Introduction
Thank you for purchasing Atlantic SOL Color Changing Lighting. Atlantic’s SOL lighting features
solid brass bodies with an oil-rubbed bronze finish. These lights create a vibrant nighttime
atmosphere with 48 dierent colors and 18 dierent pre-programed color changing
combinations. Multiple fixtures can be connected to run through one transformer and be
controlled by one remote.
Prior to Operation and Installation
Caution:
• DO NOT operate this product under any conditions other than those for which it is
specified. Failure to observe these precautions can lead to electrical shock, product failure,
or other problems.
• Follow all aspects of electrical codes when installing SOL Lighting.
• To reduce the risk of electrical shock, connect transformer to a 110 volt receptacle protected
by a ground fault circuit interrupter (GFCI).
• Always verify that the lens cover is tightly secured before submersing the fixture
• Color Changing six wire quick-connect plugs carry both AC and DC current to the in-line
driver. Moisture entering the connections will allow the AC and DC current to cross which can
damage the lighting system.
• Six wire quick-connect plugs are gasketed for outdoor use and must be fully tightened to
prevent water infiltration. Quick-connect plugs are not waterproof and should not be
submersed. Dielectric grease (found in the electrical department of most home
improvement stores) should also be used in all connections to eliminate water infiltration.
• The input power to the Color Changing Control Module is 12 volt AC.
• The Control Module can be connected to a larger outdoor lighting transformer; however this
must be done on the 12 volt AC input side of Control Module. Removing the Control Module
or tampering with the cord between the Control Module and the light fixture will damage
the LEDs and void warranty.
• The Control Module is weather resistant with an IP54 rating. Do not submerse the Control
Module or expose it to heavy rainfall. It must be mounted o the ground close to the power
source. Failure to do so will void the warranty.
• A rectangular driver labeled *DO NOT REMOVE* is attached to the end of the light
cord by a quick-connect plug. The driver converts AC current from the transformer to DC
current before it is sent to the light.
• The driver may be temporarily disconnected at this junction when pulling the light cord
through a conduit sleeve or hardscape wall. Once the cord is pulled, the driver must be
reattached before connecting the light to a power source. Failure to reattach the driver will
damage the LED and void the warranty.
• Permanently removing the driver or cutting/ shortening the cord between the driver and the
light fixture will damage the LED and void the warranty
• Extension cords (part # SOLCCEXT) are available to add an additional 20’ of cord to any
SOL Light. Only one cord can be used on each light. Never connect multiple extension
cords together.
SPOTLIGHTS & LIGHT RING - SOLCC2 / SOLCC6 / SOLCCLR
Installation
SOL Spotlights oer three dierent mounting options for your convenience:
• Adjustable stand: for placement on rock ledges, under waterfalls or for
highlighting streambeds
2

3
• Ground stake: for installation around the perimeter of the water feature or
in conventional landscape installations
• Nested: without the stand or stake, amongst the pond stones
The SOL Light Ring is ideal for illuminating fountains and uplighting waterfalls.
Proper light placement is important for every project. Whenever possible, lights should be
positioned facing away from the viewing area to minimize hot spots. When camouflaging the
light cord with rocks and gravel, always leave enough slack in the cord so that the fixture can be
raised above water level for servicing.
Brass
Body
Disc Lamp Gasket Lens Slot
Brass Lens Ring
SOLCC2:
Brass Body
Brass Lens Ring
LED Bulb
Gasket Lens Slot
SOLCC6:
Maintenance
Replacement LED Bulbs are
available for SOL Spotlights and
Compact Spotlights.
To loosen and tighten the brass
lens ring on SOL Spotlights and
Compact Spotlights, use the
included key. Simply place the
key in the slots on the brass lens
ring to loosen or tighten. Ensure
that all components are installed
correctly after servicing. Inspect
the silicone gaskets for defects
and proper placement before
re-assembling. Ensure that the
lens ring is tightly secured before
submersing the fixture.
SPOUT LIGHT - SOLCCSL2
Installation
The Spout Light can be installed behind a wall, shining through a wall spout (see Figure 1) or
under a core-drilled stone or pot (see Figure 2). The light is designed to be installed in any tee
that has 1” female threads. If the tee is larger than 1”, a reducing bushing with 1” female threads
will be needed. Install the light into the tee, with the light facing the water outlet. Apply teflon
tape, paste or RTV silicone to the threads of the light and thread the light into the fitting. Do not
use the cord to twist in the light or allow it to become twisted when tightening. The spout light
cannot transmit light through sweeps or around corners. There must be a direct path for the
light to be transmitted. The use of rigid PVC plumbing (1” diameter or greater) is highly
recommended for the best results.
Figure 1.
1½” T
1½” x 1”
Reducing
bushing
Figure 2.
¾” KF tubing
1” Female
threaded T

HARDSCAPE LIGHTS - SOLCCH06 / SOLCCH12
Installation
Hardscape Wall Lights are designed to be installed
into walls and columns, just under the capstone.
The LED light strip and driver can be replaced
without removing the capstone. The cord between
the driver connection and the light is approximately
19’, enabling the driver to be left outside of the
column or wall for future access. When laying the base
course of stone, either notch the cord into the wall or
leave a notch slightly larger than ¾” to pass the cord
through. If multiple lights are going to be installed, the
notch will need to be slightly larger to accommodate
multiple cords. When installing the mounting bracket,
make sure to notch the stone for the ¼”cord. Test fit
the mounting bracket and cord, so that it does not
rock or put too much pressure on the cord. The
holes in the bracket are for glue points to hold
the capstone and bracket in place.
NOTE: Hardscape Lights are not submersible.
Maintenance
Replacement LED fixtures are available for
Hardscape Lights. Remove the screws on the
existing light, being careful not to let the light strip
fall, as this could break the plug connecting the
light to the cord. Lower the light and squeeze the
locking clip; this will allow the plug to be separated.
Plug in the new light, making sure the gasket has
not moved or shifted and that the notched edge
of the light strip is between the two ridges on the
cord gasket. Align the screw holes and hand
tighten the screws.
4
Maintenance
Replacement LED Bulbs are available for SOL Spout Lights. To loosen and tighten the brass lens
ring on SOL Spout Lights, use the included key. Simply place the key in the slots on the brass lens
ring to loosen or tighten. Ensure that all components are installed correctly after servicing. Inspect
the silicone gaskets for defects and proper placement before re-assembling. Ensure that the lens
ring is tightly secured before submersing the fixture.
SOLCCH06:
SOLCCSL2
Driver

Maintenance
Replacement LED fixtures are available for
Hardscape Lights. Remove the screws on the
existing light, being careful not to let the light strip
fall, as this could break the plug connecting the
light to the cord. Lower the light and squeeze the
locking clip; this will allow the plug to be separated.
Plug in the new light, making sure the gasket has
not moved or shifted and that the notched edge
of the light strip is between the two ridges on the
cord gasket. Align the screw holes and hand
tighten the screws.
5
WIRING KITS - SOLCCMX3 / SOLCCMX7
All SOL Color Changing LED lights and wiring components are connected via a six wire
quick-connect plug. SOL Color Changing LED Lights will not operate if plugs are aligned
incorrectly. The six pronged connectors have raised arrows that indicate proper alignment.
Color Changing six wire quick-connect plugs carry both AC and DC current to the in-line driver.
Moisture entering the connections will allow the AC and DC current to cross which can
damage the lighting system.
Six wire quick-connect plugs are gasketed for outdoor use and must be fully tightened to
prevent water infiltration. Quick-connect plugs are not waterproof and should not be
submersed. Dielectric grease (found in the electrical department of most home
improvement stores) should also be used in all connections to eliminate water infiltration.
The SOLCCMX3 wiring kit enables up to three SOL Color Changing lights (any models) to be
installed together and controlled by a single transformer, control module and remote. The
transformer must be plugged into a properly grounded GFCI outlet. Please follow the
connection diagram below for proper installation.
The SOLCCMX7 wiring kit enables up to seven SOL Color Changing LED lights (any models)
to be installed together and controlled by a single Transformer, Control Module and Remote.
Please ensure that the quick-connect plugs are properly aligned and follow the connection
diagram below for proper installation.
SOLTRANS88
CCCM01
COLOR CHANGING
CONTROL MODULE
SOLCCSPL3
3-WAY SPLITTER
SOLCCEXT
20’ EXTENSION
CORD
TRANSFORMER
CCCM01
COLOR CHANGING
CONTROL MODULE
SOLCCSPL3
3-WAY SPLITTER

6
Operation
The SOLTRANS88 has an easily
understood control panel
featuring a rotary timer control
switch, photocell and circuit
breaker / reset button.
The circuit breaker will turn o
power to the lighting system in
to case of overload / power surge.
If the circuit is tripped, inspect / repair
the lighting system and depress the reset
button to restore power. The photocell
automatically turns the transformer on
when it begins to get dark outside. The
photocell does not need to be in contact with direct sunlight; however it must have access to
indirect sunlight to operate eectively.
The timer switch provides several modes of operation. You can choose OFF, ON, AUTO, 4H, 6H,
or 8H.
OFF: Output power is o / system is o
ON: Output power is on / system is on at all times
AUTO: Photo cell will turn the output power on at
dusk and o at dawn
4H: Photo cell will turn the output power on at
dusk and it will turn o after 4 hours
6H: Photo cell will turn the output power on at
dusk and it will turn o after 6 hours
8H: Photo cell will turn the output power on at
dusk and it will turn o after 8 hours
Input Power Cord
Timer Control
Photocell Sensor
Circuit Breaker / Reset Button
AUTO
ON
OFF
4H 6H 8H
WIRING KITS - SOLTRANS88
Installation
Connect the supplied quick-connect pigtail
to the power outlet on the back of the
transformer. Loosen the screws on the
outlet terminals and slide the spade
connectors on the pigtail under the
screw plate. Tighten the screws to
secure the spade connectors.
Mount the Transformer in the desired location.
The Transformer is weather resistant and must
be mounted above the ground on a wall or post.
Ensure that the power cord is within reach of a properly
grounded Ground Fault Circuit Interrupter (GFCI) outlet.
After all connections to low voltage lights have been completed, plug the input power cord
into the 120 volt GFCI outlet to complete installation.
Spade
Connectors
Outlet Power
Terminals

Control Module
Installation
The Control Module is weather-resistant with an IP54 rating. Do not submerse it or expose it to
heavy rainfall. It must be mounted o the ground with antenna positioned vertically, close to
the power source. Failure to do so will void the warranty.
• Remove the red protective cap from the top of the control module and install the antenna.
Thread the black antenna on until snug, making sure it seals against the gasket.
• Install the control box in a well-ventilated area to ensure that the module
operates within its specified working temperature.
• Verify that the control module input voltage is 12 volt AC. We recommend that
you use the transformer provided with this unit.
• Ensure that all cable connections are secure.
• Do not connect the power before the cord connections are finished.
• Do not cut or alter the cord between the SOL Light and the Control Module.
• The remote control requires two (2) AAA batteries (not included). Do not touch the face of
the remote while inserting batteries.
Remote Control Functions
Preset Light Changing Modes
A
BO Button
CColor Wheel
DIndicator Light
EBrightness (Up)
1Continuous full spectrum
fade change
2Solid Crystal White
3Solid Red
4Solid Green
5Solid Blue
6Solid Aqua
7Solid Purple
8Solid Yellow
9Red-Green-Blue jump change
10 7 color jump change
11 Red-Green-Blue dimmer change
12 7 color dimmer change
13 7 color dimmer then
7 color jump change
14 Crystal White fade on/o
15 Flashing Red
16 Flashing Green
17 Flashing Blue
18 Flashing Red and Blue
On Button
Touch and release to turn
the lights on. Touch for
two seconds to switch
between Color Wheel and
Preset Light Changing
Modes
FBrightness (Down)
GSpeed (Up)
HSpeed (Down)
IPreset Light Changing
Mode Selection (Up)
J
Preset Light Changing
Mode Selection
(Down)
AB
CD
G
E
F
I
J
H
7

Warranty
All Atlantic SOL Color Changing Lighting carries a five-year limited warranty.
All SOL Wiring Components carry a five-year limited warranty.
Atlantic SOLTRANS88 carries a one-year limited warranty.
This limited warranty is extended solely to the original purchaser commencing from the date
on the original purchase receipt and is void if any of the following apply:
• The cord has been cut or altered between the light body and the control module.
• The light body / LED components have been misused or abused.
• The light body / LED components have been disassembled or modified other than as
described in this manual.
• The control module and/or remote control have not been adequately protected
from moisture.
This warranty excludes labor / cost of labor for removal or installation of any product.
Synchronizing the Remote to the Control Unit
If the remote control stops working properly, please install fresh batteries. If problems persist, the
remote may need to be re-synced to the control module.
Follow the instructions below to re-sync the remote control.
1. Unplug the transformer.
2. Hold the E button down (The red indicator lamp on the remote will be lit).
3. While still holding the E button down, plug in the transformer. The lights will start blinking.
• If the SOL Lights blink white three times and stops, the remote and control unit
are synchronized.
• If the SOL Lights blink white six or more times, it is clearing all codes. Repeat steps 1-3.
8
Preset Light Changing Modes
Mode Selection
• To switch to the Color Wheel: hold the A button for two seconds and the light will return to
the last color displayed while in the Color Wheel mode. Run your finger around the color
wheel to select a new color.
• To switch to the Preset Light Changing Modes: hold the A button for two seconds, and the
light will return to the last preset mode displayed while in the Light Changing Modes. Press
the I and J button to switch between the dierent preset modes.
• To switch to the Preset Light Changing Modes: hold the B button for three seconds or until the
light changes to Crystal White. Press the D button, and the light will return to the last preset
mode displayed while in the Light Changing Modes. Press the D and E button to switch
between the dierent preset modes.
Changing the Brightness and Speed
In all modes, you can use the E and F keys to change the brightness of the light. In all
modes, you can use the G and H keys to change the speed of the light transitions. There are
10 levels for each.
Troubleshooting Guide
Always turn o power before inspecting the Color Changing Lights. Failure to observe this
precaution can result in a serious accident.
Before ordering repairs, carefully read through this instruction booklet. If the problem persists,
contact your dealer.

9
Problem Possible Cause Possible Solution
Lights will not
turn on
No input power to the
transfomer Verify power to the outlet is on / Check GFCI reset
No outlet power from
the transformer
Check the reset button / circuit breaker on the
transformer
Verify if the transformer is operational by
moving the timer to the ON position
Use a volt meter to verify transformer is
producing 12 volt AC
Photocell malfunction Cover the photocell with a piece of dark tape to
check function
Lights will not
turn o
Timer control Make sure timer control is not set to the ON position
Photo cell is covered Clean sensor and outer clear covering
Make sure nothing is shading the sensor
LED color diers
from remote
control
Improper connection
between LED light and
control module
Inspect connection / align
arrow on plugs
Controller failure Contact Dealer for repair / replacement
Individual lights
within a larger
system not
working /
displaying
dierent colors
Improper connection
to 3-way splitter /
Control Module
Inspect connections / align arrows on plugs
Defective 3-way splitter Switch positions with a working light on the same
splitter to identify if the splitter is causing the issue.
Loose connection.
Moisture or corrosion
in connections
Inspect quick-connected plugs for moisture
or corrosion.
Clean/dry/apply dielectric grease and reassemble.
Failed Driver
If possible, switch out driver with one from a work-
ing light of the same model to determine if the
driver has failed.
Replacement drivers are available.
Failed LED diode/ lamp
If possible, switch out the LED diode/ lamp with
one from a working light of the same model to
determine if the driver has failed.
Replacement LED diodes/ lamps are available.
Remote is not
working (no
indicator light)
No batteries /
batteries dead Put in new batteries.
Remote is not
working (indicator
light is on)
Remote is not synced
with Control Module
Refer to synchronizing the remote instructions on
page 8.
Lights
intermittently
responding to
remote
Loose connection.
Moisture or corrosion
in connections
Inspect quick-connected plugs for moisture
or corrosion.
Clean/ dry / apply dielectric grease and reassemble.

1.330.274.8317
www.ATLANTICWATERGARDENS.com
