AT&T NetGate 8200 User manual

1
Version 5.1
© 2010 AT&T Corp. All Rights Reserved.
AT&T NetGate®8200

2

3
Table of Contents
Installing the AT&T NetGate 8200 .........................................................4
Step 1: Establish Physical Connectivity to the Internet.........................4
Option a. Wired Ethernet Connection ...............................................5
Option b. Dial as Primary Connection...............................................6
Option c. Cellular Connection ...........................................................6
Step 2: Establish Local Network Connectivity.......................................6
Configuring the AT&T NetGate 8200.....................................................8
Access the AT&T NetGate Web Interface ............................................8
Primary Interface Set-up .......................................................................9
Configuring a Static IP Address......................................................11
Configuring PPPoE .........................................................................11
Configuring an Always-on 3G Cellular Connection.........................11
Configuring a Dial as Primary Connection......................................12
Configuring a controllable 3G Cellular Connection.........................13
3G Cellular service verification........................................................13
Administrator Access ..........................................................................15
Establishing VPN Connectivity............................................................16
LAN Port Configuration........................................................................18
VLANS.................................................................................................18
Hub Mode............................................................................................22

4
Installing the AT&T NetGate 8200
Unpack the AT&T NetGate 8200, the cables, and the power supply.
Installation steps vary depending on type of Internet connection and
type of local network connectivity. See Figure 1 for connectors on the
rear panel of the AT&T NetGate 8200.
!WARNING!
Nouserserviceableparts.
Donotremovecover.
POWER
SUPPLY
-+
OPTIONAL
USB DEVICE
OPTIONAL
DIAL
LINE
12VDC 1.5A Modem RST
USB 1 USB 2 USB 3
OPTIONAL
USB DEVICE
OPTIONAL
USB DEVICE
CONSOLE
CONSOLE
PORT RESET
LAN
LAN
EQUIPMENT
13 5 7
24 6 8
SECONDARY
BROADBAND
PORT
PRIMARY
BROADBAND
PORT
WAN 1 WAN 2
Figure 1: AT&T NetGate 8200 Rear Panel
Follow the guide below to determine the necessary set-up steps for
your environment.
Step 1: Establish Physical Connectivity to the Internet
In most cases, a wired Ethernet connection will be provided by your
ISP. This type of connection includes DSL, Cable and Managed
Internet Connections. It is also possible to connect to the Internet via
a dial up connection, or via high speed cellular access, in which case
you should proceed to the appropriate section in this guide.
Once an Internet Connection has been established, the AT&T
NetGate 8200 will try to retrieve its configuration from the network,
and if successful, may perform an automatic reboot to pick up the
new configuration. This should occur within the first 2-3 minutes after
initial power on. Wait for a steady GREEN ONLINE light on the front
panel to indicate the AT&T NetGate 8200 is ready for use.

5
Basic connectivity is shown in Figure 2. Devices in the local network
are connected to one or more of the LAN ports on the rear of the
AT&T NetGate 8200; the broadband connection is usually
established via the WAN 1 port. An optional dial connection is also
possible via the supplied cable.
!WARNING!
Nouserserviceableparts.
Donotremovecover.
-+
12VDC 1.5A
LAN
13 5 7
24 6 8
RST
USB 1 USB 2 USB 3CONSOLE
AT&T NetGate 8200
INTERNET
Optional Analog
Phone Line
Broadband Internet
Device (DSL / Cable
modem)
Other network devices
Computer
Modem WAN 2WAN 1
Figure 2: Basic Network Connectivity
Option a. Wired Ethernet Connection
Use a straight-through Ethernet cable (usually provided by your
Broadband Internet Service Provider) to connect your Internet
broadband interface device to the Ethernet port labeled WAN 1 on
the AT&T NetGate 8200. The AT&T NetGate should be connected
directly to the broadband interface device.
Dynamic Host Control Protocol (DHCP) is the default configuration
for Internet IP addressing of the AT&T NetGate 8200 Internet
network interface. If your device automatically obtains an address
from your ISP through DHCP, it should auto-configure shortly after
powering up.
If your Broadband Internet Service Provider supplied you with a static
IP address or PPPoE account information for use with your

6
broadband connection, you will need to perform additional
configuration of the primary interface through the AT&T NetGate
8200 web interface in order to establish Internet access and to
retrieve device configuration. See the appropriate section later in the
guide.
Option b. Dial as Primary Connection
Connect the supplied phone cable between the port labeled Modem
on the AT&T NetGate 8200 and a standard analog phone outlet.
The AT&T NetGate needs basic set-up of the dial interface before it
can connect to the Internet to retrieve its configuration. Dial set-up
through the AT&T NetGate web interface is covered later in this
guide.
Option c. Cellular Connection
Insert your approved cellular USB modem into one of the USB ports
labeled USB 1, USB 2, or USB 3 on the AT&T NetGate 8200.
The AT&T NetGate needs basic set-up of the cellular USB modem
through the web interface before it can connect to the Internet to
retrieve its configuration. See the appropriate section later in the
guide.
Step 2: Establish Local Network Connectivity
In most cases, your devices will attach directly to the AT&T NetGate
8200 via one of the 8 VLAN ports via a straight-through Ethernet
cable. One black straight-through cable is provided. The Local LAN
ports are all auto-sensing, so either a straight-through or a crossover
cable can be used interchangeably.
The default configuration for computers attaching to any of the AT&T
NetGate 8200 Local LAN ports is DHCP. If you are not sure if you
are using DHCP for your LAN IP addressing, please contact your
Information Services (IS) Department for assistance before
proceeding.
If your computer is configured to use DHCP, but the AT&T NetGate
8200 is not providing your computer with an IP address, please

7
contact your IS Department. In this case you will not be able to
access the Web Interface as described below.
Once the necessary cabling has been attached, connect the power
supply to the receptacle labeled 12VDC 1.5Aon the AT&T NetGate
8200 and to a standard AC power outlet.
Note: After the AT&T NetGate has retrieved its configuration, the IP
addresses given out on the LAN ports are likely to change. For that
reason it may be better to delay attaching any devices to the LAN
ports until AFTER configuration has been retrieved and the AT&T
NetGate reboots. If the IP addressing does change, it may be
necessary to enable/disable the Ethernet interface on attached
devices to obtain a valid IP address via DHCP.

8
Configuring the AT&T NetGate 8200
In most cases, no user-level configuration is required as an IP
address is retrieved automatically through DHCP and the device
configuration is retrieved from the network. In some cases it is
necessary to perform some initial configuration through the Web
Interface –for example if the primary Internet connection needs to be
manually configured prior to use.
Access the AT&T NetGate Web Interface
The AT&T NetGate web interface can be accessed from a computer
attached to a LAN port on the AT&T NetGate. The web interface can
be used to access various administration functions and can allow the
VPN connection to be controlled.
1. Open your browser (Supported browsers are Microsoft Internet
Explorer® version 5.0 or higher, Netscape Navigator® version
6.2 or higher and Mozilla Firefox v1.5 or higher).
2. In the Address or Location box enter
http://netgate.att.com and press the Enter key.
3. This will take you to one of several possible initial pages,
depending on your configuration and connectivity options.
Common navigation icons appear on the upper left side of each
page for access to “Home”, “Control Panel” and “Help”
In the event that the AT&T NetGate has already retrieved its
configuration, it may have been configured for Administrator access.
See Administrator Access on page 15 for more information on
gaining administrator access to the web interface.

9
Primary Interface Set-up
To configure the primary interface for something other than DHCP,
follow these steps to configure:
1. Access the web interface as described on page 8
2. Click on the Control Panel navigation icon.
3. Click the entry for Network Settings to display the Network
Settings sub-menu and click the entry for AT&T NetGate IP
Settings as shown in Figure 3.
Figure 4 will be displayed where you will be given the opportunity to
select your primary connection type.
Figure 3: Network Settings Selection

10
If you are not sure how your Internet Access should be configured,
contact your IS department. Two basic types of connection are
offered. An “Always-On Internet Connection” means that the
connection will normally always be available, and the AT&T NetGate
will try to re-establish connectivity if the connection is lost. The other
type is for where an Internet connection is only established when
required. This is commonly used where having a connection up at all
times may be expensive and there are periods of time when the
connection is not required. Continue configuration from the section
appropriate to your connection type.
Figure 4: NetGate IP Settings Window

11
Configuring a Static IP Address
To configure a static IP address, follow these steps after reaching
Figure 4:
1. Select the radio button next to “Static”on Figure 4 and click
OK to proceed to the Static IP set up window.
2. Enter the information requested and press OK to save the
new settings.
3. At the end of the set-up, you will be asked to reboot to pick
up the new configuration. After reboot, skip to the section
titled “Establishing VPN Connectivity”on page 16.
Configuring PPPoE
To configure PPPoE Account information, follow these steps after
reaching Figure 4:
1. Select the radio button next to “PPPoE”on Figure 4 on and
click OK to proceed to the to the PPPoE set up window
2. Enter the information requested and press OK to save the
new settings.
3. At the end of the set-up, you will be asked to reboot to pick
up the new configuration. After reboot, skip to the section
titled “Establishing VPN Connectivity”on page 16.
Configuring an Always-on 3G Cellular Connection
To configure a 3G Cellular always-on connection, follow these steps
after reaching Figure 4:
1. Ensure your supported 3G Cellular USB modem is inserted
into one of the USB ports on the rear of the AT&T NetGate
8200.
2. Select the radio button next to 3G Cellular in the “Always-On”
section and click OK to proceed to the set-up sequence.

12
3. You will be guided through a sequence of windows where
you will be asked to provide information relating to your
specific 3G cellular USB modem connection such as
selecting your USB modem from a drop-down list.
4. For more detailed information on supported 3G Cellular USB
modems and associated configuration, please contact your
IS Department.
5. At the end of the set-up, you will see a summary of the
configuration and will be asked to reboot to pick up the new
configuration. After reboot, skip to the section “Establishing
VPN Connectivity”on page 16.
Configuring a Dial as Primary Connection
To configure a dial connection for Primary Access, follow these steps
after reaching Figure 4:
1. Select the radio button next to Dial on Figure 4 and click OK
to proceed to the Dial Setup sequence
2. You will be guided through a sequence of windows where
you will be asked for a variety of information relating to your
dial connection such as your current location and dial
prefixes necessary to reach an outside line.
3. Follow the instructions on the web pages. The AT&T
NetGate may initiate a dial connection as part of set-up in
order to determine the best local number to dial.
4. At the end of the set-up, you will see a summary of the
configuration and will be asked to reboot to pick up the new
configuration. After reboot, skip to the section titled
“Establishing VPN Connectivity”on page 16.

13
Configuring a controllable 3G Cellular Connection
To configure a 3G Cellular controllable connection, follow these
steps after reaching Figure 4:
1. Ensure your supported 3G cellular USB modem is inserted
into one of the USB ports on the rear of the AT&T NetGate
8200.
2. Select the radio button next to 3G Cellular in the “User
Controllable Dial as Primary Connection” section and click
OK to proceed to the set-up sequence.
3. You will be guided through a sequence of windows where
you will be asked to provide information relating to your
specific 3G Cellular USB modem connection such as
selecting your USB Modem from a drop-down list.
4. For more detailed information on supported 3G Cellular USB
modems and associated configuration, please contact your
IS Department.
5. At the end of the set-up, you will see a summary of the
configuration and will be asked to reboot to pick up the new
configuration. After reboot, skip to the section titled
“Establishing VPN Connectivity”on page 16.
3G Cellular service verification
After completing set up of either mode of 3G connection, it is
important to determine that there is adequate signal strength before
deciding on a final installed position. Cellular coverage can vary,
even over a short distance and a bad placement of the AT&T
NetGate 8200 can result in substandard or even non-existent cellular
service.
You can check the signal strength at site of install by pressing the
“reset” button on the back while powered on with the 3G Cellular
USB modem inserted. A paper clip or other sharp object will be
required to properly depress this button.

14
The signal strength will be represented by a sequence of LEDs
illuminated on the front panel. Up to 6 LEDs, starting with the “online”
light may be illuminated depending on detected strength. The signal
strength will appear in this form for 5 seconds. At least three LEDs of
signal strength are recommended.
Figure 5: Cellular Signal Strength Display
The unit should be installed in a location that gives optimal signal
strength.

15
Administrator Access
If there is more than one user of your AT&T NetGate 8200, one or
more users may be designated as administrators by your IS
Department. If your AT&T NetGate 8200 was set up for administrator
access, Figure 6 is displayed and you must select your authentication
level. You must be a designated administrator to configure or control
the AT&T NetGate 8200. Select Administrator, enter the password
provided by your IS Department and click OK.
If an Administrator password is not required, Figure 6 is not
displayed. The AT&T NetGate must be able to retrieve configuration
from the network in order to implement Administrator access.
Figure 6: AT&T NetGate Administration Panel

16
Establishing VPN Connectivity
The authentication mode of your AT&T NetGate 8200 is determined
by the service parameters ordered by your IS Department. All
configurations require a username and password of some form and
may also require other information. This information may be
downloaded from the network and the AT&T NetGate may be set to
automatically establish connectivity. To establish a VPN connection
with your AT&T NetGate 8200 follow these steps:
1. Open your browser as described under Access the AT&T
NetGate Web Interface on page 8 and if necessary click the
Home button to view the Login screen. The form of the
screen will depend on the network and type of authentication
configured.
Figure 7: Example of Login Screen
2. One or more VPN connections may have been defined. Each
VPN connection will be represented in a status box on the
left side of the screen, showing the current state of each
connection. If there is more than one VPN connection

17
defined, only the first VPN connection can be user controlled.
The others will be established and maintained automatically.
The user controllable connection status will always be the top
entry in the status box.
3. If user input is required in order to establish the primary VPN
connection, provide the requested information and click
Connect.
4. The AT&T NetGate 8200 authenticates your credentials and
establishes a secure VPN connection to your network.
5. A status screen will be shown similar to Figure 8 until the
VPN connection is terminated.
Figure 8: Example of Logged in Screen

18
LAN Port Configuration
VLANS
VLAN support allows segmentation of the 8 Local LAN ports into
different logical LANs, each with its own address range, and
addressing method (DHCP, DHCP Relay, or static). If your AT&T
NetGate 8200 has been configured for VLANs, as part of installation
you will need to know which of the 8 Local LAN Ports attach to each
network.
You can view the VLAN configuration through the AT&T NetGate
8200 Web Interface as described below.
After initial power on, and once the Internet Connection has been
correctly configured, the AT&T NetGate 8200 will retrieve its
configuration from the network and will likely perform an automatic
reboot to pick up the new configuration. This should occur within the
first 2-3 minutes after initial power on. You will not be able to view
the VLAN configuration until the AT&T NetGate 8200 has
successfully retrieved its configuration.
1. Following the automatic reboot, when the green power light
remains on steady, open your browser as described in Access
the AT&T NetGate Web Interface on page 8. You may need to
disable then enable your Ethernet connection on your PC if the
IP addressing has changed due to VLAN configuration.
2. Click on the Control Panel navigation icon.
3. Click the entry for Network Settings to display the Network
Settings sub-menu and click the entry for Local LAN Settings
as shown in Figure 9.

19
Figure 9: Navigation to LAN Settings
4. The next window will display the Local LAN Settings. If VLANs
have been configured, the display will appear as in Figure 10. If
VLANs have not been configured, the display will appear as in
Figure 12. If no VLANs have been configured, skip to the
description for “Hub Mode” on page 22.
5. The display shows a number of rows, sorted by VLAN ID that
describes which back-panel Ethernet ports are assigned to each
VLAN.
The numbers in the Port column correspond to the numbers printed on
the back of the AT&T NetGate 8200.
6. Attach your Local LAN cables to an appropriate port based on
designated VLAN. If more than one port has been allocated to a
VLAN, any of those ports can be used.

20
Figure 10: Local LAN Settings - VLANs
7. If you are not sure of the Network-to-VLAN number mapping,
click on any of the VLAN ID hyperlinks to view detailed
information on the VLAN
8. The next window will display the details for the VLAN. The format
and content depend on factors such as whether DHCP or DHCP
relay are being used, or whether static IP addresses have been
configured. In the example for Figure 11, DHCP is configured
and so the range of IP addresses and subnet mask is displayed.
Information on any addresses already given out using DHCP will
also appear on this window.
