Memory Installation Guide
For ASUSTOR FS67 Series NAS
Ver. 4.2.0316

ASUSTOR NAS Memory Installation Guide
Page 2 of 7
Table of Contents
1. Introduction .........................................................................................................................................................................3
1.1. Notes and Precautions...................................................................................................................................................3
1.2. Parts and Tools Needed .................................................................................................................................................3
2. Installation Guide.................................................................................................................................................................4
2.1. Removing the Cover.......................................................................................................................................................4
2.2. Installing Memory ..........................................................................................................................................................5
2.3. Replacing the Cover .......................................................................................................................................................6
3. Appendix..............................................................................................................................................................................7
3.1. Troubleshooting.............................................................................................................................................................7
3.2. Contact ASUSTOR Technical Support.............................................................................................................................7

ASUSTOR NAS Memory Installation Guide
Page 3 of 7
1.
I
In nt tr ro od du uc ct ti io on n
1.1. Notes and Precautions
All FS67 Series NAS devices support up to 16GB of memory. Before adding or removing memory modules, please
read the following precautions thoroughly.
•Your NAS and memory modules use high precision components and electronic connector technology. To avoid
invalidation of the warranty during your product warranty period, we recommend that:
✓Memory for FS67 series devices may be purchased from local dealers or the online ASUSTOR Accessories
Store (http://shop.asustor.com).
✓You should not install a memory module by yourself, if you are not familiar with upgrading memory on a
computer.
✓You should not touch the connectors or open the memory module compartment cover.
•Addition or removal of memory modules by yourself may result in an accident or malfunction of your NAS
caused by breakage of the slot and module or a connection mistake. In this case, a repair fee will be charged.
•Be careful not to injure your hands or fingers with sharp edges of the memory module, inner components, or
circuit boards of your NAS.
•ASUSTOR does not guarantee that third party memory modules will work in your NAS.
•Be sure to turn off your NAS and peripherals and disconnect all attachments and connection cables before
adding or removing memory modules.
•To prevent damage from electrostatic discharge to memory modules, follow the instructions below:
✓Do not work at a location that produces static electricity easily, such as on a carpet.
✓Before adding or removing memory modules, touch an external metal object other than your NAS to ground
yourself and eliminate static electricity. Do not touch any metal parts inside the NAS.
•Do not insert a memory module into the slot facing in the wrong direction. It may cause damage to the module
or slot, or cause the circuit board to catch fire.
•Use a screwdriver that matches the size of the screws.
•Do not remove or loosen screws that are not specified to be removed.
1.2. Parts and Tools Needed
•Phillips head screwdriver

ASUSTOR NAS Memory Installation Guide
Page 4 of 7
2.
I
In ns st ta al ll la at ti io on n G Gu ui id de e
2.1. Removing the Cover
⚫Shutdown the NAS by selecting [Shut down] from the ADM User Menu.
⚫Disconnect all cables and devices connected to the NAS including the power cord.
FS6706T
FS6712X

ASUSTOR NAS Memory Installation Guide
Page 5 of 7
⚫Use a screwdriver to loosen the three screws found on the rear of the NAS as shown in the illustration.
FS6706T
FS6712X
⚫Grip the cover from both sides with two hands and then gently push it back to remove it from the chassis.
2.2. Installing Memory
⚫Upon opening the NAS, RAM slots can be found on the motherboard on the left hand side of the NAS. Insert a
DIMM into an empty slot at a 45° angle and align the notches of the RAM and the slot.
⚫Gently push the DIMM down until both latches click into place. RAM should be flush with the motherboard.

ASUSTOR NAS Memory Installation Guide
Page 6 of 7
2.3. Replacing the Cover
⚫Replace the cover and tighten the three screws that were removed previously.
FS6706T
FS6712X
⚫Reconnect all cables including the power cord and then start up the NAS.
FS6706T
FS6712X

ASUSTOR NAS Memory Installation Guide
Page 7 of 7
3.
A
Ap pp pe en nd di ix x
3.1. Troubleshooting
Q: After installing new memory my NAS won’t start. What’s wrong?
A: Please follow the steps below to resolve this issue:
1. Check if the LED indicators, system and buzzer are operating normally.
2. If your NAS is unable to recognize the new memory or cannot be started up properly, please check that you have
used memory that is compatible with the system. Also, please reinstall the memory in order to confirm that it has
been installed properly.
3. If your NAS still does not operate normally, please remove the newly installed memory module, and then restart
the NAS to see if it is able to operate normally.
4. If the previous steps have not solved your problem, please contact your local dealer or ASUSTOR customer service.
3.2. Contact ASUSTOR Technical Support
Contact us:
1. Online Support Form: https://member.asustor.com/
2. ASUSTOR Online Community: http://forum.asustor.com/
