ASUSTOR ASW205T User manual

Switch’nstor | ASW205T
5 port 2.5GBASE-T unmanaged Ethernet switch
Quick Installation Guide
Adapter x4
Type A
Type C
Type I
Type G
AC adapter Foot pads Quick Installation Guide
Screws
Anchors
AC adapter
AC adapter comes with four adapters that cover a wide variety of countries.
To install, press the socket adapter and rotate.
Diagrams are also located on the AC adapter.
To remove, press the latch and rotate socket adapter counter clockwise.
Separate the socket adapter from the AC adapter.
Latch
Package Contents

Wall Mounting Instructions
Drill two 6 mm holes into a wall spaced 110 mm apart. (FIGURE 1).
Hammer an anchor into each hole. (FIGURE 2).
Tighten screws into the anchors, leaving 5 mm exposed. (FIGURE 3).
FIGURE 1
3
1
2
FIGURE 2 FIGURE 3
140.0
92.0
3.5
110.0
Mounting holes
Align the mounting holes with the screws and hang it on the wall.
（FIGURE 4).
FIGURE 4
4
PC
NAS
Connecting Power
AC adapter
Left LED Right LED Power LED
LED Indicators
#
Power LED
Left LED
Right LED
Color
Green
Green
Orange
Yellow
Description
Power On
Connected at 2.5-Gigabit speeds
Connected at Gigabit speeds
Blinking: Transferring data.
On: Working as intended.
Specifications
Supported speeds
Authorized representative in Europe: Asustor B.V .
Address: Ambachtweg 37, 2841 MB Moordrecht, Netherlands
Chipset
Input voltage range
Dimension
Operating environment
2.5-Gigabit Unmanaged Ethernet Switch
10M/100M/1G/2.5G
DC：12V 2A
92（L）x 140 （W）x 28（H）mm
Description
RTL8371+RTL8221B
Operating Temperature : 0°C-40°C (32-104°F)
Operating Humidity : < 85% No condensation
Non-Operating Temperature: -10°C-85°C (14-176°F)
Off Connected at 10M or 100M
speeds
