ASUSTeK COMPUTER H310I-IM-A R3.0 User manual

Industrial Motherboard
H310I-IM-A R3.0

ii
E20015
First Edition
March 2022
Copyright © 2022 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means, except documentation kept by the purchaser for backup purposes, without the express written
permission of ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless
such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identication or explanation and to the
owners’ benet, without intent to infringe.

iii
Contents
Chapter 1 Product overview
1.1 Package contents......................................................................... 1-1
1.2 Features ........................................................................................ 1-1
1.3 Specications............................................................................... 1-2
Chapter 2 Motherboard information
2.1 Before you proceed ..................................................................... 2-1
2.2 Motherboard layout...................................................................... 2-2
2.3 Central Processing Unit (CPU) ................................................... 2-4
2.3.1 CPU installation .............................................................. 2-5
2.3.2 CPU heatsink and fan assembly installation................... 2-7
2.4 System memory ........................................................................... 2-9
2.5 Jumpers ...................................................................................... 2-10
2.6 Connectors ................................................................................. 2-12
2.6.1 Rear panel connectors.................................................. 2-12
2.6.2 Internal connectors ....................................................... 2-15
2.7 Slot .............................................................................................. 2-24
Chapter 3 BIOS setup
3.1 BIOS Setup program.................................................................... 3-1
3.2 Main menu .................................................................................... 3-2
3.2.1 System Date [Day MM/DD/YYYY] .................................. 3-2
3.2.2 System Time [HH:MM:SS] .............................................. 3-2
3.3 Advanced menu ........................................................................... 3-2
3.3.1 LVDS Conguration ........................................................ 3-2
3.3.2 PCH-FW Conguration ................................................... 3-4
3.3.3 Trusted Computing ......................................................... 3-4
3.3.4 CPU Conguration .......................................................... 3-5
3.3.5 Graphics Conguration ................................................... 3-5
3.3.6 PCI Express Conguration.............................................. 3-6
3.3.7 CSM Conguration.......................................................... 3-6
3.3.8 Supper IO Conguration ................................................. 3-6
3.3.9 Serial Console Redirection ............................................. 3-7
3.3.10 SATA Conguration ........................................................ 3-9
3.3.11 USB Conguration ........................................................ 3-10
3.3.12 Onboard Devices Conguration.................................... 3-11

iv
3.3.13 NVMe Conguration...................................................... 3-11
3.3.14 APM Conguration........................................................ 3-12
3.3.15 EZ-Flash ....................................................................... 3-12
3.3.16 Watchdog Timer............................................................ 3-12
3.3.17 Miscellaneous ............................................................... 3-12
3.4 Hardware Monitor menu............................................................ 3-13
3.5 Security menu ............................................................................ 3-14
3.5.1 Administrator Password ................................................ 3-14
3.5.2 User Password.............................................................. 3-14
3.5.3 Secure Boot .................................................................. 3-15
3.6 Boot menu .................................................................................. 3-15
3.7 Exit menu.................................................................................... 3-16
Appendix
Notices.......................................................................................................A-1
Service and Support.................................................................................A-5

1-1
Chapter 1: General information
1.1 Package contents
Check your industrial motherboard package for the following items.
1 x ASUS H310I-IM-A R3.0 Motherboard
2 x Serial ATA 6.0 Gb/s cables
2 x M.2 screw packages
1 x ASUS I/O Shield
NOTE: If any of the above items is damaged or missing, contact your
distributor or sales representative immediately.
1.2 Features
• Intel®socket 1151 for 9th/8th Gen Intel®Core™ i7/ i5/ i3, Pentium®, and
Celeron®processors supports 14nm CPU, Max. 65W TDP
• Two Dual Channel DDR4 2666/2400/2133MHz SO-DIMMs up to 32GB
• 2 x SATA 6.0 Gb/s, 6 x USB 3.2 Gen 1, 4 x USB 2.0, 6 x COM headers
• 1 x PCIe x16 slot, 1 x MiniPCIe, 1 x M.2 Socket 1 (Key E, 2230) for WIFI/
BT device, 1 x M.2 Socket 3 (Key M, 2242/2260/2280) with PCIe and SATA
modes for SSD
• Multi-display: 2 x DisplayPort, 1 x HDMI, LVDS
Chapter 1
Product overview

H310I-IM-A R3.0
1-2
1.3 Specications
CPU
Intel®socket 1151 for 9th/8th Gen Intel®Core™ i7/ i5/ i3, Pentium®, and
Celeron®processors, Max.65 TDP
Supports Intel® 14nm CPU
*Refer to www.asus.com for Intel®CPU support list.
Chipset Intel®H310 Chipset
Memory 2 x SO-DIMM, max.32GB, DDR4 2666/2400/2133 MHz
*Refer to www.asus.comforthelatestMemoryQVL(QualiedVendorsList).
Graphics
Integrated graphics processor - Intel®HD Graphics support
Multi-VGA output support: DP/HDMI/LVDS ports
- Supports HDMI1.4b output with a max.resolution of 4096 x 2160 @
24Hz
-Supports 2 x DisplayPort 1.2a outputs with a max. resolution of 4096
x 2160 @ 60 Hz
-Supports LVDS 1.4b output with a max. resolution of 1920 x 1200 @
60Hz
Expansion
slots
1 x PCI Express 3.0/2.0 x16 slot
1 x Full/Half mini-PCIe with SATA
1 x M.2 Socket 1 (Key E, 2230) for WIFI/BT device
1 x M.2 Socket 3 (Key M, 2242/2260/2280) with PCIe and SATA modes
for SSD
Storage
2 x SATA 6.0 Gb/s ports
1 x M.2 Socket 3 (Key M, 2242/2260/2280) with PCIe and SATA modes
for SSD
1 x full/half mini-PCIe with SATA
LAN Dual Intel®Lan: 1 x Intel®I219V, 1 x Intel®I210AT
Audio
Realtek® ALC897 8-channel High Denition Audio CODEC*
- Supports Jack-Detection, Multi-recording, and Audio Re-tasking
* The audio codec may vary between motherboards, please consult your
sales window for the motherboard’s exact codec type.
USB
4 x USB 3.2 Gen 1 ports (4 ports at the rear panel)
1 x USB 3.2 Gen 1 header (2 USB 3.2 Gen 1 ports at mid-board)
2 x USB 2.0 headers (for 4 USB 2.0 ports at mid-board)
Rear panel
I/O ports
1 x HDMI port
2 x DisplayPorts
2 x COM ports (2 x RS232/422/485)
2 x LAN (RJ45) ports
4 x USB 3.2 Gen 1 ports
2 x Audio jacks
(continued on the next page)

1-3
Chapter 1: General information
Front panel I/O
ports
2 x USB 2.0 2-port connectors support additional 4 USB 2.0 ports
1 x USB 3.2 Gen 1 2-port connector supports additional 2 USB
3.2 Gen 1 ports
2 x SATA 6.0Gb/s connectors
1 x M.2 Socket 1 (Key E, 2230) for WIFI/BT device
1 x M.2 Socket 3 (Key M, 2242/2260/2280) for SSD
1 x Full/Half mini-PCIe with SATA
1 x CPU Fan connector
1 x Chassis Fan connector
1 x Front panel audio connector (AAFP)
1 x System panel connector
1 x Clear CMOS header
4 x COM headers (4 x RS232)
1 x SPI TPM header
1 x LPC Debug header
1 x Speaker connector
1 x 24-pin ATX power connector
1 x 4-pin ATX power connector
1 x LVDS connector
1 x LCD panel monitor switch header
1 x Display panel VCC power selector
1 x Flat panel display brightness connector
1 x AT/ATX mode selection header
GPIO 1 x 8-bit GPIO header
BIOS features
128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI 3.0, WfM 2.0, SM
BIOS 3.1, ACPI 6.1, Multi-language BIOS, ASUS EZ Flash 3,
Last Modied Log, ErP Ready, ASUS Self-Recovering BIOS,
ASUS Commercial Kit
Manageability WfM 2.0, DMI 2.0, WOL by PME
Watch dog timer Yes
Power
requirement AT/ATX
Operation
Temperature 0~60°C
Non-Operation
Temperature -40~85°C
Relative Humidity 0%~85%
(continued on the next page)

H310I-IM-A R3.0
1-4
OS support
Windows®10 (64-bit)
Win10 IoT Enterprise
Ubuntu
RedHat Enterprise
Fedora Workstation
OpenSUSE
Form Factor Mini-ITX Form Factor, 6.7”x 6.7” (17.0cm x 17.0cm)
NOTE: Specications are subject to change without notice. Please refer to the
ASUS website for the latest specications.

2-1
Chapter 2: Motherboard information
Chapter 2
Motherboard information
2.1 Before you proceed
Take note of the following precautions before you install motherboard components
or change any motherboard settings.
CAUTION!
• Unplug the power cord from the wall socket before touching any
component.
• Before handling components, use a grounded wrist strap or touch a safely
grounded object or a metal object, such as the power supply case, to avoid
damaging them due to static electricity.
• Hold components by the edges to avoid touching the ICs on them.
• Whenever you uninstall any component, place it on a grounded antistatic
pad or in the bag that came with the component.
• Before you install or remove any component, always remove the AC power
by unplugging the power cord from the power outlet. Failure to do so may
cause severe damage to the motherboard, peripherals, or components.

H310I-IM-A R3.0
2-2
17.0cm(6.7in)
17.0cm(6.7in)
EATXPWR
DDR4 SO-DIMM_A1 (64bit, 260-pin module)
DDR4 SO-DIMM_B1 (64bit, 260-pin module)
M.2_(SOCKET3)
F_PANEL
SPEAKER
AT_ATX_SEL
BLKT_PWR_SEL
SATA6G_2
LCD_BLKT_PANEL
SATA6G_1
CLRTC
AAFP
ALC
887-VD2
HDMI DP2
DP1
AUDIO
Super
I/O
LAN2_U31G1_E34
LAN1_U31G1_E12
COM2
COM1 COM1_SEL
COM2_SEL
VCC_PWR_SEL
BATTERY
128Mb
BIOS
LGA1151
U31G1_12
Intel®
H310
Intel®
I219V
Intel®
I210AT
PCIEX16_1
ATX12V
CPU_FAN
DIGI
+VRM
CHA_FAN
USB56
COM6
LPC_DEBUG
COM5 COM4 COM3
LVDS
USB78
PANEL_SW
GPIO_CON
TPM
MSATA_MPCIE
ASM
1074
ASM1480
M.2(WIFI)
2242
2260
2280
14
15
16
13
12
9
10
11
18 19 17
202117
12
23
24
26
25
22
6 7 82 5431
2.2 Motherboard layout
Place this side
towards the rear
of the chassis
NOTE: Place four screws into the holes indicated by circles to secure the
motherboard to the chassis.
CAUTION! Do not overtighten the screws! Doing so can damage the
motherboard.

2-3
Chapter 2: Motherboard information
Connectors/Jumpers/Slots Page
1. COM1 Ring/+5V/+12V selection jumpers (6-pin COM1_ESL, COM2_ESL) 2-11
2. LCD panel monitor switch header (2-pin PANEL_SW) 2-15
3. USB 3.2 Gen 1 connector (20-1 pin U32G1_12) 2-15
4. USB 2.0 connectors (10-pin USB56, USB78) 2-16
5. General purpose input/output connector (GPIO_CON) 2-16
6. Serial port connectors (10-1 pin COM3, COM4, COM5, COM6) 2-22
7. TPM connector (14-1 pin TPM) 2-17
8. Display panel backlight power selection (3-pin BLKT_PWR_SEL) 2-10
9. LVDS connector (40-pin LVDS) 2-19
10. DDR4 SO-DIMM slots 2-9
11. Display panel VCC power selection (6-pin VCC_PWR_SEL) 2-11
12. ATX power connectors (24-pin EATXPWR, 4-pin ATX12V) 2-22
13. Flat panel display brightness connector (8-pin LCD_BLKT_PANEL) 2-23
14. Serial ATA 6.0Gb/s connectors (7-pin SATA6G_1/2) 2-18
15. System panel connector (10-1 pin F_PANEL) 2-18
16. Speaker connector (4-pin SPEAKER) 2-19
17. CPU and chassis fan connectors (4-pin CPU_FAN, 4-pin CHA_FAN) 2-17
18. AT/ATX mode selection (3-pin AT_ATX_SEL) 2-12
19. PCI Express 3.0/2.0 x16 slot 2-24
20. Clear RTC RAM (2-pin CLRTC) 2-10
21. Front panel audio connector (10-1 pin AAFP) 2-23
22. Intel® LGA1151 CPU socket 2-4
23. M.2 socket 3 2-20
24. mSATA/mPCIe combo slot (MSATA_MPCIE) 2-21
25. M.2 Wi-Fi 2-20
26. LPC debug header 2-21

H310I-IM-A R3.0
2-4
IMPORTANT! Unplug all power cables before installing the CPU.
CAUTION!
• Upon purchase of the motherboard, ensure that the PnP cap is on
the socket and the socket contacts are not bent. Contact your retailer
immediately if the PnP cap is missing, or if you see any damage to the
PnP cap/socket contacts/motherboard components. The manufacturer will
shoulder the cost of repair only if the damage is shipment/transit-related.
• Keep the cap after installing the motherboard. The manufacturer will
process Return Merchandise Authorization (RMA) requests only if the
motherboard comes with the cap on the LGA1151 socket.
• The product warranty does not cover damage to the socket contacts
resulting from incorrect CPU installation/removal, or misplacement/loss/
incorrect removal of the PnP cap.
2.3 Central Processing Unit (CPU)
The motherboard comes with a surface mount LGA1151 socket designed for the
Intel®9th/8th Generation Core™ i7 / Core™ i5 / Core™ i3, Pentium®, and Celeron®
processors.
LGA1151

2-5
Chapter 2: Motherboard information
2.3.1 CPU installation
1
A
B
2 3
CAUTION! LGA1156 CPU is not compatible with the LGA1151 socket. DO
NOT install an LGA1156 CPU on the LGA1151 socket.

H310I-IM-A R3.0
2-6
A
B
C
4
5

2-7
Chapter 2: Motherboard information
2.3.2 CPU heatsink and fan assembly installation
CAUTION! Apply the Thermal
Interface Material to the CPU
heatsink and CPU before you
install the heatsink and fan if
necessary.
To install the CPU heatsink and fan assembly
B
A
A
B
1
2
3 4

H310I-IM-A R3.0
2-8
A
B
B
A
To uninstall the CPU heatsink and fan assembly
2
1

2-9
Chapter 2: Motherboard information
2.4 System memory
This motherboard comes with two Double Data Rate 4 (DDR4) Small Outline Dual Inline
Memory Module (SO-DIMM) sockets. The gure below illustrates the location of the DDR4
SO-DIMM sockets:
Channel Sockets
Channel A SO-DIMM_A1
Channel B SO-DIMM_B1
Installing a DIMM
SO-DIMM_A1
SO-DIMM_B1
1 2
To remove a DIMM
B
A
B
A
A
DIMM_A1
DIMM_B1
DIMM_B1
DIMM_A1
Recommended memory conguration

H310I-IM-A R3.0
2-10
2.5 Jumpers
1. Clear RTC RAM (2-pin CLRTC)
This header allows you to clear the CMOS RTC RAM data of the system
setup information such as date, time, and system passwords.
To erase the RTC RAM:
1. Turn OFF the computer and unplug the power cord.
2. Use a metal object such as a screwdriver to short the two pins.
3. Plug the power cord and turn ON the computer.
4. Hold down the <Del> key during the boot process and enter BIOS setup
to re-enter data.
NOTE: If the steps above do not help, remove the onboard battery and move
the jumper again to clear the CMOS RTC RAM data. After clearing the CMOS,
reinstall the battery.
2. Display panel backlight power selection (3-pin BLKT_PWR_SEL)
Pins
12V (Default) 1-2
19V 2-3
CLRTC
+3V_BAT_RTC
GND
PIN 1
1 2 2 3
12V
(Default)
19V
BLKT_PWR_SEL

2-11
Chapter 2: Motherboard information
3. COM1/2 Ring/+5V/+12V selection (6-pin COM1_SEL, COM2_SEL)
Setting Pins
+12V 1-2
+5V 3-4
Ring (Default) 5-6
Setting Pins
3V (Default) 1-2
5V 3-4
12V 5-6
4. Display panel VCC power selection (6-pin VCC_PWR_SEL)
COM1_SEL
COM2_SEL
RI
(Default)
+5V+12V
12 34 56
A
A
B
B
12V5V
1
3V
(Default)
VCC_PWR_SEL
3
4
5
6
2

H310I-IM-A R3.0
2-12
5. AT/ATX mode selection (3-pin AT_ATX_SEL)
Pins
1-2 (Default) ATX mode
2-3 AT mode
21 2 3
ATX mode
(Default)
AT mode
AT_ATX_SEL
2.6 Connectors
2.6.1 Rear panel connectors
1 2 3 4
1 5 6 7
1. Serial ports (COM). These ports connect a modem, and other devices that
conform with serial specication.
2. DisplayPorts. These ports are for DisplayPort-compatible devices.
