INSTALLATION INSTRUCTIONS
AA-SMG
SOUND MASKING MODULE
AA-SMG INSTRUCTIONS
Thank you for purchasing the Atlas Sound AA-SMG masking module. Please read this instruction sheet
carefully prior to use to assure a clear understanding of the flexibility the AA120M and AA-SMG offers you.
Prior to using any Atlas Sound module please read the AA120M manual prior to use. It is very important for
one to know the difference between Amp Direct and Mix Bus modes.
KEY FEATURES
1. Gain Trim – When the gain is set to max (Clockwise), it is designed that the 70v output will not exceed
30v. When fully attenuated the module will have a 1v or less at the 70v outputs
2. EQ Trim– The EQ filter operating range is between 1 KHz and 8 kHz with a slope of 6db per octave.
When the potentiometer is rotated fully clockwise the variable Hi-Cut filter is at 8 kHz.
3. EQ Insert – This TRS insert jack allows you to use an external equalizer for fine tuning of the system.
Tip = Send to the EQ, Ring = Return from the EQ and Sleeve is the ground.
4. Line Out – This feature allows you use the generator to send a signal to another amplifier for
multizone masking. You have the selection of two signal pick up points, Pre EQ or Post EQ. The Pre
EQ is a fixed level of 250mv. The Gain, EQ or Insert jack have no effect on the Line Output. If Post EQ
is selected, the Line Out signal is affected by the Gain level, EQ setting and the Insert Jack. In Post
EQ mode the Line Out signal is the same signal that the AA120M is receiving.
5. Post or Pre EQ (jumper J11) – This is for the Line Out jack signal. To select this function, prior to
inserting the module into the amplifier, locate (jumper J11) header and place the jumper to the desired
selection. Note: You only need to move the jumper one pin over for connection. The middle pin is
always connected.
6. Pink and White Noise selection (jumper J5)- Reposition the jumper for desired signal type. The
middle pin is always connected.
7. Amp Direct and Mixed Bus (jumper J10) – This selection determines the master gain feeding the
amplifier. It also works in conjunction with Input 6 module selection switch position 5 located on the
rear panel of the AA120M. We suggest when using the AA-SMG module, the amp and module and
AA120M are set to the Amp Direct position. The middle pin is always connected.
8. Out to Amp (jumper J8) – If you do not want the AA-SMG signal to go to the AA-120M and want to
use the module to feed an external amplifier set this jumper to the OFF position.

Specifications are subject to change without notice
AtlasSound.com
1601 JACK MCKAY BOULEVARD ENNIS, TEXAS 75119 U.S.A. • TELEPHONE: [phone] • FAX: [phone]
©2007 ATLAS SOUND LP Printed in U.S.A. ATS002745 RevA 3/07 2
INSTALLATION INSTRUCTIONS
AA-SMG
SOUND MASKING MODULE
SET UP - PRIOR TO INSTALLING THE AA-SMG MODULE, YOU MUST DECIDE THE FOLLOWING.
1. Select White or Pink Noise (jumper J6)
2. Select Amp Direct or Mix Bus operation (jumper J7).
3. Turn the module gain pot down counter clockwise (Left direction).
4. Turn EQ pot clockwise (Right direction).
5. Turn the AA120M power switch off.
6. Carefully inset the AA-SMG module into the card guider rails. Push until card is seated and the panels
are flush. Secure with screws.
7. Select the AA120M input module mode, switch #5 located on the rear panel of the amp.
8. Turn all levels down on amplifier. Note if the module is in Amp Direct mode, the only level control you
have for masking is the Gain pot on the AA-SMG. The Master and Input 6 levels on the AA120M are
bypassed. All other channels operate normally.
9. Turn the amp on. You should be hearing either White or Pink noise.
10. Whenever connecting the Line Out or Insert jack, always turn off the AA120M prior to connection.
11. Tune the system as needed. Always a good suggestion to refer to Atlas’s white paper on masking.
GAIN
EQ
LINE OUT
EQ INSERT
AA-SMG
TIP=SND
RNG-REC
SLV=GND
OUT TO AMP
J8
OFF ON
J11
PRE EQ
POST EQ
J10
AMP DIRECT
MIX BUS
J5
WHITEPINK
LINE OUT
2
1
4
3
5
6
7
8
TIP
(SEND)
RING
(REC)
SLEEVE
(GND)
CONNECT TO
AA-SMG
SEND - CONNECT
TO EQ IN
TIP
(REC)
SLEEVE
(GND)
RECEIVE - CONNECT
TO EQ OUT
TIP
(SEND)
SLEEVE
(GND)
TIP
(HOT)
(GND)

Specifications are subject to change without notice
AtlasSound.com
1601 JACK MCKAY BOULEVARD ENNIS, TEXAS 75119 U.S.A. • TELEPHONE: [phone] • FAX: [phone]
©2007 ATLAS SOUND LP Printed in U.S.A. ATS002745 RevA 3/07 3
INSTALLATION INSTRUCTIONS
AA-SMG
SOUND MASKING MODULE
GRAPH #1
#1 AA-SMG – This graph illustrates the comparison of the Line Out White Noise vs. Pink Noise with no EQ
by passed.
GRAPH #2
#2 This graph shows the 70v tap output waveform of the AA120M with the AA-SMG in White Noise mode. The
graph comparison is indicating the EQ trim engaged (Counterclockwise) or disengaged (Clockwise). Note:
This graph also indicates the bandwidth of the AA-SMG through the AA120M amplifier and 70v transformer.

Specifications are subject to change without notice
AtlasSound.com
1601 JACK MCKAY BOULEVARD ENNIS, TEXAS 75119 U.S.A. • TELEPHONE: [phone] • FAX: [phone]
©2007 ATLAS SOUND LP Printed in U.S.A. ATS002745 RevA 3/07 4
INSTALLATION INSTRUCTIONS
AA-SMG
SOUND MASKING MODULE
GRAPH #3
#3 This graph shows the 70v tap output waveform of the AA120M with the AA-SMG in Pink Noise mode. The
graph comparison is indicating the EQ trim engaged (Counterclockwise) or disengaged (Clockwise). Note:
This graph also indicates the bandwidth of the AA-SMG through the AA120M amplifier and 70v transformer.
AA-SMG SPECIFICATIONS:
Filter Selection: White, Pink Noise
Gain Controls: 70v output AA120, 1v minimum – 30v maximum
Input Connection: EQ insert via TRS 1⁄4” jack.
Line Output: RCA Unbalanced, Pre EQ fixed 300mV, Post EQ variable 60mv – 1.4V
EQ Control: Variable Low Cut 1KHz – 7KHZ, defeatable on Line Out
Supply Voltage: 24 VDC, 30 mA internally derived from AA120M amplifier
Panel Finish: Silver
Dimensions: 1.38” W., x 3” H. x 3” D. (35X78X78 mm)
