Aurora AU-SPT3031 Manual

IP65 LED SPOTLIGHT PACK INSTRUCTION LEAFLET
PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE INSTALLATION
LEAVE A COPY FOR THE USER / MAINTENANCE ENGINEER FOR FUTURE REFERENCE
USING THIS INSTRUCTION LEAFLET
This instruction leaflet has been designed as a general installation guide to help you install your particular outdoor
luminaire. Please pay particular attention to how your luminaire is wired. If you require any guidance or any further
information regarding your outdoor luminaire, please contact us via the details below or visit our web site.
IMPORTANT INSTALLATION INFORMATION
•Installation should be carried out in accordance with the latest edition of the I.E.E. Wiring Regulations (BS7671)
and taking into consideration the latest Building Regulations. If in doubt, consult a qualified electrician.
•Before commencing any installation or maintenance work, ensure electricity is switched off at the mains.
•Please take note of the maximum rated voltage for your luminaire.
•Please take note of the IP (Ingress Protection) rating of your luminaire when deciding location.
•Always allow sufficient slack in the supply cable in order to remove the luminaire from its position for any future
maintenance.
•Ensure that ALL electrical connections are tight with no loose strands.
IMPORTANT USER INFORMATION
•Always switch off mains supply before installation or servicing.
•These LED luminaires are NOT dimmable.
•It is recommended to clean every two to three months to preserve the finish of this product. Do not use solvents
or aggressive cleaning agents.
GENERAL INSTALLATION - SAFETY
When positioning your luminaire, please take note that outdoor electrical installations should be installed by qualified
electricians. Electrical equipment in the garden can be lethal if incorrectly installed or if inadequate provisions have been
made in the event of an equipment fault. Water is the main threat. It can seep in through joints and gaskets; it can be drawn
into electrical enclosures by capillary action; and it can penetrate ageing materials which corrode, crack or are damaged by
wildlife, pets, children, careless gardening or just time. Water conducts electricity and as the ground is usually damp to
some extent, the contact of human feet with the ground is all that is needed to provide a fatal route for electrical current.
Proper circuit protection for all exterior electrical services should include a residual current device (RCD), also known as an
earth leakage circuit breaker (ELCB). This simple device ensures that the power is cut off immediately; it detects a leakage
of current to earth, which indicates an electrical fault which is potentially threatening to life. Observe these few simple rules
and keep your outdoor electrical installation safe.
GENERAL INSTALLATION – LAYING CABLE
Laying electrical cables in the ground may be subject to specific regulations. The aim is to ensure that the cables are buried
deeply enough in the ground to avoid any disturbance which is likely to occur. Where armoured cables can be buried at
adequate depth to avoid being damaged by any reasonable foreseeable disturbance of the ground, they can be laid in a
buffer layer of sand and covered with cable warning tape. Where it is not possible to bury the cables deeply enough because
of the presence of tree roots or unsuitable ground conditions, extra mechanical protection around the cables will be
required. This is usually in the form of plastic ducts or conduits through which the cables are run.

LED LIGHT PACK
•AU-SPT3031 and AU-SPT702 packs includes:
o3 x Aluminium IP65 LED adjustable spotlights, fitted with 2m of cable
oLED Driver – Max of 3 spotlights lights per driver
o3 port connector block with 1m of cable
INSTALLATION
1. When positioning your luminaire, please take note of:
•The IP rating (See IP rating table Fig.1.)
•Beware of existing water pipes and electric cables when preparing the site.
2. The LED Driver can be positioned outside but is fitted with 13A mains plug and must be powered from an internal
circuit.
3. Connect the 3 port connector to the LED Driver.
4. Install the Spotlights in the desired location, 2m maximum from the 3 port connector.
5. Connect the plug on the end of the luminaire cable into the socket on the 3 port connector block. Screw down the
locking ring tight to prevent any water from getting into conductors.
6. Connect the 13A plug from the LED controller to the mains supply.
7. Wipe clean surfaces, turn on mains supply and test kit.
ENVIRONMENTAL PROTECTION (W.E.E.E.) – AURORA’S WEEE REG.NO. WEE/BG0130YX
Waste Electrical & Electronic Equipment Regulations (WEEE) requires that any of our products showing this
marking (left) must not be disposed of with other household or commercial waste. Aurora does not levy any
WEEE disposal charges to its customers for affected WEEE related products. To prevent possible harm to the
environment or human health from uncontrolled waste disposal, please separate any such product from
other waste types and recycle it responsibly at your local facilities. Check with your Local Authority,
Recycling Centre or retailer for recycling advice. If, when you purchased any Aurora product, your supplier included a
WEEE disposal fee, you should then contact your supplier for advice on his takeback of the product for the correct
disposal.
GUARANTEE
This product is guaranteed in the UK for a period of 1 year from the date of purchase, unless otherwise stated in
current company literature. The guarantee is invalid in the case of improper use, installation, tampering, removal of the
Q.C. date label, installation in an improper working environment or installation not according to the current edition of
the I.E.E. Wiring Regulations (BS7671). Should this product fail during the guarantee period, it will be replaced free of
charge, subject to correct installation and return of the faulty unit. Aurora does not accept responsibility for any
installation costs associated with the replacement of this product. Your statutory rights are not affected. Aurora
reserves the right to alter specifications without prior notice.
Aurora Limited 16 Alban Park Hatfield Road St Albans Hertfordshire AL4 0JJ United Kingdom
Website: www.aurora.eu.com
Document version - AU-LED_SPOTLIGHT_KIT_V1_11
If the external flexible cable or cord of this luminaire is
damaged, it shall be exclusively replaced by the manufacturer
or his service agent or a similar qualified person in order to
avoid a hazard.
Warning
