ASUSTeK COMPUTER Pro B460M-C User manual

Motherboard
Pro B460M-C

ii
E16366
First Edition
March 2020
Copyright © 2020 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means, except documentation kept by the purchaser for backup purposes, without the express written
permission of ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless
such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identication or explanation and to the
owners’ benet, without intent to infringe.
Offer to Provide Source Code of Certain Software
This product contains copyrighted software that is licensed under the General Public License (“GPL”),
under the Lesser General Public License Version (“LGPL”) and/or other Free Open Source Software
Licenses. Such software in this product is distributed without any warranty to the extent permitted by the
applicable law. Copies of these licenses are included in this product.
Where the applicable license entitles you to the source code of such software and/or other additional data,
you may obtain it for a period of three years after our last shipment of the product, either
(1) for free by downloading it from https://www.asus.com/support/
or
(2) for the cost of reproduction and shipment, which is dependent on the preferred carrier and the location
where you want to have it shipped to, by sending a request to:
ASUSTeK Computer Inc.
Legal Compliance Dept.
1F. No.15, Lide Rd.,
Beitou Dist., Taipei City 112
Taiwan
In your request please provide the name, model number and version, as stated in the About Box of the
product for which you wish to obtain the corresponding source code and your contact details so that we
can coordinate the terms and cost of shipment with you.
The source code will be distributed WITHOUT ANY WARRANTY and licensed under the same license as
the corresponding binary/object code.
This offer is valid to anyone in receipt of this information.
ASUSTeK is eager to duly provide complete source code as required under various Free Open Source
Software licenses. If however you encounter any problems in obtaining the full corresponding source
code we would be much obliged if you give us a notication to the email address [email protected], stating
the product and describing the problem (please DO NOT send large attachments such as source code
archives, etc. to this email address).

iii
Contents
Safety information...................................................................................................... iv
About this guide.......................................................................................................... v
Package contents....................................................................................................... vi
Pro B460M-C specifications summary..................................................................... vi
Connectors with shared bandwidth ......................................................................... ix
Chapter 1 Product introduction
1.1 Before you proceed...................................................................................... 1-1
1.2 Motherboard overview .................................................................................1-1
1.3 Central Processing Unit (CPU).................................................................... 1-8
1.4 System memory............................................................................................ 1-9
Chapter 2 BIOS information
2.1 BIOS setup program.....................................................................................2-1
2.2 BIOS menu screen........................................................................................2-2
2.3 Event Log ......................................................................................................2-3
2.4 Exit menu ......................................................................................................2-4
Appendix
Notices ..................................................................................................................... A-1
ASUS contact information...................................................................................... A-6

iv
Safety information
Electrical safety
• To prevent electrical shock hazard, disconnect the power cable from the electrical outlet
before relocating the system.
• When adding or removing devices to or from the system, ensure that the power cables
for the devices are unplugged before the signal cables are connected. If possible,
disconnect all power cables from the existing system before you add a device.
• Before connecting or removing signal cables from the motherboard, ensure that all power
cables are unplugged.
• Seek professional assistance before using an adapter or extension cord. These devices
could interrupt the grounding circuit.
• Ensure that your power supply is set to the correct voltage in your area. If you are not
sure about the voltage of the electrical outlet you are using, contact your local power
company.
• If the power supply is broken, do not try to x it by yourself. Contact a qualied service
technician or your retailer.
Operation safety
• Before installing the motherboard and adding components, carefully read all the manuals
that came with the package.
• Before using the product, ensure all cables are correctly connected and the power cables
are not damaged. If you detect any damage, contact your dealer immediately.
• To avoid short circuits, keep paper clips, screws, and staples away from connectors,
slots, sockets and circuitry.
• Avoid dust, humidity, and temperature extremes. Do not place the product in any area
where it may be exposed to moisture.
• Place the product on a stable surface.
• If you encounter technical problems with the product, contact a qualied service
technician or your retailer.
• Your motherboard should only be used in environments with ambient temperatures
between 0°C and 40°C.

v
About this guide
This user guide contains the information you need when installing and conguring the
motherboard.
How this guide is organized
This guide contains the following parts:
• Chapter1:Productintroduction
This chapter describes the features of the motherboard and the new technology it
supports. It includes descriptions of the switches, jumpers, and connectors on the
motherboard.
• Chapter2:BIOSandRAIDSupport
This chapter tells how to boot into the BIOS, upgrade BIOS using the EZ Flash Utility
and support on RAID.
Where to find more information
Refer to the following sources for additional information and for product and software
updates.
1. ASUS website
The ASUS website provides updated information on ASUS hardware and software
products. Refer to the ASUS contact information.
2. Optional documentation
Your product package may include optional documentation, such as warranty yers,
that may have been added by your dealer. These documents are not part of the
standard package.
Conventions used in this guide
To ensure that you perform certain tasks properly, take note of the following symbols used
throughout this manual.
CAUTION: Information to prevent damage to the components and injuries to
yourself when trying to complete a task.
IMPORTANT: Instructions that you MUST follow to complete a task.
NOTE: Tips and additional information to help you complete a task.

vi
Pro B460M-C specifications summary
CPU
Intel®Socket LGA1200 for 10th Gen Intel®Core™, Pentium®Gold and
Celeron®Processors*
Supports Intel® 14nm CPU
Supports Intel®Turbo Boost Technology 2.0 and Intel®Turbo Boost Max
Technology 3.0**
*Refer to www.asus.com for CPU support list.
**Intel®Turbo Boost Max Technology 3.0 support depends on the CPU types.
Chipset Intel®B460 Chipset
Memory
4 x DIMM, Max. 128GB, DDR4 2933/2800/2666/2400/2133 MHz Non-ECC,
Un-buffered Memory*
Dual Channel Memory Architecture
Supports Intel® Extreme Memory Prole (XMP)
OptiMem
*For 10th Gen Intel®processors, only Core™ i9/i7 CPUs support 2933/2800/2666/
2400/2133natively,otherswillrunatthemaximumtransferrateofDDR4
2666MHz.
*Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
Graphics
2 x DisplayPorts 1.4**
1 x D-Sub
1 x HDMITM 1.4b
*Graphics specifications may vary between CPU types.
**SupportDisplayPort1.4withmax.resolutionof4096x2304@60Hz.Pleaserefer
to www.intel.com for any update.
Expansion Slots
Intel®10th Gen Processors
1 x PCIe 3.0 x16 slot (supports x16 mode)
Intel®B460 Chipset
2 x PCIe 3.0 x1 slots
1 x PCI slot
(continued on the next page)
Package contents
Check your motherboard package for the following items.
Motherboard 1 x Pro B460M-C motherboard
Cables 2 x SATA 6Gb/s cables
Miscellaneous 1 x I/O Shield
1 x M.2 SSD screw package
ApplicationDVD 1 x Support DVD
Documentation 1 x ACC Express Activation Key Card
1 x User manual
If any of the above items is damaged or missing, contact your retailer.

vii
Pro B460M-C specifications summary
Storage
Total supports 2 x M.2 slots and 6 x SATA 6Gb/s ports
Intel®B460 Chipset
M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 & SATA
modes)*
M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 mode)**
6 x SATA 6Gb/s ports
Intel®Rapid Storage Technology supports Raid 0,1,5,10
Intel®Optane™ Memory Ready
*When a device in SATA mode is installed on the M.2_1 socket, SATA6G_1 port
cannot be used.
**Only M.2_2 supports IRST.
Ethernet 1 x Intel®I219V 1Gb Ethernet
ASUS LANGuard
USB
Rear USB (Total 6 ports)
4 x USB 3.2 Gen 1 ports (4 x Type-A)
2 x USB 2.0 ports (2 x Type-A)
Front USB (Total 6 ports)
1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
2 x USB 2.0 headers support additional 4 USB 2.0 ports
Audio
Realtek ALC887 7.1-Channel High Denition Audio CODEC*
- Jack-detection, Multi-streaming, Front Panel Jack-retasking
- Supports up to 24-Bit/192kHz playback
*AchassiswithanHDaudiomoduleinthefrontpanelisrequiredtosupport
7.1-channel audio output.
Back Panel I/O Ports
4 x USB 3.2 Gen 1 ports (4 x Type-A)
2 x USB 2.0 ports (2 x Type-A)
2 x DisplayPorts
1 x D-sub port
1 x HDMITM port
1 x Intel®I219V 1Gb Ethernet port
3 x Audio jacks
1 x PS/2 keyboard (purple) port
1 x PS/2 mouse (green) port
Internal I/O
Connectors
Fan and cooling related
1 x 4-pin CPU Fan header
2 x 4-pin Chassis Fan headers
Power related
1 x 24-pin Main Power connector
1 x 8-pin +12V Power connector
Storage related
2 x M.2 slots (Key M)
6 x SATA 6Gb/s ports
USB
1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
2 x USB 2.0 headers support additional 4 USB 2.0 ports
(continued on the next page)

viii
Pro B460M-C specifications summary
Internal I/O
Connectors
Miscellaneous
1 x Clear CMOS header
1 x Chassis Intrude header
2 x COM Port headers
1 x Front Panel Audio header (AAFP)
1 x LPC Debug header
1 x LPT header
1 x Mono-out header (with Amp IC)
1 x Speaker header
1 x SPI TPM header (14-1pin)
1 x 10-1 pin System Panel header
Special Features
ASUSEZDIY
- Box Headers
BespokeMotherboardDesign&BusinessFocusedFeatures:
- ASUS Self Recovering BIOS
- ASUS Event Log
- ASUS Commercial BIOS kit
- Anti-Moisture
- 24/7 Reliability
- Overcurrent Protection
Software
Features
ASUS Exclusive Software
IT Management software supported
- ASUS Control Center Express (ACCE)
BIOS 128 Mb Flash ROM, UEFI AMI BIOS
Manageability WOL by PME, PXE
Operating System Windows® 10 - 64 bit
Form Factor mATX Form Factor
9.6 inch x 9.6 inch (24.4 cm x 24.4 cm)
Specications are subject to change without notice.

ix
Connectors with shared bandwidth
A
A
PCI
PCIEX1_2
PCIEX1_1
SPEAKER
CHASSIS
CLRTC
F_PANEL
LPC_DEBUG
USB1112USB910
LPT
TPM
U32G1_56
AAFP
MONO_OUT
EATX12V
EATXPWR
CPU_FAN
CHA_FAN1
CHA_FAN2
BATTERY
PCIEX16
Super
I/O
ASM
1083
ALC
887
DIGI
+VRM
LGA1200
Intel®
B460
Intel®
I219V
DDR4 DIMM_B1 (64bit, 288-pin module)
2280 2260
2280 2260 2242
2242
M.2_2(SOCKET3)
PCIE SATA IRST
X4 X V
M.2_1(SOCKET3)
PCIE SATA IRST
X4 XV
DDR4 DIMM_B2* (64bit,288-pin module) DDR4 DIMM_A1 (64bit, 288-pin module) DDR4 DIMM_A2* (64bit, 288-pin module)
AUDIO
KBMS
DP_12
LAN_USB78
U32G1_34
U32G1_12
128Mb
BIOS
SATA6G_6 SATA6G_5
SATA6G_4
SATA6G_1SATA6G_2SATA6G_3
HDMI
VGA
COM1 COM2
M.2_2(SOCKET3)
M.2_1(SOCKET3)
Configuration 1 2
AM.2_1 x4 SATA
SATA6G_1 V -
• When a device in SATA mode is installed on the M.2_1 slot, SATA6G_1 port cannot
be used.
• M.2_1 shares bandwidth with SATA6G_1.

x

ASUS Pro B460M-C 1-1
Product introduction
1
1.1 Before you proceed
Take note of the following precautions before you install motherboard components or change
any motherboard settings.
• Unplugthepowercordfromthewallsocketbeforetouchinganycomponent.
• Beforehandlingcomponents,useagroundedwriststraportouchasafelygrounded
objectorametalobject,suchasthepowersupplycase,toavoiddamagingthemdue
to static electricity.
• Beforeyouinstallorremoveanycomponent,ensurethattheATXpowersupplyis
switched off or the power cord is detached from the power supply. Failure to do so
maycauseseveredamagetothemotherboard,peripherals,orcomponents.
Unplugthepowercordbeforeinstallingorremovingthemotherboard.Failuretodosocan
cause you physical injury and damage motherboard components.
1.2 Motherboard overview
Place this
side towards
the rear of the
chassis
PCI
PCIEX1_2
PCIEX1_1
SPEAKER
CHASSIS
CLRTC
F_PANEL
LPC_DEBUG
USB1112USB910
LPT
TPM
U32G1_56
AAFP
MONO_OUT
EATX12V
EATXPWR
CPU_FAN
CHA_FAN1
CHA_FAN2
BATTERY
PCIEX16
Super
I/O
ASM
1083
ALC
887
DIGI
+VRM
24.4cm(9.6in)
24.4cm(9.6in)
LGA1200
Intel®
B460
Intel®
I219V
DDR4 DIMM_B1 (64bit, 288-pin module)
2280 2260
2280 2260 2242
2242
M.2_2(SOCKET3)
M.2_2(SOCKET3)
PCIE SATA IRST
X4 X V
M.2_1(SOCKET3)
PCIE SATA IRST
X4 XV
M.2_1(SOCKET3)
DDR4 DIMM_B2* (64bit,288-pin module) DDR4 DIMM_A1 (64bit, 288-pin module) DDR4 DIMM_A2* (64bit, 288-pin module)
AUDIO
KBMS
DP_12
LAN_USB78
U32G1_34
U32G1_12
128Mb
BIOS
SATA6G_6 SATA6G_5
SATA6G_4
SATA6G_1SATA6G_2SATA6G_3
HDMI
VGA
COM1 COM2
65 1 24
19749 615 14 101213
5
7
8
17
11
3
4
16
18

1-2 Chapter 1: Product introduction
1.2.1 Layout contents
1. CPU socket
The motherboard comes with a surface mount Intel®SocketLGA1200designedfor10th Gen
Intel® CoreTM,Pentium®Gold and Celeron®Processors.
Formoredetails,refertoCentral Processing Unit (CPU).
2. DDR4 DIMM slots
The motherboard comes with Dual Inline Memory Modules (DIMM) slots designed for DDR4
(Double Data Rate 4) memory modules.
Formoredetails,refertoSystem memory.
3. Expansion slots
ThismotherboardsupportsonePCIe3.0x16graphicscardandtwoPCIe3.0x1network
cards,SCSIcardsandothercardsthatcomplywiththePCIExpressspecication.ThePCI
slotsupportscardssuchasaLANcard,SCSIcard,USBcard,andothercardsthatcomply
withPCIspecications.
4. Fan headers
The Fan headers allow you to connect fans to cool the
system.
5. Power connectors
ThesePowerconnectorsallowyoutoconnectyourmotherboardtoapowersupply.The
powersupplyplugsaredesignedtotinonlyoneorientation.Findtheproperorientationand
pushdownrmlyuntilthepowersupplyplugsarefullyinserted.
Ensuretoconnectthe8-pinpowerplug.
• Forafullyconguredsystem,werecommendthatyouuseapowersupplyunit
(PSU)thatcomplieswithATX12VSpecication2.0(orlaterversion)andprovidesa
minimumpowerof350W.
• WerecommendthatyouuseaPSUwithahigherpoweroutputwhenconguringa
systemwithmorepower-consumingdevices.Thesystemmaybecomeunstableor
may not boot up if the power is inadequate.
• Ifyouareuncertainabouttheminimumpowersupplyrequirementforyoursystem,we
recommendyoutorefertoonlineresourcesforPowerSupplyWattageCalculator.
6. M.2 Slots (Key M)
TheM.2slotsallowyoutoinstallM.2devicessuchasM.2SSDmodules.
• M.2_1slot(KeyM),type2242/2260/2280(supportsPCIe3.0x4&SATAmodes).
• M.2_2slot(KeyM),type2242/2260/2280(supportsPCIe3.0x4mode).
• M.2slotssupportdatatransferspeedsupto32Gb/s.
• M.2_2slotsupportsIRST(Intel®Rapid Storage Technology).
• WhenadeviceinSATAmodeisinstalledontheM.2_1slot,SATA6G_1portcannot
be used.
FAN PWM
FAN IN
FAN PWR
GND
FAN PWM
FAN IN
FAN PWR
GND
GND
FAN PWR
FAN IN
FAN PWM

ASUS Pro B460M-C 1-3
7. SATA 6Gb/s ports
TheSATA6Gb/sportsallowyoutoconnectSATAdevicessuchasopticaldiscdrivesand
harddiskdrivesviaaSATAcable.
8. USB 3.2 Gen 1 header
TheUSB3.2Gen1headerallowsyoutoconnectaUSB3.2Gen1
moduleforadditionalUSB3.2Gen1ports.TheUSB3.2Gen1header
providesdatatransferspeedsofupto5Gb/s.
TheUSB3.2Gen1moduleispurchasedseparately.
9. USB 2.0 headers
TheUSB2.0headersallowyoutoconnectaUSBmoduleforadditionalUSB
2.0ports.TheUSB2.0headersprovidedatatransferspeedsofupto480Mb/s
connection speed.
DONOTconnecta1394cabletotheUSBconnectors.Doingsowill
damage the motherboard!
TheUSB2.0moduleispurchasedseparately.
10. Clear CMOS header
ThisheaderallowsyoutocleartheCMOSRTCRAMdataofthesystemsetupinformation
suchasdate,time,andsystempasswords.
To erase the RTC RAM:
1. Turn OFF the computer and unplug the power cord.
 2. Useametalobjectsuchasascrewdrivertoshortthetwopins.
 3. PlugthepowercordandturnONthecomputer.
4. Hold down the <Del>keyduringthebootprocessandenterBIOSsetuptore-
enter data.
Ifthestepsabovedonothelp,removetheonboardbatteryandshortthetwopinsagainto
cleartheCMOSRTCRAMdata.AfterclearingtheCMOS,reinstallthebattery.
11. Chassis intrusion header
This header is for a chassis-mounted intrusion detection sensor or switch. Connect one end
of the chassis intrusion sensor or switch cable to this header. The chassis
intrusionsensororswitchsendsahigh-levelsignaltothisheaderwhena
chassiscomponentisremovedorreplaced.Thesignalisthengeneratedasa
chassisintrusionevent.
USB+5V USB_P11- USB_P11+ GND NC
USB+5V
USB_P12-
USB_P12+
GND
PIN 1
CLRTC
+3V_BAT GND
PIN 1
USB3+5V
IntA_P5_SSRX-
IntA_P5_SSRX+
GND
IntA_P5_SSTX-
IntA_P5_SSTX+
GND
IntA_P5_D-
IntA_P5_D+
GND
PIN 1
USB3+5V
IntA_P6_SSRX-
IntA_P6_SSRX+
GND
IntA_P6_SSTX-
IntA_P6_SSTX+
GND
IntA_P6_D-
IntA_P6_D+
+5VSB_MB Chassis Signal GND
CHASSIS

1-4 Chapter 1: Product introduction
12. COM Port headers
These headers are for serial (COM) ports. Connect the serial port module
cablestotheseheaders,theninstallthemodulestoslotopeningsattheback
of the system chassis.
13. Front panel audio header
Thisheaderisforachassis-mountedfrontpanelaudioI/Omodulethat
supports HD audio standard. Connect one end of the front panel audio
I/Omodulecabletothisheader.
• Werecommendthatyouconnectahigh-denitionfrontpanel
audiomoduletothisheadertoavailofthemotherboard’shigh-
denitionaudiocapability.
• Ifyouwanttoconnectahigh-denitionfrontpanelaudio
moduletothisheader,settheFrontPanelTypeiteminthe
BIOSsetupto[HDAudio].Bydefault,thisheaderissetto[HD
Audio].
14. LPC Debug header
ThisheaderallowsconnectiontoaLPCDebugcard.
• ScantheQRcodetoviewthemeaningof
each debugging code.
• Debuggingcodesareonlyavailablefor
ASUSLPCDebugcards.
• Contactyourregionsalesrepresentative
forLPCDebugcardsordering.
15. LPT header
TheLPT(LinePrintingTerminal)headersupportsdevicessuchas
aprinter.LPTstandardizesasIEEE1284,whichistheparallelport
interfaceonIBMPC-compatiblecomputers.
16. Mono-out header
ThisinternalMono-outheaderallowsconnectiontoaninternal,lowpower
speaker for basic system sound capability. The subsystem is capable of
drivingaspeakerloadof3WattsRMSat4Ohms.
17. Speaker header
The 4-pin header is for the chassis-mounted system warning speaker. The
speaker allows you to hear system beeps and warnings.
AAFP
AGND NC SENSE1_RETUR SENSE2_RETUR
PORT1 L
PORT1 R PORT2 R
SENSE_SEND
PORT2 L
HD-audio-compliant
pin definition
PIN 1
COM
DCD
TXD
GND
RTS
RI
RXD
DTR
DSR
CTS
PIN 1
O_LPT_XSTB#_R
O_LPT_XPD0_R O_LPT_XPD1_R O_LPT_XPD2_R O_LPT_XPD3_R O_LPT_XPD4_R O_LPT_XPD5_R O_LPT_XPD6_R O_LPT_XPD7_R O_LPT_ACK#_R
O_LPT_BUSY_R
O_LPT_PE_R
O_LPT_SLCT_R
O_LPT_XAFD#_R O_LPT_ERROR#_R O_LPT_XINIT#_R O_LPT_XSLIN#_R GND GND GND GND GND GND GND GND
PIN 1
+3V +3V CK_24M_LPC GND
S_LAD0 S_LAD1 S_LAD2 S_LAD3
S_LFRAME#
LPC_DEBUG
R_OUT-
R_OUT+
PIN 1
MONO-OUT
+5V GND GND Speaker Out
SPEAKER
PIN 1

ASUS Pro B460M-C 1-5
18. SPI TPM header
ThisheadersupportsaTrustedPlatformModule(TPM)systemwitha
SerialPeripheralInterface(SPI),allowingyoutosecurelystorekeys,digital
certicates,passwords,anddata.ATPMsystemalsohelpsenhance
networksecurity,protectsdigitalidentities,andensuresplatformintegrity.
19. 10-1 pin System panel header
Thisheadersupportsseveralchassis-mountedfunctions.
• SystempowerLED(2-pinPWR_LED)
This2-pinheaderisforthesystempowerLED.Connectthechassis
powerLEDcabletothisheader.ThesystempowerLEDlightsup
whenyouturnonthesystempower,andblinkswhenthesystemisin
sleep mode.
• HarddiskdriveactivityLED(2-pinHDD_LED)
This2-pinheaderisfortheHDDActivityLED.ConnecttheHDD
ActivityLEDcabletothisheader.TheHDDLEDlightsuporasheswhendataisread
from or written to the HDD.
• ATXpowerbutton/soft-offbutton(2-pinPWR_BTN)
This header is for the system power button.
• Resetbutton(2-pinRESET)
This 2-pin header is for the chassis-mounted reset button for system reboot without
turning off the system power.
TPM
PIN 1
T_SPI_MOSI
T_SPI_CLK
GND
F_BIOS_WP#_R
S_SPI_TPM_CS2#
S_SPI_TPM_IRQ#
F_SPI_HOLD#_R T_SPI_MISO F_SPI_CS0#_R +3V_SPI NC S_PLTRST# VCCSPI
PIN 1
PWR BTN
PWR_LED+ PWR_LED- PWR GND
HDD_LED+
HDD_LED-
Ground
HWRST#
(NC)
F_PANEL
+PWR LED
+HDD_LED RESET

1-6 Chapter 1: Product introduction
1.2.2 Rear panel connectors
Ethernet port
Speed
LED
Activity Link
LED
Activity/Link LED Speed LED
Status Description Status Description
Off Nolink OFF 10Mbpsconnection
Orange Linked ORANGE 100Mbpsconnection
Orange(Blinking) Dataactivity GREEN 1Gbps connection
Orange(Blinking
then steady)
Ready to wake
upfromS5mode
1 2
7 10 11
3 4 5 6
98
1. PS/2 Mouse (green) port.ThisportisforaPS/2mouse.
2. Video Graphics Adapter (VGA) port.This15-pinportisforaVGAmonitororother
VGA-compatibledevices.
3. USB 3.2 Gen 1 (up to 5Gbps) ports.These9-pinUniversalSerialBus(USB)ports
connecttoUSB3.2Gen1devices.
4. Ethernet port.ThisportallowsGigabitconnectiontoaLocalAreaNetwork(LAN)
throughanetworkhub.RefertothetablebelowfortheEthernetportLEDindications.
Ethernet port LED indications
5. Line In port (light blue).Thisportconnectsthetape,CD,DVDplayer,orotheraudio
sources.
6. Line Out port (lime).Thisportconnectsaheadphoneoraspeaker.In4-channel,
5.1-channel,and7.1-channelcongurations,thefunctionofthisportbecomesFront
Speaker Out.
7. PS/2 keyboard (purple) port.ThisportisforaPS/2keyboard.
8. DisplayPorts.TheseportsareforDisplayPort-compatibledevices.
9. HDMITM port.ThisportisforaHigh-DenitionMultimediaInterface(HDMITM)
connector,andisHDCPcompliantallowingplaybackofHDDVD,Blu-ray,andother
protected content.
10. USB 2.0 ports.These4-pinUniversalSerialBus(USB)portsareforUSB2.0devices.

ASUS Pro B460M-C 1-7
11. Microphone port (pink). This port connects a microphone.
Refertotheaudiocongurationtableonthenextpageforthefunctionoftheaudioportsin
2,4,5.1,or7.1-channelconguration.
Audio 2, 4, 5.1 or 7.1-channel configuration
Port Headset
2-channel 4-channel 5.1-channel 7.1-channel
LightBlue
(Rear panel) Line In Rear Speaker Out Rear Speaker Out Rear Speaker Out
Lime (Rear panel) Line Out Front Speaker Out Front Speaker Out Front Speaker Out
Pink(Rearpanel) Mic In Mic In Bass/Center Bass/Center
Lime (Front panel) — — — Side Speaker Out
To configure a 7.1-channel audio output:
 AchassiswithanHDaudiomoduleinthefrontpanelisrequiredtosupport
7.1-channelaudiooutput.

1-8 Chapter 1: Product introduction
1.3 Central Processing Unit (CPU)
This motherboard comes with a surface mount Intel® SocketLGA1200
designedfor10th Gen Intel®Core™,Pentium®Gold and Celeron®
Processors.
UnplugallpowercablesbeforeinstallingtheCPU.
• EnsurethatyouinstallthecorrectCPUdesignedfortheLGA1200socketonly.DO
NOTinstallaCPUdesignedforLGA1150,LGA1151,LGA1155andLGA1156sockets
ontheLGA1200socket.
• Uponpurchaseofthemotherboard,ensurethatthePnPcapisonthesocketand
thesocketcontactsarenotbent.ContactyourretailerimmediatelyifthePnPcap
ismissing,orifyouseeanydamagetothePnPcap/socketcontacts/motherboard
components.
• Keepthecapafterinstallingthemotherboard.ASUSwillprocessReturnMerchandise
Authorization(RMA)requestsonlyifthemotherboardcomeswiththecaponthe
LGA1200socket.
• Theproductwarrantydoesnotcoverdamagetothesocketcontactsresultingfrom
incorrectCPUinstallation/removal,ormisplacement/loss/incorrectremovalofthePnP
cap.
• TheCPUtsinonlyonecorrectorientation.DONOTforcetheCPUintothesocketto
preventbendingtheconnectorsonthesocketanddamagingtheCPU.
• EnsurethatallpowercablesareunpluggedbeforeinstallingtheCPU.
Installing the CPU
1
4
ApplytheThermalInterfaceMaterialtotheCPUheatsinkandCPUbeforeyouinstallthe
heatsink and fan if necessary.
2
3
A
B
A
B
C
D
5
4
4
5

ASUS Pro B460M-C 1-9
1.4 System memory
This motherboard comes with four Double Data Rate 4 (DDR4) Dual Inline Memory Module
(DIMM)sockets.ThegureillustratesthelocationoftheDDR4DIMMsockets:
Channel Sockets
ChannelA DIMM_A1&DIMM_A2*
ChannelB DIMM_B1&DIMM_B2*
DIMM_B1
DIMM_B2*
DIMM_A1
DIMM_A2*
• YoumayinstallvaryingmemorysizesinChannelAandChannelB.Thesystem
mapsthetotalsizeofthelower-sizedchannelforthedual-channelconguration.Any
excessmemoryfromthehigher-sizedchannelisthenmappedforsingle-channel
operation.
• AlwaysinstallDIMMswiththesameCASlatency.Foroptimalcompatibility,we
recommendthatyouinstallmemorymodulesofthesameversionordatecode(D/C)
fromthesamevendor.Checkwiththeretailertogetthecorrectmemorymodules.
• For10th Gen Intel®processors,onlyCore™i9/i7CPUssupport2933/2800/2666/2400/
2133natively,otherswillrunatthemaximumtransferrateofDDR42666MHz.
• ADDR4memorymoduleisnotcheddifferentlyfromaDDR,DDR2,orDDR3module.
DONOTinstallaDDR,DDR2,orDDR3memorymoduletotheDDR4slot.
• ThedefaultmemoryoperationfrequencyisdependentonitsSerialPresenceDetect
(SPD),whichisthestandardwayofaccessinginformationfromamemorymodule.
Underthedefaultstate,somememorymodulesforoverclockingmayoperateata
lowerfrequencythanthevendor-markedvalue.
• Forsystemstability,useamoreefcientmemorycoolingsystemtosupportafull
memory load (4 DIMMs).
• Refertowww.asus.comforthelatestMemoryQVL(QualiedVendorsList).
Recommended memory configurations
DIMM_A2*
DIMM_B1
DIMM_B2*
DIMM_A2*
DIMM_B2*
DIMM_A1
DIMM_A2*

1-10 Chapter 1: Product introduction
Installing a DIMM
1 2
B
A
A
To remove a DIMM
B
A
