Aaeon RTC-1000A1 User manual

Rugged Tablet Computer
R T C - 1 0 0 0 A 1
RTC-1000A1
Intel®AtomTM N270
1.6 GHz Processor
Rugged Tablet Computer
with 10.2”WSVGA Color TFT LCD
1 COM, 2 USB2.0, 1 Mini USB
RTC-1000A1 Manual 2nd Ed
May 14, 2014

Rugged Tablet Computer
R T C - 1 0 0 0 A 1
i
Copyright Notice
This document is copyrighted, 2014. All rights are reserved. The
original manufacturer reserves the right to make improvements to the
products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in this
manual is intended to be accurate and reliable. However, the original
manufacturer assumes no responsibility for its use, or for any in-
fringements upon the rights of third parties that may result from its
use.
The material in this document is for product information only and is
subject to change without notice. While reasonable efforts have been
made in the preparation of this document to assure its accuracy,
AAEON assumes no liabilities resulting from errors or omissions in
this document, or from the use of the information contained herein.
AAEON reserves the right to make changes in the product design
without notice to its users.

Rugged Tablet Computer
R T C - 1 0 0 0 A 1
ii
Acknowledgments
All other products’name or trademarks are properties of their
respective owners.
Intel®, and AtomTM are trademarks of Intel®Corporation.
Microsoft Windows®is a registered trademark of Microsoft
Corp.
All other product names or trademarks are properties of their
respective owners.

Rugged Tablet Computer
R T C - 1 0 0 0 A 1
iii
Packing List
Before you begin operating your PC, please make sure that the
following materials are enclosed:
1 RTC-1000A1 Rugged Tablet Computer with a Hard
Disk Drive & 1GB/ 2GB SODIMM Memory Card
1 AC Adapter with Power Cord
1 Standard Battery
1 Hand Strap
1 DVD-ROM for system driver & manual
(in PDF format)
If any of these items should be missing or damaged, please contact
your distributor or sales representative immediately.

Rugged Tablet Computer
R T C - 1 0 0 0 A 1
iv
Options
The following items are normally optional, but some vendors may
include them in the standard package. Some items may not be
available in some countries, or some vendors may choose not to carry
all the items.
WLAN/BT module
GPS module
3G Modem module
Caution:when purchasing any of the accessories listed above,
purchase only those accessories that are approved for use with your
Rugged Tablet Computer. The above accessories are proprietary
items. Our system vendor can obtain these approved accessories.
If you use items that are not approved for use with this Rugged Tablet
Computer, you may cause your Rugged Tablet Computer to
malfunction, or to emit or receive electro-magnetic radiation in excess
of local regulations. For non-proprietary accessories such as PC
cards or printers, ensure that the accessory functions properly in your
Rugged Tablet Computer before making the purchase. Your system
vendor may be able to recommend reliable brands and models.

Rugged Tablet Computer
R T C - 1 0 0 0 A 1
v
Safety & Maintenance
You can use your Rugged Tablet Computer under a wide range of
environmental conditions. However, to ensure long use and
continued high performance, consider the following factors when
setting up your Rugged Tablet Computer (RTC):
Follow all warnings and instructions noted in this documentation
and in the Windows Help program.
The first time you use your RTC, we recommend that you carefully
read the Making Connections section of this manual and initialize
the battery to ensure optimum battery performance.
Unplug the RTC from the power outlet before cleaning. Use a damp
cloth for cleaning. Do not use aerosols, solvents, or strong
detergents.
Slots and openings in the system cabinet are for ventilation
purposes. Do not block or cover these openings or the system could
overheat. Do not use or store the RTC near a source of heat or dust.
On the base or rear panel of this RTC, there is a label with
information on the power requirements of this system. These
requirements must be followed. If you are unsure of your local
power supply, consult your dealer or local Power Company.
Do not step on or place anything on the power cord.
If you use the RTC with an extension cord, ensure that the total
ampere ratings of all the devices sharing the extension do not
exceed the rating of the extension cord or the rating of the wall

Rugged Tablet Computer
R T C - 1 0 0 0 A 1
vi
outlet.
Never push foreign objects into the RTC through any of the slots
or openings. Dangerous voltages are present, which could
cause electric shock or fire, or damage sensitive components.
FCC
This device complies with Part 15 FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference
received including interference that may cause
undesired operation.
Caution:
There is a danger of explosion if the battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by the
manufacturer. Dispose of used batteries according to the
manufacturer’s instructions and your local government’s recycling or
disposal directives.
Attention:
Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte.
Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le
constructeur. Recycler les batteries usées en accord avec les instructions du
fabricant et les directives gouvernementales de recyclage.

Rugged Tablet Computer
R T C - 1 0 0 0 A 1
vii
Below Table for China RoHS Requirements
产品中有毒有害物质或元素名称及含量
AAEON Panel PC/ Workstation
部件名称
有毒有害物质或元素
铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(Cr(VI))
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
印刷电路板
及其电子组件
×
○
○
○
○
○
外部信号
连接器及线材
×
○
○
○
○
○
外壳
×
○
○
○
○
○
中央处理器
与内存
×
○
○
○
○
○
硬盘
×
○
○
○
○
○
液晶模块
×
○
○
○
○
○
光驱
×
○
○
○
○
○
触控模块
×
○
○
○
○
○
电源
×
○
○
○
○
○
O：表示该有毒有害物质在该部件所有均质材料中的含量均在
SJ/T 11363-2006 标准规定的限量要求以下。
X：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出
SJ/T 11363-2006 标准规定的限量要求。
备注：
一、此产品所标示之环保使用期限，系指在一般正常使用状况下。
二、上述部件物质中央处理器、内存、硬盘、光驱、触控模块为选购品。

Rugged Tablet Computer
R T C - 1 0 0 0 A 1
viii
Contents
Chapter 1 Introduction
1.1 Getting Started.......................................................... 1-2
1.2 Features .................................................................... 1-3
1.3 Where to Look For Information .................................1-4
1.4 Quick Start.................................................................1-5
1.5 Loading Windows...................................................... 1-6
1.6 Adjusting the Volume ................................................1-7
1.7 Adjusting the Brightness ...........................................1-8
1.8 Turning off your RTC.................................................1-9
Chapter 2 Getting Started
2.1 Appearance...............................................................2-3
2.2 Power Indicators........................................................ 2-5
2.3 Front View Buttons.................................................... 2-6
2.4 Function Keys............................................................2-8
2.5 Quick Start Button..................................................... 2-9
2.6 Connecting the Printer............................................... 2-10
2.7 The PCMCIA Card Slot.............................................2-10
2.8 CompactFlash (CF) Card Slot...................................2-11
2.9 Memory .....................................................................2-11
2.10 Communication Components.................................. 2-14
Chapter 3 Making Connections
3.1 Right Side Connectors .............................................. 3-2

Rugged Tablet Computer
R T C - 1 0 0 0 A 1
ix
3.2 Top Side Connectors.................................................3-4
Chapter 4 Power Management
4.1 Power Management.................................................. 4-2
4.2 When to Replace the Battery.................................... 4-4
4.3 Heat Considerations.................................................. 4-4
Appendix A Statements
A.1 Statements.............................................................A-2
A.2 European Notice ....................................................A-5
A.3 Safety CAUTION....................................................A-6
A.4 Battery Disposal.....................................................A-7
A.5 CAUTION for Adapter............................................A-7
A.6 Battery CAUTION ..................................................A-8

Rugged Tablet Computer
R T C - 1 0 0 0 A 1
Chapter 1 Introduction 1- 1
Introduction
Chapter
1

Rugged Tablet Computer
R T C - 1 0 0 0 A 1
Chapter 1 Introduction 1- 2
1.1 Getting Started
Congratulations on your purchase of a Rugged Tablet Computer
(RTC). The RTC is a fully functional PC with built-in LAN, and
wireless connectivity. With your RTC you will be able to organize
and access important business and personal information. In
addition, you will be able to send and receive e-mail and access the
Internet.
This Manual contains all the information you need to set up and use
your RTC. It describes all the features of the RTC in an
easy-to-read yet thorough manner.

Rugged Tablet Computer
R T C - 1 0 0 0 A 1
Chapter 1 Introduction 1-3
1.2 Features
Software Included
Widows®Embedded Standard 2009 Edition which includes:
• Microsoft®Internet Explorer
• Microsoft®Outlook Express
• Microsoft®Windows Media Player
High performance Processors
Ultra Low Voltage Mobile Intel®Atom™Processor 1.6GHz CPU
High Capacity Hard Disk Drive
The Rugged Tablet Computer has a high capacity hard disk drive,
to store your favorite programs and large multimedia files.
Built-in Wireless LAN, Modem and LAN Capability
A built-in 802.11b/g, 56k modem and 10/100/1000 Mbps Ethernet
port allows you to access the Internet or a Local Area Network
(LAN).

Rugged Tablet Computer
R T C - 1 0 0 0 A 1
Chapter 1 Introduction 1- 4
1.3 Where to Look For Information
About Your RTC
This User’s Manual describes the key elements of your RTC. New
users can find a simple step-by-step orientation in the Quick Start
section of this Chapter.
About Windows
Windows Online Help, found on the Start menu, offers extensive
Windows assistance. Welcome to Windows offers an online
orientation for new Windows users. Find it in:
Start/Programs/Accessories/System Tools.

Rugged Tablet Computer
R T C - 1 0 0 0 A 1
Chapter 1 Introduction 1-5
1.4 Quick Start
Turning on the Rugged Tablet Computer for the First Time
1. Connect the AC adapter power cord to the AC adapter.
2. Connect the AC adapter to the DC power port on the bottom side
of your RTC.
3. Connect the AC adapter power cord to an AC outlet.
4. Press the power button to turn on the power.
Note: The battery is not fully charged. Allow your battery to fully charge
before using it (i.e., before disconnecting AC power). Calibrating the battery
before use is also highly recommended. Refer to Chapter of Power
Management for further information.
4

Rugged Tablet Computer
R T C - 1 0 0 0 A 1
Chapter 1 Introduction 1- 6
1.5 Loading Windows
The following section is for the Windows operating system only. If
you are installing a different operating system, please check with
your vendor for installation details.
Your RTC will begin loading Windows once you turn on the power.
Wait a few seconds for Windows setup to load.
The Welcome to Windows screen will appear. You may disable
this feature by clearing the check box labeled show this screen
each time Windows starts.
Some software comes preloaded with Windows. New users can
familiarize themselves with this software by selecting Programs
from the start menu, then clicking on programs to run them.

Rugged Tablet Computer
R T C - 1 0 0 0 A 1
Chapter 1 Introduction 1-7
1.6 Adjusting the Volume
You can adjust the volume with hot key:
Fn + Arrow Up: volume up
Fn + Arrow Down: volume down
Alternatively, you can adjust the volume with the Windows volume
control applet located on the taskbar.

Rugged Tablet Computer
R T C - 1 0 0 0 A 1
Chapter 1 Introduction 1- 8
1.7 Adjusting the Brightness
Use the following hot key combinations to adjust the LCD panel
brightness:
Fn + Arrow Left: decreases the brightness
Fn + Arrow Right: increases the brightness

Rugged Tablet Computer
R T C - 1 0 0 0 A 1
Chapter 1 Introduction 1-9
1.8 Turning off your RTC
Turning off the RTC properly is important to maintaining the RTC.
1. On the Start menu, click Shut Down.
2. Click the radio button next to Shut Down in the Shut
Down Windows screen, and then click OK.
If you are going to be away from the RTC for a short period, there
are ways of conserving power without shutting down the system.
Warning: Shutting off the RTC improperly
may result in data loss.

Rugged Tablet Computer
R T C - 1 0 0 0 A 1
Chapter 2 Getting Started 2-1
Getting Started
Chapter
2
