AT&T DLP73210 User manual

Complete user’s manual
DLP73210/DLP73410/DLP73440/
DLP73540
DECT 6.0 cordless telephone/
answering system with
BLUETOOTH® wireless technology

Congratulations
on purchasing your new AT&T product. Before using this AT&T product, please read
the Important safety information section on pages 157-159 of this manual.
Please thoroughly read this Complete user’s manual for all the feature operations
and troubleshooting information necessary to install and operate your new AT&T
product. You can also visit our website at https://telephones.att.com or call
1 [phone]. In Canada, dial 1 [phone].
This telephone meets the California Energy Commission regulations for energy
consumption. Your telephone is set up to comply with the energy–conserving
standards right out of the box. No further action is necessary.
This telephone system is compatible with certain AT&T DECT 6.0 cordless headsets
and speakerphones. Visit https://telephones.att.com/accessories for a
list of compatible cordless headsets and speakerphones.
Model number: DLP73210 (two-handset system)
DLP73410/DLP73440 (four-handset system)
  ¥©#! èɸ»´Á·Æ¸ÇÆÌÆǸÀ
Type: DECT 6.0 cordless telephone/answering system with
BLUETOOTH® wireless technology
Serial number: __________________________________________________________
Purchase date: __________________________________________________________
Place of purchase: _______________________________________________________
Both the model and serial numbers of your AT&T product can be found on the
bottom of the telephone base.
Save your sales receipt and original packaging in case it is necessary to
return your telephone for warranty service.
¸¿¸Ã»ÂÁ¸Æ¼·¸ÁǼ踷ʼǻÇ»¼Æ¿ÂºÂ»´É¸Ÿ·È¶¸·Á¼Ƹ´Á·¼ÁǸŹ¸Å¸Á¶¸Ê»¸Á
used with most T-coil equipped hearing aids and cochlear implants. The TIA-1083
Compliant Logo is a trademark of the Telecommunications Industry Association.
Used under license.
The ENERGY STAR® program (www.energystar.gov) recognizes and encourages the
use of products that save energy and help protect our environment. We are proud to
mark this product with the ENERGY STAR® label indicating it meets the latest energy
¸ï¶¼¸Á¶ÌºÈ¼·¸¿¼Á¸Æ
The Bluetooth® word mark and logos are owned by Bluetooth SIG, Inc. and any use of such marks
by Advanced American Telephones and its parent, VTech Holdings Limited, is under license. VTech
Holdings Limited is a member of Bluetooth SIG, Inc. Other trademarks and trade names are those
of their respective owners.
©2020 Advanced American Telephones. All Rights Reserved. AT&T and
the AT&T logo are trademarks of AT&T Intellectual Property licensed to
Advanced American Telephones, San Antonio, TX 78219. Printed in China.

Parts checklist
Your telephone package contains the following items. Save your sales receipt
and original packaging in the event warranty service is necessary.
Telephone line cordPower adapter for
telephone base
Telephone baseUser’s manual
Wall-mount bracket
THIS SIDE UP / CE CÔTÉ VERS LE HAUT
Battery Pack / Bloc-piles :
BT162342/BT262342 (2.4V 300mAh Ni-MH)
WARNING / AVERTISSEMENT :
DO NOT BURN OR PUNCTURE BATTERIES.
NE PAS INCINÉRER OU PERCER LES PILES.
Made in China / Fabriqué en chine GP1621
Quick start guide
Cordless handset
(2 for DLP73210)
(4 for DLP73410/
DLP73440)
(5 for DLP73540)
Charger for cordless
handset with power
adapter installed
(1 for DLP73210)
(3 for DLP73410/
DLP73440)
(4 for DLP73540)
Battery for cordless
handset
(2 for DLP73210)
(4 for DLP73410/
DLP73440)
(5 for DLP73540)
Battery
compartment cover
(2 for DLP73210)
(4 for DLP73410/
DLP73440)
(5 for DLP73540)
User’s manual
DLP73210/DLP73410/DLP73440/
DLP73540
DECT 6.0 cordless telephone/
answering system with
BLUETOOTH® wireless technology
¬À´ÅÇ¶´¿¿µ¿Â¶¾¸Å¿¸´ë¸Ç

Complete user’s manual
DLP73210/DLP73410/
DLP73440/DLP73540
DECT 6.0 cordless telephone/
answering system with
BLUETOOTH® wireless technology
Table of contents
Getting started
Installation .......................................................... 1
Quick reference guide - telephone
base .........................................................................2
Quick reference guide - handset.........6
Telephone base and charger
installation ....................................................... 10
Telephone base installation........... 10
Charger installation.............................. 11
Battery installation and charging .....12
Installation options.....................................15
Tabletop to wall-mount
installation..................................................15
Wall-mount to tabletop
installation..................................................16
Bluetooth
Introducing Bluetooth ..............................17
Connect to CellTM application ........19
Glossary of terms........................................20
Bluetooth setup ............................................21
Add a cell phone .....................................21
Add a headset ......................................... 22
Auto connection.................................... 23
Device list and connection .............24
Review the device list.........................24
Connect/disconnect an
active device.............................................24
Remove a paired device ................... 25
Download directory............................. 25
Interruption to directory
download....................................................26
Remote voice control............................... 27
Activate remote voice control.....28
Telephone settings
Handset settings .........................................29
Ringer volume.........................................30
Ringer tone.................................................31
LCD language........................................... 32
Set date and time................................. 32
Set speed dial voicemail
number.........................................................34
Voicemail (visual message
waiting) indicator..................................34
Clear voicemail indicator/
indication.................................................... 35
Key tone ...................................................... 35
Home area code ....................................36
Dial mode ................................................... 37
QUIET mode..............................................38
Telephone operation
Telephone operation ................................50
Make, answer or end a
home call.....................................................50
Make, answer or end a cell call......51
Silence the ringer.................................. 52

Call waiting on the home line ....... 53
Call waiting on the cell line............. 53
Options while on calls ..............................54
Handset speakerphone ....................54
Volume control.......................................54
Mute...............................................................54
Temporary tone dialing .................... 55
Chain dialing .............................................56
Redial ................................................................... 57
Last number redial............................... 57
Save a redial entry to the
directory......................................................58
Delete a redial entry............................58
Handset locator............................................59
Multiple handset use
Join a call in progress ...............................60
Intercom.............................................................61
Initiate an intercom call.....................61
Answer an incoming call during
an intercom call......................................63
Call transfer using intercom ................64
Push-to-talk (PTT)......................................66
ÈÅÁ©ÂÁÂÅÂæ ................................66
PTT call to a single device...............67
PTT call to multiple devices ...........69
Answer a PTT call...................................71
Change a one-to-one PTT call to
an intercom call...................................... 72
Answer an incoming call during
a PTT call..................................................... 72
Make an outgoing call during
PTT call......................................................... 73
End or leave a PTT call....................... 73
Directory
About the directory................................... 74
Create and review entries..................... 75
Create a new directory entry........ 75
Add a predialed telephone
number to the directory .................. 77
Review the directory...........................78
Search by name ..................................... 79
Dial a directory entry..........................80
Dial, delete and edit a directory
entry......................................................................81
Edit a directory entry ..........................81
Delete a directory entry...................82
Delete all directory entries.............82
Caller ID
About caller ID...............................................83
Information about caller ID
with call waiting .....................................83
Caller ID operation......................................84
How the caller ID log works ...........84
Missed (new) call indicator.............84
Memory match.......................................84
Review the caller ID log.....................85
View dialing options............................86
Dial a caller ID log entry....................86
Save a caller ID log entry to the
directory...................................................... 87
Delete caller ID log entries .............90
Reasons for missing caller ID
information ......................................................91
Smart call blocker
About Smart call blocker*.....................92
Call categories ........................................93
Call handling .............................................94
Call block settings.......................................96
¬¸Ç¬À´ÅÇ¶´¿¿µ¿Â¶¾¸ÅÂÁÂæ .......96
¬¸ÇÃÅÂ迸................................................... 97
Block list ......................................................98
Allow list ....................................................102
Star name list.........................................106
Screening announcements..........109
Voice guide to set Smart call
blocker.........................................................112
Allowed calls ..................................................113
Blocked calls ................................................. 114
Screen unknown home calls...............115
Screened call options........................117

Screen robocalls ........................................ 118
Option while on a call ............................. 119
Answering system
Answering system settings................120
Announcement.....................................120
ÁÆʸÅÂÁÂæ .......................................122
Voice guide to set up answering
system........................................................123
Call screening.........................................124
Number of rings...................................125
Remote access code.........................126
Message alert tone............................127
About the answering system............128
Answering system and
voicemail...................................................128
Use the answering system and
voicemail together.............................128
Message capacity ...............................129
Voice prompts.......................................129
Call screening.........................................130
Call intercept...........................................131
¸ÀÃÂŴż¿ÌÇÈÅÁÂæÇ»¸
message alert tone.............................131
Message playback.....................................132
Options during playback................ 133
Delete all old messages..................134
Record and play memos....................... 135
Record a memo....................................135
Playback a memo................................135
Message window displays...................136
Remote access............................................ 137
To remotely access the
answering system............................... 137
Appendix
Add and register handsets/
headsets/speakerphones ...................139
Register a handset to your
telephone base.....................................139
Deregister handsets................................ 141
Deregister all handsets from the
telephone base..................................... 141
Screen icons, indicator lights and
alert tones......................................................142
Screen icons ...........................................142
Handset indicator lights.................142
Telephone base indicator
lights ............................................................143
Handset alert tones ..........................143
Telephone base alert tones.........143
Screen messages ..................................... 144
Troubleshooting........................................ 146
Maintenance.................................................156
Important safety information.......... 157
Safety information............................. 157
Especially about cordless
telephones...............................................158
Precautions for users of
implanted cardiac
pacemakers ............................................159
ECO mode ................................................159
Especially about telephone
answering systems............................159
FCC Part 68 and ACTA............................160
FCC Part 15 .....................................................162
California Energy Commission
battery charging testing
instructions ...................................................163
Limited warranty ...................................... 164
¸¶»Á¼¶´¿Æø¶¼è¶´Ç¼ÂÁÆ........................166
DECT 6.0 digital technology.........166
Telephone operating range.........166
«¸·¸èÁ¼Áº¿ÂÁºÅ´Áº¸
coverage and clarity..........................166
Simulated full-duplex handset
and base speakerphones ..............166
Index
Index...................................................................167

Installation
Install the telephone base close to a telephone jack and a power outlet not
¶ÂÁÇÅ¿¿¸·µÌ´Ê´¿¿ÆʼǶ»»¸Ǹ¿¸Ã»ÂÁ¸µ´Æ¸¶´Áµ¸ÿ´¶¸·ÂÁ´ë´ÇÆÈŹ´¶¸
or vertically mounted on the wall (page 15). For optimum range and better
reception, place the telephone base in a central and open location.
You may hear interference if your cellular phone is too close to the telephone
base during a CELLULAR call. Make sure that your Bluetooth enabled cellular
phone is within 15 feet of the telephone base in order to maintain a clear and
consistent connection between your Bluetooth cell phone, telephone base and
cell tower.
If you subscribe to high-speed Internet service (DSL - digital subscriber line)
Ç»ÅÂȺ»ÌÂÈÅǸ¿¸Ã»ÂÁ¸¿¼Á¸ÌÂÈÀÈÆÇ¼ÁÆÇ´¿¿´¬¥è¿Ç¸Åµ¸Çʸ¸ÁÇ»¸
telephone line cord and the telephone wall jack (page 10»¸è¿Ç¸ÅßɸÁÇÆ
noise and caller ID problems caused by DSL interference. Please contact your
¬¥ƸÅɼ¶¸ÃÅÂɼ·¸Å¹ÂÅÀŸ¼Á¹ÂÅÀ´Ç¼ÂÁ´µÂÈÇ¬¥è¿Ç¸ÅÆ
Your product may be shipped with a protective sticker covering the handset or
telephone base display - remove it before use.
For customer service or product information, visit our website at
https://telephones.att.com or call 1 [phone]. In Canada, dial
1 [phone].
Avoid placing the telephone base and charger too close to:
fCommunication devices such as television sets, VCRs, or other
cordless telephones.
fExcessive heat sources.
f§Â¼Æ¸ÆÂÈŶ¸ÆÆȶ»´Æ´ʼÁ·ÂÊʼǻÇÅ´ï¶ÂÈÇƼ·¸ÀÂÇÂÅÆÀ¼¶ÅÂʴɸ
ÂɸÁÆŸ¹Å¼º¸Å´ÇÂÅÆÂÅëÈŸƶ¸ÁÇ¿¼º»Ç¼Áº
fExcessive dust sources such as a workshop or garage.
fExcessive moisture.
fExtremely low temperature.
fMechanical vibration or shock, such as on top of washing machine or
workbench.
You must install and charge
the battery before using the
cordless handset.
See pages 12-14 for easy
instructions.
1
Getting started

2
Getting started
Quick reference guide - telephone base
REDIAL/PAUSE
fPress repeatedly to view the last 10
numbers dialed (page 57).
fWhile entering numbers, press and hold
to insert a dialing pause (page 77).
VOL
fPress to adjust the volume during
message playback (page 132).
fPress to adjust the listening volume
during a call (page 54).
f When the phone is not in use, press
to adjust the telephone base ringer
volume for all lines (page 30).
MUTE/VOICE
fDuring a call, press to mute the
microphone (page 54).
fWhile the telephone base is ringing,
press to silence the ringer temporarily
(page 53).
fWhen the telephone is not in use,
press to activate the voice-controlled
application of connected cell phone
(page 27).
1
fWhile reviewing a caller ID log entry,
press repeatedly to add or remove 1in
front of the telephone number before
dialing or saving it in the directory.
fPress and hold to set (page 34) or to
dial your voicemail number.
TONE /a>A
fPress to switch to tone dialing
temporarily during a call if you have
pulse service (page 55).
fWhile entering names, press to change
the next letter to upper or lower case.
QUIET# (pound key)
fPress repeatedly to display other dialing
options when reviewing a caller ID log
entry (page 86).
fPress and hold to enter the QUIET mode
setting screen, or to deactivate QUIET
mode (page 38).
/ANS ON
Press to turn the answering system on or
Âæpage 122).
2
3
456
8
9
10
11
12
1
15
14 13
7
1
2
3
4
5

3
Getting started
Quick reference guide - telephone base
/FIND HS
fPress the button to page all system
handsets (page 59).
Antenna
X/DELETE
fPress to delete the message
currently playing (page 132).
fWhen the phone is not in use,
press twice to delete all previously
reviewed messages (page 132).
fWhile reviewing the redial list,
directory, caller ID log, allow list, block
list, or star name list, press to delete
an individual entry (pages 57,
78, 85, 103, 99 and 107).
fWhile entering names or numbers,
press to delete a digit or a character.
fWhile predialing, press to delete
a digits.
/REPEAT
fPress to repeat a message or press
twice to play the previous message
(page 132).
/SKIP
fDuring message playback, press to skip
to the next message (page 132).
/PLAY/STOP
fPress to play messages (page 132).
fPress to stop message playback (page
132).
INT
fPress to initiate an intercom
conversation or transfer a call (page
61).
HOME (Speakerphone)
fPress to make or answer a home call
(page 50).
fFlashes quickly when there is an
incoming home call.
fFlashes slowly when a home call is on
hold.
CELL
fPress to make or answer a cell call
(page 51).
fFlashes quickly when there is an
incoming cell call.
fFlashes slowly when a cell call is on hold.
2
3
456
8
9
10
11
12
1
15
14 13
7
8
9
10
11

4
Getting started
Quick reference guide - telephone base
CALL BLOCK
fPress to block the incoming call when
the telephone is ringing (page 92).
fWhen on a call, press to block the call
(page 119).
fWhen the telephone base is not in
use, press to show the call block menu
(page 92).
CELL 1 Light
XOn when the telephone is paired and
connected with a Bluetooth device.
XFlashes alternately while pairing a
Bluetooth device.
CELL 2/Headset Light
XOn when the telephone is paired and
connected with a Bluetooth device or
headset.
XFlashes alternately while pairing a
Bluetooth device or headset.
CANCEL
fWhile in a menu, press to exit without
making changes or press and hold to
return to idle mode.
fPress and hold while the telephone
is not in use to erase the missed call
indicator (page 84).
TCID
fPress to scroll down while in a menu.
fPress to review the caller ID log when
the telephone is not in use (page 85).
fWhile entering names or numbers,
ßÆÆÇÂÀÂɸÇ»¸¶ÈÅÆÂÅÇÂÇ»¸¿¸ì
MENU/SELECT
fWhen the telephone base is not in use,
press to show the menu.
f°»¼¿¸¼ÁÇ»¸À¸ÁÈßÆÆÇÂ¶ÂÁèÅÀÂÅ
save an entry or setting.
SDIR
fPress to scroll up while in a menu.
fPress to show directory entries when
the telephone is not in use (page 78).
fWhile entering names or numbers,
press to move the cursor to the right.
PTT/FLASH
fPress to display the PTT menu to begin
a PTT call (page 66).
fPress and hold to begin a one-to-group
broadcast when the telephone base is
not in use (page 69).
fDuring a call, press to answer an
incoming home call when you receive a
call waiting alert (page 50).
2
3
456
8
9
10
11
12
1
15
14 13
7
12
13
14
15

5
Getting started
Using menus:
XPress MENU/SELECT to enter the main menu.
XPress CID or DIR to scroll through menu items.
XPress MENU/SELECT to select or save the indicated item.
XPress CANCEL to cancel an operation, back up to the previous menu or
exit the menu display.
Main menu
The selected menu item is highlighted.
Feature menu
fAnswering sys (page 120)
fSmart call blk (page 92)
fDirectory (page 74)
fCaller ID log (page 83)
fIntercom (page 61)
fBluetooth (page 21)
fRingers (page 30)
fSet date/time (page 32)
fCaller ID annc (page 33)
fSettings (page 32)
Menu
Quick reference guide - telephone base

6
Getting started
Quick reference guide - handset
fPress to decrease the listening
volume when on a call (page 54),
or to decrease the message playback
volume (page 132).
CELL
fPress to make or answer a cell call
(page 51).
fDuring a cell call, press to answer an
incoming cell call when you hear a call
waiting alert (page 53).
fDuring message playback, press to call
back the caller if the caller’s number is
available (page 132).
HOME/FLASH
fPress to make or answer a home call
(page 50).
fDuring a call, press to answer an
incoming home call when you receive a
call waiting alert (page 53).
fDuring message playback, press to call
back the caller if the caller’s number is
available (page 132).
CHARGE light
fOn when the handset is charging in the
telephone base or charger.
VOL SDIR
fPress SDIR to show directory entries
when the handset is not in use (page
78).
fPress to scroll up while in menus.
fWhile entering names or numbers, press
to move the cursor to the right.
fPress to increase the listening volume
when on a call (page 54), or to increase
the message playback volume (page
132).
VOL TCID
fPress TCID to show caller ID log when
the handset is not in use (page 85).
fPress to scroll down while in menus.
fWhile entering names or numbers, press
ÇÂÀÂɸÇ»¸¶ÈÅÆÂÅÇÂÇ»¸¿¸ì
1
2
3
4
5
6
7
8
9
10
11
12
13
14
1
23
4

7
Getting started
Quick reference guide - handset
1
fWhile reviewing a caller ID log entry,
press repeatedly to add or remove 1 in
front of the telephone number before
dialing or saving it in the directory.
fPress and hold to set (page 34) or to
dial your voicemail number.
TONE /a>A
fPress to switch to tone dialing
temporarily during a call if you have
pulse service (page 55).
fWhile entering names, press to change
the next letter to upper or lower case.
/SPEAKER
fPress to make or answer a home or cell
call using the speakerphone (page 50
or page 51).
fPress to switch between the
speakerphone and the handset (page
54).
MUTE/DELETE/VOICE
fDuring a call, press to mute the
microphone (page 54).
fWhen the handset is ringing, press to
mute the ringer temporarily (page
53).
fWhile reviewing the caller ID log, the
directory or the redial memory, press
to delete an individual entry.
fWhile predialing, press to delete digits.
fDuring message or announcement
playback, press to delete the
playing message or the recorded
announcement.
fWhen the handset is not in use, press
to activate the voice-controlled
application of connected cell phone
(page 27).
MENU/SELECT
fWhen the handset is not in use, press
to show the menu.
fWhile in the menu, press to select an
item or save an entry or setting.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
7
8
9
5
6

8
Getting started
Quick reference guide - handset
CALL BLOCK
fPress to block the incoming call when
the telephone is ringing (page 92).
fWhen on a call, press to block the call
(page 119).
fWhen the handset is not in use, press to
show the call block menu (page 92).
OFF/CANCEL
fDuring a call, press to hang up (page
50 or page 51).
fWhile in a menu, press to cancel an
operation, back up to the previous
menu, or exit the menu display; or
press and hold this button to exit to idle
mode.
fWhen the handset is ringing, press to
mute the ringer temporarily (page
53).
fPress and hold while the telephone
is not in use to erase the missed call
indicator (page 84).
QUIET# (pound key)
fPress repeatedly to display other
dialing options when reviewing a caller
ID log entry (page 86).
fPress and hold to enter the QUIET
mode setting screen, or to deactivate
QUIET mode (page 38).
PTT (PUSH TO TALK)
fPress to initiate a one-to-one (page
67) or one-to-group broadcast
(page 69).
fPress and hold to broadcast to a group
of system devices (page 69).
REDIAL/PAUSE
fPress repeatedly to view the last 10
numbers dialed (page 57).
fWhile entering numbers, press and
hold to insert a dialing pause (page
77).
10
11
12
13
14
1
2
3
4
5
6
7
8
9
10
11
12
13
14

9
Getting started
Quick reference guide - handset
Feature menu
fPlay messages (page 132)
fAnswering sys (page 120)
fSmart call blk (page 92)
fDirectory (page 74)
fCaller ID log (page 83)
fIntercom (page 61)
fRingers (page 30)
fSet date/time (page 32)
fCaller ID annc (page 33)
fSettings (page 32)
Main menu
The selected menu
item is highlighted.
Using menus:
1. Press MENU/SELECT in idle mode (when the telephone is not in use) to enter
the main menu.
2. Press CID or DIR to scroll through menu items.
3. Press
MENU/SELECT to select or save the highlighted item.
-OR-
Press OFF/CANCEL to cancel an operation, back up to the previous menu,
or exit the menu display.
Menu

10
Getting started
Telephone base and charger installation
Install the telephone base and charger, as shown below.
The telephone base is ready for tabletop use. If you want to change to
wall-mounting, see Installation options on page 15 for details.
Telephone base installation
Raise the antenna.
Plug one end of the
telephone line cord into a
Ǹ¿¸Ã»ÂÁ¸½´¶¾ÂÅ´¬¥è¿Ç¸Å
Plug the small end of the
telephone base power adapter
into the power adapter jack on
the back of the telephone base.
Plug the large end of the
telephone base power adapter
into a power outlet not
controlled by a wall switch.
Plug the other end of the telephone
line cord into the telephone jack on
the back of the telephone base.
If you have DSL
high-speed Internet
ƸÅɼ¶¸´¬¥è¿Ç¸Å
(not included) is
required.
Route the
telephone line cord
through this slot.
Route the power
adapter cord through
this slot.

11
Getting started
Telephone base and charger installation
Charger installation
IMPORTANT INFORMATION
fUse only the power adapter(s) provided with this product. To obtain a
replacement, visit our website at https://telephones.att.com or call
1 [phone]. In Canada, dial 1 [phone].
fThe power adapters are intended to be correctly oriented in a vertical or
ëÂÂÅÀÂÈÁÇÃÂƼǼÂÁ»¸ÃÅÂÁºÆ´Å¸ÁÂÇ·¸Æ¼ºÁ¸·ÇÂ»Â¿·Ç»¸ÿȺ¼Áÿ´¶¸¼¹
it is plugged into a ceiling, under-the-table or cabinet outlet.
Plug the large end of the
charger’s power adapter
into an electrical outlet not
controlled by a wall switch.
Ensure the small end of the charger’s
power adapter is plugged into the power
jack on the bottom of the charger.

12
Getting started
Battery installation and charging
Install the battery, as shown below. Once you have installed the battery, the
screen indicates the battery status (see the following table). If necessary, place
the handset in the telephone base or charger to charge the battery. For best
performance, keep the handset in the telephone base or charger when not in
ÈƸ»¸µ´ÇǸÅÌ¼Æ¹È¿¿Ì¶»´Åº¸·´ì¸Å"»ÂÈÅÆ¹¶ÂÁǼÁÈÂÈÆ¶»´Åº¼Áº¬¸¸Ç»¸
table on page 166 for battery operating times.
If the screen is blank or shows Put in charger´Á·´ë´Æ»¼Áº , you need to
charge the handset without interruption for at least 30 minutes to give the
handset enough charge to use the telephone for a short time. When the
battery is low, the handset shows Low battery´Á·´ë´Æ»¼Áº . If you are on a
call in low battery mode, the handset beeps every minute.
The following table summarizes the battery charge indicators and actions
to take.
Battery indicators Battery status Action
The screen is blank or
shows Put in charger
and ë´Æ»¸Æ
The battery has no or very
little charge. The handset
cannot be used.
Charge without interruption (at least
30 minutes).
The screen shows
Low battery and
ë´Æ»¸Æ
Battery has enough
charge to be used for a
short time.
Charge without interruption (at least
30 minutes).
The screen shows
HANDSET X.
Battery is charged. To keep the battery charged, place it in the
telephone base or charger when not in use.
1. Plug the battery connector securely into the socket inside the handset
battery compartment. Insert the supplied battery with the label
THIS SIDE UP facing up, as indicated.
THIS SIDE UP / CE CÔTÉ VERS LE HAUT
BatteryPack/Bloc-piles:
BT183342/BT283342(2.4V 400mAh Ni-MH)
WARNING /AVERTISSEMENT :
DO NOT BURNOR PUNCTUREBATTERIES.
NE PASINCINÉREROU PERCERLES PILES.
Made in China /Fabriqué en chine CR1535
THIS SIDE UP

13
Getting started
Battery installation and charging
2. ¿¼ºÁÇ»¸¶ÂɸÅë´Ç´º´¼ÁÆÇÇ»¸µ´ÇǸÅÌ¶ÂÀôÅÇÀ¸ÁÇÇ»¸ÁÆ¿¼·¸¼ÇÈÃÊ´Å·Æ
until it clicks into place.
3. Charge the handset by placing it face forward in the telephone base or
charger. The CHARGE light on the top of the handset is on during charging.
THIS SIDEUP /CE CÔTÉVERS LE HAUT
Battery Pack/ Bloc-piles :
BT183342/BT283342 (2.4V 400mAh Ni-MH)
WARNING / AVERTISSEMENT :
DONOT BURN OR PUNCTURE BATTERIES.
NE PAS INCINÉRER OU PERCERLES PILES.
Made inChina /Fabriqué en chineCR1535

14
Getting started
Battery installation and charging
IMPORTANT INFORMATION
fUse only the supplied rechargeable battery or replacement battery
(model BT162342/BT262342). To order, visit our website at
https://telephones.att.com or call 1 [phone]. In Canada,
dial 1 [phone].
fIf you do not use the handset for a long time, disconnect and remove the
battery to prevent possible leakage.
ì¸ÅÌÂÈ¼ÁÆÇ´¿¿ÌÂÈÅǸ¿¸Ã»ÂÁ¸ÂÅÃÂʸÅŸÇÈÅÁÆ¹Â¿¿ÂʼÁº
a power outage, the handset and telephone base will
prompt you to set the date and time. For instructions, see
Set date/time on page 32. To skip setting the date
and time, press OFF/CANCEL on the handset or press
CANCEL on the telephone base.
ì¸ÅÇ»¸¬À´ÅÇ¶´¿¿µ¿Â¶¾¸ÅƸÇǼÁº¼Æ·ÂÁ¸ÂÅƾ¼Ãø·
the telephone base will then prompt if you want to set up
the answering system. Press MENU/SELECT to start the
answering system setup via voice guide. For more details,
see Voice guide to set Answering system on page 123.
To skip the setup, press CANCEL on the telephone base.
ì¸ÅÇ»¸·´Ç¸´Á·ǼÀ¸ƸÇǼÁº¼Æ·ÂÁ¸ÂÅƾ¼Ãø·Ç»¸
telephone base will prompt if you want to set Smart call
blocker. Press MENU/SELECT to start the Smart call blocker
setup via voice guide. For more details, see Voice guide to
set Smart call blocker on page 112. To skip the setup,
press CANCEL twice on the telephone base.
Date: MM/DD/YY
ECO
Time: HH:MM - -
ECO

Voice guide to
set up Ans sys?

Voice guide set
Smart Call Blk?
