Asus Eee Pad Transformer TF101 User manual

Eee Pad User Manual
TF101/TF101G
E6640
There are three main types of airport security devices: X-ray machines (used
on items placed on conveyor belts), magnetic detectors (used on people
walking through security checks), and magnetic wands
(hand-held devices used on people or individual items). You can send your
Eee Pad through airport X-ray machines. But do not send your Eee Pad
through airport magnetic detectors or expose it to magnetic wands.
Airplane Precautions
Ask an airline personnel if you want to use your Eee Pad onboard an aircraft.
Most airlines have restrictions for using electronic devices. Most airlines allow
electronic use only between and not during takeos and landings.
Charging Your Batteries
If you intend to use battery power, be sure to fully charge your battery pack
before going on long trips. Remember that the power adapter charges the
battery pack as long as it is plugged into the computer and an AC power source.
Be aware that it takes much longer to charge the battery pack when the Eee Pad
is in use.
Remember to fully charge the battery (8 hours or more) before rst use and
whenever it is depleted to prolong battery life. The battery reaches its maximum
capacity after a few full charging and discharging cycles.

Contents
Package Contents .............................................................................................. 4
Your Eee Pad......................................................................................................... 5
Charging the Eee Pad ....................................................................................... 8
Your Eee Pad mobile docking (optional) ................................................... 9
Docking the Eee Pad.......................................................................................12
Charging the Eee Pad on the docking......................................................13
Basic ...................................................................................................................14
Unlock your Eee Pad......................................................................................14
Desktop .............................................................................................................14
ASUS Launcher................................................................................................15
Touch panel control.......................................................................................16
File Manager.....................................................................................................18
Market .............................................................................................................21
Settings................................................................................................................22
Music ...................................................................................................................23
Image ...................................................................................................................24
Gallery .............................................................................................................24
Camera .............................................................................................................27
Mail ...................................................................................................................28
Email .............................................................................................................28
Gmail .............................................................................................................30
Reading................................................................................................................31
MyLibrary...........................................................................................................31
Locating...............................................................................................................34
Places and Maps..............................................................................................34
Documenting ....................................................................................................35
Polaris® Office ..................................................................................................35
Sharing.................................................................................................................38
MyNet .............................................................................................................38
MyCloud.............................................................................................................40
ASUS Eee Pad Manual
2

ASUS Eee Pad Manual
3
Eee Pad PC Suite (on PC)................................................................................47
MyDesktop PC Server....................................................................................47
ASUS Webstorage...........................................................................................47
ASUS Sync .........................................................................................................48
Declarations and Safety Statements.........................................................50
Federal Communications Commission Statement.............................50
RF Exposure Information (SAR)..................................................................50
IC Regulations..................................................................................................51
IC Radiation Exposure Statement.............................................................51
CE Mark Warning.............................................................................................52
Power Safety Requirement .........................................................................52
ASUS Recycling/Takeback Services..........................................................52
Copyright Information ...................................................................................54
Limitation of Liability......................................................................................54

ASUS Eee Pad Manual
4
Package Contents
• If any of the items is damaged or missing, contact your retailer.
• The power plug that comes with your Eee Pad may vary depending
on your territory to t the wall outlet.
Eee Pad USB Charger
Power Plug Docking connector to USB cable
User Manual
User Manual Warranty Card

ASUS Eee Pad Manual
5
Your Eee Pad
8
1
3
2
4
7
10
5
11
6
9

1
Power button
The power button turns your Eee Pad on/o. Hold the power
button for 2 seconds to power on your Eee Pad. When the Eee Pad
is powered on, press the power button to put the Eee Pad into sleep
mode or wake it up from sleep mode. Hold the power button for 0.5
second to display the shutdown dialog box. If the system becomes
unresponsive, press and hold the power switch to force the Eee Pad
to power o.
Forcing the system to power o may result in data loss. Please
inspect your data to ensure there is no data loss. It is strongly
recommended that important data be backed up regularly.
2
Volume Key
Press this button to increase or decrease the system volume.
3
SIM Card slot (on TF101G)
The SIM card compartment allows insertion of a mobile SIM card for
3G functions.
Use a straightened paper clip to press the opening beside the
SIM card slot to eject the SIM card tray.
4
Built-in front Camera
Use the built-in camera for picture taking, video recording, video
conferencing, and other interactive applications.
5
Touch Screen Panel
The touch screen panel allows you to operate your Eee Pad using
multi-touch up to ten ngers.
6Docking Connector
• Insert the power adapter into this port to supply power to
your Eee Pad and charge the internal battery pack. To prevent
damage to your Eee Pad and battery pack, always use the
bundled power adapter.
• Connect the docking connector to USB cable to the Eee Pad and
another system (notebook or desktop) for data transmission.
• Dock the Eee Pad to the mobile docking for extended functions,
including keyboard, touchpad and USB interface.
ASUS Eee Pad Manual
6

ASUS Eee Pad Manual
7
7
Built-in rear Camera
Use the built-in camera for picture taking, video recording, and other
interactive applications.
8
Headphone Output/Microphone Input Combo Jack
The stereo combo jack (3.5mm) connects the Eee Pad’s audio
out signal to amplied speakers or headphones. Using this jack
automatically disables the built-in speaker.
For microphone input function, the jack supports the headset
microphone ONLY.
9Microphone (Built-in)
The built-in mono microphone can be used for video conferencing,
voice narrations, or simple audio recordings.
10
mini HDMI port
Insert a mini HDMI cable into this port to connect to a high-denition
multimedia interface (HDMI) device.
11
Micro SD Card Slot
Insert Micro SD card into this slot

Charging the Eee Pad
41
2
3
• Use only the power adapter that comes with your device. Using a
dierent power adapter may damage your device.
• Using the provided power adapter and USB cord to connect your Eee
Pad to a power outlet is the best way to charge the Eee Pad.
• The input voltage range between the wall outlet and this adapter is
AC 100V–240V, and the output voltage of this adapter is DC 15V, 1.2A.
• To prolong battery life, fully charge the battery for up to 8 hours
when using the Eee Pad for the rst time and whenever the battery
power is fully depleted.
• TF101 can be charged via the USB port on the computer only when
it is in sleep mode (screen o) or powered o.
• Charging through the USB port may take longer time to complete.
• If the computer does not provide enough power for charging Eee
Pad, use the wall outlet instead.
• TF101G CANNOT be charged via the USB port on the computer.
ASUS Eee Pad Manual
8

ASUS Eee Pad Manual
9
Your Eee Pad mobile docking (optional)
The Eee Pad mobile docking is purchased separately.
1 3
4 3
2
Home PgDp
PgUp
End
Enter
Backspace
Tab
Caps Lock
Shift Shift
Ctrl Ctrl
Alt
Fn
Fn
5
76

1Docking Connector
• Insert the power adapter into this port to supply power to
your Eee Pad and charge the internal battery pack. To prevent
damage to your Eee Pad and battery pack, always use the
bundled power adapter.
• Connect the docking connector to USB cable to the Eee Pad and
another system (notebook or desktop) for data transmission.
2Battery Charge Indicator (dual-color)
With AC adapter:
Green ON: Battery power is between 95% and 100%.
Orange ON: Battery power is less than 95%.
Orange Blinking: Battery power is less than 10%.
Orange Blinking Quickly: Battery power is less than 3%.
Without AC adapter and with Eee Pad:
Orange Blinking Quickly: Battery power is less than 3%.
Ensure to connect the power charger when the indicator starts
blinking.
3USB Port (2.0)
The USB (Universal Serial Bus) port is compatible with USB 2.0 or USB
1.1 devices such as keyboards, pointing devices, ash disk drive and
hard disk drives.
4Memory Card Slot
This Eee Pad mobile docking has a built-in high-speed memory
card reader that can conveniently read from and write to many ash
memory cards.
5
Mobile docking latch
Move the mobile docking latch to the left to release the Eee Pad from
the mobile docking.
ASUS Eee Pad Manual
10

ASUS Eee Pad Manual
11
6Keyboard
The keyboard provides comfortable travel (depth at which the keys
can be depressed) and palm rest for both hands.
The keyboard diers for each territory.
7Touchpad and Buttons
The touchpad with its buttons is a pointing device that provides the
same functions as a desktop mouse.
Special Keyboard Functions
The following denes the hot keys on the Eee Pad mobile docking’s keyboard.
Some commands may have standalone function and some must combine
with the function key <Fn>.
The Hot Key locations on the function keys may vary depending on
model but the functions should remain the same. Follow the icons
instead of the function keys.
Home PgDp
PgUp
End
Fn
Returns to the previous page.
Home PgDp
PgUp
End
Fn
Toggles the internal wireless LAN ON or OFF.
Home PgDp
PgUp
End
Fn
Toggles the internal Bluetooth ON or OFF.
Home PgDp
PgUp
End
Fn
Toggles the touchpad ON or OFF.
Home PgDp
PgUp
End
Fn
Decreases the display brightness
Home PgDp
PgUp
End
Fn
Increases the display brightness
Home PgDp
PgUp
End
Fn
Toggles the ambient light sensor ON or OFF

Home PgDp
PgUp
End
Fn
Captures the desktop image.
Home PgDp
PgUp
End
Fn
Initiates the web browser.
Home PgDp
PgUp
End
Fn
Opens the Settings screen.
Home PgDp
PgUp
End
Fn
Returns to the previous track when playing music.
Home PgDp
PgUp
End
Fn
Starts playing music from your playlist. Resumes or pauses the
current music playing.
Home PgDp
PgUp
End
Fn
Fast forward or skip to the next track during the music playing.
Home PgDp
PgUp
End
Fn
Mutes the speaker.
Home PgDp
PgUp
End
Fn
Decreases the speaker volume.
Home PgDp
PgUp
End
Fn
Increases the speaker volume.
Home PgDp
PgUp
End
Fn
Locks the Eee Pad and put it into sleep mode.
Home PgDp
PgUp
End
Fn
Home PgDp
PgUp
End
Fn
Press <Fn> and arrow keys to scroll up and down or scroll to the start and
end in documents.
ASUS Eee Pad Manual
12

ASUS Eee Pad Manual
13
Docking the Eee Pad
1
2
2
3
1. Align the Eee Pad with the mobile docking.
2. Firmly insert the Eee Pad into the socket until the it snaps in place and
the Eee Pad is properly seated.
3. Ensure that the latch completely moves to the right.
When your Eee Pad is attached to the mobile docking, never pick up
the Eee Pad alone. Always pickup the entire assembly by the bottom
of the mobile docking.

Undocking the Eee Pad
3
2
2
1
1. Use one hand to move the latch to the left to release the Eee Pad and
stabilize the mobile docking.
2. Use the other hand to remove the Eee Pad from the mobile docking.
ASUS Eee Pad Manual
14

ASUS Eee Pad Manual
15
Charging the Eee Pad on the docking
• Use only the power adapter that comes with your device. Using a
dierent power adapter may damage your device.
• The input voltage range between the wall outlet and this adapter is
AC 100V–240V, and the output voltage of this adapter is DC 15V, 1.2A.
• To prolong battery life, fully charge the battery for up to 8 hours
when using the Eee Pad for the rst time and whenever the battery
power is fully depleted.
• The Eee Pad cannot be charged via USB when it is connected
to the mobile docking.
41
2
3

The desktop might update and change with Android OS.
ASUS Eee Pad Manual
16
Basic
Unlock your Eee Pad
Tap and drag the lock out of the circle to unlock your Eee Pad.
Open Google Text search
Open Google Voice search
Return to the previous screen
Return to Home (the desktop)
Display the recent apps
Customize desktop
Open Apps menu
Notication area & Settings
Shortcuts
Desktop

ASUS Eee Pad Manual
17
Display the local weather information. Tap to
customize the weather widget settings, including
the location, update frequency.
Display local date
Display your email inbox. Tap to congure
the email account for the rst time, and tap
to read the unread mail in the email inbox
folder.
ASUS Launcher

ASUS Eee Pad Manual
18
Touch panel control
Single tapping
Single-tapping on the touch panel allows you to select a desired item or
activate an application.
Double tapping
Double-tapping in the File Manager allows you to open the selected le.
Long pressing
• Long-pressing an application allows you to drag and drop the application
or the application shortcut to another desktop.
• Long-pressing a desired le in the File Manager allows you to Copy, Cut,
Rename or Delete the selected le.
You can use the pencil tool on the top right corner to Copy, Cut, or Delete
multiple les at one time.
Pinching
Use two ngers to pinch in the Gallery whenever you would like to zoom in
or zoom out.
Flipping
Use one nger to ip back and forth dierent desktops or dierent images in
the Gallery.
Inputting, inserting, selecting, and copying text
The keyboard appears when you use word processor to edit documents or
enter the web address on the web browser address bar.

ASUS Eee Pad Manual
19
Tap the text you just input and you will see the current insertion point. Move
the point to the place you would like to insert an alphabet or a word.
Double tap or hold the text to cut or copy the selected text. You can move the
select tab to expand or reduce the range of the selected text.
Tap or hold the desired text on the web page and a tool bar appears on the
top. You can copy, share, select, nd, or search on the web.

ASUS Eee Pad Manual
20
File Manager
File manager allows you to locate and manage your data either on the
internal storage device or the connected external storage devices easily.
To access the internal storage
1. Tap Apps menu on the top right corner.
2. Tap File Manager.
3. The internal storage location (mnt/sdcard/) is displayed.
