ATA FHCRX Series User manual

.4,
v=
Thankyou for purchasing
the ATA FHCRX
Series
Stand
AloneReceiver.Famiiiarise
yourself
withthe following
instructions
prior
tc commencing
setup-
Stor.ethis
information in a safeplacefor future reference-
The FHCRX,
series
receivers
na!,e
reiays
on board which provide normally
open or normallyclosedcontactfor
coniroiiing
virtually
any
eiectronic
device
including
garage
doors
andgate
cpeners.
ihe relay,,
can
be programmed
to anyof threemodes- pulse,
holdor timer.
One
or both reiays
canbe programmed with any of the three modes.
BRAND
OFTRANSMITTERS
First
memory locationsets
the type of transmitters
which canbe stored into
the receivers
memory. lt either can be ATA TrioCoderM or BND Tri-TranrM
transmitters. Forexample if first transmitter stored is
TrioCoders then rest
of transmitters
can
only
be TrioCoderMtype and mixing of TrioCoderM,Tri-
TranrM
isnot possible. Bydeleting allstored transmitter codes from
receivers
memory will allow you to choose either TrioCoderv or Tri-TranrM
transm
itters
SETTING
RELAY
OPERATING
MODES
Pulse
Mode - Relay
contact isactive whilst transmitter button ispressed.
Hold Mode - Relay
changes
state at each press
of transmitter bunon. Hold,
Release,
Hold, etc. (like
an onloff switch).
Timer Mode - Relay
will remainactive for the programmed duration.thetimer is
adjustablefrom 0 seconds
to 655.34 secondsin .01second
steps
Note: Timer mode isselectable only with the ATA prograhmer. Refer
to the
Programmer's manual
for instructions
on settinq Timer mode.
RELAY-I Puise
Mode - Remove
Jpl jumper or Jo not bridge the two pins.
RELAY-1
Hold Mode - Bridge the two pins on Jp1 jumper.
RELAY-2Pulse
Mode - Remove
Jp2 jumper or do not bridge the two pins.
RELAY-2
Hold Mode - Bridge the two pins on Jp2 jumper.
UNIVERSAL
PROGRAMMER
--.'Ar|_A-iA-ltiii\rer3-a|-'Progra-hTncr can bc-ss€@0oio --
655.34 seconds),
Edit,back up /restore transmitters.
STORING
TRANSMITTER
CODE
1
' Press
and hold SWI {for Relay
1)
or sW2 (for Relay
2)on the receiverboard.
The led will start to flash
2- Press
the transmitter button you would like to use
to control the devicefor two
seconds-
The led will startto flash
faster.
3. Release
the transmitter bufton and pause
for two seconds.
press
the same
button againfor two seconds.
The led wilrstayson for second and turns off.
4. Release
SW button.
5. Pressthe transmitter button to test ooeration,
DELETING
A SINGLE
TRANSMITTER'S
CODE
1
' Press
and hold sw1 (for Relay
1)or sw2 (for Reray
2)on the receiver
board-
The led will start to flash
2. Press
the transmitter button you would liketo remove from receiversmemorv
for two seconds.
The led will start to flashfaster.
3. Release
the transmi,ter button and pausefor two seconds.press
the same
button againfor two seconds.
The led will slowlv
flash
two times
4. Release
SWbutton.
5. Pressthe transmitter button to confirm that it hasbeen removed.
DELETING
ALL
STORED
TRANSMITTER
CODES
1.
furn the poweroff to the receiver.
2. Press
andhoidSW1
button.
3 while hoiding
swi turnpower on again.After 15
seconds
the codinq LEDurill
illuminate
to indicate
thatthe receivers
memory
has
beenclear.ed.
4' Release
suJl- Allthe stored
codesshould
now be deleted.
Confirm
thisbv
pressing
the transmitters
previousiy
used
to operate
the device.
There
should
L;e
no resoonse.
PG3
CONNECTO
=-@
FHCRX-1
FHCRX-2
TrioCoderMTri_Tr-anrM

II
\l-
-
SPECIFICATIONS
Power
Supply:
12V-24V
AC or DC
Frequency:Muiti
frequency
Memory
Capacity:
250
Transmitters
Programmable
Modes:
Pulse,
Hold.
Timer"
Controlling
Outputs
(FHCRX-1):
i x Commcn
i x Ncrmaliy
Cpen
1x l.lormally
Ciosed
N.B.FHCRX-2hastwo relays
and
two of eachcontrolling
output
Relay
ContactRating:1amp@24
voltsDC
AntennaWireLength**:
170mm
*Timer
modeavailable
withATA'sUniversal
Programmer.
** An optional
co-axialantenna
isavailable
for usewith the receiverin difficult
receptionareas.
Tl-geantenna
has
to be
mounted
ashighas
possible
sothat it isnot obstructed,e.g.on top of afence,or on awall
atthefront of a garage,
etc.
Connectthe coreof co-axial
leadto replace
the existing
antenna
wire(inner
screwsocket).Connect
shield
to the spare
{outer)
screwsocket.
WARRANTY
Subjectto allof the matter set out below, Automatic TechnologyAustraliaPtyLtd {"ATA") WARRANTS
for twelve (12)
months from
the date of purchase
(specifiedinthe tax invoicereceipt)
that the FHCRXSeries
Receiver
(the "Product") isfree of any defects in
material
andworkmanship
renderingit unmerchantable.
Thiswarranty referredto above applies only where:
a)the consumerseeking
to rely on the saidwarranty;
1)returns
the Productwhich it claims
to be defective;and
2)presents
the relevantsalesdocket and this warrantydocument. to the retailerfrom whom the Productwaspurchased
to
confirm that date of purchase;
and
bi the purchasernotified ATA or the retailerfrom whom the Product was purchased
of the alleged defect in the Product
immediately upon experience or iearning of the alieged defect.
Except
for the warrantyagainstdefects in materialanciworkmanship set out above,ATA givesno warranties
o{ any kind whatso_e.v91,
-whether express
or implied or whether statutory or at common law, in relationto the Product, and all
warranties
of fitness{or
particular
purpose and other warrantiesof whatsoeverkind relatingto the Product are hereby declaimed.Without limiting the
'generalityof the foregoing, ATA disclaims
anyliability
of whatsoevernature in respectof anyclaimor demand lossor damage which
arise
out of;
a)
accidental
damage to or normal wear and tear to the Product or to the Product'scomponents;
b)flood. rain,water, fire or lightning;
c)incorrect,improper or unreasonable
maintenance
and/or use;
d) installation,
adjustment or useother than ATA which is not in accordance
with the instructions
setout ln installation
instructions
incorporated in the document;
e)attempted or complete modification or repairs
to the Productcarriedout by a person who isnot authorised
by ATA to carryout such
modification or repairs;
0 radio (includingcitizenband transmission)
or anyelectronicinterference,
g) damage causedby electricalsurges,
h)damage causedby insects.
ATA's liabilityunder the warranty set out above islimited, at ATA's absoluteoption, to replacingor repairingthe Product which ATA,
in its unfettered opinion, considers
to the defective either in material and/or wolkmanship or to credit the consumerwith the price at
whichthe Product was purchased by the consumer.
Where the Product isretailedby any person other than ATA, except for the
warrantyset out above, suchperson hasno authority from ATA to give anywarrantyor guaranteeon ATA's behalf in addition to the
warrantyset out above
@}
June2008Automatic
Technology
(Ausiralia)
PtyLtd.Allrights
reserveci.
TrioCoderM
istrademark
ofAutomatic
Technoiogy
(Australia)
PtyLtd. No parto{thisdocument
maybe r-eproducedvrithoutpriorpermission-
In
anongoing
commitment
to
product
quality
vreieserve
theright
to changespecification
vrithoLrtnotice.
E&OE.
