Asus AP8000 Operating and maintenance manual

AP8000
Dual Pentium®III XeonTM
Corporate Server
Hardware Reference Guide

2AP8000 Hardware Reference Guide
Product Name: AP8000
Manual Revision: 1.01 E398
Release Date: June 1999
No part of this manual, including the products and software described in it, may be repro-
duced, transmitted, transcribed, stored in a retrieval system, or translated into any language
in any form or by any means, except documentation kept by the purchaser for backup pur-
poses, without the express written permission ofASUSTeK COMPUTER INC. (“ASUS”).
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND,
EITHEREXPRESSORIMPLIED, INCLUDINGBUTNOTLIMITEDTOTHEIMPLIED
WARRANTIESOR CONDITIONS OFMERCHANTABILITYOR FITNESS FORAPAR-
TICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS,
EMPLOYEES OR AGENTS BE LIABLE FORANY INDIRECT, SPECIAL, INCIDEN-
TAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF
PROFITS, LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSI-
NESSANDTHE LIKE), EVEN IFASUS HAS BEENADVISED OF THE POSSIBILITY
OF SUCH DAMAGESARISING FROMANYDEFECT OR ERROR INTHIS MANUAL
OR PRODUCT.
Product warranty or service will not be extended if: (1) the product is repaired, modified or
altered, unless such repair, modification of alteration is authorized in writing byASUS; or
(2) the serial number of the product is defaced or missing.
Products and corporate names appearing in this manual may or may not be registered trade-
marks or copyrights of their respective companies, and are used only for identification or
explanation and to the owners’ benefit, without intent to infringe.
The product name and revision number are both printed on the product itself. Manual revi-
sions are released for each product design represented by the digit before and after the
period of the manual revision number. Manual updates are represented by the third digit in
the manual revision number.
For previous or updated manuals, BIOS, drivers, or product release information, con-
tact ASUS at http://www.asus.com.tw or through any of the means indicated on the
following page.
SPECIFICATIONSAND INFORMATION CONTAINED IN THIS MANUALARE FUR-
NISHED FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT
ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A COM-
MITMENT BYASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY FOR
ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL, IN-
CLUDING THE PRODUCTSAND SOFTWARE DESCRIBED IN IT.
Copyright © 1999ASUSTeK COMPUTER INC.All Rights Reserved.
User's Notice

AP8000 Hardware Reference Guide 3
ASUS Contact Information
ASUSTeK COMPUTER INC. (Asia-Pacific)
Marketing
Address: 150 Li-Te Road, Peitou, Taipei, Taiwan 112
Telephone: [phone]
Fax: [phone]
Email: [email protected]
Technical Support
Tel (English): [phone] ext. 706
Tel (Chinese): [phone] ext. 701
Fax: [phone]
Email: [email protected]
Newsgroup: news2.asus.com.tw
WWW: www.asus.com.tw
FTP: ftp.asus.com.tw/pub/ASUS
ASUS COMPUTER INTERNATIONAL (America)
Marketing
Address: 6737 Mowry Avenue, Mowry Business Center, Building 2
Newark, CA 94560, USA
Fax: [phone]
Email: [email protected]
Technical Support
Fax: [phone]
BBS: [phone]
Email: [email protected]
WWW: www.asus.com
FTP: ftp.asus.com.tw/pub/ASUS
ASUS COMPUTER GmbH (Europe)
Marketing
Address: Harkort Str. 25, 40880 Ratingen, BRD, Germany
Telephone: [phone]
Fax: [phone]
Email: [email protected]
Technical Support
Hotline: [phone]
BBS: 49-2102-448690
Email: [email protected]
WWW: www.asuscom.de
FTP: ftp.asuscom.de/pub/ASUSCOM

4AP8000 Hardware Reference Guide
I. Introduction
1-1. How this Manual is Organized .......................................... 7
Symbols ........................................................................ 7
1-2. Component Checklist........................................................ 8
Standard Components.................................................. 8
Optional Components ................................................... 8
1-3. Features............................................................................ 9
1-4. Safeguards ..................................................................... 10
Operation Safety......................................................... 10
Tools Required............................................................ 10
1-5. Electrical Safety ...............................................................11
Static-Sensitive Devices ............................................. 11
II. Components
2-1. Server Front Side............................................................ 13
2-2. Server Back Side ............................................................ 14
2-3. Server Left Side .............................................................. 15
III. Basic Operation
3-1. Starting the Server.......................................................... 16
3-2. LED Indicators ................................................................ 16
3-3. BIOS Setup..................................................................... 16
IV. Hardware Setup
4-1. Opening the Chassis ...................................................... 17
Chassis Panels ........................................................... 17
Opening the Left Panel ............................................... 17
Fan Replacement ....................................................... 17
4-2. Motherboard ................................................................... 18
Motherboard Spacers ................................................. 18
Install the Baseboard .................................................. 18
Motherboard Screws................................................... 18
Device Cables............................................................. 19
Cable Connections ..................................................... 19
4-3. Central Processing Unit (CPU) ....................................... 20
Install Retention Mechanisms..................................... 20
Install Retention Mechanism Brace Bars.................... 20
Install Cartridge Lifters................................................ 21
Install Retention Mechanism Cap ............................... 21
Install Retention Mechanism Frame ........................... 21
4-4. Chassis Intrusion Switch................................................. 22
Chassis Intrusion Connector....................................... 23
4-5. Expansion Cards ............................................................ 23
4-6. Fixed Storage Devices.................................................... 24
Contents

AP8000 Hardware Reference Guide 5
Contents
Fixed Storage Device Tray ......................................... 24
Fixed Device Bay Cover Clips .................................... 24
Fixed Device Bay Cover ............................................. 24
4-7. Floppy Disk Drive and CD-ROM..................................... 25
Floppy Disk Drive........................................................ 25
CD-ROM Drive............................................................ 25
4-8. Hot-Swap Trays .............................................................. 26
Removing Hot-Swap Trays ......................................... 26
Hot-Swap Tray Usage................................................. 26
Hot-Swap Tray Front Connections.............................. 27
Hot-Swap Tray Interface ............................................. 27
4-9. Hot-Swap Tray Connector Board .................................... 28
Hot-Swap Tray Rear Connections .............................. 28
4-10. SCSI Backplane............................................................ 29
4-11. SCSI ID Setting ............................................................. 30
Using the SCSI Backplane Boards Separately........... 30
Using Cascaded SCSI Backplane Boards.................. 31
4-12. SCSI Backplane Board Placement ............................... 32
Installing & Removing SCSI Backplane Boards ......... 32
SCSI Hard Disk Connections...................................... 33
4-13. Circulation System........................................................ 34
Fan Module................................................................. 34
Fan Replacement ....................................................... 34
4-14. Power Supply................................................................ 35
Redundant Power Supply ........................................... 35
Power Supply Mounting.............................................. 35
Removing One Power Supply Module........................ 35
Removing the Entire Power Supply Unit..................... 36
Power Module Rating ................................................. 37
Power Module Failure................................................. 37
Power Supply Information........................................... 38
Power Supply Requirement ........................................ 39
V. Appendix
i. SCSI Cable Limits ............................................................... 41
ii. Glossary ............................................................................. 42

6AP8000 Hardware Reference Guide
FCC & DOC COMPLIANCE
FederalCommunicationsCommission Statement
This device complies with FCC Rules Part 15. Operation is subject to the
following two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received, including interfer-
ence that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with
manufacturer’s instructions, may cause harmful interference to radio com-
munications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference
toradio or televisionreception, which canbedetermined by turningthe equip-
ment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Re-orient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
WARNING! The use of shielded cables for connection of the monitor to
the graphics card is required to assure compliance with FCC regulations.
Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate this
equipment.
CanadianDepartmentof CommunicationsStatement
This digital apparatus does not exceed the Class B limits for radio noise
emissions from digital apparatus set out in the Radio Interference Regula-
tions of the Canadian Department of Communications.

AP8000 Hardware Reference Guide 7
I. Introduction
I. Introduction
You are reading theAP8000 Hardware Reference Guide. This hardware ref-
erence guide provides information and procedures on the various compo-
nents used in this server. Some components shown in this reference guide are
optionalandmaybe individually purchased tocompletetheserver.This guide
is intended for experienced users and integrators with hardware knowledge
of personal computers.You should also read all documentation and manuals
included with this server and with your separately purchased components.
There are only a few sections in this reference guide as follows:
I. Introduction
This section gives general information and features for this server.
II. Components
This is the main section which gives descriptions of each server component.
III. Getting Started
This section gives information on getting started with the server.
IV. Hardware Setup
This section gives information on setting up the server.
V.Appendix
This section gives you additional information to help plan your server.
Symbols
To complete certain tasks safely and completely, you should be aware of a
few symbols used throughout this guide.
WARNING: Information to prevent injury to yourself when trying to
complete a task.
CAUTION: Information to prevent damage to the components when
trying to complete a task.
IMPORTANT: Information that MUST be followed in order to com-
plete a task.
NOTE: Tips and information to aid in completing a task.
PHILIP (CROSS) SCREW DRIVER: Tools required to install or re-
move the components in this server.
STANDARD (FLAT) SCREW DRIVER: Tools required to install or
remove the components in this server.
STEP: Actions to complete a task
Sections
• 1-1. How this Manual is Organized

8AP8000 Hardware Reference Guide
I. Introduction
I. Introduction
• 1-2. Component Checklist
If assembling this server by yourself, it is important to prepare all the server
components before starting. This will save a great deal of time by not hav-
ing to hunt down components. The following checklist provides a guideline
as to the necessary components for a server.
Standard components
Motherboard: XG-DLS
Chassis: AS-50
Power Supply: ATX
Processor (CPU): Pentium®II XeonTM
Memory Modules: 8, 16, 32, 64, 128, 256, 512MB SDRAM
Hard Drive: Ultra2, Ultra-wide
Floppy Drive: 1.44MB
CD-ROM Drive: 40X
Expansion Cards: Ethernet, Graphics, Modem
SCSI Terminator: Terminator for 68-pin SCSI cables
User’s Manuals: CD-ROM, SCSI, Motherboard, Hardware
Reference Guide
Optional components
Ethernet Card: PCI-L101
RAID Controller: PCI-DA2100 (UW), PCI-DA2200 (U2),
DA-3000 (SCSI-SCSI U2)
Checklist

AP8000 Hardware Reference Guide 9
I. Introduction
Features
I. Introduction
• 1-3. Features
AP8000 is a corporate server configured on the XG-DLS smart mother-
board which uses the 440GX chipset from Intel and supports two Pentium®
III/II XeonTM processors and 100MHz front side bus in order to handle
even the most complicated server tasks.The following are highlights to this
server’s many features. For additional features and details, read the mother-
board User’s Manual included with this server package.
•Processor: Supports dual Intel®Pentium®III Xeon™ processors
(500MHz and faster) and Pentium ®II Xeon™ (400MHz to 450MHz)
processors for extreme processing speeds.
•Memory: Equipped with four DIMM sockets to support up to 2GB
SDRAM with ECC.
•AGP Slot: Supports Accelerated Graphics Port cards for high perfor-
mance, component level interconnect targeted at 3D graphical display
applications. Using AGP will also free up a PCI slot.
•Adaptec SCSI Chipset: Features Adaptec AIC-7896 dual-channel Ul-
tra2 SCSI chipset that supports any combination of 50-pin narrow or 68-
pin wide/ultra2 devices through the onboard 50-pin and 68-pin SCSI
connectors. Please refer to the SCSI cable limits in the appendix.
•Device Bays: Support one floppy, one CD-ROM, two additional fixed
devices, and eight hot-swap hard disk drives.
•SCSI Backplane: Ultra2 SCSI backplane with remote SCSI ID dip
switches and power to support up to 8 Ultra2 SCSI hard disk drives.
•Onboard LAN: Onboard Intel 10/100Base-TX Fast Ethernet.
•Onboard IDE: Up to 33MB/sec IDE transfer with UltraDMA/33.
•OnboardHardwareMonitor:Providesinformationforsystemandpro-
cessor voltages, fan status, temperature, chassis intrusion, and provides
automatic system restart.
•SNMPAgent and Intel LDSM: Provides server monitoring, manage-
ment, and control.
•RAID Controller: Supports PCI-DA2100 (UW), PCI-DA2200 (U2),
or DA3000 (SCSI-SCSI U2) to provide fault tolerant storage.

10 AP8000 Hardware Reference Guide
I. Introduction
Safeguards
I. Introduction
• 1-4. Safeguards
Observe the following safety instructions any time you are connecting or
disconnecting any devices.
Operation Safety
Tools Required
A Phillips (cross) screwdriver and a standard (flat) screwdriver are needed
to install or remove the components in this server.
IMPORTANT
• Any operation on this server must be conducted by certified
or experienced persons.
• Before operating your server, carefully read all the manuals
included with the server package.
• Before using the server, make sure all cables are correctly
connected and the power cables are not damaged. If anydam-
age is detected, contact your dealer as soon as possible.
• To avoid short circuits, keep paper clips, screws, and staples
away from connectors, slots, sockets and circuitry.
• Before opening the chassis panels, make sure all power cables
are unplugged.
• Avoid dust, humidity, and temperature extremes. Place the
server on a stable surface.
• If the power supply is broken, do not try to fix it by yourself.
Contact an authorized dealer.
• It is recommanded that you wear gloves when assembling or
dissembling the server to protect from cuts and scrapes.
• When the server is powered on, heat sinks and the surfaces
of certain IC devices may be hot. Do not touch them. Check
whether the fans are functioning properly.

AP8000 Hardware Reference Guide 11
I. Introduction
Electrical Safety
I. Introduction
• 1-5. Electrical Safety
IMPORTANT
• Before installing or removing signal cables, ensure that the
power cables for the system unit and all attached devices are
unplugged.
•To prevent electrical shock hazard, disconnect the power cable
from the electrical outlet before relocating the system.
• When adding or removing any additional devices to or from
the system, ensure that the power cables for those devices are
unplugged before the signal cables are connected. If possible,
disconnect all power cables from the existing system before
you add a device.
• Use one hand, when possible, to connect or disconnect signal
cables to prevent a possible shock from touching two sur-
faces with different electrical potentials.
Static-Sensitive Devices
Motherboards, adapters, and disk drives are sensitive to static
electricity discharge. These devices are wrapped in antistatic
bags to prevent this damage. Take the following precautions:
• If you have an antistatic wrist strap available, use it while
handling the device.
• Do not remove the device from the antistatic bag until you
are ready to install the device in the system unit.
• With the device still in its antistatic bag, touch it to a metal
frame of the system.
• Grasp cards and boards by the edges. Hold drives by the
frame. Avoid touching the solder joints or pins.
• If you need to lay the device down while it is out of the
antistatic bag, lay it on the antistatic bag. Before picking it
up again, touch the antistatic bag and the metal frame of the
system unit at the same time.
• Handle the devices carefully in order to prevent permanent
damage.
IMPORTANT
This product is equipped with a three-wire power cable and plug
for the user’s safety. Use the power cable in conjunction with a
properly grounded electrical outlet to avoid electrical shock.
CAUTION

12 AP8000 Hardware Reference Guide
(This page was intentionally left blank.)

AP8000 Hardware Reference Guide 13
II. System Components
II. Components
1. ATX Power Button
2. Fixed Device Bays
3. Metal Security Door
4. Left Panel Knob
5. Metal Door Lock
6. Hot Swap Tray
7. Chassis Stabilizer with Wheel
• 2-1. Server Front Side
The front side of the server is provided to show the front exterior
components of this server. The chassis is made of strong rust-resis-
tant metal and covered with a protective ivory surfacing.
Server Front Side
Front Side
1
2
4
5
7
3
6

14 AP8000 Hardware Reference Guide
II. System Components
II. Components
1. Power Supply
2. Power Supply LED
3. Power Supply Fan
4. AC Power In Connector
5. Voltage Input Switch
6. PS/2 Keyboard
7. PS/2 Mouse
8. USB Ports 1 and 2
9. Serial Port COM1
10. Parallel Port
11. Serial Port COM2
12. RJ45 Port (LAN)
13. RAID Controller (Optional)
• 2-2. Server Back Side
Server Back Side
Back Side
2
4
9
6
8
3
11
5
10
12
7
13
1

AP8000 Hardware Reference Guide 15
II. System Components
II. Components Back SideBack Side
II. Components
Server Left Side
1. Redundant Power Supply Frame
2. Fan Array Module
3. Chassis Intrusion Switch
4. I/O Device Panel
Left Side
• 2-3. Server Left Side
1
3
4
2
Control Board Fan
Release Handle
Fan Array Module

• 3-1. Starting the Server
Turn ON the server by turning the power knob clockwise and pushing in-
wards momentarily. The power button will snap back when released be-
cause ATX power systems have an electrical ON/OFF switch unlike AT
systems which require a permanent ON or OFF position. If the Power On
LED does not light, make sure the power cord is connected to the system
unit and to a working grounded outlet.
• 3-3. BIOS Setup
AP8000 Hardware Reference Guide16
III. Basic Operation
IMPORTANT
The power switch only turns off DC power (power supply output).
To turn offAC power (power supply input), you need to unplug the
electrical cords from the redundant power supply.
This server does not come with any pre-installed software. When booting
your server for the first time, make BIOS settings by following the mother-
board User’s Manual.
• 3-2. LED Indicators
The LED indicators are located on the top-left edge of the front panel. The
Power LED lights when the motherboard receives power from the power
supply. Activity LED lights when there is activity from IDE or SCSI de-
vices connected to the motherboard. Fan #1-5 lights if the corresponding
fan stops turning.
When installing Windows NT 4.0, use the Windows NT installation
disks. Installing from the CD will require you to pre-install SCSI driv-
ers by pressing F6 before setup begins. You may need device drivers
on a floppy disk in order to install devices during the Windows NT
4.0 setup. To use the onboard SCSI, you will need to copy Adaptec’s
SCSI driver (from the provided support CD) onto a floppy disk
(“Winnt”, “Disk1”, “Txtsetup.oem”).
NOTE
Starting/LEDs
III. Basic Operation
LED Indicators on Front Panel
Power LED
Activity LED
Fan #1 Error (when lit)
Fan #2 Error (when lit)
Fan #3 Error (when lit)
Fan #4 Error (when lit)
Fan #5 Error (when lit)

17
IV. Hardware Setup
IV. Hardware Setup
AP8000 Hardware Reference Guide
Fan
Replacement
Thefan arrary modulecanberemoved
bypullingout the handle and using the
handle to remove the entire module.
Thehandle must be intheout position
toinsertthefanmodule.Theindividual
fans are secured by two clips and two
hooks. To release these clips, use a
screw driver to push these clips in and
then slide the fan out.
Opening the Left
Panel
The CAM has a rotating knob with
its own keylock. Turn the knob
counterclockwise to release and
clockwise to secure. The keylock
can be used to keep the knob from
being turned by unauthorized
people.
• 4-1. Opening the Chassis
Opening the Chassis
NOTE: The fan array
module may be removed
firstfor easier motherboard instal-
lation or removal.
Chassis Panels
Thereare twoidentical sidepan-
els on the chassis, one on each
side. Each panel is secured by
two screws on the back of the
server (as circled) and also by a
CAM.

18
IV. Hardware Setup
IV. Hardware Setup
AP8000 Hardware Reference Guide
• 4-2. Motherboard
Motherboard
Spacers
Place four spacers in the ar-
eas circled on the chassis.
Spacer
Install the
Baseboard
A metal baseboard is required to
add stability to the motherboard.
A rubber pad is placed between
themetalboardandmotherboard
toprevent shorting.Align therub-
berpad over the metal baseboard
sothatthe holes match.Alignthe
XG-DLS motherboard over the
rubber pad and metal baseboard
so that the screws match up with
the motherboard’s screw holes.
Place and tighten three captive nuts in
the corner locations as circled.
Motherboard
Motherboard
Screws
Place eight screws in the areas
circled on the motherboard. The
four screws used with the moth-
erboard spacers are longer than
the others. (See page 20 for
samples.) Be careful not to over-
tightenthescrews.Doingsomay
damage your motherboard.

19
IV. Hardware Setup
IV. Hardware Setup
AP8000 Hardware Reference Guide
Motherboard
Chassis Intrusion
Connector Cable
68-pin SCSI Cable
CD-ROM Drive Cable
Floppy Disk Drive Cable
Power LED
Power SW
HDD LED
Device Cables
Several cables are used for connecting devices in this chassis. The following
picture points out the name of each cable and its suggested location. Plastic
keepers protect the cables from contacting with the fans and other devices. Make
sure that all cables are properly secured.
68-pin SCSI Cable
Floppy Disk
Drive Cable
CD-ROM Drive Cable
Cable Connections
The cables connect to the motherboard as shown.The motherboard includes onboard
SCSI with 68-pin and 50-pin SCSI connectors. RAID connections require an op-
tional RAID card.

20
IV. Hardware Setup
IV. Hardware Setup
AP8000 Hardware Reference Guide
This server supports two processors which requires one retention mecha-
nism for each processor. Before installing the CPU, secure the mother-
board on the rubber pad and metal baseboard. (See page 18.)
When only one processor is used, the other Slot 2 connector must be termi-
nated with the provided front side bus termination module.
• 4-3. Central Processing Unit (CPU)
CPU
Captive Nut
Long Screw (aligned with spacers)
Short Screw
Install Retention
Mechanisms
The retention mechanism parts
have a left and a right side. The
left side has a single dot and the
right side has two dots (when
holding the motherboard with the
ATX connectorstothe left).Place
the retention mechanisms’ holes
over the screws and the Slot2.
Screw four captive nuts onto the
inner screws (3 circled in the pic-
ture). Do not place the other cap-
tive nuts yet.
Two Dots
One Dot
Install Retention
Mechanism
Brace Bars
Place the retention mechanism
brace bar into the groove on the
top of the retention mechanism
as shown.
Retention Mechanism Brace Bar
