CALIFORNIA PUBLIC UTILITIES
COMMISSION
Advice Letter Filing Summary Sheet
(PAL)
(Date Filed / Received Stamp by CPUC Industry Division)
Date AL served on parties: July 20, 2010
Company Name: AT&T California CPUC Utility Number U -1001-C
Address: 525 Market Street, #1944 GRC-LEC URF-Carrier Other
City, State, ZIP: San Francisco, CA 94105 Commission Resolution Requested
Carrier of Last Resort (See D.96-10-066)
Filing #: 37837 Requested
Effective Date: July 20, 2010 AL Tier I II III
Name: Email Address: Phone No.: Fax No.:
Filer
Certif.
[email protected] (415) 778-1299
No. Tariff
Sheets: 0
(Name, email address & Phone and FAX numbers are Required for “Filer”)
Tariff Schedules: N/A Keyword: Compliance
For Contract Keyword, Type: Government Other Date Executed Contract
Total Rev ($)
Subject of filing:
(Service(s) included) Backup Power – Customer Education
Authorization for filing:
(Resolution #, Decision #, etc.) D.10-01-026
Affected services:
(Other services affected, pending or replacement AL filings)
Rate Element(s) affected and % change:
(Non-recurring and / or recurring)
Customer Notice Required (if so, please attach)
Notes/Comments:
(Other information & reference to advice letter, etc.)
File Protest and/or Correspondence to:
Director, Communications Division
505 Van Ness Ave., San Francisco, CA 94102
and if you have email capability, ALSO email to:
Protest also must be served on utility:
(see utility advice letter for more information)
GRC-LEC = Cost of Service LEC Carrier
URF-Carrier = Uniform Regulatory Framework Carrier
(see D.06-08-030/D.07-09-019)
OTHER = Wireless (CMRS) Carrier
(FOR CPUC USE ONLY)
Resolution Required
Executive Action Resolution Req’d.
TD Suspension on: ___ / ____ / ____
Comm. Suspension on: ___ / ___ / ___
Resolution No.: T - ____________
Rev. 09/24/07
Supv. / Analyst ________________ / ________________
Due Date to Supv.: _______________________________
Analyst Completion Date: _________________________
Supervisor Approval Date: ________________________
AL / Tariff Effective Date: _________________________
Notes: ___________________________________________
525 Market Street
Room 1944
San Francisco, CA 94105-2727 www.att.com
July 20, 2010
U 1001 C
Advice Letter No. 37837
Public Utilities Commission of the State of California
This advice letter is filed in compliance with Ordering Paragraph 2 of Decision (D.)10-01-026, which
requires facilities-based providers of telephony services who provide service to residential customers using
coaxial cable, fiber-optic cable or other technologies that require backup power on the customer’s premises
to file an information-only compliance advice letter detailing their customer education programs that comply
with D.10-01-026, including information and outreach.
Attached to this filing are copies of the materials that will be provided to the residential customers of AT&T
California who are provided telephony services using a technology that requires backup power on the
customer’s premises. Attachment A hereto is a copy of the materials that will be provided to new
customers by the time the service is installed. Attachment B hereto is a copy of the notice that will be
provided to existing customers on or before October 18, 2010 and annually thereafter. AT&T California’s
office for Disabled and Aging Customers will ensure that the material is available in formats its customers
can utilize. Copies of the material will be available in the languages in which AT&T markets its residential
services, including Spanish, Vietnamese, Korean, Chinese, Tagalog, Japanese, Russian and Polish.
However, to limit the size of the Advice Letter filing, only the English documents are attached.
In compliance with General Order 96-B, we are serving a copy of this advice letter on interested parties who
have requested it. We are also serving a copy on parties to Rulemaking 07-04-015. This advice letter
with attachments may be viewed on AT&T California’s Web-Site at https://ebiznet.att.com/calreg/. If there
are any questions regarding the distribution of this advice letter, call 415.778.1299.
Anyone may object to this advice letter, which was filed July 20, 2010, by sending a written protest to:
Telecommunications Advice Letter Coordinator, Communications Division, 505 Van Ness Avenue,
3rd Floor, San Francisco, CA 94102-3298. The protest must state specifically the grounds on which it is
based. The protest must be received by the Telecommunications Advice Letter Coordinator no later than
20 days after the date that the advice letter was filed. On or before the day that the protest is sent to the
Telecommunications Advice Letter Coordinator, the protestant must send a copy of the protest to
Eric Batongbacal, 525 Market Street, #1944, San Francisco, CA 94105 (fax number 415.543.3766). If this
advice letter was served via e-mail, the protest must be served to AT&T California via e-mail at
protests, go to the Commission’s Internet site (www.cpuc.ca.gov) and look for document links to General
Order 96-B.
Yours truly,
AT&T California
Executive Director
Attachments
AT&T California Advice Letter Service List
Via U.S. Mail
Shascom 9-1-1 Shascom 9-1-1 Tyco Electronics Power Systems Integra Telecom Holdings, Inc.
Joy Willis Kathy Galey Natasha Hood Sheila Harris
Operations Manager Systems Administrator 2043 Loggia Manager, Government Affairs
3101 South Street 3101 South Street Newport Beach, CA 92660-9039 1201 NE Lloyd Blvd., Ste. 500
Redding, CA 96001 Redding, CA 96001 Portland, OR 97232
Via e-mail
AT&T California Advice Letter Service List
Page 2
Via e-mail
ATTACHMENT A: MATERIALS PROVIDED TO NEW CUSTOMER BY TIME OF INSTALLATION
Important Customer Information Regarding your AT&T Voice and Internet Service
Traditional Telephone Service over Fiber to the Premises
AT&T DC UPS Operation Manual
CyberPower PSU
U-verse Voice
Back-up Power for RG & ONT
Back-up Power for iNID
ATTACHMENT B: ANNUAL NOTICE
Traditional Telephone Service over Fiber to the Premises
Notice
Material found at att.com/batterybackup
U-verse Voice
Notice
Material found at att.com/newbattery
Important Customer Information Regarding your AT&T Voice and Internet Service
Please retain for your records
Required Optical Network Terminal Battery Backup Power
Your AT&T voice and Internet services require electrical power from your home to operate. Electricity
from your home powers the Optical Network Terminal (ONT), an equipment box where AT&T’s fiber
network terminates and inside wiring for your home originates. AT&T provides a Power Supply Unit
(PSU) for the ONT, which can be placed within 100 feet of the ONT and is installed inside your home or
garage. AT&T supplies an initial backup battery in the PSU for the first resident of the premises where
AT&T services are installed. All subsequent backup batteries are the responsibility of the customer at the
premises.
If a power outage occurs, you will not be able to make or receive calls, including 911 calls, unless you
have battery backup power for the ONT. During a power outage, if you wish to conserve battery power
for making and receiving necessary calls, you should avoid making unnecessary calls and not use AT&T
Internet service. (If you have AT&T Internet or U-verse Voice service(s), there are additional
requirements for battery backup power for the Residential Gateway—see Note #1 below).
Optical Network Terminal Backup Battery Replacement
You are responsible for monitoring the backup battery and will need to replace it when necessary. AT&T
shall have no liability for the failure of your service to function during a power outage, including failure due
to the absence or insufficiency of battery backup power. For ONT battery replacement and recycling
please contact GS Battery (USA) Inc. at 1.800.472.2879 or www.gsbattery.com.Be sure to have the
battery model number available, which is PX12072-HG. The battery number is also located on the label
on the side of the battery. AT&T does not supply replacement batteries.
You may also be able to purchase replacement batteries through other suppliers (e.g., Batteries Plus,
Radio Shack and via the Internet from Amazon or Sears). Batteries must be of the 12-volt - 7.2 amp hour
variety with F2 Faston connectors and a size not to exceed 6.05” Length x 2.6” Depth x 4.05” Height.
Locations where batteries are available are subject to change.
Portable generators with 120-volt outlets and extension cords will power the PSU in the event of extended
power outages. See manufacturer details for operating and safety procedures when using a portable
generator. Other 120-volt PSU backup solutions may be available at certain home and electronics stores
(e.g., Uninterruptible Power Sources (UPSs) and Duracell®Standby Power Plugs).
Determine the Power Supply Unit (PSU) type
On the front of the PSU is a label that shows the Serial Number, designated by S/N. If the S/N starts with
DAE this is a Delta PSU. If the S/N starts with CYB this is a CyberPower PSU. See also the images
below.
Delta PSU CyberPower PSU
How to tell when to replace your battery
Delta PSU:
There are status lights on the front right of the Delta PSU. Refer to the Replace Battery and Missing
Battery status lights. The Replace Battery status light will be red if the battery needs to be replaced. An
audible alarm will also sound, with one beep every fifteen minutes, when the battery needs to be
replaced. When the power supply begins using battery power, it will beep once and then remain silent.
While running on battery power, if the battery begins to run low, the alarm will beep four times per minute.
ATTACHMENT A
ATTACHMENT A - Page 1 of 33
The alarm can be silenced for 24 hours by pushing the blue button on the front of the power supply. The
Missing Battery status light will be green if no battery is connected to the power supply.
For more information see the owner’s manual: att.com/batterybackup.
CyberPower PSU:
There are status lights on the front right of the CyberPower PSU. Refer to the Replace Battery and
Missing Battery status lights. The Replace Battery status light will be red if the battery needs to be
replaced. An audible alarm will also sound, with two beeps every three minutes when the battery needs
to be replaced. While running on battery power, if the battery begins to run low, the alarm will beep four
times every two minutes. The alarm can be silenced for 24 hours by pushing and holding the blue button
on the front of the power supply for three seconds. The Missing Battery status light will be red if no
battery is connected to the power supply.
For more information see the owner’s manual: att.com/batterybackup.
Replacing the Battery
Open the door, carefully pull the battery off the shelf and remove the black and red wires. Connect the
black (-) and red (+) wires onto the new battery noting the proper battery polarity. Slide the new battery
onto the shelf and secure. Close the door.
NOTE #1: If you have AT&T U-verse services (voice, high speed Internet, and/or TV), you must also have
battery backup power for the Residential Gateway for your AT&T U-verse services to function during a
power outage. For Residential Gateway battery-replacement and recycling information contact BELKIN
at 866-539-5791 or www.belkin.com/gatewaybattery. For more information, please refer to your Feature
Guide and your Belkin® | Residential Gateway Battery Backup User Manual.
NOTE #2: If you have Internet Service, you must provide battery backup power for your computer, if you
would like to have access to the Internet during a power outage. For example, your computer could be
plugged into an Uninterruptible Power Source (UPS), available at certain home and electronics stores.
NOTE #3: If you have a monitored home alarm that uses AT&T voice or Internet service as the
communications pathway, your monitored home alarm will not function during a power outage without
battery backup power for your AT&T voice or Internet service, as applicable. (AT&T voice service requires
ONT battery backup power, and AT&T U-verse services, including AT&T U-verse voice service, requires
both ONT and Residential Gateway battery backup power to function during a power outage).
NOTE #4: The ONT battery backup will not power cordless phones, home alarm panels, or other
equipment, such as telecommunications devices used to assist customers with disabilities, that are
connected to the telephone line and require electricity from the customer’s premises.
NOTE #5: A new, fully charged ONT backup battery will provide four to eight hours of backup power.
Actual results will vary, depending, among other things, on battery age, usage patterns, and
environmental conditions, including temperature extremes and fluctuations. To conserve battery backup
power for emergency calls, you should not use Internet services, U-verse TV or make unnecessary voice
calls during a power outage.
If you have any additional questions, please call 1.800.ATT.2020 or 1.800.288.2020.
ATTACHMENT A
ATTACHMENT A - Page 2 of 33
AT&T DC UPS
Operation Manual
(Leave with Customer)
DC UPS Operation Manual, Rev 1.0 Page: 1 of 8
ATTACHMENT A
ATTACHMENT A - Page 3 of 33
DC UPS Operation Manual, Rev 1.0 Page: 2 of 8
TABLE OF CONTENTS
1................................................................................................................................................................................................. 3PRODUCT INTRODUCTION
1.1 GENERAL DESCRIPTION.....................................................................................................................................................................................................3
1.2 COMPONENTS......................................................................................................................................................................................................................3
2.............................................................................................................................................................................................. 4IMPORTANT SAFETY NOTES
2.1 ELECTRICAL WARNINGS ...................................................................................................................................................................................................4
2.2 .........................................................................................................................................................................................................4BATTERY WARNINGS
2.3 SAFETY WARNING LABEL..................................................................................................................................................................................................5
3.............................................................................................................................................................................................................................. 6OP RATIONE CONTROL3.1 ............................................................................................................................................................................................................................6
3.2 ..........................................................................................................................................................................................................7OPERATIONAL LEDS
3.3 ...............................................................................................................................................................................................................................7ALARMS
3.4 ...............................................................................................................................................7ALARM LEDS AND CORRESPONDING AUDIBLE ALARMS
3.5 AUDIBLE ALARM ................................................................................................................................................................................................................7
4........................................................................................................................................................................................................................ 8MAINTENANCE
4.1 MAINTENANCE MODE........................................................................................................................................................................................................8
4.2 CUSTOMER BATTERY REPLACEMENT..............................................................................................................................................................................8
TABLE OF FIGURES
Figure 1: DC UPS Power Supply and ONT System Configuration...................................................................................................................3
Figure 2: Warning Label .......................................................................................................................................................................................5
Figure 3: DC UPS Front Panel LEDs and Control..............................................................................................................................................6
Figure 4: DC UPS Front Panel LEDs ...................................................................................................................................................................7
Figure 5: Battery Replacement...........................................................................................................................................................................8
TABLE OF TABLES
Table 1: Customer Button Operation..................................................................................................................................................................6
Table 2: LED Indicators ........................................................................................................................................................................................7
Table 3: Audible Alarm .........................................................................................................................................................................................7
Table 4: Audible Alarm Actions...........................................................................................................................................................................7
ATTACHMENT A
ATTACHMENT A - Page 4 of 33
1 PRODUCT INTRODUCTION
1.1 General Description
The DC UPS (ONT Uninterruptable Power Supply with Battery Back-Up Unit) is designed to be
mounted inside a customer premises. The DC UPS converts 120/230Vac to 12Vdc and provides
four to eight hours of backup battery power for lifeline POTS and Ethernet services in the ONT.
Alarm outputs are available on the DC UPS to monitor the status of the backup battery
(On/Low/Faulty/Missing). The DC UPS indicates its status to the resident with LEDs and audible
alarms and to the outdoor ONT by a signal return connection.
1.2 Components
The DC UPS consists of a dedicated 120V/230ac to 12Vdc power supply with Battery Backup
and dedicated support cables.
The DC UPS houses a dedicated battery charger to maintain a 12Vdc, 7.2Ah lead-acid sealed
battery, battery monitoring and alarm circuitry. It contains four indicator LEDs to provide
operational status at a glance, status audible alarms, and one customer-operation button to
silence the audible alarm for 24 hours.
Figure 1: DC UPS Power Supply and ONT System Configuration
DC UPS Operation Manual, Rev 1.0 Page: 3 of 8
ATTACHMENT A
ATTACHMENT A - Page 5 of 33
DC UPS Operation Manual, Rev 1.0 Page: 4 of 8
2 IMPORTANT SAFETY NOTES
ONLY qualified installation and repair personnel should service this power supply.
SAVE THESE INSTRUCTIONS - This manual contains important instructions for the
DC UPS units that should be followed during maintenance.
Batteries may produce hazardous currents and may present a burn hazard if
damaged or shorted.
The following precautions should be observed when working on the unit:
1. Remove watches, rings, or other metal objects.
2. Wear protective clothing and eye protection when working with batteries and installing
this equipment.
3. Always carry a water supply to wash eyes and/or skin if exposed to battery electrolyte.
4. Use tools with insulated handles.
5. Examine the packing container for damage. Notify the carrier immediately if damage is
present.
6. Do not disassemble the unit.
7. Do not operate near water or excessive humidity.
8. Keep liquid and foreign objects from getting inside the unit.
9. Do not operate close to gas or fire.
10. Do not operate unit near leaking liquid or if any liquid residue is present.
11. Immediately unplug Power Supply from AC if you see liquid leaking
12. ABP power source needs to use Alkaline battery (1.5V*12pcs)
2.1 Electrical Warnings
Servicing this equipment may require working with protective covers removed and utility
power connected. Use extreme caution during these procedures.
Check that the power cord(s), plug(s), and outlets are in good condition.
No user serviceable components other then the battery are present in the DC UPS.
2.2 Battery Warnings
Battery Warranty is top-charge date plus thirty-six months. Replacement battery should be
PX12072F2-HG. Replacement battery can be ordered by contacting GS Battery at 1-800-
472-2879 or www.gsbattery.com.
Danger of explosion if battery is incorrectly connected or replaced.
Worn-out or damaged batteries are considered environmentally unsafe. Always recycle used
batteries or dispose of the batteries in accordance with all federal, state and local
regulations.
Any gel or liquid emissions from the sealed lead-acid (SLA) battery contain sulfuric acid,
which is harmful to the skin and eyes. Emissions are electrically conductive and corrosive.
Batteries may produce explosive gases. Keep all open flames and sparks away from
batteries.
Batteries contain or emit chemicals known to the State of California to cause cancer and
birth defects or other reproductive harm. Battery post terminals and related accessories
contain lead and lead compounds. Wash hands after handling (California Proposition 65).
Wear protective clothing and eye protection whenever installing, maintaining, servicing, or
replacing batteries.
If any battery emission contacts the skin, immediately and thoroughly wash with water.
Follow approved chemical exposure procedures.
ATTACHMENT A
ATTACHMENT A - Page 6 of 33
Neutralize any spilled battery emission with the special solution contained in an approved
spill kit or with a solution of one pound Bicarbonate of soda to one gallon of water. Report
chemical spills and seek medical attention if necessary.
Never use un-insulated tools or other conductive materials when installing, maintaining,
servicing or replacing batteries.
A battery showing signs of cracking, leaking, or swelling should be replaced immediately
with a battery of identical type and rating.
2.3 Safety Warning Label
The AC power cord is supplied with the warning label “DO NOT UNPLUG! – Power Supply for
Voice, 911 Dialing, and Battery Charging” attached to the cord.
Figure 2: Warning Label
!DO NOT UNPLUG! – Power Supply
for Voice, 911 Dialing, and Battery Charging.
DC UPS Operation Manual, Rev 1.0 Page: 5 of 8
ATTACHMENT A
ATTACHMENT A - Page 7 of 33
3 OPERATION
3.1 Control
Figure 3: DC UPS Front Panel LEDs and Control
One user control is present in the form of one blue button on the front cover of the DC UPS.
This alarm-silence button will quiet the audible alarm for 24 hours. After 24 hours the alarm will
reactivate if the fault condition has not been corrected.
Function Symbol Type Location Function
Alarm
Silence Push Front
Cover Press & hold 1~2 seconds to mute alarm for 24hrs.
Table 1: Customer Button Operation
DC UPS Operation Manual, Rev 1.0 Page: 6 of 8
ATTACHMENT A
ATTACHMENT A - Page 8 of 33
3.2 Operational LEDs
Figure 4: DC UPS Front Panel LEDs
Four status LEDs are displayed on the front panel of the DC UPS. The operation of the DC UPS
can be assessed using these LEDs.
Table 2: LED Indicators
3.3 Alarms
There are audible and visual alarm signals to alert the customer to abnormal and/or service
affecting conditions present in the DC UPS.
3.4 Alarm LEDs and Corresponding Audible Alarms
TYPE Condition Buzzer
ON Battery Battery being discharged Beeps ONCE during switchover to
battery back-up
Low Battery Reached about 90% discharge Beeps 4 times per minute
Replace Battery Battery failed self test Beep once every 15 minutes
Missing Battery No battery installed or battery
disconnected None
Table 3: Audible Alarm
3.5 Audible Alarm
TYPE Condition Buzzer
Input Power Fail Loss of input power 1 second beep at power loss
Replace Battery Battery failed self test Beep once every 15 minutes
Low Battery Reached about 90% discharge Beeps 4 times/minute
Table 4: Audible Alarm Actions
DC UPS Operation Manual, Rev 1.0 Page: 7 of 8
ATTACHMENT A
ATTACHMENT A - Page 9 of 33
4 MAINTENANCE
4.1 Maintenance Mode
Every 45 days the DC UPS automatically self tests the battery to determine its remaining useful
life. No user intervention is needed. If the unit detects a failed battery, the “Replace Battery”
LED indicator on the unit will light and the audible alarm will beep once every 15 minutes.
4.2 Customer Battery Replacement
Battery replacement is detailed on a label located inside the front cover of the DC UPS.
Remove the Battery:
1. Open the front cover of the DC UPS by depressing the tab located at bottom of unit.
2. Detach the Velcro and pull out the old battery.
3. Disconnect the battery terminals (“+” & “-“) of DC UPS.
4. Remove the battery.
Install the Battery:
1. Reconnect “+” & ”-“ terminals to the new identical type battery.
2. Install the new battery.
3. Attach the Velcro and make sure the wires of the battery are free and not pinched by the
battery or door.
4. Close the door of the DC UPS.
Figure 5: Battery Replacement
DC UPS Operation Manual, Rev 1.0 Page: 8 of 8
ATTACHMENT A
ATTACHMENT A - Page 10 of 33
CyberPower ATT3612V3S (Leave Behind Manual) Page: 1 of 11
CyberPower ATT36A12V3S
(Leave Behind Manual)
ATTACHMENT A
ATTACHMENT A - Page 11 of 33
CyberPower ATT3612V3S (Leave Behind Manual) Page: 2 of 11
TABLE OF CONTENTS
1PRODUCT INTRODUCTION .................................................................................................................3
1.1 GENERAL DESCRIPTION ................................................................................................................3
1.2 COMPONENTS...............................................................................................................................3
2IMPORTANT SAFETY NOTES..............................................................................................................4
2.1 ELECTRICAL WARNINGS................................................................................................................4
2.2 BATTERY WARNINGS ....................................................................................................................4
2.3 SAFETY WARNING LABEL..............................................................................................................5
3POWER SUPPLY OVERVIEW ..............................................................................................................6
3.1 OVERVIEW....................................................................................................................................6
4OPERATION ..........................................................................................................................................7
4.1 START-UP....................................................................................................................................7
4.2 CONTROLS ...................................................................................................................................7
4.3 OPERATIONAL LEDS....................................................................................................................7
4.4 AUXILLARY POWER CONNECTION..................................................................................................8
4.5 ALARMS .......................................................................................................................................8
5MAINTENANCE .....................................................................................................................................9
5.1 MAINTENANCE MODE....................................................................................................................9
5.2 CUSTOMER BATTERY REPLACEMENT.............................................................................................9
6SPECIFICATIONS................................................................................................................................11
TABLE OF FIGURES
Figure 1: CyberPower Power Supply and ONT System Configuration.................................................3
Figure 2: Warning Label..............................................................................................................................5
Figure 3: Unit Overview (Front)..................................................................................................................6
Figure 4: Front Panel LED and Controls ...................................................................................................7
Figure 5: Auxiliary Power Connection.......................................................................................................8
Figure 6-8: Customer Battery Replacement ……………………………………………………………… 9-10
TABLE OF TABLES
Table 1: Customer Button Operation.........................................................................................................7
Table 2: LED Indicators...............................................................................................................................7
Table 3: Alarms............................................................................................................................................8
Table 4: Specifications..............................................................................................................................11
ATTACHMENT A
ATTACHMENT A - Page 12 of 33
CyberPower ATT3612V3S (Leave Behind Manual) Page: 3 of 11
1 PRODUCT INTRODUCTION
1.1 General Description
The ONT-BBPSU (Optical Network Terminal Uninterruptable Battery Backup Power Supply Unit)
is designed to be mounted inside a customer premises and provides power to the ONT. The
Optical Network Terminal (ONT) is an equipment box typically installed on the outside of your
home, where the fiber network terminates and the inside wiring for your home originates. The
BBPSU supports wireline voice communications services by converting 120/230Vac to 12Vdc.
AT&T supplies the initial backup battery for the BBPSU to the first resident of the premises
where AT&T services are installed. All subsequent backup batteries are the responsibility of the
customer at the premises. When equipped with a new, fully charged battery, the BBPSU
provides four to eight hours of backup battery power. Actual results will vary, depending,
among other things, on battery age, usage patterns, and environmental conditions. To
conserve battery backup power for emergency calls, you should not use Internet services during
a power outage.
1.2 Components
The ATT3612V3S unit consists of a dedicated 120/230Vac to 12Vdc power supply with Backup
Battery and dedicated support cables.
The ATT3612V3S unit houses a dedicated battery charger to maintain a 12Vdc, 7.2Ah sealed
lead-acid battery, battery monitoring and alarm circuitry. It contains four indicator LEDs to
provide operational status at a glance, status audible alarms, and one customer-operation
button to silence the audible alarm for 24 hours.
Figure 1: CyberPower Power Supply and ONT System Configuration
ATTACHMENT A
ATTACHMENT A - Page 13 of 33
CyberPower ATT3612V3S (Leave Behind Manual) Page: 4 of 11
2 IMPORTANT SAFETY NOTES
ONLY qualified installation and repair personnel should service this power supply.
SAVE THESE INSTRUCTIONS - This manual contains important instructions for the
ATT3612V3S units that should be followed during installation and maintenance.
Verify the supplied AC line voltage prior to installation using an AC voltage meter.
Verify branch circuit breaker or fuse on the service feed is correct for the equipment
being installed.
Batteries may produce hazardous currents and may present a burn hazard if
damaged or shorted.
The following precautions should be observed when working on the unit:
1. Remove watches, rings, or other metal objects.
2. Wear protective clothing and eye protection when working with batteries and installing
this equipment.
3. Always carry a water supply to wash eyes and/or skin if exposed to battery electrolyte.
4. Use tools with insulated handles.
5. Examine the packing container for damage. Notify the carrier immediately if damage is
present.
6. Do not disassemble the unit.
7. Do not operate near water or excessive humidity.
8. Keep liquid and foreign objects from getting inside the unit.
9. Do not operate close to gas or fire.
10.Do not operate unit near leaking liquid or if any liquid residue is present.
11.Immediately unplug Power Supply from AC if you see liquid leaking.
2.1 Electrical Warnings
Servicing this equipment may require working with protective covers removed and utility
power connected. Use extreme caution during these procedures.
Check that the power cord(s), plug(s), and outlets are in good condition.
No user serviceable components other then the battery are present in the ATT3612V3S unit.
2.2 Battery Warnings
Battery Warranty is top-charge date plus thirty-six months. Replacement battery should be
Model # PX12072F2-HG. Replacement battery can be ordered by contacting GS Battery at
1-800-228-7078 or www.gsbattery.com.
Danger of explosion if battery is incorrectly connected or replaced.
Worn-out or damaged batteries are considered environmentally unsafe. Always recycle used
batteries or dispose of the batteries in accordance with all federal, state and local
regulations.
Any gel or liquid emissions from the sealed lead-acid (SLA) battery contain sulfuric acid,
which is harmful to the skin and eyes. Emissions are electrically conductive and corrosive.
Batteries may produce explosive gases. Keep all open flames and sparks away from
batteries.
Batteries contain or emit chemicals known to the State of California to cause cancer and
birth defects or other reproductive harm. Battery post terminals and related accessories
contain lead and lead compounds. Wash hands after handling (California Proposition 65).
ATTACHMENT A
ATTACHMENT A - Page 14 of 33
CyberPower ATT3612V3S (Leave Behind Manual) Page: 5 of 11
Wear protective clothing and eye protection whenever installing, maintaining, servicing, or
replacing batteries.
If any battery emission contacts the skin, immediately and thoroughly wash with water.
Follow approved chemical exposure procedures.
Neutralize any spilled battery emission with the special solution contained in an approved
spill kit or with a solution of one pound Bicarbonate of soda to one gallon of water. Report
chemical spills and seek medical attention if necessary.
Never use un-insulated tools or other conductive materials when installing, maintaining,
servicing or replacing batteries.
A battery showing signs of cracking, leaking, or swelling should be replaced immediately
with a battery of identical type and rating.
2.3 Safety Warning Label
The AC power cord is supplied with the warning label “DO NOT UNPLUG! – Power Supply for
Voice, 911 Dialing, and Battery Charging” attached to the cord.
Figure 2: Warning Label
!DO NOT UNPLUG! – Power Supply
for Voice, 911 Dialing, and Battery Charging.
ATTACHMENT A
ATTACHMENT A - Page 15 of 33
Other manuals for DC
1
Table of contents
Other AT&T UPS manuals
