ASUSTeK COMPUTER H110T-CM-A R2.0 User manual

Industrial Motherboard
H110T-CM-A R2.0

ii
E19481
First Edition
November 2021
Copyright © 2021 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means, except documentation kept by the purchaser for backup purposes, without the express written
permission of ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless
such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identication or explanation and to the
owners’ benet, without intent to infringe.

iii
Contents
Chapter 1 Product overview
1.1 Package contents......................................................................... 1-1
1.2 Features ........................................................................................ 1-1
1.3 Specications............................................................................... 1-2
Chapter 2 Motherboard information
2.1 Before you proceed ..................................................................... 2-1
2.2 Motherboard layout...................................................................... 2-2
2.3 Central Processing Unit (CPU) ................................................... 2-4
2.3.1 Installing the CPU ........................................................... 2-5
2.3.2 CPU heatsink and fan assembly installation................... 2-7
2.4 System memory ........................................................................... 2-9
2.5 Jumpers ...................................................................................... 2-10
2.6 Connectors ................................................................................. 2-12
2.6.1 Rear panel connectors.................................................. 2-12
2.6.2 Internal connectors ....................................................... 2-14
Chapter 3 BIOS setup
3.1 BIOS setup program .................................................................... 3-1
3.1.1 BIOS menu screen.......................................................... 3-2
3.2 Main menu .................................................................................... 3-2
3.2.1 System Date [Day MM/DD/YYYY] .................................. 3-2
3.2.2 System Time [HH:MM:SS] .............................................. 3-2
3.3 Advanced menu ........................................................................... 3-3
3.3.1 Platform Misc Conguration............................................ 3-3
3.3.2 CPU Conguration .......................................................... 3-4
3.3.3 System Agent (SA) Conguration ................................... 3-6
3.3.4 PCH Conguration .......................................................... 3-7
3.3.5 PCH Storage Conguration ............................................ 3-7
3.3.6 PCH-FW Conguration ................................................... 3-8
3.3.7 LVDS Conguration ........................................................ 3-9
3.3.8 Onboard Devices Conguration.................................... 3-11
3.3.9 APM Conguration........................................................ 3-13
3.3.10 Network Stack Conguration ........................................ 3-13
3.3.11 HDD/SSD SMART Information ..................................... 3-14
3.3.12 USB Conguration ........................................................ 3-14

iv
3.4 Monitor ........................................................................................ 3-16
3.5 Boot menu .................................................................................. 3-19
3.6.1 ASUS EZ Flash 3 Utility ................................................ 3-24
3.6.2 ASUS SPD Information................................................. 3-24
3.7 Exit menu.................................................................................... 3-25
Appendix
Notices.......................................................................................................A-1
Service and Support.................................................................................A-5

1-1
Chapter 1: General information
1.1 Package contents
Check your industrial motherboard package for the following items.
1 x ASUS H110T-CM-A R2.0 Industrial Motherboard
1 x SATA 6.0 Gb/s cable
2 x M.2 screw packages
2 x I/O shields (1 x mini-ITX, 1 x thin mini-ITX)
NOTE: If any of the above items is damaged or missing, contact your
distributor or sales representative immediately.
1.2 Features
• Intel®socket 1151 for 7th/6th Gen Intel®Core™ i7/ i5/ i3, Pentium®and Celeron®
Processors
• Two Dual Channel DDR4 2133/1866 MHz Non-ECC U-DIMMs up to 32GB
• 2 x SATA 6.0 Gb/s, 4 x USB 3.0 ports, 3 x USB 2.0 headers, 1 COM port
header
• 1 x M.2 Socket 3 with M key, type 2242/2260 storage devices (SATA & PCIE
mode); 1 x M.2 Socket 1 with E key, type 2230 for Wi-Fi/BT devices (PCIE/
USB mode)
• Multi-display: 1 x DisplayPort, 1 x HDMI®, 1 x LVDS
Chapter 1
Product overview

H110T-CM-A R2.0
1-2
1.3 Specications
(continued on the next page)
CPU
Intel®socket 1151 for 7th / 6th Gen Intel®Core™ i7/ i5/ i3,
Pentium®, and Celeron®Processors
Supports Intel® 14nm CPU
Supports up to 65W
Chipset Intel®H110 Chipset
Memory 2 x SODIMM, max.32GB, DDR4 2133/1866 MHz, un-buffered
Memory
Graphics
Integrated graphics processor - Intel®HD Graphics support
Multi-VGA output support: DisplayPort/HDMI®/LVDS ports,
supports up to two displays simultaneously
- Supports DisplayPort output with a maximum resolution of
4096 x 2160 @ 60Hz
-Supports HDMI®output with a maximum resolution of 4096 x
2160 @ 24Hz / 2560 x 1600 @ 60Hz
-Supports LVDS output with a maximum resolution of 1920
x1200 @ 60Hz
Expansion slots
1 x M.2 Socket 3 with M key, type 2242/2260 storage devices
(SATA & PCIE mode)
1 x M.2 Socket 1 with E key, type 2230 for Wi-Fi/BT devices
(PCIE/USB mode)
Storage 2 x SATA Gen 6.0 Gb/s ports
LAN 1 x Intel®i219V (supports WOL/PXE)
1 x Realtek RTL8111H
Audio Realtek ALC897-VA2 High Denition Audio
Line-Out, Mic in
Rear I/O ports
1 x DC Power Input jack
4 x USB 3.0 ports
1 x HDMI®port
1 x DisplayPort
2 x LAN (RJ45) ports
2 x Audio jacks (1 x LINE Out, 1 x MIC In)
Internal I/O
connectors
1 x COM Port header (RS232)
3 x USB 2.0 headers support additional 5 USB 2.0 ports
1 x CPU Fan header (PWM mode)
1 x Chassis Fan header (PWM mode & DC mode)
1 x Chassis Intrusion header
1 x Front Panel Audio header (AAFP)
1 x System Panel header (10-1 pin)
1 x Clear CMOS header
1 x Speaker header
1 x Internal Stereo Speaker header

1-3
Chapter 1: General information
Internal I/O
connectors
1 x DMIC header
1 x RTC Battery header
1 x LVDS Signal header
1 x LCD Panel Monitor Switch header
1 x LVDS Panel VCC power selection jumper
1 x LVDS Backlight Panel selection header
1 x Display Panel Backlight Power selection jumper
1 x LPC Debug header
1 x DC Power connector
1 x SPI TPM header
Manageability WfM 2.0
Watch dog timer Yes
Power
requirement
Power type: DC IN mode
Voltage (only one of the following type can be used at one time):
- DC IN 12V/19V
- 2-pin internal DC mode 12V / 19V
Operation
Temperature 0~50°C
Non-Operation
Temperature -40~85°C
Relative Humidity 5%~95%
OS support
Windows®7 (32/64bit)
Windows®8.1
Windows®10 (64bit)
Ubuntu
RedHat Enterprise
Fedora Workstation
OpenSUSE
Certication CE, FCC
Form Factor Thin Mini-ITX, 6.7 in x 6.7 in (17cm x 17 cm)
NOTE: Specications are subject to change without notice.

H110T-CM-A R2.0
1-4

2-1
Chapter 2: Motherboard information
Chapter 2
Motherboard information
2.1 Before you proceed
Take note of the following precautions before you install motherboard components
or change any motherboard settings.
CAUTION!
• Unplug the power cord from the wall socket before touching any
component.
• Before handling components, use a grounded wrist strap or touch a safely
grounded object or a metal object, such as the power supply case, to avoid
damaging them due to static electricity.
• Hold components by the edges to avoid touching the ICs on them.
• Whenever you uninstall any component, place it on a grounded antistatic
pad or in the bag that came with the component.
• Before you install or remove any component, always remove the AC power
by unplugging the power cord from the power outlet. Failure to do so may
cause severe damage to the motherboard, peripherals, or components.

H110T-CM-A R2.0
2-2
H110T-CM-A R2.0
F_PANEL
SPEAKER
COM
SATA_PWRCON
AAFP
LINE_OUT
LAN1
LAN2
DP
HDMI
U31G1_34
U31G1_12
DC_PWR
MIC IN
CLRTC
CPU_FAN
CHA_FAN
ALC
897
17cm(6.7in)
17cm(6.7in)
PANEL_SW
LCD_BLKT_PANEL
LVDS
SATA6G_1 SATA6G_2
2260
2242
DMIC LPC_DEBUG
USB9
VCC_PWR_SEL
CHASSIS
BLKT_PWR_SEL
SPK_OUT
ATX19V
DDR4 DIMM_B1 (64bit, 260-pin module)
M.2(WIFI)
DDR4 DIMM_A1 (64bit, 260-pin module)
USB56 USB78
BATT_CON
ASM
1442K
LGA1151
Intel®
H110
Intel®
I219V
RTL
8111H
Super
I/O
TPM
128Mb
BIOS
M.2(SOCKET3)
832 5 61
3
12
11
15
3
14
13
1819 1721 20
10927
16
23
22
25
24
4
2.2 Motherboard layout
Place this side
towards the rear
of the chassis
NOTE: Place four screws into the holes indicated by circles to secure the
motherboard to the chassis.
CAUTION! Do not overtighten the screws! Doing so can damage the
motherboard.
NOTE: The audio codec may vary between motherboards, please consult
your sales window for the motherboards’ exact codec type.

2-3
Chapter 2: Motherboard information
Connectors/Jumpers/Slots Page
1. ATX power connector (2-pin ATX19V) 2-14
2. CPU and Chassis Fan headers (4-pin CPU_FAN, 4-pin CHA_FAN) 2-14
3. USB 2.0 headers (10-1pin USB56, USB78, 5-1 pin USB9) 2-15
4. SATA 6.0 Gb/s ports (7-pin SATA6G_1-2) 2-15
5. SATA Power connector (15-pin SATA_PWR) 2-16
6. DDR4 SO-DIMM slots 2-9
7. COM Port header (10-1 pin COM) 2-16
8. Panel switch (2-pin PANEL_SW) 2-17
9. System Panel header (10-1 pin F_PANEL) 2-18
10. Speaker header (4 pin SPEAKER) 2-17
11. LVDS Panel VCC Power selection jumper (6-pin VCC_PWR_SEL) 2-10
12. LVDS connector (40-pin LVDS) 2-19
13. LVDS Backlight Panel selection header (8-pin LCD_BLKT_PANEL) 2-19
14. Display Panel Backlight Power selection jumper (3-pin BLKT_PWR_SEL) 2-10
15. Intel® LGA1151 CPU socket 2-4
16. Chassis Intrusion header (4-1 pin CHASSIS) 2-20
17. Internal Stereo Speaker header (4-pin SPK_OUT) 2-20
18. TPM header (14-1 pin TPM) 2-21
19. LPC Debug header (10-1 pin LPC_DEBUG) 2-21
20. Digital Microphone header (5-1 pin DMIC) 2-22
21. Front Panel Audio header (10-1 pin AAFP) 2-22
22. Clear RTC RAM (2-pin CLRTC) 2-11
23. RTC Battery header (2-pin BATT_CON) 2-23
24. M.2 Wi-Fi 2-23
25. M.2 slot (SOCKET 3) 2-24

H110T-CM-A R2.0
2-4
IMPORTANT: Unplug all power cables before installing the CPU.
CAUTION!
• Upon purchase of the motherboard, ensure that the PnP cap is on
the socket and the socket contacts are not bent. Contact your retailer
immediately if the PnP cap is missing, or if you see any damage to the
PnP cap/socket contacts/motherboard components. The manufacturer will
shoulder the cost of repair only if the damage is shipment/transit-related.
• Keep the cap after installing the motherboard. The manufacturer will
process Return Merchandise Authorization (RMA) requests only if the
motherboard comes with the cap on the LGA1151 socket.
• The product warranty does not cover damage to the socket contacts
resulting from incorrect CPU installation/removal, or misplacement/loss/
incorrect removal of the PnP cap.
2.3 Central Processing Unit (CPU)
The motherboard comes with a surface mount LGA1151 socket designed for the
Intel®7th/6th Generation Core™ i7 / Core™ i5 / Core™ i3, Pentium®, and Celeron®
Processors.
LGA1151

2-5
Chapter 2: Motherboard information
2.3.1 Installing the CPU
1
A
B
2 3
CAUTION! LGA1156 CPU is not compatible with the LGA1151 socket. DO
NOT install an LGA1156 CPU on the LGA1151 socket.

H110T-CM-A R2.0
2-6
A
B
C
4
5

2-7
Chapter 2: Motherboard information
2.3.2 CPU heatsink and fan assembly installation
CAUTION! Apply the Thermal
Interface Material to the CPU
heatsink and CPU before you
install the heatsink and fan if
necessary.
To install the CPU heatsink and fan assembly
B
A
A
B
1
2
3 4

H110T-CM-A R2.0
2-8
A
B
B
A
To uninstall the CPU heatsink and fan assembly
2
1

2-9
Chapter 2: Motherboard information
2.4 System memory
This motherboard comes with two Double Data Rate 4 (DDR4) Small Outline Dual
Inline Memory Module (SO-DIMM) sockets. The gure below illustrates the location
of the DDR4 SO-DIMM sockets:
Channel Sockets
Channel A SO-DIMM_A1
Channel B SO-DIMM_B1
DIMM_A1
DIMM_B1
IMPORTANT!
• You may install varying memory sizes in Channel A and Channel B. The
system maps the total size of the lower-sized channel for the dual-channel
conguration. Any excess memory from the higher-sized channel is then
mapped for single-channel operation.
• Always install the DIMMS with the same CAS Latency. For an optimum
compatibility, we recommend that you install memory modules of the same
version or data code (D/C) from the same vendor. Check with the vendor to
get the correct memory modules.
• According to Intel®CPU spec, DIMM voltage below 1.35V is recommended
to protect the CPU.
NOTE: Visit the ASUS website at www.asus.com for the latest QVL.
To install a SO-DIMM
3
2
To remove a SO-DIMM
3
2

H110T-CM-A R2.0
2-10
1. LVDS Panel VCC Power selection jumper (6-pin VCC_PWR_SEL)
12V
(Default)
2
5V
1
4 3
6 5
3V
VCC_PWR_SEL
Connector type HEADER 1 x 6p, 2.54mm pitch, S/T
Setting Pins
12V (Default) 5-6
5V 3-4
3V 1-2
2.5 Jumpers
2. Display panel backlight power selection (3-pin BLKT_PWR_SEL)
Pins
12V (Default) 1-2
19V 2-3
1 2
2 3
12V
(Default)
DC_JACK_IN
BLKT_PWR_SEL
Connector type HEADER 1x3p, 2.54mm pitch, S/T

2-11
Chapter 2: Motherboard information
3. Clear RTC RAM (2-pin CLRTC)
This header allows you to clear the CMOS RTC RAM data of the system
setup information such as date, time, and system passwords.
To erase the RTC RAM:
1. Turn OFF the computer and unplug the power cord.
2. Use a metal object such as a screwdriver to short the two pins.
3. Plug the power cord and turn ON the computer.
4. Hold down the <Del> key during the boot process and enter BIOS setup
to re-enter data.
NOTE: If the steps above do not help, remove the onboard battery and move
the jumper again to clear the CMOS RTC RAM data. After clearing the CMOS,
reinstall the battery.
CLRTC
GND
+3V_BAT
PIN 1
Connector type HEADER 1x2p, 2.54mm pitch, S/T

H110T-CM-A R2.0
2-12
2.6 Connectors
2.6.1 Rear panel connectors
1 2 3 4 5 2 6 7
1. DC power connector. Insert the power adapter into this port.
• It can support both 19V and 12V DC input.
• The power adapter is purchased separately.
• Use the appropriate DC power adapter for the following scenarios.
- Use a 90W adapter when a 35W CPU is installed on the system.
- Use a 120W adapter when using your system with an LVDS panel.
- Use a high-rated adapter (above 90W) when a high-rated CPU (45W
or higher CPU) is in stalled on the system.
2. USB 3.0 (up to 5Gbps) ports. These 9-pin Universal Serial Bus (USB) ports
are for USB 3.0 devices.
3. HDMI®port. This port is for a High-Denition Multimedia Interface (HDMI®)
connector, and is HDCP compliant allowing playback of HD DVD, Blu-ray,
and other protected content.
4. DisplayPort. This port is for a DisplayPort-compatible device.
5. LAN (RJ-45) ports. These ports allow Gigabit connection to a Local Area
Network (LAN) through a network hub.
LAN port LED indications
LAN port
Speed
LED
Activity Link
LED
Activity/Link LED Speed LED
Status Description Status Description
Off No link OFF 10Mbps
connection
Orange Linked ORANGE 100Mbps
connection
Green (Blinking) Data activity GREEN 1Gbps connection
Green (Blinking
then steady)
Ready to wake
up from S5 mode
