ASUSTeK COMPUTER H310I-IM-B User manual

Industrial Motherboard
H310I-IM-B

ii
E16437
First Edition
March 2020
Copyright © 2020 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means, except documentation kept by the purchaser for backup purposes, without the express written
permission of ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless
such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identication or explanation and to the
owners’ benet, without intent to infringe.
Offer to Provide Source Code of Certain Software
This product contains copyrighted software that is licensed under the General Public License (“GPL”),
under the Lesser General Public License Version (“LGPL”) and/or other Free Open Source Software
Licenses. Such software in this product is distributed without any warranty to the extent permitted by the
applicable law. Copies of these licenses are included in this product.
Where the applicable license entitles you to the source code of such software and/or other additional data,
you may obtain it for a period of three years after our last shipment of the product, either
(1) for free by downloading it from https://www.asus.com/support/
or
(2) for the cost of reproduction and shipment, which is dependent on the preferred carrier and the location
where you want to have it shipped to, by sending a request to:
ASUSTeK Computer Inc.
Legal Compliance Dept.
1F., No. 15, Lide Rd.,
Beitou Dist., Taipei City 112
Taiwan
In your request please provide the name, model number and version, as stated in the About Box of the
product for which you wish to obtain the corresponding source code and your contact details so that we
can coordinate the terms and cost of shipment with you.
The source code will be distributed WITHOUT ANY WARRANTY and licensed under the same license as
the corresponding binary/object code.
This offer is valid to anyone in receipt of this information.
ASUSTeK is eager to duly provide complete source code as required under various Free Open Source
Software licenses. If however you encounter any problems in obtaining the full corresponding source
code we would be much obliged if you give us a notication to the email address [email protected], stating
the product and describing the problem (please DO NOT send large attachments such as source code
archives, etc. to this email address).

iii
Contents
Chapter 1 Product overview
1.1 Package contents......................................................................... 1-1
1.2 Features ........................................................................................ 1-1
1.3 Specifications............................................................................... 1-2
Chapter 2 Motherboard information
2.1 Before you proceed ..................................................................... 2-1
2.2 Motherboard layout...................................................................... 2-2
2.3 Central Processing Unit (CPU) ................................................... 2-4
2.3.1 Installing the CPU ........................................................... 2-5
2.3.2 CPU heatsink and fan assembly installation................... 2-7
2.4 System memory ........................................................................... 2-9
2.5 Jumpers ...................................................................................... 2-10
2.6 Connectors ................................................................................. 2-14
2.6.1 Rear panel connectors.................................................. 2-14
2.6.2 Internal connectors ....................................................... 2-16
Chapter 3 BIOS setup
3.1 BIOS setup program .................................................................... 3-1
3.1.1 BIOS menu screen.......................................................... 3-2
3.2 Main menu .................................................................................... 3-2
3.2.1 System Date [Day MM/DD/YYYY] .................................. 3-2
3.2.2 System Time [HH:MM:SS] .............................................. 3-2
3.3 Advanced menu ........................................................................... 3-3
3.3.1 Start ASUS EzFlash........................................................ 3-3
3.3.2 PCH-FW Conguration ................................................... 3-3
3.3.3 Trusted Computing ......................................................... 3-3
3.3.4 Platform Misc Conguration............................................ 3-3
3.3.5 CPU Conguration .......................................................... 3-4
3.3.6 System Agent (SA) Conguration ................................... 3-5
3.3.7 PCH Storage Conguration ............................................ 3-6
3.3.8 Onboard Devices Conguration...................................... 3-6
3.3.9 ACPI Settings.................................................................. 3-8
3.3.10 LVDS Conguration ........................................................ 3-8
3.3.11 APM Conguration.......................................................... 3-8
3.3.12 NCT6116D Super IO Conguration ................................ 3-9

iv
3.3.13 NCT6116D HW Monitor ................................................ 3-10
3.3.14 Serial Port Console Redirection.................................... 3-13
3.3.15 USB Conguration ........................................................ 3-13
3.3.16 NVMe Conguration...................................................... 3-14
3.3.17 HDD Secure Erase ....................................................... 3-14
3.3.18 Dynamic Digital IO ........................................................ 3-14
3.3.19 Network Stack Conguration ........................................ 3-15
3.4 Security menu ............................................................................ 3-15
3.5 Boot menu .................................................................................. 3-17
3.6 Save & Exit menu....................................................................... 3-19
3.7 Event Logs.................................................................................. 3-19
3.7.1 Change Smbios Event Log Settings ............................. 3-19
3.7.2 View Smbios Event Log ................................................ 3-20
Appendix
Notices.......................................................................................................A-1

1-1
Chapter 1: General information
1.1 Package contents
Check your industrial motherboard package for the following items.
1 x ASUS H310I-IM-B Motherboard
1 x Serial ATA 6.0 Gb/s cables
2 x M.2 screw packages
1 x ASUS I/O Shield
NOTE: If any of the above items is damaged or missing, contact your
distributor or sales representative immediately.
1.2 Features
• Intel®socket 1151 for the 9th/8th Gen Intel®Core™ i7/ i5/ i3, Pentium®, and
Celeron®processors
• Two Dual Channel DDR4 2666/2400/2133MHz Non-ECC SO-DIMMs up to
32GB
• 4 x SATA 6.0 Gb/s, 4 x USB 3.2 Gen 1, 5 x USB 2.0, 4 x COM headers
• 1 x PCIe x16 slot, 1 x M.2 (Key E, 2230) for Wi-Fi/BT devices, 1 x M.2 (Key M,
2242/2260/2280) with PCIe mode for SSD
• Multi-display: 1 x DisplayPort, 1 x DVI-D, 1 x LVDS or eDP
Chapter 1
Product overview

H310I-IM-B
1-2
1.3 Specifications
(continued on the next page)
CPU
Intel®socket 1151 for 9th / 8th Gen Intel®Core™ i7/ i5/ i3,
Pentium®, and Celeron®processors
Supports Intel® 14nm CPU
Supports up to 65W TDP
Chipset Intel®H310 Chipset
Memory 2 x SO-DIMMs, max.32GB, DDR4 2666/2400/2133 MHz SDRAM
Graphics
Integrated graphics processor - Intel®HD Graphics support
Multi-VGA output support: DP/DVI-D/LVDS/eDP ports
- Supports DVI-D output with a maximum resolution of 1920 x
1200 @ 60Hz
-Supports 1x DisplayPort 1.2 output with a maximum
resolution of 4096 x 2160 @ 60 Hz
-Supports LVDS output with a maximum resolution of 1920 x
1200 @ 60Hz
-Supports 2 lanes Embedded Display Port output with a
maximum resolution of 1920 x 1200 @ 60Hz (co-lay with
LVDS)
Expansion slots
1 x PCI Express 3.0/2.0 x16 slot
1 x M.2 socket 1 (Key E, 2230) for WiFi/BT device supports PCIE
and CNVi WiFi module
1 x M.2 socket 3 (Key M, 2242/2260/2280) with PCIe mode
Storage 4 x SATA Gen3.0 up to 6.0 Gb/s ports
LAN Dual Intel®Lan: 1 x Intel®I219V, 1 x Intel®i211AT
Audio Realtek ALC887-VD2 High Denition Audio
Rear panel I/O
ports
1 x DVI-D port
1 x DP port
2 x USB 3.2 Gen 1 ports
3 x USB 2.0 ports
2 x LAN (RJ45) ports
1 x P/S2 keyboard port
1 x P/S2 mouse port
1 x COM port (RS232/422/485)
2 x Audio jacks
Internal I/O ports
3 x COM headers(3 x RS232)
1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1
ports
1 x USB 2.0 header supports additional 2 USB 2.0 ports

1-3
Chapter 1: General information
Internal I/O ports
1 x CPU Fan header (PWM mode)
1 x Chassis Fan header supports DC/PWM mode
1 x Chassis intrusion header
1 x Front panel audio header(AAFP)
1 x System panel header
1 x Clear CMOS jumper
1 x Speaker header
1 x LPC Debug header
1 x S/PDIF connector
1 x I2C header
1 x GPIO header
1 x AT/ATX mode selection header
1 x 24-pin ATX power connector
1 x 4-pin ATX power connector
1 x SPI TPM header
1 x WDT-EN header
1 x M.2 socket 1 (Key E, 2230) for WiFi/BT device supports PCIE
and CNVi WiFi module
1 x M.2 socket 3 (Key M, 2242/2260/2280) with PCIe mode
4 x SATA 6.0Gb/s connectors
GPIO 1 x 8-bit GPIO header
Manageability WfM 2.0, DMI 2.0, WOL by PME
Watch dog timer Yes
Power
requirement
AT/ATX mode
DC in 12V
Operation
Temperature 0~60°C
Non-Operation
Temperature -40~85°C
Relative Humidity 0%~85%
OS support
Windows®10 (64-bit)
Windows®10 IoT Enterprise
Ubuntu
RedHat Enterprise
Fedora Workstation
OpenSUSE
Certification CE, FCC
Form Factor Mini-ITX Form Factor, 6.7”x 6.7” (17.0cm x 17.0cm)
NOTE: Specications are subject to change without notice.

H310I-IM-B
1-4

2-1
Chapter 2: Motherboard information
Chapter 2
Motherboard information
2.1 Before you proceed
Take note of the following precautions before you install motherboard components
or change any motherboard settings.
CAUTION!
• Unplug the power cord from the wall socket before touching any
component.
• Before handling components, use a grounded wrist strap or touch a safely
grounded object or a metal object, such as the power supply case, to avoid
damaging them due to static electricity.
• Hold components by the edges to avoid touching the ICs on them.
• Whenever you uninstall any component, place it on a grounded antistatic
pad or in the bag that came with the component.
• Before you install or remove any component, always remove the AC power
by unplugging the power cord from the power outlet. Failure to do so may
cause severe damage to the motherboard, peripherals, or components.

H310I-IM-B
2-2
17.0cm(6.7in)
17.0cm(6.7in)
EATXPWR
DDR4 SO-DIMM_B1*
DDR4 SO-DIMM_A1* M.2_(SOCKET3)
F_PANEL
SPEAKER
CHASSIS
AT_ATX_SEL
I C
WDT_EN
BKLTEN_SEL
LCD_BLKT_PANEL
SPDIF_OUT
SATA6G_1 SATA6G_2 SATA6G_3 SATA6G_4
CLRTC
ALC
887-VD2
AAFP
KBMS
USB9
DP
DVI
COM1
AUDIO
Super
I/O
LAN2_USB56
LAN1_U32G1_34
VCC_PWR_SEL
16MB
BIOS
LGA1151
U32G1_12
USB78
Intel®
H310
Intel®
I219V
PCIEX16
ATX12V
CPU_FAN
CHA_FAN
LPC_DEBUG
COM2
COM4
COM3
EDP
GPIO_CON
BATT_CON
WGI
211AT
LVDS
TPM
ASM1480
PCIE SATA IRST
X2 XX
M.2(WIFI)
2260
2242
2280
BKLPWR_SEL
2
13
12
14
15
10
9
7
1
8
17 16 18
1920
21
23
25
24
29
28
27
26
22
54 62 31
11
2.2 Motherboard layout
Place this side
towards the rear
of the chassis
NOTE: Place four screws into the holes indicated by circles to secure the
motherboard to the chassis.
CAUTION! Do not overtighten the screws! Doing so can damage the
motherboard.

2-3
Chapter 2: Motherboard information
Connectors/Jumpers/Slots Page
1. CPU and chassis fan connectors (4-pin CPU_FAN, 4-pin CHA_FAN) 2-18
2. Display panel VCC power selection (6-pin VCC_PWR_SEL) 2-11
3. ATX power connectors (24-pin EATXPWR, 4-pin ATX12V) 2-25
4. USB 3.2 Gen 1 connector (20-1 pin U32G1_12) 2-16
5. SATA 6.0Gb/s connectors (7-pin SATA6G_1-4) 2-19
6. LPC debug header 2-22
7. SPI_TPM connector (14-1 pin SPI_TPM) 2-18
8. Serial port connectors (10-1 pin COM2, COM3, COM4) 2-23
9. USB 2.0 connector (10-1pin USB78) 2-17
10. M.2 Wi-Fi 2-21
11. Embedded DisplayPort (eDP) 2-16
12. Speaker connector (4-1 pin SPEAKER) 2-20
13. Chassis Intrusion header (4-pin CHASSIS) 2-13
14. System panel connector (10-1 pin F_PANEL) 2-19
15. M.2 socket 3 2-21
16. I2C connector 2-22
17. AT/ATX mode selection (3-pin AT_ATX_SEL) 2-11
18. WDT Enbale jumper (2-pin WDT_EN) 2-12
19. Clear RTC RAM (2-pin CLRTC) 2-10
20. Front panel audio connector (10-1 pin AAFP) 2-24
21. DDR4 SO-DIMM slots 2-9
22. Intel® LGA1151 CPU socket 2-4
23. RTC Battery header (2-pin BATT_CON) 2-20
24. General purpose input/output connector (GPIO_CON) 2-17
25. Digital audio connector (4-1 pin SPDIF_OUT) 2-24
26. LVDS connector (30-pin LVDS) 2-20
27. Flat panel display brightness connector (6-pin LCD_BLKT_PANEL) 2-23
28. Display panel backlight power selection (3-pin BKLT_PWR_SEL) 2-10
29. Back Light power enable selection (3-pin BKLTEN_SEL) 2-12

H310I-IM-B
2-4
IMPORTANT: Unplug all power cables before installing the CPU.
CAUTION!
• Upon purchase of the motherboard, ensure that the PnP cap is on
the socket and the socket contacts are not bent. Contact your retailer
immediately if the PnP cap is missing, or if you see any damage to the
PnP cap/socket contacts/motherboard components. The manufacturer will
shoulder the cost of repair only if the damage is shipment/transit-related.
• Keep the cap after installing the motherboard. The manufacturer will
process Return Merchandise Authorization (RMA) requests only if the
motherboard comes with the cap on the LGA1151 socket.
• The product warranty does not cover damage to the socket contacts
resulting from incorrect CPU installation/removal, or misplacement/loss/
incorrect removal of the PnP cap.
2.3 Central Processing Unit (CPU)
The motherboard comes with a surface mount LGA1151 socket designed for the
Intel®9th/8th Generation Core™ i7 / Core™ i5 / Core™ i3, Pentium®, and Celeron®
processors.
H310I-IM-B CPU socket LGA1151

2-5
Chapter 2: Motherboard information
2.3.1 Installing the CPU
1
A
B
2 3
CAUTION! LGA1156 CPU is not compatible with the LGA1151 socket. DO
NOT install an LGA1156 CPU on the LGA1151 socket.

H310I-IM-B
2-6
A
B
C
4
5

2-7
Chapter 2: Motherboard information
2.3.2 CPU heatsink and fan assembly installation
CAUTION! Apply the Thermal
Interface Material to the CPU
heatsink and CPU before you
install the heatsink and fan if
necessary.
To install the CPU heatsink and fan assembly
B
A
A
B
1
2
3 4

H310I-IM-B
2-8
A
B
B
A
To uninstall the CPU heatsink and fan assembly
2
1

2-9
Chapter 2: Motherboard information
2.4 System memory
This motherboard comes with two Double Data Rate 4 (DDR4) Small Outline Dual Inline
Memory Module (SO-DIMM) sockets. The gure below illustrates the location of the DDR4
SO-DIMM sockets:
Channel Sockets
Channel A SO-DIMM_A1*
Channel B SO-DIMM_B1*
Installing a DIMM
H310I-IM-B DDR4 SODIMM slot
SO-DIMM_B1*
SO-DIMM_A1*
1 2
To remove a DIMM
B
A
B
A
A
DIMM_B1*
DIMM_A1*
DIMM_A1*
DIMM_B1*
Recommended memory configuration

H310I-IM-B
2-10
2.5 Jumpers
1. Clear RTC RAM (2-pin CLRTC)
This header allows you to clear the CMOS RTC RAM data of the system
setup information such as date, time, and system passwords.
To erase the RTC RAM:
1. Turn OFF the computer and unplug the power cord.
2. Use a metal object such as a screwdriver to short the two pins.
3. Plug the power cord and turn ON the computer.
4. Hold down the <Del> key during the boot process and enter BIOS setup
to re-enter data.
NOTE: If the steps above do not help, remove the onboard battery and move
the jumper again to clear the CMOS RTC RAM data. After clearing the CMOS,
reinstall the battery.
2. Display panel backlight power selection (3-pin BLKT_PWR_SEL)
Pins
12V 1-2
5V (Default) 2-3
H310I-IM-B Clear CMOS jumper
CLRTC
1 2 2 3
12V 5V
(Default)
BKLPWR_SEL
H310I-IM-B Back Light
Powe Selection jumper
Connector type HEADER 1x2p, 2.54mm pitch, S/T
Connector type HEADER 1x3p, 2.54mm pitch, S/T

2-11
Chapter 2: Motherboard information
Setting Pins
3.3V (Default) 1-2
5V 3-4
12V 5-6
3. Display panel VCC power selection (6-pin VCC_PWR_SEL)
H310I-IM-B LVDS&EDP Panel power selection
3
4
5
6
12V
2
5V
1
3.3V
(Default)
VCC_PWR_SEL
4. AT/ATX mode selection (3-pin AT_ATX_SEL)
Pins
1-2 (Default) ATX mode
2-3 AT mode
H310I-IM-B AT/ATX Mode Selection jumper
21 2 3
ATX mode
(Default)
AT mode
AT_ATX_SEL
Connector type HEADER 2 x 3p, 2.54mm pitch, S/T
Connector type HEADER 1x3p, 2.54mm pitch, S/T

H310I-IM-B
2-12
6. Back Light power enable mode (BKLTEN_SEL)
Pins
1-2 (Default) High Active
2-3 Low Active
1 2 3
BKLTEN_SEL
H310I-IM-B Back Light
Power Enable mode jumper
5. WDT Enable jumper (2-pin WDT_EN)
A watchdog timer is an electronic timer that is used to detect and recover
from computer malfunctions. The HW WDT (watchdog timer) Enable jumper
allows the HW watchdog resets the system automatically even when the
system crashes.
H310I-IM-B HW WDT Enable jumper
WDT_EN
NOTE: By default, this jumper is set to HW WDT enabled with a jumper cap
attached.
Connector type HEADER 1x2p, 2.54mm pitch, S/T
Connector type HEADER 1x3p, 2.54mm pitch, S/T
