
CanadianDepartmentofCommunicationsStatement
This digital apparatus does not exceed the Class B limits for radio noise
emissions from digital apparatus set out in the Radio Interference Regula-
tions of the Canadian Department of Communications.

AP6000 Hardware Reference Guide 7
II. Components
I. Introduction
I. Introduction
I. Introduction
You are reading theAP6000 server Hardware Reference Guide.TheAP6000
is configured on the ASUS P2B-DS smart motherboard which uses the
440BX chipset from Intel which supports dual Pentium II processors and
100MHz front side Bus in order to accelerate even the most complicated
server tasks.
This Reference Guide
This hardware reference guide provides information about the various com-
ponents used in this server.All components in shown in this reference guide
are optional and may be individually purchased to complete this server.
Server Component Checklist
If assembling this server by yourself, it is important to prepare all the server
components before starting. This will save a great deal of time by not hav-
ing to hunt down components.The following checklist provides a guideline
as to the necessary components for a corporate server.
Motherboard: ASUS P2B-DS
Chassis: ASUS AS-50
Power Supply
Pentium II Processor(s)
DIMM memory modules
Hard Disk Drives
Floppy Drive
CD-ROM Drive
Ethernet Card
RAID controller
Checklist

8 AP6000 Hardware Reference Guide
II. Components
I. Introduction
I. Introduction
Server Features
Motherboard Features: ASUS P2B-DS
•Processor:(2) Intel PentiumII processorsrunning at66 or100MHz Front
Side Bus.
•Memory:(4) 168pin DIMM sockets for 8MB-1GB SDRAM/EDO with
support for ECC and 100MHz SDRAM.
•Super Multi-I/O: (2) PCI Bus Master IDE Ports with Ultra DRAM-33
support, (2) floppy, (2) serial COM ports, (1) parallel, (1) PS/2 key-
board, (1) PS/2 mouse, (2) USB ports, and (1) IrDA connector.
•SCSI: Onboard Ultra-II SCSI controller and LVDS to single end con-
verter with (2) wide SCSI connectors and (1) narrow SCSI connector.
•Expansion Slots: (4) PCI, (2) ISA slots, and (1) AGP port.
Chassis Features: AS-50
•Chassis: Tower server chassis with wheels
•Backplane: Wide-SCSI backplane with remote SCSI ID dip switches
and power to support 8 wide SCSI hard disk drives.
•Power:ATX 350W/400W power supply with optional redundant power
supply.
•Device Bays: Support for (1) 3.5inch floppy device, (3) 5.25inch de-
vices, (8) hard disk drives in removable aluminum trays.
Features

AP6000 Hardware Reference Guide 9
II. Components
I. Introduction
I. Introduction
Safety / Static
Electrical Safety
Observe the following safety instructions any time you are connecting or
disconnecting devices to the workstation.
DANGER:An electrical outlet thatis not correctly wiredcould place
hazardous voltage on metal parts of the system or the devices that
attach to the system. It is the responsibility of the customer to ensure
that the outlet is correctly wired and grounded to prevent an electrical shock.
Before installing or removing signal cables, ensure that the power cables
for the system unit and all attached devices are unplugged.
When adding or removing any additional devices to or from the system,
ensure that the power cables for those devices are unplugged before the
signal cables are connected. If possible, disconnect all power cables from
the existing system before you add a device.
Use one hand, when possible, to connect or disconnect signal cables to pre-
vent a possible shock from touching two surfaces with different electrical
potentials.
During an electrical storm, do not connect cables for display stations, print-
ers, telephones, or station protectors for communications lines.
To prevent electrical shock hazard, disconnect the power cable from the
electrical outlet before relocating the system.
CAUTION:This product is equipped with a three-wire power cable
and plug for the user’s safety. Use the power cable in conjunction
with a properly grounded electrical outlet to avoid electrical shock.
Static-Sensitive Devices
WARNING: Adapters, planars, diskette drives, and disk drives are
sensitive to static electricity discharge. These devices are wrapped in
antistaticbags toprevent thisdamage.Take thefollowing precautions:
• If you have an antistatic wrist strap available, use it while handling the
device.
• Do not remove the device from the antistatic bag until you are ready to
install the device in the system unit.
• With the device still in its antistatic bag, touch it to a metal frame of the
system.
• Grasp cards and boards by the edges. Hold drives by the frame. Avoid
touching the solder joints or pins.
• If you need to lay the device down while it is out of the antistatic bag,
lay it on the antistatic bag. Before picking it up again, touch the anti-
static bag and the metal frame of the system unit at the same time.
• Handle the devices carefully in order to prevent permanent damage.

10 AP6000 Hardware Reference Guide
II. Components
I. Introduction
I. Introduction
Tools Required
A Phillips (cross) and standard (flat) screwdriver is needed to install or re-
move the components in this server.
Server Preparation
1. Unpack your server, do not connect the power cord.
IMPORTANT: Most servers uses anAT power supply that has a
fixed On and Off switch located on the front. This server uses an
ATX power supply that is normally off until an electrical signal is given to
the power supply through a momentary switch located on the front of the
server. There is always a standby power in the power supply in order for
ATXpower supply featuresto work, therefore removingthe power cordis
necessary to prevent electrical shocks when working on the server com-
ponents.
2. Unlock the keylocks if necessary. This server is equipped with three
securitylocks to prevent unauthorized access.Turnthe key counterclock-
wise to unlock and clockwise to lock the side panels or front door.
3. Open the front door and side panels to install final server components,
such as CPU, Memory, Hard Disk Drives, expansion cards. Use this
hardware reference guide along with your motherboard manual in order
to make these installations.
4. Connect a Keyboard and Mouse (purchased separately)
5. Connect a VGA-compatible monitor (purchased separately)
6. Connect a printer to the parallel port if desired.
7. Connect server to network (an optional network card is needed)
WARNING: To prevent electrical shock or fire, be sure not to
plugtelecommunications/telephone cables into the networkRJ45
connector in the server if one is installed.
8. Connect power cord to the server’s power supply.
9. Connect Server toAC power - The power supply will automatically de-
tect and adjust to 120VAC or 240VAC power.
WARNING: This server is designed for connection to a grounded
(earthed) outlet. To reduce the risk of electrical shock or damage to
your server, do not bypass the grounding plug.
Tools / Preparation

AP6000 Hardware Reference Guide 11
II. Components
I. Introduction
I. Introduction
Starting
Starting the Server
Turn on the system unit by turning the power knob clockwise and pushing
inwards momentarily.The power button will snap back becauseATX power
systems have a electrical On/Off switch unlike AT systems which require a
permanent On or Off position. If the power indicator does not light, make
surethe powercord isconnected tothesystem unitand toa workinggrounded
outlet.
When booting your server for the first time, hold the “Delete” key and enter
BIOS setup in order to make settings. ISA cards requires that you set “IRQ
XX Used by ISA : Yes” in BIOS PNP AND PCI SETUP in order for that
IRQ to be reserved for your ISA expansion card. You need to set “Boot
Sequence : A, C” in BIOS FEATURES SETUP in order to boot from a
floppy diskette to setup your hard disk. Insert a bootable floppy diskette and
select “Save & Exit Setup” from the BIOS main menu. Once your server
has properly booted, an “A:\>” prompt will appear. Replace your boot disk
with a RAID setup diskette and setup your RAID. Reboot your server with
the operating system boot disk in order to install drivers for your devices
(such as CD-ROM and SCSI devices) and install your server operating sys-
tem. You may be prompted for manufacturer supplied driver diskettes for
each device on your server if they are not included in the operating system
setup drivers.
NOTE: Non-RAID hard disk drives can be setup using boot dis-
kettes provided with the server operating system or with MSDOS
“FDISK.EXE”. You must have the motherboard or other SCSI de-
vice driver diskettes when prompted by the operating system setup.

12 AP6000 Hardware Reference Guide
II. System Components
II. Components
II. System Components
The front side of the server is provided to show the front exterior compo-
nents of this server. The chassis is made of strong rust-resisting metal and
covered with a protective ivory surfacing.
ATX Power Button
This server uses an ATX power supply. Turn the power switch clockwise
and push in momentarily to turn on or turn off the power.
LED Indicators
The front of the server provides several LEDs to show the server’s power,
hard disk drive, and fan statuses.
Front Side
LED indicators
Power LED
Hard Drive Activity LED
Fan #1 Error (when lit)
Fan #2 Error (when lit)
Fan #3 Error (when lit)
Fan #4 Error (when lit)
Fan #5 Error (when lit)
Server front side
ATX Power Button
Fixed Device Bays
(for tape or hard
disk drives)
Metal Door Lock
Stabilizers
with wheel
Metal
Security Door
Hot Swap Tray
Metal Side
Access Panel
Floppy Drive
CD-ROM Drive

AP6000 Hardware Reference Guide 13
II. System Components
II. Components
Power Supply
The power supply must be inserted and removed from the right side of the
chassis. Remove the right side panel in order to access the power supply.
Several screws secure the power supply to the chassis as circled.Aseparate
face plate is also mounted on the power supply.
Back Side
Server back side
Power Supply
Power In Connector
Parallel Port
PS/2 Keyboard
Serial Ports
COM1 and COM2
PS/2 Mouse
Power Supply Fan
Network Card
SCSI RAID Card
Graphics Card
USB Ports 1 and 2
Circulation System
Outlet Vents
Side Panel Screw
Server Back Side
The back side of the server is provided to show the back exterior compo-
nents of this server.
Power supply back and side

14 AP6000 Hardware Reference Guide
II. System Components
II. Components
Chassis Panels
There are two panels on the chassis, one left side and one right side panel.
Each panel is secured by two screws on the back of the server (as circled) and
also by a CAM. The CAM has a rotating knob with its own keylock.Turn the
knob counterclockwise to release and clockwise to secure. The keylock can
be used to keep the knob from being turned by unauthorized people.
WARNING: Always remove the power cord when working on the
server internal components to prevent electrical shocks or damage
to electrical components.ATX power supplies always have standby
power even when powered Off when plugged into anAC electrical outlet.
Chassis Panels
Left side panel
Left Side Panel
Left Panel Knob
Side Panel Screw
Fan Module
Server left side
Pentium II processors
SCSI RAID Card
Ethernet Card
Graphics Card
Power Supply
Housing

AP6000 Hardware Reference Guide 15
II. System Components
II. Components
Circulation System
Fan module
Release Handle
(from chassis)
Fan 1
Fan 2
Fan 3
Fan 4
Fan 5
Fan Module
Control Board
FanReplacement (Reverse side)
Circulation System
The server’s air circulation system is comprised of five 3 inch (8 cm) fans
mounted on a metal fan module. The circulation system cools the hard disk
drives by bringing fresh air in from the front and forcing the hot air out
through the back. It is important to keep the air surrounding the hard disk
drives below 122˚F (50˚C) to prevent hard disk failures.
Fan Replacement
The fan module can be removed by pulling the handle and inserted by push-
ing. The handle must be in the out position to insert the fan module. The
individual fans are secured by two clips and two hooks.To release these clips,
use a screw driver to push these clips in and then slide the fan out. If an
individual fan fails, remove the fan and send it back to the vendor for replace-
ment. If all five fans fail, it may be that the fan control board needs replacing,
remove the control board and send it back to your vendor for replacement.
When replacing fans, be sure
that the fan rotations are in the
same direction. Use the
manufacturer’s sticker on one
side of the fan as a reference as
to the side. Air flows from the
front of the server to the rear.
Removing or inserting the fan module
Release Handle
Fan Module
Air Inlet Vents (along
full length of door)

16 AP6000 Hardware Reference Guide
II. System Components
II. Components
Fixed Storage Device Tray
Internal fixed storage devices are mounted on removable trays. There are
four available, one for a floppy device and another three for full-size de-
vices. There are six screws provided (as circled) for mounting a 4 inch de-
vice such as floppy or hard disk drive. Four screws are provided (as boxed)
for mounting 6 inch devices such as a CD-ROM or tape drive.
Fixed Device Bay Cover
After releasing the device bay cover clips, pry the cover open with a screw
driver from the front.
Fixed Device Bay Cover Clips
The device bay panel is held by two plastic clips on each side. Press these
clips in with a screw driver to release these clips.
Removing the device bay cover clips
Internal Fixed Storage Device Tray
Removing the device bay cover
Fixed DeviceTray
Fixed storage device tray

AP6000 Hardware Reference Guide 17
II. System Components
II. Components
Fixed Storage Devices
Floppy Drive and CD-ROM
The floppy drive fits in the topmost bay along with the power button.ACD-
ROM can fit into either the second, third, or fourth bay from the top. A
metal clip on each side of the device tray secures the tray in place. Press
inwards to release the clips. The tray slides in or out on the side rails.
WARNING: If using an IDE hard disk drive in this large chassis, it is
recommended that only one is installed and with the shortest IDE cable
possible.LongIDEcableswillcausepoorsignal.Select“...PIO/DMAMode
: 3/1” in BIOS CHIPSET FEATURES SETUPfor a more stable IDE operation.
Removing Floppy and CD-ROM device
Floppy Drive CD-ROM
Floppy and CD-ROM drives
Floppy Drive and Storage Device Spacers
Spacers are required for cosmetics only. A floppy drive spacer is used to
cover the floppy drive and power button. A standard storage device spacer
is used to cover the CD-ROM, tape drive, or additional CD-ROMs. You
should purchase an extra spacer for each storage device.
Floppy Drive Spacer Storage Device Spacer
Floppy and CD-ROM drive spacers
Fixed Devices

18 AP6000 Hardware Reference Guide
II. System Components
II. Components
Hot-Swap Trays
Maximum uptime in a server requires devices that can be easily replaced or
“swapped.” The main hard disks are mounted in internal hot-swap trays for
easy replacing.To remove the tray, unlock the tray and pull on the handle.A
lock secures the handle and switches on or off the power to the hard drive.
Hot-Swap Tray Interface
The front of the hot-swap tray provides a keylock in order to switch the
power on, which also locks the handle, and switch the power off, which also
releases the handle.Two LEDs provide information on the power and activ-
ity status of the hard disk drive. When power is received by the hot-swap
tray’s connector board, the power LED will light. When data is written or
read to or from the contained hard disk drive, the activity LED will flash
proportional to the amount of data.
Hot-SwapTrays
Removing or inserting the hot-swap tray
Hot-Swap Tray (8 Total)
Lock/
Power
On
Unlock/
Power Off
Hot-Swap Tray Keylock Positions
Hot-swap tray face plate
Keylock / Power Switch
Power LED (PLED)
Activity LED (SLED)
Release / Transport Handle
Air Inlet

AP6000 Hardware Reference Guide 19
II. System Components
II. Components
Hot-Swap Tray Front Connections
The hot-swap tray provides wires for connecting the activity LED, power
LED, SCSI ID, power, and SCSI signal. Connect the 8 pin connector to the
SCSI Address pins according to the colors shown. Connect the 2 pin con-
nector to the activity signal pins according to the colors shown.
IMPORTANT: The following is only an example. Always consult your
hard disk drive documentation or labels for the exact wiring specific to your
hard disk drive make and model.
Hot-SwapTrays
Hot-Swap Tray Usage
Each hot-swap tray provides an aluminum carrier for a single SCSI hard
disk drives with a maximum height of 1 5/8 inch, width of 4 inches, and
length of 6 inches. The aluminum tray provides protection and maximum
heat dissipation for almost all types of high speed SCSI disk drives. The
provided cables and wires connect to the SCSI hard disk drive and screws
are needed to secure the tray to the bottom of the SCSI hard disk drive.
Hot-swap tray and its connectors
SCSI Cable
Power Connector
Activity LED
(ALED)
SCSI ID
Aluminum Tray
Hot-swap tray SCSI ID & activity LED wires connected (Seagate HD)
1248
Activity
Signal
Blue Black
White
Yellow
Green Brown
Red
Red
Black
Orange
SCSI Address (ID#)
Pin 1
Unused
Seagate Cheetah (ST34501W) side opposite power & SCSI
Pin 2

20 AP6000 Hardware Reference Guide
II. System Components
II. Components
Hot-Swap Tray Connector Board
The connector board is mounted on the hot-swap tray to interface with the
SCSI backplane in the chassis. The connector board provides combines all
the signal and power into one docking connector for a clean hot-swap unit.
Hot-Swap Tray Rear Connections
KEY: These 2 pins connect to the keylock on the tray’s front panel to turn on
and off the drive’s power.
PLED: These 2 pins connect to the power LED on the front of the tray to
show when the connector board receives power.
SCSI_ID: These 8 pins connect to the hard disk drive’s SCSI address pins
to set the SCSI ID number of the hard disk drive.
SLED & ALED: These two wires are connected as illustrated below.
Hot-Swap Connector
Hot-swap tray connector board parts
Hard Disk Drive
Power Connector
Wide SCSI
Connector
Hot-Swap Tray
Docking Connector
KEY ALED_IN
(not used) SCSI_ID
SLED
(not used) PLED
Hot-swap tray rear connections (Seagate HD)
KEY PLED SCSI_ID Power
Connector Bridge for LED
from hard disk drive’s 2 pin
activity LED (ALED wire)
from tray’s front panel 3 pin
activity LED (SLED wire)
Green
Black
Red
SLED
(wire)
Red
Black
ALED
(wire)
Bridge
