Athos Pro QA5616 User manual

1
User manual
4G Smart phone Athos Pro
Model No.: QA5616

2
Contents
Safety....................................................................................................................4
Environment........................................................................................................5
1 Getting Started.................................................................................................6
1.1 Getting to know your touch phone ....................................................6
1.2 Installing the SIM card, battery, and storage card .............................6
1.3 Charging the Battery..........................................................................7
1.4 Starting up the device.........................................................................8
1.5 Status Icons......................................................................................10
2 Using phone features .....................................................................................12
2.1 Turning the phone function on and off ............................................12
2.2 Making a call ...................................................................................12
2.3 Answering and Ending a call ...........................................................12
2.4 In-call options ..................................................................................13
2.5 Using call history.............................................................................13
2.6 Call settings......................................................................................14
3 Setting on your device....................................................................................14
4 ActiveSync.......................................................................................................17
5 Contacts ..........................................................................................................20
6 Exchanging Messages ....................................................................................22
7 Internet ...........................................................................................................27
7.1 Ways of Connecting to the Internet .................................................27
7.2 Browser............................................................................................27
8 Experiencing Multimedia..............................................................................29
8.1 Camera & Picture.............................................................................29
8.2 Music................................................................................................32
8.3 FM Radio.........................................................................................34
8.4 Sound record....................................................................................34
9 Other applications..........................................................................................34

3
9.1 Calendar...........................................................................................34
9.2 Alarm Clock.....................................................................................35
9.3 Calculator.........................................................................................36
10 Play Store*....................................................................................................37

4
Safety
Never attempt to disassemble your phone. You alone are responsible for how
you use your phone and any consequences of its use.
As a general rule, always switch off your phone wherever the use of a phone is
prohibited. Use of your phone is subject to safety measures designed to protect
users and their environment.
Do not use your phone in damp areas (bathroom, swimming pool…). Protect it
from liquids and other moisture.
Do not expose your phone to extreme temperatures lower than - 10°C and
higher than + 55°C.
The physicochemical processes created by chargers impose temperature limits
when charging the battery. Your phone automatically protects the batteries in
extreme temperatures.
Do not leave your phone within the reach of small children (certain removable
parts may be accidentally ingested).
Electrical safety: Only use the chargers listed in the manufacturer’s catalogue.
Using any other charger may be dangerous; it would also invalidate your
warranty. Line voltage must be exactly the one indicated on the charger’s serial
plate.
Aircraft safety: When traveling by plane, you will need to switch your phone
off when so instructed by the cabin crew or the warning signs.
Using a mobile phone may be dangerous to the operation of the aircraft and may
disrupt the phone network.
Its use is illegal and you could be prosecuted or banned from using cellular
networks in the future if you do not abide by these regulations.
Explosive materials: Please comply with warning signs at petrol station asking
you to switch your phone off. You will need to comply with radio equipment
usage restrictions in places such as chemical plants, fuel depots and at any
location where blasting operations are under way.
Electronic equipment: To avoid the risk of demagnetization, do not let
electronic devices close to your phone for a long time.
Electronic medical equipment: Your phone is a radio transmitter which may
interfere with electronic medical equipment or implants, such as hearing aids,
pacemakers, insulin pumps, etc. It is recommended that a minimum separation
of 15 cm be maintained between the phone and an implant. Your doctor or the

5
manufacturers of such equipment will be able to give you any advice you may
need in this area.
Hospitals: Always make sure that your phone is switched off in hospitals when
so instructed by warning signs or by medical staff.
Road safety: Do not use your phone when driving. In order to give your full
attention to driving, stop and park safely before making a call. You must comply
with any current legislation.
Distance of operation: This phone model has been tested and meets
radiofrequency exposure guidelines when used as follows:
• Against the ear: Place or receive a phone call and hold the phone as you would
a wire line telephone.
• Body worn: When transmitting, place the phone in a carry accessory that
contains no metal and positions the phone a minimum of 2.5 cm form your body.
Use of other accessories may not ensure compliance with radiofrequency
exposure guidelines. If you do not use a body worn accessory and are not
holding the phone at the ear, position the phone a minimum of 2.5 cm from your
body,
• Data operation: When using a data feature, position the phone a minimum of
2.5 cm from your body for the whole duration of the data transmission.
Environment
Packaging: To facilitate the recycling of packaging materials, please obey the
sorting rules instituted locally for this type of waste.
Batteries: Spent batteries must be deposited at the designated collection points.
The product: The crossed-out waste bin mark affixed to the product means that
it belongs to the family of electrical and electronic equipment.
To promote the recycling and recovery of waste electrical and electronic
equipment (WEEE) and at the same time safeguard the environment, European
regulations require you to obey the sorting rules instituted locally for this type
of waste.

6
1 Getting Started
1.1 Getting to know your touch phone
1.2 Installing the SIM card, battery, and storage card
You need to remove the back cover before you can install the SIM card and
battery. Also, make sure to always turn off the power before installing or
replacing the SIM card and battery.
To remove the back cover
1. Make sure your device is turned off.
2. Firmly hold the device with both hands and the front panel facing down.
3. Push the back cover up with your thumbs until it disengages from the device
and then slide it up to remove.
To remove the battery
1. Make sure your device is turned off.
2. Remove the back cover.
3. The bottom of the phone has a notch. Lift the battery by the notch to remove
it.
To install the SIM card
The SIM card contains your phone number, service details, and phonebook/
message memory. Your device is supported 2G, 3G (WCDMA) or 4G
(FDD_LTE) SIM cards.
1. Remove the battery if it is installed.
2. Locate the SIM card slot, and then insert the SIM card with its gold contacts
facing down and its cut-off corner facing out the card slot.
3. Slide the SIM card completely into the slot.
Note: • The phone can be supported the double SIM cards. The card slot
will be supported 3G (WCDMA) or 4G SIM card (FDD_LTE), but one SIM
card can use 4G networks only.
If you need to use 4G operation, please insert 4G card in the card slot
(network type is default 4G, defined in the menu Settings/More/Cellular
networks/Preferred network type), If insert 3G or 2G card in the card slot,
you can also use 3G or 2G operation only.

7
• Some legacy SIM cards may not function with your device. You should
consult with your service provider for a replacement SIM card. There may
be fees for this service.
To install a memory card
To have additional storage for your images, videos, music, and files, you can
purchase a memory card and install it into your device.
1. Make sure that your device is turned off, and then remove the back cover.
2. Locate the memory card slot on the upper part of the exposed right panel.
3. Insert the memory card into the slot with its gold contacts facing down until it
clicks into place.
Note: To remove the memory card, press it to eject it from the slot.
To install the battery
Your device comes with a rechargeable Lithium-ion battery and is designed to
use only manufacturer-specified original batteries and accessories. Battery
performance depends on many factors, including network configuration, signal
strength, and usage patterns.
Warning: To reduce risk of fire or burns:
• Do not attempt to open, disassemble, or service the battery pack.
• Do not crush, puncture, short external contacts, or dispose of in fire or water.
• Do not expose to temperatures above 60°C (140°F).
• Replace only with the battery pack designated for this product.
• Recycle or dispose of used battery as stipulated by local regulations.
1. Align the battery’s exposed copper contacts with the battery connectors at the
bottom part of the battery compartment.
2. Insert the contacts side of the battery first and then gently push the battery
into place.
3. Replace the back cover.
1.3 Charging the Battery
New batteries are shipped partially charged. Before you start using your device,
it is recommended that you install and charge the battery. Some batteries
perform best after several full charge/discharge cycles.
Note: Only the AC adapter and USB sync cable provided with your device must

8
be used to charge the device.
Connect the USB connector of the AC adapter to the sync connector on your
device, and then plug in the AC adapter to an electrical outlet to start charging
the battery.
As the battery is being charged while the device is on, a charging icon appears
in the title bar of the Home screen. After the battery has been fully charged, a
full battery icon appears in the title bar of the Home screen.
Warning: • Do not remove the battery from the device while you are charging it
using the AC or car adapter.
• As a safety precaution, the battery stops charging before it overheats.
1.4 Starting up the device
Power on/off
To power off your phone, press & hold POWER. On release, the Phone options
menu opens. Select ‘Power off’and confirm.
To power on again, press & hold POWER.
Silent mode
To silence your phone quickly, press & hold the –volume button to zero volume.
Or on the Home screen, touch and select Settings > Sound &
notification > ‘Silent’check box.
Screen sleep
After a period of inactivity, your screen will go to sleep (display will turn black).
In sleep, your phone uses less battery power. You can control this behavior:
Set screen timeout period
1. On the Home screen, touch and select Settings.
2. Select Display > Sleep. Select a time from the menu.
Prevent sleep while charging
1. On the Home screen, then touch and select Settings.
2. Select Developer options > ‘Stay awake’check box.
Lock screen & put phone to sleep
Except when on a phone call, from any screen, press POWER (immediately).
While not on a call, to lock your control buttons and screen from accidental

9
touch activation, press POWER.
You can increase the security of your phone by setting ‘Screen lock’pattern.
Once set, in order to unlock your screen, you’ll have to draw the correct unlock
pattern. You can set your screen unlock pattern as follows:
1. On the Home screen, touch and select Settings.
2. Select Security and then scroll down to ‘Screen lock’ pattern.
3. Set or change your unlock pattern by selecting ‘Screen lock’pattern, as
applicable.
4. Follow the prompts to define your pattern.
Note: You must slide your finger along the screen to create the pattern, not
select individual dots. Connect at least four dots.
If you want your pattern to be hidden as you draw it, clear ‘Make pattern
visible’check box.
Home screen
The Home screen is your starting point for using all the applications on your
phone. You can customize your Home screen to display applications, shortcuts,
and widgets as you like.
1. The Home screen actually extends beyond the screen width. On Home screen,
slide your fingertip left and right along the screen to reveal the full width of the
Home screen. This additional space gives you more room to customize Home
with applications, shortcuts, and widgets.
2. Create Home screen shortcuts and widgets:
• On Home screen, touch MENU or touch and hold the blank screen to select
‘WIDGETS’.
• Touch and hold to pick up an Application shortcut, a Shortcut to some of your
saved information (such as a play list), a Widget (a clock or picture frame) for
your Home screen. You can place the widget slide your fingertip right along the
screen to reveal the width of the Home screen.
• The application, shortcut, folder, or widget appears on Home screen.
3. To create an application shortcut quickly, touch the application tab to reveal
all the application icons, then touch & hold an application icon. Its shortcut is
added to the Home screen.

10
4. To remove a shortcut or widget from your Home screen, touch & hold the
item to enter ‘Remove mode’. Drag the item to ‘Remove’button and release.
You’ll know when your item is in ‘Remove’because the item and the tab will
turn red.
5. Move objects on the Home screen
•To move an icon or other item on the Home screen, you must first touch &
hold it to enter ‘Remove mode’. The object will magnify when it’s ready to be
moved.
•Without lifting your finger (or you’ll drop out of remove mode), drag the
object to the new position. To move an item to a section of the Home screen not
in view, move it to the edge of the screen and hold it there for a moment. The
screen view will shift; position the object and release.
1.5 Status Icons
Connection status icons
Along the top of your phone screen is the status bar. On the left side, icons will
appear, notifying you of a new message, upcoming calendar event, or something
else you should notice. On the right side of the status bar, you’ll see connection
status icons.
Network signal
E:GSM
3G:WCDMA
4G:FDD-LTE
Sign-in/sync error
Call forward
Song is playing
Missed call
WLAN service
connected
SMS/MMS
Call in progress
Alarm is set
Wireless services are
off (Airplane mode)
Ringer is off
Phone on mute

11
Bluetooth is on
Battery is low
Connected the PC
Battery is very low!
Connected the
earphone
Battery is charging
Read your notifications
When you see a notification in the status bar, touch the bar and slide your finger
down the screen to open the list of notifications displayed in the sliding window.
Ongoing notifications report activities such as call forwarding ON, current call
status, song playing.
Notifications report the arrival of new messages, calendar events, and alarms.
You can clear notifications list by selecting ‘Clear’notifications at the bottom of
the notifications window.
To open the message, reminder, or other notification, you can touch the items.
To close the notifications window, slide your finger up the screen.
Notes: On the home screen, touch the bar and slide your finger down the
screen to open the list of notifications displayed in the sliding window, you
can touch the icon on the top of the screen to enter the shortcuts
screen, such as Airplane mode, Wi-Fi, Bluetooth, Data connection, Airplane
mode, Brightness, you can open or close the selected function directly.

12
2 Using phone features
2.1 Turning the phone function on and off
To enable or disable Airplane Mode
In many countries, you are required by law to turn off the phone while on board
an aircraft. Another way to turn off the phone function is to switch your device
to Airplane Mode.
When you enable Airplane Mode, all wireless radios on your device are turned
off, including the phone function, Bluetooth, and WLAN.
1. Touch > Settings > More > Airplane mode.
2. Touch ‘Airplane mode’to enable or disable.
When you disable Airplane mode, the phone function is turned back on and the
previous state of Bluetooth and WLAN are restored.
Adjusting the volume
Press Volume button on the side of the phone to show the volume screen.
If the phone is in vibrating mode, the voice will be muted automatically and the
device will vibrate when there is an incoming call.
2.2 Making a call
On Home screen, you can touch > Phone to enter the dial screen.
1. Touch the on-screen dial pad to enter a number, touch ‘Delete’button to
delete numbers you’ve entered. Touch & hold to delete all the numbers in the
field.
To dial a call, touch ‘Call’button to make a call.
To end a call, touch ‘End’button (Red icon).
2. On the dial screen, touch Call history tab (Recents) to show the call records,
select an entry listed in the log to call the number.
3. Also, enter Contacts that the contacts with phone numbers are listed. Select a
contact, and then select the phone number to dial the call.
2.3 Answering and Ending a call
When you receive a phone call, the incoming voice call screen will appear,
allowing you to either answer or ignore the call.
1. To answer an incoming call, slide ‘ANSWER’(Green icon) button rightward.

13
2. To reject a call, slide ‘REJECT’button (Red icon) button leftward.
2.4 In-call options
While on a call, reveal the in-call options: Speaker, Mute, Hold, End.
Note that if Bluetooth services are on and you are connected to a hands-free
device, the more menu indicator will show Bluetooth on.
1. Speaker: To use the speaker, select ‘Speaker’so it shows a green bar. To turn
it off, select it again so the bar is unfilled. The status bar will display this icon
when the speaker is on.
2. Mute: To mute your side of the conversation, select ‘Mute’so it shows a
green bar. To turn it off, select it again so the bar is unfilled. The status bar will
display this icon when Mute is on.
3. Hold: To put an active call on hold, select ‘Hold’so it shows a green bar. To
resume the call, or take the call off hold, select it again so the bar is unfilled. If
you take a call while already on a call, the first call will be placed on hold
automatically. The status bar will display this icon when a call is on hold.
4. Add call: If you need to enter numbers while on a call, touch ‘Add call’.
5. Incoming call: During call in progress, if you are on a call (“call in progress”)
when another call comes in (“incoming call”), you have a few choices:
•Answer the incoming call and place the call in progress on hold. To switch
calls at any time, touch ‘Swap calls’.
•If you don’t want to interrupt your call in progress, then touch ‘END’.
•If you have one call in progress and one caller on hold, to end both calls, touch
‘End all’.
6. While on a call, you can conference up to six callers, counting yourself. Note
that you can also have an additional caller on hold during a conference call,
regardless of how many participants are on the conference.
Note: Whether the group call function can be used depends on whether the
network operator supports and provides such function as well as whether you
have applied for such function. Please contact network operator for details.
2.5 Using call history
1. The missed call icon appears in the title bar when you missed a call.

14
2. Use ‘Call history’tab to check who the caller was, or view all your dialed
numbers, and received calls. To open ‘Call history’tab, touch ‘Call history’
button in the phone screen to enter the call history list.
3. Scroll to select the contact or number you want to dial, touch ‘Call back’
button.
4. Tap and hold the selected contact you want to call, and then you can make to
do the following options of call, edit number before call, send text message or
remove from call log phone on the shortcut menu.
2.6 Call settings
On the dialing screen, press MENU > Settings to enter Call settings menu, you
can make the operation of call settings and general settings.
3 Setting on your device
Control phone-wide settings from the Home settings screen: touch and
select Settings.
3.1 Wireless & networks
Wi -Fi
1. Select this check box if you prefer to use Wi-Fi for your data connection.
2. Wi-Fi settings: Open the Wi-Fi settings screen; select it from the network list.
Provide your username or password if required.
Bluetooth
1. Use this check box to turn Bluetooth services on or off.
2. With Bluetooth services on, you can touch MENU to open the Bluetooth
settings screen.
SIM cards
You can select to set the information of the SIM card, and activate or deactivate
data connection.
More
Airplane mode on/off: When airplane mode is selected, all wireless connectivity
is off. This icon will display in the status bar when airplane mode is
selected.

15
Mobile network
• Select data roaming capability.
• Select a wireless operator network - Scan for all available networks, or select a
network automatically.
• Add or edit network Access Point Names (APNs) - Do not change this setting
unless advised to do so by your wireless operator!
3.2 Device
Display
Brightness: Select to open the brightness control, and then slide your finger
along the brightness bar to set the level. In sunlight, increase the level.
Sleep: Select to decide how long your phone must be inactive before the screen
turns off.
Sound & notification
Select one user profile that you want and enter the following options:
Volumes: Select to open the volume control, and then slide your finger along the
volume bar to set an incoming call ring volume or alarm, playing back music,
videos.
Phone ringtones: Select to decide on a ring tone to use for incoming calls. Note
that you can override this setting for individual contacts in the Edit contact
details screens.
Default notification sound: Select a ring tone to use for a notification (e.g., new
message). Note that you can override this setting for new Calendar event
notifications, text and multimedia message notifications. Go to the applications
settings screens to select specific ring tones.
Vibrate: Select to have your phone vibrate for incoming calls.
Dial pad touch tones: Select to have a tone sound when you use the on-screen
Dialer.
Touch sound: Select to have a sound play when you select an item on the screen
either using touch.
Storage
View and manage the data storage on your phone.
Memory card: Monitor and manage the use of your Memory card from this

16
screen: 1. View how much space you are using on your memory card.
2. Select to use your memory card as USB mass storage when your phone is
connected to your computer (selected by default)
3. Unmount/eject your memory card from your phone. Note that when your
phone is connected to your computer via USB, you cannot view pictures or play
any media stored on the card from your phone.
Internal phone storage: Reports how much internal storage is free.
Apps
View all the applications stored on your phone and how much space they
occupy. If you’ve downloaded an application from Android Market, you can
uninstall it from this screen. Select a specific application to:
1. Clear your user data (if you have any associated with a particular
application).
2. Disassociate the application with any actions.
3. Uninstall - If you’ve downloaded an application from Android Market, you
will be able to uninstall it from this screen by selecting Uninstall.
3.3 Personal
Location
Select a source for determining your location.
Security
Screen unlock pattern: Create a pattern you will be asked to draw before your
screen will unlock. You can select to make the pattern visible or invisible as you
draw it.
SIM card lock settings: Lock your SIM card for extra security. You can also
change your SIM card PIN from this screen. If you don’t know your SIM PIN,
you can obtain it from your wireless operator.
Visible passwords: Select to have your password display as you type it.
Unknown sources: Select this check box if you want the ability to download
applications from the Web. With this check box not selected, you will only be
able to download applications from Android Market. To ensure your personal
data and phone remain secure; it is recommended you not select this check box.

17
Accounts
Turn on/off synchronization for all services.
Backup & reset
You can select to reset your phone to factory settings. This will erase all your
data from the phone and require you to sign in and go through the setup screens
to use any of the applications.
3.4 System
Date & time
Set time, time zone, and date: Use Automatic unless you need to override the
network values.
Time format: Select from 12 or 24 hour formats.
Date format: Select from a variety of formats.
Developer options
If you are an application developer, you may be interested in these settings:
USB debugging: If you want be able to communicate with your phone directly
via USB, select ‘USB debugging’check box.
Stay awake: To prevent your phone from sleeping while charging (via power
adapter or USB), select ‘Stay awake’check box.
About phone
View your phone Status: This screen lists a variety of information, including
your phone number, the network you are currently using, the type of network,
signal strength, whether you are roaming or not, any WLAN addresses you’re
connected to, and more.
View the model number and version information for your phone.
4 ActiveSync
4.1 Data synchronization
Some applications on your phone (Contacts and so on) give you access to the
same personal information that you can add, view, and edit on your computer
using Web applications. This means that when you add, change, or delete your
information in any of these applications on the Web, the updated information

18
also appears on your phone, and vice versa. Also, if you lose your phone or if
your phone is destroyed, your personal information is not lost and will appear,
as before, on a replacement phone.
This mirroring of information happens through over-the-air data
synchronization, or data “syncing”. Data syncing occurs in the background and
shouldn’t ever get in your way. You’ll know your data is being synchronized
when you see this icon in the status bar:
Because sending large amounts of data back and forth over the air can take time
and require considerable bandwidth, there are some settings on the phone that
allow you to control data sync.
Sync by application
To control synchronization Contacts, you can do the following:
1. On the Home screen, then touch and select Settings.
2. Select Accounts. When any of the applications are synchronizing, you will
see the “sync” icon . You will also see the last time your data was
synchronized.
3. By default, the personal information in Contacts will sync whenever you
make a change or receive a new message. You can change this behavior:
Auto-sync: When selected, Auto-sync will sync Contacts automatically, as you
make changes or receive new messages. When OFF, information will not be
synced automatically, although you can force sync by using the individual
application check boxes described below.
4. Sync problems:
If you see this icon to the left of the sync check box, then there was a
temporary problem with the data synchronization. Check your data connection
and try again later.
4.2 Bluetooth
You can use Bluetooth to send and receive calls using a headset or hands-free
car kit.
Turn on Bluetooth services
1. On the Home screen, then touch and select Settings.
2. Select Bluetooth, and then select ‘Bluetooth’check box to turn on Bluetooth

19
services.
3. When on, the Bluetooth icon appears in the status bar.
Discoverability
By default, your phone is “discoverable” when turned on the Bluetooth. This
means other Bluetooth devices will see your phone in their scans for Bluetooth
devices.
Name your Bluetooth device
1. Make sure you have turned Bluetooth on.
2. Select Settings > Bluetooth > Bluetooth settings (touch MENU)> Rename
this device.
3. Type the name for your device in the dialog box, and then select ‘OK’.
4. Your new device name appears on the Bluetooth settings screen.
Pair & connect with Bluetooth devices
Before your phone can communicate with a Bluetooth headset or hands-free car
kit, the devices must “pair”, then “connect”:
1. Make sure you have turned Bluetooth on.
2. Your phone starts scanning for Bluetooth devices within range. As they are
found, the devices appear in the list of Bluetooth devices.
3. To pair with a device in the list, select it.
4. Type the device’s PIN and then ‘Pair’.
5. Once paired, select the device name to connect.
6. Pairing and connection status appear under the device name.
7. Once the other Bluetooth device shows “connected” status, you can start
using it to make and receive phone calls.
8. To un-pair with a device, touch the icon on the side of device to open the
context menu. Select Un-pair, as appropriate. If you select ‘Un-pair’when
connected, you will be disconnected as well.
Notes: The phone supports only the headset and hands-free Bluetooth profiles,
so if you try to connect to a device that is not a headset or hands-free car kit,
then you will receive an “unable to connect” message.
If you pair with a second headset while connected to the first, the first headset
will remain connected. To switch connection to the second headset you must

20
manually select that headset again after pairing.
Rescan for Bluetooth devices
If you want to update the list of Bluetooth devices, select “Refresh”.
5 Contacts
The contacts on your phone are synced with your account contacts stored on the
Web.
To view the contacts on your phone, touch and select Contacts.
Contacts belonging to a specific group (you can choose which group) are listed
in the Contacts tab. Only those contacts you star as “favorites” are listed in the
Favorites tab. Browse through your contacts by sliding your fingertip up and
down on the screen. Another way to find a contact quickly is to use “SEARCH”
button, input the first letter of the name you’re looking for and touch search icon,
the matching contacts are appeared on the screen.
From the Contacts tab, you can:
1. Go to Contact details: Select the contact’s name to open the Contact details
screen, where all screen the information you’ve saved for this contact is
displayed.
2. Take action on a contact: On the Contact details screen, you can view call the
contact’s number, send a text message, add or remove a star or edit the contact
details.
3. On the Contact details screen, press MENU to open the context menu. From
the menu you can select to share, place on home screen, or print the contact.
Add a contact
1. On the Home screen, then touch and select Contacts. Your contact list
appears.
2. Touch the ‘+ ’icon on the right-down of the screen to add new contact.
3. Add all the information you want to store for this contact in the appropriate
fields. You must add some information to save a contact. To change a default
label, select the label name to open the label menu. Select a different label or
create a custom label. To add more fields, select ‘Add another field’.
