1
ATD-6900
9 Pc. HVLP Spray Gun Set
Owner’s Manual
Read this manual carefully and understand it completely.
Retain manual for future use.
Always follow safety precautions to prevent personal injury and/or damage to the equipment.
Illustrations and photos are intended for reference only. Actual product may vary.
Specifications are subject to change without notice.
Important Safety Instructions
1. Always wear eye protection, gloves and respirator to prevent against harmful vapors while spraying.
2. Never use oxygen or any other combustible or bottle gas as a propellant. Explosion and serious
injury or death may result.
3. Many paints and solvents can be highly flammable. Please use the spray gun only on well-ventilated
areas, do not smoke or use near open flame.
4. Always disconnect the paint gun from air supply when not in use and during maintenance.
For emergency stopping and to prevent unintended operation, a valve near the gun is recommended.
5. Inspect the tool before each use to ensure there is no leakage or misaligned parts.
Be sure the trigger moves freely.
6. Never use halogenated hydrocarbon solvent, as it can chemically react with aluminum and zinc parts
of this tool.
7. Do not make any modifications to this tool.
WARNING: This product contains chemicals, including lead, known to the State of California to cause cancer,
birth defects or other reproductive harm. Wash hands after handling.
Made in China to ATD Tools, Inc. Specications
Visit us at www.atdtools.com

Figure 1:
2
Operating Instructions
POWER SOURCE
This tool operates best on a clean, dry supply of compressed air delivered at 29 to
50 psi. Use of a moisture trapping air filter (ATD-7812) is highly recommended as
CAUTION: All air pressure in the system should be rated at 29 to 50 psi. Higher or
lower pressure can adversely influence the operation or cause damage to this tool.
NOTE: To maintain 10 psi at the nozzle, use a minimum of 29 psi at the inlet.
TOOL PREPERATION
1. Check tool for worn or damaged parts. Repair or replace as necessary.
2. Check trigger to ensure that it moves freely.
3. Connect tool to air supply.
4. Adjust air pressure based on paint viscosity and paint manufacturer’s
recommendation. (fig 2)
5. Clean paint guns before use, to ensure any factory oils or pigments are not present.
Do not use halogen hydrocarbon or acidic solvents to clean paint guns.
6. Pour paint into cup.
Figure 2:
moisture or foreign matter can damage the internal parts of this tool.

GUN HANDLING
For best results, please follow these basic guidelines:
1. Keep the spray gun perpendicular to the surface. Spraying in an arc will not
give good results. (Fig. 3)
2. Keep gun moving from one side to the other while spraying. If you stop
moving the gun while you are spraying, too much paint will build up and
begin to run. Begin the horizontal movement of the gun before you begin
spraying. Also, keep the gun at a constant distance 6-12 inches from the
surface. (Fig. 4)
3
Figure 3 – INCORRECT
Figure 4 – CORRECT

4
ADJUSTMENT
1. Fine-tune the gun to your desired working settings of spray patterns, fluid
output and degree of paint atomization using the three controls illustrated in
Figure 5.
Figure 5
Maintenance
To clean the gun, pour any leftover paint back into its container. Using thinner,
clean out the paint cup and cap. Spray some thinner through the gun to clean the
spray head, needle and nozzle. Spray until thinner comes out clean. Clean all paint
passages as any paint left in the gun and allowed to dry can clog the spray head.
Wipe the exterior of the gun with the cleaning brush included and a soft cloth
moistened with thinner. If you remove the needle, remove the nozzle as well to
protect the seat. NEVER DIG WITH A WIRE OR HARD OBJECT AS THIS CAN
DAMAGE THE NEEDLE SEAT. Remove all such paint before it has a chance to
dry.
Fluid (paint)
Adjustment Knob
Spray Pattern
Adjustment Knob
Air
Adjustment Knob

5
ATD-6900
ATD-6901
1.4mm Gun
(See drawing for parts)
ATD-6902
1.8mm Gun
(See drawing for parts)
ATD-6903
1.0mm Gun
(See drawing for parts)
ATD-6926
Regulator
PRT6900-TK
Tool Cleaning Kit
ATD-7812
Spray Gun Filter

6
ATD-6901
1.4mm Gun
NOITPIRCSEDTRAP#TRAPGNIREDRO#METINOITPIRCSEDTRAP#TRAPGNIREDRO#METI 1 PRT6900-01 AIR ADJUSTASSY 9PRT6900-09 CUP
2 PRT6900-02 AIR VALVE ASSEMBLY 10 PRT6900-10 FILTER (PACK OF 10)
3* PRT6900-1.4 1.4mm TIP KIT (NEEDLE, FLUID NOZZLE, AIR CAP) 11 PRT6900-11 FLUID ADJUSTASSEMBLY
4PRT6900-04 FLUID NOZZLE PLUG 12 PRT6900-12 PATTERN ADJUST ASSEMBLY
5PRT6900-05 FLUID NOZZLE WASHER 13 PRT6900-13 GUN BODY
6PRT6900-06 NEEDLE PACKING ASSEMBLY 14 PRT6900-14 AIR INLET FITTING
7PRT6900-07 ROTALUGER6296-DTA51
YLBMESSAREGGIRT
8PRT6900-08 LLA(TIKRIAPERKR-0096TRPA/NPUCROFDIL SEALS AND SPRINGS)
* - Parts available as set only

7
ATD-6902
1.8mm Gun
NOITPIRCSEDTRAP#TRAPGNIREDRO#METINOITPIRCSEDTRAP#TRAPGNIREDRO#METI 1 PRT6900-01 AIR ADJUST ASSY 9PRT6900-09 CUP
2 PRT6900-02 AIR VALVE ASSEMBLY 10 PRT6900-10 FILTER (PACK OF 10)
3* PRT6900-1.8 1.8mm TIP KIT (NEEDLE, FLUID NOZZLE, AIR CAP) 11 PRT6900-11 FLUID ADJUSTASSEMBLY
4PRT6900-04 FLUID NOZZLE PLUG 12 PRT6900-12 PATTERN ADJUST ASSEMBLY
5PRT6900-05 FLUID NOZZLE WASHER 13 PRT6900-13 GUN BODY
6PRT6900-06 NEEDLE PACKING ASSEMBLY 14 PRT6900-14 AIR INLET FITTING
7PRT6900-07 ROTALUGER6296-DTA51
YLBMESSAREGGIRT
8PRT6900-08 LLA(TIKRIAPERKR-0096TRPA/NPUCROFDIL SEALS AND SPRINGS)
* - Parts available as set only

8
ATD-6903
1.0mm Gun
NOITPIRCSEDTRAP#TRAPGNIREDRO#METINOITPIRCSEDTRAP#TRAPGNIREDRO#METI 1 PRT6900-16 AIR ADJUSTASSY 9PRT6900-22 FLUID INLET JOINT
2 PRT6900-17 AIR VALVE ASSEMBLY 10 PRT6900-23 FLUID ADJUST ASSY
3* PRT6900-1.0 1.0mm TIP KIT (NEEDLE, FLUID NOZZLE, AIR CAP) 11 PRT6900-24 PATTERN ADJUST ASSY
4PRT6900-18 NEEDLE PACKING ASSEMBLY 12 PRT6900-25 GUN BODY
5PRT6900-19 TRIGGER ASSEMBLY 13 PRT6900-26 AIR INLET FITTING
6PRT6900-20 LID FOR CUP 14 ATD6926 REGULATOR
7PRT6900-21 )
SGNIRPSDNASLAESLLA(TIKRIAPER0.1
KR-0096TRPA/NPUC
8PRT6900-10 FILTER (PACK OF 10)
(Rev 06/16)
* - Parts available as set only
