ASUSTOR AS5010T User manual

A network storage server
offering immense storage
capacity and optimal value
The AS5010T was designed specically to meet
high capacity storage needs. It oers a substantial
total storage capacity of up to 60TB, providing
super fast performance at an cost-eective price
point.
AS5010T

Seamless Cross-Platform File Sharing
ASUSTOR NAS devices provide seamless cross-platform le
sharing, allowing you to easily connect to your NAS device
no matter if you are using Windows, Mac OS, or Unix-like
operating systems. The transfer protocols that you may
use to connect to an ASUSTOR NAS device are as follows:
Windows: CIFS/SMB, FTP and WebDAV
Mac OS X: AFP, SMB, NFS, FTP and WebDAV
Linux: NFS, SMB, FTP and WebDAV
Additionally, ASUSTOR NAS devices feature our Network
Recycle Bin. Any les you delete will be moved to the
Recycle Bin, allowing you to restore any accidentally
deleted les. Transfer protocols supported by the Recycle
Bin include: CIFS/SMB, AFP, FTP and File Explorer.
High performance technology
An Intel Celeron 2.41GHz dual-core processor and 1GB
DDR3L memory, provide premium, energy ecient processing
power. With read/write speeds of up to 112 MB/s, the AS50
series’excellent performance is sure to satisfy your storage
application needs.Furthermore, when AS50 series devices
need more computing power, they can increase the CPU
computing power from the original 2.41 GHz to 2.58 GHz,
providing a smooth and seamless experience.
*Performance results may dier depending on the testing
environment.
Eortlessly upgrade memory
Depending on your usage preferences, you can decide
whether or not you want to upgrade memory. AS50/51
devices provide users with the ability to exibly upgrade
memory so there is no need to worry about the memory
before you purchasing the device. When upgrading memory,
you simply need to remove the cover of the NAS to do it
(There are 2 expansion memory slots in total. Memory can
be expanded up to a maximum of 8GB.), letting you easily
improve system performance and allowing your NAS to
simultaneously run more Apps.
ASUSTOR AS5010T

Metallic design
Dierent from other NAS devices on the market which
feature plastic cases and suboptimal cooling, the AS50/51
devices feature aluminum casing along with a rust and
corrosion resistant coating which combines with the
metallic hard disk trays to fully make use of the natural
cooling properties of metal. This signicantly enhances
the entire cooling ability of the system.
Connect with a new generation of
I/O technology for limitless possibilities
A professional grade NAS needs to be equipped with a
diverse array of expansion functionality. ASUSTOR has
built in USB 3.0, USB 2.0, eSATA, gigabit Ethernet and
HDMI 1.4a ports along with a high delity audio
S/PDIF port, allowing the NAS to connect to dierent
types of external devices and not be limited to its
internal capacity. ASUSTOR NAS redenes the
meaning of exibility and expandability in network
storage.
High Quality Audio Output with S/PDIF
The built-in dual Ethernet ports combined with the link
aggregation function, allows your NAS to maintain its
connection even if one of your Ethernet connections fail,
signicantly decreasing the likelihood of unexpected
disconnections. Additionally, link aggregation provides
faster transfer speeds than a single connection could, along
with load balancing which automatically balances network
trac load across the two connections, making it the optimal
choice for users who require high speed reliability.
4 times the network speed and increased reliability
The built-in quad Ethernet ports combined with the link aggregation function, allows your NAS to maintain its connection
even if one of your Ethernet connections fail, signicantly decreasing the likelihood of unexpected disconnections.
Additionally, link aggregation provides faster transfer speeds than a single connection could, along with load balancing which
automatically balances network trac load across the two connections, making it the optimal choice for users who require
high speed reliability.

Create the Ultimate
Home Multimedia Center
Enjoy electrifying digital entertainment on demand with
ASUSTOR NAS. The built-in HDMI interface and variety of
multimedia Apps let you to enjoy all of your favorite
multimedia from your NAS by directly connecting it to an
LCD/LED TV or amplier.
AS5002T supports Full HD (1080p) output, allowing you to
savor your movies, TV shows, music and photos in high
denition. What's more, through ASUSTOR's App Central,
you can install additional multimedia server Apps such as
UPnP Media Server and iTunes Server giving your NAS the
ability to stream multimedia content to your computers,
TVs and mobile devices.
Additionally, you can also further add a surround sound
amplier to create an unprecedented high denition
multi-channel listening experience. Imagine watching your
favorite racing movie and being immersed in the roar of the
engines. Feel the thrill and the sense of speed as you listen
to the sounds of cars whizzing by. Prepare for an unparalleled
entertainment experience that will have you on the edge
of your seat.
A Surge in Data Transfer Performance
ADM 2.3 supports SMB 2.0 which reduces the burden of network trac on the NAS while simultaneously providing greater data
transfer capacity. In the ASUSTOR testing environment, SMB 2.0 was found to increase Windows networking performance by
30%-50%*. SMB 2.0 also signicantly increases the number of concurrent Windows client connections and simultaneously open
les, making ADM 2.3 even more suitable for large-scale Microsoft network environments.
* Actual performance may vary due to dierences in the installation environment. SMB 2.0 is supported in Windows Vista and
later versions of the Microsoft Windows operating system.
The ultimate tool for remote backup
Rsync is an application originally developed for UNIX that is usually used for backup and sync between two computers. By
providing block level replication, Rsync is able to oer incremental backup. Incremental backup allows for successive backup
jobs (after your rst backup job) to only copy data that has changed since your last backup job. Rsync is suitable for use with les
and data that are always changing. It lets you cut down on backup time while signicantly reducing bandwidth usage.

A rich and exible backup solution
ASUSTOR's Rsync Backup function supports two-way data
transfers, incremental backup, encrypted backup and also
the scheduling of your NAS to perform regular backup jobs.
It eectively simplies data backup while also substantially
reducing the burden on IT sta. ASUSTOR's Rsync backup
function may be used to complete tasks such as:
- The transfer or backup of data from your NAS to an Rsync
compatible server
- Initiating downloads of the data from an Rsync compatible
server to your NAS
Create a hybrid cloud, protect and
secure your data
Now home and business users alike can back up the data
from their ASUSTOR NAS to popular cloud storage services,
including Amazon S3, Google Drive, HiDrive, Dropbox,
further ensuring the protection of their data. This means
that in the event that the data on your NAS is damaged you
will be able to immediately restore it from cloud storages.
Regular backups of your vital data
The External backup function supports two-way data
transfers, incremental backups and also the scheduling of
your NAS to perform regular backup jobs. It may be used
to complete tasks such as:
- The transfer or backup of the data from your NAS to an
external device.
- Initializing the copying of data from an external device to
your NAS
Windows Backup
ASUSTOR's Backup Plan software for Windows provides
you with worry-free backup. Simply schedule a regular
backup job of your PC to your NAS, then let Backup Plan
take care of the rest. Backup Plan will work in the background
to ensure that your PC is always backed up.
Any data that is lost between scheduled backups is
unprotected. Backup Plan lets you congure real time le
synchronization for those important and ever-changing le
folders. Any changes that you make to your protected les
and folder will be updated in real time. Now you can rest
assured knowing that your critical les are always protected
and up to date.
Time Machine Backup
Mac lovers rejoice! You can use your Mac's built-in backup,
Time Machine, to easily back up your Mac to an ASUSTOR
NAS. All ASUSTOR NAS devices have been optimized for use
with Time Machine, providing Mac lovers with a familiar and
easy to use backup solution.
Dierent Mac users can now safely backup their computers
to the same NAS device. Unlike other NAS devices, ASUSTOR
NAS does not just use one group account to carry out backup
jobs for all Mac users, storing all their jobs under the same
directory. With ASUSTOR NAS each Mac user is able to use
an independent account and backup location thereby
guaranteeing privacy for all.
Mission Mode
Never again worry about your critical backup jobs stopping or
failing to complete because your ASUSTOR NAS won't stop
until it’s “mission complete”. Sometimes backup jobs may
be stopped because of various connection problems with
a busy server on the other end. For Rsync, FTP, external and
cloud backups, ASUSTOR’s Mission Mode allows you to
congure the number of connection attempts and time
interval for connection attempts, ensuring for the successful
completion of your backup mission. This also gives IT
administrators a signicant amount of exibility when
conguring backup jobs.

NAS hard disks on the go
The MyArchive function allows you to use hard disks as
removable storage archives. Plug in an archive when you
need it and swap it out for a dierent archive when you
don't. Enjoy "plug and play" convenience as you swap
between dierent data collections. Furthermore, the
MyArchive function helps you to save power as the archives
you are not using can be taken out for storage and do not
always have to be powered on.
Your own FTP server
FTP is one of the most widely used and popular transfer
protocols in the world. Every ASUSTOR NAS has a built-in
FTP server feature that allows you to create a personal FTP
server in just a matter of seconds. Hosting your own FTP
server will instantly give you the power to share and exchange
les over the internet.
With FTP server, you will be able to access your NAS via FTP
from almost anywhere in the world. No matter if you are on
a business trip or vacation, or wish to share les with family
and friends, all that's needed is a device with internet access
and the data on your NAS can be accessed in no time.
Create a hybrid cloud, protect and
secure your data
System Notications
Always checking up on your NAS? Worried about your data and other digital assets? ASUSTOR NAS features real-time system
event notications allowing you to enjoy peace of mind knowing that you'll be notied about any major system events.
Notications can be sent via Email, SMS or push notication giving you a variety of ways to instantly stay on top of the latest
developments.
Firewall
Use ADM Defender's rewall to control access to your NAS.
Ensure the security of your system by deciding who has
access to your NAS and who doesn't.
Network Defender
ADM Defender's Network Defender function protects you
from malicious attacks and prevents hackers from trying to
access your NAS. Any client IP addresses with too many
unsuccessful login attempts to your NAS within a specied
time period will be blocked by Network Defender.
Data Archive
Plug & Play Data Access
Secure connections – VPN
ASUSTOR NAS supports VPN connections giving you secure access and exible deployment options. Your NAS is able to act as
a VPN client which can then connect to VPN servers via PPTP or OpenVPN protocols, allowing you to gain access to dierent
virtual private networks. ASUSTOR NAS also supports the creation of multiple VPN connection proles allowing you to easily
switch connections between dierent VPN networks.

After connecting an external optical drive (CD, DVD, Blu-ray) to your NAS via USB, you can use File Explorer to directly access any
les that you have backed up to optical media and even transfer les from your optical media to your NAS via drag and drop for
future access.
Note:
This function only provides data access and does not support the audio and video playback of optical media.
Certain optical drives will require additional power in order to operate properly. If you nd that your optical drive is not spinning
or reading correctly, please use a USB Y-cable to add additional power.
External Optical Drive Support
Virtual Drive
Still wasting money and time burning CDs or DVDs every
time you need to install some software? ASUSTOR NAS
supports the mounting of ISO les which provides you
with a cost eective and environmentally friendly solution
that eectively lowers CD and DVD waste.
Folder-based AES 256-bit Encryption
Your most important data deserves the best security. ASUSTOR
NAS oers folder based military grade AES 256-bit encryption,
giving you the type of security and privacy that you require
for your most condential data. All data stored in encrypted
folders will be automatically encrypted and secured to the
highest of standards. Should you ever lose your NAS or hard
disks, you still needn't worry about your sensitive data falling
into the wrong hands.
Unlike other NAS devices, ASUSTOR NAS gives you the
exibility to select the individual folders that you want to
encrypt. Other NAS devices encrypt entire storage volumes
which signicantly slows down the system. Any encrypted
portions of storage volumes will be subject to a decrease in
performance. However, with ASUSTOR NAS you are free to
encrypt only your most condential data while leaving other
data unencrypted, creating a perfect balance between
performance and security.
Video Surveillance
Worried about leaving your home unattended? Keep an
eye on the most important things with Surveillance Center.
Surveillance Center's fully optimized interface allows you
to simultaneously view live feeds from up to 4 IP cameras,
take snapshots and control the pan tilt and zoom functions
of all cameras giving you complete peace of mind.
Virtualization
iSCSI and NFS are primary datastore solutions for virtual
environments and are also important in spreading the use
of virtualization as a whole. When compared with other
storage mediums, ASUSTOR NAS can oer an optimal
price/performance ratio and value which is of particular
importance to small and medium businesses.
ASUSTOR understand that stable and high performing
shared storage is a must for virtual environments. iSCSI and
NFS support on the ASUSTOR NAS allows you to seamlessly
integrate with any existing IT environments. All ASUSTOR
NAS devices are veried as VMware, Citrix and Hyper-V ready,
providing you with a exible and cost-ecient virtual
storage solution.

Recording & Playback
ASUSTOR's Surveillance Center comes with 4 license free channels letting you to setup 4 dierent network IP cameras. This
signicantly lowers startup costs for your surveillance system. No matter if you prefer to use Microsoft Internet Explorer, Mozilla
Firefox or Google Chrome, Surveillance Center's easy-to-use browser based interface and quick start wizard will allow you to
create a security surveillance system in a snap.
Surveillance Center oers you a variety of recording options. No matter if you need scheduled continuous recording or recording
only when certain events occur, Surveillance Center is sure to satisfy your needs. Surveillance Center's various recording modes
are listed below:
- Manual Recording: While viewing a live feed, you can click on the record button at any time to begin or stop recording. In the
event that you do not stop your recording, Surveillance Center will record until your designated recording quota has been reached.
- Continuous or Scheduled Recording: Whether you require 24/7 continuous recording or recording only during a specic time,
Surveillance Center can get the job done ensuring that you never miss any critical moments.
- Motion Trigger Recording: In the event that any motion is detected in the surveilled environment, Surveillance Center will
immediately begin recording, allowing you to save signicant space on your hard disks and ensuring that you never miss any
critical moments.
- Alarm Trigger Recording: Triggering recording via a camera's alarm mechanism allows you to precisely record all critical events.
Not only does this save space on your hard disks but also lowers the amount of reading and writing on your hard disks, prolonging
their life.
- Motion Trigger and Alarm Trigger Recording: This mode combines motion trigger and alarm trigger recording. If either mode
is triggered, recording will begin immediately. This is a comprehensive recording mode that ensures you will never miss any
critical moments.
* Surveillance Center comes with 4 free IP camera channel licenses, which is higher than the industry standard. Users can also
purchase add-on camera licenses to exibly add new camera channels.
* Two dierent camera license packages are oered: single channel and 4 channels. Currently, AS50 series can be expanded up
to a maximum of 12 channels.
* The maximum number of cameras is based on the test results for each channel using 720P (1280x720), 30 FPS and H.264.
Actual performance may vary due to camera settings and NAS load.
App Central
The applications that come pre-installed with each ASUSTOR
NAS device are just the beginning. At your convenience, you
can browse through and download any applications that
peak your interest from App Central. App Central allows you
to explore the unlimited potential of ASUSTOR NAS devices
while creating a personalized NAS device for yourself.
The NAS That's Always With You
ASUSTOR oers multiple mobile apps that give you convenient access to your NAS while on the go.
AiMaster
AiFotoAiSecureAiVideos
AiRemoteAiDownloadAiMusic
AiData
Your NAS multimedia player remote: AiRemote
What would a home entertainment center be without a remote control?
AiRemote is a mobile app that turns your mobile device into a remote control for Boxee on ASUSTOR NAS. Now you can operate
Boxee wirelessly and access all the media content on your NAS from the comfort of your couch. All that's left to do is to sit back,
relax and enjoy the show.

Bring you the smoothest mobile video viewing experience around: AiVideos
The AiVideos allows you to browse through the video collection on NAS without needing to wait for long downloads. Enjoy
high-denition 1080p streaming video with just one click. You can even select multilingual subtitles and dierent audio channels
to enjoy lms in dierent languages, bringing the movie theatre to your mobile device.
The concise and rened interface guides you with two major functions. Media Explorer allows you to browse through and search
for multimedia les on your NAS using a familiar directory structure, making everything intuitive and easy. TV Recordings allow
you to view les that appear as thumbnails with le names, allowing you to easily nd the programs that you want to view with
just one glance. Clicking on programs will allow you to instantly play high denition programs via your Web browser! You can
also use the Favorites, Recently Watched and Recently Added options to help you search for programs.
Get access to your data in the cloud and on your NAS from the convenience of your mobile device with ASUSTOR's AiData mobile
app. With its intuitive interface and incorporation of well-known cloud storage services, AiData allows you to manage all the les
on your NAS and across the cloud.
AiData features a host of convenient features to enrich your digital lifestyle. Use your mobile device to rename, copy, move or
delete data on your NAS. Save items as favorites for quick oine browsing while on the go or upload your photos directly from
your phone to your NAS. Have a le on your NAS that you want to share? Instantly email download links to your friends and family.
AiData's features truly let you take advantage of your personal cloud.
You can download data from your NAS to any folder on your Android device or upload les from folders on your Android device
to your NAS. Now, data on your NAS and the rich variety of apps on your mobile devices can be more closely integrated than ever
before.
When browsing through the substantial amount of data on your NAS, you can choose to list les in ascending or descending order
according to lename, size or date modied, giving you better organization when managing les.
Worried about losing your phone and accidentally giving someone full access to all the data on your NAS? Passcode protection
is your rst line of defense. When using passcode protection, you will need to enter a correct passcode before being able to use
an ASUSTOR mobile app. This signicantly enhances mobile privacy while ensuring that you won’t have to worry about accidentally
giving someone access to your NAS.
Cloud data access from anywhere: AiData
The most intuitive way to browse through your photos: AiFoto
AiFoto presents each photo using rened thumbnail previews. Eortlessly browse through all
your favorite memories stored on your NAS with just the swipe of a nger.
The automatic camera roll upload function ensures that you will never have to worry about
how to backup your photos. Let AiFoto automatically take care of your backup needs! You can
also open an online album and take photos that will be automatically uploaded to the album,
giving you easy organization of your photos.
People will always be curious. Protect your privacy with password encrypted oine albums to
create a private space that belongs to you and you alone.
The AiSecure dedicated mobile app allows you to easily keep an eye on everything that is happening at home. In addition to
monitoring live views of particular locations, AiSecure also features instant push notications that can be sent to your mobile
device when specied events occur, allowing you to grasp all the latest developments in the palm of your hand.
AiSecure dramatically simplies the connection process to your surveillance feeds. After enabling Cloud Connect on your NAS,
you will be able to use your dedicated Cloud ID to connect to Surveillance Center, allowing you to easily monitor all the important
things in your life from any corner of the world.
Stay Connected to Everything You Care About: AiSecure

Imagine the convenience of searching and downloading while on the go and then having your downloads ready on your NAS
as soon as you get home. With ASUSTOR's AiDownload app, all this is possible and more. AiDownload is a mobile app that
interfaces with ASUSTOR's Download Center to provide you with mobile download management. No matter if it's searching,
downloading, conguring settings or monitoring, you can do it all with AiDownload.
AiDownload includes a push notication feature that alerts you when downloads have been completed. Now you are free to
concentrate on your more important tasks knowing that you will be notied as soon as your downloads are nished.
AiMusic allows you to stream music from your NAS to your mobile device, letting you enjoy your entire music collection while
on the go.
Play music from playlists that you create yourself for an optimal listening experience. Like listening to random songs? AiMusic's
Random songs play mode is your best friend! You need only select it once to create a random playlist from your entire music
collection, allowing you to enjoy a new listening experience each and every time.
AiMusic also allows you to download songs from your NAS to your mobile device for oine listening. No matter if it is is a single
song, an album or an entire playlist, all can be easily downloaded to your mobile device for convenient listening.
Terabytes of music in the palm of your hand - AiMusic
One stop searching and downloading: AiDownload
Hardware Specication
AS5010T
Intel Celeron 2.41GHz Dual-Core (burst to 2.58GHz)
1GB SO-DIMM DDR3L (Expandable. Max 8GB)
10 x (2.5”/3.5” SATA or SSD)
3 x USB 3.0, 2 x USB 2.0, 2 x eSATA
4
215.5(H) x 293(W) x 230(D) mm
6.3 kg / 13.89 lb
Internal Power Supply: 100-240V AC
17.4W
8.4W
74.2W (Operation)
35.2W (Disk Hibernation)
3.2W (Sleep Mode)³
1 x HDMI 1.4a
Power LED Indicator
System Status LED Indicator
Hard Disk LED Indicator
Network LED Indicator
USB LED Indicator
Processor
Memory
Internal Disk
External Device Interface
Network Gigabit Ethernet
Dimensions (HxWxD)
Weight
Power
Operation*
Disk Hibernation*
Sleep Mode (S3)*
HD Display
A.
B.
C.
D.
E.
* Test HDD: WD Red 3 TB HDD
Stay up to date with your NAS: AiMaster
AiMaster is ASUSTOR's NAS management app for mobile devices that allows you to easily
control all your NAS devices no matter if you are a home user or IT administrator.
AiMaster features real-time system event notications allowing you to monitor your system
status from the convenience of your mobile device. When certain events occur, notications
are sent to your mobile device in the form of push notications helping you stay abreast of all
the latest developments.
With AiMaster you are never far from your NAS. Manage all your services, applications, and
backup jobs at any time and from any place. Execute one touch backup jobs and monitor all
users and system status. Even use the Find Me function to locate your NAS among many. All
this is possible and more with AiMaster.
A
B
C
D
E
A
B
C
D
F
G
H
J
I
E
S/PDIF Port
eSATA Port
RJ45
RJ45 & USB 2.0 Port
RJ45 & USB 3.0 Port
HDMI Port
Reset Button
K-Lock
Power Supply
System Fan
A.
B.
C.
D.
E.
F.
G.
H.
I.
J.
